CUSTOMIZE PARAMETERS

HINT

The following items can be customized.

Note. When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting.

Scheme 75

Scheme 76

Scheme 77

Scheme 78

1. POWER TILT AND POWER TELESCOPIC STEERING COLUMN SYSTEM TILT & TELESCOPIC DISPLAY DEFAULT CONTENTS SETTING Autoaway / Return function ON ON/OFF of the auto away / return function ON/OFF
2. AIR CONDITIONING SYSTEM AIR CONDITIONER Tester Display Default Contents Setting Set Temperature Shift NORMAL To control with the shifted temperature against the display temperature +2 C / +1 C / NORMAL / -1 C / -2 C Air Inlet Mode AUTO In case of turning the A/C ON when you desire to make the compartment cool down quickly, this is the function to change the mode automatically to RECIRCULATION mode MANUAL / AUTO Compressor Mode AUTO Function to turn the A/C ON automatically by pressing the AUTO button when the blower is ON and the A/C is OFF MANUAL / AUTO Compressor/Air Inlet DEF operation LINK Function to turn the A/C ON automatically linked with the FRONT DEF button when A/C OFF NORMAL / LINK Evaporator Control AUTO Function to set the evaporator control to the AUTOMATIC position (AUTO) to save power, or to the coldest position (MANUAL) to dehumidify the air and to prevent the windows from fogging up MANUAL / AUTO Emission Gas Sensor Shift* NORMAL Function to change the sensitivity of the exhaust gas sensor MU MORE / MORE / LI MORE / NORMAL / LI LESS / LESS / MU LESS Button Press Buzzer ON Function to sound a buzzer when button is pressed OFF / ON Foot/DEF Auto Mode ON Function to turn the airflow from FOOT / DEF ON automatically when AUTO MODE is ON OFF / ON Foot/DEF Automatic Blow Up Function ON Function to change the blower level automatically when the defroster is ON OFF / ON Ambient Temperature Shift NORMAL Function to control the shifted ambient temperature in relation to the displayed ambient temperature +3 C / +2 C / +1 C / NORMAL / -1 C / -2 C / -3 C Foot Air Leak ON Function to cut off the airstream felt underfoot while the vehicle is moving OFF / ON *: For 2GR-FSE
3. THEFT DETERRENT SYSTEM SECURITY Display(Item) Default Contents Setting Passive Mode OFF PASSIVE MODE is a function that switches theft deterrent system from arming preparation state to armed state 30 seconds after key is not in the actuation area and driver side door is closed, even if doors are not locked by wireless or door key lock operation In PASSIVE MODE, if you do not perform following operations within 14 seconds after door is opened during armed state, theft deterrent system will judge that condition as a theft and switch to alarm sounding state Unlock any door by key or wireless operation Reconnect battery Turn the engine switch on (IG) ON/OFF Warning by Horn ON Function that makes vehicle horn and theft deterrent horn be able to be used as a warning device ON/OFF Entry Delay Time 14 s Function that changes entry delay time (time before warning starts) for PASSIVE MODE 0 s/14 s/30 s
4. LIGHTING SYSTEM ILLUMINATED ENTRY: Display Default Contents Setting I/L when ACC OFF ON Lights up the seat illumination when the engine switch is turned off. ON / OFF Light Control ON Dims (ON setting) or turns off (OFF setting) the footwell lights under the following conditions: A/T models: engine switch on (IG), shift lever not in P, and all doors closed. M/T models: engine switch on (IG), parking lever released, and all doors closed, or engine switch on (IG), vehicle speed above 5 km/h (3 mph), and all doors closed. ON / OFF Illumination System ON Lights up the footwell lights when one of the following occurs: the engine switch is turned on (IG), or any door is unlocked or opened. ON / OFF Lighting Time 15 s Changes the lighting time of the seat illumination. 7.5 s / 15 s / 30 s I/L ON W/Unlock ON Lights up the seat illumination when the doors are unlocked with the transmitter. ON / OFF Shift Light Control AVAIL Lights up the shift illumination when the engine switch is turned on (ACC or IG). NOT AVL / AVAIL Exterior Foot Light Control AVAIL Lights up the door mirror foot lights when either of the following occurs: the doors are unlocked with the transmitter, or the key enters any actuation area around the doors. NOT AVL / AVAIL Exterior Foot Light Lighting Time 15 s Changes the lighting time of the door mirror foot lights. 15 s / 7.5 s / 30 s LIGHT CONTROL: Display Default Contents Setting Light Auto OFF Delay 30s Keeps the headlights on for a certain period of time after turning the engine switch off and closing all the doors with the headlights on. OFF / 30 s / 60 s / 90 s Sensitivity NORMAL Adjusts the sensitivity of the automatic light control system. LIGHT2 / LIGHT1 / NORMAL / DARK1 / DARK2 Disp Ex OFF Sen NORMAL Changes the ambient brightness level to brighten the dimmed lights such as the indicator lights of the combination meter, A/C indicator light, and clock LIGHT2 / LIGHT1 / NORMAL / DARK1 / DARK2 Disp Ex ON Sen NORMAL Changes the ambient brightness level to dim the lights such as the indicator lights of the combination meter, A/C indicator light, and clock. LIGHT2 / LIGHT1 / NORMAL / DARK1 / DARK2 DRL Function ON ON / OFF of the DRL function ON / OFF HINT: Sensitivity adjustment can hardly be confirmed. Check by driving the customer's vehicle.
