PROBLEM SYMPTOMS TABLE
HINT
- Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptoms by checking the suspected areas in the order they are listed. Replace parts as necessary.
- Inspect the fuses and relays related to this system before inspecting the suspected areas below.
| Symptom | Suspected Area | See |
|---|---|---|
| Entire combination meter does not operate. | Combination Meter Circuit | Refer to Entire Combination Meter does not Operate |
| Light control rheostat malfunction | Light Control Rheostat Circuit | Refer to Operating Light Control Rheostat does not Change Light Brightness |
| Meter Illumination is Always Dark. | Meter Illumination Circuit | Refer to Meter Illumination is Always Dark |
| Meter Illumination does not Dim at Night. | Meter Illumination Circuit | Refer to Meter Illumination does not Dim at Night |
| Satellite switch malfunction | Satellite Switch Circuit | Refer to Satellite Switch Circuit |
ENTIRE SYSTEM
| Symptom | Suspected Area | See |
|---|---|---|
| Speedometer malfunction | Speedometer Circuit | Refer to Speedometer Malfunction |
| Tachometer malfunction | Tachometer Circuit | Refer to Tachometer Malfunction |
| Fuel receiver gauge malfunction | Fuel Receiver Gauge Circuit | Refer to Fuel Receiver Gauge Malfunction |
| Engine coolant temperature receiver gauge malfunction | Engine Coolant Temperature Receiver Gauge Circuit | Refer to Engine Coolant Temperature Receiver Gauge Malfunction |
| Engine oil temperature gauge malfunction | Oil Temperature Gauge Circuit | Refer to Oil Temperature Gauge Malfunction |
| Voltage meter malfunction | Voltage Meter Circuit | Refer to Voltage Meter Malfunction |
METER/GAUGE
| Symptom | Suspected Area | See |
|---|---|---|
| MIL (Check engine warning light) malfunction | MIL Circuit (for 2UR-GSE) | Refer to MIL Circuit |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Charge warning light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Generator (for 2UR-GSE) | Refer to INSPECTION | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Brake warning light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Brake Warning Light Circuit | Refer to Brake Warning Light does not Come ON | |
| Wire Harness or Connector | ||
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Brake warning light does not go off. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Brake Warning Light Circuit | Refer to Brake Warning Light Remains ON | |
| Wire Harness or Connector | ||
| Combination Meter | Refer to REMOVAL - Step 9 | |
| ABS warning light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| ABS Warning Light Circuit | Refer to ABS Warning Light does not Come ON | |
| Combination Meter | Refer to DATA LIST / ACTIVE TEST | |
| ABS warning light does not go off. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| ABS Warning Light Circuit | Refer to ABS Warning Light Remains ON | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Airbag warning light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Airbag Warning Light Circuit | Refer to SRS Warning Light does not Come ON | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Airbag warning light does not go off. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Airbag Warning Light Circuit | Refer to SRS Warning Light Remains ON | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Driver side seat belt warning light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Driver Side Seat Belt Warning Light Circuit | Refer to Driver Side Seat Belt Warning Light does not Operate | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Front passenger side seat belt warning light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Front Passenger Side Seat Belt Warning Light Circuit | Refer to Front Passenger Side Seat Belt Warning Light Malfunction | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Front Passenger Side Seat Belt Warning Light | Refer to REMOVAL | |
| Door open warning light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Door Courtesy Light Switch | Refer to INSPECTION - Step 1 | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Fuel level warning light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Fuel Sender Gauge Assembly (for 2UR-GSE) | Refer to INSPECTION | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Master caution indicator light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Combination Meter | Refer to DATA LIST / ACTIVE TEST | |
