Audio & Visual System: Removal & Installation Lexus LS III рестайлинг

Entertainment Systems 65 illustrations ~4108 words

REPLACEMENT

HINT

Scheme 135

Scheme 135: REPLACEMENT
Scheme 135: REPLACEMENT

Scheme 136

Scheme 136
Scheme 136

Scheme 137

Scheme 137
Scheme 137
  1. SEE: «COMPONENTS».
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal.
  4. Set to "SHIP" mode to prevent mechanical damage due to any impacts when the radio is transported. Attach the label shown below to the top of the product case so as not to skip any procedure and to follow the procedure correctly.

Scheme 138

Scheme 138
Scheme 138

Scheme 139

Scheme 139
Scheme 139

Scheme 140

Scheme 140
Scheme 140

Scheme 141

Scheme 141
Scheme 141
  1. SHIP MODE SETTING Take out all CDs. NOTE: If the CDs cannot be taken out, do not attempt to take out forcibly. Send the unit for repair.
  2. Turn the ignition switch to the OFF position.
  3. While holding the "UP" and "DISC" switches, turn the ignition switch to the ACC position. HINT: The CD indicator light blinks during the mode setting and remains lit after the setting is completed. w/o Multi-display:When the mode setting is completed, "SHIP" appears on the display. Turn the ignition switch to the OFF position and disconnect the battery negative terminal. NOTE: Connecting the battery negative terminal automatically ends the ship mode.
  4. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER CENTER (SEE «REPLACEMENT» )
  5. REMOVE PANEL INSTRUMENT CLUSTER FINISH LOWER (SEE «REPLACEMENT» )
  6. REMOVE RADIO RECEIVER ASSEMBLY W/BRACKET w/o Multi-display: Remove the 2 bolts and disengage the 5 clips. w/ Multi-display: Remove the 2 bolts. w/ Multi-display: Disengage the 2 clips and 4 claws. Disconnect the connector and remove the radio receiver assembly with bracket.
  7. SHIP MODE CONFIRMATION See the back side of the radio receiver assy and check that the window provided for mode checking is red. NOTE: If the window is not red, perform the ship mode setting again.
  8. REMOVE RADIO RECEIVER ASSY Remove the 4 screws and 2 brackets from the radio receiver assembly.
  9. INSTALL RADIO RECEIVER ASSEMBLY W/BRACKET Make sure that the battery negative terminal is disconnected. NOTE: Radio receiver with CD changer: If the connector is installed with the battery connected, the system will start initialization. Vibration during initialization may cause problems in the radio receiver assy. Connect the connector. Install the radio receiver assembly with the 2 bolts.

HINT

  1. SEE: «COMPONENTS»
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal.

Scheme 142

Scheme 142
Scheme 142

Scheme 143

Scheme 143
Scheme 143

Scheme 144

Scheme 144
Scheme 144
  1. SHIP MODE SETTING (SEE «RADIO RECEIVER ASSY» )
  2. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER CENTER (SEE «REPLACEMENT» )
  3. REMOVE PANEL INSTRUMENT CLUSTER FINISH LOWER (SEE «REPLACEMENT» )
  4. REMOVE RADIO RECEIVER ASSEMBLY W/BRACKET (SEE «RADIO RECEIVER ASSY» )
  5. SHIP MODE CONFIRMATION (SEE «RADIO RECEIVER ASSY» )
  6. REMOVE TEMPERATURE CONTROL SWITCH ASSY Disengage the 2 claws. Disconnect the connector and remove the temperature control switch assembly. Perform the same procedure on the other side.
  7. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY CENTER Remove the 4 bolts. Disengage the 4 clips. NOTE: In order to prevent the safety pad from being damaged, do not pry with a screwdriver or similar tool Disconnect the connector and remove the instrument cluster finish panel sub-assy center.
  8. REMOVE MULTI-DISPLAY Remove the 4 screws and multi-display. HINT: After the replacement, perform the screen noise automatic adjustment when screen noise occurs (SEE «POWER SOURCE CIRCUIT (STEREO COMPONENT AMPLIFIER ASSY)» ).

