Engine Mechanical (service Information) Lexus IS F I

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. INSPECT ENGINE COOLANT
2. INSPECT ENGINE OIL
3. INSPECT BATTERY
4. INSPECT AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY Remove the air cleaner cap sub-assembly. Refer to «REMOVAL - Step 4»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information) . Remove the air filter element sub-assembly. Visually check that the air filter is not excessively damaged or oily. If necessary, replace the air filter. Install the air filter element sub-assembly. Install the air cleaner cap sub-assembly. Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information) .
5. CHECK V-RIBBED BELT See step 1
6. INSPECT V-RIBBED BELT TENSIONER ASSEMBLY Remove the V-ribbed belt. Refer to «REMOVAL»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information) . Check that nothing is caught in the tensioner by turning it clockwise and counterclockwise. If a malfunction exists, replace the tensioner. Install the V-ribbed belt. Refer to «INSTALLATION»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information) .
7. INSPECT IGNITION TIMING Warm up and stop the engine. HINT: A warmed up engine should have an engine coolant temperature of over 80°C (176°F), an engine oil temperature of 60°C (140°F), and the engine speed should be stabilized. When using the Techstream: Connect the Techstream to the DLC3. Start the engine and run it at idle. Turn the Techstream main switch on. Enter the following menus: Powertrain / Engine / Data List / IGN Advance. Standard ignition timing 8 to 18° BTDC at idle NOTE: Check the ignition timing with the cooling fans off. Turn off all electrical systems and the A/C. When checking the ignition timing, the transmission should be in neutral or park. HINT: Refer to the Techstream operator's manual for further details. Check that the ignition timing advances immediately when the engine speed is increased. Enter the following menus: Powertrain / Engine / Active Test / Connect the TC and TE1. Monitor IGN Advance. Perform the Active test. Standard ignition timing 8 to 12° BTDC at idle NOTE: When checking the ignition timing, the transmission should be in neutral or park. HINT: Refer to the Techstream operator's manual for further details. When not using the Techstream: Remove the V-bank cover sub-assembly See step 2 . Remove the cool air intake duct seal See step 3 . Remove the engine room side cover LH See step 4 . Connect the timing light tester probe to the ignition coil wire for No. 1 cylinder. NOTE: Use a timing light that detects primary signals. Using SST, connect terminals 13 (TC) and 4 (CG) of the DLC3. SST: 09843-18040 NOTE: Confirm the terminal numbers before connecting them. Connecting the wrong terminals can damage the engine. Check the ignition timing with the cooling fans off. Turn off all the electrical systems and the A/C. When checking the ignition timing, the transmission should be in neutral or park. Using a timing light, check the ignition timing. Standard ignition timing 8 to 12° BTDC at idle Remove SST from the DLC3. Check the ignition timing. Standard ignition timing 8 to 18° BTDC at idle Check that the ignition timing advances immediately when the engine speed is increased. Disconnect the timing light from the engine. Install the engine room side cover LH See step 93 . Install the cool air intake duct seal See step 94 . Install the V-bank cover sub-assembly See step 95 .
8. INSPECT ENGINE IDLE SPEED Warm up and stop the engine. HINT: A warmed up engine should have an engine coolant temperature of over 80°C (176°F), an engine oil temperature of 60°C (140°F), and the engine speed should be stabilized. When using the Techstream: Connect the Techstream to the DLC3. Start the engine and run it at idle. Turn the Techstream main switch on. Enter the following menus: Powertrain / Engine / Data List / Engine Speed. Standard idle speed 700 to 800 rpm NOTE: Check the idle speed with the cooling fans off. Turn off all the electrical systems and the A/C. When checking the idle speed, the transmission should be in neutral or park. HINT: Refer to the Techstream operator's manual for further details. If the idle speed is not as specified, check the air intake system. Refer to «ON-VEHICLE INSPECTION - Step 1»(/lexus/is-f/i-2007-2014/remont/mechanical/#intake-inspection) . When not using the Techstream: Using SST, connect a tachometer probe to terminal 9 (TAC) of the DLC3. SST: 09843-18040 NOTE: Confirm the terminal numbers before connecting them. Connecting the wrong terminals can damage the engine. Check the idle speed. Standard idle speed 700 to 800 rpm NOTE: Check the idle speed with the cooling fans off. Turn off all the electrical systems and the A/C. When checking the idle speed, the transmission should be in neutral or park. HINT: If the speed is not as specified, check the air intake system. Refer to «ON-VEHICLE INSPECTION - Step 1»(/lexus/is-f/i-2007-2014/remont/mechanical/#intake-inspection) .
9. INSPECT COMPRESSION Warm up and stop the engine. HINT: A warmed up engine should have an engine coolant temperature of over 80°C (176°F), an engine oil temperature of 60°C (140°F), and the engine speed should be stabilized. Disconnect the cable from the negative (-) battery terminal. Remove the air cleaner cap sub-assembly. Refer to «REMOVAL - Step 4»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information) . Remove the battery. Remove the 8 spark plugs. Refer to «REMOVAL»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information) . Disconnect the throttle body connector. Disconnect the 2 injector connectors as shown in the illustration. Disconnect the 4 injector connectors as shown in the illustration. Insert a compression gauge into the spark plug hole. Install the battery. Connect the cable to the negative (-) battery terminal. Fully open the throttle valve. Depress and hold the brake pedal, and turn the engine switch on (IG). Then check the compression pressure. Standard compression pressure 1400 kPa (14.0 kgf/cm 2 , 203 psi) or more Minimum pressure 980 kPa (10.0 kgf/cm 2 , 142 psi) Pressure difference 100 kPa (1.0 kgf/cm 2 , 14.5 psi) or less NOTE: The measurement must be done as quickly as possible. HINT: Always use a fully charged battery to obtain engine speed of 250 rpm or more. If the cylinder compression is low in one or more cylinders, pour a small amount of engine oil into the cylinder with low compression through its spark plug hole. Then inspect the cylinder compression pressure again. HINT: If adding oil helps boost the compression, it is likely that the piston rings and/or cylinder bore are worn or damaged. If pressure stays low, a valve may be stuck or seated improperly, or there may be leakage in the gasket. Disconnect the cable from the negative (-) battery terminal. Remove the battery. Connect the 4 injector connectors as shown in the illustration. Connect the 2 injector connectors as shown in the illustration. Connect the throttle body connector. Install the 8 spark plugs. Refer to «INSTALLATION»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information) . Install the battery. Install the air cleaner cap sub-assembly. Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information) . Connect the cable to the negative (-) battery terminal. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-diagnostics-introduction__dtc-check-clear) .
10. INSPECT CO/HC HINT: This check determines whether or not the idle CO/HC complies with regulations. Start the engine. Keep the engine speed at 2500 rpm for approximately 180 seconds. Insert the CO/HC meter testing probe at least 40 cm (1.3 ft) into the tailpipe during idle. Immediately check CO/HC concentration during idle and when running at 2500 rpm. HINT: When performing the 2 mode (with the engine idling/running at 2500 rpm) test, follow the measurement order determined by applicable local regulations. If the CO/HC concentration does not comply with the regulations, perform troubleshooting in the order given below. Check the A/F sensor and heated oxygen sensor operation. See the table below for possible causes, then inspect and correct the applicable causes if necessary. CO HC Symptom Cause Normal High Rough idle 1. Misfiring Incorrect timing Plugs are contaminated, shorted, or gaps are incorrect. 2. Leaky intake and exhaust valves 3. Leaky cylinder Low High Rough idle (Fluctuating HC reading) 1. Vacuum leaks PCV hose Intake manifold Throttle body 2. Lean mixture causing misfire High High Rough idle (Black smoke from exhaust) 1. Restricted air filter 2. Faulty SFI system Incorrect pressure Defective ECT sensor Faulty ECM Faulty injector Faulty throttle position sensor Faulty MAF sensor

Scheme 40

Scheme 41

Scheme 42

1. CHECK V-RIBBED BELT Check the belt for wear, cracks or other signs of damage. If any of the following defects is found, replace the V-ribbed belt. HINT: The belt is cracked. The belt is worn out to the extent that the cords are exposed. The belt has chunks missing from the ribs. Check that the belt fits properly in the ribbed grooves. HINT: Check by hand to confirm that the belt has not slipped out of the grooves on the bottom pulley. If it has slipped out, replace the V-ribbed belt. Install a new V-ribbed belt correctly.

Scheme 43

Scheme 44

Scheme 45

1. REMOVE COOL AIR INTAKE DUCT SEAL See step 3
2. REMOVE NO. 1 AIR CLEANER INLET See step 20
3. SEPARATE RADIATOR RESERVE TANK ASSEMBLY Remove the 2 bolts and separate the radiator reserve tank assembly.
4. REMOVE V-RIBBED BELT Rotate the V-ribbed belt tensioner pulley counterclockwise to loosen the V-ribbed belt tensioner. HINT: The pulley bolt for the V-ribbed belt tensioner is reverse threaded. While turning the V-ribbed belt tensioner counterclockwise, align the holes. Insert a bar of 5 mm (0.197 in.) into the holes to secure the V-ribbed belt tensioner in place. Remove the V-ribbed belt.

Scheme 46

1. INSTALL V-RIBBED BELT Install the V-ribbed belt as shown in the illustration. Rotate the V-ribbed belt tensioner pulley counterclockwise, and then remove the bar. NOTE: Check that the drive belt is properly set to each pulley. Check that the belt is properly positioned on each pulley. Start the engine and check that the belt turns smoothly and no abnormal noise occurs.
2. INSTALL RADIATOR RESERVE TANK ASSEMBLY Install the radiator reserve tank assembly with the 2 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf)
3. INSTALL NO. 1 AIR CLEANER INLET See step 91
4. INSTALL COOL AIR INTAKE DUCT SEAL See step 94

Scheme 47

1. INSPECT VALVE CLEARANCE Check for noise and vibration Check for valve noise or a rough idle. Judge whether the valve clearance needs to be adjusted. HINT: If the valve noise is too loud or the idle is rough, inspect the valve clearance. Refer to «ADJUSTMENT»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information) .

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

1. REMOVE FUEL PUMP ASSEMBLY (for Bank 1)
2. REMOVE FUEL PUMP ASSEMBLY (for Bank 2)
3. DISCONNECT WIRE HARNESS . Refer to «REMOVAL - Step 23»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
4. REMOVE IGNITION COIL ASSEMBLY . Refer to «REMOVAL - Step 12»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
5. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY LH (for Bank 1) See step 20
6. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY (for Bank 2) See step 21
7. REMOVE OIL REFLECTOR PLATE LH (for Bank 1) See step 45
8. REMOVE OIL REFLECTOR PLATE RH (for Bank 2) See step 49
9. REMOVE NO. 1 CYLINDER TO TDC/COMPRESSION Rotate the crankshaft clockwise to set the No. 1 cylinder to TDC compression by aligning the crankshaft pulley timing mark (notch) with the timing chain cover 0° position. Check that each timing mark is positioned as shown in the illustration. HINT: If the timing marks are not positioned as shown in the illustration, rotate the crankshaft 360° to align the timing marks.
10. INSPECT VALVE CLEARANCE Using a feeler gauge, measure the clearance between the indicated valve rocker arms and camshafts. Standard Valve Clearance (Cold) Item Specified Condition Intake 0.12 to 0.18 mm (0.00472 to 0.00709 in.) Exhaust 0.22 to 0.28 mm (0.00866 to 0.0110 in.) HINT: On this engine, valve clearance is measured between the valve rocker arms and the camshaft lobes. The shims used to adjust the valve clearance are located on the top of the valve stems. The valve clearance shown in the Standard Valve Clearance table is the clearance as measured between the cam lobe and valve rocker arm. Record any out-of-specification valve clearance measurements. They will be used later to determine the required replacement valve adjusting shim. Turn the crankshaft 1 revolution (360°) to set the No. 6 cylinder to TDC compression. Using a feeler gauge, measure the clearance between the indicated valve rocker arms and camshafts. Standard Valve Clearance (Cold) Item Specified Condition Intake 0.12 to 0.18 mm (0.00472 to 0.00709 in.) Exhaust 0.22 to 0.28 mm (0.00866 to 0.0110 in.) HINT: On this engine, valve clearance is measured between the valve rocker arms and the camshaft lobes. The shims used to adjust the valve clearance are located on the top of the valve stems. The valve clearance shown in the Standard Valve Clearance table is the clearance as measured between the cam lobe and valve rocker arm. Record any out-of-specification valve clearance measurements. They will be used later to determine the required replacement valve adjusting shim.
11. ADJUST VALVE CLEARANCE Remove the timing chain cover sub-assembly. Refer to «REMOVAL»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information) . Remove the camshaft. Refer to «REMOVAL»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information) . Raise the valve rocker arm above the shim being replaced, and remove the valve adjusting shim. NOTE: Be careful not to drop the adjusting shim into the cylinder head. To prevent damage, do not attempt to adjust valve clearance by tightening or loosening the valve rocker arm pivots. HINT: Arrange the removed parts in the correct order. Using a dial gauge, measure the thickness of the existing valve adjusting shim after removing it. HINT: Be careful not to measure at the valve adjusting shim center groove. Determine the replacement valve adjusting shim thickness according to the formula or charts below. Calculate the thickness of the replacement valve adjusting shim so that the valve clearance comes within the specified value. T2 Thickness of replacement shim T1 Thickness of existing shim A Measured valve clearance Valve clearance Intake T2 = T1 + (A - 0.15 mm (0.0059 in.)) x 1.8 Exhaust T2 = T1 + (A - 0.25 mm (0.0098 in.)) x 1.6 This example is provided only as a calculation example, based on the clearance adjustment of an intake valve. If non-metric units are being used, substitute those measurements for the values shown below. Step 1 - Determining the amount of excess clearance The specified clearance (0.15) is subtracted from the measured value (0.40), and the result is then multiplied by the rocker ratio compensation value (1.8). (Measured value - specification) x compensation value = amount of excess clearance (0.40 - 0.15) x 1.8 = 0.450 Step 2 - Using the existing valve adjusting shim to determine the required thickness of the replacement valve adjusting shim The amount of excess clearance (0.450) is added to the thickness of the existing valve adjusting shim (2.300). The resulting value is the ideal thickness of a replacement valve adjusting shim. Excess clearance + thickness of existing shim = thickness of ideal replacement shim 0.450 + 2.300 = 2.750 Step 3 - Select the valve adjusting shim closest to the thickness of the ideal replacement shim Compare the thickness of the available replacement valve adjusting shims to the ideal replacement shim and choose the shim that is the closest match. Closest replacement valve adjusting shim = 2.750 (Select a new No. 74 shim.) HINT: Select a replacement shim with a thickness as close to the calculated value as possible. Shims are available in 41 sizes in increments of 0.020 mm (0.0008 in.), from 2.000 mm (0.0787 in.) to 2.800 mm (0.1102 in.). To select a replacement valve adjusting shim, refer to the following Valve Adjusting Shim Selection Chart and New Shim Thickness tables. Intake valve clearance (Cold) 0.12 to 0.18 mm (0.00472 to 0.00709 in.) EXAMPLE: If the existing shim (installed shim) is 2.300 mm (0.0906 in.), and the measured clearance is 0.39 mm (0.0154 in.), then a new 2.740 mm (0.1079 in.) No. 74 shim should be used as a replacement for the existing shim. NEW SHIM THICKNESS MM (IN.) Shim No. Thickness Shim No. Thickness Shim No. Thickness 00 2.000 (0.0787) 28 2.280 (0.0898) 56 2.560 (0.1008) 02 2.020 (0.0795) 30 2.300 (0.0906) 58 2.580 (0.1016) 04 2.040 (0.0803) 32 2.320 (0.0913) 60 2.600 (0.1024) 06 2.060 (0.0811) 34 2.340 (0.0921) 62 2.620 (0.1031) 08 2.080 (0.0819) 36 2.360 (0.0929) 64 2.640 (0.1039) 10 2.100 (0.0827) 38 2.380 (0.0937) 66 2.660 (0.1047) 12 2.120 (0.0835) 40 2.400 (0.0945) 68 2.680 (0.1055) 14 2.140 (0.0843) 42 2.420 (0.0953) 70 2.700 (0.1063) 16 2.160 (0.0850) 44 2.440 (0.0961) 72 2.720 (0.1071) 18 2.180 (0.0858) 46 2.460 (0.0969) 74 2.740 (0.1079) 20 2.200 (0.0866) 48 2.480 (0.0976) 76 2.760 (0.1087) 22 2.220 (0.0874) 50 2.500 (0.0984) 78 2.780 (0.1094) 24 2.240 (0.0882) 52 2.520 (0.0992) 80 2.800 (0.1102) 26 2.260 (0.0890) 54 2.540 (0.1000) Exhaust valve clearance (Cold) 0.22 to 0.28 mm (0.00866 to 0.0110 in.) EXAMPLE: If the existing shim (installed shim) is 2.300 mm (0.0906 in.), and the measured clearance is 0.39 mm (0.0154 in.), then a new 2.520 mm (0.0992 in.) No. 52 shim should be used as a replacement for the existing shim. NEW SHIM THICKNESS MM (IN.) Shim No. Thickness Shim No. Thickness Shim No. Thickness 00 2.000 (0.0787) 28 2.280 (0.0898) 56 2.560 (0.1008) 02 2.020 (0.0795) 30 2.300 (0.0906) 58 2.580 (0.1016) 04 2.040 (0.0803) 32 2.320 (0.0913) 60 2.600 (0.1024) 06 2.060 (0.0811) 34 2.340 (0.0921) 62 2.620 (0.1031) 08 2.080 (0.0819) 36 2.360 (0.0929) 64 2.640 (0.1039) 10 2.100 (0.0827) 38 2.380 (0.0937) 66 2.660 (0.1047) 12 2.120 (0.0835) 40 2.400 (0.0945) 68 2.680 (0.1055) 14 2.140 (0.0843) 42 2.420 (0.0953) 70 2.700 (0.1063) 16 2.160 (0.0850) 44 2.440 (0.0961) 72 2.720 (0.1071) 18 2.180 (0.0858) 46 2.460 (0.0969) 74 2.740 (0.1079) 20 2.200 (0.0866) 48 2.480 (0.0976) 76 2.760 (0.1087) 22 2.220 (0.0874) 50 2.500 (0.0984) 78 2.780 (0.1094) 24 2.240 (0.0882) 52 2.520 (0.0992) 80 2.800 (0.1102) 26 2.260 (0.0890) 54 2.540 (0.1000) Install the camshaft. Refer to «INSTALLATION»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information) . Install the chain sub-assembly. Refer to «REASSEMBLY»(/lexus/is-f/i-2007-2014/remont/mechanical/#engine-mechanical-service-information) . Install the chain sub-assembly (for Bank 2). Install the No. 1 chain vibration damper (for Bank 2). Install the chain tensioner slipper (for Bank 2). Install the No. 1 chain tensioner assembly (for Bank 2). Install the chain sub-assembly (for Bank 1). Install the No. 1 chain vibration damper (for Bank 1). Install the chain tensioner slipper (for Bank 1). Install the No. 1 chain tensioner assembly (for Bank 1). Tighten the camshaft timing gear assembly. Inspect the valve clearance again. NOTE: Be sure to inspect the valve clearance with the chain cub-assembly installed. When rotating the camshaft without the chain sub-assembly installed, contact between the valves and pistons may occur. HINT: If the valve clearance is not as specified, readjust the valve clearance.
12. INSTALL OIL REFLECTOR PLATE LH (for Bank 1) See step 37
13. INSTALL OIL REFLECTOR PLATE RH (for Bank 2) See step 38
14. INSTALL CYLINDER HEAD COVER SUB-ASSEMBLY LH (for Bank 1) See step 49
15. INSTALL CYLINDER HEAD COVER SUB-ASSEMBLY (for Bank 2) See step 50
16. INSTALL IGNITION COIL ASSEMBLY . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
17. CONNECT WIRE HARNESS . Refer to «INSTALLATION - Step 37»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
18. INSTALL FUEL PUMP ASSEMBLY (for Bank 1)
19. INSTALL FUEL PUMP ASSEMBLY (for Bank 2)

Scheme 55

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

1. REMOVE TIMING CHAIN COVER SUB-ASSEMBLY
2. SET NO. 1 CYLINDER TO TDC/COMPRESSION See step 33
3. REMOVE NO. 1 CHAIN TENSIONER ASSEMBLY (for Bank 1) See step 34
4. REMOVE CHAIN TENSIONER SLIPPER (for Bank 1) See step 35
5. REMOVE NO. 1 CHAIN VIBRATION DAMPER (for Bank 1) See step 36
6. REMOVE CHAIN SUB-ASSEMBLY (for Bank 1) See step 37
7. REMOVE NO. 3 CHAIN TENSIONER ASSEMBLY See step 38
8. REMOVE NO. 1 CHAIN TENSIONER ASSEMBLY (for Bank 2) See step 39
9. REMOVE CHAIN TENSIONER SLIPPER (for Bank 2) See step 40
10. REMOVE NO. 1 CHAIN VIBRATION DAMPER (for Bank 2) See step 41
11. REMOVE CHAIN SUB-ASSEMBLY (for Bank 2) See step 42
12. REMOVE NO. 2 CHAIN TENSIONER ASSEMBLY See step 43
13. REMOVE OIL REFLECTOR PLATE LH (for Bank 1) See step 45
14. REMOVE CAMSHAFT BEARING CAP (for Bank 1) NOTE: When rotating the camshafts without the timing chains installed, be careful to ensure that the valves do not contact the pistons. If contact occurs between the valves and pistons, damage may result. Make sure that each knock pin of the camshafts is positioned as shown in the illustration. Uniformly loosen and remove the 20 bearing cap bolts in the sequence shown in the illustration. NOTE: Uniformly loosen the bolts while keeping the camshaft level. Remove the 8 bearing caps. NOTE: Arrange the removed parts in the correct order.
15. REMOVE NO. 3 CAMSHAFT Remove the No. 3 camshaft from the cylinder head sub-assembly.
16. REMOVE NO. 4 CAMSHAFT Remove the No. 4 camshaft from the cylinder head sub-assembly.
17. REMOVE OIL REFLECTOR PLATE RH (for Bank 2) See step 49
18. REMOVE CAMSHAFT BEARING CAP (for Bank 2) NOTE: When rotating the camshafts without the timing chains installed, be careful to ensure that the valves do not contact the pistons. If contact occurs between the valves and pistons, damage may result. Make sure that each knock pin of the camshafts is positioned as shown in the illustration. Uniformly loosen and remove the 20 bearing cap bolts in the sequence shown in the illustration. NOTE: Uniformly loosen the bolts while keeping the camshaft level. Remove the 8 bearing caps. NOTE: Arrange the removed parts in the correct order.
19. REMOVE CAMSHAFT Remove the camshaft from the cylinder head sub-assembly.
20. REMOVE NO. 2 CAMSHAFT Remove the No. 2 camshaft from the cylinder head sub-assembly.

