Maintenance Reminder Light Reset Procedures Lexus IS F I

CHANGE A/C FILTER SERVICE REMINDER INDICATOR

Note. To determine the appropriate reset procedure, refer to CHANGE A/C FILTER SERVICE REMINDER INDICATOR RESET INDEX . Only vehicles listed in this index have a change A/C filter service reminder indicator reset.

CHANGE A/C FILTER SERVICE REMINDER INDICATOR RESET INDEX

CHANGE A/C FILTER SERVICE REMINDER RESET - PROCEDURE 1

If CHANGE A/C FILTER appears on multi-information display, the passenger compartment A/C filter must be changed as soon as possible. After replacing A/C filter, push and hold OFF button for front air conditioning controls for more than 4 seconds. If A/C FILTER RESET appears on display and a tone sounds, service interval has been reset.

ENGINE OIL REPLACEMENT REMINDER LIGHT

Note. To determine the appropriate reset procedure, refer to ENGINE OIL REPLACEMENT REMINDER RESET INDEX . Only vehicles listed in this index have an engine oil replacement reminder light.

ENGINE OIL REPLACEMENT REMINDER RESET INDEX

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 1

To reset MAINT REQD reminder light after engine oil change

1. Turn ignition switch to OFF position with odometer display showing.
2. Turn ignition switch to ON position while holding down ODO/TRIP reset knob.
3. Hold ODO/TRIP reset knob down for at least 5 seconds. Odometer should display "000000", and reminder light will turn OFF.
4. If system fails to reset, reminder light will remain flashing.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 2

To reset MAINT reminder light after engine oil change

1. Start engine. For Hybrid models, use Operating mode.
2. Switch odometer display to TRIP A.
3. Turn ignition OFF.
4. Turn ignition ON (Power mode for Hybrid - Operating mode will cancel reset) while holding down trip meter reset button. On some models, a resetting message is shown on the instrument cluster display
5. Continue to press and hold button until the trip meter displays "000000" and the reminder light turns OFF.
6. If system fails to reset, reminder light will remain flashing.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 3

To reset OIL MAINT REQD reminder light after engine oil change

1. Turn ignition ON, with engine OFF.
2. Push the ODO TRIP switch in the switch box (box flips out on left side of instrument panel) to change the display to blank.
3. Turn ignition switch OFF.
4. Hold down trip meter RESET switch and then turn ignition switch ON.
5. Hold down the RESET switch for more than 7 seconds after ignition switch has been turned ON.
6. The master warning light should come ON, a warning tone should sound, and the multi-information display will show a message informing that engine oil maintenance data has been reset.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 4

To reset OIL MAINT REQD reminder light after engine oil change

1. Turn ignition ON, with engine OFF.
2. Press the DISP switch to change the multi-information display to blank.
3. Turn ignition OFF.
4. Hold down trip meter RESET switch and then turn ignition switch ON.
5. Hold down the trip meter RESET button for more than 7 seconds after ignition switch has been turned ON.
6. The OIL MILEAGE RESET message will appear on the display. The master warning light and tone will turn ON. After 5 seconds, the system reset is completed.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 5

To reset MAINT REQD reminder light after engine oil change

1. Turn ignition ON, with engine OFF.
2. Switch display to ODOMETER.
3. Turn ignition OFF.
4. While pressing the ODO/TRIP button, turn the ignition switch to the ON position.
5. Continue to press and hold button until the "MAINTENANCE REQD RESET MODE COMPLETE" message is displayed.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 6

To reset MAINT REQD reminder light after engine oil change

1. Turn ignition switch to OFF position with odometer display showing.
2. Turn ignition switch to ON position while holding down ODO/TRIP knob.
3. Hold ODO/TRIP reset knob down until reminder light goes OFF. NOTE: Before reminder light goes OFF, it will illuminate for 3 seconds, flash for 2 seconds and illuminate for one second.
4. If system fails to reset, reminder light will remain flashing.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 7

Note. Vehicle is equipped with electronic ignition key. Key should be on your person. Engine switch mode can be changed by pressing ENGINE START/STOP button (1-OFF; 2-ACC; 3-IG-ON) without depressing brake pedal (A/T) or clutch pedal (M/T). Depressing brake or clutch pedal and pressing engine switch will start the engine (engine switch indicator turns Green).

