Automatic Transmission (A960E) (Diagnostic Codes & Circuit Tests): Other Lexus IS II facelift 2

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

TYPICAL MALFUNCTION THRESHOLDS

Scheme 817

PROCEDURE

1. INSPECT SPEED SENSOR INSTALLATION Check the speed sensor (SP2) installation. OK The installation bolt is tightened properly and there is no clearance between the sensor and transmission case. NG --> SECURELY INSTALL SPEED SENSOR OR REPLACE SPEED SENSOR OK: Go to next step
2. INSPECT SPEED SENSOR (SP2) Disconnect the speed sensor connector from the transmission. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 1 - 2 560 to 680 ohms NG --> REPLACE SPEED SENSOR (SP2) OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (SPEED SENSOR - ECM) Connect the speed sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) E4-23 (SP2+) - E4-22 (SP2-) 560 to 680 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) Tester Connection Specified Condition E4-23 (SP2+) - Body ground 10 kohms or higher E4-22 (SP2-) - Body ground ↑ NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM

One of the following conditions is met: Condition (A), (B) or (C)

CONDITION (A)

When shift lever is in S position, one of the following conditions is met

CONDITION (B)

All of following conditions are met

CONDITION (C)

COMPONENT OPERATING RANGE

Scheme 818

1. INSPECT PARK/NEUTRAL POSITION SWITCH ASSEMBLY Disconnect the park/neutral position switch connector. Measure resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard resistance Shift Position Tester Connection Specified Condition P 2 - 6 and 4 - 5 Below 1 ohms Except P ↑ 10 kohms or higher R 1 - 2 Below 1 ohms Except R ↑ 10 kohms or higher N 2 - 9 and 4 - 5 Below 1 ohms Except N ↑ 10 kohms or higher D, S, "+" and "-" 2 - 7 Below 1 ohms Except D, S, "+" and "-" ↑ 10 kohms or higher NG --> REPLACE PARK/NEUTRAL POSITION SWITCH ASSEMBLY OK: Go to next step
2. INSPECT TRANSMISSION CONTROL SWITCH Connect the park/neutral position switch connector. Disconnect the transmission control switch connector of shift lock control unit assembly. Measure resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard resistance Shift Position Tester Connection Specified Condition S, "+" and "-" 3 - 7 Below 1 ohms Except S, "+" and "-" ↑ 10 kohms or higher NG --> REPLACE TRANSMISSION CONTROL SWITCH OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ECM) Connect the transmission control switch connector of shift lock control unit assembly. Turn the engine switch on (IG) position, and measure the voltage according to the value(s) in the table below when the shift lever is moved to each position. Standard voltage Shift Position Tester Connection Specified Condition P and N E4-4 (STAR) - Body ground Below 1 V Except P and N ↑ 10 to 14 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (PARK/NEUTRAL POSITION SWITCH - ECM) Disconnect the ECM connector. Turn the engine switch on (IG) position, and measure the voltage according to the value(s) in the table below when the shift lever is moved to each position. Standard voltage Shift Position Tester Connection Specified Condition P E4-6 (P) - Body ground 10 to 14 V Except P ↑ Below 1 V N E4-32 (N) - Body ground 10 to 14 V Except N ↑ Below 1 V R E4-8 (R) - Body ground 10 to 14 V * Except R ↑ Below 1 V D and S E4-9 (D) - Body ground 10 to 14 V Except D and S ↑ Below 1 V S, "+" and "-" A6-9 (S) - Body ground 10 to 14 V Except S, "+" and "-" ↑ Below 1 V HINT: *: The voltage will drop slightly due to the turning on of the back up light. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM

ALL

CONDITION A

CONDITION B

CONDITION C

CONDITION D

CONDITION E

HINT

*1: Following conditions are met

CONDITION A, B, C AND D

CONDITION E

Scheme 819

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0711) Connect the Techstream to the DLC3. Turn the engine switch on (IG) position and push the Techstream main switch ON. When you use Techstream: Select the item "Powertrain / ECT / Trouble Codes". Read the DTCs using the Techstream. Result Display (DTC output) Proceed to Only "P0711" is output A "P0711" and other DTCs B HINT: If any other codes besides "P0711" are output, perform troubleshooting for those DTCs first. B --> GO TO DTC CHART A: Go to next step
2. CHECK TRANSMISSION FLUID LEVEL OK Automatic transmission fluid level is correct. NG --> ADD FLUID OK --> REPLACE TRANSMISSION WIRE

1. P0712: RANGE CHECK (LOW RESISTANCE) The monitor will run whenever these DTCs are not present. None Battery voltage 8 V or more Engine switch on (IG)

P0713: Range check (High resistance)

1. One of the following conditions is met: Condition (A) or (B) CONDITION (A) Engine coolant temperature (ECT) or intake air temperature (IAT) at engine start -29.375°C (-20.875°F) or less Time after engine start 297 seconds or more ECT sensor circuit fail (P0115, P0117, P0118) Not detected IAT sensor circuit fail (P0097, P0098, P0112, P0113) Not detected CONDITION (B) Engine coolant temperature (ECT) or intake air temperature (IAT) at engine start More than -29.375°C (-20.875°F) Time after engine start 10 seconds or more ECT sensor circuit fail (P0115, P0117, P0118) Not detected IAT sensor circuit fail (P0097, P0098, P0112, P0113) Not detected

P0712: RANGE CHECK (LOW RESISTANCE)

P0713: RANGE CHECK (HIGH RESISTANCE)

1. INSPECT TRANSMISSION WIRE (ATF TEMPERATURE SENSOR) Disconnect the transmission wire connector from the transmission. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 1 (E2) - 9 (OIL) 79 ohms to 156 kohms 1 (E2) - Body ground 10 kohms or higher 9 (OIL) - Body ground 10 kohms or higher HINT: If the resistance is out of the specified range with either the ATF temperature shown in the table below, the driveability of the vehicle may decrease. ATF Temperature Specified Condition 10°C (50°F) 5 to 8 kohms 25°C (77°F) 2.5 to 4.5 kohms 110°C (230°F) 0.22 to 0.28 kohms NG --> REPAIR OR REPLACE TRANSMISSION WIRE OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transmission. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition E4-27 (OIL) - E4-26 (EOIL) 79 ohms to 156 kohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check or short) Tester Connection Specified Condition E4-27 (OIL) - Body ground 10 kohms or higher E4-26 (EOIL) - Body ground ↑ NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM

