Scheme 219
| *1 | MASS AIR FLOW METER ASSEMBLY | *2 | CRANKSHAFT POSITION SENSOR |
|---|---|---|---|
| *3 | THROTTLE BODY WITH MOTOR ASSEMBLY | *4 | ECM |
| *5 | INTAKE AIR CONTROL VALVE (for ACIS) - ROTARY SOLENOID (for ACIS) - ACIS VALVE | *6 | ENGINE ROOM RELAY BLOCK NO. 2 AND JUNCTION BLOCK NO. 2 ASSEMBLY - EFI NO. 2 FUSE |
| *7 | INTAKE AIR CONTROL VALVE ACTUATOR (for SWIRL CONTROL VALVE) - DC MOTOR (for SCV) | *8 | SWIRL CONTROL VALVE POSITION SENSOR |
Scheme 220
![Scheme 220: SYSTEM DIAGRAM [04/2013 - ]](https://i.diagnostdata.com/repair/6e/6e7be8eef5cc660708901925e467cdd42aa07552ac51a2287d2d56068a7a32c3.webp)
| *1 | ECM | *2 | Mass Air Flow Meter Assembly |
|---|---|---|---|
| *3 | Air Cleaner Filter Element Sub-assembly | *4 | Throttle Body with Motor Assembly |
| *5 | Intake Air Control Valve Actuator (for ACIS) | *6 | Swirl Control Valve Position Sensor |
| *7 | Intake Air Control Valve (for ACIS) | *8 | Intake Air Control Valve (for SCV) |
| *9 | Crankshaft Position Sensor |
Scheme 221
| *1 | Air Cleaner Filter Element Sub-assembly | *2 | Throttle Body with Motor Assembly |
|---|---|---|---|
| *3 | Intake Air Control Valve (for ACIS) | *4 | Intake Air Control Valve (for SCV) |
| *5 | Intake Air Control Valve Actuator (for ACIS) | *6 | Intake Air Control Valve Actuator (for SCV) |
| *7 | Swirl Control Valve Position Sensor | *8 | ECM |
Scheme 222
Scheme 223
- INSPECT INTAKE SYSTEM HINT: Perform "Inspection After Repair" after repairing vacuum leaks in the intake system. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000) Check that there are no vacuum leaks at the points shown in the illustration. *A w/ Intake Air Sound Creator
- INSPECT INTAKE MANIFOLD (for SCV) Remove the V-bank cover sub-assembly. Refer to «PROCEDURE - Step 3»(ref-665703-S21356895402014102400000) Check that the swirl control valve activation link (on the front of the intake manifold) is moving to confirm that the swirl control valve is operating. *a Open *b Fully Closed *c Valve Opening Angle *d Engine Condition *e OFF *f Idling *g Between approximately 10° and Fully Open - - After the engine switch is turned off, confirm that the swirl control valve opens to between approximately 10° and the fully open position. After the engine is started, confirm that the swirl control valve is fully closed with the engine idling. After the engine switch is turned off again, confirm that the swirl control valve opens to between approximately 10° and the fully open position. Inspection procedure when using the Techstream: Connect the Techstream to the DLC3. Turn the engine switch on (IG) and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the SCV Duty Ratio. Powertrain > Engine > Active Test Tester Display Control the SCV Duty Ratio NOTE: This test procedure must be completed within 10 seconds. Check that the swirl control valve activation link (on the front of the intake manifold) moves to the left and right. Inspection procedure when applying voltage between terminals: Disconnect the swirl control valve connector. Alternately apply battery voltage to terminals 1 and 2 of the swirl control valve. Check that the swirl control valve activation link (on the front of the intake manifold) moves to the left and right. NOTE: Do not apply battery voltage for more than 30 seconds. Measure the resistance between the terminals. Standard Resistance 1 to 19 ohms at 20°C (68°F) If the result is not as specified, replace the intake manifold.
- INSPECT FUNCTION OF AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Check the air cleaner filter element sub-assembly. Standard Condition Not excessively dirty. If the air cleaner filter element sub-assembly is excessively dirty, replace the air cleaner filter element sub-assembly. Use compressed air if the air cleaner filter element sub-assembly needs to be cleaned.
- PERFORM INITIALIZATION Perform "Inspection After Repair" after repairing vacuum leaks in the intake system. Refer to «INITIALIZATION [04/2013 - ]»(ref-665554-S39644640142014102400000)
