Axle: Removal & Installation Lexus LS IV

REMOVAL

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

1. REMOVE FRONT WHEEL
2. DISCONNECT SPEED SENSOR CONNECTOR Remove the 2 bolts and disconnect the connector from the speed sensor. NOTE: Do not twist the speed sensor wire.
3. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH Remove the bolt and disconnect the flexible hose from the steering knuckle. Remove the 2 bolts and front disc brake caliper assembly LH. NOTE: Hang the front disc brake caliper assembly with a rope or wire. Do not damage the brake hose.
4. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
5. REMOVE FRONT DISC BRAKE DUST COVER LH Remove the 4 bolts and front disc brake dust cover LH.
6. DISCONNECT TIE ROD ASSEMBLY LH (See «REMOVAL»(ref-349733-S36942300362009120800000) )
7. DISCONNECT FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH Remove the clip and nut. Install 2 spacers (SST spacer A) onto the front No. 1 suspension lower arm assembly LH so that there is a space of approximately 1 mm between the arm and spacers. SST 09960-20010 (0996+1-02050) NOTE: Make sure to install the spacers (SST spacer A) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm or less. Using SST, disconnect the No. 1 suspension arm from the steering knuckle. SST 09960-20010 (09961-02010) NOTE: Do not damage the dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.
8. DISCONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH Remove the bolt, and then remove the bracket of the front height control sensor LH.
9. REMOVE FRONT STABILIZER LINK ASSEMBLY LH Remove the 2 nuts and front stabilizer link assembly LH. HINT: If the stud bolt turns with the nut, use a 6 mm hexagon wrench to hold the stud.
10. DISCONNECT FRONT SHOCK ABSORBER ASSEMBLY LH Remove the bolt and nut, and then disconnect the bottom side of the front shock absorber assembly LH from the front No. 2 suspension lower arm LH.
11. DISCONNECT FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH SST 09960-20010 (09961-02010, 09961-02050) Remove the clip and nut. Install 2 spacers (SST spacer A) onto the front No. 2 suspension lower arm assembly LH so that there is a space of approximately 1 mm between the arm and spacers. SST 09960-20010 (09961-02050) NOTE: Make sure to install the spacers (SST spacer A) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm or less. Using SST, disconnect the front No. 2 suspension lower arm from the steering knuckle. SST 09960-20010 (09961-02010) NOTE: Do not damage the dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.
12. REMOVE STEERING KNUCKLE SUB-ASSEMBLY LH SST 09960-20010 (09961-02060, 09961-02010) Support the steering knuckle LH with a jack and wooden block. Remove the 2 clips and 2 nuts. Install 2 spacers (SST spacer B) onto the front No. 1 suspension upper arm assembly LH so that there is a space of approximately 1 mm between the arm and spacers. SST 09960-20010 (09961-02060) NOTE: Make sure to install the spacers (SST spacer B) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm or less. Using SST, disconnect the front No. 1 suspension upper arm from the steering knuckle. SST 09960-20010 (09961-02010) NOTE: Do not damage the dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping. Install 2 spacers (SST spacer B) onto the front No. 2 suspension upper arm assembly LH so that there is a space of approximately 1 mm between the arm and spacers. SST 09960-20010 (09961-02060) NOTE: Make sure to install the spacers (SST spacer B) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm or less. Using SST, disconnect the front No. 2 suspension upper arm from the steering knuckle. SST 09960-20010 (09961-02010) NOTE: Do not damage the dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.
13. REMOVE FRONT AXLE HUB SUB-ASSEMBLY LH Remove the 4 bolts and front axle hub from the steering knuckle.

INSTALLATION

HINT

Scheme 21

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (SS-2).