| EPS warning light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Power Steering Warning Light Circuit | Refer to PS Warning Light does not Come ON | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| EPS warning light remains on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Power Steering Warning Light Circuit | Refer to PS Warning Light Remains ON | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Tire pressure warning light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Tire Pressure Warning System | Refer to Tire Pressure Warning Light Circuit | |
| Combination Meter | Refer to REMOVAL - Step 9 |
WARNING LIGHT
| Symptom | Suspected Area | See |
|---|---|---|
| Turn indicator light does not come on. | Turn Indicator Light Circuit | Refer to Turn Signal Light Circuit |
| Wire Harness or Connector | ||
| Combination Meter | Refer to REMOVAL - Step 9 | |
| High beam indicator light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Lighting System | Refer to Headlight (HI-BEAM) Circuit | |
| Wire Harness or Connector | ||
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Cruise indicator light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Cruise Indicator Light Circuit | Refer to Cruise Main Indicator Light Circuit | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Slip indicator light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| SLIP Indicator Light Circuit | Refer to Slip Indicator Light does not Come ON | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Slip indicator light does not go off. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| SLIP Indicator Light Circuit | Refer to Slip Indicator Light Remains ON | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| TRAC OFF indicator light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| TRAC OFF indicator Light Circuit | Refer to TRAC OFF Indicator Light does not Come ON | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| TRAC OFF indicator light does not go off. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| TRAC OFF indicator Light Circuit | Refer to TRAC OFF Indicator Light Remains ON | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Head (for U.S.A.) indicator light malfunction | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Lighting System | Refer to PROBLEM SYMPTOMS TABLE | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Tail (for Canada) indicator light malfunction | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Lighting System | Refer to Taillight Circuit | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| A/T shift indicator light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| ECM (for 2UR-GSE) | Refer to REMOVAL - Step 6 | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| AFS OFF indicator light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Lighting System | Refer to PROBLEM SYMPTOMS TABLE | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Sonar indicator light does not come on. (w/ Intuitive Parking Assist System) | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Intuitive Parking Assist System | Refer to PROBLEM SYMPTOMS TABLE | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| PCS indicator light does not come on. (w/ Pre-collision System) | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Pre-collision System | Refer to PROBLEM SYMPTOMS TABLE | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Sport indicator light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| ECM (for 2UR-GSE) | Refer to DIAGNOSTIC TROUBLE CODE CHART | |
| Pattern Select Switch (for AA80E) | Refer to Pattern Select Switch Circuit | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Snow indicator light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| ECM (for 2UR-GSE) | Refer to DIAGNOSTIC TROUBLE CODE CHART | |
| Pattern Select Switch (for AA80E) | Refer to Pattern Select Switch Circuit | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Front fog indicator light does not come on. | Combination Meter (LED) | Refer to DATA LIST / ACTIVE TEST |
| Front Fog Light Circuit | Refer to Front Fog Light Circuit | |
| Combination Meter | Refer to REMOVAL - Step 9 |
INDICATOR LIGHT
| Symptom | Suspected Area | See |
|---|---|---|
