Differential (Service Information): Removal & Installation Lexus HS I

Differentials & Drive Axles 34 illustrations ~3753 words

REPLACEMENT

Note. When the brake pedal is first depressed after replacing the brake pads or pushing back the disc brake piston, DTC C1214 may be output. As there is no malfunction, clear the DTC.

HINT

  1. Use the same procedure for the RH side and LH side.
  2. The procedure listed below is for the LH side.

Scheme 8

Scheme 8: REPLACEMENT
Scheme 8: REPLACEMENT

Scheme 9

Scheme 9
Scheme 9
  1. PRECAUTION (w/ Navigation System) NOTE: After the power switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  3. DISABLE BRAKE CONTROL . Refer to «REMOVAL - Step 3»(ref-398212-S03672311542011051600000)
  4. REMOVE FRONT WHEEL
  5. SEPARATE FRONT DISC BRAKE CALIPER ASSEMBLY Remove the 2 bolts and separate the front disc brake caliper assembly. NOTE: Use wire or an equivalent tool to keep the front disc brake caliper assembly from hanging down by the flexible hose.
  6. REMOVE FRONT DISC . Refer to «REMOVAL - Step 16»(ref-398221-S33784855472011051600000)
  7. REMOVE FRONT AXLE HUB BOLT Temporarily install 2 nuts to the front axle hub bolts as shown in the illustration. TEXT IN ILLUSTRATION *a Nut Recommended service nut Thread diameter: 12.0 mm (0.472 in.) Thread pitch: 1.5 mm (0.0591 in.) NOTE: Install the nuts to prevent damage to the hub bolts. Using SST and a screwdriver or an equivalent tool to hold the front axle hub sub-assembly, remove the front axle hub bolt. SST: 09628-10011 NOTE: Do not damage the threads of the front axle hub bolts.
  8. INSTALL FRONT AXLE HUB BOLT Install a washer and nut to a new front axle hub bolt as shown in the illustration. TEXT IN ILLUSTRATION *a Nut *b Washer Recommended service nut Thread diameter: 12.0 mm (0.472 in.) Thread pitch: 1.5 mm (0.0591 in.) HINT: Recommended thickness of the washer is 5 mm (0.197 in.) or more. Using a screwdriver or an equivalent tool to hold the front axle, install the hub bolt by tightening the nut. NOTE: Install the nuts to prevent damage to the front axle hub bolts. Do not damage the threads of the front axle hub bolts. Remove the 3 nuts and washer from the 3 front axle hub bolts.
  9. INSTALL FRONT DISC . Refer to «INSTALLATION - Step 1»(ref-398221-S22413988682011051600000)
  10. INSTALL FRONT DISC BRAKE CALIPER ASSEMBLY Install the front disc brake caliper assembly to the steering knuckle with the 2 bolts. Torque: 107 N*m (1089 kgf*cm, 79 ft.*lbf) NOTE: Do not twist the brake hose when installing the front disc brake caliper assembly.
  11. INSTALL FRONT WHEEL Torque: 103 N*m (1050 kgf*cm, 76 ft.*lbf)
  12. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Connect the cable to the negative (-) battery terminal and close the front luggage compartment trim cover. Connect the reservoir level switch connector. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398097-S18517405762011051600000) .
  13. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 3»(ref-398219-S33566720602011051600000)

Scheme 10

Scheme 10: ILLUSTRATION
Scheme 10: ILLUSTRATION

Scheme 11

Scheme 11: ILLUSTRATION
Scheme 11: ILLUSTRATION

REMOVAL

Note. When the brake pedal is first depressed after replacing the brake pads or pushing back the disc brake piston, DTC C1214 may be output. As there is no malfunction, clear the DTC.