Scheme 22

1. INSTALL FRONT AXLE HUB SUB-ASSEMBLY LH Install the front axle hub to the steering knuckle with the 4 bolts. Torque: 65 N*m (663 kgf*cm, 48 ft.*lbf)
2. INSTALL STEERING KNUCKLE SUB-ASSEMBLY LH Install the steering knuckle to the front No. 1 suspension upper arm LH and front No. 2 suspension upper arm LH with the nuts. Torque: 60 N*m (612 kgf*cm, 44 ft.*lbf) Install new clips. NOTE: If it is necessary to align the holes for the clips after installing the nuts, the nuts can be tightened up to 60° more.
3. CONNECT FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH Connect the front No. 2 suspension lower arm assembly LH to the steering knuckle with the nut. Torque: 145 N*m (1479 kgf*cm, 107 ft.*lbf) Install a new clip. NOTE: If it is necessary to align the holes for the clip after installing the nut, the nut can be tightened up to 60° more.
4. CONNECT FRONT SHOCK ABSORBER ASSEMBLY LH Install the bottom side of the front shock absorber assembly LH to the No. 2 suspension lower arm LH. Then insert the bolt from the rear of the vehicle and temporarily install it with the nut. Torque: 108 N*m (1101 kgf*cm, 80 ft.*lbf)
5. INSTALL FRONT STABILIZER LINK ASSEMBLY LH Install the front stabilizer link with the 2 nuts. Torque: 84 N*m (857 kgf*cm, 62 ft.*lbf) HINT: If the ball joint turns together with the nut, use a hexagon (6 mm) wrench to hold the stud.
6. CONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH Install the bracket of the front height control sensor LH to the front No. 2 suspension lower arm LH with the bolt. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf)
7. CONNECT FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH Connect the No. 1 suspension lower arm to the steering knuckle with the nut. Torque: 145 N*m (1479 kgf*cm, 107 ft.*lbf) Install a new clip. NOTE: If it is necessary to align the holes for the clip after installing the nut, the nut can be tightened up to 60° more.
8. CONNECT TIE ROD ASSEMBLY LH (See «INSTALLATION»(ref-349733-S30676435532009120800000) )
9. INSTALL FRONT DISC BRAKE DUST COVER LH Install the front disc brake dust cover LH with the 4 bolts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf)
10. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
11. CONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH Install the front disc brake caliper assembly LH to the steering knuckle with the new 2 bolts. Torque: 135 N*m (1377 kgf*cm, 100 ft.*lbf) NOTE: Do not twist the flexible hose. Make sure the screw parts are free from foreign matter and are not damaged. Be careful not to overtighten the bolts, as the steering knuckle is made of aluminum. Connect the flexible hose to the steering knuckle with the bolt. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf)
12. CONNECT SPEED SENSOR CONNECTOR Connect the speed sensor connector to the speed sensor. NOTE: Do not damage the tip of the speed sensor. Do not allow foreign matter to contact the tip or installation area of the speed sensor. Do not twist the speed sensor wire. Install the speed sensor wire to the front No. 1 suspension lower arm with the 2 bolts. Torque: 8.5 N*m (87 kgf*cm, 75 in.*lbf)
13. INSTALL FRONT WHEEL Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf)
14. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT Inspect and adjust the front wheel alignment (SP-5).
15. CHECK ABS SPEED SENSOR SIGNAL Check the speed sensor signal (BC-47).
16. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight aiming (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 23

Scheme 24

Scheme 25

1. REMOVE FRONT WHEEL
2. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
3. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
4. INSPECT FRONT AXLE HUB BEARING LOOSENESS Using a dial indicator, measure the looseness near the center of the axle hub. Maximum: 0.05 mm (0.00197 in.) NOTE: Ensure that the dial indicator is set at a right angle to the measurement surface. If the looseness exceeds the maximum, replace the axle hub.
5. INSPECT FRONT AXLE HUB RUNOUT Using a dial indicator, measure the runout on the surface of the axle hub outside the hub bolt. Maximum: 0.05 mm (0.00197 in.) NOTE: Ensure that the dial indicator is set at a right angle to the measurement surface. If the runout exceeds the maximum, replace the axle hub.
6. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
7. CONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
8. INSTALL FRONT WHEEL Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf)

