Headlamp Protector Retainer Lexus LS III рестайлинг

Exterior Lights 8 illustrations ~341 words

REPLACEMENT

HINT

  1. Use the same procedures for the RH side and LH side.
  2. The procedures listed below are for the LH side.
  3. To minimize damage to the headlamp unit in case of a collision, the stays for the headlamp unit have been constructed to break off. The stays are available as supply parts for low-cost repair.

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41

Scheme 42

Scheme 42
Scheme 42

Scheme 43

Scheme 43
Scheme 43

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45

Scheme 46

Scheme 46
Scheme 46
  1. REMOVE ENGINE UNDER COVER NO. 1 (SEE «ON-VEHICLE INSPECTION» )
  2. REMOVE FRONT FENDER LINER LB (SEE «ON-VEHICLE INSPECTION» )
  3. REMOVE FRONT FENDER LINER RH (SEE «ON-VEHICLE INSPECTION» )
  4. REMOVE FRONT BUMPER COVER (SEE «ON-VEHICLE INSPECTION» )
  5. REMOVE LH HEADLAMP ASSY (SEE «ADJUSTMENT»(/lexus/ls/iii-2003-2006/remont/exterior-lights/#headlamps) )
  6. INSTALL HEADLAMP LH BRACKET Cut off the part shaded in the illustration and sand smooth with sandpaper. NOTE: After cutting off the part, place the headlamp LH bracket against the bosses and gradually file away until installation is possible. Install the headlamp LH bracket with the 2 screws.
  7. INSTALL HEADLAMP RH BRACKET Cut off the part shaded in the illustration and sand smooth with sandpaper. NOTE: After cutting off the part, place the headlamp RH bracket against the bosses and gradually file away until installation is possible. Install the headlamp RH bracket with the 2 screws.
  8. INSTALL HEADLAMP PROTECTOR RETAINER UPPER LH Cut off the part shaded in the illustration and sand smooth with sandpaper. NOTE: After cutting off the part, place the headlamp protector retainer UPPER LH against the bosses and gradually file away until installation is possible. Install the headlamp protector retainer UPPER LH with the 2 screws.
  9. INSTALL HEADLAMP PROTECTOR RETAINER LWR LH Cut off the part shaded in the illustration and sand smooth with sandpaper. NOTE: After cutting off the part, place the headlamp protector retainer LWR LH against the bosses and gradually file away until installation is possible. Install the headlamp protector retainer LWR LH with the 2 screws.
  10. HEADLIGHT AIM ONLY (SEE ADJUSTMENT )
  11. ADJUST FOG LIGHT AIM (SEE «ADJUSTMENT»(/lexus/ls/iii-2003-2006/remont/exterior-lights/#fog-lamps) )
