Power Mirror Control System (W/ Memory ) (Diagnostics & Symptom Tests): Other Lexus IS II facelift 2

PRECAUTION [08/2012 - ]

1. PRECAUTION FOR DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following systems after the cable is reconnected. System Name See Procedure Parking Assist Monitor System Refer to «INITIALIZATION [08/2012 - ]»(ref-606329-S33601054862014032500000)

Scheme 56

Scheme 57

Scheme 58

PROCEDURE

1. CHECK MULTIPLEX COMMUNICATION SYSTEM Use the Techstream to check if multiplex communication system is functioning normally. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2012 - ]»(ref-606519-S01282570262014032500000) . OK Multiplex communication DTC is not output. NG --> See step 8 OK: Go to next step
2. READ VALUE USING TECHSTREAM (OUTER MIRROR SWITCH ASSEMBLY) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Body / Data List. Read the Data List according to the display on the Techstream. BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note Mirror Selection SW (L) Mirror select switch signal for LH mirror / ON or OFF ON: Switch in L position OFF: Switch off or in R position - Mirror Position SW (R) Mirror adjust switch signal (right) / ON or OFF ON: Mirror adjust switch pressed right OFF: Mirror adjust switch not pressed right Check with the mirror select switch in the L position. Mirror Position SW (L) Mirror adjust switch signal (left) / ON or OFF ON: Mirror adjust switch pressed left OFF: Mirror adjust switch not pressed left Check with the mirror select switch in the L position. Mirror Position SW (Up) Mirror adjust switch signal (up) / ON or OFF ON: Mirror adjust switch pressed up OFF: Mirror adjust switch not pressed up Check with the mirror select switch in the L position. Mirror Position SW (Dwn) Mirror adjust switch signal (down) / ON or OFF ON: Mirror adjust switch not pressed down OFF: Mirror adjust switch not pressed down Check with the mirror select switch in the L position. OK On the Techstream screen, ON or OFF is displayed for each item according to the table above. NG --> See step 5 OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (POWER MIRROR CONTROL FUNCTION) Enter the following menus: Body Electrical / Mirror L / Active Test. Perform the Active Test according to the display on the Techstream. MIRROR L Tester Display Test Part Control Range Diagnostic Note Mirror Up/Down Mirror vertical operation Up / OFF / Down - Mirror Right/Left Mirror horizontal operation Right / OFF / Left - OK Power mirror operation is normal. NG --> See step 4 OK --> See step 7
4. INSPECT OUTER MIRROR ACTUATOR ASSEMBLY LH Remove the outer rear view mirror assembly LH. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000) . Apply battery voltage and check the operation of the outer rear view mirror assembly LH. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal h1-1 (DMVR) Battery negative (-) --> Terminal h1-10 (DM+R) Turns upward Battery negative (-) --> Terminal h1-1 (DMVR) Battery positive (+) --> Terminal h1-10 (DM+R) Turns downward Battery positive (+) --> Terminal h1-9 (DMHR) Battery negative (-) --> Terminal h1-10 (DM+R) Turns left Battery negative (-) --> Terminal h1-9 (DMHR) Battery positive (+) --> Terminal h1-10 (DM+R) Turns right NG --> See step 9 OK --> See step 11
5. INSPECT OUTER MIRROR SWITCH ASSEMBLY Remove the outer mirror switch assembly. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S06285686882014032500000) . Turn the mirror select switch to the L position. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition M18-16 (M+) - M18-14 (E) Mirror adjust switch pressed up 95 to 105 ohms Mirror adjust switch pressed down 446 to 493 ohms Mirror adjust switch pressed left 760 to 840 ohms Mirror adjust switch pressed right 237 to 262 ohms Mirror adjust switch not pressed 10 kohms or higher M18-13 (MSW) - M18-14 (E) Mirror select switch L 95 to 105 ohms Mirror select switch off 10 kohms or higher NG --> See step 10 OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (OUTER MIRROR SWITCH ASSEMBLY - MAIN BODY ECU) Disconnect the J74 connector from the main body ECU (cowl side junction block RH). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition M18-16 (M+) - J74-11 (MIRB) Always Below 1 ohms M18-13 (MSW) - J74-12 (MIRS) Always Below 1 ohms M18-14 (E) - J74-3 (MIRE) Always Below 1 ohms M18-16 (M+) - Body ground Always 10 kohms or higher M18-13 (MSW) - Body ground Always 10 kohms or higher M18-14 (E) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (OUTER MIRROR SWITCH ASSEMBLY - MAIN BODY ECU) OK --> REPLACE MAIN BODY ECU (COWL SIDE JUNCTION BLOCK RH)
7. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER SIDE). Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)
8. GO TO MULTIPLEX COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606519-S32480039292014032500000)
9. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY LH. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000)
10. REPLACE OUTER MIRROR SWITCH ASSEMBLY. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S06285686882014032500000)
11. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER SIDE). Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)