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. REMOVE FRONT WHEEL
2. REMOVE FRONT AXLE SHAFT NUT LH Using SST and a hammer, release the staked part of the front axle shaft nut. SST 09930-00010 NOTE: Release the staked part of the nut completely, otherwise the threads of the drive shaft may be damaged.
3. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH Remove the bolt and disconnect the flexible hose from the steering knuckle. Remove the 2 bolts and disconnect front disc brake caliper. NOTE: Hang the front disc brake caliper assembly with a rope or wire. Do not damage the brake hose.
4. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
5. REMOVE FRONT DISC BRAKE DUST COVER LH Remove the 4 bolts and dust cover.
6. DISCONNECT SKID CONTROL SENSOR WIRE Disconnect the front speed sensor connector. NOTE: Do not twist the skid control sensor wire. Remove the bolt and sensor clamp.
7. REMOVE FRONT SPEED SENSOR LH Remove the bolt and speed sensor from the steering knuckle. NOTE: Do not damage the tip of the speed sensor. Do not allow foreign matter to contact the tip or installation area of the speed sensor.
8. DISCONNECT TIE ROD ASSEMBLY LH Remove the clip and nut. Install 2 spacers (SST spacer B) onto the tie rod assembly LH so that there is a space of approximately 1 mm (0.0394 in.) between the arm and spacers. SST 09960-20010 (09961-02060) NOTE: Make sure to install the spacers (SST spacer B) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not less than 1 mm (0.0394 in.). Using SST, disconnect the tie rod assembly from the steering knuckle. SST 09960-20010 (09961-02010) NOTE: Do not damage the dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and claw are the parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.
9. DISCONNECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH Remove the clip and nut. Install 2 spacers (SST spacer B) onto the front No. 1 suspension upper arm assembly LH so that there is a space of approximately 1 mm (0.0394 in.) between the arm and spacers. SST 09960-20010 (09961-02060) NOTE: Make sure to install the spacers (SST spacer B) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not less than 1 mm (0.0394 in.). Using SST, disconnect the front No. 1 suspension upper arm from the steering knuckle. SST 09960-20010 (09961-02010) NOTE: Do not damage the dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and claw are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.
10. DISCONNECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH Remove the clip and nut. Install 2 spacers (SST spacer B) onto the front No. 2 suspension upper arm assembly LH so that there is a space of approximately 1 mm (0.0394 in.) between the arm and spacers. SST 09960-20010 (09961-02060) NOTE: Make sure to install the spacers (SST spacer B) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not less than 1 mm (0.0394 in.). Using SST, disconnect the front No. 2 suspension upper arm from the steering knuckle. SST 09960-20010 (09961-02010) NOTE: Do not damage the dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and claw are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.
11. REMOVE STEERING KNUCKLE SUB-ASSEMBLY LH Remove the 3 bolts. Then disconnect the steering knuckle from the front lower ball joint. Using a plastic-faced hammer, lightly tap the end of the front drive shaft to remove the front axle hub and steering knuckle from the front drive shaft. HINT: If the spline connection is tight, using a brass bar and hammer, tap the front drive shaft. While supporting the drive shaft, remove the steering knuckle LH. NOTE: Do not damage the drive shaft outboard joint boot. Suspend the drive shaft assembly with a rope or wire. Be careful when handling or installing the drive shaft as bending or sliding the drive shaft excessively may cause the tripod joint to come out of its groove.
12. REMOVE FRONT AXLE HUB SUB-ASSEMBLY LH Remove the 4 bolts and front axle hub from the steering knuckle.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (See «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. INSTALL FRONT AXLE HUB SUB-ASSEMBLY LH Install the front axle hub to the steering knuckle with the 4 bolts. Torque: 65 N*m (663 kgf*cm, 48 ft.*lbf)
