Mirror: Diagnosis Lexus IS II

HOW TO PROCEED WITH TROUBLESHOOTING

HINT

1. Use this procedure to troubleshoot the power mirror control system.
2. The intelligent tester should be used in steps 3 and 5 .

1. VEHICLE BROUGHT TO WORKSHOP
2. CUSTOMER PROBLEM ANALYSIS CHECK AND SYMPTOM CHECK
3. CHECK COMMUNICATION FUNCTION OF BODY MULTIPLEX COMMUNICATION SYSTEM (BEAN) HINT: See «DIAGNOSIS SYSTEM»(ref-235597-S04957123052006062400000) Use the intelligent tester to check for normal function of the multiplex communication system. (ECU unconnected, communication line malfunctioning) If no codes are output, proceed to A. (ECU unconnected, communication line malfunctioning) If any codes are output, proceed to B. B: GO TO «MULTIPLEX COMMUNICATION SYSTEM»(ref-235578-S20958542052006062400000) A: Go to next step.
4. PROBLEM SYMPTOMS TABLE HINT: See «PROBLEM SYMPTOMS TABLE»(ref-235597-S30875364862006062400000)
5. OVERALL ANALYSIS AND TROUBLESHOOTING Data list/Active test HINT: See «DATA LIST/ACTIVE TEST»(ref-235597-S03429999672006062400000) Circuit inspection Terminals of ECU HINT: See «TERMINALS OF ECU»(ref-235597-S40183723182006062400000)
6. ADJUST, REPAIR OR REPLACE END

PROBLEM SYMPTOMS TABLE

Power Mirror Control System

PROBLEM SYMPTOMS TABLE

Scheme 30

Scheme 31

1. CHECK OUTER MIRROR CONTROL ECU LH Disconnect the M10 connector. Measure the voltage and resistance according to the value(s) in «TERMINALS VOLTAGE TABLE»(ref-235597-S28076213042006062400000) . Voltage TERMINALS VOLTAGE TABLE Symbols (Terminal No. Wiring Color Terminal Description Condition Specified Condition SIG (M10-3) - Body ground B - Body ground Ignition power supply Engine switch OFF --> ON (IG) 0 V --> 10 to 14 V CPUB (M10-4) - Body ground G - Body ground +B power supply Always 10 to 14 V BDR (M10-6) - Body ground L - Body ground +B power supply Always 10 to 14 V Resistance TERMINALS RESISTANCE TABLE Symbols (Terminal No. Wiring Color Terminal Description Condition Specified Condition GND (M10-1) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the M10 connector. Measure the voltage according to the value(s) in «TERMINALS VOLTAGE TABLE»(ref-235597-S27996173102006062400000) . Voltage TERMINALS VOLTAGE TABLE Symbols (Terminal No. Wiring Color Terminal Description Condition Specified Condition MV (h1-1) - Body ground W - Body ground Outer mirror switch signal (Up or Right) Engine switch on (IG), Left/Right adjustment switch L side, Mirror switch OFF --> UP or Right 0 V --> 10 to 14 V VC (h1-5) - Body ground R-W - Body ground Power source for mirror position sensor Engine switch OFF --> ON (IG) 0 V --> 0 to 5 V VSSR (h-6) - Body ground V - Body ground Vertical direction position signal Engine switch on (IG), Left/Right adjustment switch L side, Mirror switch uppermost position --> lowermost position 0 V --> 1 to 3 V MH (h1-9) - Body ground R - Body ground Outer mirror switch signal (Left or Down) Engine switch on (IG), Left/Right adjustment switch L side, Mirror switch OFF --> LEFT or DOWN 0 V --> 10 to 14 V M+ (h1-10) - Body ground B - Body ground Outer mirror switch signal (Right or Down) Engine switch on (IG), Left/Right adjustment switch L side, Mirror switch OFF --> RIGHT or DOWN 0 V --> 10 to 14 V HSSR (h1-13) - Body ground LG - Body ground Horizontal direction position signal Engine switch on (IG), Left/Right adjustment switch L side, Mirror switch innermost position --> outermost position 0 V --> 1 to 3 V
2. CHECK OUTER MIRROR CONTROL ECU RH Disconnect the L10 connector. Measure the voltage and resistance according to the value(s) in «TERMINALS VOLTAGE TABLE»(ref-235597-S00798002262006062400000) . Voltage TERMINALS VOLTAGE TABLE Symbols (Terminal No. Wiring Color Terminal Description Condition Specified Condition SIG (L10-3) - Body ground B - Body ground Ignition power supply Engine switch OFF --> ON (IG) 0 V --> 10 to 14 V CPUB (L10-4) - Body ground G - Body ground +B power supply Always 10 to 14 V BDR (L10-6) - Body ground L - Body ground +B power supply Always 10 to 14 V Resistance TERMINALS RESISTANCE TABLE Symbols (Terminal No. Wiring Color Terminal Description Condition Specified Condition GND (L10-1) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the L10 connector. Measure the voltage according to the value(s) in «TERMINALS VOLTAGE TABLE»(ref-235597-S20388535392006062400000) . Voltage TERMINALS VOLTAGE TABLE Symbols (Terminal No. Wiring Color Terminal Description Condition Specified Condition MV (g1-1) - Body ground W - Body ground Outer mirror switch signal (Up or Right) Engine switch on (IG), Left/Right adjustment switch R side, Mirror switch OFF --> UP or Right 0 V --> 10 to 14 V VC (g1-5) - Body ground R-W - Body ground Power source for mirror position sensor Engine switch OFF --> ON (IG) 0 V --> 0 to 5 V VSSR (g-6) - Body ground V - Body ground Vertical direction position signal Engine switch on (IG), Left/Right adjustment switch R side, Mirror switch uppermost position --> lowermost position 0 V --> 1 to 3 V MH (g1-9) - Body ground R - Body ground Outer mirror switch signal (Left or Down) Engine switch on (IG), Left/Right adjustment switch R side, Mirror switch OFF --> LEFT or DOWN 0 V --> 10 to 14 V M+ (g1-10) - Body ground B - Body ground Outer mirror switch signal (Right or Down) Engine switch on (IG), Left/Right adjustment switch R side, Mirror switch OFF --> RIGHT or DOWN 0 V --> 10 to 14 V HSSR (g1-13) - Body ground LG - Body ground Horizontal direction position signal Engine switch on (IG), Left/Right adjustment switch R side, Mirror switch innermost position --> outermost position 0 V --> 1 to 3 V

