CAN Communication: Overview Lexus IS II

Scheme 1

Scheme 2

Scheme 3

Scheme 4

1. STEERING SYSTEM HANDLING PRECAUTIONS Care must be taken when replacing parts. Incorrect replacement could affect the performance of the steering system and result in hazardous driving.
2. SRS AIRBAG SYSTEM HANDLING PRECAUTIONS This vehicle is equipped with an SRS (Supplemental Restraint System) which includes components such as the driver airbag and front passenger airbag. Failure to carry out service operations in the correct sequence could cause unexpected SRS deployment during servicing and may lead to a serious accident. Before servicing (including removal or installation of parts, inspection or replacement), be sure to read the precautionary notice for the Supplemental Restraint System (See «PRECAUTION»(ref-235542-S10058841152006062400000) ).
3. BUS LINE REPAIR After repairing the bus line with solder, wrap the repaired part with electrical tape. NOTE: The CANL bus line and CANH bus line must be installed together all the times. When installing, make sure to twist them. CAN bus lines are likely to be influenced by electrical noise if they are not twisted. The difference in length between the CANL bus line and CANH bus line should be 100 mm (3.937 in.) or less. Leave approximately 80 mm (3.150 in.) loose in the twisted wires around the connector. Do not use bypass wiring between the connectors. NOTE: The ability of the twisted bus lines to resist interference will be lost if bypass wiring is used.
4. CONNECTOR HANDLING When checking resistance with a tester, insert the tester probes from the backside (harness side) of the connector. Use a service wire to check the connector if it is impossible to check continuity from the rear of the connector.
5. PRECAUTION FOR DISCONNECTING THE BATTERY TERMINAL NOTE: When disconnecting the negative (-) battery terminal, initialize the following systems after the terminal is reconnected. SYSTEM NAME REFERENCE TABLE System Name See procedure Power Window Control System «INITIALIZATION»(ref-235541-S32349848442006062400000) Perform the RESET MEMORY (AT initialization) operation after replacing the automatic transmission assembly, engine assembly, or ECM.

HINT

RESET MEMORY cannot be completed by disconnecting the battery terminal.

Scheme 5

Scheme 6

Scheme 7

HINT

1. The skid control ECU detects and stores steering angle sensor and yaw rate sensor DTCs and performs DTC communication by receiving information from the steering angle sensor and yaw rate sensor.
2. The ECM detects and stores distance control ECU DTCs, and performs DTC communication by receiving information from the distance control ECU.
3. The ECM, 4WD ECU, and power steering ECU use the CAN communication system to perform DTC communication instead of the conventional communication line (SIL).

SYSTEM DESCRIPTION

1. BRIEF DESCRIPTION The CAN (Control Area Network) is a serial data communication system for real time application. It is a vehicle multiplex communication system which has a high communication speed (500 kbps) and the ability to detect malfunctions. By pairing the CANH and CANL bus lines, the CAN performs communication based on differential voltage. Many ECUs (sensors) installed on the vehicle operate by sharing information and communicating with each other. The CAN has two resistors of 120 ohms which are necessary to communicate with the main bus line.
2. DEFINITION OF TERMS Main bus line The main bus line is a wire harness between the two terminating resistors on the bus (communication line). This is the main bus in the CAN communication system. Branch line The branch line is a wire harness which diverges from the main bus line to an ECU or sensor. Terminating resistors Two resistors of 120 ohms resistance are installed in parallel across the ends of the CAN main bus lines. They are called terminating resistors. These resistors allow the changes of the voltage differential between the CAN bus lines to be accurately judged. To allow proper function of CAN communication, it is necessary to have both terminating resistors installed. Since the two resistors are installed in parallel, a measurement of resistance between the two CAN bus lines should produce a reading of approximately 60 ohms.
3. ECUS OR SENSORS WHICH COMMUNICATE THROUGH CAN COMMUNICATION SYSTEM Skid control ECU Yaw rate sensor Steering angle sensor Seat belt control ECU Distance control ECU Center airbag sensor ECM Gateway ECU Power steering ECU
4. DIAGNOSTIC CODE FOR CAN COMMUNICATION SYSTEM DTCs for the CAN communication system are as follows: U0073, U0100, U0101, U0122, U0123, U0124, U0126, U1101, U0105, U0121.
5. TROUBLESHOOTING REMARKS DTCs for the CAN communication system can be checked using the intelligent tester via the CAN VIM. The DLC3 is connected to the CAN communication system, but no DTCs exist regarding problems in the DLC3 or the DLC3 branch lines. If there is trouble in the DLC3 or the DLC3 branch lines, ECUs on the CAN network cannot output codes to the intelligent tester via the CAN VIM. Trouble in the CAN buses (communication lines) can be checked by measuring the resistance between terminals of the DLC3. However, an open circuit in a branch line other than the DLC3 branch lines cannot be checked from the DLC3. NOTE: Do not insert the tester probes directly into the DLC3. Be sure to use service wires.
6. HOW TO DISTINGUISH THE CAN J/C CONNECTOR In the CAN communication system, the shape of all connectors connected to the CAN J/C is the same. The connectors connected to the CAN J/C can be distinguished by the colors of the bus line and the connecting side of the junction connector. HINT: See «TERMINALS OF ECU»(ref-235565-S02261800822006062400000) for bus line color or the type of connecting surface.

DESCRIPTION

SKID CONTROL ECU COMMUNICATION STOP MODE

HINT

"ABS/VSC/TRAC" refers to the circuit that includes the skid control ECU.

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. CONFIRM MODEL Result CONFIRM MODEL Result Proceed to with VDIM System A without VDIM System B B: Go to step 4 A: Go to next step.
2. CHECK CAN BUS LINE FOR OPEN (SKID CONTROL ECU BRANCH LINE) Turn the engine switch off. Disconnect the skid control ECU connector (J77). Measure the resistance according to the value(s) in «CAN BUS LINE FOR OPEN (SKID CONTROL ECU BRANCH LINE)»(ref-235565-S08685815992006062400000) . Standard resistance CAN BUS LINE FOR OPEN (SKID CONTROL ECU BRANCH LINE) Tester Connection Condition Specified Value J77-8 (CANH) - J77-16 (CANL) Engine switch off 54 to 69 ohms NG: REPAIR OR REPLACE SKID CONTROL ECU BRANCH LINE OR CONNECTOR (CAN-H, CAN-L) OK: Go to next step.
3. CHECK WIRE HARNESS (IG1, GND1) Disconnect the skid control ECU connectors (J78) and (A35). Measure the resistance according to the value(s) in «WIRE HARNESS (IG1, GND1) (RESISTANCE)»(ref-235565-S40099528772006062400000) . Standard resistance WIRE HARNESS (IG1, GND1) (RESISTANCE) Tester Connection Condition Specified Value J78-26 (GND1) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in «WIRE HARNESS (IG1, GND1) (VOLTAGE)»(ref-235565-S30798746652006062400000) . Standard voltage WIRE HARNESS (IG1, GND1) (VOLTAGE) Tester Connection Condition Specified Value J77-1 (IG1) - Body ground Engine switch on (IG) 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE SKID CONTROL ECU
4. CHECK CAN BUS LINE FOR OPEN (SKID CONTROL ECU BRANCH LINE) Turn the engine switch off. Disconnect the skid control ECU connector (A14). Measure the resistance according to the value(s) in «CAN BUS LINE FOR OPEN (SKID CONTROL ECU BRANCH LINE)»(ref-235565-S29005673482006062400000) . Standard resistance CAN BUS LINE FOR OPEN (SKID CONTROL ECU BRANCH LINE) Tester Connection Condition Specified Value A14-11 (CANH) - A14-25 (CANL) Engine switch on (IG) 54 to 69 ohms NG: REPAIR OR REPLACE SKID CONTROL ECU BRANCH LINE OR CONNECTOR (CAN-H, CAN-L) OK: Go to next step.
5. CHECK WIRE HARNESS (IG1, GND1) Measure the resistance according to the value(s) in «WIRE HARNESS (IG1, GND1)»(ref-235565-S23483049662006062400000) . Standard resistance WIRE HARNESS (IG1, GND1) (RESISTANCE) Tester Connection Condition Specified Value A14-32 (GND1) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in «WIRE HARNESS (IG1, GND1) (VOLTAGE)»(ref-235565-S23612025002006062400000) . Standard voltage WIRE HARNESS (IG1, GND1) (VOLTAGE) Tester Connection Condition Specified Value A14-46 (IG1) - Body ground Engine switch on (IG) 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE SKID CONTROL ECU (BRAKE ACTUATOR)

