Audio / Visual (Service Information): Overview Lexus IS II facelift

Entertainment Systems 21 illustrations ~910 words

Scheme 2

Scheme 2: ILLUSTRATION
Scheme 2: ILLUSTRATION

Scheme 3

Scheme 3: ILLUSTRATION
Scheme 3: ILLUSTRATION

Scheme 4

Scheme 4: REMOVAL
Scheme 4: REMOVAL

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (for Automatic Transmission) . Refer to «REMOVAL - Step 4»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  2. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transmission) . Refer to «REMOVAL - Step 5»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  3. REMOVE UPPER NO. 1 CONSOLE PANEL GARNISH (for Automatic Transmission) . Refer to «REMOVAL - Step 6»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  4. REMOVE UPPER NO. 2 CONSOLE PANEL GARNISH (for Automatic Transmission) . Refer to «REMOVAL - Step 7»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  5. REMOVE CONSOLE PANEL SUB-ASSEMBLY (for Automatic Transmission) . Refer to «REMOVAL - Step 8»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  6. REMOVE REAR CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission) . Refer to «REMOVAL - Step 9»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  7. REMOVE FRONT CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission) . Refer to «REMOVAL - Step 10»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  8. REMOVE FRONT ASH RECEPTACLE SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  9. REMOVE CONSOLE BOX REGISTER ASSEMBLY . Refer to «REMOVAL - Step 12»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  10. REMOVE CONSOLE BOX . Refer to «REMOVAL - Step 13»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  11. REMOVE NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY . Refer to «REMOVAL - Step 14»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  12. REMOVE CENTER LOWER INSTRUMENT CLUSTER FINISH PANEL . Refer to «REMOVAL - Step 15»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  13. REMOVE INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY (w/o Navigation System) Remove the 4 bolts. Pull the integration control panel w/ radio receiver assembly toward the rear of the vehicle. Disconnect each connector and remove the panel.
  14. REMOVE NO. 1 RADIO BRACKET (w/o Navigation System) Remove the 6 bolts and radio No. 1 bracket.
  15. REMOVE NO. 2 RADIO BRACKET (w/o Navigation System) Remove the 6 bolts and radio No. 2 bracket.
  16. REMOVE RADIO RECEIVER ASSEMBLY (w/o Navigation System) Slide the integration control panel in the direction shown by the arrow to remove the radio receiver assembly.
  17. REMOVE MULTI-DISPLAY WITH RADIO RECEIVER ASSEMBLY (w/ Navigation System) Remove the 4 bolts. Pull the multi-display w/ radio receiver assembly toward the rear of the vehicle. Disconnect each connector and remove the multi-display.
  18. REMOVE NO. 1 RADIO BRACKET (w/ Navigation System) Disengage the connector clamp. Remove the 7 bolts and radio No. 1 bracket.
  19. REMOVE NO. 2 RADIO BRACKET (w/ Navigation System) Remove the 7 bolts and radio No. 2 bracket.
  20. REMOVE RADIO RECEIVER ASSEMBLY (w/ Navigation System) Slide the multi-display in the direction shown by the arrow to remove the radio receiver assembly.