HINT

  1. SEE: «COMPONENTS»
  2. SEE: «LOCATION»
  3. Installation is in the reverse order of removal.

Scheme 145

Scheme 145
Scheme 145

Scheme 146

Scheme 146
Scheme 146

Scheme 147

Scheme 147
Scheme 147

Scheme 148

Scheme 148
Scheme 148
  1. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (SEE «REPLACEMENT» )
  2. REMOVE DECK TRIM SIDE BOARD RH (SEE «REPLACEMENT» )
  3. REMOVE REAR FLOOR FINISH PLATE (SEE «REPLACEMENT» )
  4. SEPARATE LUGGAGE COMPARTMENT TRIM COVER FRONT (SEE «REPLACEMENT» )
  5. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY RH (SEE «REPLACEMENT» )
  6. REMOVE NAVIGATION ECU W/BRACKET Disconnect the connector. Remove the 2 nuts and navigation ECU with bracket.
  7. REMOVE NAVIGATION ECU W/BRACKET Remove the 2 screws. Remove the navigation ECU with bracket along the guide as shown in the illustration. Remove the 4 screws and 2 brackets. HINT: After the replacement, perform the screen noise automatic adjustment when screen noise occurs (SEE «POWER SOURCE CIRCUIT (STEREO COMPONENT AMPLIFIER ASSY)» ).

HINT

Installation is in the reverse order of removal.

Scheme 149

Scheme 149: REPLACEMENT
Scheme 149: REPLACEMENT

Scheme 150

Scheme 150
Scheme 150

Scheme 151

Scheme 151
Scheme 151
  1. REMOVE RR SEAT CTR ARMREST PANEL Remove the 2 rear seat back covers. Remove the 2 screws and disconnect the rear seat armrest board. Remove the 3 screws. Disengage the 12 claws and remove the rear seat center armrest panel.
  2. REMOVE RADIO SWITCH AND VOLUME ASSY Disconnect the connector. Remove the 6 screws and radio switch and volume assy.

HINT

  1. SEE: «COMPONENTS»
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal.

Scheme 152

Scheme 152
Scheme 152

Scheme 153

Scheme 153
Scheme 153

Scheme 154

Scheme 154
Scheme 154

Scheme 155

Scheme 155
Scheme 155

Scheme 156

Scheme 156
Scheme 156

Scheme 157

Scheme 157
Scheme 157
  1. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (SEE «REPLACEMENT» )
  2. REMOVE DECK TRIM SIDE BOARD RH (SEE «REPLACEMENT» )
  3. REMOVE REAR FLOOR FINISH PLATE Remove the 2 bolts and 2 hooks. Remove the 5 clips. Disengage the 4 clips and remove the rear floor finish plate.
  4. SEPARATE LUGGAGE COMPARTMENT TRIM COVER FRONT Remove the 3 clips and luggage compartment trim cover front.
  5. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY RH Remove the bolt and hook. Remove the 4 clips and luggage compartment trim cover assy RH.
  6. REMOVE NAVIGATION ECU W/BRACKET (W/ LEXUS NAVIGATION SYSTEM) (SEE «NAVIGATION ECU» )
  7. REMOVE STEREO COMPONENT TUNER ASSY W/BRACKET (W/O LEXUS NAVIGATION SYSTEM) Disconnect the connector. Remove the 2 nuts and stereo component tuner assy with bracket.
  8. REMOVE STEREO COMPONENT TUNER ASSY W/BRACKET (W/ LEXUS NAVIGATION SYSTEM) Disconnect the connector. Remove the nut and stereo component tuner assy with bracket.
  9. REMOVE STEREO COMPONENT TUNER ASSY Remove the 4 screws and 2 brackets.

HINT

  1. SEE: «COMPONENTS».
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal.

Scheme 158

Scheme 158
Scheme 158
  1. REMOVE REAR COMBINATION LAMP SERVICE COVER RH (SEE «REPLACEMENT» )
  2. REMOVE REAR COMBINATION LAMP SERVICE COVER LH (SEE «REPLACEMENT» )
  3. REMOVE LUGGAGE COMPARTMENT LAMP ASSY NO.1 (SEE «REPLACEMENT» )
  4. REMOVE BACK DOOR TRIM COVER (SEE «REPLACEMENT» )
  5. REMOVE LUGGAGE OPENER CANCEL CYLINDER & KEY SET (SEE «REPLACEMENT» )
  6. REMOVE LUGGAGE DOOR OPENING SWITCH ASSY (SEE «REPLACEMENT» )
  7. REMOVE LUGGAGE COMPARTMENT DOOR GARNISH SUB-ASSY OUTSIDE (SEE «REPLACEMENT» )
  8. REMOVE TELEVISION CAMERA ASSY Disconnect the connector. Remove the 2 bolts and television camera assy.
  9. INSTALL TELEVISION CAMERA ASSY Install the television camera assy with the 2 bolts. Connect the connector.