2. INSTALL STEERING KNUCKLE SUB-ASSEMBLY LH Connect the splines of the steering knuckle LH and drive shaft assembly. Install the steering knuckle to the front lower ball joint with the 3 bolts. Torque: 113 N*m (1149 kgf*cm, 83 ft.*lbf)
3. CONNECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH Install the steering knuckle to the front No. 1 suspension upper arm with the nut. Torque: 60 N*m (612 kgf*cm, 44 ft.*lbf) Install new clips. NOTE: If it is necessary to align the holes for the clips after installing the nuts, the nuts can be tightened up to 60° more.
4. CONNECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH Install the steering knuckle to the front No. 2 suspension upper arm with the nut. Torque: 60 N*m (612 kgf*cm, 44 ft.*lbf) Install new clips. NOTE: If it is necessary to align the holes for the clips after installing the nuts, the nuts can be tightened up to 60° more.
5. CONNECT TIE ROD ASSEMBLY LH Connect the tie rod to the steering knuckle with the nut. Torque: 60 N*m (612 kgf*cm, 44 ft.*lbf) Install new clips. NOTE: If it is necessary to align the holes for the clips after installing the nuts, the nuts can be tightened up to 60° more.
6. INSTALL FRONT SPEED SENSOR LH Install the speed sensor to the steering knuckle with the bolt. Torque: 8.5 N*m (87 kgf*cm, 75 in.*lbf) NOTE: Do not damage the tip of the speed sensor. Do not allow foreign matter to contact the tip or installation area of the speed sensor.
7. CONNECT SKID CONTROL SENSOR WIRE Connect the front speed sensor connector. Install the sensor clamp to the steering knuckle LH with the bolt. Torque: 8.5 N*m (87 kgf*cm, 75 in.*lbf) NOTE: Do not twist the skid control sensor wire.
8. INSTALL FRONT DISC BRAKE DUST COVER LH Install the front disc brake dust cover with the 4 bolts. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf)
9. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
10. CONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH Install the front disc brake caliper to the steering knuckle with 2 new bolts. Torque: 135 N*m (1377 kgf*cm, 100 ft.*lbf) NOTE: Do not twist the flexible hose. Make sure the threaded parts are free from foreign matter and are not damaged. Be careful not to overtighten the bolts, as the steering knuckle is made of aluminum. Connect the flexible hose to the steering knuckle with the bolt. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf)
11. INSTALL FRONT AXLE SHAFT NUT LH Clean the threaded parts on the drive shaft and axle shaft nut using a non-residue solvent. NOTE: Be sure to perform this work for a new drive shaft. Keep the threaded parts free of oil and foreign objects. Using a 30 mm socket wrench, install a new axle shaft nut. Torque: 294 N*m (2998 kgf*cm, 217 ft.*lbf) NOTE: Do not stake the shaft nut. HINT: Stake the shaft nut after the axle hub bearing looseness and axle hub runout inspections.
12. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
13. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
14. INSPECT FRONT AXLE HUB BEARING LOOSENESS (See «ON-VEHICLE INSPECTION»(ref-349749-S22093808772009120800000) )
15. INSPECT FRONT AXLE HUB RUNOUT (See «ON-VEHICLE INSPECTION»(ref-349749-S22093808772009120800000) )
16. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
17. CONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH Install the front disc brake caliper to the steering knuckle with 2 new bolts. Torque: 135 N*m (1377 kgf*cm, 100 ft.*lbf) NOTE: Do not twist the flexible hose. Make sure the threaded parts are free from foreign matter and are not damaged. Be careful not to overtighten the bolts, as the steering knuckle is made of aluminum. Connect the flexible hose to the steering knuckle with the bolt. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf)
18. STAKE FRONT AXLE SHAFT NUT LH Using a chisel and hammer, stake the front axle shaft nut.
19. INSTALL FRONT WHEEL Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf)
20. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT Inspect and adjust the front wheel alignment (See «FRONT WHEEL ALIGNMENT (FOR 2WD)»(ref-349722-S22862354252009120800000) ).
21. CHECK ABS SPEED SENSOR SIGNAL Check the speed sensor signal (See «TEST MODE PROCEDURE»(ref-349740-S02170830312009120800000) ).
22. ADJUST VEHICLE HEIGHT Adjust the vehicle height (See «ADJUSTMENT»(ref-349750-S01070563512009120800000) ).
23. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 46