Scheme 32

1. DESCRIPTION Data of the system can be read from the Data Link Connector 3 (DLC3) of the vehicle. Therefore, when the system seems to be malfunctioning, use the intelligent tester to check for a malfunction and repair it.
2. CHECK DLC3 The vehicle's ECM uses ISO 9141-2 communication protocol. The terminal arrangement of the DLC3 complies with SAE J1962 and matches the ISO 9141-2 format. Standard TESTER CONDITION SPECIFIED CONDITION TABLE Tester Connection Condition Specified Condition 7 (Bus + line) - 5 (Signal ground) During communication Pulse generation 4 (Chassis ground) - Body ground Constant Below 1 ohms 5 (Signal ground) - Body ground Constant Below 1 ohms 16 (B+) - Body ground Constant 9 to 14 V HINT: If the screen displays a communication error message after you have connected the cable of the intelligent tester to the DLC3, turned the engine switch on (IG) and used the intelligent tester, the problem may be on the vehicle side or tester side. If communication is normal when the tester is connected to another vehicle, inspect the DLC3 of the original vehicle. If communication is still impossible when the tester is connected to another vehicle, the problem is probably in the tester itself, so consult the Service Department listed in the tester's instruction manual.

DATA LIST / ACTIVE TEST

1. USING INTELLIGENT TESTER Connect the intelligent tester to the DLC3. Monitor the ECU data by following the prompts on the tester screen. HINT: The intelligent tester has a "Snapshot" function which records the monitored data. Refer to the intelligent tester operator's manual for further details.
2. DATA LIST HINT: Using the DATA LIST displayed on the intelligent tester, the value of the switch, sensor, actuator, etc. can be read without part removal. Reading the DATA LIST as the first step of troubleshooting is one way to shorten labor time. Connect the intelligent tester to the DLC3. Turn the engine switch on (IG). Read the DATA LIST according to the display on the tester. MIRROR-L/MIRROR-R DATA LIST DISPLAY TABLE Item Test Details Diagnostic Note MIRR POS SEN V Vertical mirror position/MIN: 0, MAX 5 V Within range from 0 to 5 V MIRR POS SEN H Horizontal mirror position/MIN: 0, MAX 5 V Within range from 0 to 5 V MIRR MEM 1 Mirror position memorized in memory switch M1/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized MIRR MEM 2 Mirror position memorized in memory switch M2/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized MIRR MEM 3 Mirror position memorized in memory switch M3/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized D-SEAT DATA LIST DISPLAY TABLE Item Test Details Diagnostic Note POWER VOLTAGE Power supply for position control ECU & switch/MIN: 0 V, MAX: 19.89 V Within range from 11 to 14 V IG SW Ignition switch status/ON or OFF ON: Engine switch is on (IG) OFF: Engine switch is OFF KEY UNLOCK SW Key unlock warning switch signal/ON or OFF ON: Key is in door key cylinder OFF: Key is not in door key cylinder PNP SW Park/Neutral position switch signal/ON or OFF ON: Shift in P position OFF: Shift in any position except neutral M1 SW Seat memory switch M1 signal/ON or OFF ON: Seat memory switch M1 is ON OFF: Seat memory switch M1 is OFF M2 SW Seat memory switch M2 signal/ON or OFF ON: Seat memory switch M2 is ON OFF: Seat memory switch M2 is OFF M3 SW Seat memory switch M3 signal/ON or OFF ON: Seat memory switch M3 is ON OFF: Seat memory switch M3 is OFF SET SW Seat memory set switch signal/ON or OFF ON: Memory set switch is ON OFF: Memory set switch is OFF MEM M1 SW Driving position memorized in seat memory switch M1/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized MEM M2 SW Driving position memorized in seat memory switch M2/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized MEM M3 SW Driving position memorized in seat memory switch M3/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized SEAT MEM M1 Driver side mirror position memorized in seat memory switch M1/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized SEAT MEM M2 Driver side mirror position memorized in seat memory switch M2/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized SEAT MEM M3 Driver side mirror position memorized in seat memory switch M3/NOT MEM or MEM MEM: Memorized NOT MEM: Not memorized BODY DATA LIST DISPLAY TABLE Item Test Details Diagnostic Note MIRR SEL SW R Mirror selection switch signal for RH mirror/ON or OFF ON: Switch is in Right position OFF: Switch is in neutral or Left position MIRR SEL SW L Mirror selection switch signal for LH mirror/ON or OFF ON: Switch is in Left position OFF: Switch is in neutral or Right position MIRR POS SW R Mirror position switch signal (Right)/ON or OFF ON: Switch R is ON OFF: Any switch except R is ON or all switches are OFF MIRR POS SW L Mirror position switch signal (Left)/ON or OFF ON: Switch L is ON OFF: Any switch except L is ON or all switches are OFF MIRR POS SW UP Mirror position switch signal (Up)/ON or OFF ON: Switch UP is ON OFF: Any switch except UP is ON or all switches are OFF MIRR POS SW DWN Mirror position switch signal (Down)/ON or OFF ON: Switch DOWN is ON OFF: Any switch except DOWN is ON or all switches are OFF
3. ACTIVE TEST HINT: Performing the ACTIVE TEST using the intelligent tester allows the relay, VSV, actuator, etc. to be operated without part removal. Performing the ACTIVE TEST as the first step of troubleshooting is one way to shorten labor time. It is possible to display the DATA LIST during the ACTIVE TEST. Connect the intelligent tester to the DLC3. Turn the engine switch on (IG). Perform the ACTIVE TEST according to the display on the tester. MIRROR-L/MIRROR-R ACTIVE TEST DISPLAY TABLE Item Test Details MIRR UP/DOWN Mirror vertical operation: UP/DOWN MIRR RIGHT/LEFT Mirror horizontal operation: RIGHT/LEFT AIR CONDITIONER ACTIVE TEST DISPLAY TABLE Item Test Details MIRR HEATER Mirror heater operation: OFF/ON