HINT

  1. SEE: «COMPONENTS»
  2. SEE: «LOCATION»
  3. Installation is in the reverse order of removal.

Scheme 159

Scheme 159
Scheme 159
  1. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (SEE «REPLACEMENT» )
  2. REMOVE DECK TRIM SIDE BOARD RH (SEE «REPLACEMENT» )
  3. REMOVE REAR FLOOR FINISH PLATE (SEE «REPLACEMENT» )
  4. SEPARATE LUGGAGE COMPARTMENT TRIM COVER FRONT (SEE «REPLACEMENT» )
  5. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY RH (SEE «REPLACEMENT» )
  6. REMOVE TELEVISION CAMERA ECU Disconnect the connector and remove the bolt. Pull out the television camera ECU along the stereo component amplifier assy guide toward the rear of the vehicle to remove it. If the television camera ECU is not easily removed due to a lack of space between the television camera ECU and the vehicle, remove the television camera ECU together with the stereo component amplifier assy (SEE «STEREO COMPONENT AMPLIFIER ASSY» ).
  7. INSTALL TELEVISION CAMERA ECU Install the television camera ECU by aligning it with the stereo component amplifier assy guide, and tighten the bolt. Connect the connector. HINT: After the replacement, perform the screen noise automatic adjustment when screen noise occurs (SEE «POWER SOURCE CIRCUIT (STEREO COMPONENT AMPLIFIER ASSY)» ).

HINT

  1. SEE: «COMPONENTS».
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal.

Scheme 160

Scheme 160
Scheme 160

Scheme 161

Scheme 161
Scheme 161

Scheme 162

Scheme 162
Scheme 162
  1. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (SEE «REPLACEMENT» )
  2. REMOVE DECK TRIM SIDE BOARD RH (SEE «REPLACEMENT» )
  3. REMOVE REAR FLOOR FINISH PLATE (SEE «REPLACEMENT» )
  4. SEPARATE LUGGAGE COMPARTMENT TRIM COVER FRONT (SEE «REPLACEMENT» )
  5. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY RH (SEE «REPLACEMENT» )
  6. REMOVE TELEVISION CAMERA ECU (W/ TELEVISION CAMERA) (SEE «TELEVISION CAMERA ECU» )
  7. REMOVE STEREO COMPONENT AMPLIFIER ASSY W/BRACKET Disconnect the connector. Remove the 2 nuts. Disengage the 2 clips and remove the stereo component amplifier assy with bracket.
  8. REMOVE STEREO COMPONENT AMPLIFIER ASSY Mark levinson system: Remove the 6 screws and 2 brackets. Non-mark levinson system: Remove the 5 screws and 2 brackets.

HINT

  1. SEE: «ADJUSTMENT».
  2. SEE: «LOCATION»
  3. Installation is in the reverse order of removal.
  4. The procedure for the left side is the same as that for the right side. The procedure for right side is shown below.

Scheme 163

Scheme 163
Scheme 163
  1. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSY (SEE «OVERHAUL» )
  2. REMOVE FRONT DOOR INSIDE HANDLE BEZEL RH (SEE «OVERHAUL» )
  3. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY RH (SEE «OVERHAUL» )
  4. REMOVE FRONT NO.1 SPEAKER ASSY Disconnect the connector. Disengage the 2 clips. Remove the 3 screws and front No.1 speaker assy.

HINT

  1. SEE: «ADJUSTMENT»
  2. SEE: «LOCATION»
  3. Installation is in the reverse order of removal.
  4. The procedure for the left side is the same as that for the right side. The procedure for right side is shown below.

Scheme 164

Scheme 164
Scheme 164
  1. REMOVE SIDE TRIM BOARD COVER FRONT RH (SEE «OVERHAUL» )
  2. REMOVE SIDE REAR CURTAIN ASSY RH (W/ REAR CURTAIN SUB-ASSY) (SEE «OVERHAUL» )
  3. REMOVE POWER WINDOW REGULATOR SWITCH ASSY REAR (SEE «OVERHAUL» )
  4. REMOVE REAR DOOR INSIDE HANDLE BEZEL RH (SEE «OVERHAUL» )
  5. REMOVE REAR DOOR TRIM BOARD SUB-ASSY RH (SEE «OVERHAUL» )
  6. REMOVE REAR SPEAKER ASSY Disconnect the connector. Remove the 3 screws and rear speaker assy.

HINT

  1. SEE: «COMPONENTS (FRONT SEATS)»(/lexus/ls/iii-2003-2006/remont/seats/#front-seat) , «COMPONENTS (REAR SEAT FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type) and «COMPONENTS (REAR SEAT POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type)
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal.