1. INSPECT STEERING KNUCKLE BALL JOINT RATTLE Jack up the vehicle. Move the front No. 2 suspension lower arm up and down by hand, and check for rattle. OK: No rattle.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

1. REMOVE FRONT WHEEL
2. DISCONNECT SPEED SENSOR CONNECTOR LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
3. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
4. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
5. REMOVE FRONT DISC BRAKE DUST COVER LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
6. DISCONNECT TIE ROD ASSEMBLY LH (See «REMOVAL»(ref-349733-S36942300362009120800000) )
7. DISCONNECT FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
8. DISCONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
9. REMOVE FRONT STABILIZER LINK ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
10. DISCONNECT FRONT SHOCK ABSORBER ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
11. DISCONNECT FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
12. REMOVE STEERING KNUCKLE SUB-ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )
13. REMOVE FRONT AXLE HUB SUB-ASSEMBLY LH (See «REMOVAL»(ref-349749-S38905054652009120800000) )

Scheme 47

1. INSPECT STEERING KNUCKLE SUB-ASSEMBLY LH Temporarily install the nut, and flip the ball joint stud back and forth 5 times as shown in the illustration. Use a torque wrench to turn the nut continuously at a rate of 3 to 5 seconds per turn. Take the torque reading on the fifth turn. Standard turning torque: 0.5 to 6.0 N*m (5 to 61 kgf*cm, 4 to 53 in.*lbf) If the value is not within the specified range, replace the steering knuckle with a new one. Check the dust boot for cracks or grease leakage.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (See «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

1. INSTALL FRONT AXLE HUB SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
2. INSTALL STEERING KNUCKLE SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
3. CONNECT FRONT NO. 2 SUSPENSION LOWER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
4. CONNECT FRONT SHOCK ABSORBER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
5. INSTALL FRONT STABILIZER LINK ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
6. CONNECT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
7. CONNECT FRONT NO. 1 SUSPENSION LOWER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
8. CONNECT TIE ROD ASSEMBLY LH (See «INSTALLATION»(ref-349733-S30676435532009120800000) )
9. INSTALL FRONT DISC BRAKE DUST COVER LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
10. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
11. CONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
12. CONNECT SPEED SENSOR CONNECTOR LH (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
13. INSTALL FRONT WHEEL
14. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT (See «INSTALLATION»(ref-349749-S39253153892009120800000) )
15. CHECK ABS SPEED SENSOR SIGNAL Check the speed sensor signal (See «TEST MODE PROCEDURE»(ref-349740-S02170830312009120800000) ).
16. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

1. REMOVE FRONT WHEEL
2. REMOVE FRONT AXLE SHAFT NUT LH (See «ON-VEHICLE INSPECTION»(ref-349749-S22093808772009120800000) )
3. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
4. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
5. REMOVE FRONT DISC BRAKE DUST COVER LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
6. DISCONNECT SKID CONTROL SENSOR WIRE (See «REMOVAL»(ref-349749-S15701984032009120800000) )
7. REMOVE FRONT SPEED SENSOR LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
8. DISCONNECT TIE ROD ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
9. DISCONNECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
10. DISCONNECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
11. REMOVE STEERING KNUCKLE SUB-ASSEMBLY LH Remove the 3 bolts. Then disconnect the steering knuckle from the front lower ball joint. Using a plastic-faced hammer, lightly tap the end of the front drive shaft to remove the front axle hub and steering knuckle from the front drive shaft. HINT: If the spline connection is tight, using a brass bar and hammer, tap the front drive shaft.
12. REMOVE FRONT AXLE HUB SUB-ASSEMBLY LH Remove the 4 bolts and front axle hub from the steering knuckle.

