Wiper / Washer (Diagnostics & Circuit Tests): Overview Lexus HS I

SYSTEM DESCRIPTION

1. AUTO WIPER SYSTEM General The auto wiper system controls the wiper timing in accordance with the amount of raindrops that strike the windshield when the wiper switch is in AUTO. The windshield wiper relay assembly controls the timing based on the signal from the rain sensor.
2. HEADLIGHT CLEANER SYSTEM General The headlight cleaner system operates when the headlight cleaner switch is pushed ON. The headlight cleaner system also operates when the front washer switch is first operated with the headlights on.

DESCRIPTION

The windshield wiper relay assembly controls the windshield wiper motor assembly.

Scheme 12

Scheme 13

Scheme 14

1. INSPECT WINDSHIELD WIPER MOTOR ASSEMBLY Remove the windshield wiper motor assembly. Refer to «COMPONENTS»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information) . Check low speed operation. Connect a battery positive (+) lead to terminal 1 (+1) and a negative (-) lead to terminal 5 (E), and check that the motor operates at low speed. OK Motor operates at low speed. Check high speed operation. Connect a battery positive (+) lead to terminal 4 (+2) and a negative (-) lead to terminal 5 (E), and check that the motor operates at high speed. OK Motor operates at high speed. TEXT IN ILLUSTRATION *1 Component without harness connected (Windshield Wiper Motor Assembly) NG --> See step 5 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (WINDSHIELD WIPER MOTOR ASSEMBLY - BATTERY AND BODY GROUND) Disconnect the A30 windshield wiper motor connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition A30-2 (B) - Body ground Power switch on (IG) 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A30-5 (E) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Windshield Wiper Motor Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (WINDSHIELD WIPER MOTOR - WINDSHIELD WIPER RELAY) Disconnect the F101 windshield wiper relay assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A30-1 (+1) - F101-2 (+1) Always Below 1 ohms A30-1 (+1) - Body ground Always 10 kohms or higher A30-4 (+2) - F101-3 (+2) Always Below 1 ohms A30-4 (+2) - Body ground Always 10 kohms or higher A30-3 (+S) - F101-10 (+SM) Always Below 1 ohms A30-3 (+S) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
4. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-398269-S10200689712011051600000)
5. REPLACE WINDSHIELD WIPER MOTOR ASSEMBLY. Refer to «COMPONENTS»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)

This circuit detects the state of the windshield wiper switch assembly (front wiper switch and front washer switch) and sends it to the windshield wiper relay assembly.

Scheme 15

Scheme 16

1. INSPECT WINDSHIELD WIPER SWITCH ASSEMBLY Remove the windshield wiper switch assembly. Refer to «COMPONENTS»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information) . Measure the resistance according to the value(s) in the table below. Standard Resistance Front Washer Switch Adjusting Ring*1 FRONT WIPER SWITCH Tester Connection Switch Condition Specified Condition F28-3 (+1) - F28-1 (+S) OFF Below 1 ohms F28-3 (+1) - F28-2 (+B) MIST LO F28-2 (+B) - F28-4 (+2) HI F28-9 (AUTO) - F28-1 (+S) AUTO Tester Connection Switch Condition Specified Condition F27-2 (EW) - F27-3 (WF) ON Below 1 ohms OFF 10 kohms or higher Tester Connection Condition Specified Condition F28-7 (VR1) - F28-8 (VR2) Adjusting ring changed from (+) side to (-) side 0 to 2.7 kohms TEXT IN ILLUSTRATION *1 Component without harness connected (Windshield Wiper Switch Assembly) HINT: *1: The rain sensor sensitivity can be adjusted by the windshield wiper switch adjusting ring. NG --> See step 3 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (WIPER SWITCH - WIPER RELAY AND BODY GROUND) Disconnect the F27 and F28 windshield wiper switch assembly connectors. Disconnect the F101 windshield wiper relay assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F28-2 (+B) - F101-12 (IG) Always Below 1 ohms F28-2 (+B) - Body ground Always 10 kohms or higher F28-3 (+1) - F101-1 (+2S) Always Below 1 ohms F28-3 (+1) - Body ground Always 10 kohms or higher F28-4 (+2) - F101-3 (+2) Always Below 1 ohms F28-4 (+2) - Body ground Always 10 kohms or higher F28-1 (+S) - F101-11 (+SSW) Always Below 1 ohms F28-1 (+S) - Body ground Always 10 kohms or higher F28-9 (AUTO) - F101-17 (C1) Always Below 1 ohms F28-9 (AUTO) - Body ground Always 10 kohms or higher F28-10 (E) - F101-16 (CO) Always Below 1 ohms F28-10 (E) - Body ground Always 10 kohms or higher F28-7 (VR1) - F101-7 (VR1) Always Below 1 ohms F28-7 (VR1) - Body ground Always 10 kohms or higher F28-8 (VR2) - F101-6 (VR2) Always Below 1 ohms F28-8 (VR2) - Body ground Always 10 kohms or higher F27-3 (WF) - F101-4 (W) Always Below 1 ohms F27-3 (WF) - Body ground Always 10 kohms or higher F27-2 (EW) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
3. REPLACE WINDSHIELD WIPER SWITCH ASSEMBLY. Refer to «COMPONENTS»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
4. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-398269-S10200689712011051600000)

The windshield wiper relay assembly receives a signal from the rain sensor to control the auto wiper system.