Scheme 165

Scheme 165
Scheme 165
  1. REMOVE REAR SEAT CUSHION ASSY RH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  2. REMOVE REAR SEAT CUSHION ASSY LH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  3. REMOVE REAR SEAT BACK ASSY RH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  4. REMOVE REAR SEAT BACK ASSY LH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  5. REMOVE REAR DOOR SCUFF PLATE RH (SEE «OVERHAUL» )
  6. REMOVE REAR DOOR SCUFF PLATE LH (SEE «OVERHAUL» )
  7. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH (SEE «OVERHAUL» )
  8. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH (SEE «OVERHAUL» )
  9. REMOVE REAR SEAT SIDE COVER RH (SEE «OVERHAUL» )
  10. REMOVE REAR SEAT SIDE COVER LH (SEE «OVERHAUL» )
  11. REMOVE ROOF SIDE GARNISH INNER RH (SEE «OVERHAUL» )
  12. REMOVE ROOF SIDE GARNISH INNER LH (SEE «OVERHAUL» )
  13. REMOVE CENTER STOP LAMP ASSY (SEE «OVERHAUL» )
  14. REMOVE REAR SPEAKER GRILLE SUB-ASSY (SEE «OVERHAUL» )
  15. REMOVE PACKAGE TRAY TRIM PANEL ASSY (SEE «OVERHAUL» )
  16. REMOVE STEREO COMPONENT SPEAKER ASSY REAR Disconnect the connector. Remove the 4 screws and stereo component speaker assy rear.

HINT

  1. SEE: «LOCATION».
  2. Installation is in the reverse order of removal.

Scheme 166

Scheme 166
Scheme 166
  1. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY (SEE «REPLACEMENT» )
  2. REMOVE FRONT NO.2 SPEAKER ASSY Disconnect the connector. Disengage the clip. Remove the 2 nuts and front No.2 speaker assy. Perform the same procedure on the other side.

HINT

  1. SEE: «ADJUSTMENT»
  2. SEE: «LOCATION»
  3. Installation is in the reverse order of removal.
  4. The procedure for the left side is the same as that for the right side. The procedure for right side is shown below.

Scheme 167

Scheme 167
Scheme 167
  1. REMOVE SIDE TRIM BOARD COVER FRONT RH (SEE «OVERHAUL» )
  2. REMOVE SIDE REAR CURTAIN ASSY RH (W/ REAR CURTAIN SUB-ASSY) (SEE «OVERHAUL» )
  3. REMOVE POWER WINDOW REGULATOR SWITCH ASSY REAR (SEE «OVERHAUL» )
  4. REMOVE REAR DOOR INSIDE HANDLE BEZEL RH (SEE «OVERHAUL» )
  5. REMOVE REAR DOOR TRIM BOARD SUB-ASSY RH (SEE «OVERHAUL» )
  6. REMOVE REAR SPEAKER ASSY NO.2 Disconnect the connector. Remove the 3 screws and rear speaker assy No.2.

HINT

  1. SEE: «LOCATION».
  2. Installation is in the reverse order of removal.

Scheme 168

Scheme 168
Scheme 168
  1. REMOVE MAP LAMP ASSY (SEE «REPLACEMENT»(/lexus/ls/iii-2003-2006/remont/exterior-lights/#headlamp-protector-retainer__replacement) )
  2. REMOVE MICROPHONE ASSY Disconnect the connector. Remove the screw. Peel the adhesive tape and remove the microphone assy.

HINT

  1. SEE: «LOCATION».
  2. Installation is in the reverse order of removal.

Scheme 169

Scheme 169
Scheme 169

Scheme 170

Scheme 170
Scheme 170
  1. REMOVE MAP LAMP ASSY (SEE «REPLACEMENT»(/lexus/ls/iii-2003-2006/remont/exterior-lights/#headlamp-protector-retainer__replacement) )
  2. REMOVE MICROPHONE ASSY (SEE «MICROPHONE ASSY» )
  3. REMOVE MICROPHONE AMPLIFIER ASSY Remove the screw. Disconnect the connector as shown in the illustration, and remove the microphone amplifier assy.
  4. INSTALL MICROPHONE AMPLIFIER ASSY Connect the connector as shown in the illustration, and install the microphone amplifier assy. Install the screw.

HINT

  1. SEE: «COMPONENTS (LUGGAGE COMPARTMENT DOOR)», «COMPONENTS (REAR SEAT FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type), «COMPONENTS (REAR SEAT POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type) and «COMPONENTS (WINDSHIELD)»(/lexus/ls/iii-2003-2006/remont/mirrors/#windshield-glass)
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal.