To reset MAINT reminder light after engine oil change

1. Start engine (or activate the Hybrid system). Switch the odometer display to TRIP A while the engine is running/activated.
2. Turn the ENGINE START STOP switch to OFF.
3. Turn the ENGINE START STOP switch to IGNITION ON mode with trip meter reset button held down. NOTE: DO NOT start/activate engine, otherwise the reset mode will be cancelled.
4. Press and hold the button until the multi-information display indicates that the reset is COMPLETE.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 8

To reset MAINT REQD reminder light after engine oil change

1. With ignition switch on, push ODO/TRIP button to change display to blank.
2. Turn ignition switch to OFF position.
3. Turn ignition switch to ON position, while holding trip meter RESET button down.
4. Continue pushing RESET button for more than 5 seconds, after the ignition switch is turned to ON position.
5. Master warning light comes on, a warning tone sounds, and MILEAGE RESET message appears, to inform that engine oil maintenance data has been reset.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 9

To reset MAINT reminder light after engine oil change

1. Switch the power source to IG-ON. Then use the TRIP switch to turn ON the TRIP A display on the multi-information display.
2. Switch the power source to OFF.
3. While pushing the RESET button, switch the power source to IG-ON.
4. Keep holding the RESET switch (for at least five seconds) while the multi-information display counts down.
5. When the reset operation is complete, the multi-information display will display "COMPLETE". Release the RESET switch. After 6 seconds, the "COMPLETE" display will turn OFF.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 10

To reset MAINT reminder light after engine oil change

1. Switch the odometer display to the TRIP METER A while the hybrid system is operating.
2. Turn the POWER switch to OFF mode.
3. While pressing the trip meter RESET button, turn the POWER switch to ON mode (DO NOT start engine, otherwise the reset mode will be cancelled).
4. Press and hold the button until the multi-information display indicates that the reset is COMPLETE.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 11

To reset MAINT reminder light after engine oil change

1. Turn ignition switch to OFF position with odometer display showing.
2. Turn ignition switch to ON position while holding down ODO/TRIP reset knob.
3. Hold ODO/TRIP reset knob down for at least 5 seconds. Odometer should display "000000", and reminder light will turn OFF.
4. If system fails to reset, reminder light will remain flashing.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 12

To reset MAINT reminder light after engine oil change

Note. The reset switch is located inside the integration control and panel assembly on the left side of the instrument panel.

1. Turn the engine switch on (IG) while pressing and holding the reset switch.
2. Hold the reset switch for 5 seconds, and the display shows "OIL MILEAGE RESET" and the master warning light illuminates.
3. When "OIL MILEAGE RESET" disappears and the master warning light turns off, the reset is complete.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 13

To reset MAINT reminder light after engine oil change

1. Turn the engine switch on (IG) and use the ODO/TRIP button to change the screen display to TRIP A. NOTE: The ODO/TRIP switch is in the light control rheostat.
2. Turn the engine switch OFF.
3. While holding in the ODO/TRIP button, turn the engine switch ON (IG).
4. After 5 seconds, reminder system is reset.

Note. If the engine switch is turned OFF during the reset operation, reset mode will be canceled. If the ODO/TRIP button is released during the reset operation, reset mode will be canceled.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 14

To reset MAINT reminder light after engine oil change

1. Turn the ignition (or Power) switch (IG) ON.
2. Use the ODO/TRIP button to change the screen display to TRIP A.
3. Turn the ignition (or Power) switch OFF.
4. Turn the ignition (or Power) switch ON (IG) while pressing and holding the ODO/TRIP button.
5. Hold the ODO/TRIP button for 5 seconds until the following conditions are met: The TRIP A meter shows "000000". The master warning light illuminates.
6. When "000000" disappears and the master warning light turns off, the resetting procedure is complete.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 15

To reset MAINT reminder light after engine oil change

1. Turn the engine switch ON (IG).
2. Press the TRIP meter RESET knob until the ODO meter appears
3. Turn ignition OFF.
4. Turn the engine switch ON (IG) while pressing and holding the trip meter RESET knob.
5. Hold the trip meter RESET knob until the the ODO meter shows "000000", the master warning light illuminates.
6. When "000000" disappears and the master warning light turns OFF, the resetting procedure is complete.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 16

To reset MAINT reminder light after engine oil change

1. Press the Menu switch to change the multi-information display to blank.
2. Turn the ENGINE START STOP switch OFF.
3. While pressing the ODO/TRIP button, turn the ENGINE START STOP switch to IGNITION ON mode.
4. Continue to press and hold the button for more than 7 seconds after the ENGINE START STOP switch is turned to IGNITION ON mode.