DISTANCE CONTROL ECU COMMUNICATION STOP MODE

HINT

"CRUISE CONTROL" refers to the circuit that includes the distance control ECU.

Scheme 14

Scheme 15

Scheme 16

1. CHECK CAN BUS LINE FOR OPEN (DISTANCE CONTROL ECU BRANCH LINE) Turn the engine switch off. Disconnect the distance control ECU connector (J17). Measure the resistance according to the value(s) in «CAN BUS LINE FOR OPEN (DISTANCE CONTROL ECU BRANCH LINE)»(ref-235565-S05923149582006062400000) . Standard resistance CAN BUS LINE FOR OPEN (DISTANCE CONTROL ECU BRANCH LINE) Tester Connection Condition Specified Value J17-8 (CANH) - J17-9 (CANL) Engine switch off 54 to 69 ohms NG: REPAIR OR REPLACE DISTANCE CONTROL ECU BRANCH LINE OR CONNECTOR (CAN-H, CAN-L) OK: Go to next step.
2. CHECK WIRE HARNESS (+B, GND) Measure the resistance according to the value(s) in «WIRE HARNESS (+B, GND)»(ref-235565-S17329159452006062400000) . Standard resistance WIRE HARNESS (+B, GND) (RESISTANCE) Tester Connection Condition Specified Value J17-12 (GND) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in «WIRE HARNESS (+B, GND) (VOLTAGE)»(ref-235565-S21930860072006062400000) . Standard voltage WIRE HARNESS (+B, GND) (VOLTAGE) Tester Connection Condition Specified Value J17-1 (+B) - Body ground Engine switch on (IG) 10 to 14 V OK: REPLACE DISTANCE CONTROL ECU NG: REPAIR OR REPLACE HARNESS OR CONNECTOR

SEAT BELT CONTROL ECU COMMUNICATION STOP MODE

HINT

"PSB" refers to the circuit that includes the seat belt control ECU.

Scheme 17

Scheme 18

Scheme 19

1. CHECK CAN BUS LINE FOR OPEN (SEAT BELT CONTROL ECU BRANCH LINE) Turn the engine switch off. Disconnect the seat belt control ECU connector (Q38). Measure the resistance according to the value(s) in «CAN BUS LINE FOR OPEN (SEAT BELT CONTROL ECU BRANCH LINE)»(ref-235565-S42465366522006062400000) . Standard resistance CAN BUS LINE FOR OPEN (SEAT BELT CONTROL ECU BRANCH LINE) Tester Connection Condition Specified Value Q38-4 (CANH) - Q38-6 (CANL) Engine switch off 54 to 69°F NG: REPAIR OR REPLACE SEAT BELT CONTROL ECU BRANCH LINE OR CONNECTOR (CAN-H, CAN-L) OK: Go to next step.
2. CHECK WIRE HARNESS (IG1, PGND) Measure the resistance according to the value(s) in «WIRE HARNESS (IG1, PGND) (RESISTANCE)»(ref-235565-S36143888852006062400000) . Standard resistance WIRE HARNESS (IG1, PGND) (RESISTANCE) Tester Connection Condition Specified Value Q38-18 (PGND) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in «WIRE HARNESS (IG1, PGND) (VOLTAGE)»(ref-235565-S39888237992006062400000) . Standard voltage WIRE HARNESS (IG1, PGND) (VOLTAGE) Tester Connection Condition Specified Value Q38-3 (IG1) - Body ground Engine switch on (IG) 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE SEAT BELT CONTROL ECU

POWER STEERING ECU COMMUNICATION STOP MODE

HINT

"EPS" refers to the circuit that includes the power steering ECU.

Scheme 20

Scheme 21

Scheme 22

1. CHECK CAN BUS LINE FOR OPEN (POWER STEERING ECU BRANCH LINE) Turn the engine switch off. Disconnect the power steering ECU connector (A31). Measure the resistance according to the value(s) in «CAN BUS LINE FOR OPEN (POWER STEERING ECU BRANCH LINE)»(ref-235565-S03599244752006062400000) . Standard resistance CAN BUS LINE FOR OPEN (POWER STEERING ECU BRANCH LINE) Tester Connection Condition Specified Value A31-2 (CANH) - A31-3 (CANL) Engine switch off 54 to 69 ohms NG: REPAIR OR REPLACE POWER STEERING ECU BRANCH LINE OR CONNECTOR (CANH, CANL) OK: Go to next step.
2. CHECK WIRE HARNESS (IG, PGND) Measure the resistance according to the value(s) in «WIRE HARNESS (IG, PGND) (RESISTANCE)»(ref-235565-S29548008812006062400000) . Standard resistance WIRE HARNESS (IG, PGND) (RESISTANCE) Tester Connection Condition Specified Value A31-5 (PGND) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in «WIRE HARNESS (IG, PGND) (VOLTAGE)»(ref-235565-S10684569892006062400000) . Standard voltage WIRE HARNESS (IG, PGND) (VOLTAGE) Tester Connection Condition Specified Value A31-9 (IG) - Body ground Engine switch on (IG) 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE POWER STEERING ECU

GATEWAY ECU COMMUNICATION STOP MODE

HINT

"BODY/GATEWAY" refers to the circuit that includes the gateway ECU.

Scheme 23

Scheme 24

1. CHECK WIRE HARNESS (BATT, ACC, IG, GND) Turn the engine switch off. Disconnect the gateway ECU connector (J76). Measure the resistance according to the value(s) in «WIRE HARNESS (BATT, ACC, IG, GND) (RESISTANCE)»(ref-235565-S40548051022006062400000) . Standard resistance WIRE HARNESS (BATT, ACC, IG, GND) (RESISTANCE) Tester Connection Condition Specified Value J76-24 (GND) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in «WIRE HARNESS (BATT, ACC, IG, GND) (VOLTAGE)»(ref-235565-S17078759222006062400000) . Standard voltage WIRE HARNESS (BATT, ACC, IG, GND) (VOLTAGE) Tester Connection Condition Specified Value J76-10 (BATT) - Body ground Always 10 to 14 V J76-2 (ACC) - Body ground Engine switch on (IG) 10 to 14 V J76-1 (IG) - Body ground Engine switch on (IG) 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE GATEWAY ECU

STEERING ANGLE SENSOR COMMUNICATION STOP MODE

HINT

"STEERING SENSOR" refers to the circuit that includes the steering angle sensor.