Scheme 171

Scheme 171
Scheme 171

Scheme 172

Scheme 172
Scheme 172

Scheme 173

Scheme 173
Scheme 173

Scheme 174

Scheme 174
Scheme 174
  1. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (SEE «REPLACEMENT» )
  2. REMOVE DECK TRIM SIDE BOARD RH (SEE «REPLACEMENT» )
  3. REMOVE DECK TRIM SIDE BOARD LH (SEE «REPLACEMENT» )
  4. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (SEE «REPLACEMENT» )
  5. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY RH (SEE «REPLACEMENT» )
  6. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY LH (SEE «REPLACEMENT» )
  7. REMOVE PORTABLE PHONE-L BATTERY Disconnect the connector. Remove the nut and portable phone-l battery. Remove the mobile phone bracket No.2.
  8. REMOVE MAYDAY ASSY Disconnect the 4 connectors. Disengage the clip. Disconnect the connector. Disengage the clip from the Mayday assy. Remove the 4 bolts, nut and Mayday assy.
  9. REMOVE REAR SEAT CUSHION ASSY RH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  10. REMOVE REAR SEAT CUSHION ASSY LH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  11. REMOVE REAR SEAT BACK ASSY RH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  12. REMOVE REAR SEAT BACK ASSY LH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  13. REMOVE REAR DOOR SCUFF PLATE RH (SEE «OVERHAUL» )
  14. REMOVE REAR DOOR SCUFF PLATE LH (SEE «OVERHAUL» )
  15. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH (SEE «OVERHAUL» )
  16. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH (SEE «OVERHAUL» )
  17. REMOVE REAR SEAT SIDE COVER RH (SEE «OVERHAUL» )
  18. REMOVE REAR SEAT SIDE COVER LH (SEE «OVERHAUL» )
  19. REMOVE ROOF SIDE GARNISH INNER RH (SEE «OVERHAUL» )
  20. REMOVE ROOF SIDE GARNISH INNER LH (SEE «OVERHAUL» )
  21. REMOVE CENTER STOP LAMP ASSY (SEE «OVERHAUL» )
  22. REMOVE REAR SPEAKER GRILLE SUB-ASSY (SEE «OVERHAUL» )
  23. REMOVE PACKAGE TRAY TRIM PANEL ASSY (SEE «OVERHAUL» )
  24. REMOVE MOBILE PHONE BRACKET Remove the nut and mobile phone bracket.
  25. REMOVE MOBILE PHONE BRACKET NO.1 Remove the nut and mobile phone bracket No.1. Remove the bus buffer ECU from the bracket.

HINT

Scheme 175

Scheme 175: REPLACEMENT
Scheme 175: REPLACEMENT
  1. COMPONENTS: SEE «AIR BAG RESTRAINT SYSTEMS».
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal.

Scheme 176

Scheme 176
Scheme 176
  1. REMOVE SWITCH & VOLUME CASE Disengage the 3 claws and remove the switch & volume case.
  2. REMOVE STEERING WHEEL COVER LOWER NO.2 (SEE «GARAGE DOOR OPENER SYSTEM»(/lexus/ls/iii-2003-2006/remont/communication-devices/#garage-door-opener-system) )
  3. REMOVE HORN BUTTON ASSY (SEE «GARAGE DOOR OPENER SYSTEM»(/lexus/ls/iii-2003-2006/remont/communication-devices/#garage-door-opener-system) )
  4. REMOVE STEERING PAD SWITCH MODULATOR Remove the 4 screws. Disconnect the connectors and remove the steering pad switch modulator.
  5. INSTALL HORN BUTTON ASSY (SEE «GARAGE DOOR OPENER SYSTEM»(/lexus/ls/iii-2003-2006/remont/communication-devices/#garage-door-opener-system) )
  6. INSPECT HORN BUTTON ASSY (SEE «GARAGE DOOR OPENER SYSTEM»(/lexus/ls/iii-2003-2006/remont/communication-devices/#garage-door-opener-system) )
  7. SRS WARNING LIGHT (SEE «SOURCE VOLTAGE DROP» )

HINT

  1. SEE «COMPONENTS (FRONT BUMPER)»(/lexus/ls/iii-2003-2006/remont/exteriorinterior-trim/#front-bumper) and «COMPONENTS (REAR BUMPER)»(/lexus/ls/iii-2003-2006/remont/exteriorinterior-trim/#rear-bumper)
  2. SEE: «LOCATION»
  3. Installation is in the reverse order of removal

Scheme 177

Scheme 177
Scheme 177

Scheme 178

Scheme 178
Scheme 178
  1. REMOVE FRONT BUMPER COVER (SEE «REPLACEMENT»(/lexus/ls/iii-2003-2006/remont/exteriorinterior-trim/#front-bumper__replacement) )
  2. REMOVE REAR BUMPER COVER (SEE «REPLACEMENT»(/lexus/ls/iii-2003-2006/remont/exteriorinterior-trim/#rear-bumper__replacement) )
  3. REMOVE ULTRASONIC SENSOR RETAINER NO.1 Disconnect the connector Remove the ultrasonic sensor retainer No.1 as shown in the illustration.
  4. REMOVE ULTRASONIC SENSOR NO.1 Remove the ultrasonic sensor No.1.

HINT

  1. SEE: «COMPONENTS (FRONT BUMPER)»(/lexus/ls/iii-2003-2006/remont/exteriorinterior-trim/#front-bumper) and «COMPONENTS (REAR BUMPER)»(/lexus/ls/iii-2003-2006/remont/exteriorinterior-trim/#rear-bumper) .
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal.