The message "RESETTING OIL MAINTENANCE DATA" will appear on the display. After 5 seconds, the system reset will be completed.

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 17

To reset MAINT reminder light after engine oil change

1. Switch the display to the odometer when the engine is running.
2. Turn the "ENGINE START STOP" switch OFF.
3. While pressing the trip meter reset button, set the "ENGINE START STOP" switch to IGNITION ON mode (but do not start the engine because otherwise the reset mode will be cancelled). On some models, a resetting message will appear on the instrument cluster display. Continue to press and hold the button until the trip meter displays "000000" (on some models COMPLETE is displayed).

ENGINE OIL REPLACEMENT REMINDER RESET - PROCEDURE 18

After the required maintenance is performed according to the maintenance schedule, please reset the maintenance data. To reset the data, follow the procedure described below

1. While the engine is running, switch the multi-information display to the SETTINGS screen. Use the right-side steering wheel controls.
2. Select MAINTENANCE SYSTEM on the SETTINGS screen.
3. Select YES on the MAINTENANCE SYSTEM screen. A message will be displayed when the reset procedure has been completed.

INTUITIVE PARKING ASSIST

Note. To determine the appropriate reset procedure, refer to STEERING SENSOR INITIALIZATION INDEX . Only vehicles listed in this index require a steering sensor initialization.

STEERING SENSOR INITIALIZATION INDEX

STEERING SENSOR INITIALIZATION - PROCEDURE 1

When "System is Initializing" is displayed on the multi-display, correct the steering angle neutral point by fully turn the steering wheel to the right and left on flat ground.

Note. Memorizing the steering angle neutral point must be carried out with the hybrid system started. Apply the parking brake, depress the brake pedal, push the P position switch, and ensure that the vehicle is not moving.

Note. The "?" button is displayed at the same time as "System Initializing". If the "?" button is selected, Steering Initialization method is displayed.

Scheme 1

STEERING SENSOR INITIALIZATION - PROCEDURE 2

Note. On some vehicles, an Intelligent Tester or Techstream may be used to perform the Steering Initialization procedure.

If the following message is displayed (Scheme 2), calibrate the neutral position of the steering wheel and confirm that the message has disappeared.

Scheme 2

Initializing The Steering Sensor - Use one of the following methods

1. With vehicle stopped, (On older models, turn on clearance sonar main switch, if equipped), turn the steering wheel all the way to the left and right. (The order is not important.)
2. Drive for more than 5 minutes on an un-crowded road with as few curves and corners as possible

If the steering guide symbol disappears, the steering sensor has been initialized. If the steering guide symbol does not disappear, have the vehicle checked by your Lexus dealer.

TIRE PRESSURE MONITOR SYSTEM (TPMS)

Note. To determine the appropriate reset procedure, refer to TPMS RESET INDEX . Only the vehicles listed in this index have a TPMS reset.

TPMS RESET INDEX

Registration Of Transmitter ID

Note. If completion of steps 4 - 6 is not accomplished within 5 minutes., the mode will return to normal operating mode.

1. Set the tire pressure of all wheels to the specified value.
2. Connect the intelligent tester to DLC3.
3. Turn the ignition switch to the ON position.
4. Read and write down the ID by using the DATA LIST.
5. Select the registration mode "MAIN".
6. Input the ID using the intelligent tester and transmit it to the tire pressure warning ECU.
7. Set the ID transmission condition to "COMPLETE".

Confirmation Of Transmitter ID Registration

1. Set the tire pressure of all wheels to the specified value.
2. Connect the intelligent tester to DLC3.
3. Turn the ignition switch to the ON position.
4. Select the "SIGNAL CHECK" mode on the intelligent tester.
5. Forcibly transmit the transmitter IDs for all wheels.
6. Check that test mode DTCs C2181/81, C2182/82, C2183/83, C2184/84 and C2185/85 are all erased.
7. Set the tire pressure of all wheels to the specified value.