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (See «SPECIFIED TORQUE FOR STANDARD BOLTS»(ref-349708-S13378942112009120800000) ).

1. INSTALL FRONT AXLE HUB SUB-ASSEMBLY LH Install the front axle hub to the steering knuckle with the 4 bolts. Torque: 65 N*m (663 kgf*cm, 48 ft.*lbf)
2. INSTALL STEERING KNUCKLE SUB-ASSEMBLY LH Install the steering knuckle to the front lower ball joint with the 3 bolts. Torque: 113 N*m (1149 kgf*cm, 83 ft.*lbf)
3. CONNECT FRONT NO. 1 SUSPENSION UPPER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
4. CONNECT FRONT NO. 2 SUSPENSION UPPER ARM ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
5. CONNECT TIE ROD ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
6. INSTALL FRONT SPEED SENSOR LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
7. CONNECT SKID CONTROL SENSOR WIRE (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
8. INSTALL FRONT DISC BRAKE DUST COVER LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
9. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
10. CONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
11. INSTALL FRONT AXLE SHAFT NUT LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
12. DISCONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S15701984032009120800000) )
13. REMOVE FRONT DISC (See «REMOVAL»(ref-349719-S21827681662009120800000) )
14. INSPECT FRONT AXLE HUB BEARING LOOSENESS (See «ON-VEHICLE INSPECTION»(ref-349749-S22093808772009120800000) )
15. INSPECT FRONT AXLE HUB RUNOUT (See «ON-VEHICLE INSPECTION»(ref-349749-S22093808772009120800000) )
16. INSTALL FRONT DISC (See «INSTALLATION»(ref-349719-S33447390982009120800000) )
17. CONNECT FRONT DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
18. STAKE FRONT AXLE SHAFT NUT LH (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
19. INSTALL FRONT WHEEL (See «INSTALLATION»(ref-349749-S19109048572009120800000) )
20. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT Inspect and adjust the front wheel alignment (See «FRONT WHEEL ALIGNMENT (FOR 2WD)»(ref-349722-S22862354252009120800000) ).
21. CHECK ABS SPEED SENSOR SIGNAL Check the speed sensor signal (See «TEST MODE PROCEDURE»(ref-349740-S02170830312009120800000) ).
22. ADJUST VEHICLE HEIGHT Adjust the vehicle height (See «ADJUSTMENT»(ref-349750-S01070563512009120800000) ).
23. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).

Scheme 48

Scheme 49

Scheme 50

1. REMOVE REAR WHEEL
2. REMOVE REAR DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S08887431922009120800000) )
3. REMOVE REAR DISC (See «REMOVAL»(ref-349719-S20561870172009120800000) )
4. REMOVE REAR AXLE LH HUB BOLT Using SST, remove the rear axle hub bolt. SST 09650-17011
5. INSTALL REAR AXLE LH HUB BOLT Install a washer and nut to a new bolt as shown in the illustration. Using a screwdriver or an equivalent to hold the hub and bearing, install the rear axle hub bolt by tightening the nut. NOTE: Do not damage the threads of the hub bolts.
6. INSTALL REAR DISC (See «INSTALLATION»(ref-349719-S30633082262009120800000) )
7. ADJUST PARKING BRAKE SHOE CLEARANCE (See «ADJUSTMENT»(ref-349711-S26260822612009120800000) )
8. INSTALL REAR DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S36272118122009120800000) )
9. INSTALL REAR WHEEL Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf)

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

1. REMOVE REAR WHEEL
2. DISCONNECT REAR DISC BRAKE CALIPER ASSEMBLY LH (See «REMOVAL»(ref-349749-S08887431922009120800000) )
3. REMOVE REAR DISC (See «REMOVAL»(ref-349719-S20561870172009120800000) )
4. INSPECT REAR AXLE HUB BEARING LOOSENESS Using a dial indicator, check for looseness near the center of the axle hub. Maximum: 0.05 mm (0.0020 in.) NOTE: Ensure that the dial indicator is set at a right angle to the measurement surface. If the looseness exceeds the maximum, replace the axle hub.
5. INSPECT REAR AXLE HUB RUNOUT Using a dial indicator, check for runout on the surface of the axle hub outside the hub bolt. Maximum: 0.05 mm (0.0020 in.) NOTE: Ensure that the dial indicator is set at a right angle to the measurement surface. If the runout exceeds the maximum, replace the axle hub.
6. INSTALL REAR DISC (See «INSTALLATION»(ref-349719-S30633082262009120800000) )
7. ADJUST PARKING BRAKE SHOE CLEARANCE (See «ADJUSTMENT»(ref-349711-S26260822612009120800000) )
8. CONNECT REAR DISC BRAKE CALIPER ASSEMBLY LH (See «INSTALLATION»(ref-349749-S36272118122009120800000) )
9. INSTALL REAR WHEEL Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf)