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. INSTALL NO. 3 CAMSHAFT Apply a light coat of engine oil to the camshaft journals. Install the No. 3 camshaft to the cylinder head sub-assembly.
2. INSTALL NO. 4 CAMSHAFT Apply a light coat of engine oil to the camshaft journals. Install the No. 4 camshaft to the cylinder head sub-assembly.
3. INSTALL CAMSHAFT BEARING CAP (for Bank 1) NOTE: When rotating the camshafts without the timing chains installed, be careful to ensure that the valves do not contact the pistons. If contact occurs between the valves and pistons, damage may result. Make sure that each knock pin of the camshafts is positioned as shown in the illustration. Apply a light coat of engine oil to the camshaft housing and bearing caps. Confirm the marks and numbers on the camshaft bearing caps and place them in their proper positions and directions. Temporarily install the 20 bolts in the sequence shown in the illustration. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Tighten the 20 bolts in the sequence shown in the illustration. Torque: 19 N*m (190 kgf*cm, 14 ft.*lbf)
4. INSTALL CAMSHAFT Apply a light coat of engine oil to the camshaft journals. Install the camshaft to the cylinder head sub-assembly.
5. INSTALL NO. 2 CAMSHAFT Apply a light coat of engine oil to the camshaft journals. Install the No. 2 camshaft to the cylinder head sub-assembly.
6. INSTALL CAMSHAFT BEARING CAP (for Bank 2) NOTE: When rotating the camshafts without the timing chains installed, be careful to ensure that the valves do not contact the pistons. If contact occurs between the valves and pistons, damage may result. Make sure that each knock pin of the camshafts is positioned as shown in the illustration. Apply a light coat of engine oil to the camshaft housing and bearing caps. Confirm the marks and numbers on the camshaft bearing caps and place them in their proper positions and directions. Temporarily install the 20 bolts in the sequence shown in the illustration. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Tighten the 20 bolts in the sequence shown in the illustration. Torque: 19 N*m (190 kgf*cm, 14 ft.*lbf)
7. INSTALL NO. 2 CHAIN TENSIONER ASSEMBLY See step 23
8. INSTALL CHAIN SUB-ASSEMBLY (for Bank 2) See step 24
9. INSTALL NO. 1 CHAIN VIBRATION DAMPER (for Bank 2) See step 25
10. INSTALL CHAIN TENSIONER SLIPPER (for Bank 2) See step 26
11. INSTALL NO. 1 CHAIN TENSIONER ASSEMBLY (for Bank 2) See step 27
12. INSTALL NO. 3 CHAIN TENSIONER ASSEMBLY (for Bank 1) See step 28
13. INSTALL CHAIN SUB-ASSEMBLY (for Bank 1) See step 29
14. INSTALL NO. 1 CHAIN VIBRATION DAMPER (for Bank 1) See step 30
15. INSTALL CHAIN TENSIONER SLIPPER (for Bank 1) See step 31
16. INSTALL NO. 1 CHAIN TENSIONER ASSEMBLY (for Bank 1) See step 32
17. TIGHTEN CAMSHAFT TIMING GEAR ASSEMBLY See step 33
18. INSPECT NO. 1 CYLINDER TO TDC/COMPRESSION See step 34
19. INSPECT VALVE CLEARANCE See step 10
20. ADJUST VALVE CLEARANCE See step 11
21. INSTALL OIL REFLECTOR PLATE LH (for Bank 1) See step 37
22. INSTALL OIL REFLECTOR PLATE RH (for Bank 2) See step 38
23. INSTALL TIMING CHAIN COVER SUB-ASSEMBLY Refer to «INSTALLATION»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information) .

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

1. REMOVE ENGINE AND TRANSMISSION
2. REMOVE EXHAUST MANIFOLD SUB-ASSEMBLY RH
3. REMOVE EXHAUST MANIFOLD SUB-ASSEMBLY LH
4. REMOVE NO. 3 CAMSHAFT
5. REMOVE NO. 4 CAMSHAFT
6. REMOVE CAMSHAFT
7. REMOVE NO. 2 CAMSHAFT
8. REMOVE FUEL INJECTOR ASSEMBLY (for Direct Injection)
9. REMOVE NO. 1 VALVE ROCKER ARM SUB-ASSEMBLY See step 53
10. REMOVE CYLINDER HEAD SUB-ASSEMBLY (for Bank 1) Remove the 3 bolt sand camshaft housing. Uniformly loosen and remove the 2 bolts in the sequence shown in the illustration. Using a 10 mm bi-hexagon wrench, uniformly loosen the 10 bolts in the sequence shown in the illustration. Remove the 10 cylinder head bolts and plate washers. NOTE: Be careful not to drop washers into the cylinder head. Head warpage or cracking could result from removing the bolts in an incorrect order. HINT: Be sure to keep the removed parts separate for each installation position. Remove the cylinder head.
11. REMOVE NO. 2 CYLINDER HEAD GASKET (for Bank 1) Remove the No. 2 cylinder head gasket.
12. REMOVE CYLINDER HEAD SUB-ASSEMBLY (for Bank 2) Remove the 3 bolts and camshaft housing. Uniformly loosen and remove the 2 bolts in the sequence shown in the illustration. Using a 10 mm bi-hexagon wrench, uniformly loosen the 10 bolts in the sequence shown in the illustration. Remove the 10 cylinder head bolts and plate washers. NOTE: Be careful not to drop washers into the cylinder head. Head warpage or cracking could result from removing the bolts in an incorrect order. HINT: Be sure to keep the removed parts separate for each installation position. Remove the cylinder head.
13. REMOVE CYLINDER HEAD GASKET (for Bank 2) Remove the cylinder head gasket.

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

1. INSPECT CYLINDER HEAD SET BOLT See step 6
2. INSTALL NO. 2 CYLINDER HEAD GASKET (for Bank 1) Place a new No. 2 cylinder head gasket the cylinder block surface with the Lot No. stamp facing upward. NOTE: Be sure to place the gasket in the correct direction. Gently place the cylinder head on the cylinder block in order to prevent damaging the gasket.
3. INSTALL CYLINDER HEAD SUB-ASSEMBLY (for Bank 1) Place the cylinder head sub- assembly on the cylinder block. NOTE: Clean and degrease all contact surface. Inspect and clean each cylinder head bolt and installation hole. Apply a light coat of engine oil to the threads and under the heads of the cylinder head bolts. HINT: Tighten the cylinder head bolts in 3 progressive steps. Step 1: Using a 10 mm bi-hexagon wrench, install and uniformly tighten the 10 cylinder head bolts with the plate washers in several steps, in the sequence shown in the illustration. Torque: 36 N*m (367 kgf*cm, 27 ft.*lbf) Step 2: Mark each cylinder head bolt head with paint as shown in the illustration. Tighten the cylinder head bolts another 90° in the sequence shown in step 1. Step 3: Tighten the cylinder head bolts by an additional 90° in the sequence shown in step 1. Check that the painted marks are now facing rearward. Install the 2 bolts in the sequence shown in the illustration. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Place the camshaft housing on the cylinder head sub-assembly. Temporarily tighten the camshaft housing with the 3 bolt in the sequence shown in the illustration. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Fully tighten the 3 bolts in the sequence shown in the illustration. Torque: 24 N*m (245 kgf*cm, 18 ft.*lbf)
4. INSTALL CYLINDER HEAD GASKET (for Bank 2) Place a new cylinder head gasket onto the cylinder block surface with the Lot No. stamp facing upward. NOTE: Be sure to place the gasket in the correct direction. Gently place the cylinder head onto the cylinder block in order to prevent damaging the gasket.
5. INSTALL CYLINDER HEAD SUB-ASSEMBLY (for Bank 2) Place the cylinder head sub-assembly on the cylinder block. NOTE: Clean and degrease all contact surface. Inspect and clean each cylinder head bolt and installation hole. Apply a light coat of engine oil to the threads and under the heads of the cylinder head bolts. HINT: Tighten the cylinder head bolts in 3 progressive steps. Step 1: Using a 10 mm bi-hexagon wrench, install and uniformly tighten the 10 cylinder head bolts with the plate washers in several steps, in the sequence shown in the illustration. Torque: 36 N*m (367 kgf*cm, 27 ft.*lbf) Step 2: Mark each cylinder head bolt head with paint as shown in the illustration. Tighten the cylinder head bolts another 90° in the sequence shown in step 1. Step 3: Tighten the cylinder head bolts by an additional 90° in the sequence shown in step 1. Check that the painting marks are now facing rearward. Install the 2 cylinder head bolts in the sequence shown in the illustration. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Place the camshaft housing on the cylinder head sub-assembly. Temporarily tighten the camshaft housing with the 3 bolt in the sequence shown in the illustration. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Fully tighten the 3 bolts in the sequence shown in the illustration. Torque: 24 N*m (245 kgf*cm, 18 ft.*lbf)
6. INSTALL NO. 1 VALVE ROCKER ARM SUB-ASSEMBLY See step 15
7. INSTALL FUEL INJECTOR ASSEMBLY (for Direct Injection)
8. INSTALL NO. 3 CAMSHAFT
9. INSTALL NO. 4 CAMSHAFT
10. INSTALL CAMSHAFT
11. INSTALL NO. 2 CAMSHAFT
12. INSTALL EXHAUST MANIFOLD SUB-ASSEMBLY LH
13. INSTALL EXHAUST MANIFOLD SUB-ASSEMBLY RH
14. INSTALL ENGINE AND TRANSMISSION

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

1. REMOVE ENGINE UNDER COVER
2. REMOVE COOL AIR INTAKE DUCT SEAL See step 3
3. REMOVE NO. 1 AIR CLEANER INLET See step 20
4. SEPARATE RADIATOR RESERVE TANK ASSEMBLY See step 3
5. REMOVE V-RIBBED BELT See step 4
6. REMOVE CRANKSHAFT PULLEY Using SST, loosen the crankshaft pulley set bolt. SST: 09213-38010 SST: 09330-00021 HINT: Loosen the crankshaft pulley set bolt until 2 to 3 threads remain threaded to the crankshaft. Using the pulley set bolt and SST, remove the crankshaft pulley. SST: 09950-50013 09951-05010 09952-05010 09953-05010 09954-05031 HINT: Apply grease to the threads and tip of the SST center bolt.
7. REMOVE CRANKSHAFT TIMING GEAR KEY Remove the crankshaft timing gear key from the crankshaft.
8. REMOVE TIMING GEAR CASE OR TIMING CHAIN CASE OIL SEAL Using a knife, cut through the oil seal lip. Using a screwdriver with its tip taped, pry out the oil seal. NOTE: After removal, check the crankshaft for damage. If it is damaged, smooth the surface with 400-grit sandpaper.

Scheme 92

Scheme 93

1. INSTALL TIMING GEAR CASE OR TIMING CHAIN CASE OIL SEAL Using SST, tap in a new oil seal until its surface is flush with the timing chain case edge. SST: 09223-22010 SST: 09506-35010 NOTE: Keep the lip free from foreign matter. Do not tap on the oil seal at an angle. Do not install the oil seal excessively.
2. INSTALL CRANKSHAFT TIMING GEAR KEY Install the crankshaft timing gear key.
3. INSTALL CRANKSHAFT PULLEY Align the pulley set key with the key groove of the pulley, and slide on the pulley. Using SST, install the pulley bolt. SST: 09213-38010 SST: 09330-00021 Torque: 330 N*m (3365 kgf*cm, 243 ft.*lbf)
4. INSTALL V-RIBBED BELT See step 1
5. INSTALL RADIATOR RESERVE TANK ASSEMBLY See step 2
6. INSTALL NO. 1 AIR CLEANER INLET See step 91
7. INSTALL COOL AIR INTAKE DUCT SEAL See step 94
8. INSTALL ENGINE UNDER COVER

Scheme 94

Scheme 95

1. REMOVE AUTOMATIC TRANSMISSION ASSEMBLY
2. REMOVE DRIVE PLATE AND RING GEAR SUB-ASSEMBLY See step 84
3. REMOVE ENGINE REAR OIL SEAL Using a knife, cut through the oil seal lip. Using a screwdriver with its tip taped, pry out the oil seal. NOTE: After removal, check the crankshaft for damage. If it is damaged, smooth the surface with 400-grit sandpaper.

Scheme 96

1. INSTALL ENGINE REAR OIL SEAL Using SST, tap in a new engine rear oil seal until its surface is flush with the oil seal retainer edge. SST: 09223-15030 SST: 09950-70010 09951-07150 NOTE: Keep the lip free from foreign matter. Do not tap on the oil seal at an angle. Do not install the oil seal excessively.
2. INSTALL DRIVE PLATE AND RING GEAR SUB-ASSEMBLY See step 3
3. INSTALL AUTOMATIC TRANSMISSION ASSEMBLY

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

1. PRECAUTION
2. REMOVE V-BANK COVER SUB-ASSEMBLY Hold the front of the V-bank cover sub-assembly and raise it to disengage the 2 clips on the front of the cover. Continue to raise the cover to disengage the 2 clips on the rear of the cover and remove the V-bank cover sub-assembly. NOTE: Attempting to disengage both front and rear clips at the same time may cause the cover to break.
3. REMOVE COOL AIR INTAKE DUCT SEAL Remove the 9 clips and cool air intake duct seal.
4. REMOVE ENGINE ROOM SIDE COVER LH Remove the 5 clips and engine room side cover LH.
5. REMOVE ENGINE ROOM SIDE COVER RH Remove the 3 clips and engine room side cover RH.
6. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
7. DISCHARGE REFRIGERANT FROM REFRIGERATION SYSTEM . Refer to «REPLACEMENT - Step 1»(/lexus/is-f/i-2007-2014/remont/automatic-hvac-system/#air-conditioning-service-information)
8. DISCHARGE FUEL SYSTEM PRESSURE
9. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL . Refer to «REMOVAL - Step 3»(/lexus/is-f/i-2007-2014/remont/steering-column/#steering-column-service-information)
10. REMOVE FRONT WHEEL
11. REMOVE ENGINE UNDER COVER
12. REMOVE REAR ENGINE UNDER COVER LH
13. REMOVE REAR ENGINE UNDER COVER RH
14. REMOVE NO. 2 ENGINE UNDER COVER
15. REMOVE FRONT LOWER SUSPENSION MEMBER PROTECTOR . Refer to «REMOVAL - Step 7»(/lexus/is-f/i-2007-2014/remont/manual-power-steering/#steering-gear-linkage-service-information)
16. REMOVE ENGINE UNDER COVER AIR GUIDE BRACKET Remove the 2 bolts and engine under cover air guide bracket.
17. DRAIN ENGINE OIL . Refer to «REPLACEMENT - Step 1»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
18. DRAIN ENGINE COOLANT . Refer to «REPLACEMENT - Step 3»(/lexus/is-f/i-2007-2014/remont/cooling-fan/#cooling-service-information)
19. DRAIN AUTOMATIC TRANSMISSION FLUID . Refer to «REMOVAL - Step 3»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
20. REMOVE NO. 1 AIR CLEANER INLET Remove the bolt, clip and No. 1 air cleaner inlet.
21. REMOVE AIR CLEANER CAP SUB-ASSEMBLY . Refer to «REMOVAL - Step 4»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
22. REMOVE AIR CLEANER CASE SUB-ASSEMBLY Remove the 2 clamps and disconnect the vacuum hose. Remove the clamp and disconnect the vacuum switching valve connector. Remove the 2 bolts and air cleaner case sub-assembly.
23. DISCONNECT RESERVE TANK OUTLET HOSE Disconnect the reserve tank outlet hose.
24. DISCONNECT NO. 1 RADIATOR HOSE Disconnect the No. 1 radiator hose.
25. DISCONNECT NO. 2 RADIATOR HOSE Disconnect the No. 2 radiator hose.
26. DISCONNECT NO. 2 OIL COOLER INLET HOSE Disconnect the No. 2 oil cooler inlet hose.
27. DISCONNECT NO. 2 OIL COOLER OUTLET HOSE Disconnect the No. 2 oil cooler outlet hose.
28. DISCONNECT HEATER WATER HOSE INLET A Disconnect the heater inlet water hose A.
29. DISCONNECT HEATER WATER OUTLET HOSE A Disconnect the heater outlet water hose A.
30. DISCONNECT VACUUM HOSE ASSEMBLY Disconnect the vacuum hose assembly from the hose clamp. Disconnect the vacuum hose assembly from the intake air surge tank assembly.
31. DISCONNECT NO. 2 FUEL VAPOR FEED HOSE Disconnect the No. 2 fuel vapor feed hose.
32. DISCONNECT NO. 3 FUEL HOSE Remove the 2 fuel pipe clamps. Pinch the fuel tube connector and then pull out the No. 3 fuel hose. NOTE: Check for any dirt and foreign matter contamination in the pipe and around the connector. Clean if necessary. Foreign matter may damage the O-rings or cause leaks in the seal between the pipe and connector. Do not use any tools to separate the pipe and connector. Do not forcefully bend or twist the nylon tube. Check for any dirt and foreign matter on the pipe seal surface. Clean if necessary. Put the pipe and connector ends in plastic bags to prevent damage and dirt contamination. If the pipe and connector are stuck together, pinch the tube between your fingers and turn it carefully to free it. Then disconnect the hose.
33. DISCONNECT NO. 1 FUEL HOSE Remove the 2 fuel pipe clamps. Pinch the 2 fuel tube connector and then pull out the No. 1 fuel hose. NOTE: Check for any dirt and foreign matter contamination in the pipe and around the connector. Clean if necessary. Foreign matter may damage the O-rings or cause leaks in the seal between the pipe and connector. Do not use any tools to separate the pipe and connector. Do not forcefully bend or twist the nylon tube. Check for any dirt and foreign matter on the pipe seal surface. Clean if necessary. Put the pipe and connector ends in plastic bags to prevent damage and dirt contamination. If the pipe and connector are stuck together, pinch the tube between your fingers and turn it carefully to free it. Then disconnect the hose. Lift up the retainer to release its lock. Pinch the 2 fuel tube connectors and then pull out the No. 1 fuel hose. NOTE: Check for any dirt and foreign matter contamination in the pipe and around the connector. Clean if necessary. Foreign matter may damage the O-rings or cause leaks in the seal between the pipe and connector. Do not use any tools to separate the pipe and connector. Do not forcefully bend or twist the nylon tube. Check for any dirt and foreign matter on the pipe seal surface. Clean if necessary. Put the pipe and connector ends in plastic bags to prevent damage and dirt contamination. If the pipe and connector are stuck together, pinch the tube between your fingers and turn it carefully to free it. Then disconnect the hose.
34. DISCONNECT NO. 1 COOLER REFRIGERANT SUCTION HOSE . Refer to «REMOVAL - Step 8»(/lexus/is-f/i-2007-2014/remont/automatic-hvac-system/#air-conditioning-service-information)
35. DISCONNECT DISCHARGE HOSE SUB-ASSEMBLY . Refer to «REMOVAL - Step 9»(/lexus/is-f/i-2007-2014/remont/automatic-hvac-system/#air-conditioning-service-information)
36. REMOVE BATTERY . Refer to «REMOVAL - Step 7»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
37. REMOVE NO. 1 BATTERY TRAY SUPPORT
38. REMOVE POWER STEERING ECU ASSEMBLY . Refer to «REMOVAL - Step 3»(/lexus/is-f/i-2007-2014/remont/manual-power-steering/#power-steering-inspection)
39. REMOVE BATTERY TRAY . Refer to «REMOVAL - Step 10»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
40. REMOVE WIRE HARNESS CLAMP BRACKET . Refer to «REMOVAL - Step 11»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
41. REMOVE ENGINE ROOM ECU COVER . Refer to «REMOVAL - Step 5»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
42. DISCONNECT WIRE HARNESS Remove the 3 connectors and connector clamp. Detach the claw and disconnect the No. 4 connector holder. Disconnect the 5 connectors and grommet from the ECM box. Remove the nut, and disconnect the battery positive (+) cable and clamp from the battery. Remove the No. 1 engine room relay block cover. Remove the nut. Disconnect the clamp, detach the 2 claws and disconnect the wire harness from the No. 1 relay block. Remove the bolt and disconnect the ground cable. Remove the bolt, and disconnect the clamp and ground cable. Disconnect the power steering wire harness. Remove bolt (A) to disconnect the earth wire from the bracket. Remove the 2 clamps to disconnect the wire harness from the bracket. Disconnect 2 connectors (B) and (C) from the power steering link assembly. Release the lock of connector (D) and disconnect connector (D) from the power steering link assembly. Remove the bolt and disconnect the ground cable.
43. REMOVE NO. 2 FLOOR UNDER COVER . Refer to «REMOVAL - Step 1»(/lexus/is-f/i-2007-2014/remont/axle-shafts/#drive-shaft-service-information)
44. REMOVE NO. 1 FLOOR UNDER COVER . Refer to «REMOVAL - Step 2»(/lexus/is-f/i-2007-2014/remont/axle-shafts/#drive-shaft-service-information)
45. REMOVE TAIL EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 1»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
46. REMOVE REAR NO. 1 FLOOR PANEL BRACE . Refer to «REMOVAL - Step 5»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
47. REMOVE FRONT CENTER FLOOR BRACE . Refer to «REMOVAL - Step 6»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
48. DISCONNECT HEATED OXYGEN SENSOR . Refer to «REMOVAL - Step 7»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
49. REMOVE FRONT EXHAUST PIPE ASSEMBLY . Refer to «REMOVAL - Step 8»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
50. REMOVE FRONT NO. 1 FLOOR HEAT INSULATOR . Refer to «REMOVAL - Step 8»(/lexus/is-f/i-2007-2014/remont/axle-shafts/#drive-shaft-service-information)
51. REMOVE OUTSIDE AIR GUIDE PLATE RH . Refer to «REMOVAL - Step 9»(/lexus/is-f/i-2007-2014/remont/axle-shafts/#drive-shaft-service-information)
52. REMOVE PROPELLER SHAFT WITH CENTER BEARING ASSEMBLY . Refer to «REMOVAL - Step 10»(/lexus/is-f/i-2007-2014/remont/axle-shafts/#drive-shaft-service-information)
53. SEPARATE FRONT SHOCK ABSORBER ASSEMBLY LH . Refer to «REMOVAL - Step 10»(/lexus/is-f/i-2007-2014/remont/suspension-front/#front-suspension-service-information)
54. SEPARATE FRONT SHOCK ABSORBER ASSEMBLY RH HINT: Perform the same procedure for the LH side.
55. SEPARATE STEERING KNUCKLE LH . Refer to «REMOVAL - Step 8»(/lexus/is-f/i-2007-2014/remont/suspension-front/#front-suspension-service-information)
56. SEPARATE STEERING KNUCKLE RH HINT: Perform the same procedure for the LH side.
57. SEPARATE HEIGHT CONTROL SENSOR LINK SUB-ASSEMBLY . Refer to «REMOVAL - Step 5»(/lexus/is-f/i-2007-2014/remont/suspension-front/#front-suspension-service-information)
58. SEPARATE STEERING SLIDING YOKE SUB-ASSEMBLY . Refer to «REMOVAL - Step 8»(/lexus/is-f/i-2007-2014/remont/manual-power-steering/#steering-gear-linkage-service-information)
59. REMOVE STEERING COLUMN ASSEMBLY
60. DISCONNECT FLOOR SHIFT GEAR SHIFTING ROD SUB-ASSEMBLY . Refer to «REMOVAL - Step 13»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
61. REMOVE ENGINE AND TRANSMISSION Set the engine lifter. Remove the 4 bolts and disconnect the mounting member. Remove the 10 bolts and 2 nuts shown in the illustration. Operate the engine lifter to slowly remove the engine from the vehicle. NOTE: Make sure that the engine is clear of all wiring and hoses.
62. INSTALL ENGINE HANGER Install the 2 engine hangers with the 2 bolts as shown in the illustration. Engine Hanger Part No. Item Part No. Engine hanger 12081-38020 Bolt 90119-14120 Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf) Attach an engine sling device and hang the engine with a chain block. NOTE: When hanging the engine, make sure to hang the engine with the chains at an angle of 50° or less. Otherwise, the engine or engine hangers may be damaged.
63. REMOVE ENGINE OIL LEVEL DIPSTICK
64. REMOVE ENGINE OIL LEVEL DIPSTICK GUIDE . Refer to «REMOVAL - Step 3»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
65. REMOVE ENGINE UNDER COVER SUB-ASSEMBLY LH Remove the 2 clamps and engine under cover sub-assembly LH from the front suspension crossmember sub-assembly.
66. REMOVE ENGINE UNDER COVER SUB-ASSEMBLY RH Remove the 2 clamps and engine under cover sub-assembly RH from the front suspension crossmember sub-assembly.
67. REMOVE ENGINE MOUNTING DAMPER Remove the 2 bolts and 2 engine mounting dampers.
68. REMOVE NO. 1 EXHAUST MANIFOLD HEAT INSULATOR . Refer to «REMOVAL - Step 4»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
69. REMOVE EXHAUST MANIFOLD SUB-ASSEMBLY RH . Refer to «REMOVAL - Step 6»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
70. REMOVE NO. 2 EXHAUST MANIFOLD HEAT INSULATOR . Refer to «REMOVAL - Step 8»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
71. REMOVE EXHAUST MANIFOLD SUB-ASSEMBLY LH . Refer to «REMOVAL - Step 10»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
72. REMOVE NO. 3 EXHAUST MANIFOLD HEAT INSULATOR . Refer to «REMOVAL - Step 6»(/lexus/is-f/i-2007-2014/remont/starter/#starting-service-information)
73. REMOVE V-RIBBED BELT See step 4
74. SEPARATE BREATHER PLUG HOSE . Refer to «REMOVAL - Step 14»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
75. DISCONNECT WIRE HARNESS AND CONNECTORS . Refer to «REMOVAL - Step 15»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
76. REMOVE OIL COOLER TUBE Disconnect the wire harness clamp from the oil cooler tube. Remove the 2 bolts, nut, clamp and oil cooler tube.
77. REMOVE COMPRESSOR AND PULLEY Remove the 2 bolts and 2 nuts. Using an E8 "TORX" socket, remove the 2 stud bolts and compressor.
78. REMOVE GENERATOR ASSEMBLY . Refer to «REMOVAL - Step 15»(/lexus/is-f/i-2007-2014/remont/body-electrical/#charging-system-service-information)
79. REMOVE STARTER ASSEMBLY . Refer to «REMOVAL - Step 7»(/lexus/is-f/i-2007-2014/remont/starter/#starting-service-information)
80. REMOVE DRIVE PLATE AND TORQUE CONVERTER CLUTCH SETTING BOLT . Refer to «REMOVAL - Step 10»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
81. REMOVE AUTOMATIC TRANSMISSION ASSEMBLY . Refer to «REMOVAL - Step 16»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
82. REMOVE REAR ENGINE MOUNTING MEMBER Remove the 4 nuts and rear engine mounting member.
83. REMOVE REAR ENGINE MOUNTING INSULATOR ASSEMBLY . Refer to «REMOVAL - Step 12»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
84. REMOVE DRIVE PLATE AND RING GEAR SUB-ASSEMBLY Using SST, hold the crankshaft. SST: 09213-38010 SST: 09330-00021 Remove the 10 bolts, drive plate spacer RR, drive plate and ring gear sub-assembly and crankshaft angle sensor rotor.
85. REMOVE FRONT SUSPENSION CROSSMEMBER SUB-ASSEMBLY Remove the 2 nuts, then remove the front suspension crossmember sub-assembly from the engine.
86. REMOVE FRONT ENGINE MOUNTING INSULATOR Remove the 2 engine mounting spacers. Remove the 2 nuts and 2 front engine mounting insulators from the front suspension crossmember sub-assembly.

