DISPOSAL GAS CAMBER
Place the gas camber in a vise and saw a hole in the hatched area shown in the illustration using a saw to discharge the gas inside.
| CAUTION | The gas discharging is colorless, odorless and harmless. Saw a hole while covering the saw with a shop rug because chips may fly up. |
Identifying Gas Camber. Scheme 100
Scheme 101
Scheme 102
- REMOVE GAS CHAMBER Place damping force control actuator in a vise. Using SST, remove the gas camber. SST 09922-10010 Remove the O-ring and back up ring from the gas chamber.
- INSTALL GAS CHAMBER Install a new back up ring and O-ring to the gas chamber. NOTE: Be careful not to damage the O-ring. Coat the O-ring with suspension fluid AHC. (Scheme 101): Removing Gas Camber Using SST, install the gas chamber. SST 09922-10010 Torque: 25 N.m (250 kgf.cm, 18 ft.lbf) HINT: Use a torque wrench with a fulcrum length of 345 mm (13.58 in.). NOTE: Use SST (09922-10010) in direction shown in the illustration. (Scheme 102): Installing Gas Chamber