HINT

  1. Use the same procedure for the RH side and LH side.
  2. The procedure listed below is for the LH side.

Scheme 12

Scheme 12: REMOVAL
Scheme 12: REMOVAL

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18
  1. PRECAUTION (w/ Navigation System) NOTE: After the power switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  3. DISABLE BRAKE CONTROL . Refer to «REMOVAL - Step 3»(ref-398212-S03672311542011051600000)
  4. REMOVE FRONT WHEEL
  5. REMOVE FRONT AXLE SHAFT NUT . Refer to «REMOVAL - Step 9»(ref-398256-S30923904202011051600000)
  6. SEPARATE FRONT SPEED SENSOR Remove the bolt and clamp, and separate the front speed sensor wire. NOTE: Be sure to separate the front speed sensor from the front shock absorber with coil spring completely. Remove the bolt and separate the front speed sensor from the steering knuckle. NOTE: Prevent foreign matter from attaching to the sensor tip. Be careful not to damage the front speed sensor. Clean the speed sensor installation hole and the contact surfaces every time the speed sensor is removed.
  7. SEPARATE FRONT FLEXIBLE HOSE Remove the bolt and separate the front flexible hose from the steering knuckle.
  8. SEPARATE FRONT DISC BRAKE CALIPER ASSEMBLY See step 5
  9. REMOVE FRONT DISC . Refer to «REMOVAL - Step 16»(ref-398221-S33784855472011051600000)
  10. SEPARATE TIE ROD END SUB-ASSEMBLY . Refer to «REMOVAL - Step 14»(ref-398255-S11225442242011051600000)
  11. SEPARATE FRONT NO. 1 LOWER SUSPENSION ARM SUB-ASSEMBLY Remove the bolt and 2 nuts, and separate the front No. 1 lower suspension arm sub-assembly from the front lower ball joint.
  12. SEPARATE FRONT DRIVE SHAFT ASSEMBLY Put matchmarks on the front drive shaft assembly and front axle hub sub-assembly. TEXT IN ILLUSTRATION *a Matchmark Using a plastic hammer, separate the front drive shaft assembly from the front axle assembly. If it is difficult to separate, tap the end of the front drive shaft assembly using a brass bar and a hammer. NOTE: Be careful not to damage the drive shaft boot and speed sensor rotor.
  13. REMOVE FRONT AXLE ASSEMBLY Remove the 2 bolts, 2 nuts and front axle assembly. NOTE: When removing the nuts, keep the bolts from rotating. Be careful not to damage the drive shaft boot and speed sensor rotor.
  14. REMOVE FRONT AXLE HUB SUB-ASSEMBLY Secure the front axle assembly between aluminium plates in a vise. NOTE: Do not overtighten the vise. Remove the 4 bolts, front axle hub sub-assembly and front disc brake dust cover. NOTE: Do not drop the front axle hub sub-assembly.

