# High/low bus circuit

# High/low bus circuit (1 of 3)

Computer data lines — High/low bus circuit — High/low bus circuit (1 of 3). Lexus IS II (2005-2008)
Components on the diagram

    # High/low bus circuit (2 of 3)

    Computer data lines — High/low bus circuit — High/low bus circuit (2 of 3). Lexus IS II (2005-2008)
    Components on the diagram

      # High/low bus circuit (3 of 3)

      Computer data lines — High/low bus circuit — High/low bus circuit (3 of 3). Lexus IS II (2005-2008)
      Components on the diagram