Scheme 820

1. INSPECT SPEED SENSOR INSTALLATION Check the speed sensor (NT) installation. OK The installation bolt is tightened properly and there is no clearance between the sensor and transmission case. NG --> SECURELY INSTALL SPEED SENSOR OR REPLACE SPEED SENSOR OK: Go to next step
2. INSPECT SPEED SENSOR (NT) Disconnect the speed sensor connector from the transmission. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 1 - 2 560 to 680 ohms NG --> REPLACE SPEED SENSOR (NT) OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (SPEED SENSOR - ECM) Connect the speed sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) E4-21 (NT+) - E4-20 (NT-) 560 to 680 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) Tester Connection Specified Condition E4-21 (NT+) - Body ground 10 kohms or higher E4-20 (NT-) - Body ground ↑ NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM

GO and STOP is defined as follows

THE STOP LIGHT SWITCH REMAINS ON DURING GO AND STOP 5 TIMES.

1. READ VALUE USING DATA LIST (STP SIGNAL) HINT: Using Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG) position. Turn the Techstream on. Select the item "Powertrain / ECT / Data List". According to the display on the tester, read the "Data List". Standard Item Measurement Item/ Range (display) Normal Condition Stop Light Switch Stop light switch Status/ ON or OFF Brake Pedal is depressed: ON Brake Pedal is Released: OFF NOTE: In the table above, the conditions listed under "Normal Condition" are reference conditions. Do not depend solely on these reference conditions when deciding whether a part is faulty or not. OK --> See step 3 NG: Go to next step
2. INSPECT STOP LIGHT SWITCH ASSEMBLY Remove the stop light switch assembly. Measure the resistance according to the value(s) in the table below. Standard resistance Switch position Tester Connection Specified Condition Switch pin free 1 - 2 Below 1 ohms Switch pin pushed in ↑ 10 kohms or higher Switch pin free 3 - 4 10 kohms or higher Switch pin pushed in ↑ Below 1 ohms NG --> REPLACE STOP LIGHT SWITCH ASSEMBLY OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (STOP LIGHT SWITCH ASSEMBLY - ECM) Install the stop light switch assembly. Disconnect the ECM connector. Measure the voltage according to the value(s) in the table below when the brake pedal is depressed and released. Standard voltage Condition Tester Connection Specified Condition Brake pedal is depressed A6-4 (STP) - Body ground 10 to 14 V Brake pedal is released ↑ Below 1 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM

THE FOLLOWING ITEMS ARE COMMON TO ALL CONDITIONS BELOW.

CONDITION (A)

CONDITION (B)

Both of the following condition are met: Condition (A) and (B)

CONDITION (A)

CONDITION (B)

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0729) Connect the Techstream to the DLC3. Turn the engine switch on (IG) position and push the Techstream main switch ON. When you use Techstream: Select the item "Powertrain / ECT / Trouble Codes". Read the DTCs using the Techstream. Result Display (DTC output) Proceed to Only "P0729" is output A "P0729" and other DTCs B HINT: If any other codes besides "P0729" are output, perform troubleshooting for those DTCs first. B --> GO TO DTC CHART A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM HINT: Using the Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG) position. Turn the Techstream on. Select the item "Powertrain / ECT / Active Test". According to the display on tester, perform the "Active Test". HINT: While driving, the shift position can be forcibly changed with the Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART [08/2012 - ]»(ref-606494-S38462055682014032500000) . Item Test Details Diagnostic Note Control the Shift Position [Test Details] Operate the shift solenoid valve and set the each shift position by yourself. [Vehicle Condition] IDL: ON (4th, 5th and 6th) Less than 50 km/h (31 mph) [Others] Press "-->" button: Shift up Press "<--" button: Shift down Possible to check the operation of the shift solenoid valves. HINT: This test can be conducted when the vehicle speed is 50 km/h (31 mph) or less. The 4th to 5th and 5th to 6th up-shiftings must be performed with the accelerator pedal released. The 6th to 5th and 5th to 4th down-shiftings must be performed with the accelerator pedal released. Do not operate the accelerator pedal for at least 2 seconds after shifting and do not shift successively. The shift position commanded by the ECM is shown in the Data List (Shift Status) display on the Techstream. Gear positions in the event of a solenoid valve mechanical problem: Tester command gearshift 1st 2nd 3rd 4th 5th 6th Actual gear position under malfunction ↑ ↑ ↑ ↑ ↑ 4th OK Gear position changes in accordance with the tester command. NG --> REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFT SOLENOID VALVE SLT) NOTE: Perform the test at the normal operating ATF (Automatic Transmission Fluid) temperature: 50 to 80°C (122 to 176°F) Be careful to prevent SST hose from interfering with the exhaust pipe. This check must be conducted after checking and adjusting engine. Perform under condition that A/C is OFF. HINT: Using the Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Turn the engine switch off. Lift the vehicle up. Remove the test plug on the transmission case center right side and connect SST. SST: 09992-00095 09992-00231 09992-00271 Lower the vehicle. Fully apply the parking brake and chock the 4 wheels. Connect the Techstream to the DLC3. Start the engine. Warm up the ATF (Automatic Transmission Fluid). Measure the line pressure when the engine is idling. Turn the Techstream on. Select the item "Powertrain / ECT / Active Test". According to the display on tester, perform the "Active Test". Measure the line pressure with SST. Item Test Details Activate the Solenoid (SLT)* [Test Details] Operate the shift solenoid SLT and raise the line pressure. [Vehicle Condition] Vehicle Stopped. IDL: ON HINT: OFF: Line pressure up (When the active test of "Activate the Solenoid (SLT)" is performed, the ECM commands the SLT solenoid to turn off). ON: No action (normal operation) *: "Activate the Solenoid (SLT)" in the Active Test is performed to check the line pressure changes by connecting the SST to the automatic transmission, which is used in the HYDRAULIC TEST. Refer to «HYDRAULIC TEST [08/2012 - ]»(ref-606494-S32925369402014032500000) as well. HINT: The pressure values in Active Test and HYDRAULIC TEST are different from each other. OK The line pressure changes as specified when performing the Active Test. NG --> REPLACE SHIFT SOLENOID VALVE SLT OK: Go to next step
4. CLEAR THE DTC AND RUNNING TEST Clear the DTC, and check DTC again after conducting the "MONITOR DRIVE PATTERN FOR ECT TEST". Refer to «MONITOR DRIVE PATTERN [08/2012 - ]»(ref-606494-S35893142672014032500000) . OK No DTC code NG --> REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK --> END