Scheme 152

Scheme 153

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

Scheme 162

Scheme 163

Scheme 164

Scheme 165

1. INSTALL FRONT ENGINE MOUNTING INSULATOR Install the 2 engine mounting insulators with the 2 nuts. Torque: 70 N*m (714 kgf*cm, 52 ft.*lbf) Install the 2 engine mounting spacers.
2. INSTALL FRONT SUSPENSION CROSSMEMBER SUB-ASSEMBLY Install the front suspension crossmember sub-assembly with the 2 nuts. Torque: 35 N*m (357 kgf*cm, 26 ft.*lbf)
3. INSTALL DRIVE PLATE AND RING GEAR SUB-ASSEMBLY Using SST, hold the crankshaft. SST: 09213-38010 SST: 09330-00021 Clean the 10 bolt holes. Install the crankshaft angle sensor rotor. HINT: Align the pin hole of the crankshaft angle sensor rotor with the pin of the crankshaft. Install the drive plate and ring gear sub-assembly and drive plate spacer RR on to the crankshaft. Uniformly install and tighten 10 new bolts in the sequence shown in the illustration. Torque: 30 N*m (301 kgf*cm, 22 ft.*lbf) NOTE: Do not reuse the drive plate and ring gear sub-assembly installation bolts. Do not impact or damage the drive plate and ring gear sub-assembly installation bolts. Be sure to handle them carefully. Mark the upside of each drive plate and ring gear sub-assembly installation bolt with paint. Retighten the drive plate and ring gear sub-assembly installation bolts 90° as shown in the illustration. Check that the painted marks are now at a 90° angle to the upside.
4. INSTALL REAR ENGINE MOUNTING INSULATOR ASSEMBLY . Refer to «INSTALLATION - Step 9»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
5. INSTALL REAR ENGINE MOUNTING MEMBER Install the rear engine mounting member to the automatic transmission assembly with the 4 nuts. Torque: 13 N*m (133 kgf*cm, 10 ft.*lbf)
6. INSTALL AUTOMATIC TRANSMISSION ASSEMBLY . Refer to «INSTALLATION - Step 5»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
7. INSTALL DRIVE PLATE AND TORQUE CONVERTER CLUTCH SETTING BOLT . Refer to «INSTALLATION - Step 11»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
8. INSTALL STARTER ASSEMBLY . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/starter/#starting-service-information)
9. INSTALL GENERATOR ASSEMBLY . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/body-electrical/#charging-system-service-information)
10. INSTALL COMPRESSOR AND PULLEY Using an E8 "TORX" socket, install the compressor and pulley with the 2 stud bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Install the compressor and pulley with the 2 bolts and 2 nuts. Torque: 25 N*m (255 kgf*cm, 18 ft.*lbf) HINT: Tighten the bolts and nuts in the order shown in the illustration to install the compressor.
11. INSTALL OIL COOLER TUBE Install the oil cooler tube with the 2 bolts and nut. Bolt Torque: 14 N*m (140 kgf*cm, 10 ft.*lbf) Nut Torque: 5.5 N*m (56 kgf*cm, 49 in.*lbf) Connect the wire harness clamp.
12. CONNECT WIRE HARNESS AND CONNECTORS . Refer to «INSTALLATION - Step 6»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
13. CONNECT BREATHER PLUG HOSE . Refer to «INSTALLATION - Step 7»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
14. INSTALL V-RIBBED BELT See step 1
15. INSTALL NO. 3 EXHAUST MANIFOLD HEAT INSULATOR . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/starter/#starting-service-information)
16. INSTALL EXHAUST MANIFOLD SUB-ASSEMBLY LH . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
17. INSTALL NO. 2 EXHAUST MANIFOLD HEAT INSULATOR . Refer to «INSTALLATION - Step 3»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
18. INSTALL EXHAUST MANIFOLD SUB-ASSEMBLY RH . Refer to «INSTALLATION - Step 5»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
19. INSTALL NO. 1 EXHAUST MANIFOLD HEAT INSULATOR . Refer to «INSTALLATION - Step 7»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
20. INSTALL ENGINE MOUNTING DAMPER Install the 2 engine mounting dampers with the 2 bolts. Torque: 11 N*m (112 kgf*cm, 8 ft.*lbf)
21. INSTALL ENGINE UNDER COVER SUB-ASSEMBLY LH Install the engine under cover sub-assembly LH to the front suspension crossmember sub-assembly with the 2 clamps.
22. INSTALL ENGINE UNDER COVER SUB-ASSEMBLY RH Install the engine under cover sub-assembly RH to the front suspension crossmember sub-assembly with the 2 clamps.
23. INSTALL ENGINE OIL LEVEL DIPSTICK GUIDE . Refer to «INSTALLATION - Step 8»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
24. INSTALL ENGINE OIL LEVEL DIPSTICK
25. INSTALL ENGINE AND TRANSMISSION Place the engine on an engine lifter. HINT: Place the engine on wooden blocks or equivalent so that the engine is level. Remove the 2 bolts and 2 engine hangers. Operate the engine lifter to install the engine into the vehicle. NOTE: Make sure that the engine is clear of all wiring and hoses. Install the 10 bolts and 2 nuts. Bolt A Torque: 204 N*m (2080 kgf*cm, 150 ft.*lbf) Bolt B Torque: 50 N*m (510 kgf*cm, 37 ft.*lbf) Bolt C Torque: 49 N*m (500 kgf*cm, 36 ft.*lbf) Nut Torque: 167 N*m (1703 kgf*cm, 123 ft.*lbf) Install the engine rear mounting member to the body with the 4 bolts. Torque: 26 N*m (260 kgf*cm, 19 ft.*lbf)
26. CONNECT FLOOR SHIFT GEAR SHIFTING ROD SUB-ASSEMBLY . Refer to «INSTALLATION - Step 3»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
27. INSTALL STEERING COLUMN ASSEMBLY
28. CONNECT STEERING SLIDING YOKE SUB-ASSEMBLY . Refer to «INSTALLATION - Step 4»(/lexus/is-f/i-2007-2014/remont/manual-power-steering/#steering-gear-linkage-service-information)
29. CONNECT HEIGHT CONTROL SENSOR LINK SUB-ASSEMBLY . Refer to «INSTALLATION - Step 9»(/lexus/is-f/i-2007-2014/remont/suspension-front/#front-suspension-service-information)
30. CONNECT STEERING KNUCKLE LH . Refer to «INSTALLATION - Step 4»(/lexus/is-f/i-2007-2014/remont/suspension-front/#front-suspension-service-information)
31. CONNECT STEERING KNUCKLE RH HINT: Perform the same procedure for the LH side.
32. TEMPORARILY TIGHTEN FRONT SHOCK ABSORBER ASSEMBLY LH . Refer to «INSTALLATION - Step 4»(/lexus/is-f/i-2007-2014/remont/suspension-front/#front-suspension-service-information)
33. TEMPORARILY TIGHTEN FRONT SHOCK ABSORBER ASSEMBLY RH HINT: Perform the same procedure for the LH side.
34. INSTALL PROPELLER SHAFT WITH CENTER BEARING ASSEMBLY . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/axle-shafts/#drive-shaft-service-information)
35. FULLY TIGHTEN NO. 1 CENTER SUPPORT BEARING ASSEMBLY . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/axle-shafts/#drive-shaft-service-information)
36. INSPECT AND ADJUST BOTH NO. 2 AND NO. 3 JOINT ANGLE . Refer to «INSTALLATION - Step 3»(/lexus/is-f/i-2007-2014/remont/axle-shafts/#drive-shaft-service-information)
37. INSTALL OUTSIDE AIR GUIDE PLATE RH . Refer to «INSTALLATION - Step 4»(/lexus/is-f/i-2007-2014/remont/axle-shafts/#drive-shaft-service-information)
38. INSTALL FRONT NO. 1 FLOOR HEAT INSULATOR . Refer to «INSTALLATION - Step 5»(/lexus/is-f/i-2007-2014/remont/axle-shafts/#drive-shaft-service-information)
39. INSTALL FRONT EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
40. CONNECT HEATED OXYGEN SENSOR . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
41. INSTALL FRONT CENTER FLOOR BRACE . Refer to «INSTALLATION - Step 3»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
42. INSTALL REAR NO. 1 FLOOR PANEL BRACE . Refer to «INSTALLATION - Step 4»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
43. INSTALL TAIL EXHAUST PIPE ASSEMBLY . Refer to «INSTALLATION - Step 8»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
44. INSTALL NO. 2 FLOOR UNDER COVER . Refer to «INSTALLATION - Step 11»(/lexus/is-f/i-2007-2014/remont/axle-shafts/#drive-shaft-service-information)
45. INSTALL NO. 1 FLOOR UNDER COVER . Refer to «INSTALLATION - Step 12»(/lexus/is-f/i-2007-2014/remont/axle-shafts/#drive-shaft-service-information)
46. CONNECT WIRE HARNESS Install the ground cable with the nut. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the power steering wire harness. Connect wire harness connector (D) to the power steering link assembly and securely lock the connector. Connect 2 wire harness connectors (B) and (C) to the power steering link assembly. Install the 2 wire harness clamps to the power steering link assembly. Connect the earth wire to the bracket with bolt (A). Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Connect the ground cable with the bolt and clamp. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Connect the ground cable with the bolt. Torque: 8.0 N*m (82 kgf*cm, 71 in.*lbf) Connect the wire to the engine room No. 1 junction block. Connect the clamp. Install the nut and connect the wire harness. Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf) Install the No. 1 engine room relay block cover. Connect the positive (+) battery cable with the nut and clamp. Torque: 13 N*m (130 kgf*cm, 9 ft.*lbf) Connect the 5 connectors and grommet to the ECM box. Connect the No. 4 connector holder. Connect the 3 connectors and connector clamp.
47. INSTALL ENGINE ROOM ECU COVER . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
48. INSTALL WIRE HARNESS CLAMP BRACKET . Refer to «INSTALLATION - Step 3»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
49. INSTALL BATTERY TRAY . Refer to «INSTALLATION - Step 4»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
50. INSTALL POWER STEERING ECU ASSEMBLY . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/manual-power-steering/#power-steering-inspection)
51. INSTALL NO. 1 BATTERY TRAY SUPPORT
52. INSTALL BATTERY . Refer to «INSTALLATION - Step 7»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
53. INSTALL DISCHARGE HOSE SUB-ASSEMBLY . Refer to «INSTALLATION - Step 3»(/lexus/is-f/i-2007-2014/remont/automatic-hvac-system/#air-conditioning-service-information)
54. INSTALL NO. 1 COOLER REFRIGERANT SUCTION HOSE . Refer to «INSTALLATION - Step 4»(/lexus/is-f/i-2007-2014/remont/automatic-hvac-system/#air-conditioning-service-information)
55. CONNECT NO. 1 FUEL HOSE Push in the fuel tube connector to the No. 1 fuel hose until the fuel tube connector makes a "click" sound. NOTE: Check that there is no damage or foreign objects on the fuel pipe connectors. After connecting, check that the fuel tube connector and the pipe are securely connected by pulling on them. Push in the fuel tube connector to the No. 1 fuel hose until the fuel tube connector makes a "click" sound. Push down on the retainer to lock it in place. NOTE: Check that there is no damage or foreign objects on the fuel pipe connectors. After connecting, check that the fuel tube connector and the pipe are securely connected by pulling on them. Install the 2 fuel pipe clamps.
56. CONNECT NO. 3 FUEL HOSE Push in the fuel tube connector to the No. 3 fuel hose until the fuel tube connector makes a "click" sound. NOTE: Check that there is no damage or foreign objects on the fuel pipe connectors. After connecting, check that the fuel tube connector and the pipe are securely connected by pulling on them. Install the 2 fuel pipe clamps.
57. INSTALL NO. 2 FUEL VAPOR FEED HOSE Connect the No. 2 fuel vapor feed hose.
58. CONNECT VACUUM HOSE ASSEMBLY Connect the vacuum hose assembly to the intake air surge tank assembly with the clamp. Connect the vacuum hose assembly to the hose clamp. NOTE: Align the vacuum hose matchmarks and the hose clamps as shown in the illustration.
59. INSTALL HEATER WATER OUTLET HOSE A Connect the heater water outlet hose A.
60. INSTALL HEATER WATER HOSE INLET A Connect the heater water inlet hose A.
61. CONNECT NO. 2 OIL COOLER OUTLET HOSE Connect the No. 2 oil cooler outlet hose with the clip.
62. CONNECT NO. 2 OIL COOLER INLET HOSE Connect the No. 2 oil cooler inlet hose with the clip.
63. CONNECT NO. 2 RADIATOR HOSE Connect the No. 2 radiator hose with the clamp.
64. CONNECT NO. 1 RADIATOR HOSE Connect the No. 1 radiator hose with the clamp.
65. CONNECT RESERVE TANK OUTLET HOSE Connect the reserve tank outlet hose with the clamp.
66. INSTALL AIR CLEANER CASE SUB-ASSEMBLY Install the air cleaner case sub-assembly with the 2 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) Connect the vacuum switching valve connector and clamp. Connect the vacuum hose and 2 clamps.
67. INSTALL AIR CLEANER CAP SUB-ASSEMBLY . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
68. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL . Refer to «INSTALLATION - Step 18»(/lexus/is-f/i-2007-2014/remont/steering-column/#steering-column-service-information)
69. ADD ENGINE OIL . Refer to «REPLACEMENT - Step 5»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
70. ADD ENGINE COOLANT . Refer to «REPLACEMENT - Step 4»(/lexus/is-f/i-2007-2014/remont/cooling-fan/#cooling-service-information)
71. ADD AUTOMATIC TRANSMISSION FLUID
72. CHARGE REFRIGERANT . Refer to «REPLACEMENT - Step 2»(/lexus/is-f/i-2007-2014/remont/automatic-hvac-system/#air-conditioning-service-information)
73. INSPECT FOR OIL LEAK
74. INSPECT FOR COOLANT LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(/lexus/is-f/i-2007-2014/remont/cooling-system-mechanical/#cooling-inspection)
75. INSPECT FOR FUEL LEAK . Refer to «ON-VEHICLE INSPECTION - Step 1»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-inspection)
76. INSPECT FOR EXHAUST GAS LEAK
77. INSTALL FRONT WHEEL
78. STABILIZE SUSPENSION . Refer to «INSTALLATION - Step 9»(/lexus/is-f/i-2007-2014/remont/suspension-front/#front-suspension-service-information)
79. FULLY TIGHTEN FRONT SHOCK ABSORBER ASSEMBLY LH . Refer to «INSTALLATION - Step 10»(/lexus/is-f/i-2007-2014/remont/suspension-front/#front-suspension-service-information)
80. FULLY TIGHTEN FRONT SHOCK ABSORBER ASSEMBLY RH HINT: Perform the same procedure for the LH side.
81. PLACE FRONT WHEELS FACING STRAIGHT AHEAD
82. CHECK AND ADJUST FRONT WHEEL ALIGNMENT
83. ADJUST SHIFT LEVER POSITION . Refer to «ADJUSTMENT - Step 1»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
84. INSPECT SHIFT LEVER POSITION . Refer to «ON-VEHICLE INSPECTION - Step 1»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
85. INSTALL ENGINE UNDER COVER AIR GUIDE BRACKET Install the engine under cover air guide bracket with the 2 bolts. Torque: 26 N*m (265 kgf*cm, 19 ft.*lbf)
86. INSTALL FRONT LOWER SUSPENSION MEMBER PROTECTOR . Refer to «INSTALLATION - Step 5»(/lexus/is-f/i-2007-2014/remont/manual-power-steering/#steering-gear-linkage-service-information)
87. INSTALL NO. 2 ENGINE UNDER COVER
88. INSTALL REAR ENGINE UNDER COVER RH
89. INSTALL REAR ENGINE UNDER COVER LH
90. INSTALL ENGINE UNDER COVER
91. INSTALL NO. 1 AIR CLEANER INLET Install the No. 1 air cleaner inlet with the bolt and clip. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf)
92. INSTALL ENGINE ROOM SIDE COVER RH Install the engine room side cover RH with the 3 clips.
93. INSTALL ENGINE ROOM SIDE COVER LH Install the engine room side cover LH with the 5 clips.
94. INSTALL COOL AIR INTAKE DUCT SEAL Install the cool air intake duct seal with the 9 clips.
95. INSTALL V-BANK COVER SUB-ASSEMBLY Engage the 4 clips to install the V-bank cover sub-assembly. NOTE: Be sure to engage the clips securely. Do not apply excessive force or hit the cover to engage the clips. This may cause the cover to break.
96. INSPECT IGNITION TIMING See step 7
97. INSPECT ENGINE IDLE SPEED See step 8
98. INSPECT CO/HC See step 10
99. CHECK AUTOMATIC TRANSMISSION SYSTEM PRECAUTION
100. VEHICLE PREPARATION FOR HEADLIGHT AIMING ADJUSTMENT . Refer to «ADJUSTMENT - Step 1»(/lexus/is-f/i-2007-2014/remont/exterior-lights/#lighting-exterior-service-information)
101. PREPARATION FOR HEADLIGHT AIMING (Using a headlight aim test machine) . Refer to «ADJUSTMENT - Step 2»(/lexus/is-f/i-2007-2014/remont/exterior-lights/#lighting-exterior-service-information)
102. PREPARATION FOR HEADLIGHT AIMING (Using a screen) . Refer to «ADJUSTMENT - Step 3»(/lexus/is-f/i-2007-2014/remont/exterior-lights/#lighting-exterior-service-information)
103. INSPECT HEADLIGHT AIMING . Refer to «ADJUSTMENT - Step 4»(/lexus/is-f/i-2007-2014/remont/exterior-lights/#lighting-exterior-service-information)
104. ADJUST HEADLIGHT AIMING . Refer to «ADJUSTMENT - Step 5»(/lexus/is-f/i-2007-2014/remont/exterior-lights/#lighting-exterior-service-information)