1. CHECK MULTIPLEX COMMUNICATION SYSTEM Use the Techstream to check if the multiplex communication system is functioning normally. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2012 - ]»(ref-606519-S01282570262014032500000) . OK Multiplex communication DTC is not output. NG --> See step 9 OK: Go to next step
2. READ VALUE USING TECHSTREAM (OUTER MIRROR SWITCH ASSEMBLY) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Body / Data List. Read the Data List according to the display on the Techstream. BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note Mirror Selection SW (R) Mirror select switch signal for RH mirror / ON or OFF ON: Switch in R position OFF: Switch off or in L position - Mirror Position SW (R) Mirror adjust switch signal (right) / ON or OFF ON: Mirror adjust switch pressed right OFF: Mirror adjust switch not pressed right Check with the mirror select switch in the R position Mirror Position SW (L) Mirror adjust switch signal (left) / ON or OFF ON: Mirror adjust switch pressed left OFF: Mirror adjust switch not pressed left Check with the mirror select switch in the R position Mirror Position SW (Up) Mirror adjust switch signal (up) / ON or OFF ON: Mirror adjust switch pressed up OFF: Mirror adjust switch not pressed up Check with the mirror select switch in the R position Mirror Position SW (Dwn) Mirror adjust switch signal (down) / ON or OFF ON: Mirror adjust switch pressed down OFF: Mirror adjust switch not pressed down Check with the mirror select switch in the R position OK On the Techstream screen, ON or OFF is displayed for each item according to the table above. NG --> See step 5 OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (POWER MIRROR CONTROL FUNCTION) Enter the following menus: Body Electrical / Mirror R / Active Test. Perform the Active Test according to the display on the Techstream. MIRROR R Tester Display Test Part Control Range Diagnostic Note Mirror Up/Down Mirror vertical operation Up / OFF / Down - Mirror Right/Left Mirror horizontal operation Right / OFF / Left - OK Power mirror operation is normal. NG --> See step 4 OK --> See step 7
4. INSPECT OUTER MIRROR ACTUATOR ASSEMBLY RH Remove the outer rear view mirror assembly RH. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000) . Apply battery voltage and check the operation of the outer rear view mirror assembly RH. OK Measurement Condition Specified Condition Battery positive (+) --> Terminal g1-1 (PMVR) Battery negative (-) --> Terminal g1-10 (PM+R) Turns upward Battery negative (-) --> Terminal g1-1 (PMVR) Battery positive (+) --> Terminal g1-10 (PM+R) Turns downward Battery positive (+) --> Terminal g1-9 (PMHR) Battery negative (-) --> Terminal g1-10 (PM+R) Turns left Battery negative (-) --> Terminal g1-9 (PMHR) Battery positive (+) --> Terminal g1-10 (PM+R) Turns right NG --> See step 10 OK --> See step 11
5. INSPECT OUTER MIRROR SWITCH ASSEMBLY Remove the outer mirror switch assembly. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S06285686882014032500000) . Turn the mirror select switch to the R position. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition M18-16 (M+) - M18-14 (E) Mirror adjust switch pressed up 95 to 105 ohms Mirror adjust switch pressed down 446 to 493 ohms Mirror adjust switch pressed left 760 to 840 ohms Mirror adjust switch pressed right 237 to 262 ohms Mirror adjust switch not pressed 10 kohms or higher M18-13 (MSW) - M18-14 (E) Mirror select switch R Below 1ohms Mirror select switch off 10 kohms or higher NG --> See step 8 OK: Go to next step
6. CHECK HARNESS AND CONNECTOR (OUTER MIRROR SWITCH ASSEMBLY - MAIN BODY ECU) Disconnect the J74 connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition M18-16 (M+) - J74-11 (MIRB) Always Below 1 ohms M18-13 (MSW) - J74-12 (MIRS) Always Below 1 ohms M18-14 (E) - J74-3 (MIRE) Always Below 1 ohms M18-16 (M+) - Body ground Always 10 kohms or higher M18-13 (MSW) - Body ground Always 10 kohms or higher M18-14 (E) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (OUTER MIRROR SWITCH ASSEMBLY - MAIN BODY ECU) OK --> REPLACE MAIN BODY ECU (COWL SIDE JUNCTION BLOCK RH)
7. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (PASSENGER SIDE). Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)
8. REPLACE OUTER MIRROR SWITCH ASSEMBLY. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S06285686882014032500000)
9. GO TO MULTIPLEX COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606519-S32480039292014032500000)
10. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY RH. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000)
11. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)