| Key reminder warning buzzer does not sound. | Combination Meter (Buzzer) | Refer to DATA LIST / ACTIVE TEST |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Seat belt warning buzzer does not sound. | Combination Meter (Seat Belt Buzzer ON/OFF Setting) | Refer to CUSTOMIZE PARAMETERS |
| Combination Meter (Buzzer) | Refer to DATA LIST / ACTIVE TEST | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Shift down reject buzzer does not sound. | Combination Meter (Buzzer) | Refer to DATA LIST / ACTIVE TEST |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Multi-information display warning buzzer does not sound. | Combination Meter (Buzzer) | Refer to DATA LIST / ACTIVE TEST |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Engine speed limit warning buzzer does not sound. | Combination Meter (Buzzer) | Refer to DATA LIST / ACTIVE TEST |
| Combination Meter | Refer to REMOVAL - Step 9 |
BUZZER
| Symptom | Suspected Area | See |
|---|---|---|
| Multi-information display does not light up. | Combination Meter (Multi-information Display) | Refer to DATA LIST / ACTIVE TEST |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Multi-information display does not change when pressing the DISP switch. | Steering Pad Switch | Refer to INSPECTION |
| Spiral Cable | Refer to INSPECTION | |
| Wire Harness or Connector | ||
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Door open warning display does not available. | Main Body ECU RH (Cowl Side Junction Block RH) | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Maintenance required display malfunction. (for U.S.A.) | Combination Meter (Oil Maintenance Resetting Procedure) | Refer to INITIALIZATION |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| ODO/TRIP display does not come on. | Combination Meter | Refer to REMOVAL - Step 9 |
| Outside temperature display malfunction | Outside Temperature Sensor Circuit | Refer to DTC B1412/12: Ambient Temperature Sensor Circuit |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Instantaneous fuel consumption display malfunction | ECM (for 2UR-GSE) | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Average fuel consumption display or average fuel consumption after refueling display malfunction | ECM (for 2UR-GSE) | |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Driving with parking brake unreleased display malfunction | Parking Brake Switch | Refer to INSPECTION - Step 1 |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| A/T shift display malfunction | Automatic Transmission System (for AA80E) | Refer to HOW TO PROCEED WITH TROUBLESHOOTING |
| Shift Paddle Switch Circuit (for AA80E) | Refer to Shift Paddle Switch Circuit | |
| Combination Meter | Refer to REMOVAL | |
| Dynamic Radar cruise control system display malfunction (w/ Dynamic Radar Cruise Control System) | Cruise Control System | Refer to Cruise Main Indicator Light Circuit |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Moon roof open display malfunction (w/ Sliding Roof) | Sliding Roof Control System | Refer to PROBLEM SYMPTOMS TABLE |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Steering lock display malfunction | Steering Lock System | Refer to HOW TO PROCEED WITH TROUBLESHOOTING |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Key system display malfunction | Smart Access System with Push-button Start (for Start Function) | Refer to HOW TO PROCEED WITH TROUBLESHOOTING |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Low oil pressure display malfunction | Oil Pressure Switch (for 2UR-GSE) | Refer to INSPECTION - Step 1 |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Low engine oil level display malfunction | Oil Level Sensor (for 2UR-GSE) | Refer to INSPECTION - Step 1 |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| High engine oil temperature display malfunction | Engine Oil Temperature Sensor (for 2UR-GSE) | Refer to INSPECTION |
| Wire Harness or Connector | ||
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Low washer fluid display malfunction | Washer Fluid Level Warning Switch | Refer to INSPECTION - Step 1 |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| Check PCS display malfunction (w/ Pre-collision System) | Pre-Collision System | Refer to PROBLEM SYMPTOMS TABLE |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| A/T fluid temperature warning display malfunction | Automatic Transmission System (for AA80E) | Refer to DIAGNOSTIC TROUBLE CODE CHART |