Scheme 821

1. INSPECT TRANSMISSION WIRE (SL1) Disconnect the transmission wire connector from the transmission. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 11 (SL1+) - 3 (SL1-) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) Tester Connection Specified Condition 11 (SL1+) - Body ground 10 kohms or higher 3 (SL1-) - Body ground ↑ NG --> See step 3 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transmission. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) E4-25 (SL1+) - E4-24 (SL1-) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) Tester Connection Specified Condition E4-25 (SL1+) - Body ground 10 kohms or higher E4-24 (SL1-) - Body ground ↑ NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM
3. INSPECT SHIFT SOLENOID VALVE SL1 Remove the shift solenoid valve SL1. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SL1 OK --> REPAIR OR REPLACE TRANSMISSION WIRE

THE FOLLOWING ITEMS ARE COMMON TO ALL CONDITIONS BELOW.

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

OFF MALFUNCTION (C)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

[OFF malfunction]

Both of the following conditions are met

OFF malfunction (A)

OFF malfunction (B) or (C)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

OFF MALFUNCTION (C)

[ON malfunction]

Both of the following conditions are met: ON malfunction (A) and (B)

2 detections are necessary per driving cycle

1st detection; temporary flag ON

2nd detection; pending fault code ON

ON MALFUNCTION (A)

ON MALFUNCTION (B)

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0751) Connect the Techstream to the DLC3. Turn the engine switch on (IG) position and push the Techstream main switch ON. When you use Techstream: Select the item "Powertrain / ECT / Trouble Codes". Read the DTCs using the Techstream. Result Display (DTC output) Proceed to Only "P0751" is output A "P0751" and other DTCs B HINT: If any other codes besides "P0751" are output, perform troubleshooting for those DTCs first. B --> GO TO DTC CHART A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFT SOLENOID VALVE SLT) NOTE: Perform the test at the normal operating ATF (Automatic Transmission Fluid) temperature: 50 to 80°C (122 to 176°F) Be careful to prevent SST hose from interfering with the exhaust pipe. This check must be conducted after checking and adjusting engine. Perform under condition that A/C is OFF. HINT: Using the Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Turn the engine switch off. Lift the vehicle up. Remove the test plug on the transmission case center right side and connect SST. SST: 09992-00095 09992-00231 09992-00271 Lower the vehicle. Fully apply the parking brake and chock the 4 wheels. Connect the Techstream to the DLC3. Start the engine. Warm up the ATF (Automatic Transmission Fluid). Measure the line pressure when the engine is idling. Turn the Techstream on. Select the item "Powertrain / ECT / Active Test". According to the display on tester, perform the "Active Test". Measure the line pressure with SST. Item Test Details Activate the Solenoid (SLT)* [Test Details] Operate the shift solenoid SLT and raise the line pressure. [Vehicle Condition] Vehicle Stopped. IDL: ON HINT: OFF: Line pressure up (When the active test of "Activate the Solenoid (SLT)" is performed, the ECM commands the SLT solenoid to turn off). ON: No action (normal operation) *: "Activate the Solenoid (SLT)" in the Active Test is performed to check the line pressure changes by connecting the SST to the automatic transmission, which is used in the HYDRAULIC TEST. Refer to «HYDRAULIC TEST [08/2012 - ]»(ref-606494-S32925369402014032500000) as well. HINT: The pressure values in Active Test and HYDRAULIC TEST are different from each other. OK The line pressure changes as specified when performing the Active Test. NG --> REPLACE SHIFT SOLENOID VALVE SLT OK: Go to next step
3. INSPECT SHIFT SOLENOID VALVE S1 Remove the shift solenoid valve S1. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S1) - Solenoid Body (S1) 11 to 15 ohms Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE S1 OK: Go to next step
4. INSPECT TRANSMISSION VALVE BODY ASSEMBLY OK There are no foreign objects on each valve. NG --> REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK --> REPLACE AUTOMATIC TRANSMISSION ASSEMBLY

THE FOLLOWING ITEMS ARE COMMON TO ALL CONDITIONS BELOW.

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

[OFF malfunction]

Both of the following conditions are met: OFF malfunctions (A) and (B)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

[ON malfunction]

Both of the following conditions are met: ON malfunctions (A) and (B)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0756) Connect the Techstream to the DLC3. Turn the engine switch on (IG) position and push the Techstream main switch ON. When you use Techstream: Select the item "Powertrain / ECT / Trouble Codes". Read the DTCs using the Techstream. Result Display (DTC output) Proceed to Only "P0756" is output A "P0756" and other DTCs B HINT: If any other codes besides "P0756" are output, perform troubleshooting for those DTCs first. B --> GO TO DTC CHART A: Go to next step
2. INSPECT SHIFT SOLENOID VALVE S2 Remove the shift solenoid valve S2. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S2) - Solenoid Body (S2) 11 to 15 ohms Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE S2 OK: Go to next step
3. INSPECT TRANSMISSION VALVE BODY ASSEMBLY OK There are no foreign objects on each valve. NG --> REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK --> REPAIR OR REPLACE AUTOMATIC TRANSMISSION ASSEMBLY

THE FOLLOWING ITEMS ARE COMMON TO ALL CONDITIONS BELOW.

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

[OFF malfunction]

Both of the following condition are met: OFF malfunctions (A) and (B)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

[ON malfunction]