Scheme 25

Scheme 26

Scheme 27

1. CHECK CAN BUS LINE FOR OPEN (STEERING ANGLE SENSOR BRANCH LINE) Turn the engine switch off. Disconnect the steering angle sensor connector (J23). Measure the resistance according to the value(s) in «CAN BUS LINE FOR OPEN (STEERING ANGLE SENSOR BRANCH LINE)»(ref-235565-S17830666912006062400000) . Standard resistance CAN BUS LINE FOR OPEN (STEERING ANGLE SENSOR BRANCH LINE) Tester Connection Condition Specified Value J23-10 (CANH) - J23-9 (CANL) Engine switch off 54 to 69 ohms NG: REPAIR OR REPLACE STEERING ANGLE SENSOR BRANCH LINE OR CONNECTOR (CANH, CANL) OK: Go to next step.
2. CHECK WIRE HARNESS (IG, ESS) Measure the resistance according to the value(s) in «WIRE HARNESS (IG, ESS) (RESISTANCE)»(ref-235565-S03162497182006062400000) . Standard resistance WIRE HARNESS (IG, ESS) (RESISTANCE) Tester Connection Condition Specified Value J23-2 (ESS) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in «WIRE HARNESS (IG, ESS) (VOLTAGE)»(ref-235565-S18687107042006062400000) . Standard voltage WIRE HARNESS (IG, ESS) (VOLTAGE) Tester Connection Condition Specified Value J23-1 (IG) - Body ground Engine switch on (IG) 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE STEERING ANGLE SENSOR

YAW RATE SENSOR COMMUNICATION STOP MODE

HINT

"YAW/DECELERAT" refers to the circuit that includes the yaw rate sensor.

Scheme 28

Scheme 29

Scheme 30

1. CHECK CAN BUS LINE FOR OPEN (YAW RATE SENSOR BRANCH LINE) Turn the engine switch off. Disconnect the yaw rate sensor connector (J41). Measure the resistance according to the value(s) in «CAN BUS LINE FOR OPEN (YAW RATE SENSOR BRANCH LINE)»(ref-235565-S22308639732006062400000) . Standard resistance CAN BUS LINE FOR OPEN (YAW RATE SENSOR BRANCH LINE) Tester Connection Condition Specified Value J41-3 (CANH) - J41-2 (CANL) Engine switch off 54 to 69 ohms NG: REPAIR OR REPLACE YAW RATE SENSOR BRANCH LINE OR CONNECTOR (CANH, CANL) OK: Go to next step.
2. CHECK WIRE HARNESS (IG, GND) Measure the resistance according to the value(s) in «WIRE HARNESS (IG, GND) (RESISTANCE)»(ref-235565-S21530904352006062400000) . Standard resistance WIRE HARNESS (IG, GND) (RESISTANCE) Tester Connection Condition Specified Value J41-1 (GND) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in «WIRE HARNESS (IG, GND) (VOLTAGE)»(ref-235565-S13194690502006062400000) . Standard voltage WIRE HARNESS (IG, GND) (VOLTAGE) Tester Connection Condition Specified Value J41-5 (IG) - Body ground Engine switch on (IG) 10 to 14 V OK: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE YAW RATE AND ACCELERATION SENSOR

ECM COMMUNICATION STOP MODE

HINT

"ENGINE" and "ECT" refer to the circuit that includes the ECM.

Scheme 31

Scheme 32

1. CHECK WIRE HARNESS (+B1, +B, E) Turn the engine switch off. Disconnect the ECM connectors (E4) and (A5). Measure the resistance according to the value(s) in «WIRE HARNESS (+B1, +B, E) (RESISTANCE)»(ref-235565-S26178434012006062400000) . Standard resistance WIRE HARNESS (+B1, +B, E) (RESISTANCE) Tester Connection Condition Specified Value E4-7 (E1) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in «WIRE HARNESS (+B1, +B, E) (VOLTAGE)»(ref-235565-S25437696732006062400000) . Standard voltage WIRE HARNESS (+B1, +B, E) (VOLTAGE) Tester Connection Condition Specified Value A5-5 (+B1) - Body ground Engine switch off 10 to 14 V A5-6 (+B) - Body ground Engine switch off 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE ECM

CENTER AIRBAG SENSOR COMMUNICATION STOP MODE

HINT

"SRS AIRBAG" refers to the circuit that includes the center airbag sensor.

Scheme 33

Scheme 34

Scheme 35

1. CHECK CAN BUS LINE FOR OPEN (CENTER AIRBAG SENSOR BRANCH LINE) Turn the engine switch off. Disconnect the center airbag sensor connector (J47). Measure the resistance according to the value(s) in «CAN BUS LINE FOR OPEN (CENTER AIRBAG SENSOR BRANCH LINE)»(ref-235565-S15609635462006062400000) . Standard resistance CAN BUS LINE FOR OPEN (CENTER AIRBAG SENSOR BRANCH LINE) Tester Connection Condition Specified Value J47-13 (CANH) - J47-22 (CANL) Engine switch off 54 to 69 ohms NG: REPAIR OR REPLACE CENTER AIRBAG SENSOR BRANCH LINE OR CONNECTOR (CANH, CANL) OK: Go to next step.
2. CHECK WIRE HARNESS (IG2, E1, E2) Measure the resistance according to the value(s) in «WIRE HARNESS (IG2, E1, E2) (RESISTANCE)»(ref-235565-S07407426572006062400000) . Standard resistance WIRE HARNESS (IG2, E1, E2) (RESISTANCE) Tester Connection Condition Specified Value J47-25 (E1) - Body ground Always Below 1 ohms J47-26 (E2) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in «WIRE HARNESS (IG2, E1, E2) (VOLTAGE)»(ref-235565-S10012066932006062400000) . Standard voltage WIRE HARNESS (IG2, E1, E2) (VOLTAGE) Tester Connection Condition Specified Value J47-21 (IG2) - Body ground Engine switch on (IG) 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE CENTER AIRBAG SENSOR ASSEMBLY

4WD CONTROL ECU COMMUNICATION STOP MODE

HINT

"4WD" refers to the circuit that includes the 4WD control ECU.

Scheme 36

Scheme 37

Scheme 38

1. CHECK CAN BUS LINE FOR OPEN (4WD CONTROL ECU BRANCH LINE) Turn the engine switch off. Disconnect the 4WD control ECU connector (A32). Measure the resistance according to the value(s) in «STANDARD RESISTANCE DESCRIPTION TABLE»(ref-235565-S38140725172006062400000) . Standard resistance CAN BUS LINE FOR OPEN (4WD CONTROL ECU BRANCH LINE) Tester Connection Condition Specified Value A32-1 (CANH) - A32-14 (CANL) Engine switch off 54 to 69 ohms NG: REPAIR OR REPLACE 4WD CONTROL ECU BRANCH LINE OR CONNECTOR (CANH, CANL) OK: Go to next step.
2. CHECK WIRE HARNESS (IG1, GND) Measure the resistance according to the value(s) in «WIRE HARNESS (IG1, GND) (RESISTANCE)»(ref-235565-S33299556342006062400000) . Standard resistance WIRE HARNESS (IG1, GND) (RESISTANCE) Tester Connection Condition Specified Value A32-30 (GND) - Body ground Always Below 1 ohms Measure the voltage according to the value(s) in «WIRE HARNESS (IG1, GND) (VOLTAGE)»(ref-235565-S24823549672006062400000) . Standard voltage WIRE HARNESS (IG1, GND) (VOLTAGE) Tester Connection Condition Specified Value A32-9 (IG1) - Body ground Engine switch on (IG) 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE 4WD CONTROL ECU

When any DTC for the CAN communication system is output, first measure the resistance between the terminals of the DLC3 to specify the trouble area. Then check that there is no short in the CAN main bus line, between the CAN bus lines, to +B, or to GND.

Scheme 39

Scheme 40

Scheme 41

Scheme 42

1. CHECK CAN BUS LINE (MAIN BUS LINE FOR OPEN, BUS LINES FOR SHORT CIRCUIT) Turn the engine switch off. Measure the resistance according to the value(s) in «CAN BUS LINE (MAIN BUS LINE FOR OPEN, BUS LINES FOR SHORT CIRCUIT)»(ref-235565-S25783145372006062400000) . Standard resistance CAN BUS LINE (MAIN BUS LINE FOR OPEN, BUS LINES FOR SHORT CIRCUIT) Tester Connection Condition Specified Value J21-6 (CANH) - J21-14 (CANL) Engine switch off 54 to 69 ohms Result RESULT DESCRIPTION TABLE Result Proceed to Reference OK A - 69 ohms or higher B «Open in CAN Main Bus Line»(ref-235565-S29782111242006062400000) Below 54 ohms C «Short in CAN Bus Lines»(ref-235565-S33688709942006062400000) B: OPEN IN CAN MAIN BUS LINE C: SHORT IN CAN BUS LINES A: Go to next step.
2. CHECK CAN BUS LINE (SHORT TO B+ IN CAN BUS LINE) Measure the resistance according to the value(s) in «CAN BUS LINE (SHORT TO B+ IN CAN BUS LINE)»(ref-235565-S20014702952006062400000) . Standard resistance CAN BUS LINE (SHORT TO B+ IN CAN BUS LINE) Tester Connection Condition Specified Value J21-6 (CANH) - J21-16 (BAT) Engine switch off 1 M ohms or higher J21-14 (CANL) - J21-16 (BAT) Engine switch off 1 M ohms or higher Reference RESULT DESCRIPTION TABLE Result Reference OK Go to step 3 NG «Short to B+ in CAN Bus Line»(ref-235565-S29902207602006062400000) NG: SHORT TO B+ IN CAN BUS LINE OK: Go to next step.
3. CHECK CAN BUS LINE (SHORT TO GND IN CAN BUS LINE) Measure the resistance according to the value(s) in «CAN BUS LINE (SHORT TO GND IN CAN BUS LINE)»(ref-235565-S26525258432006062400000) . Standard resistance CAN BUS LINE (SHORT TO GND IN CAN BUS LINE) Tester Connection Condition Specified Value J21-4 (CG) - J21-6 (CANH) Engine switch off 1 k ohms or higher J21-4 (CG) - J21-14 (CANL) Engine switch off 1 k ohms or higher Reference RESULT DESCRIPTION TABLE Result See Procedure OK «INSPECTION PROCEDURE»(ref-235565-S12392148882007100200000) NG «SYSTEM DESCRIPTION»(ref-235565-S08244194302006062400000) NG: SHORT TO GND IN CAN BUS LINE OK: GO TO «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-235565-S11257827982006062400000)

There may be an open circuit in the CAN main bus line and/or the DLC3 branch line when the resistance between terminals 6 (CANH) and 14 (CANL) of the DLC3 is 69 ohms or more.

TROUBLE AREA DESCRIPTION TABLE

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

1. CHECK DLC3 Turn the engine switch off. Measure the resistance according to the value(s) in «DLC3 STANDARD RESISTANCE DESCRIPTION TABLE»(ref-235565-S18165970752006062400000) . Standard resistance DLC3 STANDARD RESISTANCE DESCRIPTION TABLE Tester Connection Condition Specified Value Result J21-6 (CANH) - J21-14 (CANL) Engine switch off 108 to 132 ohms A J21-6 (CANH) - J21-14 (CANL) Engine switch off 132 ohms or higher B NOTE: When the measured value is 132 ohms or more and a CAN communication system diagnostic trouble code is output, there may be a fault besides disconnection of the DLC3 branch line. For that reason, troubleshooting should be performed again from «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-235565-S11257827982006062400000) after repairing the trouble area. B: REPAIR OR REPLACE DLC3 BRANCH LINE OR CONNECTOR (CANH, CANL) A: Go to next step.
2. CHECK FOR OPEN IN CAN MAIN BUS LINE (BUS CHECK) Perform "Communication BUS CHECK" using the intelligent tester (See «DIAGNOSIS SYSTEM»(ref-235565-S21398601552006062400000) ). Result FOR OPEN IN CAN MAIN BUS LINE (BUS CHECK) Specified Condition Proceed to "ENGINE and ECT" only are not displayed A "BODY/GATEWAY" only is not displayed B Others C B: Go to step 4 C: Go to step 7 A: Go to next step
3. CHECK FOR OPEN IN CAN MAIN BUS LINE (ECM - CAN LH J/C) Turn the engine switch off. Disconnect the ECM connector (A5). Measure the resistance according to the value(s) in «STANDARD RESISTANCE DESCRIPTION TABLE»(ref-235565-S07975115802006062400000) . Standard resistance FOR OPEN IN CAN MAIN BUS LINE (ECM - CAN LH J/C) Tester Connection Condition Specified Value A5-25 (CANH) - A5-24 (CANL) Engine switch off 108 to 132 ohms NG: REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (ECM - CAN LH J/C) OK: REPLACE ECM
4. CHECK FOR OPEN IN CAN MAIN BUS LINE (GATEWAY ECU - CAN LH J/C) Turn the engine switch off. Disconnect the gateway ECU connector (J76). Measure the resistance according to the value(s) in «FOR OPEN IN CAN MAIN BUS LINE (GATEWAY ECU - CAN LH J/C)»(ref-235565-S08241506422006062400000) . Standard resistance FOR OPEN IN CAN MAIN BUS LINE (GATEWAY ECU - CAN LH J/C) Tester Connection Condition Specified Value J76-17 (CA1H) - J76-18 (CA1L) Engine switch off 108 to 132 ohms OK: REPLACE GATEWAY ECU NG: Go to next step.
5. RECONNECT CONNECTOR Reconnect the gateway ECU connector (J76). Go to next step.
6. CHECK FOR OPEN IN CAN MAIN BUS LINE (CAN RH J/C - GATEWAY ECU) Disconnect the CAN main bus line connector (J84) from the CAN RH J/C B side (without earth terminal). NOTE: Before disconnecting the connector, make a note of where it is connected. Reconnect the connector to its original position. Measure the resistance according to the value(s) in «FOR OPEN IN CAN MAIN BUS LINE (CAN RH J/C - GATEWAY ECU)»(ref-235565-S15937715482006062400000) . Standard resistance FOR OPEN IN CAN MAIN BUS LINE (CAN RH J/C - GATEWAY ECU) Tester Connection Condition Specified Value J84-1 (CANH) - J84-2 (CANL) Engine switch off 108 to 132 ohms NG: REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN RH J/C - GATEWAY ECU) OK: REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN LH J/C - CAN RH J/C)
7. CHECK FOR OPEN IN CAN MAIN BUS LINE (ECM - CAN LH J/C) Turn the engine switch off. Disconnect the ECM connector (A5). Measure the resistance according to the value(s) in «FOR OPEN IN CAN MAIN BUS LINE (ECM - CAN LH J/C)»(ref-235565-S04551297212006062400000) . Standard resistance FOR OPEN IN CAN MAIN BUS LINE (ECM - CAN LH J/C) Tester Connection Condition Specified Value A5-25 (CANH) - A5-24 (CANL) Engine switch off 108 to 132 ohms OK: REPLACE ECM NG: Go to next step.
8. RECONNECT CONNECTOR Reconnect the ECM connector (A5). Go to next step.
9. CHECK FOR OPEN IN CAN MAIN BUS LINE (GATEWAY ECU - CAN LH J/C) Disconnect the gateway ECU connector (J76). Measure the resistance according to the value(s) in «FOR OPEN IN CAN MAIN BUS LINE (GATEWAY ECU - CAN LH J/C)»(ref-235565-S25134570612006062400000) . Standard resistance FOR OPEN IN CAN MAIN BUS LINE (GATEWAY ECU - CAN LH J/C) Tester Connection Condition Specified Value J76-17 (CA1H) - J76-18 (CA1L) Engine switch off 108 to 132 ohms OK: REPLACE GATEWAY ECU NG: Go to next step.
10. RECONNECT CONNECTOR Reconnect the gateway ECU connector (J76).
11. CHECK FOR OPEN IN CAN MAIN BUS LINE (CAN RH J/C - GATEWAY ECU) Disconnect the CAN main bus line connector (J84) from the CAN RH J/C B side (without earth terminal). NOTE: Before disconnecting the connector, make a note of where it is connected. Reconnect the connector to its original position. Measure the resistance according to the value(s) in «FOR OPEN IN CAN MAIN BUS LINE (CAN RH J/C - GATEWAY ECU)»(ref-235565-S41068647352006062400000) . Standard resistance FOR OPEN IN CAN MAIN BUS LINE (CAN RH J/C - GATEWAY ECU) Tester Connection Condition Specified Value J84-1 (CANH) - J84-2 (CANL) Engine switch off 108 to 132 ohms NG: REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN RH J/C - GATEWAY ECU) OK: Go to next step.
12. RECONNECT CONNECTOR Reconnect the CAN main bus line connector (J84) to the CAN RH J/C B side (without earth terminal). Go to next step.
13. CHECK FOR OPEN IN CAN MAIN BUS LINE (ECM - CAN LH J/C) Disconnect the CAN main bus line connector (J2) from the CAN LH J/C A side (with earth terminal). Measure the resistance according to the value(s) in «FOR OPEN IN CAN MAIN BUS LINE (ECM - CAN LH J/C)»(ref-235565-S05754178342006062400000) . Standard resistance FOR OPEN IN CAN MAIN BUS LINE (ECM - CAN LH J/C) Tester Connection Condition Specified Value J2-1 (CANH) - J2-2 (CANL) Engine switch off 108 to 132 ohms NG: REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (ECM - CAN LH J/C) OK: REPAIR OR REPLACE CAN MAIN BUS LINE OR CONNECTOR (CAN LH J/C - CAN RH J/C)

The CAN bus lines are considered to be shorted when the resistance between terminals 6 (CANH) and 14 (CANL) of the DLC3 is below 54 ohms.

TROUBLE AREA DESCRIPTION TABLE

Scheme 51

Scheme 52

Scheme 53

Scheme 54

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

1. CHECK FOR SHORT IN CAN BUS LINES (DLC3 BRANCH LINE) Turn the engine switch off. Disconnect the DLC3 branch line connector (J8) from the CAN LH J/C B side (without earth terminal). NOTE: Before disconnecting the connector, make a note of where it is connected. Reconnect the connector to its original position. Measure the resistance according to the value(s) in «FOR SHORT IN CAN BUS LINES (DLC3 BRANCH LINE)»(ref-235565-S41237008612006062400000) . Standard resistance FOR SHORT IN CAN BUS LINES (DLC3 BRANCH LINE) Tester Connection Condition Specified Value J21-6 (CANH) - J21-14 (CANL) Engine switch off 1 M ohms or higher NG: REPAIR OR REPLACE DLC3 BRANCH LINE OR CONNECTOR OK: Go to next step.
2. RECONNECT CONNECTOR Reconnect the DLC3 branch line connector (J8) to the CAN LH J/C B side (without earth terminal).
3. CHECK FOR SHORT IN CAN BUS LINES (BRANCH LINE) Connect the probes of an ohmmeter to terminals 6 (CANH) and 14 (CANL) of the DLC3. While observing the resistance value shown on the tester, disconnect connectors J1, J3, J4, J5, J6, J9, J82, J83, and J86 from the CAN LH J/C or CAN RH J/C one by one until the resistance becomes normal (between 54 and 69 ohms). HINT: Disconnect the branch line connectors other than those of the DLC3. Wiring color: CAN LH J/C A SIDE (WITH EARTH TERMINAL) WIRING COLOR TABLE CAN LH J/C A Side (with Earth Terminal) Code Color (CANH Side) Color (CANL Side) Steering angle sensor J1 P W ECM J2 B W Seat belt control ECU J3 V W Center airbag sensor J4 R W Wiring color: CAN LH J/C B SIDE (WITHOUT EARTH TERMINAL) WIRING COLOR TABLE CAN LH J/C B Side (without Earth Terminal) Code Color (CANH Side) Color (CANL Side) Yaw rate sensor J5 P W Skid control ECU (without VDIM) J6 R W CAN main bus line (bus line connecting CAN LH J/C and CAN RH J/C) J7 B W DLC3 J8 G W Distance control ECU J9 GR W Wiring color: CAN RH J/C A SIDE (WITH EARTH TERMINAL) WIRING COLOR TABLE CAN RH J/C A Side (with Earth Terminal) Code Color (CANH Side) Color (CANL Side) CAN main bus line (bus line connecting CAN RH J/C and CAN LH J/C) J81 B W Power steering ECU J82 P W Skid control ECU (with VDIM) J83 R W Wiring color: CAN RH J/C B SIDE (WITHOUT EARTH TERMINAL) WIRING COLOR TABLE CAN RH J/C B Side (without Earth Terminal) Code Color (CANH Side) Color (CANL Side) Gateway ECU J84 B W 4WD control ECU J86 V W NOTE: Do not reconnect the disconnected connectors until this inspection is complete because there may be a short in 2 or more branch lines. Result RESULT DESCRIPTION TABLE Symptom Proceed to The resistance is still below 54 ohms when all the specified connectors are disconnected. (There are no shorts in the branch lines.) A The resistance becomes normal (between 54 and 69 ohms) when a connector is disconnected. (There is a short in one or more of the branch lines.) B When there is a short in one or more of the branch lines: Reconnect all of the connectors to the CAN J/C, except for the one that was disconnected last (the short-circuited bus line). Check that the resistance shown on the tester is normal (between 54 and 69 ohms) to confirm that there is a short in the one branch line only. HINT: The connectors connected to the CAN J/C can be distinguished according to the color of the communication bus lines and the shape of the connectors. Reconnecting the connectors to non-specified positions on the CAN J/C does not affect system operation. However, it is preferred to reconnect the connectors to their specified positions to avoid negative effects on the wiring such as tension on the wiring harnesses, and to make future maintenance easier. B: Go to step 9 A: Go to next step.
4. CHECK FOR SHORT IN CAN BUS LINES (GATEWAY ECU MAIN BUS LINE) Disconnect the gateway ECU main bus line connector (J84) from the CAN RH J/C B side (without earth terminal). NOTE: Before disconnecting the connector, make a note of where it is connected. Reconnect the connector to its original position. Measure the resistance according to the value(s) in «STANDARD RESISTANCE DESCRIPTION TABLE»(ref-235565-S27313195832006062400000) . Standard resistance FOR SHORT IN CAN BUS LINES (GATEWAY ECU MAIN BUS LINE) Tester Connection Condition Specified Value J21-6 (CANH) - J21-14 (CANL) Engine switch off 108 to 132 ohms Result RESULT DESCRIPTION TABLE Symptom Proceed to The resistance is still below 54 ohms when the gateway ECU connector is disconnected. (There are no shorts in the gateway ECU main bus lines.) A The resistance falls within the specified range (between 108 and 132 ohms) (either of the terminating resistances is normal) when the gateway ECU connector is disconnected. (There is a short in the gateway ECU main bus lines.) B B: Go to step 11 A: Go to next step.
5. CHECK FOR SHORT IN CAN BUS LINES (ECM MAIN BUS LINE) Disconnect the ECM main bus line connector (J2) from the CAN LH J/C A side (with earth terminal). NOTE: Before disconnecting the connector, make a note of where it is connected. Reconnect the connector to its original position. Measure the resistance according to the value(s) in «FOR SHORT IN CAN BUS LINES (ECM MAIN BUS LINE)»(ref-235565-S24678917622006062400000) . FOR SHORT IN CAN BUS LINES (ECM MAIN BUS LINE) Tester Connection Condition Specified Value J21-6 (CANH) - J21-14 (CANL) Engine switch off 1 M ohms or higher HINT: Measure the resistance with the gateway ECU main bus line connector (J84) disconnected. RESULT DESCRIPTION TABLE Symptom Proceed to The resistance is still below 1 M ohms when the ECM connector is disconnected. (There are no shorts in the ECM main bus lines.) A The resistance becomes 1 M ohms or more when the ECM connector is disconnected. (There is a short in the ECM main bus lines.) B B: Go to step 13 A: Go to next step.
6. CHECK CAN LH J/C Disconnect the CAN main bus line connector (J7) from the CAN LH J/C B side (without earth terminal). NOTE: Before disconnecting the connector, make a note of where it is connected. Reconnect the connector to its original position. Measure the resistance according to the value(s) in «CAN LH J/C»(ref-235565-S39386508912006062400000) . Standard resistance CAN LH J/C Tester Connection Condition Specified Value J21-6 (CANH) - J21-14 (CANL) Engine switch off 1 M ohms or higher NG: REPLACE CAN LH J/C OK: Go to next step.
7. RECONNECT CONNECTOR Reconnect the CAN main bus line connector (J7) to the CAN LH J/C B side (with earth terminal).
8. CHECK CAN RH J/C Disconnect the CAN main bus line connector (J81) from the CAN RH J/C A side (with earth terminal). NOTE: Before disconnecting the connector, make a note of where it is connected. Reconnect the connector to its original position. Measure the resistance according to the value(s) in «CAN RH J/C»(ref-235565-S08754117302006062400000) . Standard resistance CAN RH J/C Tester Connection Condition Specified Value J21-6 (CANH) - J21-14 (CANL) Engine switch off 1 M ohms or higher OK: REPLACE CAN RH J/C NG: REPAIR OR REPLACE CAN MAIN BUS LINE (CAN LH J/C - CAN RH J/C)
9. RECONNECT CONNECTOR Reconnect the connector for the short-circuited branch line to the CAN J/C (the connector that caused the bus line resistance to become normal (between 54 and 69 ohms) when it was disconnected). Go to next step.
10. CHECK FOR SHORT IN CAN BUS LINES Disconnect the connector that includes terminals CANH and CANL from the ECU (or sensor) to which the short-circuited branch line is connected. (See «TERMINALS OF ECU»(ref-235565-S02261800822006062400000) ) Measure the resistance according to the value(s) in «FOR SHORT IN CAN BUS LINES»(ref-235565-S10343907542006062400000) . Standard resistance FOR SHORT IN CAN BUS LINES Tester Connection Condition Specified Value J21-6 (CANH) - J21-14 (CANL) Engine switch off 1 M ohms or higher HINT: If the resistance becomes normal (between 54 and 69 ohms) when the connector is disconnected from the ECU (or sensor), there may be a short in the ECU (or sensor). NG: REPAIR OR REPLACE CORRESPONDING ECU OR SENSOR BRANCH LINE OR CONNECTOR OK: REPLACE CORRESPONDING ECU OR SENSOR
11. RECONNECT CONNECTOR Reconnect the gateway ECU main bus line connector (J84) to the CAN RH J/C B side (without earth terminal).
12. CHECK FOR SHORT IN CAN BUS LINES (GATEWAY ECU) Disconnect the gateway ECU connector (J76). Measure the resistance according to the value(s) in «FOR SHORT IN CAN BUS LINES (GATEWAY ECU)»(ref-235565-S39316036582006062400000) . Standard resistance FOR SHORT IN CAN BUS LINES (GATEWAY ECU) Tester Connection Condition Specified Value J21-6 (CANH) - J21-14 (CANL) Engine switch off 108 to 132 ohms HINT: If the resistance becomes normal (between 108 to 132 ohms) when the connector is disconnected, there may be a short in the gateway ECU. NG: REPAIR OR REPLACE CAN MAIN BUS LINE (GATEWAY ECU MAIN BUS LINE) OK: REPLACE GATEWAY ECU
13. RECONNECT CONNECTOR Reconnect the ECM main bus line connector (J2) to the CAN LH J/C A side (with earth terminal).
14. CHECK FOR SHORT IN CAN BUS LINES (ECM) Disconnect the ECM connector (A5). Measure the resistance according to the value(s) in «FOR SHORT IN CAN BUS LINES (ECM)»(ref-235565-S28419210732006062400000) . Standard resistance FOR SHORT IN CAN BUS LINES (ECM) Tester Connection Condition Specified Value J21-6 (CANH) - J21-14 (CANL) Engine switch off 1 M ohms or higher HINT: Measure the resistance with the gateway ECU main bus line connector (J84) disconnected. If the resistance changes to 1 Mohms or more when the connector is disconnected, there may be a short in the ECM. NG: REPAIR OR REPLACE CAN MAIN BUS LINE (ECM MAIN BUS LINE) OK: REPLACE ECM

A short to B+ is suspected in the CAN bus line when the resistance between terminals 6 (CANH) and 16 (BAT), or terminals 14 (CANL) and 16 (BAT) of the DLC3 is below 1 M ohms.

TROUBLE AREA DESCRIPTION TABLE

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

1. CHECK FOR SHORT TO B+ IN CAN BUS LINE Turn the engine switch off. Disconnect the DLC3 branch line connector (J8) from the CAN LH J/C B side (without earth terminal). NOTE: Before disconnecting the connector, make a note of where it is connected. Reconnect the connector to its original position. Measure the resistance according to the value(s) in «FOR SHORT TO B+ IN CAN BUS LINE»(ref-235565-S37333938972006062400000) . Standard resistance FOR SHORT TO B+ IN CAN BUS LINE Tester Connection Condition Specified Value J21-6 (CANH) - J21-16 (BAT) Engine switch off 1 M ohms or higher J21-14 (CANL) - J21-16 (BAT) Engine switch off 1 M ohms or higher NG: REPAIR OR REPLACE DLC3 BRANCH LINE OR CONNECTOR OK: Go to next step.
2. RECONNECT CONNECTOR Reconnect the DLC3 branch line connector (J8) to the CAN LH J/C B side (without earth terminal).
3. CHECK FOR SHORT TO B+ IN CAN BUS LINE Disconnect connectors from the CAN LH J/C or CAN RH J/C one at a time. HINT: Disconnect the ECU and sensor connectors other than the DLC3 branch lines and CAN main bus lines between the CAN LH J/C and CAN RH J/C. Using an ohmmeter, measure the resistance between terminals 6 (CANH) and 16 (BAT), and between terminals 14 (CANL) and 16 (BAT) of the DLC3 each time a connector is disconnected. Wiring color: CAN LH J/C A SIDE (WITH EARTH TERMINAL) WIRING COLOR TABLE CAN LH J/C A Side (with Earth Terminal) Code Color (CANH Side) Color (CANL Side) Steering angle sensor J1 P W ECM J2 B W Seat belt control ECU J3 V W Center airbag sensor J4 R W Wiring color: CAN LH J/C B SIDE (WITHOUT EARTH TERMINAL) WIRING COLOR TABLE CAN LH J/C B Side (without Earth Terminal) Code Color (CANH Side) Color (CANL Side) Yaw rate sensor J5 P W Skid control ECU (without VDIM) J6 R W CAN main bus line (bus line connecting CAN LH J/C and CAN RH J/C) J7 B W DLC3 J8 G W Distance control ECU J9 GR W Wiring color: CAN RH J/C B SIDE (WITHOUT EARTH TERMINAL) WIRING COLOR TABLE CAN RH J/C A Side (with Earth Terminal) Code Color (CANH Side) Color (CANL Side) CAN main bus line (bus line connecting CAN RH J/C and CAN LH J/C) J81 B W Power steering ECU J82 P W Skid control ECU (with VDIM) J83 R W Wiring color: CAN RH J/C B SIDE (WITHOUT EARTH TERMINAL) WIRING COLOR TABLE CAN RH J/C B Side (without Earth Terminal) Code Color (CANH Side) Color (CANL Side) Gateway ECU J84 B W 4WD control ECU J86 V W NOTE: Do not reconnect the disconnected connectors until this inspection is complete because there may be a short to B+ in 2 or more CAN bus lines. Result RESULT DESCRIPTION TABLE Symptom Proceed to The resistance between terminals 6 (CANH) and 16 (BAT), or the resistance between 14 (CANL) and 16 (BAT) is still below 1 M ohms when all the specified connectors are disconnected from the CAN J/C. (There is a short to B+ in the CAN main bus lines between the CAN LH J/C and CAN RH J/C.) A The resistance between terminals 6 (CANH) and 16 (BAT), or the resistance between 14 (CANL) and 16 (BAT) becomes normal (1 M ohms or more) when a connector is disconnected from the CAN J/C. (There is a short to B+ in one of the areas that relate to one or more of the disconnected bus lines.) B When there is a short to B+ in one or more of the bus lines that connect to an ECU (or sensor): Reconnect all of the connectors to the CAN J/C, except for the one that was disconnected last (the bus line that is shorted to B+). Check that the resistance shown on the tester is normal (1 Mohms or more) to confirm that there is a short to B+ in the one bus line only. HINT: The connectors connected to the CAN J/C can be distinguished according to the color of the communication bus lines and the shape of the connectors. Reconnecting the connectors to non-specified positions on the CAN J/C does not affect system operation. However, it is preferred to reconnect the connectors to their specified positions to avoid negative effects on the wiring such as tension on the wiring harnesses, and to make future maintenance easier. A: REPAIR OR REPLACE CAN MAIN BUS LINE (CAN LH J/C - CAN RH J/C) B: Go to next step.
4. RECONNECT CONNECTOR Reconnect the connector of the bus line that is shorted to B+ to the CAN J/C (the connector that caused the bus line resistance to change to 1 Mohms or more when it was disconnected).
5. CHECK FOR SHORT TO B+ IN CAN BUS LINE Disconnect the connector that includes terminals CANH and CANL from the ECU (or sensor) to which the bus line shorted to B+ is connected. (See «TERMINALS OF ECU»(ref-235565-S02261800822006062400000) ) Measure the resistance according to the value(s) in «FOR SHORT TO B+ IN CAN BUS LINE»(ref-235565-S20721915122006062400000) . Standard resistance FOR SHORT TO B+ IN CAN BUS LINE Tester Connection Condition Specified Value J21-6 (CANH) - J21-16 (BAT) Engine switch off 1 M ohms or higher J21-14 (CANL) - J21-16 (BAT) Engine switch off 1 M ohms or higher HINT: If the resistance changes to 1 Mohms or higher when the connector is disconnected from the ECU (or sensor), there may be a short in the ECU (or sensor). NG: REPAIR OR REPLACE CORRESPONDING ECU OR SENSOR BUS LINE OR CONNECTOR OK: REPLACE CORRESPONDING ECU OR SENSOR

A short to GND is suspected in the CAN bus line when the resistance between terminals 4 (CG) and 6 (CANH), or terminals 4 (CG) and 14 (CANL) of the DLC3 is below 1 kohms.

TROUBLE AREA DESCRIPTION TABLE

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. CHECK FOR SHORT TO GND IN CAN BUS LINE Turn the engine switch off. Disconnect the DLC3 branch line connector (J8) from the CAN LH J/C B side (without earth terminal). NOTE: Before disconnecting the connector, make a note of where it is connected. Reconnect the connector to its original position. Measure the resistance according 10 me value(s) in «FOR SHORT TO GND IN CAN BUS LINE»(ref-235565-S37147824922006062400000) . Standard resistance FOR SHORT TO GND IN CAN BUS LINE Tester Connection Condition Specified Value J21-6 (CANH) - J21-4 (CG) Engine switch off 1 M ohms or higher J21-14 (CANL) - J21-4 (CG) Engine switch off 1 M ohms or higher NG: REPAIR OR REPLACE DLC3 BRANCH LINE OR CONNECTOR OK: Go to next step.
2. RECONNECT CONNECTOR Reconnect the DLC3 branch line connector (J8) to the CAN LH J/C B side (without earth terminal).
3. CHECK FOR SHORT TO GND IN CAN BUS LINE Disconnect connectors from the CAN LH J/C or CAN RH J/C one at a time. HINT: Disconnect the ECU and sensor connectors other than the DLC3 branch lines and CAN main bus lines between the CAN LH J/C and CAN RH J/C. Using an ohmmeter, measure the resistance between terminals 6 (CANH) and 4 (CG), and between terminals 14 (CANL) and 4 (CG) of the DLC3 each time a connector is disconnected. Wiring color: CAN LH J/C A SIDE (WITH EARTH TERMINAL) WIRING COLOR TABLE CAN LH J/C A Side (with Earth Terminal) Code Color (CANH Side) Color (CANL Side) Steering angle sensor J1 P W ECM J2 B W Seat belt control ECU J3 V W Center airbag sensor J4 R W Wiring color: CAN LH J/C B SIDE (WITHOUT EARTH TERMINAL) WIRING COLOR TABLE CAN LH J/C B Side (without Earth Terminal) Code Color (CANH Side) Color (CANL Side) Yaw rate sensor J5 P W Skid control ECU (without VDIM) J6 R W CAN main bus line (bus line connecting CAN LH J/C and CAN RH J/C) J7 B W DLC3 J8 G W Distance control ECU J9 GR W Wiring color: CAN RH J/C A SIDE (WITH EARTH TERMINAL) WIRING COLOR TABLE CAN RH J/C A Side (with Earth Terminal) Code Color (CANH Side) Color (CANL Side) CAN main bus line (bus line connecting CAN RH J/C and CAN LH J/C) J81 B W Power steering ECU J82 P W Skid control ECU (with VDIM) J83 R W Wiring color: CAN RH J/C B SIDE (WITHOUT EARTH TERMINAL) WIRING COLOR TABLE CAN RH J/C B Side (without Earth Terminal) Code Color (CANH Side) Color (CANL Side) Gateway ECU J84 B W 4WD Control ECU J86 V W NOTE: Do not reconnect the disconnected connectors until this inspection is complete because there may be a short to GND in 2 or more CAN bus lines. Result RESULT DESCRIPTION TABLE Symptom Proceed to The resistance between terminals 6 (CANH) and 4 (CG), or the resistance between 14 (CANL) and 4 (CG) is still below 1 k ohms when all the specified connectors are disconnected from the CAN J/C. (There is a short to GND in the CAN main bus lines between the CAN LH J/C and CAN RH J/C.) A The resistance between terminals 6 (CANH) and 4 (CG), or the resistance between 14 (CANL) and 4 (CG) becomes normal (1 k ohms or more) when a connector is disconnected from the CAN J/C. (There is a short to GND in one of the areas that relate to the disconnected bus lines.) B When there is a short to GND in one or more of the bus lines that connect to an ECU (or sensor): Reconnect all of the connectors to the CAN J/C, except for the one that was disconnected last (the bus line that is shorted to GND). Check that the resistance shown on the tester is normal (1 kohms or more) to confirm that there is a short to GND in the one branch line only. HINT: The connectors connected to the CAN J/C can be distinguished according to the color of the communication bus lines and the shape of the connectors. Reconnecting the connectors to non-specified positions on the CAN J/C does not affect system operation. However, it is preferred to reconnect the connectors to their specified positions to avoid negative effects on the wiring such as tension on the wiring harnesses, and to make future maintenance easier. A: REPAIR OR REPLACE CAN MAIN BUS LINE (CAN LH J/C - CAN RH J/C) B: Go to next step.
4. RECONNECT CONNECTOR Reconnect the connector of the bus line that is shorted to GND to the CAN J/C (the connector that caused the bus line resistance to change to 1 kohms or more when it was disconnected).
5. CHECK FOR SHORT TO GND IN CAN BUS LINE Disconnect the connector that includes terminals CANH and CANL from the ECU (or sensor) to which the bus line shorted to GND is connected. (See «TERMINALS OF ECU»(ref-235565-S02261800822006062400000) ) Measure the resistance according to the value(s) in «FOR SHORT TO GND IN CAN BUS LINE»(ref-235565-S36342565692006062400000) . Standard resistance FOR SHORT TO GND IN CAN BUS LINE Tester Connection Condition Specified Value J21-6 (CANH) - J21-4 (CG) Engine switch off 1 k ohms or higher J21-14 (CANL) - J21-4 (CG) Engine switch off 1 k ohms or higher HINT: If the resistance changes to 1 kohms or higher when the connector is disconnected from the ECU (or sensor), there may be a short in the ECU (or sensor). NG: REPAIR OR REPLACE CORRESPONDING ECU OR SENSOR BUS LINE OR CONNECTOR OK: REPLACE CORRESPONDING ECU OR SENSOR

If some ECUs and sensors are not displayed on the "BUS CHECK" screen of the intelligent tester and some ECUs and sensors repeatedly appear and disappear from the screen when the CAN main bus lines are normal (there is no open, short, short to B+, or short to GND in the main bus lines), there may be an open circuit in either of the CAN branch lines.

HINT

If some ECUs and sensors repeatedly appear and disappear from the "BUS CHECK" screen, communication between the normal ECUs (sensors) and intelligent tester may be affected by the incomplete signals that are output from the ECU that has an open circuit in either of its CAN branch lines. In this case, the CAN branch lines for the ECUs and sensors that repeatedly appear and disappear from the screen are normal and the ECU that is not displayed on the screen may be the main cause of the problem (this ECU may have an open circuit in either of its CAN branch lines).

TROUBLE AREA DESCRIPTION TABLE

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

1. CHECK FOR OPEN IN ONE SIDE OF CAN BRANCH LINE Confirm the systems (ECUs and sensors), which use CAN communication, equipped on the vehicle. (See «DIAGNOSIS SYSTEM»(ref-235565-S21398601552006062400000) ) Using the intelligent tester, select and perform "BUS CHECK". (See «DIAGNOSIS SYSTEM»(ref-235565-S21398601552006062400000) ) Observe the screen for approximately 1 minute to check the ECUs and sensors that are not displayed on the screen and also those that repeatedly appear and disappear from the screen. Disconnect the branch line connectors, which are connected to the ECUs or sensors that are not displayed on the screen, from the CAN J/C. Wiring color: CAN LH J/C A SIDE (WITH EARTH TERMINAL) WIRING COLOR TABLE CAN LH J/C A Side (with Earth Terminal) Code Color (CANH Side) Color (CANL Side) Steering angle sensor J1 P W ECM J2 B W Seat belt control ECU J3 V W Center airbag sensor J4 R W Wiring color: CAN LH J/C B (WITHOUT EARTH TERMINAL) WIRING COLOR TABLE CAN LH J/C B Side (without Earth Terminal) Code Color (CANH Side) Color (CANL Side) Yaw rate sensor J5 P W Skid control ECU (without VDIM) J6 R W CAN main bus line (bus line connecting CAN LH J/C and CAN RH J/C) J7 B W DLC3 J8 G W Distance control ECU J9 GR W Result CAN RH J/C A SIDE (WITH EARTH TERMINAL) WIRING COLOR TABLE CAN RH J/C A Side (with Earth Terminal) Code Color (CANH Side) Color (CANL Side) CAN main bus line (bus line connecting CAN RH J/C and CAN LH J/C) J81 B W Power steering ECU J82 P W Skid control ECU (with VDIM) J83 R W Result CAM RH J/C B SIDE (WITHOUT EARTH TERMINAL) WIRING COLOR TABLE CAN RH J/C B Side (without Earth Terminal) Code Color (CANH Side) Color (CANL Side) Gateway ECU J84 B W 4WD Control ECU J86 V W HINT: Connecting locations of the connectors shown in the above tables are those of a vehicle whose connector locations have never been changed. If the connector locations differ from those shown in the above tables, identify each connector according to the color of the bus lines. Check that the ECUs and sensors, which repeatedly appeared and disappeared from the "BUS CHECK" screen, are constantly displayed. Perform the communication stop mode check for the ECUs and sensors which correspond to the disconnected branch line connectors. (See «PROBLEM SYMPTOMS TABLE»(ref-235565-S04377592842006062400000) ). NEXT: GO TO CORRESPONDING COMMUNICATION STOP MODE
