Wiring diagram: Power windows — Power windows circuit Lexus IS III
All systems — 36 systems
- Air conditioning
- Anti-lock brakes
- Anti-theft 3
- Body control modules 4
- Computer data lines 3
- Cooling fan
- Cruise control 4
- Defoggers 2
- Electronic power steering 3
- Electronic suspension
- Engine performance 2.5l
- Engine performance 3.5l
- Engine performance 5.0l
- Exterior lights 2
- Ground distribution
- Headlights 2
- Horn
- Instrument cluster 2
- Interior lights 2
- Memory systems 4
- Navigation 6
- Passive restraints
- Power distribution
- Power door locks
- Power mirrors 2
- Power seats 6
- Power top/sunroof
- Power windows 2
- Radio 4
- Shift interlock 2
- Starting/charging 2
- Supplemental restraints 3
- Transmission 5
- Trunk, tailgate, fuel door
- Warning systems 2
- Wiper/washer 2
Power windows
# Power windows circuit
# Power windows circuit
Components on the diagram
# Power windows circuit (1 of 2)
Components on the diagram
# Power windows circuit (2 of 2)