One of the following conditions is met: ON malfunctions (A), (B) or (C)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0761) Connect the Techstream to the DLC3. Turn the engine switch on (IG) position and push the Techstream main switch ON. When you use Techstream: Select the item "Powertrain / ECT / Trouble Codes". Read the DTCs using the Techstream. Result Display (DTC output) Proceed to Only "P0761" is output A "P0761" and other DTCs B HINT: If any other codes besides "P0761" are output, perform troubleshooting for those DTCs first. B --> GO TO DTC CHART A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFT SOLENOID VALVE SLT) NOTE: Perform the test at the normal operating ATF (Automatic Transmission Fluid) temperature: 50 to 80°C (122 to 176°F) Be careful to prevent SST hose from interfering with the exhaust pipe. This check must be conducted after checking and adjusting engine. Perform under condition that A/C is OFF. HINT: Using the Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Turn the engine switch off. Lift the vehicle up. Remove the test plug on the transmission case center right side and connect SST. SST: 09992-00095 09992-00231 09992-00271 Lower the vehicle. Fully apply the parking brake and chock the 4 wheels. Connect the Techstream to the DLC3. Start the engine. Warm up the ATF (Automatic Transmission Fluid). Measure the line pressure when the engine is idling. Turn the Techstream on. Select the item "Powertrain / ECT / Active Test". According to the display on tester, perform the "Active Test". Measure the line pressure with SST. Item Test Details Activate the Solenoid (SLT)* [Test Details] Operate the shift solenoid SLT and raise the line pressure. [Vehicle Condition] Vehicle Stopped. IDL: ON HINT: OFF: Line pressure up (When the active test of "Activate the Solenoid (SLT)" is performed, the ECM commands the SLT solenoid to turn off). ON: No action (normal operation) *: "Activate the Solenoid (SLT)" in the Active Test is performed to check the line pressure changes by connecting the SST to the automatic transmission, which is used in the HYDRAULIC TEST. Refer to «HYDRAULIC TEST [08/2012 - ]»(ref-606494-S32925369402014032500000) as well. HINT: The pressure values in Active Test and HYDRAULIC TEST are different from each other. OK The line pressure changes as specified when performing the Active Test. NG --> REPLACE SHIFT SOLENOID VALVE SLT OK: Go to next step
3. INSPECT SHIFT SOLENOID VALVE S3 Remove the shift solenoid valve S3. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S3) - Solenoid Body (S3) 11 to 15 ohms Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE S3 OK: Go to next step
4. INSPECT TRANSMISSION VALVE BODY ASSEMBLY OK There are no foreign objects on each valve. NG --> REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK --> REPAIR OR REPLACE AUTOMATIC TRANSMISSION ASSEMBLY

ALL

P0766 OFF MALFUNCTION (A) AND P0776 ON MALFUNCTION (A)

P0766 OFF MALFUNCTION (B) AND P0776 ON MALFUNCTION (B)

[OFF malfunction]

1. Both of the following conditions are met: OFF malfunction (A) and (B)

P0766 OFF MALFUNCTION (A)

P0766 OFF MALFUNCTION (B)

[ON malfunction]

1. Both of the following conditions are met: ON malfunction (A) and (B)

P0776 ON MALFUNCTION (A)

P0776 ON MALFUNCTION (B)

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0766 AND P0776) Connect the Techstream to the DLC3. Turn the engine switch on (IG) position and push the Techstream main switch ON. When you use Techstream: Select the item "Powertrain / ECT / Trouble Codes". Read the DTCs using the Techstream. Result Display (DTC output) Proceed to Only P0766 and P0776 are output A P0766, P0776 and other DTCs are output B HINT: If any other codes besides P0766 and P0776 are output, perform troubleshooting for those DTCs first. B --> GO TO DTC CHART A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFT SOLENOID VALVE SLT) NOTE: Perform the test at the normal operating ATF (Automatic Transmission Fluid) temperature: 50 to 80°C (122 to 176°F) Be careful to prevent SST hose from interfering with the exhaust pipe. This check must be conducted after checking and adjusting engine. Perform under condition that A/C is OFF. HINT: Using the Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Turn the engine switch off. Lift the vehicle up. Remove the test plug on the transmission case center right side and connect SST. SST: 09992-00095 09992-00231 09992-00271 Lower the vehicle. Fully apply the parking brake and chock the 4 wheels. Connect the Techstream to the DLC3. Start the engine. Warm up the ATF (Automatic Transmission Fluid). Measure the line pressure when the engine is idling. Turn the Techstream on. Select the item "Powertrain / ECT / Active Test". According to the display on tester, perform the "Active Test". Measure the line pressure with SST. Item Test Details Activate the Solenoid (SLT)* [Test Details] Operate the shift solenoid SLT and raise the line pressure. [Vehicle Condition] Vehicle Stopped. IDL: ON HINT: OFF: Line pressure up (When the active test of "Activate the Solenoid (SLT)" is performed, the ECM commands the SLT solenoid to turn off). ON: No action (normal operation) *: "Activate the Solenoid (SLT)" in the Active Test is performed to check the line pressure changes by connecting the SST to the automatic transmission, which is used in the HYDRAULIC TEST. Refer to «HYDRAULIC TEST [08/2012 - ]»(ref-606494-S32925369402014032500000) as well. HINT: The pressure values in Active Test and HYDRAULIC TEST are different from each other. OK The line pressure changes as specified when performing the Active Test. NG --> REPLACE SHIFT SOLENOID VALVE SLT OK: Go to next step
3. INSPECT SHIFT SOLENOID VALVE S4 Remove the shift solenoid valve S4. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S4) - Solenoid Body (S4) 11 to 15 ohms Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE S4 OK: Go to next step
4. INSPECT SHIFT SOLENOID VALVE SL2 Remove the shift solenoid valve SL2. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SL2 OK: Go to next step
5. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. OK There are no foreign objects on each valve. NG --> REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK --> REPAIR OR REPLACE AUTOMATIC TRANSMISSION ASSEMBLY

Scheme 822

1. INSPECT TRANSMISSION WIRE (SL2) Disconnect the transmission wire connector from the transmission. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 10 (SL2+) - 2 (SL2-) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) Tester Connection Specified Condition 10 (SL2+) - Body ground 10 kohms or higher 2 (SL2-) - Body ground ↑ NG --> See step 3 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transmission. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) E4-11 (SL2+) - E4-10 (SL2-) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) Tester Connection Specified Condition E4-11 (SL2+) - Body ground 10 kohms or higher E4-10 (SL2-) - Body ground ↑ NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM
3. INSPECT SHIFT SOLENOID SL2 Remove the shift solenoid valve SL2. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID SL2 OK --> REPAIR OR REPLACE TRANSMISSION WIRE

THE FOLLOWING ITEMS ARE COMMON TO ALL CONDITIONS BELOW.