5. WIPER AND WASHER SYSTEM WIPER: Display Default Contents Setting Auto Wiper Available Function to change to the intermittent operation when the vehicle comes to a stop from driving condition with the wiper switch in the LO position Not Available / Available. Auto Wiper Available Function to operate the wiper automatically when it is raining Not Available / Available. Re - wiper Control Speed Mode Function to change the time between end of wiper motor operation and start of wiper operation to prevent streaking from washer fluid Speed Mode / 3 sec. / OFF
6. POWER DOOR LOCK CONTROL SYSTEM DOOR LOCK Tester Display Default Contents Setting Auto Lock A/T : OFF M/T : ON Function that locks doors when vehicle speed reaches 20 km/h (13 mph) ON/OFF Unlk/Key Twice (Unlock w/ 2 times D key operation) ON Function that unlocks only the driver side door when the driver side door key cylinder is turned to unlock once and unlocks all the doors when it is turned to unlock twice In the OFF setting, turning it once unlocks all doors ON/OFF All Unlk/Opn-Cl (All unlock w/ D door open-close) A/T : OFF M/T : ON Function that unlocks all other doors when opening driver side door within 10 seconds after turning the engine switch off from on (IG) ON/OFF Unlock/Park (Unlock w/ engine switch on (IG), shift P, speed 0 km/h (0 mph)) ON Function that unlocks doors when the shift lever is moved to the P position from any other position while the engine switch is on (IG) ON/OFF Auto Lock/Shift (Auto lock/shift not P) ON Function that locks doors when the shift lever is moved from the P position to any other position ON/OFF
7. WIRELESS DOOR LOCK CONTROL SYSTEM WIRELESS DOOR LOCK CONTROL SYSTEM Item (Display) Default Contents Setting Open Door Warning ON If a door is not completely closed and LOCK is pressed, this function sounds a buzzer for 10 seconds. ON / OFF Wireless Control (Wireless door lock control function) ON This function turns the wireless door lock function on or off. ON / OFF Panic Function ON This function operates the theft deterrent system when PANIC is pressed and held for 0.8 seconds. ON / OFF Unlock 2 Operation (Wireless unlock operated twice) ON This function unlocks the driver side door when UNLOCK is pressed once, and unlocks all doors when pressed twice. If set to OFF, pressing UNLOCK once unlocks all doors. ON / OFF Trunk Lid Operation (Wireless luggage compartment door open function setting) 0.8 PR This function changes operation method of transmitter to open luggage compartment door. 1 TIME: Push 1 time 2 TIMES: Push 2 times (within 3 seconds) 0.8 PR: Push longer than 0.8 seconds OFF: Does not operate 1 TIME / 2 TIMES / 0.8 PR / OFF Wireless Auto Lock ON Function to control automatic re-locking of doors after unlocking with wireless door lock function. ON / OFF Auto Lock Time 60 s This function controls the amount of time from unlocking doors to automatic re-locking. 30 s / 60 s / 120 s Hazard Answer Back (Hazard answer-back for wireless door lock operation) ON When LOCK is pressed, all hazard warning lights flash once. When UNLOCK is pressed, all hazard warning lights flash twice. ON / OFF Wireless Buzzer Resp (Buzzer answer-back of Wireless) ON This function makes the wireless door lock buzzer sound for answer-back when LOCK/UNLOCK is pressed. ON / OFF
8. SMART ACCESS SYSTEM WITH PUSH-BUTTON START (FOR DOOR LOCK) Smart (Smart Access System with Push-button Start) Tester Display Default Contents Setting Ignition Available Area ALL Function that switches the entry ignition detection area FRONT / ALL Park Wait Time (Waiting time to permit opening door after locking) 3.0s Function that sets waiting time to permit opening door after door is locked with entry lock function 1.0s / 2.0s / 3.0s / 5.5s Trunk Open Mode (Luggage compartment door open mode when vehicle is locked) ON Function to permit opening luggage compartment door ON / OFF Key Low Battery Warning (Warning when key battery becomes weak) ON Function that warns driver that the key's battery power is low ON / OFF