Scheme 13

Scheme 13: INSTALLATION
Scheme 13: INSTALLATION

Scheme 14

Scheme 14
Scheme 14
  1. INSTALL RADIO RECEIVER ASSEMBLY (w/o Navigation System) Install the radio receiver assembly as shown in the illustration.
  2. INSTALL NO. 2 RADIO BRACKET (w/o Navigation System) Install the radio No. 2 bracket with the 6 bolts.
  3. INSTALL NO. 1 RADIO BRACKET (w/o Navigation System) Install the radio No. 1 bracket with the 6 bolts.
  4. INSTALL INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY (w/o Navigation System) Connect each connector. Install the integration control panel w/ radio receiver assembly with the 4 bolts.
  5. INSTALL RADIO RECEIVER ASSEMBLY (w/ Navigation System) Install the radio receiver assembly as shown in the illustration.
  6. INSTALL NO. 2 RADIO BRACKET (w/ Navigation System) Install the radio No. 2 bracket with the 7 bolts.
  7. INSTALL NO. 1 RADIO BRACKET (w/ Navigation System) Install the radio No. 1 bracket with the 7 bolts. Engage the connector clamp.
  8. INSTALL MULTI-DISPLAY WITH RADIO RECEIVER ASSEMBLY (w/ Navigation System) Connect each connector. Install the multi-display w/ radio receiver assembly with the 4 bolts.
  9. INSTALL CENTER LOWER INSTRUMENT CLUSTER FINISH PANEL . Refer to «INSTALLATION - Step 40»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  10. INSTALL NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY . Refer to «INSTALLATION - Step 41»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  11. INSTALL CONSOLE BOX . Refer to «INSTALLATION - Step 42»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  12. INSTALL CONSOLE BOX REGISTER ASSEMBLY . Refer to «INSTALLATION - Step 43»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  13. INSTALL FRONT ASH RECEPTACLE SUB-ASSEMBLY . Refer to «INSTALLATION - Step 44»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  14. INSTALL FRONT CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission) . Refer to «INSTALLATION - Step 45»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  15. INSTALL REAR CONSOLE PANEL SUB-ASSEMBLY (for Manual Transmission) . Refer to «INSTALLATION - Step 46»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  16. INSTALL CONSOLE PANEL SUB-ASSEMBLY (for Automatic Transmission) . Refer to «INSTALLATION - Step 47»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  17. INSTALL UPPER NO. 2 CONSOLE PANEL GARNISH (for Automatic Transmission) . Refer to «INSTALLATION - Step 48»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  18. INSTALL UPPER NO. 1 CONSOLE PANEL GARNISH (for Automatic Transmission) . Refer to «INSTALLATION - Step 49»(/lexus/is/ii-facelift-2008-2010/remont/gauges-instrument-panels/#instrument-panel-service-information)
  19. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Manual Transmission)
  20. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (for Automatic Transmission)
  21. ADJUST CLOCK

Scheme 15

Scheme 15: ILLUSTRATION
Scheme 15: ILLUSTRATION

Scheme 16

Scheme 16: REMOVAL
Scheme 16: REMOVAL

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22
  1. REMOVE LUGGAGE COMPARTMENT TRIM COVER
  2. REMOVE DECK SIDE TRIM BOX RH
  3. REMOVE DECK SIDE TRIM BOX LH
  4. REMOVE ROPE HOOK ASSEMBLY Remove the 3 bolts and 3 rope hook assemblies.
  5. REMOVE REAR LUGGAGE COMPARTMENT TRIM COVER. Refer to «REMOVAL - Step 5»(ref-387357-S31768447742011022400000)
  6. REMOVE ROOM LIGHT ASSEMBLY. Refer to «REMOVAL - Step 6»(ref-387357-S31768447742011022400000)
  7. REMOVE ROPE HOOK. Refer to «REMOVAL - Step 7»(ref-387357-S31768447742011022400000)
  8. REMOVE FRONT LUGGAGE COMPARTMENT TRIM COVER. Refer to «REMOVAL - Step 8»(ref-387357-S31768447742011022400000)
  9. REMOVE LUGGAGE COMPARTMENT TRIM HOOK Remove the screw and luggage compartment trim hook.
  10. REMOVE SIDE LUGGAGE COMPARTMENT TRIM COVER Using a clip remover, remove the 3 clips and side luggage compartment trim cover.
  11. REMOVE STEREO COMPONENT AMPLIFIER ASSEMBLY WITH BRACKET Disconnect the connectors. Remove the 2 nuts and the stereo component amplifier assembly with bracket. Disengage the 2 clips and remove the amplifier cover.
  12. REMOVE NO. 1 AMPLIFIER BRACKET Remove the 2 bolts and the No. 1 amplifier bracket.
  13. REMOVE NO. 2 AMPLIFIER BRACKET Remove the 2 bolts and the No. 2 amplifier bracket.
  14. REMOVE STEREO COMPONENT AMPLIFIER ASSEMBLY