1. CHECK MULTIPLEX COMMUNICATION SYSTEM Use the Techstream to check if the multiplex communication system is functioning normally. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2012 - ]»(ref-606519-S01282570262014032500000) . OK Multiplex communication DTC is not output. NG --> See step 5 OK: Go to next step
2. READ VALUE USING TECHSTREAM (OUTER MIRROR SWITCH ASSEMBLY) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Body / Data List. Read the Data List according to the display on the Techstream. BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note Mirror Selection SW (R) Mirror select switch signal for RH mirror / ON or OFF ON: Switch in R position OFF: Switch off or in L position - Mirror Selection SW (L) Mirror select switch signal for LH mirror / ON or OFF ON: Switch in L position OFF: Switch off or in R position - Mirror Position SW (R) Mirror adjust switch signal (right) / ON or OFF ON: Mirror adjust switch pressed right OFF: Mirror adjust switch not pressed right Check with the mirror select switch in except neutral position Mirror Position SW (L) Mirror adjust switch signal (left) / ON or OFF ON: Mirror adjust switch pressed left OFF: Mirror adjust switch not pressed left Check with the mirror select switch in except neutral position Mirror Position SW (Up) Mirror adjust switch signal (up) / ON or OFF ON: Mirror adjust switch pressed up OFF: Mirror adjust switch not pressed up Check with the mirror select switch in except neutral position Mirror Position SW (Dwn) Mirror adjust switch signal (down) / ON or OFF ON: Mirror adjust switch pressed down OFF: Mirror adjust switch not pressed down Check with the mirror select switch in except neutral position OK On the Techstream screen, ON or OFF is displayed for each item according to the table above. NG --> See step 3 OK --> REPLACE MAIN BODY ECU (COWL SIDE JUNCTION BLOCK RH)
3. INSPECT OUTER MIRROR SWITCH ASSEMBLY Remove the outer mirror switch assembly. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S06285686882014032500000) . Turn the mirror select switch to the L position. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition M18-16 (M+) - M18-14 (E) Mirror adjust switch pressed up 95 to 105 ohms Mirror adjust switch pressed down 446 to 493 ohms Mirror adjust switch pressed left 760 to 840 ohms Mirror adjust switch pressed right 237 to 262 ohms Mirror adjust switch not pressed 10 kohms or higher M18-13 (MSW) - M18-14 (E) Mirror select switch L 95 to 105 ohms Mirror select switch off 10 kohms or higher Turn the mirror select switch to the R position. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition M18-16 (M+) - M18-14 (E) Mirror adjust switch pressed up 95 to 105 ohms Mirror adjust switch pressed down 446 to 493 ohms Mirror adjust switch pressed left 760 to 840 ohms Mirror adjust switch pressed right 237 to 262 ohms Mirror adjust switch not pressed 10 kohms or higher M18-13 (MSW) - M18-14 (E) Mirror select switch R Below 1ohms Mirror select switch off 10 kohms or higher NG --> See step 6 OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (OUTER MIRROR SWITCH ASSEMBLY - MAIN BODY ECU) Disconnect the J74 connector from the main body ECU (cowl side junction block RH). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition M18-16 (M+) - J74-11 (MIRB) Always Below 1 ohms M18-13 (MSW) - J74-12 (MIRS) Always Below 1 ohms M18-14 (E) - J74-3 (MIRE) Always Below 1 ohms M18-16 (M+) - Body ground Always 10 kohms or higher M18-13 (MSW) - Body ground Always 10 kohms or higher M18-14 (E) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (OUTER MIRROR SWITCH ASSEMBLY - MAIN BODY ECU) OK --> See step 7
5. GO TO MULTIPLEX COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606519-S32480039292014032500000)
6. REPLACE OUTER MIRROR SWITCH ASSEMBLY. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S06285686882014032500000)
7. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)