9. ENTRY UNLOCK MODE SWITCHING NOTE: Because the electrical key (card type) does not have a wireless transmitter function, it cannot be used to change the entry unlock mode. To change the vehicle entry unlock mode, make sure the vehicle power is off and simultaneously press and hold the electrical key LOCK switch and another electrical key switch for 5 seconds. Driver door unlock default setting: When the switches are pressed and held for 5 seconds, the entry door unlock mode changes to the mode that is not currently selected. NOTE: After pressing and holding the switches for 5 seconds, wait 5 seconds before performing the same procedure again. Driver door unlock mode: When the driver door touch sensor is touched, only the driver door unlocks. When any of the other touch sensors is touched, all doors unlock. All door unlock mode: When any of the touch sensors is touched, all doors unlock. The certification ECU receives wireless signal from the entry door control receiver and changes the smart access system with push-button start to entry unlock mode. The certification ECU sounds the buzzers of the wireless door lock buzzer and combination meter to inform the user that the mode has been changed. HINT: The procedure only changes the entry unlock mode of the smart access system with push-button start. It does not switch the unlocking of the wireless door lock control.
10. ELECTRICAL KEY CANCEL NOTE: Because the electrical key (card type) does not have a wireless transmitter function, it cannot be used to perform the entry key cancel operation. The electrical key cancel operation disables the following functions: Entry Unlock / Lock Entry Luggage Compartment Open Electrical key Lock-in Prevention Warning Memory Call The operation procedure is as follows: Precondition: Engine switch off, driver side door closed and unlocked Unlock the driver side door once with the UNLOCK switch of the electrical key. Open the driver door within 5 seconds. Unlock the driver side door twice with the UNLOCK switch of the electrical key within 5 seconds. Close and open the driver door twice within 30 seconds. (Driver door: Close --> Open --> Close --> Open) Unlock the driver side door twice with the UNLOCK switch of the electrical key within 5 seconds. Close and open the driver door within 30 seconds. (Driver door: Close --> Open) Close the driver door within 5 seconds. When electrical key cancel is activated, the wireless door lock buzzer sounds twice. To return to the original condition, perform this procedure again. When the original condition is returned, the wireless door lock buzzer sounds once.
11. METER / GAUGE SYSTEM COMBINATION METER: Tester Display Default Contents Setting Key Remind Volume Large Function to change the volume of the key remind warning buzzer Large, Medium, Small Key Remind Sound Normal Function to change the cycle of the key remind warning buzzer Fast, Normal, Slow Units By Region ML/G (*1) KM/L (*2) Function to change the unit of the trip information display ML/G, ML/G, KM/L HINT: The following items can be customized without using the Techstream. Item Default Contents Setting Seat belt warning buzzer (See procedure a b-on Function to change volume of key remind warning buzzer b-on, b-oFF Speed indicator (See procedure b 75 (mph) (*1) 120 (km/h) (*2) Function to change the value that decides the speed indicator when to illuminate 30 to 100 (mph) (*1), 50 to 160 (km/h) (*2) Tach indicator (See procedure b 5000 (RPM) Function to change the value that decides the tach indicator when to illuminate 2000 to 6500 (RPM) *1: U.S.A. *2: except U.S.A. Seat Belt Buzzer ON/OFF setting (Procedure "A") The buzzer ON/OFF setting, which is a setting of the buzzer function of the combination meter, can disable the driver and front passenger side seat belt buzzers. NOTE: These buzzers should be on for safe driving. Perform these procedures only if it is necessary to set the buzzer off (disabled). When either the battery cable or the combination meter connector is disconnected, these buzzers are set on (enabled). Odometer returns to 0 after starting this procedure, although it is not displayed. HINT: "b-oFF" indicates that the buzzer is OFF. "b-on" indicates that the buzzer is ON. The buzzer ON/OFF setting will be finished (the odometer will display "ODO") if the ODO/TRIP switch is not operated for 10 seconds or more. In this case, perform step 11 to check that the buzzer ON/OFF setting is complete. If it is not complete, start from step 1 again. Driver and front passenger side seat belt buzzers Engine switch on (IG). Press the ODO/TRIP switch until the odometer displays "ODO". Engine switch off. Engine switch on (IG). Press the ODO/TRIP switch immediately (within 6 seconds) and hold it down for 10 seconds or more. Continue holding down the