Transfer (Service Information): Overview Lexus IS II facelift

Transfer Case 16 illustrations ~670 words

Scheme 23

Scheme 23: ILLUSTRATION
Scheme 23: ILLUSTRATION

Scheme 24

Scheme 24: REPLACEMENT
Scheme 24: REPLACEMENT

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28
  1. DRAIN AUTOMATIC TRANSMISSION FLUID. Refer to «REMOVAL - Step 6»(ref-387323-S15869217832011022400000)
  2. REMOVE REAR NO. 1 FLOOR PANEL BRACE . Refer to «REMOVAL - Step 3»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  3. REMOVE FRONT CENTER FLOOR BRACE . Refer to «REMOVAL - Step 4»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  4. REMOVE HEATED OXYGEN SENSOR . Refer to «REMOVAL - Step 6»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  5. REMOVE FRONT EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 7»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  6. REMOVE FRONT PROPELLER SHAFT ASSEMBLY . Refer to «REMOVAL - Step 2»(/lexus/is/ii-facelift-2008-2010/remont/driveshaft-universal-joints/#propeller-shaft-service-information)
  7. REMOVE FLANGE YOKE Using SST and a hammer, release the staked part of the nut. SST: 09930-00010 NOTE: Be sure to use the SST with the tapered surface facing the shaft. Do not grind the tip of the SST with a grinder or other device. Completely loosen the staked part of the nut when removing it. Do not damage the threads of the output shaft. Using SST, hold the flange yoke. SST: 09330-00021 SST: 09213-54015 Using a deep socket wench (30 mm), remove the nut. Remove the flange yoke from the transfer assembly.
  8. REMOVE TRANSFER CASE FRONT OIL SEAL Using SST, remove the oil seal. SST: 09308-00010
  9. INSTALL TRANSFER CASE FRONT OIL SEAL Using SST and a hammer, install a new oil seal. SST: 09316-60011 09316-00011 09316-00071 Oil seal installation depth 5.6 to 6.2 mm (0.220 to 0.244 in.) Apply MP grease to the oil seal lip.
  10. INSTALL FLANGE YOKE Install the flange yoke to the transfer assembly. Using SST, hold the flange yoke. SST: 09213-54015 SST: 09330-00021 Using a deep socket wench (30 mm), torque a new nut. Torque: 123 N*m ( 1,250 kgf*cm, 91 ft.*lbf) Using a chisel and hammer, stake the nut.
  11. INSTALL FRONT PROPELLER SHAFT ASSEMBLY . Refer to «INSTALLATION - Step 1»(/lexus/is/ii-facelift-2008-2010/remont/driveshaft-universal-joints/#propeller-shaft-service-information)
  12. INSTALL FRONT EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 4»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  13. INSTALL HEATED OXYGEN SENSOR . Refer to «INSTALLATION - Step 6»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  14. INSTALL FRONT CENTER FLOOR BRACE . Refer to «INSTALLATION - Step 7»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  15. INSTALL REAR NO. 1 FLOOR PANEL BRACE . Refer to «INSTALLATION - Step 8»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  16. ADD AUTOMATIC TRANSMISSION FLUID. Refer to «INSTALLATION - Step 28»(ref-387323-S39283212652011022400000)
  17. CHECK FOR EXHAUST GAS LEAKS