Scheme 179

Scheme 179
Scheme 179

Scheme 180

Scheme 180
Scheme 180
  1. REMOVE FRONT BUMPER COVER (SEE «REPLACEMENT»(/lexus/ls/iii-2003-2006/remont/exteriorinterior-trim/#front-bumper__replacement) )
  2. REMOVE REAR BUMPER COVER (SEE «REPLACEMENT»(/lexus/ls/iii-2003-2006/remont/exteriorinterior-trim/#rear-bumper__replacement) )
  3. REMOVE ULTRASONIC SENSOR RETAINER NO.2 Disconnect the connector. Remove the ultrasonic sensor retainer No.2 as shown in the illustration.
  4. REMOVE ULTRASONIC SENSOR NO.2 Remove the ultrasonic sensor No.2.

HINT

  1. SEE: «COMPONENTS».
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal.

Scheme 181

Scheme 181
Scheme 181
  1. REMOVE SWITCH BASE HOLE COVER (SEE «REPLACEMENT» )
  2. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY NO.1 (SEE «REPLACEMENT» )
  3. REMOVE CLEARANCE WARNING BUZZER NO.1 Disconnect the connector. Disengage the clip and remove the clearance warning buzzer No.1.

HINT

  1. SEE: «COMPONENTS (FRONT SEATS)»(/lexus/ls/iii-2003-2006/remont/seats/#front-seat) , «COMPONENTS (REAR SEAT FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type) and «COMPONENTS (REAR SEAT POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type)
  2. SEE: «LOCATION»
  3. Installation is in the reverse order of removal.

Scheme 182

Scheme 182
Scheme 182
  1. REMOVE REAR SEAT CUSHION ASSY RH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  2. REMOVE REAR SEAT CUSHION ASSY LH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  3. REMOVE REAR SEAT BACK ASSY LH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  4. REMOVE REAR SEAT BACK ASSY RH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  5. REMOVE REAR DOOR SCUFF PLATE RH (SEE «OVERHAUL» )
  6. REMOVE REAR DOOR SCUFF PLATE LH (SEE «OVERHAUL» )
  7. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH (SEE «OVERHAUL» )
  8. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH (SEE «OVERHAUL» )
  9. REMOVE REAR SEAT SIDE COVER RH (SEE «OVERHAUL» )
  10. REMOVE REAR SEAT SIDE COVER LH (SEE «OVERHAUL» )
  11. REMOVE ROOF SIDE GARNISH INNER RH (SEE «OVERHAUL» )
  12. REMOVE ROOF SIDE GARNISH INNER LH (SEE «OVERHAUL» )
  13. REMOVE CENTER STOP LAMP ASSY (SEE «OVERHAUL» )
  14. REMOVE REAR SPEAKER GRILLE SUB-ASSY (SEE «OVERHAUL» )
  15. PACKAGE TRAY TRIM PANEL ASSY (SEE «OVERHAUL» )
  16. REMOVE CLEARANCE WARNING BUZZER NO. Disconnect the connector. Disengage the clip and remove the clearance warning buzzer No.2.

HINT

  1. SEE: «COMPONENTS».
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal

Scheme 183

Scheme 183
Scheme 183
  1. REMOVE REAR FLOOR FINISH PLATE (SEE «REPLACEMENT» )
  2. REMOVE ROOM PARTITION NET ASSY (SEE «REPLACEMENT» )
  3. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (SEE «REPLACEMENT» )
  4. REMOVE ROPE HOOK ASSY (SEE «REPLACEMENT» )
  5. REMOVE REAR FLOOR FINISH PLATE (SEE «REPLACEMENT» )
  6. REMOVE TOOL CASE (SEE «REPLACEMENT» )
  7. REMOVE SIDE TRIM TOOL BAG COVER (SEE «REPLACEMENT» )
  8. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY LH (SEE «REPLACEMENT» )
  9. REMOVE CLEARANCE WARNING ECU ASSY Disconnect the connector. Remove the 2 nuts and clearance warning ECU assy.

HINT

  1. SEE: «LOCATION».
  2. Installation is in the reverse order of removal.

Scheme 184

Scheme 184
Scheme 184

Scheme 185

Scheme 185
Scheme 185
  1. REMOVE TELEPHONE ANTENNA ROD Rotate the telephone antenna rod in the direction indicated by the arrow to remove it.
  2. REMOVE ROOF HEADLINING ASSY (SEE «REPLACEMENT»(/lexus/ls/iii-2003-2006/remont/exterior-lights/#headlamp-protector-retainer__replacement) )
  3. REMOVE TELEPHONE ANTENNA BASE Disconnect the connector. Remove the 2 nuts and telephone antenna base.