TPMS RESET - PROCEDURE 2

Note. This system requires initializing after changing tires or wheels or after rotating the tires. Be sure to adjust the tire pressure to the specified value before initialization.

1. Turn the ignition switch to the ON position.
2. Press and hold the tire pressure warning reset switch until the "Pressure Initial" indicator comes on.
3. Drive the vehicle at 19 mph (30 km/h) or more to complete the initialization of the skid control ECU. NOTE: If the "Pressure Initial" indicator does not come on, perform the initialization again (With the ignition switch off, perform steps 2 and 3 ).
4. Check that the indicator is not displayed after driving the vehicle for approximately 60 minutes.
5. After initialization is completed, the skid control ECU monitors the tire pressure by using the wheel speed sensors.

Description Of Code Registration

Note. It is necessary to register the transmitter ID in the tire pressure warning ECU when replacing the tire pressure warning valve and transmitter and/or tire pressure warning ECU.

Prepare all transmitter ID data before starting registration. Before performing registration procedure

1. In case of tire pressure warning ECU replacement: Read the registered transmitter IDs that are stored in the old ECU using the Techstream and note them down. If reading stored transmitter IDs is impossible due to malfunctions of components such as the tire pressure warning antenna and receiver, remove the tires from the wheels and check the IDs located on the tire pressure warning valves and transmitters.
2. In case of tire pressure warning valve and transmitter, take a note of the 7 digit number (transmitter ID) written on the tire pressure warning valve and transmitter.

Note. The transmitter ID is written on the tire pressure warning valve and transmitter. It will be unable to be read after installing the tire pressure warning valve and transmitter on the tire and wheel. Therefore, take a note of the transmitter ID before installing the tire pressure warning valve and transmitter.

Register Transmitter ID

1. Set the tire pressure of all tires to the specified value.
2. Turn the ignition switch OFF.
3. Connect the Techstream to the DLC3.
4. Turn the ignition switch ON and the Techstream on.
5. Select the registration mode "MAIN".
6. Enter the menu items in this order: Chassis / Tire Pressure Monitor / Utility / ID Registration.
7. Perform the procedures displayed on the screen.
8. Confirmation of transmitter ID registration: Enter the menu items in this order: Chassis / Tire Pressure Monitor / Data List . Read the "ID Tire Inflation Pressure" values. Confirm that the tire pressure data of all tires is displayed on the screen.

Note. It may take up to about 2 or 3 minutes to update the tire pressure data. If the values are not displayed after a few minutes, perform troubleshooting according to the inspection procedure for DTCs C2121/21 to C2125/25 *1 or C2131/31 to C2135/35 *2. If the IDs have not been registered, DTC C2171/71 *1 (Transmitter ID not Registered in Main Mode) or C2172/72 *2 (Transmitter ID not Registered in 2nd Mode) is set in the tire pressure warning ECU after 3 minutes or more. If normal pressure values are displayed, the IDs have been registered correctly. If the tire pressure values are not displayed after a few minutes, the IDs may be incorrect or the system may have a malfunction. After all IDs are registered, DTC C2126/26 *1 (Transmitter ID not Received in Main Mode) or C2127/27 *2 (Transmitter ID not Received in 2nd Mode) is set in the tire pressure warning ECU and the tire pressure warning light blinks for 1 minute and then comes on. When the tire pressure warning ECU successfully receives information from all the transmitters whose IDs are stored in the ECU, DTC C2126/26 *1 or C2127/27 *2 is deleted and the tire pressure warning light goes off. * 1: Main * 2: 2nd

TPMS RESET - PROCEDURE 4

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

The system will need to be initialized when tires are rotated; tires are inflated to a specification different from currently logged pressures; tire pressure sensor and/or tire pressure monitor ECU are replaced. See TPM Initialization . When a tire pressure sensor and/or tire pressure monitor ECU are replaced, the sensor IDs must be memorized by the tire pressure monitor ECU prior to system initialization. See Sensor Registration .

Sensor Registration

Note. This procedure relies on the use of the Toyota Intelligent Tester or Techstream.

