STARTER CONTROL CIRCUIT

With ignition switch in START position, current flows to Park/Neutral Position (PNP) switch. PNP switch prevents the starter from operating if the transmission is in gear. Current flows through the starter relay coil to ground. This energizes the starter relay, allowing battery power to the starter solenoid. The starter solenoid engages, allowing current to flow through starter motor field coils.

ES300

Remove glove box and locate ECM. See COMPONENT LOCATIONS. Using DVOM, backprobe ECM 22-pin connector E7 terminal No. 7 (Gray wire). (Scheme 10) Check for voltage with ignition in START position. If voltage is 6 volts or more, ECM is okay. If voltage is less than 6 volts, check for open in wiring harness or connectors between ECM and starter relay. Repair as necessary. If wiring harness and connectors are okay, replace ECM.

Scheme 10

Scheme 10: ES300

GS300

Remove ECM hood and cover, and locate ECM. See COMPONENT LOCATIONS. Using DVOM, backprobe ECM 28-pin connector E5 terminal No. 2 (Black wire). (Scheme 11) Check for voltage with ignition in START position. If voltage is 6 volts or more, ECM is okay. If voltage is less than 6 volts, check for open in wiring harness or connectors between ECM and starter relay. Repair as necessary. If wiring harness and connectors are okay, replace ECM.

Scheme 11

Scheme 11: GS300

GS430

Remove ECM hood and cover, and locate ECM. See COMPONENT LOCATIONS. Using DVOM, backprobe ECM 28-pin connector E6 terminal No. 12 (Black wire). (Scheme 10) Check for voltage with ignition in START position. If voltage is 6 volts or more, ECM is okay. If voltage is less than 6 volts, check for open in wiring harness or connectors between ECM and starter relay. Repair as necessary. If wiring harness and connectors are okay, replace ECM.

LS430

Remove instrument panel under cover, and locate ECM. See COMPONENT LOCATIONS. Using DVOM, backprobe ECM 31-pin connector E3 terminal No. 12 (Blue/Orange wire). (Scheme 12) Check for voltage with ignition in START position. If voltage is 6 volts or more, ECM is okay. If voltage is less than 6 volts, check for open in wiring harness or connectors between ECM, starter and starter relay. Repair as necessary. If wiring harness and connectors are okay, replace ECM.

Scheme 12

Scheme 12: LS430

RX300

Remove glove box and locate ECM. See COMPONENT LOCATIONS. Using DVOM, backprobe ECM 22-pin connector E5 terminal No. 7 (Black wire). (Scheme 10) Check for voltage with ignition in START position. If voltage is 6 volts or more, ECM is okay. If voltage is less than 6 volts, check for open in wiring harness or connectors between ECM and starter relay. Repair as necessary. If wiring harness and connectors are okay, replace ECM.

BRUSHES

  1. Using a vernier caliper, measure brush length. See «STARTER SPECIFICATIONS»(ref-91435-S31558869102001031400000) . If brush length is less than minimum specification, replace brush holder and field frame.
  2. Using a pull scale, note brush spring tension the instant the brush spring separates from brush. See «STARTER SPECIFICATIONS»(ref-91435-S31558869102001031400000) . If brush spring tension is less than minimum specification, replace brush springs.

ES300, GS300, IS300 & RX300

ApplicationSpecification
Brush Length
Standard.61" (15.5 mm)
Minimum.39" (10.0 mm)
Brush Spring Tension3.9-5.3 Lbs. (1.8-2.4 kg)
Commutator Diameter
Standard1.18" (30.0 mm)
Minimum1.14" (29.0 mm)
Commutator Mica Undercut (Minimum) (1).008" (.20 mm)
Commutator Runout (Maximum).002" (.05 mm)
(1) Depth of groove between each segment of commutator.
(1)Depth of groove between each segment of commutator.

STARTER SPECIFICATIONS (ES300, GS300, IS300 & RX300)

GS340 & LS430

ApplicationSpecification
Brush Length
Standard.59" (15.0 mm)
Minimum.35" (9.0 mm)
Brush Spring Tension4.8-6.2 Lbs. (2.2-2.8 kg)
Commutator Diameter
Standard1.38" (35.0 mm)
Minimum1.34" (34.0 mm)
Commutator Mica Undercut (Minimum) (1).008" (.20 mm)
Commutator Runout (Maximum).002" (.05 mm)
(1) Depth of groove between each segment of commutator.
(1)Depth of groove between each segment of commutator.

STARTER SPECIFICATIONS (GS430 & LS430)

ApplicationFt. Lbs. (N.m)
Starter Bolt27 (37)
Terminal Nut12-13 (17-18)
INCH Lbs. (N.m)
Air Cleaner Case Bolt (RX300)44 (5.0)
End Cover Bolt22 (2.5)

TORQUE SPECIFICATIONS (ES300, GS300, IS300 & RX300)

GS430 & LS430

ApplicationFt. Lbs. (N.m)
Coolant By-Pass Pipe Bolt13 (18)
Fuel Inlet-To-Fuel Main Tube22 (30)
Intake Manifold Bolt/Nut13 (18)
Rear Coolant By-Pass Joint Nut13 (18)
Starter Bolt
GS43027 (37)
LS43029 (39)
Terminal Nut13 (18)
Throttle Body Bolt/Nut13 (18)
INCH Lbs. (N.m)
End Cover Bolt32 (3.6)

TORQUE SPECIFICATIONS (GS430 & LS430)

Starting System Wiring Diagram (ES300). Scheme 13

Scheme 13: Starting System Wiring Diagram (ES300)

Starting System Wiring Diagram (GS300 & GS430). Scheme 14

Scheme 14: Starting System Wiring Diagram (GS300 & GS430)

Starting System Wiring Diagram (IS300). Scheme 15

Scheme 15: Starting System Wiring Diagram (IS300)

Starting System Wiring Diagram (LS430). Scheme 16

Scheme 16: Starting System Wiring Diagram (LS430)

Starting System Wiring Diagram (LX470). Scheme 17

Scheme 17: Starting System Wiring Diagram (LX470)

Starting System Wiring Diagram (RX300). Scheme 18

Scheme 18: Starting System Wiring Diagram (RX300)