HINT

  1. SEE: «LOCATION».
  2. Installation is in the reverse order of removal.

Scheme 186

Scheme 186
Scheme 186
  1. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (SEE «REPLACEMENT» )
  2. REMOVE DECK TRIM SIDE BOARD RH (SEE «REPLACEMENT» )
  3. REMOVE REAR FLOOR FINISH PLATE (SEE «REPLACEMENT» )
  4. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (SEE «REPLACEMENT» )
  5. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY RH (SEE «REPLACEMENT» )
  6. REMOVE ROOF HEADLINING ASSY (SEE «REPLACEMENT»(/lexus/ls/iii-2003-2006/remont/exterior-lights/#headlamp-protector-retainer__replacement) )
  7. REMOVE ANTENNA CORD SUB-ASSY Disconnect the connector. Remove the bolt. Disengage the 5 clips and remove the antenna cord sub-assy.

HINT

  1. SEE: «COMPONENTS».
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal.

Scheme 187

Scheme 187
Scheme 187
  1. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY (SEE «REPLACEMENT» )
  2. REMOVE NAVIGATION ANTENNA ASSY Remove the 2 screws and navigation antenna assy from the instrument panel safety pad.

HINT

  1. SEE: «COMPONENTS (FRONT SEATS)»(/lexus/ls/iii-2003-2006/remont/seats/#front-seat) , «COMPONENTS (REAR SEAT FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type) and «COMPONENTS (REAR SEAT POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type)
  2. SEE: «LOCATION».
  3. Installation is in the reverse order of removal.

Scheme 188

Scheme 188
Scheme 188

Scheme 189

Scheme 189
Scheme 189
  1. REMOVE LUGGAGE COMPARTMENT FLOOR MAT (SEE «REPLACEMENT» )
  2. REMOVE DECK TRIM SIDE BOARD RH (SEE «REPLACEMENT» )
  3. REMOVE DECK TRIM SIDE BOARD LH (SEE «REPLACEMENT» )
  4. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT (SEE «REPLACEMENT» )
  5. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY RH (SEE «REPLACEMENT» )
  6. REMOVE LUGGAGE COMPARTMENT TRIM COVER ASSY LH (SEE «REPLACEMENT» )
  7. REMOVE REAR SEAT CUSHION ASSY RH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  8. REMOVE REAR SEAT CUSHION ASSY LH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  9. REMOVE REAR SEAT BACK ASSY RH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  10. REMOVE REAR SEAT BACK ASSY LH (SEE «OVERHAUL (FIXED TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-fixed-type__overhaul) and «OVERHAUL (POWER ADJUSTER TYPE)»(/lexus/ls/iii-2003-2006/remont/seats/#rear-seat-power-adjuster-type__overhaul) )
  11. REMOVE REAR DOOR SCUFF PLATE RH (SEE «OVERHAUL» )
  12. REMOVE REAR DOOR SCUFF PLATE LH (SEE «OVERHAUL» )
  13. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH (SEE «OVERHAUL» )
  14. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH (SEE «OVERHAUL» )
  15. REMOVE REAR SEAT SIDE COVER RH (SEE «OVERHAUL»
  16. REMOVE REAR SEAT SIDE COVER LH (SEE «OVERHAUL» )
  17. REMOVE ROOF SIDE GARNISH INNER RH (SEE «OVERHAUL» )
  18. REMOVE ROOF SIDE GARNISH INNER LH (SEE «OVERHAUL» )
  19. REMOVE CENTER STOP LAMP ASSY (SEE «OVERHAUL» )
  20. REMOVE REAR SPEAKER GRILLE SUB-ASSY (SEE «OVERHAUL» )
  21. REMOVE PACKAGE TRAY TRIM PANEL ASSY (SEE «OVERHAUL» )
  22. REMOVE MAYDAY GPS ANTENNA Disconnect the connector. Disengage the clip from the Mayday assy. Disengage the 3 clips. Peel the adhesive tapes and remove the Mayday GPS antenna.

HINT

  1. SEE: «COMPONENTS».
  2. Installation is in the reverse order of removal.

Scheme 190

Scheme 190
Scheme 190
  1. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER CENTER (SEE «REPLACEMENT» )
  2. REMOVE CONSOLE PANEL SUB-ASSY UPPER (SEE «REPLACEMENT» )
  3. REMOVE CIGARETTE LIGHTER ASSY Rotate the socket cap counterclockwise to remove it. Remove the cigarette lighter assy from the cigar-lighter hole bezel.
  4. INSTALL CIGARETTE LIGHTER ASSY Properly position the socket and ring at the cutout of the cigar-lighter hole bezel and insert them. Rotate the socket cap clockwise from the backside.