HINT

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

1. REMOVE REAR WHEEL
2. REMOVE LOAD SENSING VALVE SENSOR BRACKET Remove the bolt and load sensing valve sensor bracket from the toe control link sub-assembly.
3. DISCONNECT REAR STABILIZER LINK ASSEMBLY LH Remove the bolt and nut, and then disconnect the rear stabilizer link assembly LH from the rear No. 2 suspension arm assembly LH.
4. REMOVE REAR AXLE SHAFT LH NUT Using SST and a hammer, release the staked part of the rear axle shaft LH nut. SST 09930-00010 NOTE: Release the staked part of the nut completely, otherwise the screw of the drive shaft may be damaged. While applying the brakes, remove the rear axle shaft LH nut.
5. DISCONNECT REAR DISC BRAKE CALIPER ASSEMBLY LH Remove the 2 bolts and separate the rear disc brake caliper assembly. NOTE: Hang the caliper with wire or equivalent. Do not damage the brake hose.
6. DISCONNECT SPEED SENSOR REAR LH Remove the 2 bolts and rear speed sensor.
7. REMOVE REAR DISC (See «REMOVAL»(ref-349719-S20561870172009120800000) )
8. REMOVE NO. 2 PARKING BRAKE SHOE RETURN TENSION SPRING (See «DISASSEMBLY»(ref-349711-S28130262752009120800000) )
9. REMOVE NO. 1 PARKING BRAKE SHOE RETURN TENSION SPRING (See «DISASSEMBLY»(ref-349711-S28130262752009120800000) )
10. REMOVE PARKING BRAKE SHOE ADJUSTING SCREW SET LH (See «DISASSEMBLY»(ref-349711-S28130262752009120800000) )
11. REMOVE NO. 1 PARKING BRAKE SHOE ASSEMBLY LH (See «DISASSEMBLY»(ref-349711-S28130262752009120800000) )
12. REMOVE NO. 2 PARKING BRAKE SHOE ASSEMBLY LH (See «DISASSEMBLY»(ref-349711-S28130262752009120800000) )
13. REMOVE PARKING BRAKE SHOE LEVER LH (See «DISASSEMBLY»(ref-349711-S28130262752009120800000) )
14. DISCONNECT REAR SHOCK ABSORBER ASSEMBLY LH (for Coil suspension) (See «REMOVAL»(ref-349722-S36340836592009120800000) )
15. DISCONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH (for Air suspension) (See «REMOVAL»(ref-349722-S36340836592009120800000) )
16. REMOVE REAR NO. 2 SUSPENSION ARM ASSEMBLY LH Using a plastic-faced hammer or equivalent, strike the part labeled A from the rear of the vehicle to maintain the clearance at the slide pin area. Remove the nut, washer, bolt and No. 2 suspension arm from the axle carrier. Remove the nut, rear suspension attachment sub-assembly, and rear No. 2 suspension toe adjust plate. Then remove the rear No. 2 suspension arm assembly.
17. DISCONNECT REAR NO. 1 SUSPENSION ARM ASSEMBLY LH Remove the nut from the rear No. 1 suspension arm. Install 2 spacers (SST spacer B) onto the rear No. 1 suspension arm so that there is a space of approximately 1 mm between the arm and spacers. SST 09960-20010 (09961-02060) NOTE: Make sure to install the spacers (SST spacer B) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm or less. Using SST, disconnect the rear No. 1 suspension arm from the axle carrier. SST 09960-20010 (09961-02010) NOTE: Do not damage the ball joint dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.
18. DISCONNECT TOE CONTROL LINK SUB-ASSEMBLY LH Remove the nut on the rear axle carrier side. Install 2 spacers (SST spacer B) onto the toe control link so that there is a space of approximately 1 mm between the arm and spacers. SST 09960-20010 (09961-02060) NOTE: Make sure to install the spacers (SST spacer B) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm or less. Using SST, disconnect the toe control link from the axle carrier. SST 09960-20010 (09961-02010) NOTE: Do not damage the ball joint dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.
19. DISCONNECT REAR UPPER NO. 1 CONTROL ARM ASSEMBLY LH Remove the nut on the rear axle carrier side. Install 2 spacers (SST spacer A) onto the rear upper No. 1 control arm so that there is a space of approximately 1 mm between the arm and spacers. SST 09960-20010 (09961-02050) NOTE: Make sure to install the spacers (SST spacer A) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm or less. Using SST, disconnect the upper No. 1 control arm from the axle carrier. SST 09960-20010 (09961-02010) NOTE: Do not damage the ball joint dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.
20. DISCONNECT REAR UPPER NO. 2 CONTROL ARM ASSEMBLY LH Remove the nut on the rear axle carrier side. Install 2 spacers (SST spacer A) onto the rear upper No. 2 control arm so that there is a space of approximately 1 mm between the arm and spacers. SST 09960-20010 (09961-02050) NOTE: Make sure to install the spacers (SST spacer A) as the steering knuckle spacer may shift. As SST may become damaged, make sure the space between the arm and spacers is not 1 mm or less. Using SST, disconnect the upper No. 2 control arm from the axle carrier. SST 09960-20010 (09961-02010) NOTE: Do not damage the ball joint dust cover. As the dust cover may be damaged, adjust SST with the center nut so that the body and crow are parallel. Make sure to tie the string of SST to the vehicle to prevent SST from dropping.
21. REMOVE REAR AXLE ASSEMBLY LH Using a plastic-faced hammer, separate the drive shaft from the rear axle carrier sub-assembly. Remove the rear axle assembly. NOTE: Be careful not to damage the boots. Use a wire or an equivalent to keep the rear drive shaft assembly from hanging down.
22. REMOVE REAR NO. 1 WHEEL BEARING DUST DEFLECTOR LH Using a screwdriver, remove the bearing dust deflector from the rear axle carrier. NOTE: Be careful not to dent or damage the axle carrier, as it is made of aluminum.
23. REMOVE REAR AXLE HUB AND BEARING ASSEMBLY LH Hold the axle hub and bearing in a vise between aluminum plates. NOTE: Do not overtighten the vise. Remove the 4 bolts and axle hub and bearing from the rear axle carrier. Remove the 2 nuts, parking brake anchor block, parking brake cable support bracket, and parking brake plate from the rear axle carrier.