1. CHECK MULTIPLEX COMMUNICATION SYSTEM NG --> See step 12 OK: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM Connect the Techstream to the DLC3. Turn the engine switch on (IG). Enter the following menus: Body Electrical / Air Conditioner / Active Test. Perform an Active Test according to the display on the tester. Tester Display Test Part Control Range Diagnostic Note Mirror Heater Mirror heater operation OFF / ON - OK Mirrors become warm. NG --> See step 5 OK: Go to next step
3. REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY Replace the air conditioning amplifier assembly. Refer to «REMOVAL [08/2012 - ]»(ref-606491-S15241473622014032500000) NEXT: Go to next step
4. CONFIRM MIRROR HEATER OPERATION Turn the engine switch on (IG). Check mirror heater operation. Result Result Proceed to Mirrors become warm A Mirrors do not operate linked with automatic wiper B Mirrors do not operate linked with windshield wiper switch assembly C B --> See step 13 C --> See step 14 A --> END (AIR CONDITIONING AMPLIFIER ASSEMBLY WAS DEFECTIVE)
5. PERFORM ACTIVE TEST USING TECHSTREAM Select the Active Test, use the Techstream to issue a control command, and then check heater mirror relay operation. Check that operation sound of the heater mirror relay can be heard. OK Operation sound of the heater mirror relay can be heard. NG --> See step 9 OK: Go to next step
6. INSPECT HEATER MIRROR RELAY Remove the heater mirror relay. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 When battery voltage is applied to terminals 1 and 2 Below 1 ohms 3 - 5 When battery voltage is not applied to terminals 1 and 2 10 kohms or higher NG --> REPLACE HEATER MIRROR RELAY OK: Go to next step
7. CHECK HARNESS AND CONNECTOR (HEATER MIRROR RELAY - BATTERY) Measure the voltage according to the table below. Standard Voltage Tester Connection Condition Specified Condition Relay block terminal 5 - Body ground Always 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (HEATER MIRROR RELAY - BATTERY) OK: Go to next step
8. CHECK HARNESS AND CONNECTOR (HEATER MIRROR RELAY - OUTER REAR VIEW MIRROR) Disconnect the L14 and M15 connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Outer Rear View Mirror Assembly LH Outer Rear View Mirror Assembly RH Tester Connection Condition Specified Condition Relay block terminal 3 - M15-3 (+) Always Below 1 ohms Relay block terminal 3 - Body ground Always 10 kohms or higher M15-9 (-) - Body ground Always Below 1 ohms Tester Connection Condition Specified Condition Relay block terminal 3 - L14-3 (+) Always Below 1 ohms Relay block terminal 3 - Body ground Always 10 kohms or higher L14-9 (-) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (HEATER MIRROR RELAY - OUTER REAR VIEW MIRROR ASSEMBLY) OK --> See step 15
9. INSPECT HEATER MIRROR RELAY Remove the heater mirror relay. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 3 - 5 When battery voltage is applied to terminals 1 and 2 Below 1 ohms 3 - 5 When battery voltage is not applied to terminals 1 and 2 10 kohms or higher NG --> REPLACE HEATER MIRROR RELAY OK: Go to next step
10. CHECK HARNESS AND CONNECTOR (HEATER MIRROR RELAY - BATTERY) Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition Relay block terminal 1 - Body ground Engine switch on (IG) 11 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (HEATER MIRROR RELAY - BATTERY) OK: Go to next step
11. CHECK HARNESS AND CONNECTOR (HEATER MIRROR RELAY - A/C AMPLIFIER ASSEMBLY) Disconnect the J58 connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Relay block terminal 2 - J58-2 (MHTR) Always Below 1 ohms Relay block terminal 2 - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (HEATER MIRROR RELAY - A/C AMPLIFIER ASSEMBLY) OK --> See step 16
12. GO TO MULTIPLEX COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606519-S32480039292014032500000)
13. REPLACE RAIN SENSOR. Refer to «REMOVAL [08/2012 - ]»(ref-606488-S25544659392014032500000)
14. REPAIR WINDSHIELD WIPER SWITCH ASSEMBLY. Refer to «REMOVAL [08/2012 - ]»(ref-606488-S39233419652014032500000)
15. REPLACE OUTER REAR VIEW MIRROR ASSEMBLY. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000)
16. REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY. Refer to «REMOVAL [08/2012 - ]»(ref-606491-S15241473622014032500000)