ON-VEHICLE INSPECTION

1. CHECK POWER MIRROR SWITCH OPERATION Remote control The mirror adjust switch can control the adjustment axis of the mirror surface. Reverse-linked This function tilts the mirror surface downward to improve the visibility when driving in reverse, provided that all the conditions given below have been met. Engine switch is on (IG). Shift lever is moved to "R".
2. CHECK MEMORY SWITCH OPERATION Memory Memorizes the positions when all conditions below have been met and the 1, 2 or 3 button is pushed while the "SET" button is pushed. Engine switch is on (IG). Shift position is "P" (A/T models). Vehicle speed is 3 km (1.9 mph) or less (M/T models). Parking brake lever is pulled (M/T models). When the memory setting is completed, the buzzer will sound for 0.5 seconds. Recall If the button 1, 2 or 3 is pressed when all conditions below have been met, it recalls the positions. Engine switch is on (IG). Shift position is "P" (A/T models). Vehicle speed is 3 km (1.9 mph) or less (M/T models). Parking brake lever is pulled (M/T models). If the button 1, 2 or 3 is pressed when all conditions have been met and within 30 seconds, it recalls the positions. Engine switch on (IG). Driver door is opened.

Power Mirror Control System

PROBLEM SYMPTOMS TABLE

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

1. SELECT COMPASS DISPLAY MODE The COMP switch allows you to select the Display or Non-display mode of the compass.
2. SET ZONE Deviation between the "magnetic north" and "actual north" differs depending on the location. Therefore, adjustment of the magnetism is required. Since the magnetic condition differs depending on the area where the vehicle is used, it is necessary for each user to set the zone (Scheme 37) The zone setting can be changed using the COMP switch of the inner mirror.
3. PERFORM CALIBRATION Because each vehicle has its own magnetic field, calibration should be performed for each vehicle. This compass function is used when storing the record of the vehicle's magnetic field.
4. WHEN COMPASS IS MAGNETIZED A compass could be magnetized during shipping by vessels or freight cars. Therefore, make sure to perform calibration and ensure that calibration is performed properly before delivery. If it cannot be done (cannot be completed in spite of driving around several times), it may be caused by magnetization. Demagnetize the vehicle using a demagnetizer and perform calibration again.
5. SET COMPASS
6. ZONE SETTING MODE Pressing the COMP switch for 3 seconds in the normal mode will activate the zone setting mode. A number (1 to 15) is displayed on the compass display. NOTE: In the initial state, "8" is displayed. The displayed number increases by 1 every time the COMP switch is pressed. Referring to the map, check the number for the area where the vehicle will be used and set the zone number. Leave it untouched for several seconds after setting and check that the compass display shows an azimuthal direction (N, NE, E, SE, S, SW, W or NW) or "C".
7. CALIBRATION SETTING MODE Pressing the COMP switch for 6 seconds in the normal mode will activate the calibration setting mode. Drive the vehicle at a slow speed of 8 km/h (5 mph) or less in the circular direction. Driving around the circle 1 to 3 times will display the azimuthal direction on the display, completing the calibration. NOTE: After the calibration is completed, it is not necessary to perform the above procedures unless the magnetic field strength is drastically changed. If this happens, the azimuthal display will be changed to "C".

AUTOMATIC GLARE-RESISTANT EC MIRROR

PROBLEM SYMPTOMS TABLE

Scheme 38

Scheme 39

1. REMOVE INNER REAR VIEW MIRROR STAY HOLDER COVER Disengage the 2 claws and remove the inner rear view mirror stay holder cover.
2. REMOVE INNER REAR VIEW MIRROR ASSEMBLY Disconnect the connector. Using a "torx" socket wrench (T20), remove the screw and the inner rear view mirror.

Scheme 40

1. INSPECT INNER REAR VIEW MIRROR ASSEMBLY Inspect operation of the electrochromatic inner mirror. Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2. Attach black colored tape to the forward sensor to prevent it from sensing. Light up the mirror with an electric light, and check that the mirror surface changes from bright to dark. Standard: Mirror surface changes from bright to dark If the result is not as specified, replace the mirror assembly.