HINT

Scheme 70

1. Use the same procedures for the RH side and LH side.
2. The procedures listed below are for the LH side.
3. A bolt without a torque specification is shown in the standard bolt chart (SS-2).

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. INSTALL REAR AXLE HUB AND BEARING ASSEMBLY LH Install the parking brake plate, cable support bracket and parking brake anchor block to the rear axle carrier with the 2 nuts. Torque: 76 N*m (775 kgf*cm, 56 ft.*lbf) Hold the axle hub and bearing in a vise between aluminum plates. NOTE: Do not overtighten the vise. Install the axle hub and bearing to the rear axle carrier with the 4 bolts. Torque: 97 N*m (989 kgf*cm, 72 ft.*lbf)
2. INSTALL REAR NO. 1 WHEEL BEARING DUST DEFLECTOR LH Using SST and a hammer, install the No. 1 bearing dust deflector to the rear axle carrier. SST 09950-70010 (09951-07150), 09951-01000 HINT: Align the hole for the speed sensor in the No. 1 bearing dust deflector with the rear axle carrier.
3. INSTALL REAR AXLE ASSEMBLY LH Engage the spline part of the rear axle carrier to the spline part of the driver shaft assembly. Using a jack, lift up the rear axle carrier, and align the installation positions of each arm. NOTE: Place a wooden block between the jack and rear axle carrier to prevent damage.
4. TEMPORARILY CONNECT REAR SHOCK ABSORBER ASSEMBLY LH (for Coil suspension) (See «INSTALLATION»(ref-349722-S11477672232009120800000) )
5. TEMPORARILY CONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH (for Air suspension) (See «INSTALLATION»(ref-349722-S11477672232009120800000) )
6. CONNECT REAR UPPER NO. 1 CONTROL ARM ASSEMBLY LH Connect the control arm with a new nut to the axle carrier. Torque: 160 N*m (1632 kgf*cm, 118 ft.*lbf)
7. CONNECT REAR UPPER NO. 2 CONTROL ARM ASSEMBLY LH Connect the control arm with a new nut to the axle carrier. Torque: 160 N*m (1632 kgf*cm, 118 ft.*lbf)
8. CONNECT TOE CONTROL LINK SUB-ASSEMBLY LH Connect the control link with a new nut to the axle carrier. Torque: 118 N*m (1203 kgf*cm, 87 ft.*lbf)
9. TEMPORARILY TIGHTEN REAR NO. 2 SUSPENSION ARM ASSEMBLY LH Install the stud of the suspension arm, and temporarily install a washer, nut and the bolt to the axle carrier. Temporarily install the No. 2 suspension arm with the No. 2 suspension toe adjust plate, rear suspension attachment and nut to the suspension member.
10. CONNECT REAR NO. 1 SUSPENSION ARM ASSEMBLY LH Connect the suspension arm with a new nut to the axle carrier. Torque: 118 N*m (1203 kgf*cm, 87 ft.*lbf)
11. APPLY HIGH TEMPERATURE GREASE (See «REASSEMBLY»(ref-349711-S27450328232009120800000) )
12. INSTALL PARKING BRAKE SHOE LEVER LH (See «REASSEMBLY»(ref-349711-S27450328232009120800000) )
13. INSTALL NO. 1 PARKING BRAKE SHOE ASSEMBLY LH (See «REASSEMBLY»(ref-349711-S27450328232009120800000) )
14. INSTALL NO. 2 PARKING BRAKE SHOE ASSEMBLY LH (See «REASSEMBLY»(ref-349711-S27450328232009120800000) )
15. INSTALL PARKING BRAKE SHOE ADJUSTING SCREW SET LH (See «REASSEMBLY»(ref-349711-S27450328232009120800000) )
16. INSTALL NO. 1 PARKING BRAKE SHOE RETURN TENSION SPRING (See «REASSEMBLY»(ref-349711-S27450328232009120800000) )
17. INSTALL NO. 2 PARKING BRAKE SHOE RETURN TENSION SPRING (See «REASSEMBLY»(ref-349711-S27450328232009120800000) )
18. CHECK PARKING BRAKE INSTALLATION (See «REASSEMBLY»(ref-349711-S27450328232009120800000) )
19. INSTALL REAR AXLE SHAFT LH NUT Install a new rear axle shaft nut. Torque: 290 N*m (2957 kgf*cm, 214 ft.*lbf)
20. INSPECT REAR AXLE HUB BEARING LOOSENESS (See «ON-VEHICLE INSPECTION»(ref-349749-S13595269672009120800000) )
21. INSPECT REAR AXLE HUB RUNOUT (See «ON-VEHICLE INSPECTION»(ref-349749-S13595269672009120800000) )
22. INSTALL REAR DISC (See «INSTALLATION»(ref-349719-S30633082262009120800000) )
23. ADJUST PARKING BRAKE SHOE CLEARANCE (See «ADJUSTMENT»(ref-349711-S26260822612009120800000) )
24. CONNECT SPEED SENSOR REAR LH Install the rear speed sensor with the 2 bolts. Torque: 8.5 N*m (87 kgf*cm, 75 in.*lbf)
25. CONNECT REAR DISC BRAKE CALIPER ASSEMBLY LH Connect the rear disc brake caliper assembly LH with new 2 bolts. Torque: 86 N*m (877 kgf*cm, 63 ft.*lbf) NOTE: Do not twist the flexible hose. Make sure the screw parts are free from foreign matter and are not damaged. Be careful not to overtighten the bolts, as the rear axle carrier is made of aluminum.
26. STAKE REAR AXLE SHAFT LH NUT Using a chisel and a hammer, stake the axle shaft nut.
27. INSTALL LOAD SENSING VALVE SENSOR BRACKET Install the load sensing valve sensor bracket to the toe control link sub-assembly with the bolt. Torque: 3.6 to 6.9 N*m (37 to 70 kgf*cm, 32 to 61 in.*lbf)
28. STABILIZE SUSPENSION (for Coil Suspension) (See «INSTALLATION»(ref-349722-S37097628642009120800000) )
29. STABILIZE SUSPENSION (for Air Suspension) (See «INSTALLATION»(ref-349722-S27364139402009120800000) )
30. CONNECT REAR SHOCK ABSORBER ASSEMBLY LH (for Coil suspension) (See «INSTALLATION»(ref-349722-S11477672232009120800000) )
31. CONNECT PNEUMATIC CYLINDER WITH REAR SHOCK ABSORBER ASSEMBLY LH (for Air suspension) (See «INSTALLATION»(ref-349722-S11477672232009120800000) )
32. CONNECT REAR STABILIZER LINK ASSEMBLY LH Insert the bolt from the front of the vehicle. Then install the rear stabilizer link assembly LH with the nut. Torque: 26 N*m (265 kgf*cm, 19 ft.*lbf)
33. TIGHTEN REAR NO. 2 SUSPENSION ARM ASSEMBLY LH Tighten the nut on the rear suspension member side. Torque: 150 N*m (1530 kgf*cm, 111 ft.*lbf) Tighten the nut on the rear axle carrier side. Torque: 225 N*m (2294 kgf*cm, 166 ft.*lbf)
34. INSTALL REAR WHEEL Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf)
35. PERFORM PARKING BRAKE SHOE BEDDING Perform parking brake shoe bedding (See «INITIALIZATION»(ref-349711-S26535095002009120800000) ).
36. INSPECT AND ADJUST REAR WHEEL ALIGNMENT (See «INSPECTION»(ref-349722-S28566524042009120800000) )
37. CHECK ABS SPEED SENSOR SIGNAL Check the speed sensor signal (See «TEST MODE PROCEDURE»(ref-349740-S02170830312009120800000) ).
38. ADJUST HEADLIGHT ASSEMBLY Adjust the headlight (See «ADJUSTMENT»(ref-349731-S09246046722009120800000) ).