CONDITION (A)

CONDITION (B)

CONDITION (C)

CONDITION (D)

Both of the following conditions are met: Condition (A), and Condition (B), (C) or (D)

MALFUNCTION (A)

MALFUNCTION (B)

MALFUNCTION (C)

MALFUNCTION (D)

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P0781) Connect the Techstream to the DLC3. Turn the engine switch on (IG) position and push the Techstream main switch ON. When you use Techstream: Select the item "Powertrain / ECT / Trouble Codes". Read the DTCs using the Techstream. Result Display (DTC output) Proceed to Only "P0781" is output A "P0781" and other DTCs B HINT: If any other codes besides "P0781" are output, perform troubleshooting for those DTCs first. B --> GO TO DTC CHART A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM HINT: Using the Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG) position. Turn the Techstream on. Select the item "Powertrain / ECT / Active Test". According to the display on tester, perform the "Active Test". HINT: While driving, the shift position can be forcibly changed with the Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART [08/2012 - ]»(ref-606494-S38462055682014032500000) . Item Test Details Diagnostic Note Control the Shift Position [Test Details] Operate the shift solenoid valve and set the each shift position by yourself. [Vehicle Condition] IDL: ON (4th, 5th and 6th) Less than 50 km/h (31 mph) [Others] Press "-->" button: Shift up Press "<--" button: Shift down Possible to check the operation of the shift solenoid valves. HINT: This test can be conducted when the vehicle speed is 50 km/h (31 mph) or less. The 4th to 5th and 5th to 6th up-shiftings must be performed with the accelerator pedal released. The 6th to 5th and 5th to 4th down-shiftings must be performed with the accelerator pedal released. Do not operate the accelerator pedal for at least 2 seconds after shifting and do not shift successively. The shift position commanded by the ECM is shown in the Data List (Shift Status) display on the Techstream. Gear positions in the event of a solenoid valve mechanical problem: Tester command gear shift 1st 2nd 3rd 4th 5th 6th Actual gear position under malfunction ↑ 1st ↑ 3rd N* N* N*: Neutral OK Gear position changes in accordance with the tester command. NG --> REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFT SOLENOID VALVE SLT) NOTE: Perform the test at the normal operating ATF (Automatic Transmission Fluid) temperature: 50 to 80°C (122 to 176°F) Be careful to prevent SST hose from interfering with the exhaust pipe. This check must be conducted after checking and adjusting engine. Perform under condition that A/C is OFF. HINT: Using the Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Turn the engine switch off. Lift the vehicle up. Remove the test plug on the transmission case center right side and connect SST. SST: 09992-00095 09992-00231 09992-00271 Lower the vehicle. Fully apply the parking brake and chock the 4 wheels. Connect the Techstream to the DLC3. Start the engine. Warm up the ATF (Automatic Transmission Fluid). Measure the line pressure when the engine is idling. Turn the Techstream on. Select the item "Powertrain / ECT / Active Test". According to the display on tester, perform the "Active Test". Measure the line pressure with SST. Item Test Details Activate the Solenoid (SLT)* [Test Details] Operate the shift solenoid SLT and raise the line pressure. [Vehicle Condition] Vehicle Stopped. IDL: ON HINT: OFF: Line pressure up (When the active test of "Activate the Solenoid (SLT)" is performed, the ECM commands the SLT solenoid to turn off). ON: No action (normal operation) *: "Activate the Solenoid (SLT)" in the Active Test is performed to check the line pressure changes by connecting the SST to the automatic transmission, which is used in the HYDRAULIC TEST. Refer to «HYDRAULIC TEST [08/2012 - ]»(ref-606494-S32925369402014032500000) as well. HINT: The pressure values in Active Test and HYDRAULIC TEST are different from each other. OK The line pressure changes as specified when performing the Active Test. NG --> REPLACE SHIFT SOLENOID VALVE SLT OK: Go to next step
4. CLEAR THE DTC AND RUNNING TEST Clear the DTC, and check DTC again after conducting the "MONITOR DRIVE PATTERN FOR ECT TEST". Refer to «MONITOR DRIVE PATTERN [08/2012 - ]»(ref-606494-S35893142672014032500000) . OK No DTC code NG --> REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK --> END

Scheme 823

The linear solenoid valve (SLT) controls the transmission line pressure for smooth transmission operation based on signals from the throttle position sensor and the vehicle speed sensor. The ECM adjusts the duty ratio (*) of the SLT solenoid valve to control hydraulic line pressure coming from the primary regulator valve. Appropriate line pressure assures smooth shifting with varying engine outputs.

HINT

*: The duty ratio is the ratio of the current ON time (A) to the total of the current ON and OFF time (A + B).

Duty Ratio (%) = A / (A + B) x 100

ALL

[P0894: ON malfunction]

1. When either condition below is met: OFF malfunction (A) or (B)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

[P2714: ON malfunction]

1. One of the following conditions is met: ON malfunction (A), (B), (C), (D), (E), (F), (G) or (H)

ON MALFUNCTION (A)

ON MALFUNCTION (B)

ON MALFUNCTION (C)

ON MALFUNCTION (D)

ON MALFUNCTION (E)

ON MALFUNCTION (F)

ON MALFUNCTION (G)

ON MALFUNCTION (H)

1. CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0894 AND P2714) Connect the Techstream to the DLC3. Turn the engine switch on (IG) position and push the Techstream main switch ON. When you use Techstream: Select the item "Powertrain / ECT / Trouble Codes". Read the DTCs using the Techstream. Result Display (DTC output) Proceed to Only P0894 is output Only P0894 and P2714 are output A P0894, P2714 and other DTCs are output B HINT: If any other codes besides P0894 and P2714 are output, perform troubleshooting for those DTCs first. B --> GO TO DTC CHART A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFT SOLENOID VALVE SLT) NOTE: Perform the test at the normal operating ATF (Automatic Transmission Fluid) temperature: 50 to 80°C (122 to 176°F) Be careful to prevent SST hose from interfering with the exhaust pipe. This check must be conducted after checking and adjusting engine. Perform under condition that A/C is OFF. HINT: Using the Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Turn the engine switch off. Lift the vehicle up. Remove the test plug on the transmission case center right side and connect SST. SST: 09992-00095 09992-00231 09992-00271 Lower the vehicle. Fully apply the parking brake and chock the 4 wheels. Connect the Techstream to the DLC3. Start the engine. Warm up the ATF (Automatic Transmission Fluid). Measure the line pressure when the engine is idling. Turn the Techstream on. Select the item "Powertrain / ECT / Active Test". According to the display on tester, perform the "Active Test". Measure the line pressure with SST. Item Test Details Activate the Solenoid (SLT)* [Test Details] Operate the shift solenoid SLT and raise the line pressure. [Vehicle Condition] Vehicle Stopped. IDL: ON HINT: OFF: Line pressure up (When the active test of "Activate the Solenoid (SLT)" is performed, the ECM commands the SLT solenoid to turn off). ON: No action (normal operation) *: "Activate the Solenoid (SLT)" in the Active Test is performed to check the line pressure changes by connecting the SST to the automatic transmission, which is used in the HYDRAULIC TEST. Refer to «HYDRAULIC TEST [08/2012 - ]»(ref-606494-S32925369402014032500000) as well. HINT: The pressure values in Active Test and HYDRAULIC TEST are different from each other. OK The line pressure changes as specified when performing the Active Test. NG --> See step 9 OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (RUNNING TEST) HINT: Using the Techstream to perform Active Test allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Test early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Test. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG) position. Turn the Techstream on. Select the item "Powertrain / ECT / Active Test". According to the display on tester, perform the "Active Test". HINT: While driving, the shift position can be forcibly changed with the Techstream. Comparing the shift position commanded by the Active Test with the actual shift position enables you to confirm the problem. Refer to «FAIL-SAFE CHART [08/2012 - ]»(ref-606494-S38462055682014032500000) . Item Test Details Diagnostic Note Control the Shift Position [Test Details] Operate the shift solenoid valve and set the each shift position by yourself. [Vehicle Condition] IDL: ON (4th, 5th and 6th) Less than 50 km/h (31 mph) [Others] Press "-->" button: Shift up Press "<--" button: Shift down Possible to check the operation of the shift solenoid valves. HINT: This test can be conducted when the vehicle speed is 50 km/h (31 mph) or less. The 4th to 5th and 5th to 6th up-shiftings must be performed with the accelerator pedal released. The 6th to 5th and 5th to 4th down-shiftings must be performed with the accelerator pedal released. Do not operate the accelerator pedal for at least 2 seconds after shifting and do not shift successively. The shift position commanded by the ECM is shown in the Data List (Shift Status) display on the Techstream. Gear positions in the event of a solenoid valve mechanical problem: ECM gear shift command 1st 2nd 3rd 4th 5th 6th Proceed to Actual gear position under malfunction Shift solenoid S1 Stuck ON*1 2nd 2nd 3rd 4th 5th 6th A Stuck OFF 1st 1st 3rd 4th 5th N*2 Shift solenoid S2 Stuck ON 1st 2nd 2nd 4th 6th 6th B Stuck OFF 3rd 3rd 3rd 4th 5th 5th Shift solenoid S3 Stuck ON 1st 2nd 3rd 3rd N*2 N*2 C Stuck OFF 3rd 4th 4th 4th 5th 6th Shift solenoid S4 Stuck ON*3 1st 2nd 3rd 4th 5th 6th D Stuck OFF 1st 2nd 3rd 4th 4th 4th HINT: *1: When shift solenoid S1 is stuck ON, the vehicle cannot drive in reverse. *2: Neutral *3: When shift solenoid S4 is stuck ON, gear shifting is normal. OK Gear position changes in accordance with the tester command. OK --> See step 9 B --> See step 5 C --> See step 6 D --> See step 7 A: Go to next step
4. INSPECT SHIFT SOLENOID VALVE S1 Remove the shift solenoid valve S1. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S1) - Solenoid Body (S1) 11 to 15 ohms Connect positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. OK --> See step 10 NG --> REPLACE SHIFT SOLENOID VALVE S1
5. INSPECT SHIFT SOLENOID VALVE S2 Remove the shift solenoid valve S2. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S2) - Solenoid Body (S2) 11 to 15 ohms Connect positive (+) lead to the terminal of solenoid connector, negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. OK --> See step 10 NG --> REPLACE SHIFT SOLENOID VALVE S2
6. INSPECT SHIFT SOLENOID VALVE S3 Remove the shift solenoid valve S3. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S3) - Solenoid Body (S3) 11 to 15 ohms Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. OK --> See step 10 NG --> REPLACE SHIFT SOLENOID VALVE S3
7. INSPECT SHIFT SOLENOID VALVE S4 Remove the shift solenoid valve S4. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S4) - Solenoid Body (S4) 11 to 15 ohms Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE S4 OK: Go to next step
8. INSPECT SHIFT SOLENOID VALVE SL2 Remove the shift solenoid valve SL2. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. OK --> See step 10 NG --> REPLACE SHIFT SOLENOID VALVE SL2
9. INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SLT OK: Go to next step
10. INSPECT TRANSMISSION VALVE BODY ASSEMBLY Check the transmission valve body assembly. OK There are no foreign objects on each valve. NG --> REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK: Go to next step
11. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION [08/2012 - ]»(ref-606455-S41660141522014032500000) . OK The torque converter clutch operates normally. NG --> REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY OK --> REPAIR OR REPLACE AUTOMATIC TRANSMISSION ASSEMBLY

Range check (Low resistance).

P0973

Range check (High resistance).

P0974

Range check (Low resistance)

P0973

Range check (High resistance)

P0974

Scheme 824

1. INSPECT TRANSMISSION WIRE (S1) Disconnect the transmission wire connector from the transmission. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 8 - Body ground 11 to 15 ohms NG --> See step 3 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transmission. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) E4-19 (S1) - Body ground 11 to 15 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM
3. INSPECT SHIFT SOLENOID VALVE S1 Remove the shift solenoid valve S1. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S1) - Solenoid Body (S1) 11 to 15 ohms Connect positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE S1 OK --> REPAIR OR REPLACE TRANSMISSION WIRE

Range check (Low resistance).

P0976

Range check (High resistance).

P0977

Range check (Low resistance)

P0976

Range check (High resistance)

P0977

Scheme 825

1. INSPECT TRANSMISSION WIRE (S2) Disconnect the transmission wire connector from the transmission. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 15 - Body ground 11 to 15 ohms NG --> See step 3 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transmission. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) E4-18 (S2) - Body ground 11 to 15 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM
3. INSPECT SHIFT SOLENOID VALVE S2 Remove the shift solenoid valve S2. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S2) - Solenoid Body (S2) 11 to 15 ohms Connect positive (+) lead to the terminal of solenoid connector, negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE S2 OK --> REPAIR OR REPLACE TRANSMISSION WIRE

Range check (Low resistance)

P0979

Range check (High resistance)

P0980

Range check (Low resistance)

P0979

Range check (High resistance)

P0980

Scheme 826

1. INSPECT TRANSMISSION WIRE (S3) Disconnect the transmission wire connector from the transmission. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 7 - Body ground 11 to 15 ohms NG --> See step 3 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transmission. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) E4-17 (S3) - Body ground 11 to 15 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM
3. INSPECT SHIFT SOLENOID VALVE S3 Remove the shift solenoid valve S3. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S3) - Solenoid Body (S3) 11 to 15 ohms Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE S3 OK --> REPAIR OR REPLACE TRANSMISSION WIRE

Range check (Low resistance).

