Cruise Control System (Diagnostic Codes & Circuit Tests): Overview Lexus IS III

Cruise Control Systems 3 illustrations ~521 words

DESCRIPTION

When the brake pedal is depressed, the stop light switch assembly sends a signal to the ECM. When the ECM receives this signal, it cancels control of vehicle speed by the cruise control system. The fail-safe function operates to enable normal driving even if there is a malfunction in the stop light signal circuit. The cancellation condition occurs when voltage is applied to terminal STP. When the brake is applied, voltage is normally applied to terminal STP of the ECM through the STOP fuse and the stop light switch assembly, and the ECM cancels control of vehicle speed by the cruise control system.

DTC No.Detection ItemDTC Detection ConditionTrouble Area
P0571Brake Switch "A" CircuitWhen voltage of STP terminal and that of ST1- terminal of ECM are less than 1 V for 0.5 sec. or moreStop light switch assembly Harness or connector ECM

Scheme 39

Scheme 39: WIRING DIAGRAM

This DTC indicates an abnormality in the ECM.

DTC No.Detection ItemDTC Detection ConditionTrouble Area
P0575Cruise Control Input CircuitWhen either of following conditions is met: Cruise control input signal abnormal Stop light switch assembly input signal abnormalECM

HINT

The ECM receives signals from each sensor to control all functions of the cruise control system. When a malfunction is detected, the fail-safe function operates until the engine switch is turned off.

The ECM receives signals from the skid control ECU (brake actuator assembly) via CAN communication.

DTC No.Detection ItemDTC Detection ConditionTrouble Area
U0122Lost Communication with Vehicle Dynamics Control ModuleWhile vehicle speed is 40 km/h (25 mph) or more and cruise switch (ON/OFF button) is on, data cannot be received from skid control ECU (brake actuator assembly) for 2.5 seconds or more.CAN communication system ECM Skid control ECU (brake actuator assembly)

This DTC is output when the vehicle stability control system has a problem. Check the vehicle stability control system when this DTC P1578 is output.

DTC No.Detection ItemDTC Detection ConditionTrouble Area
P1578Brake System MalfunctionThere is an vehicle stability control system malfunctionVehicle stability control system ECM

The cruise control switch is used to turn the cruise control system on and off, as well as operate 7 functions: SET, - (COAST), TAP-DOWN, RES (RESUME), + (ACCEL), TAP-UP and CANCEL. The SET, TAP-DOWN and - (COAST) functions, and the RES (RESUME), TAP-UP and + (ACCEL) functions are operated with the same switch. The cruise control switch is an automatic return type switch which turns on only while operating it in the direction of each arrow and turns off after releasing it. The internal contact points of the cruise control switch turn on with switch operation. Then the ECM reads the voltage value that has been changed by the switch operation to control the SET, - (COAST), RES (RESUME), + (ACCEL), and CANCEL functions.

Scheme 40

Scheme 40: WIRING DIAGRAM
  1. The ECM turns on the cruise control indicator by sending indicator output demand signals to the combination meter assembly using CAN communication.
  2. The cruise control indicator illuminates when the cruise control system has been turned on using the cruise control switch (ON/OFF button). If a malfunction is detected, the cruise control indicator goes off and a warning message is displayed.
  3. The cruise control indicator circuit uses CAN communication. If the cruise control indicator is not functioning correctly, check for CAN communication DTCs before troubleshooting this circuit.
  1. The ECM turns on the SET indicator by sending indicator output demand signals to the combination meter assembly using CAN communication.
  2. The cruise control SET indicator illuminates when the cruise control system is controlling vehicle speed.
  3. The cruise control indicator circuit uses CAN communication. If the cruise control indicator is not functioning correctly, check for CAN communication DTCs before troubleshooting this circuit.

Connecting terminals TC and CG of the DLC3 causes the cruise control system to enter self-diagnostic mode.

HINT

When a particular warning light remains blinking, a ground short in the wiring of terminal TC of the DLC3 or an internal ground short in the relevant ECU is suspected.

Scheme 41

Scheme 41: WIRING DIAGRAM