ODO/TRIP switch and fasten the driver side seat belt. Check that the odometer displays either "b-on" or "b-oFF". Press the ODO/TRIP switch to change the display to "b-oFF". Engine switch off. Engine switch on (IG). Check that no buzzer sounds. Front passenger side seat belt buzzer Engine switch on (IG). Press the ODO/TRIP switch until the odometer displays "ODO". Engine switch off. Engine switch on (IG). Sit in the front passenger seat. Press the ODO/TRIP switch immediately (within 6 seconds) and hold it down for 10 seconds or more. Sit in the front passenger seat. Continue holding down the ODO/TRIP switch and fasten the front passenger side seat belt. Check that the odometer displays either "b-on" or "b-oFF". Press the ODO/TRIP switch to change the display to "b-oFF". Engine switch off. Engine switch on (IG). Check that no buzzer sounds. SPEED AND TACH INDICATOR (Procedure "B") Select the SPEED INDICATOR or TACH INDICATOR using the satellite switch (RH, ON/OFF, or LH switch). Turn the SPEED INDICATOR or TACH INDICATOR function off by using the ON/OFF switch. Turn the SPEED INDICATOR or TACH INDICATOR function on again by using the ON/OFF switch. Leave the display on for 1 second to allow it to change to the SET display. When SET flashes, the speedometer needle moves to indicate the previously set vehicle speed and then stops. Push the LH or RH switch within 6 seconds of the speedometer needle moving in order to allow setting of the speedometer indicator set point. The speedometer needle moves by 1 degree each time the LH or RH switch is pushed. Pushing and holding the switch changes values at a faster rate. When the ON/OFF switch is pushed, the speedometer or tachometer needle stays at the setting value for 1 second, the buzzer sounds once, and the SPEED indicator illuminates only momentarily one time in yellow.
12. INTUITIVE PARKING ASSIST SYSTEM WARNING Tester Display Default Contents Setting Rear Buzzer Onset Range Wide Function to set rear buzzer activation range / NARROW or WIDE NARROW: 600 mm(23.62 in.) WIDE: 1,500 mm (59.06 in.) Keep Sense Status Buzzer ON Function to make buzzer sound when distance between vehicle and obstacle does not change for more than 3 seconds ON / OFF Fr & Rr Buzzer Volume M2 Function to change volume of buzzer / L, M1, M2, M3 or H L: Low volume M1: medium low volume M2: medium volume M3: medium high volume H: High volume SENSOR Tester Display (ITEM) Default Contents Setting Non P/R Range Sensor F Function to set available sensors when shift position is not in P or R / F, Rcrn2 or F F, Rcrn2: Corner sensors are available F: front sensors are available
13. POWER WINDOW CONTROL SYSTEM POWER WINDOW Tester Display Default Content Setting Door Key Linked P/W Up ON Function that raises all power windows when, with engine switch off, key in driver door key cylinder is turned to and held in lock position for more than 1.5 seconds ON/OFF Door Key Linked P/W Down ON Function that lowers all power windows when, with engine switch off, key in driver door key cylinder is turned to and held in unlock position for more than 1.5 seconds ON/OFF P/W Down w/ Transmitter ON Function that lowers all power windows when, with engine switch off, unlock switch on transmitter is pressed and held for more than 3.0 seconds ON/OFF
14. REAR SUNSHADE SYSTEM OTHERS Tester Display Default Contents Selection R Output Time 0.7 sec. Function to change the time until operating the function linked shift R 0 / 0.7 / 0.9 / 1.2 R-Shade Reverse AVAIL NOT AVL/AVAIL of the rear sunshade reverse function. NOT AVL / AVAIL
15. SLIDING ROOF SYSTEM SLIDE ROOF Tester Display Default Contents Setting Door Key Related Open ON Function to manually open sliding roof linked with power window by holding driver side door key for 2.5 seconds or more to unlock position when engine switch is off ON/OFF Door Key Related Close ON Function to manually close sliding roof linked with power window by holding driver side door key for 2.5 seconds or more to lock position when engine switch is off ON/OFF Wireless Key Related Open ON Function to manually open sliding roof linked with power window by pressing transmitter UNLOCK switch for 3.4 seconds or more when engine switch is off ON/OFF Door Key Related Operation Slide Function to select tilt up or slide open of manual sliding roof operation linked with power window by holding driver side door key for 2.5 seconds or more to unlock position when engine switch is off Tilt/Slide Wireless Key Related Operation Slide Function to select tilt up or slide open of manual sliding roof operation linked with power window by pressing on transmitter UNLOCK switch for 3.4 seconds or more when engine switch is off Tilt/Slide