INSTALLATION

HINT

  1. Use the same procedure for the RH side and LH side.
  2. The procedure listed below is for the LH side.

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21
  1. INSTALL FRONT AXLE HUB SUB-ASSEMBLY Secure the steering knuckle between aluminium plates in a vise. NOTE: Do not overtighten the vise. Install the front axle hub sub-assembly and front disc brake dust cover with the 4 bolts. Torque: 96 N*m (979 kgf*cm, 71 ft.*lbf)
  2. INSTALL FRONT AXLE ASSEMBLY Install the front axle assembly to the front shock absorber with the 2 bolts and 2 nuts. Torque: 240 N*m (2447 kgf*cm, 177 ft.*lbf) NOTE: When installing the nuts, keep the bolts from rotating.
  3. INSTALL FRONT DRIVE SHAFT ASSEMBLY Align the matchmarks and install the front drive shaft assembly to the front axle hub sub-assembly. TEXT IN ILLUSTRATION *a Matchmark
  4. INSTALL FRONT NO. 1 LOWER SUSPENSION ARM SUB-ASSEMBLY Install the front No. 1 lower suspension arm sub-assembly to the front lower ball joint with the bolt and 2 nuts. Torque: 92 N*m (938 kgf*cm, 68 ft.*lbf)
  5. CONNECT TIE ROD END SUB-ASSEMBLY . Refer to «INSTALLATION - Step 13»(ref-398255-S38291903472011051600000)
  6. INSTALL FRONT DISC . Refer to «INSTALLATION - Step 1»(ref-398221-S22413988682011051600000)
  7. INSTALL FRONT DISC BRAKE CALIPER ASSEMBLY See step 10
  8. TEMPORARILY INSTALL FRONT AXLE SHAFT NUT Clean the threaded parts on the front drive shaft assembly and front axle shaft nut using a non-residue solvent. NOTE: Be sure to perform this work for a new front drive shaft assembly. Keep the threaded parts free of oil and foreign matter. Using a socket wrench, install a new front axle hub shaft nut. Torque: 216 N*m (2203 kgf*cm, 159 ft.*lbf) NOTE: Stake the nut after inspecting for looseness and runout in the following steps. HINT: Keep depressing the brake pedal to prevent the front drive shaft from rotating.
  9. SEPARATE FRONT DISC BRAKE CALIPER ASSEMBLY See step 5
  10. REMOVE FRONT DISC . Refer to «REMOVAL - Step 16»(ref-398221-S33784855472011051600000)
  11. INSPECT FRONT AXLE HUB BEARING LOOSENESS See step 7
  12. INSPECT FRONT AXLE HUB RUNOUT See step 8
  13. INSTALL FRONT DISC . Refer to «INSTALLATION - Step 1»(ref-398221-S22413988682011051600000)
  14. INSTALL FRONT DISC BRAKE CALIPER ASSEMBLY See step 10
  15. INSTALL FRONT FLEXIBLE HOSE Install the front flexible hose to the steering knuckle with the bolt. Torque: 19 N*m (192 kgf*cm, 14 ft.*lbf)
  16. INSTALL FRONT SPEED SENSOR Install the front speed sensor wire to the front shock absorber with the bolt and clamp. Torque: 19 N*m (192 kgf*cm, 14 ft.*lbf) NOTE: Do not twist the front speed sensor when installing it. HINT: Install the font flexible hose first and then the speed sensor harness bracket. Install the front speed sensor to the steering knuckle with the bolt. Torque: 8.5 N*m (87 kgf*cm, 75 in.*lbf) NOTE: Do not twist the front speed sensor when installing it.
  17. STAKE FRONT AXLE SHAFT NUT Using a chisel and hammer, stake the front axle shaft nut.
  18. INSTALL FRONT WHEEL Torque: 103 N*m (1050 kgf*cm, 76 ft.*lbf)
  19. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Connect the cable to the negative (-) battery terminal and close the front luggage compartment trim cover. Connect the reservoir level switch connector. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398097-S18517405762011051600000) .
  20. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 3»(ref-398219-S33566720602011051600000)
  21. STABILIZE SUSPENSION . Refer to «INSTALLATION - Step 5»(ref-398257-S35449861272011051600000)
  22. INSPECT AND ADJUST FRONT WHEEL ALIGNMENT
  23. CHECK FOR SPEED SENSOR SIGNAL

Scheme 22

Scheme 22: ILLUSTRATION
Scheme 22: ILLUSTRATION

HINT

  1. Use the same procedure for the RH side and LH side.
  2. The procedure listed below is for the LH side.
  1. REMOVE FRONT AXLE ASSEMBLY HINT: Refer to the procedures up to Remove Front Axle Assembly See step 13 .
  2. REMOVE FRONT LOWER BALL JOINT ASSEMBLY . Refer to «REMOVAL - Step 2»(ref-398257-S10485691112011051600000)
  3. REMOVE STEERING KNUCKLE Secure the front axle assembly between aluminium plates in a vise. NOTE: Do not overtighten the vise. Remove the 4 bolts, front axle hub sub-assembly and front disc brake dust cover from the steering knuckle. NOTE: Do not drop the front axle hub sub-assembly.

HINT

  1. Use the same procedure for the RH side and LH side.
  2. The procedure listed below is for the LH side.
  1. INSTALL STEERING KNUCKLE Secure the steering knuckle between aluminium plates in a vise. NOTE: Do not overtighten the vise. Install the front axle hub sub-assembly and front disc brake dust cover with the 4 bolts. Torque: 96 N*m (979 kgf*cm, 71 ft.*lbf)
  2. INSTALL FRONT LOWER BALL JOINT ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-398257-S21782082592011051600000)
  3. INSTALL FRONT AXLE ASSEMBLY HINT: Refer to the procedures from Install Front Axle Assembly See step 2 .