Scheme 41

Scheme 42

1. INSTALL INNER REAR VIEW MIRROR ASSEMBLY Using a "torx" socket wrench (T20), install the inner rear view mirror with the screw. Torque: 1.8 N*m (18 kgf*cm, 16 in.*lbf) Connect the connector.
2. INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER Engage the 2 claws and install the inner rear view mirror stay holder cover.

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

1. REMOVE FRONT DOOR INSIDE HANDLE BEZEL PLUG (See «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
2. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See Step 2 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
3. REMOVE COURTESY LIGHT ASSEMBLY (See Step 3 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
4. REMOVE FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See Step 4 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
5. REMOVE FRONT DOOR INNER GLASS WEATHERSTRIP (See Step 8 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
6. REMOVE FRONT DOOR TRIM COVER (See Step 9 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
7. REMOVE DOOR FRAME GARNISH (See Step 10 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
8. REMOVE OUTER MIRROR CONTROL ECU (w/Memory) (See Step 13 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
9. REMOVE OUTER MIRROR PROTECTOR Disengage the clamp and disconnect the connector. Remove the outer mirror protector. HINT: Remove the remaining tape on the door.
10. REMOVE OUTER REAR VIEW MIRROR ASSEMBLY Remove the 3 nuts. Disengage the clamp and remove the outer rear view mirror assembly.

