TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| Flexible Hose-To-Brake Caliper | 29 (39) |
| Brake Line To Master Cylinder | 11 (15) |
| Brake Pedal Push Rod Lock Nut | 19 (26) |
| Front Brake Caliper Installation Bolts | 81 (110) |
| Rear Anchor Block-To-Backing Plate | 56 (76) |
| Rear Brake Caliper Installation Bolts | 58 (78) |
| Wheel Lug Nut | 76 (103) |
| INCH Lbs. (N.m) |
| Master Cylinder Installation Nuts | 115 (13) |
| Parking Brake Cable Sub-Assembly | 53 (6) |
| Parking Brake Lock Nut | 53 (6) |
| Parking Brake Pedal Assembly | 115 (13) |
| Reservoir Set Screws | 16 (2) |
DISC BRAKE SPECIFICATIONS
| Application | In. (mm) |
|---|
| Brake Pad Thickness |
| Front |
| Standard | .433 (11) |
| Minimum | .039 (1.0) |
| Rear |
| Standard | .394 (10.0) |
| Minimum | .039 (1.0) |
| Front Disc |
| Standard Thickness | 1.181 (30) |
| Minimum Thickness | 1.102 (28) |
| Disc Runout (1) | .002 (.05) |
| Rear Disc |
| Standard Thickness | .630 (16) |
| Minimum Thickness | .571 (14.5) |
| Disc Runout (1) | .002 (.05) |
| Rear Disc Parking Brake Drum (2) |
| Drum Diameter | 7.48 (190) |
| Maximum Diameter | 7.52 (191) |
| Parking Brake Shoe Lining Thickness (3) |
| Standard Thickness | .138 (3.5) |
| Minimum Thickness | .039 (1.0) |
| (1) Measured .39 in. (10 mm) from outer edge of rotor. (2) This is the drum for the parking brake on the inside of the rear disc. (3) This is brake lining for the parking brake on the inside of the rear disc. |
| (1) | Measured .39 in. (10 mm) from outer edge of rotor. |
| (2) | This is the drum for the parking brake on the inside of the rear disc. |
| (3) | This is brake lining for the parking brake on the inside of the rear disc. |
DISC BRAKE SPECIFICATIONS
Scheme 1
Scheme 2