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

1. INSTALL ENGINE ON ENGINE STAND Install the engine onto an engine stand with the bolts.
2. REMOVE ENGINE HANGER Remove the 2 bolts and 2 engine hangers.
3. REMOVE ENGINE WIRE Remove the engine wire.
4. REMOVE FRONT NO. 1 ENGINE MOUNTING BRACKET RH Remove the 4 bolts and front No. 1 engine mounting bracket RH.
5. REMOVE FRONT NO. 1 ENGINE MOUNTING BRACKET LH Remove the 4 bolts and front No. 1 engine mounting bracket LH.
6. REMOVE WIRE HARNESS CLAMP BRACKET Remove the 2 bolts and 2 wire harness clamp brackets.
7. REMOVE TRANSMISSION BREATHER ASSEMBLY . Refer to «REMOVAL - Step 19»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
8. REMOVE THROTTLE BODY ASSEMBLY . Refer to «REMOVAL - Step 5»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
9. REMOVE INJECTOR DRIVER . Refer to «REMOVAL - Step 19»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
10. DISCONNECT WATER BY-PASS HOSE Slide the 3 clamps, and disconnect the water by-pass pipe hose, No. 3 water by-pass hose and No. 9 water by-pass hose from the water by-pass pipe sub-assembly.
11. REMOVE INTAKE AIR SURGE TANK ASSEMBLY . Refer to «REMOVAL - Step 24»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
12. REMOVE NO. 3 COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 7»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
13. REMOVE FUEL PRESSURE PULSATION DAMPER ASSEMBLY (for Direct Injection) . Refer to «REMOVAL - Step 8»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
14. REMOVE NO. 3 FUEL PIPE SUB-ASSEMBLY . Refer to «REMOVAL - Step 7»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
15. REMOVE NO. 2 FUEL PIPE SUB-ASSEMBLY . Refer to «REMOVAL - Step 8»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
16. REMOVE ENGINE COVER SUB-ASSEMBLY (for Bank 1) . Refer to «REMOVAL - Step 5»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
17. REMOVE ENGINE COVER SUB-ASSEMBLY (for Bank 2) . Refer to «REMOVAL - Step 6»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
18. REMOVE FUEL PUMP ASSEMBLY (for Bank 1) . Refer to «REMOVAL - Step 9»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
19. REMOVE FUEL PUMP ASSEMBLY (for Bank 2) . Refer to «REMOVAL - Step 10»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
20. REMOVE FUEL PUMP SPACER Remove the 2 fuel pimp spacers.
21. REMOVE NO. 1 ENGINE COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 11»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
22. REMOVE NO. 2 ENGINE COVER SUB-ASSEMBLY LH . Refer to «REMOVAL - Step 12»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
23. REMOVE NO. 4 FUEL PIPE SUB-ASSEMBLY . Refer to «REMOVAL - Step 13»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
24. REMOVE SEPARATOR CASE . Refer to «REMOVAL - Step 14»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
25. REMOVE NO. 2 FUEL DELIVERY PIPE (for Direct Injection) . Refer to «REMOVAL - Step 15»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
26. REMOVE FUEL DELIVERY PIPE (for Direct Injection) . Refer to «REMOVAL - Step 16»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
27. REMOVE FUEL INJECTOR ASSEMBLY (for Direct Injection) . Refer to «REMOVAL - Step 17»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
28. REMOVE FUEL INJECTOR SEAL . Refer to «REMOVAL - Step 18»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
29. REMOVE NO. 5 ENGINE WIRE Disconnect the 4 knock sensor connectors. Remove the 2 bolts and No. 5 engine wire.
30. REMOVE NO. 4 ENGINE COVER SUB-ASSEMBLY Remove the engine cover.
31. REMOVE NO. 2 IDLER PULLEY SUB-ASSEMBLY Remove the bolt and No. 2 idler pulley sub-assembly.
32. REMOVE OIL PUMP DRIVE SHAFT PULLEY . Refer to «REMOVAL - Step 33»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
33. REMOVE WATER PUMP PULLEY . Refer to «REMOVAL - Step 15»(/lexus/is-f/i-2007-2014/remont/cooling-fan/#cooling-service-information)
34. REMOVE INLET WATER HOUSING Remove the hose clamp and disconnect the water inlet hose. Remove the 3 bolts, inlet water housing and gasket.
35. REMOVE ENGINE OIL PRESSURE SWITCH ASSEMBLY Using a deep socket wrench (24 mm) remove the engine oil pressure switch assembly.
36. REMOVE OIL TEMPERATURE SENSOR . Refer to «REMOVAL - Step 2»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
37. REMOVE ENGINE OIL LEVEL SENSOR . Refer to «REMOVAL - Step 8»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
38. REMOVE NO. 2 WATER BY-PASS PIPE SUB-ASSEMBLY Remove the 3 hose clamps and disconnect the 3 water by-pass hoses. Remove the 4 bolts and No. 2 water by-pass pipe sub-assembly.
39. REMOVE E.F.I. ENGINE COOLANT TEMPERATURE SENSOR . Refer to «REMOVAL - Step 6»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
40. REMOVE KNOCK SENSOR . Refer to «REMOVAL - Step 8»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
41. REMOVE IGNITION COIL ASSEMBLY . Refer to «REMOVAL - Step 12»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
42. REMOVE NO. 4 V-BANK COVER BRACKET SUB-ASSEMBLY Remove the nut and No. 4 V-bank cover bracket sub-assembly.
43. REMOVE NO. 3 V-BANK COVER BRACKET SUB-ASSEMBLY Remove the bolt and No. 3 V-bank cover bracket sub-assembly.

Scheme 194

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

Scheme 201

Scheme 202

Scheme 203

Scheme 204

Scheme 205

Scheme 206

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Scheme 215

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221

Scheme 222

Scheme 223

Scheme 224

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

Scheme 231

Scheme 232

Scheme 233

Scheme 234

Scheme 235

Scheme 236

Scheme 237

Scheme 238

Scheme 239

Scheme 240

Scheme 241

Scheme 242

Scheme 243

Scheme 244

Scheme 245

Scheme 246

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

Scheme 252

Scheme 253

Scheme 254

Scheme 255

Scheme 256

1. REMOVE OIL FILLER CAP SUB-ASSEMBLY Remove the oil filler cap sub-assembly. Remove the oil filler cap gasket from the oil filler cap.
2. REMOVE OIL FILLER CAP HOUSING Remove the 2 bolts, oil filler cap housing and oil filler cap housing gasket.
3. REMOVE SPARK PLUG . Refer to «REMOVAL - Step 13»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
4. REMOVE OIL PAN DRAIN PLUG Remove the oil pan drain plug and gasket from the No. 2 oil pan.
5. REMOVE VVT SENSOR for Bank 1: Remove the 2 bolts and 2 VVT sensors. for Bank 2: Remove the 2 bolts and 2 VVT sensors.
6. REMOVE CAMSHAFT POSITION SENSOR Remove the bolt and camshaft position sensor.
7. REMOVE CRANKSHAFT POSITION SENSOR Remove the bolt and crankshaft position sensor.
8. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY LH Remove the bolt and camshaft timing oil control valve assembly LH. Remove the O-ring from the camshaft timing oil control valve assembly LH.
9. REMOVE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY RH Remove the bolt and camshaft timing oil control valve assembly RH. Remove the O-ring from the camshaft timing oil control valve assembly RH.
10. REMOVE CYLINDER BLOCK WATER DRAIN COCK SUB-ASSEMBLY Remove the 2 cylinder block water drain cock plugs from the cylinder block water drain cock sub-assembly. Remove the 2 cylinder block water drain cock sub-assembly from the cylinder block.
11. REMOVE CAMSHAFT TIMING CONTROL MOTOR ASSEMBLY LH (for Bank 1) Remove the 3 bolts and the camshaft timing control motor assembly LH. Remove the O-ring from the camshaft timing control motor assembly LH.
12. REMOVE CAMSHAFT TIMING CONTROL MOTOR ASSEMBLY RH (for Bank 2) Remove the 3 bolts and the camshaft timing control motor assembly RH. Remove the O-ring from the camshaft timing control motor assembly RH.
13. REMOVE FRONT WATER BY-PASS JOINT Remove the 4 nuts, front water by-pass joint and 2 gaskets.
14. REMOVE OIL FILTER ELEMENT Using a SST, temporarily loosen the oil filter cap by approximately 4 turns. SST: 09228-06501 HINT: Make sure that the oil filter cap ribs are vertical, this will allow the engine oil to drain from the gap between the oil filter cap and the housing. Remove the oil filter cap. Remove the oil filter element and O-ring from the oil filter cap. NOTE: Be sure to remove the O-ring (for the cap) by hand, without using any tools, to prevent damage to the groove for the O-ring on the cap.
15. REMOVE OIL COOLER ASSEMBLY Remove the bolt. Remove the union bolt, gasket and oil cooler assembly.
16. REMOVE OIL FILTER BRACKET Remove the 2 bolts and oil filter bracket stay. Remove the 2 bolts, 2 nuts and oil filter bracket. Remove the 2 gaskets from the timing chain cover sub-assembly.
17. REMOVE CRANKSHAFT PULLEY See step 6
18. REMOVE NO. 1 V-BANK COVER BRACKET (for Bank 1) Remove the No. 1 V-bank cover bracket from the cylinder head cover sub-assembly LH.
19. REMOVE NO. 1 V-BANK COVER BRACKET (for Bank 2) Remove the No. 1 V-bank cover bracket from the cylinder head cover sub-assembly.
20. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY LH (for Bank 1) Remove the fuel pump spacer gasket. Remove the 16 bolts, 3 seal washers, cylinder head cover sub-assembly LH and cylinder head cover gasket LH. HINT: Make sure that the removed parts are returned to the original places they were removed from. Remove the 2 oil hole gaskets and 2 O-rings from the camshaft bearing caps.
21. REMOVE CYLINDER HEAD COVER SUB-ASSEMBLY (for Bank 2) Remove the fuel pump spacer gasket. Remove the 16 bolts, 3 seal washers, cylinder head cover sub-assembly and cylinder head cover gasket. HINT: Make sure that the removed parts are returned to the original places they were removed from. Remove the 2 oil hole gaskets and 2 O-rings from the camshaft bearing caps.
22. REMOVE SPARK PLUG TUBE GASKET Using a screwdriver, pry out the 8 spark plug tube gaskets from the each cylinder head sub-assembly. HINT: Tape the screwdriver tip before use.
23. REMOVE OIL CONTROL VALVE FILTER for Bank 1: Remove the 2 bolts, cylinder head cover spacer LH, gasket and oil control valve filter. for Bank 2: Remove the 2 bolts, cylinder head cover spacer, gasket and oil control valve filter.
24. REMOVE V-RIBBED BELT TENSIONER ASSEMBLY Remove the standard bolt, 6 mm hexagon bolt and V-ribbed belt tensioner assembly.
25. REMOVE TIMING CHAIN COVER SUB-ASSEMBLY . Refer to «REMOVAL - Step 55»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
26. REMOVE INLET WATER PIPE . Refer to «REMOVAL - Step 56»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
27. REMOVE WATER PUMP ASSEMBLY Remove the 5 bolts, water pump assembly and water pump gasket from the timing chain cover sub-assembly.
28. REMOVE NO. 1 OIL PIPE . Refer to «REMOVAL - Step 2»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
29. REMOVE NO. 2 OIL PIPE . Refer to «REMOVAL - Step 3»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
30. REMOVE NO. 3 OIL PIPE . Refer to «REMOVAL - Step 4»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
31. REMOVE SCAVENGING PUMP ASSEMBLY . Refer to «REMOVAL - Step 5»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
32. REMOVE TIMING CHAIN CASE OIL SEAL Using screwdriver, remove the timing chain case oil seal. HINT: Tape the screwdriver tip before use.
33. SET NO. 1 CYLINDER TO TDC/COMPRESSION Temporarily tighten the crankshaft pulley set bolt. Rotate the crankshaft clockwise so that the timing marks on the crankshaft timing gear and camshaft timing gears are as shown in the illustration. HINT: If the timing marks do not align, rotate the crankshaft clockwise again and align the timing marks.
34. REMOVE NO. 1 CHAIN TENSIONER ASSEMBLY (for Bank 1) Move the stopper plate upward to release the lock, and fully push the plunger into the tensioner. Move the stopper plate downward to set the lock, and insert a 2 mm hexagon wrench into the stopper plate hole. Remove the 2 bolts and chain tensioner. Remove the chain tensioner gasket.
35. REMOVE CHAIN TENSIONER SLIPPER (for Bank 1) Remove the chain tensioner slipper.
36. REMOVE NO. 1 CHAIN VIBRATION DAMPER (for Bank 1) Remove the 2 bolts and chain vibration damper.
37. REMOVE CHAIN SUB-ASSEMBLY (for Bank 1) While pushing down the No. 3 chain tensioner, insert a 1.0 mm (0.0394 in.) pin into the hole to fix it in place. Hold the hexagonal portion of the camshaft with a wrench and loosen the bolt with a 12 mm hexagon wrench. NOTE: Be careful not to damage the cylinder head with the wrench. Do not disassemble the camshaft timing gear. Hold the hexagonal portion of the camshaft with a wrench and loosen the bolt. NOTE: Be careful not to damage the cylinder head with the wrench. Remove the 2 bolts. Then with the No. 1 chain sub-assembly and No. 2 chain sub-assembly still connected to the gears, remove the camshaft timing gear assembly, camshaft timing exhaust gear and crankshaft timing sprocket LH. Remove the No. 1 chain sub-assembly and No. 2 chain sub-assembly from the gears.
38. REMOVE NO. 3 CHAIN TENSIONER ASSEMBLY (for Bank 1) Remove the 2 bolts and No. 3 chain tensioner assembly.
39. REMOVE NO. 1 CHAIN TENSIONER ASSEMBLY (for Bank 2) Move the stopper plate upward to release the lock, and fully push the plunger into the tensioner. Move the stopper plate downward to set the lock, and insert a 2 mm hexagon wrench into the stopper plate hole. Remove the 2 bolts and No. 1 chain tensioner assembly.
40. REMOVE CHAIN TENSIONER SLIPPER (for Bank 2) Remove the chain tensioner slipper.
41. REMOVE NO. 1 CHAIN VIBRATION DAMPER (for Bank 2) Remove the 2 bolts and No. 1 chain vibration damper.
42. REMOVE CHAIN SUB-ASSEMBLY (for Bank 2) While raising up the No. 2 chain tensioner, insert a 1.0 mm (0.0394 in.) pin into the hole to fix it in place. Hold the hexagonal portion of the camshaft with a wrench and loosen the bolt with a 12 mm hexagon wrench. NOTE: Be careful not to damage the cylinder head with the wrench. Do not disassemble the camshaft timing gear. Hold the hexagonal portion of the camshaft with a wrench and loosen the bolt. NOTE: Be careful not to damage the cylinder head with the wrench. Remove the 2 bolts. Then with the No. 1 chain sub-assembly and No. 2 chain sub-assembly still connected to the gears, remove the camshaft timing gear assembly, camshaft timing exhaust gear and crankshaft timing gear. Remove the No. 1 chain sub-assembly and No. 2 chain sub-assembly from the gears.
43. REMOVE NO. 2 CHAIN TENSIONER ASSEMBLY (for Bank 2) Remove the 2 bolts and chain tensioner.
44. REMOVE CRANKSHAFT TIMING GEAR KEY Using a screwdriver, remove the 2 timing gear keys from the crankshaft.
45. REMOVE OIL REFLECTOR PLATE LH (for Bank 1) Remove the 2 bolts and oil reflector plate LH from the cylinder head assembly LH.
46. REMOVE CAMSHAFT BEARING CAP (for Bank 1) See step 14
47. REMOVE NO. 3 CAMSHAFT See step 15
48. REMOVE NO. 4 CAMSHAFT See step 16
49. REMOVE OIL REFLECTOR PLATE RH (for Bank 2) Remove the 2 bolts and oil reflector plate RH from the cylinder head assembly.
50. REMOVE CAMSHAFT BEARING CAP (for Bank 2) See step 18
51. REMOVE CAMSHAFT See step 19
52. REMOVE NO. 2 CAMSHAFT See step 20
53. REMOVE NO. 1 VALVE ROCKER ARM SUB-ASSEMBLY Remove the 32 No. 1 valve rocker arms from the cylinder heads. HINT: Arrange the removed parts in the correct order.
54. REMOVE VALVE ROCKER ARM PIVOT Remove the 32 valve rocker arm pivots from the cylinder head sub-assembly.
55. REMOVE CYLINDER HEAD SUB-ASSEMBLY (for Bank 1) See step 10
56. REMOVE NO. 2 CYLINDER HEAD GASKET (for Bank 1) See step 11
57. REMOVE CYLINDER HEAD SUB-ASSEMBLY (for Bank 2) See step 12
58. REMOVE CYLINDER HEAD GASKET (for Bank 2) See step 13
59. REMOVE CYLINDER BLOCK WATER JACKET SPACER Remove the 2 cylinder block water jacket spacers from the cylinder block. NOTE: Be sure to remove the cylinder block water jacket spacers. Otherwise, they may fall out and be damaged when the cylinder block is inverted.
60. REMOVE HEAT EXCHANGER ASSEMBLY Remove the bolt. Remove the 11 bolts and 2 nuts. Remove the heat exchanger assembly by prying between the heat exchanger assembly and cylinder block with a screwdriver. HINT: Tape the screwdriver tip before use.
61. REMOVE VENTILATION PIPE GASKET Using a screwdriver, pry out the ventilation pipe gasket. HINT: Tape the screwdriver tip before use.
62. REMOVE NO. 2 OIL PAN SUB-ASSEMBLY Remove the 15 bolts and 2 nuts. Insert the blade of an oil pan cutter between the oil pans. Cut through the applied sealer and remove the No. 2 oil pan sub-assembly. NOTE: Be careful not to damage the contact surfaces of the oil pans.
63. REMOVE OIL PAN SUB-ASSEMBLY Remove the 14 bolts and 2 nuts. HINT: Be sure to clean the bolts and stud bolts, and check the threads for cracks or other damage. Remove the oil pan sub-assembly by prying between the oil pan and cylinder block with a screwdriver. NOTE: Be careful not to damage the contact surfaces of the cylinder block and oil pan sub-assembly. HINT: Tape the screwdriver tip before use.
64. REMOVE NO. 1 OIL PAN BAFFLE PLATE Remove the 8 bolts and No. 1 oil pan baffle plate.
65. REMOVE OIL STRAINER SUB-ASSEMBLY Remove the 2 bolts, oil strainer sub-assembly and O-ring.
66. REMOVE ENGINE REAR OIL SEAL RETAINER Remove the 6 bolts. Using a screwdriver with its tip taped, pry out the engine rear oil seal retainer.
67. REMOVE OIL DRAIN PIPE SUB-ASSEMBLY Remove the bolt and oil drain pipe sub-assembly. Remove the O-ring.