HINT

  1. SEE: «COMPONENTS».
  2. Installation is in the reverse order of removal.

Scheme 191

Scheme 191
Scheme 191

Scheme 192

Scheme 192
Scheme 192

Scheme 193

Scheme 193
Scheme 193
  1. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER CENTER (SEE «REPLACEMENT» )
  2. REMOVE CONSOLE PANEL SUB-ASSY UPPER (SEE «REPLACEMENT» )
  3. REMOVE INSTRUMENT PANEL CUP HOLDER ASSY (SEE «REPLACEMENT» )
  4. REMOVE CONSOLE UPPER REAR PANEL SUB-ASSY (SEE «REPLACEMENT» )
  5. REMOVE CONSOLE BOX CARPET (SEE «REPLACEMENT» )
  6. REMOVE REAR CONSOLE ARMREST ASSY (SEE «REPLACEMENT» )
  7. REMOVE CONSOLE BOX PLATE Disconnect the connector. Disengage the 6 claws and remove the console box plate.
  8. REMOVE CIGARETTE LIGHTER COVER REAR Disengage the 2 claws and remove the cigarette lighter cover rear.
  9. REMOVE CIGARETTE LIGHTER ASSY REAR Turn the socket counterclockwise as shown in the illustration. Disengage the claw between the socket and the cigarette lighter bezel stay, and push out the socket. Align the socket with the notch on the cigarette lighter bezel stay, and remove the cigarette lighter assy.
  10. REMOVE CIGARETTE LIGHTER BEZEL STAY REAR
  11. REMOVE CIGAR LIGHTER HOLE BEZEL
  12. INSTALL CIGARETTE LIGHTER ASSY Align the socket with the notch on the cigarette lighter bezel stay, push in the cigarette lighter assy as hard as possible to install it.

HINT

  1. SEE: «COMPONENTS».
  2. Installation is in the reverse order of removal.

Scheme 194

Scheme 194
Scheme 194
  1. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER CENTER (SEE «REPLACEMENT» )
  2. REMOVE CONSOLE PANEL SUB-ASSY UPPER (SEE «REPLACEMENT» )
  3. REMOVE POWER POINT SOCKET ASSY Pressing the claw of the power point socket assy in the direction indicated by the arrow, push the power point socket assy toward the inside of the chamber and remove it.
  4. REMOVE POWER POINT SOCKET COVER
  5. INSTALL POWER POINT SOCKET ASSY Align the claw of the power point socket assy with the cutout of the power point cover and fully push it to install.

HINT

  1. SEE: «COMPONENTS».
  2. Installation is in the reverse order of removal.

Scheme 195

Scheme 195
Scheme 195
  1. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY CENTER (SEE «REPLACEMENT» )
  2. REMOVE INSTRUMENT PANEL CUP HOLDER ASSY (SEE «REPLACEMENT» )
  3. REMOVE CONSOLE UPPER REAR PANEL SUB-ASSY (SEE «REPLACEMENT» )
  4. REMOVE CONSOLE BOX CARPET (SEE «REPLACEMENT» )
  5. REMOVE REAR CONSOLE ARMREST ASSY (SEE «REPLACEMENT» )
  6. REMOVE POWER OUTLET SOCKET ASSY CTR Turn the socket counterclockwise as shown in the illustration. Disengage the claw between the socket and the socket cover, and push out the socket. Align the socket with the notch on the socket cover, and remove the socket assy.
  7. INSTALL POWER OUTLET SOCKET ASSY CTR Align the socket with the notch on the socket cover, push in the socket assy as hard as possible to install it.

Scheme 196

Scheme 196: REPAIR
Scheme 196: REPAIR

Scheme 197

Scheme 197
Scheme 197

Scheme 198

Scheme 198
Scheme 198

Scheme 199

Scheme 199
Scheme 199
  1. GLASS PRINTED ANTENNA INSPECTION PROCEDURE NOTE: When cleaning the glass, use a soft, dry cloth, and wiper the glass in the direction of the wire. Take care not to damage the wires. Do not use detergents or glass cleaners with abrasive ingredients. When measuring voltage, wind a piece of tin foil around the top of the negative probe and press the foil against the wire with your finger, as shown in the illustration. Inspect the continuity at the center of each antenna wire, as shown in the illustration.
  2. GLASS PRINTED ANTENNA REPAIR PROCEDURE Clean the broken wire tips with a grease, wax and silicone remover. Place the masking tape along both sides of the wire to be repaired. Thoroughly mix the repair agent (DuPont paste No. 4817). Using a fine tip brush, apply a small amount to the wire. After a few minutes, remove the masking tape. Do not repair the defogger wire for at least 24 hours.

More articles — Audio & Visual System