Note. It is necessary to register the transmitter ID in the tire pressure warning ECU when replacing the tire pressure warning valve and transmitter and/or tire pressure warning ECU. Before registration: In case of tire pressure warning ECU replacement. Read the registered transmitter IDs that are stored in the old ECU using the Intelligent Tester and note them down. If reading stored transmitter IDs is impossible due to malfunctions of components such as the tire pressure warning antenna and receiver, remove the tires from the wheels and check the IDs located on the tire pressure warning valves and transmitters. In case of tire pressure warning valve and transmitter replacement. When replacing the tire pressure warning valves and transmitters, note down the IDs written on the tire pressure warning valves and transmitters.

1. Connect the Intelligent Tester to DLC3.
2. Turn the engine switch ON.
3. Turn the Intelligent Tester ON and enter the menu items in this order: DIAGNOSIS / OBD/MOBD / CHASSIS / TIRE PRESSURE. Then, select the "UTILITY" item.
4. Select the registration mode "MAIN".
5. Input the IDs (ID1 to ID4 or ID5) using the Intelligent Tester and transmit them to the tire pressure warning ECU.
6. The "ID Registration is complete" is displayed. NOTE: The tire pressure warning light will continue to blink until the tire pressure warning ECU receives the input ID signals. Registration can be performed during initialization. However, the initialization will be cancelled when the registration is started.

TPM Initialization

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. Before initialization, set the air pressure of all wheels, including the full-size spare tire, to the specified value. Perform the tire pressure adjustment after the vehicle has sufficiently cooled down. If the vehicle is not sufficiently cooled down, increase the air pressure by 20 to 30 kPa (0.2 to 0.3 kgf/cm2, 2.9 to 4.3 psi) above the specified value.

Note. Perform initialization in the following cases: After replacement of the tire pressure ECU. Perform initialization after the transmitter ID registration is completed. After replacement of the tire pressure warning valve and transmitter. Perform initialization after the transmitter ID registration is completed.

Note. Tire pressure warning light will not blink until the system initialization is complete.