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

1. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY RH (w/Memory) Inspect outer mirror motor operation. Apply battery voltage and check operation of the mirror face, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S31258113172006062400000) and (Scheme 48). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (MV) Battery negative (-) --> Terminal 10 (M+) Turns upward (A) Battery positive (+) --> Terminal 10 (M+) Battery negative (-) --> Terminal 1 (MV) Turns downward (B) Battery positive (+) --> Terminal 9 (MH) Battery negative (-) --> Terminal 10 (M+) Turns left (C) Battery positive (+) --> Terminal 10 (M+) Battery negative (-) --> Terminal 9 (MH) Turns right (D) Inspect the retract mirror operation. Apply battery voltage and check operation of the mirror, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S01678539822006062400000). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 7 (MF) Battery negative (-) --> Terminal 1 (MV) Returns (Driving position) Battery positive (+) --> Terminal 1 (MV) Battery negative (-) --> Terminal 7 (MF) Retracts Inspect outer mirror heater operation. Apply battery voltage and check operation of the mirror face, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S40379248432006062400000). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 3 (HTR+) Battery negative (-) --> Terminal 9 (HTR-) Mirror surface temperature becomes higher Inspect electrochromatic outer mirror operation. Apply battery voltage and check operation of the mirror face, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S10598660502006062400000) and (Scheme 49). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 7 (EC+) Battery negative (-) --> Terminal 15 (EC-) Mirror surface changes to dark
2. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY RH (w/o Memory) Inspect outer mirror motor operation. Apply battery voltage and check operation of the mirror face, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S16802702602006062400000) and (Scheme 50). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 5 (MV) Battery negative (-) --> Terminal 6 (M+) Turns upward (A) Battery positive (+) --> Terminal 6 (M+) Battery negative (-) --> Terminal 5 (MV) Turns downward (B) Battery positive (+) --> Terminal 11 (MH) Battery negative (-) --> Terminal 6 (M+) Turns left (C) Battery positive (+) --> Terminal 6 (M+) Battery negative (-) --> Terminal 11 (MH) Turns right (D) Inspect the retract mirror operation. Apply battery voltage and check operation of the mirror, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S40518861972006062400000). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 7 (MF) Battery negative (-) --> Terminal 1 (MV) Returns (Driving position) Battery positive (+) --> Terminal 1 (MV) Battery negative (-) --> Terminal 7 (MF) Retracts Inspect outer mirror heater operation. Apply battery voltage and check operation of the mirror face, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S36210343162006062400000). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 3 (HTR+) Battery negative (-) --> Terminal 9 (HTR-) Mirror surface temperature becomes higher Inspect electrochromatic outer mirror operation. Apply battery voltage and check operation of the mirror face, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S00855214042006062400000) or (Scheme 51). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 4 (EC+) Battery negative (-) --> Terminal 10 (EC-) Mirror surface changes to dark
3. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY LH (w/Memory) Inspect outer mirror motor operation. Remove the outer rear view mirror assembly. Apply battery voltage and check operation of the mirror face, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S08346104582006062400000) and (Scheme 52). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (MV) Battery negative (-) --> Terminal 10 (M+) Turns upward (A) Battery positive (+) --> Terminal 10 (M+) Battery negative (-) --> Terminal 1 (MV) Turns downward (B) Battery positive (+) --> Terminal 9 (LMHR) Battery negative (-) --> Terminal 10 (LM+R) Turns left (C) Battery positive (+) --> Terminal 10 (M+) Battery negative (-) --> Terminal 9 (MH) Turns right (D) Inspect the retract mirror operation. Apply battery voltage and check operation of the mirror, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S18273270252006062400000). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 7 (MF) Battery negative (-) --> Terminal 1 (MV) Returns (Driving position) Battery positive (+) --> Terminal 1 (MV) Battery negative (-) --> Terminal 7 (MF) Retracts Inspect outer mirror heater operation. Apply battery voltage and check operation of the mirror face, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S33729721082006062400000). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 3 (HTR+) Battery negative (-) --> Terminal 9 (HTR-) Mirror surface temperature becomes higher Inspect electrochromatic outer mirror operation. Apply battery voltage and check operation of the mirror face, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S09802656402006062400000) and (Scheme 53). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 7 (EC+) Battery negative (-) --> Terminal 15 (EC-) Mirror surface changes to dark
4. INSPECT OUTER REAR VIEW MIRROR ASSEMBLY LH (w/o Memory) Inspect outer mirror motor operation. Apply battery voltage and check operation of the mirror face, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S26743277942006062400000) and (Scheme 54). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 5 (MV) Battery negative (-) --> Terminal 6 (M+) Turns upward (A) Battery positive (+) --> Terminal 6 (M+) Battery negative (-) --> Terminal 5 (MV) Turns downward (B) Battery positive (+) --> Terminal 11 (MH) Battery negative (-) --> Terminal 6 (M+) Turns left (C) Battery positive (+) --> Terminal 6 (M+) Battery negative (-) --> Terminal 11 (MH) Turns right (D) Inspect the retract mirror operation. Apply battery voltage and check operation of the mirror, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S23961125542006062400000). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 7 (MF) Battery negative (-) --> Terminal 1 (MV) Returns (Driving position) Battery positive (+) --> Terminal 1 (MV) Battery negative (-) --> Terminal 7 (MF) Retracts Inspect outer mirror heater operation. Apply battery voltage and check operation of the mirror face, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S12735040032006062400000). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 3 (HTR+) Battery negative (-) --> Terminal 9 (HTR-) Mirror surface temperature becomes higher Inspect electrochromatic outer mirror operation. Apply battery voltage and check operation of the mirror face, as shown in «MEASUREMENT CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S05909048382006062400000) and (Scheme 55). Standard MEASUREMENT CONDITION SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery positive (+) --> Terminal 4 (EC+) Battery negative (-) --> Terminal 10 (EC-) Mirror surface changes to dark

Scheme 56

Scheme 57

Scheme 58

Scheme 59

1. INSTALL OUTER REAR VIEW MIRROR ASSEMBLY Engage the clamp to install the outer rear view mirror assembly. Install the outer rear view mirror assembly with the 3 nuts. Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf)
2. INSTALL OUTER MIRROR PROTECTOR Apply butyl tape. Install a new outer mirror protector. Connect the connector and engage the clamp.
3. INSTALL OUTER MIRROR CONTROL ECU (w/Memory) (See Step 27 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
4. INSTALL DOOR FRAME GARNISH (See Step 30 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
5. INSTALL FRONT DOOR TRIM COVER (See Step 31 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
6. INSTALL FRONT DOOR INNER GLASS WEATHERSTRIP (See Step 32 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
7. INSTALL FRONT DOOR TRIM BOARD SUB-ASSEMBLY (See Step 36 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
8. INSTALL COURTESY LIGHT ASSEMBLY (See Step 37 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
9. INSTALL POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See Step 38 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
10. INSTALL FRONT DOOR INSIDE HANDLE BEZEL PLUG (See Step 39 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
11. INITIALIZE POWER WINDOW CONTROL SYSTEM (See Step 40 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