1. CHECK MULTIPLEX COMMUNICATION SYSTEM Use the Techstream to check if the multiplex communication system is functioning normally. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2012 - ]»(ref-606519-S01282570262014032500000) . OK Multiplex communication DTC is not output. NG --> See step 8 OK: Go to next step
2. READ VALUE USING TECHSTREAM (OUTER MIRROR RETRACT SWITCH) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Body / Data List. Read the Data List according to the display on the Techstream. BODY Tester Display Measurement Item/Range Normal Condition Diagnostic Note Outer Mirror Fold SW Outer mirror retract switch signal / ON or OFF ON: Outer mirror retract switch in retract position OFF: Outer mirror retract switch in driving position - OK On the Techstream screen, ON or OFF is displayed for each item according to the above. NG --> See step 4 OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (MIRROR RETRACT FUNCTION) Enter the following menus: Body Electrical / Mirror L or Mirror R / Active Test. Perform the Active Test according to the display on the Techstream. MIRROR L / MIRROR R Tester Display Test Part Control Range Diagnostic Note Mirror Fold Mirror retract operation ON / OFF - Mirror Return Mirror retract operation ON / OFF - Result Result Proceed to Outer rear view mirror assemblies operate normally A Outer rear view mirror assembly RH does not operate normally B Outer rear view mirror assembly LH does not operate normally C B --> See step 6 C --> See step 7 A --> REPLACE MAIN BODY ECU (COWL SIDE JUNCTION BLOCK RH)
4. INSPECT OUTER MIRROR SWITCH ASSEMBLY Remove the outer mirror switch assembly. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S06285686882014032500000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition M18-22 (MR) - M18-20 (E) Retract position Below 1 ohms Except retract position 10 kohms or higher NG --> See step 10 OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (OUTER MIRROR SWITCH ASSEMBLY - MAIN BODY ECU) Disconnect the J74 connector from the main body ECU (cowl side junction block RH). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition J74-21 (RET) - M18-22 (MR) Always Below 1 ohms M18-22 (MR) - Body ground Always 10 kohms or higher M18-20 (E) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (OUTER MIRROR SWITCH ASSEMBLY - MAIN BODY ECU) OK --> REPLACE MAIN BODY ECU (COWL SIDE JUNCTION BLOCK RH)
6. INSPECT OUTER MIRROR ACTUATOR ASSEMBLY RH Remove the outer rear view mirror assembly RH. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000) . For each mirror position: Disconnect the battery, set the mirror position by hand, connect the battery, and check the retract mirror movement. NOTE: Disconnect and reconnect the battery for each mirror position check. The mirror position cannot be changed manually when the battery is connected. To change the mirror position manually, the battery must be disconnected first. OK Measurement Condition Mirror Position Specified Condition Battery positive (+) --> Terminal g1-3 (MR+) Battery negative (-) --> Terminal g1-11 (MR-) Forward position (A) Moves from (A) to retracted position (E) Battery negative (-) --> Terminal g1-3 (MR+) Battery positive (+) --> Terminal g1-11 (MR-) Forward position (A) Does not move Battery positive (+) --> Terminal g1-3 (MR+) Battery negative (-) --> Terminal g1-11 (MR-) Between forward position (A) and driving position (C) Moves from (B) to retracted position (E) Battery negative (-) --> Terminal g1-3 (MR+) Battery positive (+) --> Terminal g1-11 (MR-) Between forward position (A) and driving position (C) Moves from (B) to forward position (A) Battery positive (+) --> Terminal g1-3 (MR+) Battery negative (-) --> Terminal g1-11 (MR-) Driving position (C) Moves from (C) to retracted position (E) Battery negative (-) --> Terminal g1-3 (MR+) Battery positive (+) --> Terminal g1-11 (MR-) Driving position (C) Does not move Battery positive (+) --> Terminal g1-3 (MR+) Battery negative (-) --> Terminal g1-11 (MR-) Between driving position (C) and retracted position (E) Moves from (D) to retracted position (E) Battery negative (-) --> Terminal g1-3 (MR+) Battery positive (+) --> Terminal g1-11 (MR-) Between driving position (C) and retracted position (E) Moves from (D) to driving position (C) Battery positive (+) --> Terminal g1-3 (MR+) Battery negative (-) --> Terminal g1-11 (MR-) Retracted position (E) Does not move Battery negative (-) --> Terminal g1-3 (MR+) Battery positive (+) --> Terminal g1-11 (MR-) Retracted position (E) Moves from (E) to driving position (C) NG --> See step 12 OK --> See step 11
7. INSPECT OUTER MIRROR ACTUATOR ASSEMBLY LH Remove the outer rear view mirror assembly LH. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000) . For each mirror position: Disconnect the battery, set the mirror position by hand, connect the battery, and check the retract mirror movement. NOTE: Disconnect and reconnect the battery for each mirror position check. The mirror position cannot be changed manually when the battery is connected. To change the mirror position manually, the battery must be disconnected first. OK Measurement Condition Mirror Position Specified Condition Battery positive (+) --> Terminal h1-3 (MR+) Battery negative (-) --> Terminal h1-11 (MR-) Forward position (A) Moves from (A) to retracted position (E) Battery negative (-) --> Terminal h1-3 (MR+) Battery positive (+) --> Terminal h1-11 (MR-) Forward position (A) Does not move Battery positive (+) --> Terminal h1-3 (MR+) Battery negative (-) --> Terminal h1-11 (MR-) Between forward position (A) and driving position (C) Moves from (B) to retracted position (E) Battery negative (-) --> Terminal h1-3 (MR+) Battery positive (+) --> Terminal h1-11 (MR-) Between forward position (A) and driving position (C) Moves from (B) to forward position (A) Battery positive (+) --> Terminal h1-3 (MR+) Battery negative (-) --> Terminal h1-11 (MR-) Driving position (C) Moves from (C) to retracted position (E) Battery negative (-) --> Terminal h1-3 (MR+) Battery positive (+) --> Terminal h1-11 (MR-) Driving position (C) Does not move Battery positive (+) --> Terminal h1-3 (MR+) Battery negative (-) --> Terminal h1-11 (MR-) Between driving position (C) and retracted position (E) Moves from (D) to retracted position (E) Battery negative (-) --> Terminal h1-3 (MR+) Battery positive (+) --> Terminal h1-11 (MR-) Between driving position (C) and retracted position (E) Moves from (D) to driving position (C) Battery positive (+) --> Terminal h1-3 (MR+) Battery negative (-) --> Terminal h1-11 (MR-) Retracted position (E) Does not move Battery negative (-) --> Terminal h1-3 (MR+) Battery positive (+) --> Terminal h1-11 (MR-) Retracted position (E) Moves from (E) to driving position (C) NG --> See step 9 OK --> See step 13
8. GO TO MULTIPLEX COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606519-S32480039292014032500000)
9. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY LH. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000)
10. REPLACE OUTER MIRROR SWITCH ASSEMBLY. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S06285686882014032500000)
11. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)
12. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY RH. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000)
13. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)