1. Turn the engine power switch to ON.
2. On IS models: Repeatedly press either of the ARROW buttons on the TPMS reset switch until the initialization setting display appears. (Scheme 3) Then press and hold the ON/OFF button until the tire pressure warning light blinks slowly 3 times to indicate that the initial setting is complete. On All Other Models: Press and hold the TPMS reset switch until the tire pressure warning light blinks slowly 3 times. (Scheme 4) NOTE: Initialization will be completed if signals are received from all the wheels (including the spare tire).
3. Turn the engine switch OFF.
4. Wait for 2 or 3 minutes with the engine switch ON. NOTE: The initialization is normally completed within 2 to 3 minutes. If the initialization has not been completed successfully, DTC C2177/77 will be stored in the tire pressure warning ECU after a vehicle speed of at least 5 mph (8 km/h) for 20 minutes or more. The initialization can be terminated by making a short circuit between terminals TC and CG of the DLC3 connector.
5. Confirm Initialization Has Been Completed: Check the data of tire pressure of all the wheels (including the ground spare tire) are displayed on the Techstream display to confirm that the initialization has been completed. Turn the engine switch off. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn Techstream on. Check the Data List. Enter the following menus: Chassis / Tire Pressure Monitor / Data List. Tire Pressure Monitor: NORMAL CONDITION CHART Tester Display Measurement Item/Range Normal Condition Diagnostic Note ID1 Tire Inflation Pressure ID1 tire inflation pressure/ min. Absolute pressure/ 0 kPa (0 kgf/cm 2, 0 psi), Relative pressure/ -100 kPa (-1 kgf/cm 2, -14 psi) max.: Absolute pressure/ 637.5 kPa (6.5 kgf/cm 2, 92 psi), Relative pressure/ 537.5 kPa (5.4 kgf/cm 2, 78 psi) Actual tire inflation pressure If 0 kPa(0 kgf/cm 2, 0 psi) is displayed for absolute pressure or -100 kPa (-1 kgf/cm 2, -14 psi) is displayed for relative pressure, data has not been received. (*1) ID2 Tire Inflation Pressure ID2 tire inflation pressure/ min. Absolute pressure/ 0 kPa (0 kgf/cm 2, 0 psi), Relative pressure/ -100 kPa(-1 kgf/cm 2,-14 psi) max.: Absolute pressure/ 637.5 kPa (6.5 kgf/cm 2, 92 psi), Relative pressure/ 537.5 kPa (5.4 kgf/cm 2, 78 psi) Actual tire inflation pressure If 0 kPa (0 kgf/cm 2, 0 psi) is displayed for absolute pressure or -100 kPa (-1 kgf/cm 2, -14 psi) is displayed for relative pressure, data has not been received. (*1) ID3 Tire Inflation Pressure ID3 tire inflation pressure/ min. Absolute pressure/ 0 kPa (0 kgf/cm 2, 0 psi), Relative pressure/ -100 kPa(-1 kgf/cm 2, -14 psi) max.: Absolute pressure/ 637.5 kPa (6.5 kgf/cm 2, 92 psi), Relative pressure/ 537 5 kPa (5.4 kgf/cm 2, 78 psi) Actual tire inflation pressure If 0 kPa (0 kgf/cm 2, 0 psi) is displayed for absolute pressure or -100 kPa (-1 kgf/cm 2, -14 psi) is displayed for relative pressure, data has not been received. (*1) ID4 Tire Inflation Pressure ID4 tire inflation pressure/ min.: Absolute pressure/ 0 kPa (0 kgf/cm 2, 0 psi), Relative pressure/ -100 kPa (-1 kgf/cm 2, -14 psi) max.: Absolute pressure/ 637.5 kPa (6.5 kgf/cm 2, 92 psi), Relative pressure/537.5 kPa (5.4 kgf/cm 2, 78 psi) Actual tire inflation pressure If 0 kPa (0 kgf/cm 2, 0 psi) is displayed for absolute pressure or -100 kPa (-1 kgf/cm 2, -14 psi) is displayed for relative pressure, data has not been received. (*1) ID5 Tire Inflation Pressure ID5 tire inflation pressure/ min.: Absolute pressure/ 0 kPa (0 kgf/cm 2, 0 psi), Relative pressure/ -100 kPa (-1 kgf/cm 2, -14 psi) max.: Absolute pressure/ 637.5 kPa (6 5 kgf/cm 2, 92 psi), Relative pressure/537.5 kPa (5.4 kgf/cm 2, 78 psi) Actual tire inflation pressure If 0 kPa (0 kgf/cm 2, 0 psi) is displayed for absolute pressure or -100 kPa (-1 kgf/cm 2, -14 psi) is displayed for relative pressure, data has not been received (*1) HINT: The initialization is complete when the Data List "ID Tire Inflation Pressure" display shows the correct pressures. *1: It may take about 2 or 3 minutes until the values are displayed. If the values are not displayed after a few minutes, perform troubleshooting according to the inspection procedure for DTCs C2121/21 to C2125/25 (or DTCs C2131/31 to C2135/35) ).

Scheme 3

Scheme 4

TPMS RESET - PROCEDURE 5

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

The system will need to be initialized when tires are rotated; tires are inflated to a specification different from currently logged pressures; tire pressure sensor and/or tire pressure monitor ECU are replaced. See TPM Initialization . When a tire pressure sensor and/or tire pressure monitor ECU are replaced, the sensor IDs must be memorized by the tire pressure monitor ECU prior to system initialization. See Sensor Registration .

Note. This procedure relies on the use of the Toyota Techstream.

Note. It is necessary to register the transmitter ID in the tire pressure warning ECU when replacing the tire pressure warning valve and transmitter and/or tire pressure warning ECU. Before registration: In case of tire pressure warning ECU replacement. Read the registered transmitter IDs that are stored in the old ECU using the Techstream and note them down. If reading stored transmitter IDs is impossible due to malfunctions of components such as the tire pressure warning antenna and receiver, remove the tires from the wheels and check the IDs located on the tire pressure warning valves and transmitters. In case of tire pressure warning valve and transmitter replacement. When replacing the tire pressure warning valves and transmitters, note down the IDs written on the tire pressure warning valves and transmitters.

Note. If the ID registration step is not completed within 300 seconds, ID registration will be canceled.

