TERMINALS OF ECU
HINT
This information describes the standard CAN values for all CAN related components.
Scheme 88
Scheme 89
Scheme 90
Scheme 91
Scheme 92
Scheme 93
Scheme 94
Scheme 95
Scheme 96
Scheme 97
Scheme 98
Scheme 99
Scheme 100
Scheme 101
Scheme 102
Scheme 103
Scheme 104
- CAN J/C (CAN LH J/C, CAN RH J/C) HINT: The connectors connected to the CAN J/C can be distinguished by the colors of the bus lines and the connecting side of the junction connector. The connectors can be connected to any terminals on the same side. CAN LH J/C WIRING COLOR: CAN LH J/C A Side (w/ Earth Terminal) Code Color (CANH Side) Color (CANL Side) Steering angle sensor J1 P W ECM J2 B W Seat belt control ECU (w/ Pre-collision system) J3 V W Center airbag sensor J4 R W WIRING COLOR: CAN LH J/C B Side (w/o Earth Terminal) Code Color (CANH Side) Color (CANL Side) Yaw rate sensor J5 P W Skid control ECU J6 R W CAN main bus line (bus line connecting CAN LH J/C and CAN RH J/C) J7 B W DLC3 J8 G W Distance control ECU (w/ Dynamic radar cruise control system) J9 GR W CAN RH J/C WIRING COLOR: CAN RH J/C A Side (w/ Earth Terminal) Code Color (CANH Side) Color (CANL Side) CAN main bus line (bus line connecting CAN RH J/C and CAN LH J/C) J81 B W Power steering ECU J82 P W WIRING COLOR: CAN RH J/C B Side (w/o Earth Terminal) Code Color (CANH Side) Color (CANL Side) Gateway ECU J84 B W 4WD control ECU (for 4WD) J86 V W The terminals on connectors for the CAN J/C Terminal Terminal Symbol 1 CANH 2 CANL Wiring diagram for identifying CAN J/C connectors
- DLC3 Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J21-6 (CANH) - J21-14 (CANL) G - W HIGH-level CAN bus line - LOW-level CAN bus line Engine switch off 54 to 69 ohms J21-6 (CANH) - J21-4 (CG) G - W-B HIGH-level CAN bus line - Ground Engine switch off 200 ohms or higher J21-14 (CANL) - J21-4 (CG) W - W-B LOW-level CAN bus line - Ground Engine switch off 200 ohms or higher J21-6 (CANH) - J21-16 (BAT) G - L HIGH-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher J21-14 (CANL) - J21-16 (BAT) W - L LOW-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher
- SKID CONTROL ECU WITH ACTUATOR Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A58-25 (CANH) - A58-14 (CANL) B - R HIGH-level CAN bus line - LOW-level CAN bus line Engine switch off 54 to 69 ohms A58-25 (CANH) - A58-1 (GND1) B - W-B HIGH-level CAN bus line - Ground Engine switch off 200 ohms or higher A58-14 (CANL) - A58-1 (GND1) R - W-B LOW-level CAN bus line - Ground Engine switch off 200 ohms or higher A58-25 (CANH) - A58-12 (+BS) B - BR HIGH-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher A58-14 (CANL) - A58-12 (+BS) R - BR LOW-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher
- STEERING ANGLE SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J23-10 (CANH) - J23-9 (CANL) P - W HIGH-level CAN bus line - LOW-level CAN bus line Engine switch off 54 to 69 ohms J23-10 (CANH) - J23-2 (ESS) P - W-B HIGH-level CAN bus line - Ground Engine switch off 200 ohms or higher J23-9 (CANL) - J23-2 (ESS) W - W-B LOW-level CAN bus line - Ground Engine switch off 200 ohms or higher J23-10 (CANH) - J23-3 (BAT) P - LG HIGH-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher J23-9 (CANL) - J23-3 (BAT) W - LG LOW-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher
- YAW RATE SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J91-3 (CANH) - J91-2 (CANL) P - W HIGH-level CAN bus line - LOW-level CAN bus line Engine switch off 54 to 69 ohms J91-3 (CANH) - J91-1 (GND) P - W-B HIGH-level CAN bus line - Ground Engine switch off 200 ohms or higher J91-2 (CANL) - J91-1 (GND) W - W-B LOW-level CAN bus line - Ground Engine switch off 200 ohms or higher J91-3 (CANH) - J21-16 (BAT) P - L HIGH-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher J91-2 (CANL) - J21-16 (BAT) W - L LOW-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher
- DISTANCE CONTROL ECU (w/ Dynamic radar cruise control system) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Condition Specified Condition J17-8 (CANH) - J17-9 (CANL) GR - W Engine switch off 54 to 69 ohms J17-8 (CANH) - J17-12 (GND) GR - BR Engine switch off 200 ohms or higher J17-9 (CANL) - J17-12 (GND) W - BR Engine switch off 200 ohms or higher J17-8 (CANH) - J21-16 (BAT) GR - L Cable disconnected from negative (-) battery terminal 6 kohms or higher J17-9 (CANL) - J21-16 (BAT) W - L Cable disconnected from negative (-) battery terminal 6 kohms or higher