1. CHECK MULTIPLEX COMMUNICATION SYSTEM Use the Techstream to check if multiplex communication system is functioning normally. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2012 - ]»(ref-606519-S01282570262014032500000) . OK Multiplex communication DTC is not output. NG --> See step 15 OK: Go to next step
2. CHECK AUTO POWER RETRACT MIRROR FUNCTION Perform an auto power retract mirror function properly. Refer to «ON-VEHICLE INSPECTION [08/2012 - ]»(ref-606613-S20944478372014032500000) . Result Result Proceed to Both mirrors functions are not normal A Only one mirror function is not normal B B --> See step 7 A: Go to next step
3. CHECK SMART ACCESS SYSTEM WITH PUSH-BUTTON START (ENTRY FUNCTION) Check the smart access system with push-button start (entry function). Refer to «ON-VEHICLE INSPECTION [08/2012 - ]»(ref-606592-S34868910772014032500000) . OK Smart access system with push-button start (entry function) is normal. NG --> See step 8 OK: Go to next step
4. CHECK POWER RETRACT MIRROR FUNCTION (MANUAL FUNCTION) Check the power retract mirror function (manual function). Refer to «ON-VEHICLE INSPECTION [08/2012 - ]»(ref-606613-S20944478372014032500000) . OK Power retract mirror function (manual function) is normal. NG --> See step 9 OK: Go to next step
5. CHECK AUTOMATIC MEMORY CALL FUNCTION Perform an automatic memory call function properly. Refer to «OPERATION CHECK [08/2012 - ]»(ref-606590-S08031380322014032500000) . OK Automatic memory call function is normal. NG --> See step 10 OK: Go to next step
6. CHECK COMBINATION METER ASSEMBLY Check that AUTO is on in satellite switch mode on the multi-information display. Refer to «SYSTEM DESCRIPTION [08/2012 - ]»(ref-606485-S21973912552014032500000) . Result Result Proceed to AUTO is on A AUTO is not on B NG --> See step 11 OK --> See step 12
7. CHECK POWER RETRACT MIRROR FUNCTION (MANUAL FUNCTION) Check power retract mirror function (manual function). Result Result Proceed to Power retract mirror function is normal A Power retract mirror on one side does not operate B B --> See step 13 A --> See step 14
8. GO TO SMART ACCESS SYSTEM WITH PUSH-BUTTON START (PROBLEM SYMPTOMS TABLE). Refer to «PROBLEM SYMPTOMS TABLE [08/2012 - ]»(ref-606526-S11361911422014032500000)
9. GO TO OTHER FLOW CHART. Refer to «Power Retractable Mirrors do not Operate with Power Retract Mirror Switch»(ref-606613-S34785849792014032500000)
10. GO TO OTHER FLOW CHART (PROBLEM SYMPTOMS TABLE). Refer to «PROBLEM SYMPTOMS TABLE [08/2012 - ]»(ref-606590-S31144029202014032500000)
11. GO TO METER / GAUGE SYSTEM (Satellite Switch Circuit). Refer to «Satellite Switch Circuit»(ref-606485-S42766827842014032500000)
12. REPLACE COMBINATION METER ASSEMBLY. Refer to «REMOVAL [08/2012 - ]»(ref-606486-S22433089902014032500000)
13. GO TO OTHER FLOW CHART (Power Retract Mirrors do not Operate). Refer to «Power Retractable Mirrors do not Operate with Power Retract Mirror Switch»(ref-606613-S34785849792014032500000)
14. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)
15. GO TO MULTIPLEX COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606519-S32480039292014032500000)