| Combination Meter | Refer to REMOVAL - Step 9 | |
| DTC (Diagnostic Trouble Code) display malfunction | Tire Pressure Warning ECU | Refer to HOW TO PROCEED WITH TROUBLESHOOTING |
| Combination Meter | Refer to REMOVAL - Step 9 |
MULTI-INFORMATION DISPLAY
Scheme 51
Scheme 52
Scheme 53
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
- COMBINATION METER Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J34-1 (E2) - Body ground W-B - Body ground Ground Always Below 1 V J34-2 (FE) - Body ground BR - Body ground Ground (Fuel ground) Always Below 1 V J34-3 (GND) - Body ground W - Body ground Ground (Engine oil temperature sensor ground) Always Below 1 V J34-4 (INT) - Body ground LG - Body ground Tire pressure select switch signal Engine switch on (IG), tire pressure select display ON 8 to 15 V Engine switch on (IG), tire pressure select display off Below 1.5 V J34-5 (+S) - Body ground P - Body ground Speed signal (Output) Wheel turned slowly Pulse generation (See waveform 1) J34-6 (MPX+) - Body ground BR - Body ground Multiplex communication signal Engine switch on (IG) Pulse generation J34-7 (GAGE) - Body ground L - Body ground Engine oil temperature sensor signal Engine switch on (IG), engine oil temperature is about 0°C (32°F) 4 to 6 V Engine switch on (IG), engine oil temperature is about 100°C (212°F) 0.5 to 2.5 V J34-8 (TC) - Body ground P - Body ground Light control rheostat signal Engine switch on (IG), the light control rheostat knob is at the MAX. position (turns fully clockwise) 4 to 6 V Engine switch on (IG), the light control rheostat knob is at the MIN. position (turns fully counterclockwise) Below 1 V J34-9 (ILL+) - Body ground V - Body ground Light control rheostat signal Engine switch on (IG), combination switch is except on OFF 4 to 6 V J34-11 (B) - Body ground G - Body ground Turn indicator light signal Engine switch on (IG), turn signal LH indicator light OFF Below 1 V Engine switch on (IG), turn signal LH indicator light blinks 11 to 14 V J34-12 (IG+) - Body ground BE - Body ground Engine switch signal Engine switch off Below 1 V Engine switch on (IG) 11 to 14 V J34-13 (ES) - Body ground W-B - Body ground Ground (Signal ground) Always Below 1 V J34-14 (ET) - Body ground Y - Body ground Ground (Rheostat ground) Always Below 1 V J34-15 (INT) - Body ground P - Body ground Tire pressure initial switch signal Engine switch on (IG), tire pressure initial message is displayed 8 to 15 V Engine switch on (IG), tire pressure initial message is not displayed Below 1.5 V J34-16 (S) - Body ground W - Body ground Tachometer signal Engine switch on (IG), engine idle speed Pulse generation (See waveform 2) J34-17 (SI) - Body ground V - Body ground Speed signal (Input) Engine switch on (IG), wheel turned slowly Pulse generation (See waveform 1) J34-18 (MPX-) - Body ground BR - Body ground Multiplex communication signal Engine switch on (IG) Pulse generation J34-19 (FR) - Body ground SB - Body ground Fuel signal Engine switch on (IG), fuel level is FULL Below 1 V Engine switch on (IG), fuel level is EMPTY 4 to 7 V J34-20 (MSSL) - Body ground Y - Body ground Steering pad switch signal Engine switch on (IG), DISP switch is not pressed 4 to 6 V Engine switch on (IG), DISP switch is pressed Below 1 V J34-21 (TR) - Body ground B - Body ground Light control rheostat signal Engine switch on (IG), the light control rheostat knob is at the MIN. position (turns fully counterclockwise). Below 1 V Engine switch on (IG), the light control rheostat knob is at the MAX. position (turns fully clockwise). 4 to 6 V J34-23 (B) - Body ground L - Body ground Battery Always 11 to 14 V J34-24 (B) - Body ground LG - Body ground Battery Always 11 to 14 V J35-3 (PBLT) - Body ground P - Body ground Front seat inner belt assembly (for passenger side) signal Sit in the front passenger seat, engine switch on (IG), front passenger side seat belt is unfastened 11 to 14 V Sit in the front passenger seat, engine switch on (IG), front passenger side seat belt is fastened Below 1 V J35-5 (RSEL) - Body ground GR - Body ground Satellite switch RH signal Engine switch on (IG), satellite switch RH is not pressed 11 to 14 V Engine switch on (IG), satellite switch RH is pressed Below 1 V J35-6 (LSEL) - Body ground BE - Body ground Satellite switch LH signal Engine switch on (IG), satellite switch LH is not pressed 11 to 14 V Engine switch on (IG), satellite switch LH is pressed Below 1 V J35-7 (SET) - Body ground V - Body ground Satellite switch ON/OFF signal Engine switch on (IG), satellite switch ON/OFF is not pressed 11 to 14 V Engine switch on (IG), satellite switch ON/OFF is pressed Below 1 V J35-9 (ILL-) - Body ground W - Body ground Illumination signal Engine switch on (IG) 11 to 14 V J35-10 (B) - Body ground R - Body ground Turn indicator light signal Engine switch on (IG), turn signal RH indicator light OFF Below 1 V Engine switch on (IG), turn signal RH indicator light blinks 11 to 14 V J35-12 (EFI) - Body ground SB - Body ground MIL (Check engine indicator light) signal Engine switch on (IG), MIL ON Below 1 V Engine switch on (IG), MIL OFF 11 to 14 V J35-15 (SW) - Body ground LG - Body ground Brake fluid level warning light signal Engine switch on (IG), brake warning light OFF 11 to 14 V Engine switch on (IG), brake warning light ON Below 1.5 V Waveform 1 (Reference) : Using an oscilloscope: OK: Item Condition Tool setting 5 V/DIV., 20 ms./DIV. Vehicle condition Driving at approx. 20 km/h (12 mph) HINT: When the system is functioning normally, one drive wheel revolution generates 4 pulses. As the vehicle speed increases, the width indicated by (A) in the illustration narrows. Waveform 2 (Reference): Using an oscilloscope: OK: Item Condition Tool setting 5 V/DIV., 10 ms./DIV. Vehicle condition Engine idle speed
- INTEGRATION CONTROL AND PANEL ASSEMBLY (w/o Navigation System) Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J54-3 (ILL+) - Body ground G - Body ground Illumination signal Combination switch OFF Below 1 V Combination switch Head 11 to 14 V J54-4 (IG+) - Body ground B - Body ground Engine switch signal Engine switch off Below 1 V Engine switch on (IG) 11 to 14 V J54-5 (ACC) - Body ground BE - Body ground Engine switch signal Engine switch off Below 1 V Engine switch on (IG) 11 to 14 V J54-8 (E) - Body ground W-B - Body ground Ground Always Below 1 V J54-10 (ILL-) - Body ground W - Body ground Illumination Signal Engine switch on (IG), combination switch Head, and light control rheostat position MAX. Pulse generation (See waveform) J54-14 (B) - Body ground LG - Body ground Battery Always 11 to 14 V Waveform (Reference) : Using an oscilloscope: OK: Item Condition Tool setting 5 V/DIV., 200 ms./DIV. Vehicle condition Engine switch on (IG), light control rheostat is in the MID. position.
- CLOCK ASSEMBLY (w/ Navigation System) Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition J98-3 (E) - Body ground W-B - Body ground Ground Always Below 1 V J98-5 (ILL+) - Body ground G - Body ground Illumination signal Combination switch OFF Below 1 V Combination switch Head 11 to 14 V J98-6 (ACC) - Body ground BE - Body ground Engine switch signal Engine switch off Below 1 V Engine switch on (IG) 11 to 14 V J98-7 (B) - Body ground LG - Body ground Battery Always 11 to 14 V J98-14 (ILL-) - Body ground W - Body ground Illumination signal Engine switch on (IG), combination switch Head, and light control rheostat position MAX. Pulse generation (See waveform) J98-15 (IG+) - Body ground B - Body ground Engine switch signal Engine switch off Below 1 V Engine switch on (IG) 11 to 14 V Waveform (Reference) : Using an oscilloscope: OK: Item Condition Tool setting 5 V/DIV., 200 ms./DIV. Vehicle condition Engine switch on (IG), light control rheostat is in the MID. position.
- COMBINATION METER INNER CIRCUIT Combination Meter Inner Circuit Terminal No. Wire Harness Side (Symbol) J34 1 Ground (E2) 2 Fuel Sender Gauge Assembly (Sub) (FE) 3 Engine Oil Temperature Sensor (GND) 4 Tire Pressure Warning ECU (INT) 5 Each part that uses speed signal (+S) 6 Multiplex Communication Line (MPX+) 7 Engine Oil Temperature Sensor (GAGE) 8 Light Control Rheostat (TC) 9 Light Control Rheostat (ILL+) 10 - 11 Turn Signal Flasher (B) 12 GAUGE Fuse (IG+) 13 Ground (ES) 14 Light Control Rheostat (ET) 15 Tire Pressure Warning ECU (INT) 16 ECM (S) 17 Skid Control ECU (SI) 18 Multiplex Communication Line (MPX-) 19 Fuel Sender Gauge Assembly (FR) 20 Steering Pad Switch (MSSL) 21 Light Control Rheostat (TR) 22 - 23 DOME Fuse (B) 24 MPX-B Fuse (B) J35 1 - 2 - 3 Clock Assembly (PBLT) 4 - 5 Satellite Switch (RSEL) 6 Satellite Switch (LSEL) 7 Satellite Switch (SET) 8 - 9 Illumination Parts (ILL-) 10 Turn Signal Flasher (B) 11 - 12 ECM (EFI) 13 - 14 - 15 Brake Fluid Level Warning Switch (SW) 16