- SEAT BELT CONTROL ECU (w/ Pre-collision system) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition Q59-1 (CANH) - Q59-2 (CANL) B - W HIGH-level CAN bus line - LOW-level CAN bus line Engine switch off 54 to 69 ohms Q59-1 (CANH) - Q58-8 (PGND) B - W-B HIGH-level CAN bus line - Ground Engine switch off 200 ohms or higher Q59-2 (CANL) - Q58-8 (PGND) W - W-B LOW-level CAN bus line - Ground Engine switch off 200 ohms or higher Q59-1 (CANH) - Q58-7 (+B) B - W HIGH-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher Q59-2 (CANL) - Q58-7 (+B) W - W LOW-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher
- 4WD CONTROL ECU (for 4WD) Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A32-14 (CANH) - A32-16 (CANL) B - V HIGH-level CAN bus line - LOW-level CAN bus line Engine switch off 54 to 69 ohms A32-14 (CANH) - A32-23 (GND) B - W-B HIGH-level CAN bus line - Ground Engine switch off 200 ohms or higher A32-16 (CANL) - A32-23 (GND) V - W-B LOW-level CAN bus line - Ground Engine switch off 200 ohms or higher A32-14 (CANH) - J21-16 (BAT) B - L HIGH-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher A32-16 (CANL) - J21-16 (BAT) V - L LOW-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher
- POWER STEERING ECU Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A31-2 (CANH) - A31-3 (CANL) B - R HIGH-level CAN bus line - LOW-level CAN bus line Engine switch off 54 to 69 ohms A31-2 (CANH) - A31-5 (PGND) B - B HIGH-level CAN bus line - Ground Engine switch off 200 ohms or higher A31-3 (CANL) - A31-5 (PGND) R - B LOW-level CAN bus line - Ground Engine switch off 200 ohms or higher A31-2 (CANH) - A31-4 (PIG) B - R HIGH-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher A31-3 (CANL) - A31-4 (PIG) R - R LOW-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher
- CENTER AIRBAG SENSOR Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J47-13 (CANH) - J47-22 (CANL) R - W HIGH-level CAN bus line - LOW-level CAN bus line Engine switch off 54 to 69 ohms J47-13 (CANH) - J47-25 (E1) R - W-B HIGH-level CAN bus line - Ground Engine switch off 200 ohms or higher J47-22 (CANL) - J47-25 (E1) W - W-B LOW-level CAN bus line - Ground Engine switch off 200 ohms or higher J47-13 (CANH) - J21-16 (BAT) R - L HIGH-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher J47-22 (CANL) - J21-16 (BAT) W - L LOW-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher
- ECM Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Condition Specified Condition A5-25 (CANH) - A5-24 (CANL) Engine switch off 108 to 132 ohms Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition A5-25 (CANH) - A5-24 (CANL) B - W HIGH-level CAN bus line - LOW-level CAN bus line Engine switch off 108 to 132 ohms A5-25 (CANH) - A5-2 (EC) B - W-B HIGH-level CAN bus line - Ground Engine switch off 200 ohms or higher A5-24 (CANL) - A5-2 (EC) W - W-B LOW-level CAN bus line - Ground Engine switch off 200 ohms or higher A5-25 (CANH) - A5-4 (BATT) B - L HIGH-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher A5-24 (CANL) - A5-4 (BATT) W - L LOW-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher
- GATEWAY ECU Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Condition Specified Condition J76-17 (CA1H) - J76-18 (CA1L) Engine switch off 108 to 132 ohms Measure the resistance according to the value(s) in the table below. Standard Resistance Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J76-17 (CA1H) - J76-18 (CA1L) B - W HIGH-level CAN bus line - LOW-level CAN bus line Engine switch off 108 to 132 ohms J76-17 (CA1H) - J76-24 (GND) B - W-B HIGH-level CAN bus line - Ground Engine switch off 200 ohms or higher J76-18 (CA1L) - J76-24 (GND) W - W-B LOW-level CAN bus line - Ground Engine switch off 200 ohms or higher J76-17 (CA1H) - J76-10 (BATT) B - LG HIGH-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher J76-18 (CA1L) - J76-10 (BATT) W - LG LOW-level CAN bus line - Battery positive Cable disconnected from negative (-) battery terminal 6 kohms or higher
FAIL-SAFE CHART
- FAIL-SAFE FUNCTION When communication fails in any of the CAN bus lines (communication lines), a fail-safe function(s) will operate. The fail-safe function that is specified for each system operates to prevent those systems from malfunctioning. The following table shows the effects on each system when communication is impossible. (For further details, see the informations for each system.) Function ECM Skid Control ECU Steering Angle Sensor Yaw Rate Sensor Distance Control ECU Condition when communication is impossible DTC detection (Driver detectable) VDIM Control (Controls driving force while VDIM is in operation) o • o o - VDIM function stops Detectable (Light comes on) Dynamic Radar Cruise (Maintains vehicle-to-vehicle distance) o o o o • Vehicle-to-Vehicle