Scheme 257

Scheme 258

Scheme 259

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Scheme 264

Scheme 265

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Scheme 277

Scheme 278

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

1. INSPECT CAMSHAFT TIMING EXHAUST GEAR ASSEMBLY Install the camshaft housing to the cylinder head sub-assembly LH (for Bank 1). Place the camshaft housing onto the cylinder head sub-assembly LH. Temporarily tighten the camshaft housing with the 3 bolts in the sequence shown in the illustration. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Fully tighten the 3 bolts in the sequence shown in the illustration. Torque: 24 N*m (245 kgf*cm, 18 ft.*lbf) Install the camshaft housing to the cylinder head sub-assembly (for Bank 2). Place the camshaft housing onto the cylinder head sub-assembly. Temporarily tighten the camshaft housing with the 3 bolts in the sequence shown in the illustration. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Fully tighten the 3 bolts in the sequence shown in the illustration. Torque: 24 N*m (245 kgf*cm, 18 ft.*lbf) Install the No. 4 camshaft. HINT: Only install the exhaust camshaft. Install the No. 2 camshaft. HINT: Only install the exhaust camshaft. Install the camshaft bearing cap See step 3 (for Bank 1). Install the camshaft bearing cap See step 6 (for Bank 2). Apply a light coat of engine oil to the camshaft and camshaft timing exhaust gear assembly. Align and insert the knock pin of the camshaft into the pin hole of the camshaft timing exhaust gear assembly. NOTE: Do not forcefully push in the camshaft timing exhaust gear assembly. This may cause the camshaft knock pin tip to damage the camshaft timing exhaust gear assembly. Be sure not to remove the other 4 bolts. If removed, replace the camshaft timing exhaust gear assembly. Apply a light coat of engine oil to the threads and under the head of the bolt. Using a wrench to hold the hexagonal portion of the camshaft, install the camshaft timing exhaust gear assembly with the bolt. Torque: 100 N*m (1020 kgf*cm, 74 ft.*lbf) Remove the camshaft bearing cap See step 14 . (for Bank 1) Remove the camshaft bearing cap See step 18 . (for Bank 2) Check the lock of the camshaft timing exhaust gear assembly. Make sure that the camshaft timing exhaust gear assembly is locked. Release the lock pin. Cover the 4 oil paths of the cam journal with vinyl tape as shown in the illustration. Prick a hole in the tape placed on the advance side path. Prick a hole in the tape placed on the retard side path on the opposite side to that of the advance side path, as shown in the illustration. Apply approximately 200 kPa (2.0 kgf/cm 2 , 28 psi) of air pressure to the 2 broken paths (the advance side path and the retard side path). WARNING: Cover the paths with a piece of cloth when applying pressure to keep oil from splashing. Check that the camshaft timing exhaust gear assembly rotates in the retard direction when reducing the air pressure applied to the advance side path. HINT: This operation releases the lock pin for the most retarded position. When the camshaft timing exhaust gear assembly reaches the most retarded position, release the air pressure from the advance side path and retard side path, in that order. NOTE: Do not release the air pressure from the retard side path first. The gear may abruptly shift in the advance direction and break the lock pin. Check for smooth rotation. Turn the camshaft timing exhaust gear assembly within its movable range (21°) 2 or 3 times, but do not turn it to the most advanced position. Make sure that the gear turns smoothly. NOTE: Do not use air pressure to check for smooth rotation. Check the lock in the most advanced position. Confirm that the camshaft timing exhaust gear assembly is locked at the most advanced position. Install the No. 4 camshaft. HINT: Only install the exhaust camshaft. Install the No. 2 camshaft. HINT: Only install the exhaust camshaft. Install the camshaft bearing cap See step 3 (for Bank 1). Install the camshaft bearing cap See step 6 (for Bank 2). Hold the hexagonal portion of the camshaft with a wrench and loosen the bolt. Remove the camshaft bearing cap See step 14 (for Bank 1). Remove the camshaft bearing cap See step 18 (for Bank 2). Remove the flange bolt and camshaft timing exhaust gear assembly. NOTE: Be sure not to remove the other 4 bolts. Remove the camshaft housing from the cylinder head sub-assembly LH. (for Bank 1) Remove the 3 bolt and camshaft housing from the cylinder head sub-assembly LH. Remove the camshaft housing from the cylinder head sub-assembly. (for Bank 2) Remove the 3 bolt and camshaft housing from the cylinder head sub-assembly.
2. INSPECT NO. 1 VALVE ROCKER ARM SUB-ASSEMBLY Turn the roller by hand to check that it turns smoothly. If the roller does not turn smoothly, replace the No. 1 valve rocker arm sub-assembly.
3. INSPECT CAMSHAFT Inspect the camshaft for runout. Place the camshaft on V-blocks. Using a dial indicator, measure the circle runout at the center journal. Maximum circle runout 0.04 mm (0.00157 in.) If the circle runout is greater than the maximum, replace the camshaft. HINT: Check the oil clearance after replacing the camshaft. Using a micrometer, measure the cam lobe height. Standard Cam Lobe Height Item Specified Condition Intake 44.953 to 45.103 mm (1.7698 to 1.7757 in.) Exhaust 44.576 to 44.726 mm (1.7549 to 1.7609 in.) Minimum Cam Lobe Height Item Specified Condition Intake 44.903 mm (1.7678 in.) Exhaust 44.526 mm (1.7530 in.) If the cam lobe height is less than the minimum, replace the camshaft. Using a micrometer, measure the journal diameter. Standard Journal Diameter Item Specified Condition No. 1 journal 29.956 to 29.970 mm (1.1794 to 1.1799 in.) Other journal 25.959 to 25.975 mm (1.0220 to 1.0226 in.) If the journal diameter is not as specified, check the oil clearance.
4. INSPECT CAMSHAFT OIL CLEARANCE Clean the bearing caps, camshaft housing and camshaft journals. Install the camshaft housing onto the cylinder head sub-assembly LH (for Bank 1). Place the camshaft housing to the cylinder head sub-assembly LH. Temporarily tighten the camshaft housing with the 3 bolt in the sequence shown in the illustration. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Fully tighten the 3 bolts in the sequence shown in the illustration. Torque: 24 N*m (245 kgf*cm, 18 ft.*lbf) Install the camshaft housing to the cylinder head sub-assembly (for bank 2). Place the camshaft housing onto the cylinder head sub-assembly. Temporarily tighten the camshaft housing with the 3 bolt in the sequence shown in the illustration. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Fully tighten the 3 bolts in the sequence shown in the illustration. Torque: 24 N*m (245 kgf*cm, 18 ft.*lbf) Place the camshafts on the cylinder heads. Lay a strip of Plastigage across each of the camshaft journals. Install the camshaft bearing cap See step 18 (for Bank 1). NOTE: Do not turn the camshaft. Install the camshaft bearing cap See step 21 (for Bank 2). NOTE: Do not turn the camshaft. Remove the camshaft bearing cap See step 46 (for Bank 1). Remove the camshaft bearing cap See step 50 (for Bank 2). Measure the Plastigage at its widest point. Standard Oil Clearance Item Specified Condition No. 1 journal 0.030 to 0.069 mm (0.00118 to 0.00272 in.) Other journal 0.025 to 0.062 mm (0.000984 to 0.00244 in.) Maximum Oil Clearance Item Specified Condition No. 1 journal 0.09 mm (0.00354 in.) Other journal 0.09 mm (0.00354 in.) If the oil clearance is greater than the maximum, replace the camshaft. If necessary, replace the cylinder head sub-assembly. Remove the camshafts from the cylinder heads. Remove the camshaft housing from the cylinder head sub-assembly LH. (for Bank 1) Remove the 3 bolt and camshaft housing from the cylinder head sub-assembly LH. Remove the camshaft housing from the cylinder head sub-assembly. (for Bank 2) Remove the 3 bolt and camshaft housing from the cylinder head sub-assembly.
5. INSPECT CAMSHAFT TIMING GEAR ASSEMBLY Using a vernier caliper, measure the width of the camshaft timing gear assembly's eccentric shaft cutout. Standard width 5.9 to 6.2 mm (0.232 to 0.244 in.) Maximum width 6.7 mm (0.264 in.) If the result is greater than the maximum value, replace the camshaft timing gear assembly. Rotate the keyway part of the camshaft timing gear assembly's eccentric shaft by hand. Standard Rotates smoothly If the result is not as specified, replace the camshaft timing gear assembly. NOTE: Do not drop the camshaft timing gear assembly. If dropped, replace it. Do not disassemble the camshaft timing gear assembly. If disassembled, replace it.
6. INSPECT CYLINDER HEAD SET BOLT Using a vernier caliper, measure the minimum diameter of the elongated thread at the measuring point. Standard outside diameter 10.85 to 11.00 mm (0.427 to 0.433 in.) Minimum outside diameter 10.6 mm (0.417 in.) Measuring point 90 mm (3.54 in.) for intake side bolt 85 mm (3.35 in.) for exhaust side bolt HINT: If a visual check shows no excessively thin areas, check the center of the bolt (see illustration) and find the area that has the smallest diameter. If the diameter is less than the minimum, replace the cylinder head bolt.
7. INSPECT NO. 1 CHAIN SUB-ASSEMBLY Using a spring scale, pull the No. 1 chain sub-assembly with a force of 147 N (15 kgf, 33 lbf) as shown in the illustration. Using a vernier caliper, measure the length of 15 pins. Maximum chain elongation 136.9 mm (5.39 in.) If the elongation is greater than the maximum, replace the No. 1 chain sub-assembly. NOTE: Perform the measurement at 3 random places.
8. INSPECT NO. 2 CHAIN SUB-ASSEMBLY Using a spring scale, pull the No. 2 chain sub-assembly with a force of 147 N (15 kgf, 33 lbf) as shown in the illustration. Using a vernier caliper, measure the length of 15 pins. Maximum chain elongation 137.6 mm (5.42 in.) If the elongation is greater than the maximum, replace the No. 2 chain sub-assembly. NOTE: Perform the measurement at 3 random places.
9. INSPECT CRANKSHAFT TIMING GEAR Wrap the No. 1 chain sub-assembly around the sprocket. Using a vernier caliper, measure the sprocket diameter with the No. 1 chain sub-assembly. Minimum sprocket diameter (w/ chain sub-assembly) 61.4 mm (2.42 in.) HINT: The vernier caliper must contact the No. 1 chain sub-assembly rollers for the measurement. If the diameter is less than the minimum, replace the No. 1 chain sub-assembly and crankshaft timing gear.
10. INSPECT CRANKSHAFT TIMING SPROCKET LH Wrap the No. 1 chain sub-assembly around the crankshaft timing sprocket LH. Using a vernier caliper, measure the crankshaft timing sprocket LH diameter with the No. 1 chain sub-assembly. Minimum crankshaft timing sprocket LH diameter (w/ No. 1 chain sub-assembly) 61.4 mm (2.42 in.) NOTE: The vernier caliper must contact the No. 1 chain sub-assembly rollers for the measurement. If the diameter is less than the minimum, replace the No. 1 chain sub-assembly and crankshaft timing sprocket LH.
11. INSPECT NO. 1 CHAIN TENSIONER ASSEMBLY Move the stopper plate upward to release the lock. Push the plunger and check that it moves smoothly. If necessary, replace the No. 1 chain tensioner assembly.
12. INSPECT NO. 2 CHAIN TENSIONER ASSEMBLY Check that the plunger moves smoothly. Measure the worn depth of the No. 2 chain tensioner assembly. Maximum depth 0.9 mm (0.0354 in.) If the depth is greater than the maximum, replace the No. 2 chain tensioner assembly.
13. INSPECT NO. 3 CHAIN TENSIONER ASSEMBLY Check that the plunger moves smoothly. Measure the worn depth of the No. 3 chain tensioner assembly. Maximum depth 0.9 mm (0.0354 in.) If the depth is greater than the maximum, replace the No. 3 chain tensioner assembly.
14. INSPECT CHAIN TENSIONER SLIPPER for Bank 1: Measure the worn depth of the chain tensioner slipper. Maximum depth 1.0 mm (0.0394 in.) If the depth is greater than the maximum, replace the chain tensioner slipper. for Bank 2: Measure the worn depth of the chain tensioner slipper. Maximum depth 1.0 mm (0.0394 in.) If the depth is greater than the maximum, replace the chain tensioner slipper.
15. INSPECT NO. 1 CHAIN VIBRATION DAMPER for Bank 1: Measure the worn depth of the No. 1 chain vibration damper. Maximum depth 1.0 mm (0.0394 in.) If the depth is greater than the maximum, replace the No. 1 chain vibration damper. for Bank 2: Measure the worn depth of the No. 1 chain vibration damper. Maximum depth 1.0 mm (0.0394 in.) If the depth is greater than the maximum, replace the No. 1 chain vibration damper.
16. INSPECT CYLINDER HEAD SUB-ASSEMBLY See step 1
17. INSPECT EXHAUST MANIFOLD SUB-ASSEMBLY LH Using a precision straightedge and feeler gauge, measure the warpage of the surface that contacts the cylinder head sub-assembly LH. Maximum warpage 0.5 mm (0.0197 in.) If the warpage is greater than the maximum, replace the exhaust manifold sub-assembly LH.
18. INSPECT EXHAUST MANIFOLD SUB-ASSEMBLY RH Using a precision straightedge and feeler gauge, measure the warpage of the surface that contacts the cylinder head sub-assembly. Maximum warpage 0.5 mm (0.0197 in.) If the warpage is greater than the maximum, replace the exhaust manifold sub-assembly RH.

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

1. REPLACE TIMING CHAIN COVER STRAIGHT PIN Remove the 4 straight pins. Using a plastic-faced hammer, tap in new straight pins to the timing chain cover sub-assembly. Standard protrusion 5.5 to 6.5 mm (0.217 to 0.256 in.)
2. REPLACE TIMING CHAIN COVER RING PIN Remove the 4 ring pins. Using a plastic-faced hammer, tap in new ring pins to the timing chain cover sub-assembly. Standard Protrusion Item Specified Condition Ring pin A 7.5 to 8.5 mm (0.295 to 0.335 in.) Ring pin B 3.6 to 4.6 mm (0.142 to 0.181 in.)
3. REPLACE OIL PAN STUD BOLT Using an E6 "TORX" socket wrench, install the 2 stud bolts as shown in the illustration. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf)
4. REPLACE ENGINE REAR OIL SEAL Place the oil seal retainer on wooden blocks. Using a screwdriver and hammer, tap out the oil seal. Using SST, tap in a new oil seal until its surface is flush with the oil seal retainer edge. SST: 09223-15030 SST: 09950-70010 09951-07100 NOTE: Keep the lip free from foreign matter. Do not tap on the oil seal at an angle.