1. Set the air pressure of all tires to the specified value(s).
2. Turn the power switch off.
3. Connect the Techstream to DLC3.
4. Turn the engine switch on (IG) and the Techstream on.
5. Enter the following menus: Chassis / Tire Pressure Monitor / Utility / ID Registration.
6. Perform the procedure displayed on the Techstream.
7. Enter the following menus: Chassis / Tire Pressure Monitor / Data List.
8. Read the "ID Tire Inflation Pressure" values.
9. Confirm that the tire pressure data of all tires (except the spare tire) is displayed on the Techstream screen.

Note. Initialization is NOT required if re-inflating tires to the currently specified tire pressure.

Note. If the signals from all the wheels are received, initialization is completed. Initialization can be confirmed through the tire pressure warning light. Initialization is completed when the Data List "ID Tire Inflation Pressure" display shows the correct pressures. It may take up to a few minutes until the values are displayed. If the values are not displayed after a few minutes, perform troubleshooting according to the inspection procedure for DTCs C2121/21 to C2124/24. If initialization has not been completed successfully, DTC C2177/77 is stored after a vehicle speed of 8 km/h (5 mph) or more continues for 20 minutes or more. During test mode (sensor check mode), the system will not change to initialization mode even if the tire pressure warning reset switch is pushed.

Note. Before initialization, set the air pressure of all wheels to the specified value. Perform the tire pressure adjustment after the vehicle has sufficiently cooled down. If the vehicle is not sufficiently cooled down, increase the air pressure by 2.9 to 4.3 psi above the specified value.

Note. Tire pressure warning light will not blink until the system initialization is complete.

1. Turn the power switch ON (IG).
2. Press and hold the tire pressure warning reset switch for 3 seconds or more so that the tire pressure warning light blinks 3 times. (Scheme 4)
3. Wait for a few minutes with the power switch in ON mode and turn the power switch OFF.
4. Connect the Techstream to the DLC3.
5. Turn the power switch ON (IG) and turn the Techstream ON.
6. Enter the following menus: Chassis / Tire Pressure Monitor / Data List.
7. Check that initialization has been completed.
8. Confirm that the tire pressure data of all tires is displayed on the Techstream screen.

TPMS RESET - PROCEDURE 6

Note. When the tire pressure warning light does not go off, or when it comes on during driving, inflate tires to specification. Adjusting the tire inflation pressure will turn off the warning light after a few minutes.

Note. It is necessary to register the transmitter (tire pressure sensor) ID in the tire pressure warning ECU when replacing the tire pressure warning valve and transmitter and/or tire pressure warning ECU. Before registration: In case of tire pressure warning ECU replacement. Read the registered transmitter IDs that are stored in the old ECU using the Techstream and note them down. If reading stored transmitter IDs is impossible due to malfunctions of components such as the tire pressure warning antenna and receiver, remove the tires from the wheels and check the IDs located on the tire pressure warning valves and transmitters. In case of tire pressure warning valve and transmitter replacement. When replacing the tire pressure warning valves and transmitters, note down the IDs written on the tire pressure warning valves and transmitters.

Note. If the ID registration step is not completed within 300 seconds, ID registration will be canceled.

1. Set the air pressure of all tires to the specified value(s).
2. Turn the power switch OFF.
3. Connect the Techstream to DLC3.
4. Turn the engine switch ON and the Techstream ON.
5. Enter the following menus: Chassis / Tire Pressure Monitor / Utility / ID Registration.
6. Perform the procedure displayed on the Techstream.
7. Enter the following menus: Chassis / Tire Pressure Monitor / Data List.
8. Read the "ID Tire Inflation Pressure" values.
9. Confirm that the tire pressure data of all tires (except the spare tire) is displayed on the Techstream screen.

See also:
• CHANGE A/C FILTER SERVICE REMINDER INDICATOR RESET INDEX
• Change A/C Filter Service Reminder Reset - Procedure 1
• Engine Oil Replacement Reminder Reset - Procedure 14
• Steering Sensor Initialization - Procedure 1
• Steering Sensor Initialization - Procedure 2
• TPMS Reset - Procedure 5
• TPMS Reset - Procedure 4
• TPMS Reset - Procedure 6
• TPMS Reset - Procedure 2
• TPM Initialization
• Sensor Registration