distance control does not operate Detectable (Light comes on) Pre-collision Control (Requests braking and seat belt tightening when an unavoidable collision possibility is detected) - o - - o Pre-collision is inoperative Detectable (Light comes on) Electric power steering (Outputs the assist current) o o o - - Control continues with steering assist force based on a vehicle speed of 100 km/h (62.2 mile/h) or equivalent Detectable (Light comes on) 4WD Control (Controls torque distribution to the front and rear wheels) o o o - - Fixed torque distribution Front 30: Rear 70 Can be recognized due to abnormal operation of the light Meter Display (Displays operation condition and DTCs) o o - - - Light does not come on or remains on Can be recognized due to abnormal operation of the light Function Seat belt control ECU Gateway ECU Power steering ECU Airbag ECU 4WD control ECU Condition when communication is impossible DTC detection (Driver detectable) VDIM Control (Controls driving force while VDIM is in operation) - - o - - VDIM function stops Detectable (Light comes on) Dynamic Radar Cruise (Maintains vehicle-to-vehicle distance) o - - - - Vehicle-to-Vehicle distance control does not operate Detectable (Light comes on) Pre-collision Control (Requests braking and seat belt tightening when an unavoidable collision possibility is detected) • - - o - Pre-collision is inoperative Detectable (Light comes on) Electric power steering (Outputs the assist current) - - • - - Control continues with steering assist force based on a vehicle speed of 100 km/h (62.2 mile/h) or equivalent Detectable (Light comes on) 4WD Control (Controls torque distribution to the front and rear wheels) - - - - • Fixed torque distribution Front 30: Rear 70 Can be recognized due to abnormal operation of the light Meter Display (Displays operation condition and DTCs) o • (Meter) o o o Light does not come on or remains on Can be recognized due to abnormal operation of the light HINT: •: Control master o: System related
PROCEDURE
- CHECK ECM POWER SOURCE CIRCUIT Check the ECM power source circuit. Refer to «ECM Power Source Circuit»(ref-387346-S04248617552011022400000) for 2GR-FSE. Refer to «ECM Power Source Circuit»(ref-387361-S23225864082011022400000) for 4GR-FSE). OK The ECM power source circuit is normal. HINT: If there is no abnormality in the ECM power source circuit, replace the ECM. NG --> REPAIR OR REPLACE ECM POWER SOURCE CIRCUIT OK --> REPLACE ECM
- CHECK FOR OPEN IN ONE SIDE OF CAN BRANCH WIRE Confirm the systems (ECUs and sensors), which use CAN communication, equipped on the vehicle. Refer to «DIAGNOSIS SYSTEM»(ref-387391-S05169532582011022400000) . Using the Techstream, select and perform "CAN Bus Check". Refer to «DIAGNOSIS SYSTEM»(ref-387391-S05169532582011022400000) . Observe the screen for approximately 1 minute to check the ECUs and sensors that are not displayed on the screen and also those that repeatedly appear and disappear from the screen. Disconnect the branch line connectors, which are connected to the ECUs or sensors that are not displayed on the screen, from the CAN J/C. WIRING COLOR: CAN LH J/C A Side (w/ Earth Terminal) Code Color (CANH Side) Color (CANL Side) Steering angle sensor J1 P W ECM J2 B W Seat belt control ECU (w/ Pre-collision system) J3 V W Center airbag sensor J4 R W WIRING COLOR: CAN LH J/C B Side (w/o Earth Terminal) Code Color (CANH Side) Color (CANL Side) Yaw rate sensor J5 P W Skid control ECU J6 R W CAN main bus line (bus line connecting CAN LH J/C and CAN RH J/C) J7 B W DLC3 J8 G W Distance control ECU (w/ Dynamic radar cruise control system) J9 GR W WIRING CLOR: CAN RH J/C A Side (w/Earth Terminal) Code Color (CANH Side) Color (CANL Side) CAN main bus line (bus line connecting CAN RH J/C and CAN LH J/C) J81 B W Power steering ECU J82 P W WIRING CLOR: CAN RH J/C B Side (w/o arth Terminal) Code Color (CANH Side) Color (CANL Side) Gateway ECU J84 B W 4WD Control ECU (for 4WD) J86 V W HINT: Connecting locations of the connectors shown in the above tables are those of a vehicle whose connector locations have never been changed. If the connector locations differ from those shown in the above tables, identify each connector according to the color of the bus lines. Check that the ECUs and sensors, which repeatedly appeared and disappeared from the "CAN Bus Check" screen, are constantly displayed. Perform the communication stop mode check for the ECUs and sensors which correspond to the disconnected branch line connectors. Refer to «PROBLEM SYMPTOMS TABLE»(ref-387391-S39962466682011022400000) . NEXT --> GO TO CORRESPONDING COMMUNICATION STOP MODE