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

Scheme 294

Scheme 295

Scheme 296

Scheme 297

Scheme 298

Scheme 299

Scheme 300

Scheme 301

Scheme 302

Scheme 303

Scheme 304

Scheme 305

Scheme 306

Scheme 307

Scheme 308

Scheme 309

Scheme 310

Scheme 311

Scheme 312

Scheme 313

Scheme 314

Scheme 315

Scheme 316

Scheme 317

Scheme 318

Scheme 319

Scheme 320

Scheme 321

Scheme 322

Scheme 323

Scheme 324

Scheme 325

Scheme 326

Scheme 327

1. INSTALL OIL DRAIN PIPE SUB-ASSEMBLY Apply a light coat of engine oil to a new O-ring. Install the new O-ring to the oil drain pipe sub-assembly. Install the oil drain pipe sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
2. INSTALL ENGINE REAR OIL SEAL RETAINER Apply seal packing in a continuous line as shown in the illustration. Seal packing Toyota Genuine Seal Packing Black, Three Bond 1207B or equivalent Seal diameter 2.0 to 3.0 mm (0.0787 to 0.118 in.) Application position from inside edge of retainer 3.5 mm (0.138 in.) NOTE: Remove any oil from the contact surface. Install the oil pan within 3 minutes and tighten the bolts and nuts within 15 minutes after applying seal packing. Do not start the engine for at least 2 hours after installing the oil seal retainer. When installing the engine rear oil seal retainer, make sure that the lip of the oil seal is not damaged. When installing the engine rear oil seal retainer, make sure that the lip of the oil seal is folded correctly. Install the engine rear oil seal retainer with the 6 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
3. INSTALL OIL STRAINER SUB-ASSEMBLY Apply a light coat of engine oil to a new O-ring. Install the new O-ring to the oil strainer sub-assembly. Install the oil strainer sub-assembly with the 2 bolts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) NOTE: Make sure that the O-ring is not twisted or damaged.
4. INSTALL NO. 1 OIL PAN BAFFLE PLATE Install the No. 1 oil pan baffle plate with the 8 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
5. INSTALL OIL PAN SUB-ASSEMBLY Apply seal packing in a continuous line as shown in the illustration. Seal packing Toyota Genuine Seal Packing Black, Three Bond 1207B or equivalent Standard seal diameter 3.0 to 4.0 mm (0.118 to 0.157 in.) Application position from inside edge of oil pan 6.0 mm (0.236 in.) NOTE: Remove any oil from the contact surface. Install the oil pan sub-assembly within 3 minutes and tighten the bolts and nuts within 15 minutes after applying seal packing. Do not start the engine for at least 2 hours after installing the oil pan sub-assembly. Install the oil pan sub-assembly with the 14 bolts and 2 nuts. Bolt A Torque: 35 N*m (357 kgf*cm, 26 ft.*lbf) Bolt B Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Nut Torque: 35 N*m (357 kgf*cm, 26 ft.*lbf)
6. INSTALL NO. 2 OIL PAN SUB-ASSEMBLY Apply seal packing in a continuous line as shown in the illustration. Seal packing Toyota Genuine Seal Packing Black, Three Bond 1207B or equivalent Standard seal diameter 3.0 to 4.0 mm (0.118 to 0.157 in.) NOTE: Remove any oil from the contact surface. Install the No. 2 oil pan sub-assembly within 3 minutes and tighten the bolts and nuts within 10 minutes after applying seal packing. Do not start the engine for at least 2 hours after installing the oil pan sub-assembly. Install the No. 2 oil pan sub-assembly with the 15 bolts and 2 nuts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
7. INSTALL VENTILATION PIPE GASKET Using SST, evenly tap in a new ventilation pipe gasket until its surface is flush with the lip of the ventilation pipe. SST: 09950-60010 09951-00360 SST: 09950-70010 09951-07100 HINT: Do not tap the ventilation pipe gasket at an angle. Do not tap the ventilation pipe gasket excessively.
8. INSTALL HEAT EXCHANGER ASSEMBLY Apply seal packing in a continuous line as shown in the illustration. Seal packing Toyota Genuine Seal Packing 1282B, Three Bond 1282B or equivalent Standard seal diameter 3.0 to 4.0 mm (0.118 to 0.157 in.) NOTE: Remove any oil from the contact surface. Install the heat exchanger assembly with the 11 bolts and 2 nuts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) NOTE: Install the No. 1 heat exchanger cover within 3 minutes and tighten the bolts and nuts within 15 minutes after applying seal packing. Do not start the engine for at least 2 hours after installing the cover. Install the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
9. INSTALL CYLINDER BLOCK WATER JACKET SPACER Install the 2 cylinder block water jacket spacers as shown in the illustration. HINT: Face the cutouts away from the center of the engine. Face each "Up" mark as shown in the illustration.
10. INSTALL NO. 2 CYLINDER HEAD GASKET (for Bank 1) See step 2
11. INSTALL CYLINDER HEAD SUB-ASSEMBLY (for Bank 1) See step 3
12. INSTALL CYLINDER HEAD GASKET (for Bank 2) See step 4
13. INSTALL CYLINDER HEAD SUB-ASSEMBLY (for Bank 2) See step 5
14. INSTALL VALVE ROCKER ARM PIVOT Install the 32 valve rocker arm pivots to the cylinder head assembly. Torque: 23 N*m (234 kgf*cm, 17 ft.*lbf)
15. INSTALL NO. 1 VALVE ROCKER ARM SUB-ASSEMBLY Apply engine oil to the valve rocker arm pivot and valve adjusting shim. Install the 32 No. 1 valve rocker arm sub-assembly on the cylinder heads. Make sure that the 32 No. 1 valve rocker arm sub-assembly are installed as shown in the illustration.
16. INSTALL NO. 3 CAMSHAFT See step 1
17. INSTALL NO. 4 CAMSHAFT See step 2
18. INSTALL CAMSHAFT BEARING CAP (for Bank 1) See step 3
19. INSTALL CAMSHAFT See step 4
20. INSTALL NO. 2 CAMSHAFT See step 5
21. INSTALL CAMSHAFT BEARING CAP (for Bank 2) See step 6
22. INSTALL CRANKSHAFT TIMING GEAR KEY Install the crankshaft timing gear key. Temporarily install the crankshaft pulley set bolt, and set the crankshaft timing gear key in the position as shown in the illustration. Remove the crankshaft pulley set bolt.
23. INSTALL NO. 2 CHAIN TENSIONER ASSEMBLY (for Bank 2) Install the No. 2 chain tensioner assembly with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) While raising the No. 2 chain tensioner assembly, insert a 1.0 mm (0.0394 in.) pin into the hole to fix it in place.
24. INSTALL CHAIN SUB-ASSEMBLY (for Bank 2) HINT: The crankshaft timing gear, camshaft timing gear assembly and camshaft timing exhaust gear assembly will be installed with the No. 1 chain sub-assembly and No. 2 chain sub-assembly connected to the gears. Align the No. 1 chain's orange mark plates with the camshaft timing gear's timing mark, and attach the chain to the gear as shown in the illustration. Align the No. 1 chain's orange mark plate with the crankshaft timing gear's timing mark, and attach the chain to the gear as shown in the illustration. Align the No. 2 chain's mark plates (yellow) with the timing marks of the camshaft timing gear assembly and camshaft timing exhaust gear assembly, and attach the No. 2 chain to the gears as shown in the illustration. Install the crankshaft timing gear to the crankshaft. Align and attach the knock pin of the No. 1 camshaft with the pin hole of the camshaft timing gear assembly. Using the hexagonal portion of the No. 2 camshaft, align and attach the knock pin of the No. 2 camshaft with the pin hole of the camshaft timing exhaust gear assembly. Remove the pin from the No. 2 chain tensioner assembly.
25. INSTALL NO. 1 CHAIN VIBRATION DAMPER (for Bank 2) Install the No. 1 chain vibration damper with the 2 bolts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
26. INSTALL CHAIN TENSIONER SLIPPER (for Bank 2) Install the chain tensioner slipper. HINT: If you cannot install the chain tensioner slipper due to the tension of the chain, use the hexagonal portion of the camshaft to loosen the chain, and then install the chain tensioner slipper.
27. INSTALL NO. 1 CHAIN TENSIONER ASSEMBLY (for Bank 2) Move the stopper plate upward to release the lock, and fully push the plunger into the No. 1 chain tensioner assembly. Move the stopper plate downward to set the lock, and insert a 2 mm hexagon wrench into the hole of the stopper plate. Install the No. 1 chain tensioner assembly with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Remove the hexagon wrench from the No. 1 chain tensioner assembly.
28. INSTALL NO. 3 CHAIN TENSIONER ASSEMBLY Install the No. 3 chain tensioner assembly with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) While raising the No. 3 chain tensioner assembly, insert a 1.0 mm (0.0394 in.) pin into the hole to fix it in place.
29. INSTALL CHAIN SUB-ASSEMBLY (for Bank 1) HINT: The crankshaft timing sprocket, camshaft timing gear assembly and camshaft timing exhaust gear assembly will be installed with the No. 1 chain sub-assembly and No. 2 chain sub-assembly connected to the gears. Align the No. 1 chain's orange mark plates with the camshaft timing gear's timing mark, and attach the chain to the gear as shown in the illustration. Align the No. 1 chain's orange mark plate with the crankshaft timing sprocket's timing mark, and attach the chain to the gear as shown in the illustration. Align the No. 2 chain's mark plates (yellow) with the timing marks of the camshaft timing gear assembly and camshaft timing exhaust gear assembly, and attach the No. 2 chain to the gears as shown in the illustration. Install the crankshaft timing sprocket to the crankshaft. Align and attach the knock pin of the No. 3 camshaft with the pin hole of the camshaft timing gear assembly. Using the hexagonal portion of the No. 4 camshaft, align and attach the knock pin of the No. 4 camshaft with the pin hole of the camshaft timing exhaust gear assembly. NOTE: Because the gears' timing mark positions may shift due to looseness of the No. 1 chain, use the hexagonal portion of the camshaft to hold the No. 3 camshaft in place until the No. 1 chain tensioner is installed. Remove the pin from the No. 3 chain tensioner.
30. INSTALL NO. 1 CHAIN VIBRATION DAMPER (for Bank 1) Install the No. 1 chain vibration damper with the 2 bolts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Remove the hexagon wrench from the No. 1 chain tensioner assembly.
31. INSTALL CHAIN TENSIONER SLIPPER (for Bank 1) Install the chain tensioner slipper. HINT: If you cannot install the chain tensioner slipper due to the tension of the chain, use the hexagonal portion of the camshaft to loosen the chain and install the chain tensioner slipper.
32. INSTALL NO. 1 CHAIN TENSIONER ASSEMBLY (for Bank 1) Move the stopper plate upward to release the lock, and fully push the plunger into the No. 1 chain tensioner assembly. Move the stopper plate downward to set the lock, and insert a 2 mm hexagon wrench into the hole of the stopper plate. Install the No. 1 chain tensioner assembly and gasket with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
33. TIGHTEN CAMSHAFT TIMING GEAR ASSEMBLY for Bank 1: Using a wrench, hold the hexagonal portion of the No. 3 camshaft. Using a 12 mm socket hexagon wrench, tighten the camshaft timing gear assembly with a new bolt. Torque: 79 N*m (806 kgf*cm, 58 ft.*lbf) Using a wrench to hold the hexagonal portion of the No. 4 camshaft, tighten the camshaft timing exhaust gear assembly with the bolt. Torque: 100 N*m (1020 kgf*cm, 74 ft.*lbf) for Bank 2: Using a wrench, hold the hexagonal portion of the No. 1 camshaft. Using a 12 mm socket hexagon wrench, tighten the camshaft timing gear assembly with a new bolt. Torque: 79 N*m (806 kgf*cm, 58 ft.*lbf) Using a wrench to hold the hexagonal portion of the No. 2 camshaft, tighten the camshaft timing exhaust gear assembly with the bolt. Torque: 100 N*m (1020 kgf*cm, 74 ft.*lbf)
34. INSPECT NO. 1 CYLINDER TO TDC/COMPRESSION Temporarily install the crankshaft pulley bolt. Rotate the crankshaft clockwise, and check that the timing marks on the crankshaft timing gear and camshaft timing gears are as shown in the illustration. Remove the crankshaft pulley bolt.
35. INSPECT VALVE CLEARANCE See step 10
36. ADJUST VALVE CLEARANCE See step 11
37. INSTALL OIL REFLECTOR PLATE LH (for Bank 1) Install the oil reflector plate LH with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
38. INSTALL OIL REFLECTOR PLATE RH (for Bank 2) Install the oil reflector plate RH with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
39. INSTALL INLET WATER PIPE . Refer to «INSTALLATION - Step 5»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
40. INSTALL SCAVENGING PUMP ASSEMBLY . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
41. INSTALL NO. 3 OIL PIPE . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
42. INSTALL NO. 2 OIL PIPE . Refer to «INSTALLATION - Step 3»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
43. INSTALL NO. 1 OIL PIPE . Refer to «INSTALLATION - Step 4»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
44. INSTALL WATER PUMP ASSEMBLY Install the water pump assembly and new water pump gasket with the 5 bolts. Torque: 20 N*m (204 kgf*cm, 15 ft.*lbf)
45. INSTALL TIMING CHAIN COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 6»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
46. INSTALL TIMING GEAR CASE OR TIMING CHAIN CASE OIL SEAL See step 1
47. INSTALL OIL CONTROL VALVE FILTER for Bank 1: Install the oil control valve filter to the cylinder head cover spacer LH. Install a new gasket and the cylinder head cover spacer LH with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) for Bank 2: Install the oil control valve filter to the cylinder head cover spacer. Install a new gasket and the cylinder head cover spacer with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
48. INSTALL SPARK PLUG TUBE GASKET Install the 8 new spark plug tube gaskets to each cylinder head sub-assembly. NOTE: Install the gaskets in the correct direction. Push in each gasket until its bottom surface contacts the cylinder head.
49. INSTALL CYLINDER HEAD COVER SUB-ASSEMBLY LH (for Bank 1) Install 2 new oil hole gaskets and 2 new O-rings to the camshaft bearing caps. Install a new cylinder head cover gasket LH to the cylinder head cover sub-assembly LH. NOTE: Remove any oil from the contact surface. Apply seal packing as shown in the illustration. Seal packing Toyota Genuine Seal Packing Black, Three Bond 1207B or equivalent NOTE: Remove any oil from the contact surface. Install the cylinder head cover sub-assembly within 3 minutes and tighten the bolts within 15 minutes after applying seal packing. Do not start the engine for at least 2 hours after installing the cylinder head cover sub-assembly. Install the cylinder head cover sub-assembly LH with 3 new seal washers and the 16 bolts. Bolt A Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Except bolt A Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf) Install a new fuel pump spacer gasket.
50. INSTALL CYLINDER HEAD COVER SUB-ASSEMBLY (for Bank 2) Install 2 new oil hole gaskets and 2 new O-rings to the camshaft bearing caps. Install a new cylinder head cover gasket to the cylinder head cover sub-assembly. NOTE: Remove any oil from the contact surface. Apply seal packing as shown in the illustration. Seal packing Toyota Genuine Seal Packing Black, Three Bond 1207B or equivalent NOTE: Remove any oil from the contact surface. Install the cylinder head cover sub-assembly within 3 minutes and tighten the bolts within 15 minutes after applying seal packing. Do not start the engine for at least 2 hours after installing the cylinder head cover sub-assembly. Install the cylinder head cover sub-assembly with 3 new seal washers and the 16 bolts. Bolt A Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Except bolt A Torque: 12 N*m (122 kgf*cm, 9 ft.*lbf) Install a new fuel pump spacer gasket.
51. INSTALL NO. 1 V-BANK COVER BRACKET (for Bank 1) Install the No. 1 V-bank cover bracket to the cylinder head cover sub-assembly LH. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
52. INSTALL NO. 1 V-BANK COVER BRACKET (for Bank 2) Install the No. 1 V-bank cover bracket to the cylinder head cover sub-assembly RH. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
53. INSTALL CRANKSHAFT PULLEY See step 3
54. INSTALL OIL FILTER BRACKET Install 2 new gaskets and the filter bracket with the 2 bolts and 2 nuts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Install the oil filter bracket stay with the 2 bolts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
55. INSTALL OIL COOLER ASSEMBLY Temporarily install the oil cooler assembly with the bolt. Install the union bolt to the oil cooler assembly with a new gasket. Tighten the bolt and union bolt. Bolt Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Union bolt Torque: 59 N*m (602 kgf*cm, 43 ft.*lbf)
56. INSTALL OIL FILTER ELEMENT Clean the inside of the oil filter cap, the threads and O-ring groove. Apply a light coat of engine oil to a new O-ring and install it to the oil filter cap. Set a new oil filter element in the oil filter cap. Remove any dirt or foreign matter from the installation surface of the oil filter bracket. Apply a light coat of engine oil to the O-ring again and install the oil filter cap. Using SST, tighten the oil filter cap. SST: 09228-06501 Torque: 25 N*m (255 kgf*cm, 18 ft.*lbf) NOTE: Make sure that the oil filter is installed securely as shown in the illustration. Be careful that the O-ring does not get caught between the parts.
57. INSTALL CYLINDER BLOCK WATER DRAIN COCK SUB-ASSEMBLY Apply adhesive to 2 or 3 threads of the cylinder block water drain cock sub-assembly. Adhesive Toyota Genuine Adhesive 1344, Three Bond 1344 or equivalent Install the cylinder block water drain cock sub-assembly as shown in the illustration. Torque: 30 N*m (306 kgf*cm, 22 ft.*lbf) NOTE: Do not rotate the cylinder block water drain cock sub-assembly more than 1 revolution (360°) after tightening to the specified torque. Do not loosen the cylinder block water drain cock sub-assembly to adjust them. If an adjustment is necessary, remove the cylinder block water drain cock sub-assembly and reinstall them. Install the cylinder block water drain cock plugs to the cylinder block water drain cock sub-assembly. Torque: 13 N*m (132 kgf*cm, 10 ft.*lbf)
58. INSTALL FRONT WATER BY-PASS JOINT Install the front water by-pass joint and 2 new gaskets with the 4 nuts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf)
59. INSTALL CAMSHAFT TIMING CONTROL MOTOR ASSEMBLY LH (for Bank 1) Turn the camshaft timing gear assembly intermediate shaft index slot in the counterclockwise direction by hand, to set it to the maximum retard angle position. HINT: When a camshaft lobe opens a valve, the intermediate shaft becomes difficult to turn. The position where the intermediate shaft stops is the maximum retard angle. Install a new O-ring to the timing chain cover. Align the joint of the camshaft timing control motor assembly LH and the keyway of the camshaft timing gear assembly, and install the camshaft timing control motor assembly LH with the 3 bolts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) NOTE: Check that [L] is printed on the label of the camshaft timing control motor assembly LH. Do not allow foreign matter to contact the oil seal face of the camshaft timing control motor assembly LH (the surface that contacts the timing chain cover sub-assembly). When installing the camshaft timing control motor assembly LH, do not use excessive force. Align the timing chain cover sub-assembly knock pin with the camshaft timing control motor pin hole to install the camshaft timing control motor assembly LH. Install the camshaft timing control motor assembly LH with the arrow facing upward, as shown in the illustration. Do not drop the camshaft timing control motor assembly LH. If dropped, replace it. Do not disassemble the camshaft timing control motor assembly LH. If disassembled, replace it.
60. INSTALL CAMSHAFT TIMING CONTROL MOTOR ASSEMBLY RH (for Bank 2) Turn the camshaft timing gear assembly intermediate shaft index slot in the counterclockwise direction by hand, to set it to the maximum retard angle position. HINT: When a camshaft lobe opens a valve, the intermediate shaft becomes difficult to turn. The position where the intermediate shaft stops is the maximum retard angle. Install a new O-ring to the timing chain cover. Align the joint of the camshaft timing control motor assembly RH and the keyway of the camshaft timing gear assembly, and install the camshaft timing control motor assembly RH with the 3 bolts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) NOTE: Check that [R] is printed on the label of the camshaft timing control motor assembly RH. Do not allow foreign matter to contact the oil seal face of the camshaft timing control motor assembly RH (the surface that contacts the timing chain cover sub-assembly). When installing the camshaft timing control motor assembly RH, do not use excessive force. Align the timing chain cover sub-assembly knock pin with the camshaft timing control motor pin hole to install the camshaft timing control motor assembly RH. Install the camshaft timing control motor assembly RH with the arrow facing upward, as shown in the illustration. Do not drop the camshaft timing control motor assembly RH. If dropped, replace it. Do not disassemble the camshaft timing control motor assembly RH. If disassembled, replace it.
61. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY LH Apply a light coat of engine oil to a new O-ring. Install the O-ring to the camshaft timing oil control valve assembly LH. Install the camshaft timing oil control valve assembly LH with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
62. INSTALL CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY RH Apply a light coat of engine oil to a new O-ring. Install the O-ring to the camshaft timing oil control valve assembly RH. Install the camshaft timing oil control valve assembly RH with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
63. INSTALL CRANKSHAFT POSITION SENSOR Apply a light coat of engine oil to the O-ring on the crankshaft position sensor. Install the crankshaft position sensor with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
64. INSTALL CAMSHAFT POSITION SENSOR Apply a light coat of engine oil to the O-ring on each camshaft position sensor. Install the camshaft position sensor with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
65. INSTALL VVT SENSOR for Bank 1: Apply a light coat of engine oil to the O-ring on each VVT sensor. Install the 2 VVT sensors with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) for Bank 2: Apply a light coat of engine oil to the O-ring on the VVT sensor. Install the 2 VVT sensors with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
66. INSTALL SPARK PLUG . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
67. INSTALL OIL FILLER CAP HOUSING Align the protrusion of a new oil filler cap gasket with the cutout of the oil filler cap housing, and install the oil filler cap gasket to the oil filler cap housing. Install the oil filler cap housing with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
68. INSTALL OIL FILLER CAP SUB-ASSEMBLY Install a new oil filler cap gasket to the oil filler cap. Install the oil filler cap sub-assembly to the oil filler cap housing.

Scheme 328

1. INSTALL NO. 3 V-BANK COVER BRACKET SUB-ASSEMBLY Install the No. 3 V-bank cover bracket sub-assembly with the bolt. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
2. INSTALL NO. 4 V-BANK COVER BRACKET SUB-ASSEMBLY Install the No. 4 V-bank cover bracket sub-assembly with the nut. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
3. INSTALL IGNITION COIL ASSEMBLY . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
4. INSTALL KNOCK SENSOR . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
5. INSTALL E.F.I. ENGINE COOLANT TEMPERATURE SENSOR . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
6. INSTALL ENGINE OIL LEVEL SENSOR . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
7. INSTALL OIL TEMPERATURE SENSOR . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
8. INSTALL ENGINE OIL PRESSURE SWITCH ASSEMBLY Apply adhesive to 2 or 3 threads of the oil pressure switch. Adhesive Toyota Genuine Adhesive 1344, Three Bond 1344 or equivalent Using a deep socket wrench (24mm), install the oil pressure switch. Torque: 15 N*m (153 kgf*cm, 11 ft.*lbf) NOTE: Do not start the engine for at least 1 hour after installing the switch.
9. INSTALL NO. 2 WATER BY-PASS PIPE SUB-ASSEMBLY Install the No. 2 water by-pass pipe sub-assembly with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the 3 water by-pass hoses with the 3 hose clamps.
10. INSTALL INLET WATER HOUSING Install the inlet water housing and a new gasket with the 3 bolts. Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) Connect the inlet water hose with the hose clamp.
11. INSTALL WATER PUMP PULLEY . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/cooling-fan/#cooling-service-information)
12. INSTALL OIL PUMP DRIVE SHAFT PULLEY . Refer to «INSTALLATION - Step 27»(/lexus/is-f/i-2007-2014/remont/lubrication-system/#lubrication-service-information)
13. INSTALL NO. 2 IDLER PULLEY SUB-ASSEMBLY Install the bolt and idler pulley. Torque: 43 N*m (439 kgf*cm, 32 ft.*lbf)
14. INSTALL NO. 4 ENGINE COVER SUB-ASSEMBLY Install the engine cover.
15. INSTALL NO. 5 ENGINE WIRE Install the engine wire with the 2 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Connect the 4 knock sensor connectors.
16. INSTALL FUEL INJECTOR SEAL . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
17. INSTALL FUEL INJECTOR ASSEMBLY (for Direct Injection) . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
18. INSTALL NO. 2 FUEL DELIVERY PIPE (for Direct Injection) . Refer to «INSTALLATION - Step 3»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
19. INSTALL FUEL DELIVERY PIPE (for Direct Injection) . Refer to «INSTALLATION - Step 4»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
20. INSTALL SEPARATOR CASE . Refer to «INSTALLATION - Step 5»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
21. INSTALL NO. 4 FUEL PIPE SUB-ASSEMBLY . Refer to «INSTALLATION - Step 6»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
22. INSTALL NO. 2 ENGINE COVER SUB-ASSEMBLY LH . Refer to «INSTALLATION - Step 7»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
23. INSTALL NO. 1 ENGINE COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 8»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
24. INSTALL FUEL PUMP SPACER Install the 2 fuel pump spacers.
25. INSTALL FUEL PUMP ASSEMBLY (for Bank 1) . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
26. INSTALL NO. 3 FUEL PIPE SUB-ASSEMBLY . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
27. INSTALL ENGINE COVER SUB-ASSEMBLY (for Bank 1) . Refer to «INSTALLATION - Step 3»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
28. INSTALL FUEL PUMP ASSEMBLY (for Bank 2) . Refer to «INSTALLATION - Step 4»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
29. INSTALL NO. 2 FUEL PIPE SUB-ASSEMBLY . Refer to «INSTALLATION - Step 5»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
30. INSTALL ENGINE COVER SUB-ASSEMBLY (for Bank 2) . Refer to «INSTALLATION - Step 6»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
31. INSTALL FUEL PRESSURE PULSATION DAMPER ASSEMBLY (for Direct Injection) . Refer to «INSTALLATION - Step 2»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
32. INSTALL NO. 3 COVER SUB-ASSEMBLY . Refer to «INSTALLATION - Step 3»(/lexus/is-f/i-2007-2014/remont/fuel-system/#fuel-service-information)
33. INSTALL INTAKE AIR SURGE TANK ASSEMBLY . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
34. CONNECT WATER BY-PASS HOSE Connect the water by-pass pipe hose, No. 3 water by-pass hose and No. 9 water by-pass hose with the 3 clamps to the water by-pass pipe sub-assembly.
35. INSTALL INJECTOR DRIVER . Refer to «INSTALLATION - Step 6»(/lexus/is-f/i-2007-2014/remont/exhaust/#exhaust-service-information)
36. INSTALL THROTTLE BODY ASSEMBLY . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/testing-diagnostics/#engine-control-service-information)
37. INSTALL TRANSMISSION BREATHER ASSEMBLY . Refer to «INSTALLATION - Step 1»(/lexus/is-f/i-2007-2014/remont/automatic-trans/#automatic-transmission-service-information)
38. INSTALL WIRE HARNESS CLAMP BRACKET Install the 2 wire harness clamp brackets with the 2 bolts. for LH side Torque: 21 N*m (214 kgf*cm, 15 ft.*lbf) for RH side Torque: 29 N*m (296 kgf*cm, 21 ft.*lbf)
39. INSTALL FRONT NO. 1 ENGINE MOUNTING BRACKET RH Install the mounting bracket with the 4 bolts. Torque: 35 N*m (357 kgf*cm, 26 ft.*lbf)
40. INSTALL FRONT NO. 1 ENGINE MOUNTING BRACKET LH Install the mounting bracket with the 4 bolts. Torque: 35 N*m (357 kgf*cm, 26 ft.*lbf)
41. INSTALL ENGINE WIRE Install the engine wire.
42. INSTALL ENGINE HANGER Install the 2 engine hangers with the 2 bolts as shown in the illustration. Engine Hanger Part No. Item Part No. Engine hanger 12081-38020 Bolt 90119-14120 Torque: 43 N*m (438 kgf*cm, 32 ft.*lbf)
43. REMOVE ENGINE STAND Attach an engine sling device and hang the engine with a chain block. NOTE: When hanging the engine, make sure to hang the engine with the chain at an angle of 50° or less. Otherwise, the engine or engine hangers may be damaged. Remove the bolts and engine assembly from the engine stand.

Scheme 329

Scheme 330

Scheme 331

Scheme 332

Scheme 333

Scheme 334

Scheme 335

Scheme 336

Scheme 337

1. REMOVE VALVE ADJUSTING SHIM Remove the valve adjusting shim from the cylinder head. HINT: Arrange the removed parts in the correct order.
2. REMOVE INTAKE VALVE Using SST and wooden blocks, compress the inner compression spring and remove the valve spring retainer lock. SST: 09202-70020 09202-00010 09202-01010 09202-01020 Remove the valve spring retainer, inner compression spring and intake valve. HINT: Arrange the removed parts in the correct order.
3. REMOVE EXHAUST VALVE Using SST and wooden blocks, compress the inner compression spring and remove the valve spring retainer lock. SST: 09202-70020 09202-00010 09202-01010 09202-01020 Remove the valve spring retainer, inner compression spring and exhaust valve. HINT: Arrange the removed parts in the correct order.
4. REMOVE INTAKE VALVE STEM OIL SEAL Using pliers, remove the intake valve stem oil seals from the intake valve stems.
5. REMOVE EXHAUST VALVE STEM OIL SEAL Using pliers, remove the exhaust valve stem oil seals from the exhaust valve stems.
6. REMOVE VALVE SPRING SEAT Using compressed air and a magnetic pick-up tool, remove the valve spring seat by blowing air onto it. HINT: Arrange the removed parts in the correct order.
7. REMOVE NO. 1 STRAIGHT SCREW PLUG NOTE: If water leaks from the No. 1 screw plug or the plug is corroded, replace it. Using a 10 mm hexagon wrench, remove the 6 screw plugs and 6 gaskets.
8. REMOVE NO. 2 STRAIGHT SCREW PLUG Using a 14 mm hexagon wrench, remove the 2 No. 2 straight screw plugs and 2 gaskets. NOTE: If water leaks from the No. 2 screw plug or the plug is corroded, replace it.