1. CHECK MULTIPLEX COMMUNICATION SYSTEM Use the Techstream to check if the multiplex communication system is functioning normally. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2012 - ]»(ref-606519-S01282570262014032500000) . OK Multiplex communication DTC is not output. NG --> See step 10 OK: Go to next step
2. CHECK SEAT MEMORY SWITCH FUNCTION Check that the memory operation is properly completed. HINT: Mirror surface position memory function is initiated by a signal from the position control ECU and switch assembly. Therefore, be sure to confirm that the seat position memory function operates normally. Refer to «OPERATION CHECK [08/2012 - ]»(ref-606590-S08031380322014032500000) . OK Seat position can be memorized using seat memory switch. NG --> See step 8 OK: Go to next step
3. CHECK MIRROR SURFACE POSITION MEMORY FUNCTION Check the mirror surface position memory function. Using the outer mirror switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the outer mirror switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded fully left position. HINT: Be sure to memorize the mirror surface position at the fully left position in order to confirm that a new position can be memorized because the mirror surface may be turned to the previously memorized position. Result Result Proceed to Both mirror surface positions are not memorized A RH side mirror surface position is not memorized B LH side mirror surface position is not memorized C B --> See step 4 C --> See step 6 A --> See step 11
4. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY RH Replace the outer mirror actuator assembly RH. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000) . NEXT: Go to next step
5. CHECK MIRROR SURFACE POSITION MEMORY FUNCTION Check the mirror surface position memory function. Using the outer mirror switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the outer mirror switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded fully left position. HINT: Be sure to memorize the mirror surface position at the fully left position in order to confirm that a new position can be memorized because the mirror surface may be turned to the previously memorized position. OK Mirror surface position memory function is normal. NG --> See step 9 OK --> END (OUTER MIRROR ACTUATOR ASSEMBLY RH WAS DEFECTIVE)
6. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY LH Replace the outer mirror actuator assembly LH. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000) . NEXT: Go to next step
7. CHECK MIRROR SURFACE POSITION MEMORY FUNCTION Check the mirror surface position memory function. Using the outer mirror switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the outer mirror switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded fully left position. HINT: Be sure to memorize the mirror surface position at the fully left position in order to confirm that a new position can be memorized because the mirror surface may be turned to the previously memorized position. OK Mirror surface position memory function is normal. NG --> See step 12 OK --> END (OUTER MIRROR ACTUATOR ASSEMBLY LH WAS DEFECTIVE)
8. GO TO POWER SEAT CONTROL SYSTEM. Refer to «PROBLEM SYMPTOMS TABLE [08/2012 - ]»(ref-606590-S31144029202014032500000)
9. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (PASSENGER SIDE). Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)
10. GO TO MULTIPLEX COMMUNICATION SYSTEM (DIAGNOSTIC TROUBLE CODE CHART). Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606519-S32480039292014032500000)
11. REPLACE POSITION CONTROL ECU AND SWITCH ASSEMBLY. Refer to «REMOVAL [08/2012 - ]»(ref-606514-S20781350072014032500000)
12. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER SIDE). Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)

1. CHECK MULTIPLEX COMMUNICATION SYSTEM Use the Techstream to check if the multiplex communication system is functioning normally. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2012 - ]»(ref-606519-S01282570262014032500000) . OK Multiplex communication DTC is not output. NG --> See step 10 OK: Go to next step
2. CHECK SEAT MEMORY SWITCH FUNCTION When any seat memory switch (M1 switch, M2 switch or M3 switch) is pressed, check that the driver side seat moves to the recorded position. OK The driver side seat moves to the memorized position. NG --> See step 11 OK: Go to next step
3. CHECK POWER MIRROR CONTROL FUNCTION (USING OUTER MIRROR SWITCH ASSEMBLY) Check the power mirror control function. Refer to «ON-VEHICLE INSPECTION [08/2012 - ]»(ref-606613-S20944478372014032500000) . OK Power mirror control function is normal. NG --> See step 12 OK: Go to next step
4. READ VALUE USING TECHSTREAM (MIRROR POSITION MEMORY) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Mirror L or Mirror R/ Data List. Read the Data List according to the display on the Techstream. MIRROR L / MIRROR R Tester Display Measurement Item/Range Normal Condition Diagnostic Note Mirror Memory No. 1 Mirror position memorized in seat memory switch M1 / ON or OFF ON: Memorized OFF: Not memorized - Mirror Memory No. 2 Mirror position memorized in seat memory switch M2 / ON or OFF ON: Memorized OFF: Not memorized - Mirror Memory No. 3 Mirror position memorized in seat memory switch M3 / ON or OFF ON: Memorized OFF: Not memorized - OK "ON" (Memorized) appears on the screen. NG --> See step 15 OK: Go to next step
5. CHECK MEMORY AND REACTIVATION FUNCTION Turn the engine switch on (IG). Using the outer mirror switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the outer mirror switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded fully left position. Result Result Proceed to Memory and reactivation function on both mirrors is normal A Memory and reactivation function on RH side mirror is not normal B Memory and reactivation function on LH side mirror is not normal C B --> See step 6 C --> See step 8 A --> See step 16
6. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY RH Replace the outer mirror actuator assembly RH. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000) . NEXT: Go to next step
7. CHECK MEMORY AND REACTIVATION FUNCTION Turn the engine switch on (IG). Using the outer mirror switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the outer mirror switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded fully left position. OK Memory and reactivation function is normal. NG --> See step 13 OK --> END (OUTER MIRROR ACTUATOR ASSEMBLY RH WAS DEFECTIVE)
8. REPLACE OUTER MIRROR ACTUATOR ASSEMBLY LH Replace the outer mirror actuator assembly LH. Refer to «REMOVAL [08/2012 - ]»(ref-606584-S10081630422014032500000) . NEXT: Go to next step
9. CHECK MEMORY AND REACTIVATION FUNCTION Turn the engine switch on (IG). Using the outer mirror switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the outer mirror switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded fully left position. OK Memory and reactivation function is normal. NG --> See step 14 OK --> END (OUTER MIRROR ACTUATOR ASSEMBLY LH WAS DEFECTIVE)
10. GO TO MULTIPLEX COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606519-S32480039292014032500000)
11. GO TO POWER SEAT CONTROL SYSTEM. Refer to «PROBLEM SYMPTOMS TABLE [08/2012 - ]»(ref-606590-S31144029202014032500000)
12. GO TO OTHER FLOW CHART. Refer to «Power Mirror cannot be Adjusted with Power Mirror Switch»(ref-606613-S19102284682014032500000)
13. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (Power Mirror Surface Position is not Memorized). Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)
14. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY (DRIVER SIDE). Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)
15. GO TO OTHER FLOW CHART (Power Mirror Surface Position is not Memorized). Refer to «Power Mirror Surface Position is not Memorized»(ref-606613-S27545290702014032500000)
16. REPLACE POSITION CONTROL ECU AND SWITCH. Refer to «REMOVAL [08/2012 - ]»(ref-606514-S20781350072014032500000)

