PRECAUTION

Note. When the negative (-) battery terminal is disconnected, initialize the following system after the terminal is reconnected.

Scheme 59

Scheme 59: PRECAUTION

Scheme 60

Scheme 60: LOCATION

Scheme 61

Scheme 61: SYSTEM DIAGRAM

Scheme 62

Scheme 62

Input and output signals of each ECU.

Scheme 63

Scheme 63

Scheme 64

Scheme 64: SYSTEM DESCRIPTION

Scheme 65

Scheme 65

Scheme 66

Scheme 66

Scheme 67

Scheme 67
  1. GENERAL The steering lock system consists of a starter switch, interlock cable, steering lock actuator, and steering lock ECU. The steering lock ECU is built into the steering lock actuator. This system is provided in models with a smart key system.
  2. STEERING LOCK ECU The steering lock ECU is integrated with the immobilizer ECU and controls both steering lock and engine immobilizer. The theft deterrent ECU checks the ID code of the ignition key and transmits its signal to the steering lock ECU. Then, the steering lock ECU transmits an engine start authorization signal to the ECM and a motor activation signal to the steering lock motor.
  3. STARTER SWITCH The starter switch consists of a starter switch knob and a rotor. The tip of the interlock cable is fitted into the groove on the rotor. When the starter switch knob is turned, the rotor turns, pulling on the interlock cable fitted into the rotor groove.
  4. STEERING LOCK ACTUATOR The steering lock actuator consists of a steering lock motor, gear, cam, steering lock bar, and starter switch lock lever. In the steering lock system, the steering lock motor operates in accordance with signals from the steering lock ECU. This causes the gear to rotate as well as the cam that is integrated with the gear, and the cam pushes the steering lock bar up, disengaging it from the steering lock holder.
  5. INTERLOCK CABLE The steering lock actuator and the starter switch are connected by the interlock cable and thereby they operates as shown in the figure (Scheme 66) below.