Scheme 338

Scheme 339

Scheme 340

Scheme 341

Scheme 342

Scheme 343

Scheme 344

Scheme 345

Scheme 346

Scheme 347

Scheme 348

Scheme 349

Scheme 350

Scheme 351

Scheme 352

1. INSPECT CYLINDER HEAD SUB-ASSEMBLY Using a precision straightedge and feeler gauge, measure the warpage of the contact surfaces of the cylinder block and manifold. Standard Warpage Item Specified Condition Cylinder head lower side 0.05 mm (0.00197 in.) Intake side 0.08 mm (0.00315 in.) Exhaust side 0.05 mm (0.00197 in.) Maximum warpage 0.10 mm (0.00394 in.) If the warpage is greater than the maximum, replace the cylinder head. Using a dye penetrant, check the intake ports, exhaust ports and cylinder surface for cracks. If cracked, replace the cylinder head.
2. INSPECT INTAKE VALVE Using a micrometer, measure the diameter of the valve stem. Standard valve stem diameter 5.470 to 5.485 mm (0.215 to 0.216 in.) Using a vernier caliper, measure the valve head margin thickness. Standard margin thickness 1.25 mm (0.0492 in.) Minimum margin thickness 0.50 mm (0.0197 in.) If the margin thickness is less than the minimum, replace the intake valve. Using a vernier caliper, measure the valve's overall length. Standard overall length 105.85 mm (4.17 in.) Minimum overall length 105.35 mm (4.15 in.) If the overall length is less than the minimum, replace the intake valve.
3. INSPECT EXHAUST VALVE Using a micrometer, measure the diameter of the valve stem. Standard valve stem diameter 5.465 to 5.480 mm (0.215 to 0.216 in.) Using a vernier caliper, measure the valve head margin thickness. Standard margin thickness 1.4 mm (0.0551 in.) Minimum margin thickness 0.50 mm (0.0197 in.) If the margin thickness is less than the minimum, replace the exhaust valve. Using a vernier caliper, measure the valve's overall length. Standard overall length 110.40 mm (4.35 in.) Minimum overall length 109.90 mm (4.33 in.) If the overall length is less than the minimum, replace the exhaust valve.
4. INSPECT INTAKE VALVE SEAT Apply a light coat of Prussian blue to the valve face. Lightly press the valve face against the valve seat. HINT: Do not rotate the valve while pressing the valve. Check the valve face and valve seat. Check that the valve seat contacts the middle of the valve face with the width between 1.1 and 1.5 mm (0.0433 and 0.0591 in.). If not, correct the valve seat. Check that the contact surfaces of the valve seat and valve face are even around the entire valve seat. If not, correct the valve seat See step 1 .
5. INSPECT EXHAUST VALVE SEAT Apply a light coat of Prussian blue to the valve face. Lightly press the valve face against the valve seat. Check the valve face and valve seat. Check that the valve seat contacts the middle of the valve face with the width between 1.3 and 1.7 mm (0.0512 and 0.0669 in.). If not, correct the valve seat. Check that the contact surface of the valve seat and valve face are even around the entire valve seat. If not, correct the valve seat See step 2 .
6. INSPECT INNER COMPRESSION SPRING Using a vernier caliper, measure the free length of the inner compression spring. Standard Free Length Item Standard Condition Intake side 47.86 mm (1.88 in.) Exhaust side 47.24 mm (1.86 in.) If the free length is not as specified, replace the inner compression spring. Using a steel square, measure the deviation of the inner compression spring. Maximum deviation 1.0 mm (0.0394 in.) Maximum angle (reference) 2° If the deviation is greater than the maximum, replace the inner compression spring.
7. INSPECT VALVE GUIDE BUSH OIL CLEARANCE Using a caliper gauge, measure the inside diameter of the guide bush. Standard bush inside diameter 5.51 to 5.53 mm (0.217 to 0.218 in.) Subtract the valve stem diameter measurement from the guide bush inside diameter measurement. Standard Oil Clearance Item Specified Condition Intake 0.025 to 0.060 mm (0.000984 to 0.00236 in.) Exhaust 0.030 to 0.065 mm (0.00118 to 0.00256 in.) Maximum Oil Clearance Item Specified Condition Intake 0.08 mm (0.00315 in.) Exhaust 0.10 mm (0.00394 in.) If the clearance is greater than the maximum, replace the valve and guide bush.
8. INSPECT CAMSHAFT THRUST CLEARANCE Inspect the bank 1 camshafts. Install the bank 1 camshafts. Using a dial indicator, measure the thrust clearance while moving the camshaft back and forth. Standard thrust clearance 0.08 to 0.14 mm (0.00315 to 0.00551 in.) Maximum thrust clearance 0.15 mm (0.00591 in.) If the thrust clearance is greater than the maximum, replace the cylinder head. If the camshaft thrust surface is damaged, replace the camshaft. Inspect the bank 2 camshafts. Install the bank 2 camshafts. Using a dial indicator, measure the thrust clearance while moving the camshaft back and forth. Standard thrust clearance 0.08 to 0.14 mm (0.00315 to 0.00551 in.) Maximum thrust clearance 0.15 mm (0.00591 in.) If the thrust clearance is greater than the maximum, replace the cylinder head. If the camshaft thrust surface is damaged, replace the camshaft.

Scheme 353

Scheme 354

Scheme 355

Scheme 356

Scheme 357

Scheme 358

Scheme 359

Scheme 360

Scheme 361

Scheme 362

1. REPLACE INTAKE VALVE GUIDE BUSH Heat the cylinder head sub-assembly to approximately 80 to 100°C (176 to 212°F). Place the cylinder head sub-assembly on wooden blocks. Using SST and a hammer, tap out the intake valve guide bush. SST: 09201-10000 09201-01050 SST: 09950-70010 09951-07100 Using a caliper gauge, measure the bush bore diameter of the cylinder head side. Standard cylinder bore diameter 10.285 to 10.306 mm (0.405 to 0.406 in.) If the bush bore diameter of the cylinder head sub-assembly is between 10.285 and 10.306 mm (0.405 and 0.406 in.), proceed to the next step. If the bush bore diameter of the cylinder head sub-assembly is 10.356 mm (0.408 in.) or more, replace the cylinder head sub-assembly. Select a new intake valve guide bush (STD or O/S 0.05), and measure its diameter. Machine the bush bore diameter of the cylinder head sub-assembly to the diameter of the selected intake valve guide bush. Bush Bore Diameter Bush Size Specified Condition STD 10.285 to 10.306 mm (0.405 to 0.406 in.) O/S 0.05 10.335 to 10.356 mm (0.407 to 0.408 in.) Heat the cylinder head sub-assembly to approximately 80 to 100°C (176 to 212°F). Using SST and a hammer, tap in a new intake valve guide bush to the specified protrusion height. SST: 09201-10000 09201-01050 SST: 09950-70010 09951-07100 Standard protrusion height 14.3 to 14.7 mm (0.563 to 0.579 in.) Using a sharp 5.5 mm reamer, ream the intake valve guide bush to obtain the specified clearance between the intake valve guide bush and valve stem.
2. REPLACE EXHAUST VALVE GUIDE BUSH Heat the cylinder head sub-assembly to approximately 80 to 100°C (176 to 212°F). Place the cylinder head sub-assembly on wooden blocks. Using SST and a hammer, tap out the exhaust valve guide bush. SST: 09201-10000 09201-01050 SST: 09950-70010 09951-07100 Using a caliper gauge, measure the bush bore diameter of the cylinder head side. Standard cylinder bore diameter 10.285 to 10.306 mm (0.405 to 0.406 in.) If the bush diameter of the cylinder head sub-assembly is between 10.285 and 10.306 mm (0.405 and 0.406 in.), proceed to the next step. If the bush bore diameter of the cylinder head sub-assembly is 10.356 mm (0.408 in.) or more, replace the cylinder head sub-assembly. Select a new exhaust valve guide bush (STD or O/S 0.05), and measure its diameter. Machine the bush bore diameter of the cylinder head side to the diameter of the selected exhaust valve guide bush. Bush Bore Diameter Bush Size Specified Condition STD 10.285 to 10.306 mm (0.405 to 0.406 in.) O/S 0.05 10.335 to 10.356 mm (0.407 to 0.408 in.) Heat the cylinder head sub-assembly to approximately 80 to 100°C (176 to 212°F). Using SST and a hammer, tap in a new exhaust valve guide bush to the specified protrusion height. SST: 09201-10000 09201-01050 SST: 09950-70010 09951-07100 Standard protrusion height 14.3 to 14.7 mm (0.563 to 0.579 in.) Using a sharp 5.5 mm reamer, ream the exhaust valve guide bush to obtain the specified clearance between the exhaust valve guide bush and exhaust valve stem.
3. REPLACE STRAIGHT PIN NOTE: It is not necessary to remove the straight pins unless they are being replaced. Remove the straight pins. Using a plastic-faced hammer, tap in new straight pins until they stop. Standard protrusion 8.0 to 10.0 mm (0.315 to 0.394 in.)
4. REPLACE STUD BOLT NOTE: If a stud bolt is deformed or the threads are damaged, replace it. Remove the stud bolts. Using E6 and E8 "TORX" socket wrenches, install the stud bolts. Bolt A,B,C and D Torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf) Bolt E Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf)

Scheme 363

Scheme 364

Scheme 365

Scheme 366

Scheme 367

Scheme 368

1. INSTALL NO. 2 STRAIGHT SCREW PLUG Using a 14 mm hexagon wrench, install 2 new gaskets and the 2 No. 2 straight screw plugs. Torque: 80 N*m (815 kgf*cm, 59 ft.*lbf)
2. INSTALL NO. 1 STRAIGHT SCREW PLUG Using a 10 mm hexagon wrench, install 6 new gaskets and the 6 No. 1 straight screw plugs. Torque: 44 N*m (448 kgf*cm, 32 ft.*lbf)
3. INSTALL VALVE SPRING SEAT Install the valve spring seats to the cylinder head.
4. INSTALL INTAKE VALVE STEM OIL SEAL Apply a light coat of engine oil to new intake valve stem oil seals. NOTE: Pay attention when installing the intake valve stem oil seals. Installing the intake valve stem oil seals on the opposite valve guide bush may cause installation problems later. HINT: The intake valve oil seals are brown and the exhaust valve oil seals are gray. Using SST, push in the intake valve stem oil seals. SST: 09201-41020 NOTE: Failure to use SST will cause the seal to be damaged or improperly seated.
5. INSTALL EXHAUST VALVE STEM OIL SEAL HINT: Perform the same procedure as for the intake side.
6. INSTALL INTAKE VALVE Apply plenty of engine oil to the tip area of the intake valve shown in the illustration. Install the intake valve, inner compression spring and valve spring retainer to the cylinder head sub-assembly. NOTE: Install the same parts in the same combination to their original locations. Using SST and wooden blocks, compress the inner compression spring and install the valve spring retainer lock. SST: 09202-70020 09202-00010 09202-01010 09202-01020 Using a plastic-faced hammer, lightly tap the valve stem tip to ensure a proper fit. NOTE: Be careful not to damage the valve spring retainer.
7. INSTALL EXHAUST VALVE Apply plenty of engine oil to the tip area of the exhaust valve shown in the illustration. Install the exhaust valve, inner compression spring and valve spring retainer to the cylinder head sub-assembly. NOTE: Install the same parts in the same combination to their original locations. Using SST and wooden blocks, compress the inner compression spring and install the valve spring retainer lock. SST: 09202-70020 09202-00010 09202-01010 09202-01020 Using a plastic-faced hammer, lightly tap the valve stem tip to ensure a proper fit. NOTE: Be careful not to damage the valve spring retainer.
8. INSTALL VALVE ADJUSTING SHIM Apply a light coat of engine oil to the valve adjusting shims. Install the valve adjusting shims to the cylinder heads.

Scheme 369

Scheme 370

Scheme 371

Scheme 372

1. REPAIR INTAKE VALVE SEAT NOTE: Repair the seat while checking the seating position. Keep the lip free of foreign matter. Using a 45° cutter, resurface the valve seat so that the valve seat width is more than the specification. Using 30° and 60° cutters, correct the valve seat so that the valve contacts the entire circumference of the seat. The contact should be in the center of the valve seat, and the valve seat width should be maintained within the specified range around the entire circumference of the seat. Standard width 1.1 to 1.5 mm (0.0433 to 0.0591 in.) Handrub the valve and valve seat with an abrasive compound. Check the valve seating position.
2. REPAIR EXHAUST VALVE SEAT NOTE: Repair the seat while checking the seating position. Keep the lip free of foreign matter. Using a 45° cutter, resurface the valve seat so that the valve seat width is more than the specification. Using 30° and 60° cutters, correct the valve seat so that the valve contacts the entire circumference of the seat. The contact should be in the center of the valve seat, and the valve seat width should be maintained within the specified range around the entire circumference of the seat. Standard width 1.3 to 1.7 mm (0.0512 to 0.0669 in.) Handrub the valve and valve seat with an abrasive compound. Check the valve seating position.

Scheme 373

Scheme 374

Scheme 375

Scheme 376

Scheme 377

Scheme 378

Scheme 379

Scheme 380

Scheme 381

Scheme 382

Scheme 383

Scheme 384

Scheme 385

Scheme 386

Scheme 387

Scheme 388

Scheme 389

Scheme 390

Scheme 391

Scheme 392

Scheme 393

Scheme 394

Scheme 395

1. INSPECT CONNECTING ROD THRUST CLEARANCE Using a dial indicator, measure the thrust clearance while moving the connecting rod back and forth. Standard thrust clearance 0.15 to 0.55 mm (0.00591 to 0.0217 in.) Maximum thrust clearance 0.70 mm (0.0276 in.) If the thrust clearance is greater than the maximum, replace connecting rods as necessary. If necessary, replace the crankshaft.
2. INSPECT CONNECTING ROD OIL CLEARANCE Check that the marks on the connecting rod and cap are aligned to ensure correct reassembly. NOTE: When installing the caps, the marks on bank 1 cylinders (1, 3, 5, 7) face towards the front of the engine and bank 2 cylinders (2, 4, 6, 8) face towards the rear of the engine. Remove the 2 connecting rod cap bolts. Using the 2 removed connecting rod cap bolts, remove the connecting rod cap and lower bearing by wiggling the connecting rod cap right and left. HINT: Keep the lower bearing inserted to the connecting rod cap. Clean the crank pin and bearing. NOTE: Check the crank pin and bearing for pitting and scratches. Lay a strip of Plastigage on the crank pin. Check that the mark of the connecting rod cap is facing the correct direction. NOTE: Be sure to assemble the bank 2 rods with the marks facing towards the rear of the engine. Install and alternately tighten the bolts of the connecting rod cap in several steps. Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) NOTE: Do not turn the crankshaft. Mark the front side of each connecting cap bolt with paint. Retighten the cap bolts 90° as shown in the illustration. Check that the painted marks are now at a 90° angle to the front. NOTE: Do not turn the crankshaft. Remove the 2 connecting rod cap bolts. Using the 2 removed connecting rod cap bolts, remove the connecting rod cap and lower bearing by wiggling the connecting rod cap right and left. HINT: Keep the lower bearing inserted to the connecting rod cap. Measure the Plastigage at its widest point. Standard oil clearance 0.037 to 0.062 mm (0.00146 to 0.00244 in.) Maximum oil clearance 0.080 mm (0.00315 in.) If the oil clearance is greater than the maximum, replace the bearings. If necessary, replace the crankshaft. HINT: If replacing a bearing, replace it with one that has the same number as its respective connecting rod cap. Each bearing's standard thickness is indicated by a 1, 2, 3 or 4 mark on its surface. Select the correct bearing by adding together the number marks imprinted on the connecting rod big end and crank pin. Example: Connecting rod "1" + Crank pin "2" = 3 (Use bearing "3") Reference: Standard Sized Bearing Center Wall Thickness Mark Thickness 2 1.483 to 1.486 mm (0.0584 to0.0585 in.) 3 1.486 to 1.489 mm (0.0585 to 0.0586 in.) 4 1.489 to 1.492 mm (0.0586 to 0.0587 in.) 5 1.492 to 1.495 mm (0.0587 to 0.0589 in.) 6 1.495 to 1.498 mm (0.0589 to 0.0590 in.) 7 1.498 to 1.501 mm (0.0590 to 0.0591 in.) Connecting Rod Big End Inside Diameter Mark Thickness 1 56.000 to 56.006 mm (2.2047 to 2.2050 in.) 2 56.007 to 56.012 mm (2.2050 to 2.2052 in.) 3 56.013 to 56.018 mm (2.2052 to 2.2054 in.) 4 56.019 to 56.024 mm (2.2055 to 2.2057 in.) Crankshaft Pin Diameter Mark Thickness 1 52.995 to 53.000 mm (2.0864 to 2.0866 in.) 2 52.989 to 52.994 mm (2.0862 to 2.0864 in.) 3 52.982 to 52.988 mm (2.0859 to 2.0861 in.) Completely remove the Plastigage. Perform the inspection above for each cylinder.
3. REMOVE PISTON AND CONNECTING ROD Using a ridge reamer, remove all the carbon from the top of the cylinder. Remove the 16 cap bolts and 8 connecting rod caps. Push the 8 pistons, 8 connecting rods and 8 upper bearings through the top of the cylinder block. HINT: Keep each bearing, connecting rod and cap together. Arrange the pistons and connecting rods in the correct order.
4. REMOVE CONNECTING ROD BEARING Remove the connecting rod bearings from the connecting rods and connecting rod caps. HINT: Arrange the removed parts in the correct order.
5. INSPECT CRANKSHAFT THRUST CLEARANCE Using a dial indicator, measure the thrust clearance while prying the crankshaft back and forth with a screwdriver. Standard thrust clearance 0.020 to 0.220 mm (0.000787 to 0.00866 in.) Maximum thrust clearance 0.30 mm (0.0118 in.) If the thrust clearance is greater than the maximum, replace the thrust washers as a set. If necessary, replace the crankshaft. Standard thrust washer thickness 2.44 to 2.49 mm (0.0961 to 0.0980 in.)
6. REMOVE CRANKSHAFT Using several steps, uniformly loosen and remove the 10 bearing cap bolts and 10 seal washers in the sequence shown the illustration. Using several steps, uniformly loosen the 20 bearing cap bolts in the sequence shown in the illustration. Using a screwdriver, pry out the main bearing caps. Remove the 5 main bearing caps and lower bearings. NOTE: Pry up the main beaning caps gradually and evenly in turns. Be careful not to damage the joint surface between the cylinder block and main bearing caps. HINT: Tape the screwdriver tip before use. Remove the crankshaft.
7. REMOVE CRANKSHAFT THRUST WASHER SET Remove the thrust washer set from the cylinder block and No. 3 bearing cap.
8. REMOVE CRANKSHAFT BEARING Remove the crankshaft bearings from the bearing caps and cylinder block. HINT: Arrange the removed parts in the correct order.
9. REMOVE NO. 1 OIL NOZZLE SUB-ASSEMBLY Using a 5 mm hexagon wrench, remove the 4 bolts and 4 oil nozzles.
10. REMOVE PISTON RING SET HINT: Arrange the piston rings in the correct order. Using a piston ring expander, remove the 2 compression rings. Using a piston ring expander, remove the oil ring. Remove the oil ring expander by hand.
11. REMOVE PISTON WITH PIN SUB-ASSEMBLY Disconnect the connecting rod from the piston. Using a screwdriver, pry off the snap rings from the piston. Using a brass bar and plastic-faced hammer, lightly tap out the piston pin and remove the connecting rod. HINT: The piston and pin are a matched set. Arrange the pistons, pins, rings, connecting rods and bearings in the correct order. Clean the piston. Using a gasket scraper, remove the carbon from the piston top. Using a groove cleaning tool or broken ring, clean the piston ring grooves. Using solvent and a brush, thoroughly clean the piston. NOTE: Do not use a wire brush.