1. REMOVE OUTER REAR VIEW MIRROR GLASS Push the upper part of the mirror surface and tilt it. Using a molding remover, disengage the 2 claws at the lower part of the outer rear view mirror, and separate the outer rear view mirror glass. Disconnect the connector and remove the outer rear view mirror glass.
2. INSTALL OUTER REAR VIEW MIRROR GLASS Connect the connector. Engage the 2 claws on the upper part of the outer rear view mirror glass to the outer rear view mirror. Engage the 2 claws on the lower part of the outer rear view mirror glass to the outer rear view mirror.

Scheme 65

Scheme 66

Scheme 67

Scheme 68

1. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See Step 2 in «DISASSEMBLY»(ref-235587-S17204566112006062400000) )
2. REMOVE OUTER MIRROR SWITCH ASSEMBLY (for Standard) Disengage the 4 claws and remove the outer mirror switch assembly.
3. REMOVE OUTER MIRROR SWITCH ASSEMBLY (for Wood Panel) Remove the 2 screws and the outer mirror switch assembly with the front door armrest base cover lower LH. Disengage the 4 claws to remove the outer mirror switch assembly.

Scheme 69

Scheme 70

1. INSPECT OUTER MIRROR SWITCH (w/o Seat Position Memory System) Inspect the outer mirror switch. Measure the resistance according to the value(s) in «TESTER CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S42797089072006062400000) when the switch is operated. Resistance: Select "L" on the left/right adjustment switch TESTER CONDITION SPECIFIED CONDITION TABLE Tester Connection Switch Position Specified Condition 4 - 8 UP Below 1 ohms 6 - 7 4 - 7 DOWN 6 - 8 5 - 8 LEFT 6 - 7 5 - 7 RIGHT 6 - 8 Select "R" on the left/right adjustment switch TESTER CONDITION SPECIFIED CONDITION TABLE Tester Connection Switch Position Specified Condition 3 - 8 UP Below 1 ohms 6 - 7 3 - 7 DOWN 6 - 8 2 - 8 LEFT 6 - 7 2 - 7 RIGHT 6 - 8
2. INSPECT OUTER MIRROR SWITCH (w/Seat Position Memory System) Inspect the outer mirror switch. Measure the resistance according to the value(s) in «TESTER CONDITION SPECIFIED CONDITION TABLE»(ref-235597-S23903041342006062400000) when the switch is operated. Resistance TESTER CONDITION SPECIFIED CONDITION TABLE Tester Connection Switch Position Specified Condition 2 - 3 OFF 10 k ohms or higher UP 225 to 275 ohms DOWN 437 to 503 ohms LEFT 744 to 856 ohms RIGHT 437 to 503 ohms 1 - 2 L 90 to 110 ohms R 10 ohms or less 4 - 7 6 - 8 Retracts Below 1 ohms 4 - 8 6 - 7 Returns (Driving position) Below 1 ohms

Scheme 71

Scheme 72

Scheme 73

1. INSTALL OUTER MIRROR SWITCH ASSEMBLY (for Standard) Engage the 4 claws to install the outer mirror switch assembly.
2. INSTALL OUTER MIRROR SWITCH ASSEMBLY (for Wood Panel) Engage the 4 claws to install the outer mirror switch assembly. Install the outer mirror switch assembly with the front door armrest base cover lower LH with the 2 screws.
3. INSTALL POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY (See Step 38 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )
4. INITIALIZE POWER WINDOW CONTROL SYSTEM (See Step 40 in «REASSEMBLY»(ref-235587-S42708921892006062400000) )

Scheme 74

1. INSPECT MIR HTR RELAY Measure the resistance of the DEFOG relay. Standard TESTER CONDITION SPECIFIED CONDITION TABLE Tester Condition Specified Condition 1 - 2 Below 1 ohms 3 - 5 10 k ohms or higher (when battery voltage is not applied between terminals) 3 - 5 Below 1 ohms (when battery voltage is applied to terminals 1 and 2) If the result is not as specified, replace the relay.