P0982

Range check (High resistance).

P0983

Range check (Low resistance).

P0982

Range check (High resistance).

P0983

Scheme 827

1. INSPECT TRANSMISSION WIRE (S4) Disconnect the transmission wire connector from the transmission. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 14 - Body ground 11 to 15 ohms NG --> See step 3 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transmission. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) E4-16 (S4) - Body ground 11 to 15 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM
3. INSPECT SHIFT SOLENOID VALVE S4 Remove the shift solenoid valve S4. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (S4) - Solenoid Body (S4) 11 to 15 ohms Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE S4 OK --> REPAIR OR REPLACE TRANSMISSION WIRE

Range check (Low resistance)

P0985

Range check (High resistance)

P0986

Range check (Low resistance)

P0985

Range check (High resistance)

P0986

Scheme 828

1. INSPECT TRANSMISSION WIRE (SR) Disconnect the transmission wire connector from the transmission. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 6 - Body ground 11 to 15 ohms NG --> See step 3 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission connector to the transmission. Disconnect the connector from the ECM. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) E4-2 (SR) - Body ground 11 to 15 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM
3. INSPECT SHIFT SOLENOID VALVE SR Remove the shift solenoid valve SR. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) Solenoid Connector (SR) - Solenoid Body (SR) 11 to 15 ohms Connect the positive (+) lead to the terminal of the solenoid connector, and the negative (-) lead to the solenoid body. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SR OK --> REPAIR OR REPLACE TRANSMISSION WIRE

Scheme 829

1. INSPECT TRANSMISSION WIRE (SLT) Disconnect the transmission wire connector from the transmission. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 13 (SLT+) - 5 (SLT-) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) Tester Connection Specified Condition 13 (SLT+) - Body ground 10 kohms or higher 5 (SLT-) - Body ground ↑ NG --> See step 3 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transmission. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) E4-35 (SLT+) - E4-34 (SLT-) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) Tester Connection Specified Condition E4-35 (SLT+) - Body ground 10 kohms or higher E4-34 (SLT-) - Body ground ↑ NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM
3. INSPECT SHIFT SOLENOID VALVE SLT Remove the shift solenoid valve SLT. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SLT OK --> REPAIR OR REPLACE TRANSMISSION WIRE

THE FOLLOWING ITEMS ARE COMMON TO ALL CONDITIONS BELOW.

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

ON MALFUNCTION

Both of the following condition are met: OFF malfunction (A) and (B)

OFF MALFUNCTION (A)

OFF MALFUNCTION (B)

2 detections are necessary per driving cycle

1st detection; temporary flag ON

2nd detection; pending fault code ON

Vehicle speed must be under 6.2mph (10 km/h) once before 2nd detection.

ON MALFUNCTION

1. CHECK OTHER DTCS OUTPUT (IN ADDITION TO DTC P2757) Connect the Techstream to the DLC3. Turn the engine switch on (IG) position and push the Techstream main switch ON. When you use Techstream: Select the item "Powertrain / ECT / Trouble Codes". Read the DTCs using the Techstream. Result Display (DTC output) Proceed to Only "P2757" is output A "P2757" and other DTCs B HINT: If any other codes besides "P2757" are output, perform troubleshooting for those DTCs first. B --> GO TO DTC CHART A: Go to next step
2. INSPECT SHIFT SOLENOID VALVE SLU Remove the shift solenoid valve SLU. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SLU OK: Go to next step
3. INSPECT TRANSMISSION VALVE BODY ASSEMBLY OK There are no foreign objects on each valve. NG --> REPLACE TRANSMISSION VALVE BODY ASSEMBLY OK: Go to next step
4. INSPECT TORQUE CONVERTER CLUTCH ASSEMBLY Check the torque converter clutch assembly. Refer to «INSPECTION [08/2012 - ]»(ref-606455-S41660141522014032500000) . OK The torque converter clutch operates normally. NG --> REPLACE TORQUE CONVERTER CLUTCH ASSEMBLY OK --> REPAIR OR REPLACE AUTOMATIC TRANSMISSION ASSEMBLY

Scheme 830

1. INSPECT TRANSMISSION WIRE (SLU) Disconnect the transmission wire connector from the transmission. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 12 (SLU+) - 4 (SLU-) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) Tester Connection Specified Condition 12 (SLU+) - Body ground 10 kohms or higher 4 (SLU-) - Body ground ↑ NG --> See step 3 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TRANSMISSION WIRE - ECM) Connect the transmission wire connector to the transmission. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) E4-13 (SLU+) - E4-12 (SLU-) 5.0 to 5.6 ohms Measure the resistance according to the value(s) in the table below. Standard resistance (Check for short) Tester Connection Specified Condition E4-13 (SLU+) - Body ground 10 kohms or higher E4-12 (SLU-) - Body ground ↑ NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> REPLACE ECM
3. INSPECT SHIFT SOLENOID VALVE SLU Remove the shift solenoid valve SLU. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 20°C (68°F) 1 - 2 5.0 to 5.6 ohms Connect the positive (+) lead with a 21 W bulb to terminal 2 and the negative (-) lead to terminal 1 of the solenoid valve connector, then check the movement of the valve. OK The solenoid makes an operating sound. NG --> REPLACE SHIFT SOLENOID VALVE SLU OK --> REPAIR OR REPLACE TRANSMISSION WIRE

1. CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC U0100) Connect the Techstream to the DLC3. Turn the engine switch on (IG) position and push the Techstream main switch ON. When you use Techstream: Select the item "Powertrain / ECT / Trouble Codes". Read the DTCs using the Techstream. Result Display (DTC output) Proceed to U0100 A U0100 and other DTCs B B --> GO TO DTC CHART A --> REPLACE ECM