Scheme 396

Scheme 397

Scheme 398

Scheme 399

Scheme 400

Scheme 401

Scheme 402

Scheme 403

Scheme 404

Scheme 405

Scheme 406

Scheme 407

Scheme 408

Scheme 409

Scheme 410

Scheme 411

Scheme 412

Scheme 413

Scheme 414

Scheme 415

Scheme 416

Scheme 417

Scheme 418

Scheme 419

Scheme 420

Scheme 421

Scheme 422

Scheme 423

Scheme 424

Scheme 425

Scheme 426

1. INSPECT NO. 1 OIL NOZZLE SUB-ASSEMBLY Push the check valve with a pin to check if it is stuck. If stuck, replace the No. 1 oil nozzle sub-assembly. While covering A, apply air into B. Then check the No. 1 oil nozzle sub-assembly for damage or clogging. If there is an air leak, clean or replace the No. 1 oil nozzle sub-assembly. HINT: Cover B and apply air into A. Perform the check again. Push the check valve while covering A, and apply air into B. Check that air passes through the No. 1 oil nozzle sub-assembly. If air cannot pass through, clean or replace the No. 1 oil nozzle sub-assembly. HINT: Cover B and, while pushing the check valve, apply air into A. Perform the check again.
2. INSPECT CYLINDER BLOCK FOR WARPAGE Using a precision straightedge and feeler gauge, measure the warpage of the surface that contacts the cylinder head gasket. Maximum warpage 0.05 mm (0.00197 in.) If the warpage is greater than the maximum, replace the cylinder block sub-assembly. Visually check the cylinder for vertical scratches. If deep scratches are present, rebore all 8 cylinders. If necessary, replace the cylinder block sub-assembly.
3. INSPECT CYLINDER BORE Using a cylinder gauge, measure the cylinder bore diameter at positions A, B and C in the thrust and axial directions. Standard diameter 94.000 to 94.012 mm (3.7008 to 3.7013 in.) Maximum diameter 94.200 mm (3.7087 in.) If the diameter is greater than the maximum, replace the cylinder block sub-assembly.
4. INSPECT PISTON SUB-ASSEMBLY WITH PIN Using a micrometer, measure the piston diameter at a position that is 10.7 mm (0.421 in.) below the center of the piston pin hole (refer to the illustration). Standard diameter 93.980 to 93.990 mm (3.7000 to 3.7004 in.) Minimum diameter 93.830 mm (3.6941 in.)
5. INSPECT PISTON OIL CLEARANCE Measure the cylinder bore diameter in the thrust direction. Subtract the piston diameter measurement from the cylinder bore diameter measurement. Standard oil clearance 0.010 to 0.032 mm (0.000394 to 0.00126 in.) Maximum oil clearance 0.370 mm (0.0146 in.) If the oil clearance is greater than the maximum, replace all the pistons. If necessary, replace the cylinder block sub-assembly.
6. INSPECT RING GROOVE CLEARANCE Using a feeler gauge, measure the clearance between a new piston ring and the wall of the ring groove. Standard Ring Groove Clearance Item Specified Condition No. 1 0.020 to 0.070 mm (0.000787 to 0.00276 in.) No. 2 0.020 to 0.060 mm (0.000787 to 0.00236 in.) Oil 0.020 to 0.070 mm (0.000787 to 0.00276 in.) If the clearance is not as specified, replace the piston.
7. INSPECT PISTON RING END GAP Insert the piston ring into the cylinder bore. Using a piston, push the piston ring a little beyond the bottom of the ring travel, 60 mm (2.36 in.) from the top of the cylinder block. Using a feeler gauge, measure the end gap. Standard End Gap Item Specified Condition No. 1 0.23 to 0.33 mm (0.00906 to 0.0130 in.) No. 2 0.35 to 0.45 mm (0.0138 to 0.0177 in.) Oil 0.10 to 0.40 mm (0.00394 to 0.0157 in.) Maximum End Gap Item Specified Condition No. 1 0.40 mm (0.0157 in.) No. 2 0.50 mm (0.0197 in.) Oil 0.45 mm (0.0177 in.) If the end gap is greater than the maximum, replace the piston ring. If the end gap is greater than the maximum even with a new piston ring, replace the cylinder block sub-assembly.
8. INSPECT PISTON PIN OIL CLEARANCE Check each mark on the piston, piston pin and connecting rod. Using a caliper gauge, measure the inside diameter of the piston pin hole. Standard Piston Pin Hole Inside Diameter Mark Specified Condition A 21.998 to 22.001 mm (0.86606 to 0.86618 in.) B 22.002 to 22.004 mm (0.86622 to 0.86629 in.) C 22.005 to 22.007 mm (0.86634 to 0.86642 in.) Using a micrometer, measure the piston pin diameter. Standard Piston Pin Diameter Mark Specified Condition A 21.997 to 22.000 mm (0.86602 to 0.86614 in.) B 22.001 to 22.003 mm (0.86618 to 0.86626 in.) C 22.004 to 22.006 mm (0.86629 to 0.86638 in.) Subtract the piston pin diameter measurement from the piston pin hole diameter measurement. Standard oil clearance -0.002 to 0.004 mm (-0.0000787 to 0.000158 in.) Maximum oil clearance 0.015 mm (0.000591 in.) HINT: If the oil clearance is greater than the maximum, replace the piston with pin sub-assembly. Using a caliper gauge, measure the inside diameter of the connecting rod bush. Standard Bush Inside Diameter Mark Specified Condition A 22.005 to 22.008 mm (0.86634 to 0.86646 in.) B 22.009 to 22.011 mm (0.86649 to 0.86657 in.) C 22.012 to 22.014 mm (0.86661 to 0.86669 in.) Subtract the piston pin diameter measurement from the bush inside diameter measurement. Standard oil clearance 0.005 to 0.011 mm (0.000197 to 0.000433 in.) Maximum oil clearance 0.030 mm (0.00118 in.) HINT: If the oil clearance is greater than the maximum, replace the piston with pin sub-assembly.
9. INSPECT CONNECTING ROD SUB-ASSEMBLY Using a rod aligner and feeler gauge, check the connecting rod alignment. Check for bend. Maximum bend 0.05 mm (0.00197 in.) per 100 mm (3.94 in.) If the bend is greater than the maximum, replace the connecting rod. Check for twist. Maximum twist 0.15 mm (0.00591 in.) per 100 mm (3.94 in.) If the twist is greater than the maximum, replace the connecting rod.
10. INSPECT CONNECTING ROD BOLT Using a vernier caliper, measure the tension portion diameter of the bolt. Standard diameter 8.5 to 8.6 mm (0.335 to 0.339 in.) Minimum diameter 8.3 mm (0.327 in.) If the diameter is less than the minimum, replace the bolt.
11. INSPECT CRANKSHAFT Inspect for circle runout. Place the crankshaft on V-blocks. Using a dial indicator, measure the circle runout at the center journal. Maximum circle runout 0.01 mm (0.000394 in.) If the circle runout is greater than the maximum, replace the crankshaft. Inspect the main journals. Using a micrometer, measure the diameter of each main journal. Standard journal diameter 66.988 to 67.000 mm (2.63731 to 2.63779 in.) If the diameter is not as specified, check the oil clearance. If necessary, replace the crankshaft. Inspect the crank pin. Using a micrometer, measure the diameter of each crank pin. Standard crank pin diameter 52.982 to 53.000 mm (2.08590 to 2.08661 in.) If the diameter is not as specified, check the oil clearance. If necessary, replace the crankshaft.
12. INSPECT CRANKSHAFT OIL CLEARANCE Clean each main journal and bearing. Check each main journal and bearing for pitting and scratches. HINT: If the journal or bearing is damaged, replace the bearing. Install the crankshaft bearing. HINT: See step 4 .) Install the crankshaft thrust washer set. HINT: See step 5 .) Place the crankshaft on the cylinder block. Lay a strip of Plastigage across each journal. Examine the front marks and numbers, and install the bearing caps on the cylinder block. HINT: A number is marked on each main bearing cap to indicate the installation position. Apply a light coat of engine oil to the threads and under the heads of the bearing cap bolts. Place the crankshaft bearing caps onto the cylinder block. Temporarily install the 10 main bearing cap bolts to the inside positions. Insert the main bearing caps by hand until the clearance between the main bearing cap and cylinder block is less than 6 mm (0.236 in.) by marking the 2 internal bearing cap bolts as a guide. Bolt length 91 mm (3.58 in.) Using a plastic-faced hammer, lightly tap the bearing cap to ensure a proper fit. Apply a light coat of engine oil to the threads and under the heads of the 10 main bearing cap bolts. Temporarily install the 10 main bearing cap bolts to the outside positions. Bolt length 79.5 mm (3.13 in.) HINT: Tighten the main bearing cap bolts in 2 progressive steps. Step 1: Install and uniformly tighten the 20 main bearing cap bolts in the sequence shown in the illustration. Torque: 61 N*m (622 kgf*cm, 45 ft.*lbf) for inside position Torque: 27 N*m (275 kgf*cm, 20 ft.*lbf) for outside position If any of the main bearing cap bolts does not meet the specified torque, replace it. NOTE: Do not turn the crankshaft. Step 2: Mark the front of each bearing cap bolt with paint. Tighten the bearing cap bolts another 90° in the order shown in step 1. Check that the painted marks are now at a 90° angle to the front. Install and uniformly tighten the 10 main bearing cap bolts and 10 seal washers in several steps, in the sequence shown in the illustration. Torque: 45 N*m (459 kgf*cm, 33 ft.*lbf) Remove the 30 bolts and bearing caps. Measure the Plastigage at its widest point. Standard Oil Clearance Number Mark Specified Condition No. 1 and No. 5 journal 0.017 to 0.030 mm (0.000669 to 0.00118 in.) Other journals 0.024 to 0.037 mm (0.000945 to 0.00146 in.) Maximum Oil Clearance Number Mark Specified Condition No. 1 and No. 5 journal 0.050 mm (0.00197 in.) Other journals 0.060 mm (0.00236 in.) If the oil clearance is greater than the maximum, replace the bearings. If necessary, replace the crankshaft. HINT: If replacing a bearing, replace it with one having the same number. If the number of the bearing cannot be determined, select the correct bearing by adding together the numbers imprinted on the cylinder block and crankshaft. Refer to the table below for the appropriate bearing number. There are 6 sizes of standard bearings. For No. 1 and No. 5 position bearings, use bearings marked 4, 5, 6, 7, 8 and 9. For other position bearings, use bearing marked 3, 4, 5, 6, 7 and 8. Example: Cylinder block "07" + Crankshaft "06" = Total number 13 (Use upper bearing "6" and lower bearing "7") Standard Crankshaft Main Journal Diameter Number Mark Specified Condition 00 66.999 to 67.000 mm (2.63775 to 2.63779 in.) 01 66.998 to 66.999 mm (2.63771 to 2.63775 in.) 02 66.997 to 66.998 mm (2.63767 to 2.63771 in.) 03 66.996 to 66.997 mm (2.63763 to 2.63767 in.) 04 66.995 to 66.996 mm (2.63759 to 2.63763 in.) 05 66.994 to 66.995 mm (2.63755 to 2.63759 in.) 06 66.993 to 66.994 mm (2.63751 to 2.63755 in.) 07 66.992 to 66.993 mm (2.63748 to 2.63751 in.) 08 66.991 to 66.992 mm (2.63744 to 2.63748 in.) 09 66.990 to 66.991 mm (2.63740 to 2.63744 in.) 10 66.989 to 66.990 mm (2.63736 to 2.63740 in.) 11 66.988 to 66.989 mm (2.63732 to 2.63736 in.) Standard Bearing Center Wall Thickness for No. 1 and No. 5 Journals (A) + (B) Upper Bearing Lower Bearing Number Mark Specified Condition Number Mark Specified Condition 00 to 02 4 2.501 to 2.504 mm (0.0985 to 0.0986 in.) 5 2.488 to 2.491 mm (0.0980 to 0.0981 in.) 03 to 05 5 2.504 to 2.507 mm (0.0986 to 0.0987 in.) 5 2.488 to 2.491 mm (0.0980 to 0.0981 in.) 06 to 08 5 2.504 to 2.507 mm (0.0986 to 0.0987 in.) 6 2.491 to 2.494 mm (0.0981 to 0.0982 in.) 09 to 11 6 2.507 to 2.510 mm (0.0987 to 0.0988 in.) 6 2.491 to 2.494 mm (0.0981 to 0.0982 in.) 12 to 14 6 2.507 to 2.510 mm (0.0987 to 0.0988 in.) 7 2.494 to 2.497 mm (0.0982 to 0.0983 in.) 15 to 17 7 2.510 to 2.513 mm (0.0988 to 0.0989 in.) 7 2.494 to 2.497 mm (0.0982 to 0.0983 in.) 18 to 20 7 2.510 to 2.513 mm (0.0988 to 0.0989 in.) 8 2.497 to 2.500 mm (0.0983 to 0.0984 in.) 21 to 23 8 2.513 to 2.516 mm (0.0989 to 0.0991 in.) 8 2.497 to 2.500 mm (0.0983 to 0.0984 in.) 24 to 26 8 2.513 to 2.516 mm (0.0989 to 0.0991 in.) 9 2.500 to 2.503 mm (0.0984 to 0.0985 in.) 27 to 28 9 2.516 to 2.519 mm (0.0991 to 0.0992 in.) 9 2.500 to 2.503 mm (0.0984 to 0.0985 in.) Standard Bearing Center Wall Thickness for Other Journals (A) + (B) Upper Bearing Lower Bearing Number Mark Specified Condition Number Mark Specified Condition 00 to 02 3 2.482 to 2.485 mm (0.0977 to 0.0978 in.) 4 2.501 to 2.504 mm (0.0985 to 0.0986 in.) 03 to 05 4 2.485 to 2.488 mm (0.0978 to 0.0980 in.) 4 2.501 to 2.504 mm (0.0985 to 0.0986 in.) 06 to 08 4 2.485 to 2.488 mm (0.0978 to 0.0980 in.) 5 2.504 to 2.507 mm (0.0986 to 0.0987 in.) 09 to 11 5 2.488 to 2.491 mm (0.0980 to 0.0981 in.) 5 2.504 to 2.507 mm (0.0986 to 0.0987 in.) 12 to 14 5 2.488 to 2.491 mm (0.0980 to 0.0981 in.) 6 2.507 to 2.510 mm (0.0987 to 0.0988 in.) 15 to 17 6 2.491 to 2.494 mm (0.0981 to 0.0982 in.) 6 2.507 to 2.510 mm (0.0987 to 0.0988 in.) 18 to 20 6 2.491 to 2.494 mm (0.0981 to 0.0982 in.) 7 2.510 to 2.513 mm (0.0988 to 0.0989 in.) 21 to 23 7 2.494 to 2.497 mm (0.0982 to 0.0983 in.) 7 2.510 to 2.513 mm (0.0988 to 0.0989 in.) 24 to 26 7 2.494 to 2.497 mm (0.0982 to 0.0983 in.) 8 2.513 to 2.516 mm (0.0989 to 0.0991 in.) 27 to 28 8 2.497 to 2.500 mm (0.0983 to 0.0984 in.) 8 2.513 to 2.516 mm (0.0989 to 0.0991 in.) Completely remove the Plastigage.
13. INSPECT CRANKSHAFT BEARING CAP SET BOLT Using a vernier caliper, measure the minimum diameter of the elongated thread at the measuring point. Standard diameter 10.8 to 11.0 mm (0.425 to 0.433 in.) for bolt A 9.8 to 10.0 mm (0.386 to 0.394 in.) for bolt B Minimum diameter 10.7 mm (0.421 in.) for bolt A 9.7 mm (0.382 in.) for bolt B Measuring point 47 mm (1.85 in.) If the diameter is less than the minimum, replace the bolt.

Scheme 427

Scheme 428

1. REPLACE STRAIGHT PIN NOTE: It is not necessary to remove the straight pins unless they are being replaced. Remove the straight pins. Using a plastic-faced hammer, tap in new straight pins to the cylinder block. Standard Protrusion Item Specified Condition Pin A 23 mm (0.906 in.) Pin B 11 mm (0.433 in.) Pin C 9 mm (0.354 in.) Pin D 6 mm (0.236 in.)
2. REPLACE STUD BOLT NOTE: If a stud bolt is deformed or the threads are damaged, replace it. Remove the stud bolts. Using E8 and E10 "TORX" socket wrenches, install the stud bolts. Bolt A Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf) Bolt B Torque: 9.0 N*m (92 kgf*cm, 80 in.*lbf)

Scheme 429

Scheme 430

Scheme 431

Scheme 432

Scheme 433

Scheme 434

Scheme 435

Scheme 436

Scheme 437

Scheme 438

Scheme 439

Scheme 440

Scheme 441

Scheme 442

Scheme 443

1. INSTALL NO. 1 OIL NOZZLE SUB-ASSEMBLY Using a 5 mm hexagon wrench, install the 4 No. 1 oil nozzles assembly with the 4 bolts. Torque: 10 N*m (102 kgf*cm, 7 ft.*lbf)
2. INSTALL PISTON WITH PIN SUB-ASSEMBLY Using a screwdriver, install a new snap ring at one end of the piston pin hole. HINT: Be sure that the end gap of the snap ring is not aligned with the service hole of the piston. Gradually heat the piston to approximately 80°C (176°F). Coat the piston pin and connecting rod with engine oil. Align the front marks of the piston and connecting rod as shown in the illustration. Then push in the piston pin with your thumb until the piston pin contacts the snap ring. Front Mark Item Front Mark Bank 1 piston 1 mark Bank 2 piston 2 marks NOTE: For bank 1, assemble the piston and connecting rod so that the front mark of the piston and mark of the connecting rod face the same direction. For bank 2, assemble so that the front mark of the piston and mark of the connecting rod face the opposite direction. HINT: The piston and pin are a matched set. Move the connecting rod back and forth on the piston pin. Check the fitting condition. Rotate the piston back and forth on the piston pin. Check the fitting condition. Using a screwdriver, install a new snap ring at the other end of the piston pin hole. HINT: Be sure that the end gap of the snap ring is not aligned with the service hole of the piston.
3. INSTALL PISTON RING SET Install the oil ring expander by hand. Using a piston ring expander, install the oil ring as shown in the illustration. Using a piston ring expander, install the 2 compression rings so that the code marks are positioned as shown in the illustration. HINT: Install the No. 1 compression ring with the code mark (1N) facing upward. Install the No. 2 compression ring with the code mark (2N) facing upward.
4. INSTALL CRANKSHAFT BEARING Clean the main journals and both surfaces of the bearings. Install the upper bearings. NOTE: Main bearings come in widths of 21 mm (0.827 in.) and 22.5 mm (0.886 in.). Install the 22.5 mm (0.886 in.) bearings in the No. 1 and No. 5 cylinder block journal positions with the main bearing caps. Install the 21 mm (0.827 in.) bearings in the No. 2, No. 3 and No. 4 positions. Install the upper bearings to the cylinder block as shown in the illustration. NOTE: Do not apply engine oil to the bearing inner surfaces or main journal contact surfaces. Both sides of the oil groove in the cylinder block should be visible through the oil feed holes in the bearing. The amount visible on each side of the holes should be equal. Do not allow coolant to come into contact with the bearing inner surface. If any coolant comes into contact with the bearing inner surface, replace the bearing with a new one. Install the lower bearings. NOTE: Be sure to install the selected bearings. Main bearings come in widths of 21 mm (0.827 in.) and 22.5 mm (0.886 in.). Install the 22.5 mm (0.886 in.) bearings in the No. 1 and No. 5 cylinder block journal positions with the main bearing caps. Install the 21 mm (0.827 in.) bearings in the No. 2, No. 3 and No. 4 positions. Install the lower bearings to the bearing caps. Using a vernier caliper, measure the distance between the bearing cap's edge and the lower bearing's edge. Dimension A - B or B - A 0 to 0.7 mm (0 to 0.0276 in.) NOTE: Do not apply engine oil to the bearing inner surfaces or bearing cap contact surfaces. Do not allow coolant to come into contact with the bearing inner surface. If any coolant comes into contact with the bearing inner surface, replace the bearing with a new one.
5. INSTALL CRANKSHAFT THRUST WASHER SET Apply engine oil to the thrust washer set. Install the 4 thrust washers to the No. 3 journal position of the cylinder block and bearing cap with the oil grooves facing outward.
6. INSTALL CRANKSHAFT Apply engine oil to the upper and lower bearings, then place the crankshaft on the cylinder block. Confirm the front marks and numbers of the main bearing caps, and install the bearing caps onto the cylinder block. HINT: A number is marked on each main bearing cap to indicate the installation position. Apply a light coat of engine oil to the threads and under the heads of the bearing cap bolts. Temporarily install the 10 main bearing cap bolts to the inside positions. Insert the main bearing cap by hand until the clearance between the main bearing cap and cylinder block is less than 6 mm (0.236 in.) by marking the 2 internal bearing cap bolts as a guide. Bolt length 91 mm (3.58 in.) Using a plastic-faced hammer, lightly tap the bearing cap to ensure a proper fit. Apply a light coat of engine oil to the threads and under the heads of the 10 main bearing cap bolts. Temporarily install the 10 main bearing cap bolts to the outside positions. Bolt length 79.5 mm (3.13 in.) HINT: Tighten the main bearing cap bolts in 2 progressive steps. Step 1: Install and uniformly tighten the 20 main bearing cap bolts in the sequence shown in the illustration. Torque: 61 N*m (622 kgf*cm, 45 ft.*lbf) for inside position Torque: 27 N*m (275 kgf*cm, 20 ft.*lbf) for outside position If any of the main bearing cap bolts does not meet the specified torque, replace it. Step 2: Mark the front of each bearing cap bolt with paint. Tighten the bearing cap bolts another 90° in the order shown in step 1. Check that the painted marks are now at a 90° angle to the front. Check that the crankshaft turns smoothly. Install and uniformly tighten the 10 main bearing cap bolts and 10 seal washers in several steps, in the sequence shown in the illustration. Torque: 45 N*m (459 kgf*cm, 33 ft.*lbf) Check that the crankshaft turns smoothly.
7. INSTALL CONNECTING ROD BEARING Install the connecting rod bearing to the connecting rod and bearing cap. Using a vernier caliper, measure the distance between the connecting rod and bearing cap edges, and each connecting rod bearing edge. Dimension A - B or B - A 0 to 0.7 mm (0 to 0.0276 in.) NOTE: Do not apply engine oil to the bearing inner surfaces or connecting rod contact surfaces. Do not allow coolant to come into contact with the bearing inner surface. If any coolant comes into contact with the bearing inner surface, replace the bearing with a new one.
8. INSTALL PISTON AND CONNECTING ROD Apply engine oil to the cylinder walls, the pistons, and the surfaces of the connecting rod bearings. Position the piston rings so that the ring ends are as shown in the illustration. NOTE: Do not align the ring ends. Using a piston ring compressor, push the correctly numbered piston and connecting rod into the cylinder with the front mark of the piston facing forward. NOTE: Match the numbered connecting rod cap with the connecting rod. Front Mark Item Front Mark Bank 1 1 mark Bank 2 2 marks Check that the mark of the connecting rod cap is facing the correct side. Front Mark Item Mark Bank 1 Front Side Bank 2 Rear Side Apply a light coat of engine oil to the threads and under the heads of the connecting rod cap bolts. Temporarily install the connecting cap bolts. HINT: The connecting cap bolts are tightened in 2 progressive steps. Step 1: Install and alternately tighten the bolts of the connecting rod cap in several steps. Torque: 40 N*m (408 kgf*cm, 30 ft.*lbf) Step 2: Mark the front side of each connecting cap bolt with paint. Tighten the cap bolts another 90° as shown in the illustration in the order in step 1. Check that the painted marks are now at a 90° angle to the front. When using new connecting rod cap bolts, loosen each bolt once after tightening it 90° and perform steps 1 and 2 again. Check that the crankshaft turns smoothly.

See also:
• REMOVAL - Step 4
• ON-VEHICLE INSPECTION - Step 1
• DTC CHECK / CLEAR
• REMOVAL - Step 23
• REPLACEMENT - Step 1
• REMOVAL - Step 3
• REMOVAL - Step 7
• REPLACEMENT - Step 3
• REMOVAL - Step 3
• REMOVAL - Step 3
• REMOVAL - Step 1
• REMOVAL - Step 1
• REMOVAL - Step 10
• REMOVAL - Step 6
• REMOVAL - Step 15
• ON-VEHICLE INSPECTION - Step 1
• ON-VEHICLE INSPECTION - Step 1
• ADJUSTMENT - Step 1
• REMOVAL - Step 7
• REMOVAL