Scheme 17

Scheme 18

Scheme 19

1. CHECK HARNESS AND CONNECTOR (WINDSHIELD WIPER RELAY ASSEMBLY - RAIN SENSOR) Disconnect the F101 windshield wiper relay assembly connector. Disconnect the P7 rain sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F101-8 (SIG) - P7-4 (SIG) Always Below 1 ohms P7-4 (SIG) - Body ground Always 10 kohms or higher F101-14 (PA1) - P7-3 (AUTO) Always Below 1 ohms P7-3 (AUTO) - Body ground Always 10 kohms or higher F101-25 (E) - P7-1 (ES) Always Below 1 ohms P7-1 (ES) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
2. INSPECT WINDSHIELD WIPER RELAY ASSEMBLY Reconnect the F101 windshield wiper relay assembly connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition F101-8 (SIG) - F101-25 (E) Power switch on (IG) 7.5 to 8.5 V TEXT IN ILLUSTRATION *1 Component with harness connected (Windshield Wiper Relay Assembly) NG --> See step 6 OK: Go to next step
3. INSPECT RAIN SENSOR Reconnect the P7 rain sensor connector. Connect an oscilloscope to the automatic light control sensor connector. Check for pulses. OK Tester Connection Condition Specified Condition P7-3 (AUTO) - P7-1 (ES) Power switch on (IG) Pulse generation TEXT IN ILLUSTRATION *1 Component with harness connected (Rain Sensor) NG --> See step 5 OK --> See step 4
4. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-398269-S10200689712011051600000)
5. REPLACE RAIN SENSOR. Refer to «COMPONENTS»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)
6. REPLACE WINDSHIELD WIPER RELAY ASSEMBLY. Refer to «COMPONENTS»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)

The combination meter receives washer fluid level warning switch condition (on or off) information to control the washer fluid level warning system.

Scheme 20

Scheme 21

1. INSPECT LEVEL WARNING SWITCH ASSEMBLY HINT: The following check should be performed with the windshield washer motor and pump installed to the washer jar. Fill the washer jar with washer fluid. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (S) - 2 (E) Fluid volume is more than 800 ml 10 kohms or higher 1 (S) - 2 (E) Fluid volume is less than 600 ml Below 1 ohms TEXT IN ILLUSTRATION *1 Component without harness connected (Level Warning Switch Assembly) NG --> See step 4 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (LEVEL WARNING SWITCH - COMBINATION METER AND BODY GROUND) Disconnect the F4 combination meter connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F4-7 (WLVL) - A8-1 (S) Always Below 1 ohms A8-2 (E) - Body ground Always Below 1 ohms F4-7 (WLVL) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 3
3. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-398269-S10200689712011051600000)
4. REPLACE LEVEL WARNING SWITCH ASSEMBLY. Refer to «COMPONENTS»(/lexus/hs/i-2009-2012/remont/wiperwasher-systems/#wiper-washer-service-information)

The windshield wiper relay assembly receives a vehicle speed signal from the combination meter to control the automatic windshield wiper system.

A voltage of 12 V or 5 V is output from the combination meter assembly and then input to the skid control ECU.

A voltage of 12 V or 5 V is output from each ECU or relay and then input to the combination meter assembly.

The signal is changed to a pulse signal at the transistor in the combination meter assembly.

Each ECU controls the respective system based on the pulse signal.

If a short occurs in any of the ECUs or in the wire harness connected to an ECU, all systems in the diagram below will not operate normally.

Scheme 22

Scheme 23

1. CHECK COMBINATION METER SYSTEM The circuit that sends vehicle speed signals to the combination meter system is inspected in the meter information. Refer to «Speed Signal Circuit»(ref-398261-S34359180092011051600000) . NEXT: Go to next step
2. CHECK HARNESS AND CONNECTOR (WINDSHIELD WIPER RELAY ASSEMBLY - COMBINATION METER) Disconnect the F101 windshield wiper relay assembly connector and F4 combination meter assembly connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F101-19 (SPD) - F4-7 (+S) Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. INSPECT COMBINATION METER ASSEMBLY (SPEED SENSOR SIGNAL) Check the output waveform. Remove the combination meter assembly with the connector still connected. Connect an oscilloscope to terminal F4-7 (+S) and body ground. Turn the power switch on (IG). Turn a wheel slowly. Check the signal waveform according to the condition(s) in the table below. Item Condition Tool setting 5 V/DIV., 20 ms./DIV. Vehicle condition Wheel being rotated OK The waveform is similar to that shown in the illustration. HINT: When the system is functioning normally, one wheel revolution generates 4 pulses. As the vehicle speed increases, the width indicated by (A) in the illustration narrows. TEXT IN ILLUSTRATION *1 Component with harness connected (Combination Meter Assembly) NG --> See step 5 OK --> See step 4
4. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-398269-S10200689712011051600000)
5. REPLACE COMBINATION METER ASSEMBLY. Refer to «COMPONENTS»(ref-398236-S29550529402011051600000)

This circuit provides power to the windshield wiper relay assembly.

Scheme 24

Scheme 25

1. CHECK HARNESS AND CONNECTOR (WINDSHIELD WIPER RELAY ASSEMBLY - BATTERY AND BODY GROUND) Disconnect the F101 windshield wiper relay assembly connector. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition F101-12 (IG) - Body ground Power switch on (IG) 11 to 14 V F101-23 (WIG) - Body ground Power switch on (IG) 11 to 14 V Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition F101-26 (E) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *1 Front view of wire harness connector (to Windshield Wiper Relay Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 2
2. PROCEED TO NEXT SUSPECTED AREA SHOWN IN PROBLEM SYMPTOMS TABLE. Refer to «PROBLEM SYMPTOMS TABLE»(ref-398269-S10200689712011051600000)