Scheme 29

Scheme 29: ILLUSTRATION
Scheme 29: ILLUSTRATION

Scheme 30

Scheme 30: REPLACEMENT
Scheme 30: REPLACEMENT

Scheme 31

Scheme 31
Scheme 31
  1. DRAIN AUTOMATIC TRANSMISSION FLUID. Refer to «REMOVAL - Step 6»(ref-387323-S15869217832011022400000)
  2. REMOVE REAR NO. 1 FLOOR PANEL BRACE . Refer to «REMOVAL - Step 3»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  3. REMOVE FRONT CENTER FLOOR BRACE . Refer to «REMOVAL - Step 4»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  4. REMOVE HEATED OXYGEN SENSOR . Refer to «REMOVAL - Step 6»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  5. REMOVE FRONT EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 7»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  6. REMOVE FRONT NO. 1 FLOOR HEAT INSULATOR . Refer to «REMOVAL - Step 2»(/lexus/is/ii-facelift-2008-2010/remont/driveshaft-universal-joints/#propeller-shaft-service-information)
  7. REMOVE OUTSIDE AIR GUIDE PLATE RH . Refer to «REMOVAL - Step 3»(/lexus/is/ii-facelift-2008-2010/remont/driveshaft-universal-joints/#propeller-shaft-service-information)
  8. REMOVE PROPELLER SHAFT WITH CENTER BEARING ASSEMBLY . Refer to «REMOVAL - Step 4»(/lexus/is/ii-facelift-2008-2010/remont/driveshaft-universal-joints/#propeller-shaft-service-information)
  9. REMOVE TRANSFER CASE REAR OIL SEAL Using SST, remove the oil seal. SST: 09308-00010
  10. INSTALL TRANSFER CASE REAR OIL SEAL Using SST and a hammer, install a new oil seal. SST: 09325-40010 Oil seal installation depth 2.3 to 2.7 mm (0.091 to 0.106 in.) Apply MP grease to the oil seal lip.
  11. INSTALL PROPELLER SHAFT WITH CENTER BEARING ASSEMBLY . Refer to «INSTALLATION - Step 1»(/lexus/is/ii-facelift-2008-2010/remont/driveshaft-universal-joints/#propeller-shaft-service-information)
  12. INSPECT AND ADJUST BOTH NO. 2 AND NO. 3 JOINT ANGLES . Refer to «INSTALLATION - Step 2»(/lexus/is/ii-facelift-2008-2010/remont/driveshaft-universal-joints/#propeller-shaft-service-information)
  13. INSTALL FRONT NO. 1 FLOOR HEAT INSULATOR . Refer to «INSTALLATION - Step 3»(/lexus/is/ii-facelift-2008-2010/remont/driveshaft-universal-joints/#propeller-shaft-service-information)
  14. INSTALL OUTSIDE AIR GUIDE PLATE RH . Refer to «INSTALLATION - Step 4»(/lexus/is/ii-facelift-2008-2010/remont/driveshaft-universal-joints/#propeller-shaft-service-information)
  15. INSTALL FRONT EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 4»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  16. INSTALL HEATED OXYGEN SENSOR . Refer to «INSTALLATION - Step 6»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  17. INSTALL FRONT CENTER FLOOR BRACE . Refer to «INSTALLATION - Step 7»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  18. INSTALL REAR NO. 1 FLOOR PANEL BRACE . Refer to «INSTALLATION - Step 8»(/lexus/is/ii-facelift-2008-2010/remont/exhaust/#exhaust-service-information-4gr-fse)
  19. ADD AUTOMATIC TRANSMISSION FLUID. Refer to «INSTALLATION - Step 28»(ref-387323-S39283212652011022400000)
  20. CHECK FOR EXHAUST GAS LEAKS

Scheme 32

Scheme 32: ILLUSTRATION
Scheme 32: ILLUSTRATION

Scheme 33

Scheme 33: ILLUSTRATION
Scheme 33: ILLUSTRATION

Scheme 34

Scheme 34: ILLUSTRATION
Scheme 34: ILLUSTRATION

Scheme 35

Scheme 35: ILLUSTRATION
Scheme 35: ILLUSTRATION

Scheme 36

Scheme 36: ILLUSTRATION
Scheme 36: ILLUSTRATION

Scheme 37

Scheme 37: ILLUSTRATION
Scheme 37: ILLUSTRATION

Scheme 38

Scheme 38: ILLUSTRATION
Scheme 38: ILLUSTRATION
