Suspension Control System: Removal & Installation Lexus LS III рестайлинг

Electronic Suspension 17 illustrations ~692 words

REPLACEMENT

HINT

  1. Use the same procedures for the RH side and LH side.
  2. The procedures listed below are for the LH side.

Scheme 268

Scheme 268
Scheme 268

Scheme 269

Scheme 269
Scheme 269

Scheme 270

Scheme 270
Scheme 270

Scheme 271

Scheme 271
Scheme 271
  1. REMOVE FRONT WHEELS
  2. REMOVE HEIGHT CONTROL SENSOR SUB-ASSY FRONT LH Disconnect the connector. Remove the nut and disconnect the height control sensor link. Remove the 2 bolts and height control sensor sub-assy front LH.
  3. INSTALL HEIGHT CONTROL SENSOR SUB-ASSY FRONT LH Install the height control sensor sub-assy front LH with 2 bolts. Torque: 7.8 N.m (80 kgf.cm, 69 in. lbf) Connect the height control sensor link with a nut. Torque: 5.4 N.m (55 kgf.cm, 48 in. lbf) Connect the connector.
  4. INSTALL FRONT WHEELS Torque: 103 N.m (1,050 kgf.cm, 76 ft.lbf) ADJUST VEHICLE HEIGHT (SEE «ON-VEHICLE INSPECTION» )

Scheme 272

Scheme 272: COMPONENTS
Scheme 272: COMPONENTS

HINT

  1. Use the same procedures for the RH side and LH side.
  2. The procedures listed below are for the LH side.

Scheme 273

Scheme 273
Scheme 273

Scheme 274

Scheme 274
Scheme 274

Scheme 275

Scheme 275
Scheme 275

Scheme 276

Scheme 276
Scheme 276
  1. REMOVE HEIGHT CONTROL SENSOR SUB-ASSY REAR LH Disconnect the connector. Place matchmarks on the height control sensor link and bracket. Remove the nut and disconnect the height control sensor link. Remove the 2 bolts and height control sensor sub-assy rear LH.
  2. INSTALL HEIGHT CONTROL SENSOR SUB-ASSY REAR LH Install the height control sensor sub-assy rear LH with 2 bolts. Torque: 7.8 N.m (80 kgf.cm, 69 in. lbf) Align the matchmarks on the height control sensor link and bracket. Install the nut. Torque: 5.4 N.m (55 kgf.cm, 48 in. lbf) Connect the connector.
  3. ADJUST VEHICLE HEIGHT (SEE «ON-VEHICLE INSPECTION» )

Scheme 277

Scheme 277: COMPONENTS
Scheme 277: COMPONENTS

Scheme 278

Scheme 278: REPLACEMENT
Scheme 278: REPLACEMENT

Scheme 279

Scheme 279
Scheme 279
  1. REMOVE FRONT WHEELS
  2. REMOVE FRONT FENDER LINER LH
  3. REMOVE HEIGHT CONTROL VALVE SUB-ASSY NO.1 Disconnect the connector. Disconnect the under side air tube (see «PRECAUTION» ). Disconnect the 3 side air tubes (see «PRECAUTION» ). Remove the 2 nuts and height control valve sub-assy No.1.
  4. INSTALL HEIGHT CONTROL VALVE SUB-ASSY NO.1 Install the height control valve sub-assy No.1 with 2 nuts. Torque: 5.4 N.m (55 kgf.cm, 48 in. lbf) Connect the 3 side air tubes (see «PRECAUTION» ). Connect the under side air tube (see «PRECAUTION» ). Connect the connector.
  5. INSTALL FRONT FENDER LINER LH
  6. INSTALL FRONT WHEELS Torque: 103 N.m (1,050 kgf.cm, 76 ft.lbf)
  7. INSPECT AIR LEAK (SEE «ON-VEHICLE INSPECTION» )

Scheme 280

Scheme 280: COMPONENTS
Scheme 280: COMPONENTS

Scheme 281

Scheme 281: REPLACEMENT
Scheme 281: REPLACEMENT

Scheme 282

Scheme 282
Scheme 282
  1. REMOVE HEIGHT CONTROL VALVE SUB-ASSY NO.2 Disconnect the connector. Disconnect the 3 air tubes (see «PRECAUTION» ). Remove the 2 nuts and height control valve sub-assy No.2.
  2. INSTALL HEIGHT CONTROL VALVE SUB-ASSY NO.2 Install the height control valve sub-assy No.2 with 2 nuts. Torque: 5.4 N.m (55 kgf.cm, 48 in. lbf) Connect the 3 air tubes (see «PRECAUTION» ). Connect the connector.
  3. INSPECT AIR LEAK (SEE «ON-VEHICLE INSPECTION»

Scheme 283

Scheme 283: REPLACEMENT
Scheme 283: REPLACEMENT

Scheme 284

Scheme 284
Scheme 284
  1. SEPARATE BATTERY NEGATIVE TERMINAL
  2. REMOVE INSTRUMENT CLUSTER FINISH PANEL CENTER LOWER (SEE «REPLACEMENT» )
  3. REMOVE INSTRUMENT CLUSTER FINISH PANEL END (SEE «REPLACEMENT» )
  4. REMOVE INSTRUMENT PANEL UNDER COVER SUB-ASSY NO.1 (SEE «REPLACEMENT» )
  5. REMOVE COIN BOX ASSY (SEE «REPLACEMENT» )
  6. REMOVE OUTER MIRROR SWITCH ASSY (SEE «REPLACEMENT» )
  7. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY (SEE «REPLACEMENT» )
  8. REMOVE INSTRUMENT PANEL AIR BAG ASSY LOWER NO.1 (SEE «INSTRUMENT PANEL» )
  9. REMOVE SUSPENSION CONTROL ECU Disconnect the connectors. Remove the 2 nuts and suspension control ECU with bracket. Remove the 2 nuts and suspension control ECU from the bracket.
  10. INSTALL SUSPENSION CONTROL ECU Install the suspension control ECU to the bracket with the 2 nuts. Torque: 5.5 N.m (56 kgf.cm, 48 in. lbf) Install the suspension control ECU with bracket with the 2 nuts. Torque: 5.5 N.m (56 kgf.cm, 48 in. lbf) Connect the connectors.
  11. INSTALL INSTRUMENT PANEL AIR BAG ASSY LOWER NO.1 (SEE «INSTRUMENT PANEL» )
  12. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY (SEE «REPLACEMENT» )
  13. INSTALL OUTER MIRROR SWITCH ASSY (SEE «REPLACEMENT» )
  14. INSTALL COIN BOX ASSY (SEE «REPLACEMENT» )
  15. INSTALL INSTRUMENT PANEL UNDER COVER SUB-ASSY NO.1 (SEE «REPLACEMENT» )
  16. INSTALL INSTRUMENT CLUSTER FINISH PANEL END (SEE «REPLACEMENT» )
  17. INSTALL INSTRUMENT CLUSTER FINISH PANEL CENTER LOWER (SEE «REPLACEMENT» )
  18. INSPECT SRS WARNING LIGHT (SEE «AIR BAG WARNING LIGHT DOES NOT ILLUMINATE» )
  19. CONNECT BATTERY NEGATIVE TERMINAL