1. CHECK MULTIPLEX COMMUNICATION SYSTEM Use the Techstream to check if multiplex communication system is functioning normally. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2012 - ]»(ref-606519-S01282570262014032500000) . OK Multiplex communication DTC is not output. NG --> See step 7 OK: Go to next step
2. CHECK REVERSE SHIFT-LINKED FUNCTION Turn the engine switch on (IG). Set the mirror select switch to L or R. Check that the mirror surface turns downward when the shift lever is moved to R. Result Result Proceed to Reverse shift-linked function on both mirrors is not normal A Reverse shift-linked function on either mirror is not normal B B --> See step 6 A: Go to next step
3. CHECK CAN COMMUNICATION SYSTEM Use the Techstream to check if the CAN communication system is functioning normally. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2012 - ]»(ref-606524-S11885193892014032500000) . OK CAN communication DTC is not output. NG --> See step 8 OK: Go to next step
4. CHECK FOR DTC (P705) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine / DTC. Check if DTC P0705 is output. Result Result Proceed to DTC P0705 is not output A DTC P0705 is output (for A760E) B DTC P0705 is output (for 4GR-FSE with A760H) C DTC P0705 is output (for 2GR-FSE with A760H) D DTC P0705 is output (for A960E) E B --> See step 9 C --> See step 10 D --> See step 16 E --> See step 11 A: Go to next step
5. READ VALUE USING TECHSTREAM Enter the following menus: Chassis / ABS/VSC / Data List. Read the Data List according to the display on the Techstream ABS/VSC/TRAC Tester Display Measurement Item/Range Normal Condition Diagnostic Note Shift Lever Position Shift lever position information / P/N, R, D/M, 1st-6th/B, FAIL Actual shift lever position - Result Result Proceed to R is displayed on the Techstream when the shift lever is in R A R is not displayed on the Techstream when the shift lever is in R (for 2GR-FSE) B R is not displayed on the Techstream when the shift lever is in R (for 4GR-FSE) C B --> See step 12 C --> See step 13 A --> REPLACE NETWORK GATEWAY ECU
6. CHECK MEMORY AND REACTIVATION FUNCTION Turn the engine switch on (IG). Using the outer mirror switch assembly, turn the mirror surface to the fully left position. Press the M1 switch while the SET switch is being pressed. Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized. Using the outer mirror switch assembly, turn the mirror surface to the fully right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded fully left position. OK Memory and reactivation function is normal. NG --> See step 14 OK --> See step 15
7. GO TO MULTIPLEX COMMUNICATION SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2012 - ]»(ref-606519-S32480039292014032500000)
8. GO TO CAN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2012 - ]»(ref-606524-S11885193892014032500000)
9. GO TO AUTOMATIC TRANSMISSION SYSTEM (for A760E). Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-606531-S32521245942014032500000)
10. GO TO AUTOMATIC TRANSAXLE SYSTEM (for 4GR-FSE with A760H). Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-606537-S42767998912014032500000)
11. GO TO AUTOMATIC TRANSAXLE SYSTEM (for A960E). Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-606540-S11109778482014032500000)
12. REPLACE ECM (for 2GR-FSE). Refer to «REMOVAL [08/2012 - ]»(ref-606479-S02413959172014032500000)
13. REPLACE ECM (for 4GR-FSE). Refer to «REMOVAL [08/2012 - ]»(ref-606499-S08803598952014032500000)
14. GO TO OTHER FLOW CHART (Power Mirrors do not Return to Memorized Position). Refer to «Power Mirrors do not Return to Memorized Position»(ref-606613-S15107910052014032500000)
15. REPLACE OUTER MIRROR CONTROL ECU ASSEMBLY. Refer to «DISASSEMBLY [08/2012 - ] - Step 13»(ref-606568-S15452695272014032500000)
16. GO TO AUTOMATIC TRANSMISSION SYSTEM (for 2GR-FSE with A760H). Refer to «DTC P0705: Transmission Range Sensor Circuit Malfunction (PRNDL Input)»(ref-606536-S25089481872014032500000)