1. CHECK HARNESS AND CONNECTOR (BATTERY - TRANSMISSION CONTROL SWITCH) Disconnect the transmission control switch connector of shift lock control unit assembly. Measure the voltage according to the value(s) in the table below. Standard voltage Switch Condition Tester Connection Specified Condition Engine switch on (IG) 3 - Body ground 10 to 14 V Engine switch off ↑ Below 1 V NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (TRANSMISSION CONTROL SWITCH - BODY GROUND) Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 5 - Body ground Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. INSPECT TRANSMISSION CONTROL SWITCH Measure resistance between each terminal of shift lock control unit assembly when the shift lever is moved to each position. Standard resistance Shift Position Tester Connection Specified Condition S, "+" and "-" 3 - 7 Below 1 ohms Except S, "+" and "-" ↑ 10 kohms or higher Press continuously "+" (Up shift) 2 - 5 Below 1 ohms S ↑ 10 kohms or higher Press continuously "-" (Down shift) 1 - 5 Below 1 ohms S ↑ 10 kohms or higher NG --> REPLACE TRANSMISSION CONTROL SWITCH OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (TRANSMISSION CONTROL SWITCH - ECM) Connect the transmission control switch connector of shift lock control unit assembly. Disconnect the ECM connector. Turn the engine switch on (IG) position, and measure the voltage according to the value(s) in the table below when the shift lever is moved to each position. Standard voltage Shift Position Tester Connection Specified Condition S, "+" and "-" A6-9 (S) - Body ground 10 to 14 V Except S, "+" and "-" ↑ Below 1 V Turn the engine switch off position. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below when the shift lever is moved to each position. Standard resistance Shift Position Tester Connection Specified Condition Press continuously "+" (Up shift) A6-30 (SFTU) - Body ground Below 1 ohms S ↑ 10 kohms or higher Press continuously "-" (Down shift) A6-19 (SFTD) - Body ground Below 1 ohms S ↑ 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

1. CHECK HARNESS AND CONNECTOR (SPIRAL CABLE - BODY GROUND) Disconnect the steering pad switch connector and spiral cable connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 2 - Body ground Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. INSPECT SPIRAL CABLE SUB-ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition J24-2 - k1-6 Always Below 1 ohms J24-9 - k1-2 Always Below 1 ohms J24-10 - k1-3 Always Below 1 ohms NG --> REPLACE SPIRAL CABLE SUB-ASSEMBLY OK: Go to next step
3. INSPECT TRANSMISSION SHIFT SWITCH ASSEMBLY Disconnect the switch wire connector from the transmission shift switch. Measure the resistance between each terminal when the paddle shift is moved to each position. Standard resistance Paddle Shift Position Tester Connection Specified Condition Pull continuously "+" (Up shift) SUP - ECC Below 1 ohms Release "+" (Up shift) ↑ 10 kohms or higher Pull continuously "-" (Down shift) SDN - ECC Below 1 ohms Release "-" (Down shift) ↑ 10 kohms or higher NG --> REPLACE TRANSMISSION SHIFT SWITCH ASSEMBLY OK: Go to next step
4. INSPECT SWITCH NO. 1 WIRE Connect the switch wire connector to the transmission shift switch. Measure the resistance between each terminal when the paddle shift is moved to each position. Standard resistance Paddle Shift Position Tester Connection Specified Condition Pull continuously "+" (Up shift) 2 - 6 Below 1 ohms Release "+" (Up shift) ↑ 10 kohms or higher Pull continuously "-" (Down shift) 3 - 6 Below 1 ohms Release "-" (Down shift) ↑ 10 kohms or higher NG --> REPLACE SWITCH NO. 1 WIRE OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (SPIRAL CABLE - ECM) Connect the spiral cable connector and steering pad switch connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below when the paddle shift is moved to each position. Standard resistance Paddle Shift Position Tester Connection Specified Condition Pull continuously "+" (Up shift) A6-30 (SFTU) - Body ground Below 1 ohms Release "+" (Up shift) ↑ 10 kohms or higher Pull continuously "-" (Down shift) A6-19 (SFTD) - Body ground Below 1 ohms Release "-" (Down shift) ↑ 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE

1. DRIVING TEST Start the engine. Turn the ECT SNOW switch "OFF" (Normal drive mode). Confirm vehicle response by driving from a parked position to fully depressing the accelerator pedal. Turn the ECT SNOW switch "ON" and perform the same check as above. Confirm that there is a difference between ECT SNOW switch "ON" and "OFF". HINT: Driving test should be done on a paved road (a nonskid road). Make sure not to use the TRAC system when testing a vehicle equipped with one. OK There is a difference in acceleration between "ON" and "OFF". NG --> See step 2 OK --> PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOM TABLE
2. CHECK HARNESS AND CONNECTOR (PATTERN SELECT SWITCH ASSEMBLY - BODY GROUND) Disconnect the connector of pattern select switch. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 3 - Body ground Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. INSPECT PATTERN SELECT SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance Switch Condition Tester Connection Specified Condition Press continuously Pattern select switch (SNOW) 1 - 3 Below 1 ohms Release Pattern select switch (SNOW) ↑ 10 kohms or higher NG --> REPLACE PATTERN SELECT SWITCH ASSEMBLY OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (PATTERN SELECT SWITCH ASSEMBLY - MAIN BODY ECU) Connect the connector of pattern select switch. Disconnect the cowl side junction block (main body ECU RH) connector. Measure the resistance between terminal SNOW of the cowl side junction block (main body ECU RH) and body ground. Standard resistance Switch Condition Tester Connection Specified Condition Press continuously Pattern select switch (SNOW) J75-17 (SNOW) - Body ground Below 1 ohms Release Pattern select switch (SNOW) ↑ 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOM TABLE

1. CHECK HARNESS AND CONNECTOR (PATTERN SELECT SWITCH ASSEMBLY - BODY GROUND) Disconnect the connector of pattern select switch. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition 3 - Body ground Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. INSPECT PATTERN SELECT SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance Switch Condition Tester Connection Specified Condition Pattern select switch (PWR) 3 - 7 Below 1 ohms Pattern select switch (NORM) ↑ 10 kohms or higher NG --> REPLACE PATTERN SELECT SWITCH ASSEMBLY OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (PATTERN SELECT SWITCH ASSEMBLY - MAIN BODY ECU) Connect the connector of pattern select switch. Disconnect the cowl side junction block (main body ECU RH) connector. Measure the resistance between terminal PWR of the cowl side junction block (main body ECU RH) and body ground. Standard resistance Switch Condition Tester Connection Specified Condition Pattern select switch (PWR) J75-18 (PWR) - Body ground Below 1 ohms Pattern select switch (NORM) ↑ 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE
