Power Seat Control System: Overview Lexus IS I

Seats 18 illustrations ~706 words

Scheme 14

Scheme 14: LOCATION

Scheme 15

Scheme 15: 1) INSPECT DRIVER'S POWER SEAT SWITCH CONTINUITY

Slide switch

Scheme 16

Scheme 16

Front vertical switch

Scheme 17

Scheme 17

Lifter switch

Scheme 18

Scheme 18

Reclining switch

Scheme 19

Scheme 19

If continuity is not as specified, replace the switch.

5) INSPECT SLIDE MOTOR OPERATION

  1. Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2, check that the motor turns counterclockwise.
  2. Reverse the polarity, check that the motor turns clockwise. If operation is not as specified, replace the seat adjuster.

Scheme 20

Scheme 20

Scheme 21

Scheme 21: 6) INSPECT SLIDE MOTOR PTC THERMISTOR OPERATION
  1. ( ): Passenger side Connect the positive (+) lead from the battery to terminal 1 (2), the positive (+) lead from the ammeter to terminal 2 (1)and the negative (-) lead to the battery negative (-) terminal, then move the seat cushion to the front position.
  2. Continue to apply voltage, check that current changes to less than 1 ampere within 4 to 90 seconds.
  3. Disconnect the leads from terminals.
  4. Approximately 60 seconds later, connect the positive (+) lead from the battery to terminal 2 (1) and the negative (-) lead to terminal 1 (2), check that the seat cushion begins to move backwards.

If operation is not as specified, replace the seat adjuster.

Scheme 22

Scheme 22

7) INSPECT FRONT VERTICAL MOTOR OPERATION

  1. Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2, check that the motor turns counterclockwise.
  2. Reverse the polarity, check that the motor turns clockwise.

If operation is not as specified, replace the seat adjuster.

Scheme 23

Scheme 23

Scheme 24

Scheme 24: 8) INSPECT FRONT VERTICAL MOTOR PTC THERMISTOR OPERATION
  1. ( ): Passenger side Connect the positive (+) lead from the battery to terminal 1 (2), the positive (+) lead from the ammeter to terminal 2 (1) and the negative (-) lead to the battery negative (-) terminal, then move the seat cushion to the highest position.
  2. Continue to apply voltage, check that the current changes to less than 1 ampere within 4 to 90 seconds.
  3. Disconnect the leads from the terminals.
  4. Approximately 60 seconds later, connect the positive (+) lead from the battery to terminal 2 (1) and the negative (-) lead to terminal 1 (2), check that the seat cushion begins to descend.

If operation is not as specified, replace the seat adjuster.

Scheme 25

Scheme 25

9) INSPECT LIFTER MOTOR OPERATION

  1. Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2, check that the motor turns counterclockwise.
  2. Reverse the polarity, check that the motor turns clockwise.

If operation is not as specified, replace the seat adjuster.

Scheme 26

Scheme 26

Scheme 27

Scheme 27: 10) INSPECT LIFTER MOTOR PTC THERMISTOR OPERATION
  1. ( ): Passenger side Connect the positive (+) lead from the battery to terminal 1 (2), the positive (+) lead from the ammeter to terminal 2 and the negative (-) lead to the battery negative (-) terminal, then move the seat cushion to the highest position.
  2. Continue to apply voltage, check that the current changes to less than 1 ampere within 4 to 90 seconds.
  3. Disconnect the leads from the terminals.
  4. Approximately 60 seconds later, connect the positive (+) lead from the battery to terminal 2 and the negative (-) lead to terminal 1 (2), check that the seat cushion begins to descend.

If operation is not as specified, replace the seat adjuster.

Scheme 28

Scheme 28

11) INSPECT RECLINING MOTOR OPERATION

  1. Connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2, check that the motor turns counterclockwise.
  2. Reverse the polarity, check that the motor turns clockwise.

If operation is not as specified, replace the seat adjuster.

Scheme 29

Scheme 29

Scheme 30

Scheme 30: 12) INSPECT RECLINING MOTOR PTC THERMISTOR OPERATION

Scheme 31

Scheme 31
  1. Connect the positive (+) lead from the battery to terminal 2, the positive (+) lead from the ammeter to terminal 1 and the negative (-) lead to the battery negative (-) terminal, then recline the seat back to the most forward position.
  2. Continue to apply voltage, check that the current changes to less than 1 ampere within 4 to 90 seconds.
  3. Disconnect the leads from the terminals.
  4. Approximately 60 seconds later, connect the positive (+) lead from the battery to terminal 1 and the negative (-) lead to terminal 2, check that the seat back begins to fall backward. If operation is not as specified, replace the seat adjuster.