Scheme 23

Scheme 23: ILLUSTRATION
Scheme 23: ILLUSTRATION

HINT

  1. Use the same procedure for the RH side and LH side.
  2. The procedure listed below is for the LH side.

Scheme 24

Scheme 24
Scheme 24

Scheme 25

Scheme 25
Scheme 25
  1. SEPARATE PARKING BRAKE SHOE LEVER HINT: Refer to the procedure up to Separate Parking Brake Shoe Lever. Refer to «DISASSEMBLY - Step 12»(ref-398282-S05922336272011051600000) .
  2. REMOVE REAR AXLE HUB BOLT Temporarily install 2 nuts to the rear axle hub bolts as shown in the illustration. TEXT IN ILLUSTRATION *a Nut Recommended service nut Thread diameter: 12.0 mm (0.472 in.) Thread pitch: 1.5 mm (0.0591 in.) NOTE: Install the nuts to prevent damage to the rear axle hub bolts. Using SST and a screwdriver or an equivalent tool to hold the rear axle hub and bearing assembly, remove the rear axle hub bolt. SST: 09611-12010 NOTE: Do not damage the threads of the rear axle hub bolts.
  3. INSTALL REAR AXLE HUB BOLT Temporarily install a new rear axle hub bolt to the rear axle hub and bearing assembly. TEXT IN ILLUSTRATION *a Nut *b Washer Install a washer and nut to the new rear axle hub bolt as shown in the illustration. Recommended service nut Thread diameter: 12.0 mm (0.472 in.) Thread pitch: 1.5 mm (0.0591 in.) HINT: The thickness of the washer is preferably 5 mm (0.197 in.) or more. Using a screwdriver or an equivalent tool to hold the rear axle hub and bearing assembly, install the rear axle hub bolt by tightening the nut. NOTE: Install the nuts to prevent damage to the rear axle hub bolts. Do not damage the threads of the rear axle hub bolts. Remove the 3 nuts and washer from the 3 rear axle hub bolts.
  4. APPLY HIGH TEMPERATURE GREASE . Refer to «REASSEMBLY - Step 1»(ref-398282-S22607428932011051600000)
  5. INSTALL PARKING BRAKE SHOE LEVER HINT: Refer to the procedure from Install Parking Brake Shoe Lever. Refer to «REASSEMBLY - Step 5»(ref-398282-S22607428932011051600000) .

Scheme 26

Scheme 26: ILLUSTRATION
Scheme 26: ILLUSTRATION

Note. When the brake pedal is first depressed after replacing the brake pads or pushing back the disc brake piston, DTC C1214 may be output. As there is no malfunction, clear the DTC.

HINT

  1. Use the same procedure for the RH side and LH side.
  2. The procedure listed below is for the LH side.

Scheme 27

Scheme 27: REMOVAL
Scheme 27: REMOVAL

Scheme 28

Scheme 28
Scheme 28
  1. PRECAUTION (w/ Navigation System) NOTE: After the power switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  3. DISABLE BRAKE CONTROL . Refer to «REMOVAL - Step 3»(ref-398212-S03672311542011051600000)
  4. REMOVE REAR WHEEL
  5. REMOVE REAR SUSPENSION ARM COVER . Refer to «REMOVAL - Step 2»(ref-398258-S10231511732011051600000)
  6. SEPARATE REAR SPEED SENSOR WIRE . Refer to «REMOVAL - Step 6»(ref-398283-S24702569462011051600000)
  7. SEPARATE REAR DISC BRAKE CALIPER ASSEMBLY Remove the bolt, and separate the rear flexible hose from the No. 2 flexible hose bracket. Remove the 2 bolts, and separate the rear disc brake caliper assembly. NOTE: Use wire or an equivalent tool to keep the brake caliper from hanging down by the flexible hose.
  8. REMOVE PARKING BRAKE SHOE ADJUSTING HOLE PLUG . Refer to «REMOVAL - Step 16»(ref-398222-S35463831962011051600000)
  9. REMOVE REAR DISC . Refer to «REMOVAL - Step 17»(ref-398222-S35463831962011051600000)
  10. REMOVE REAR AXLE HUB AND BEARING ASSEMBLY Remove the 4 bolts and the rear axle hub and bearing assembly from the rear axle carrier sub-assembly.

HINT

  1. Use the same procedure for the RH side and LH side.
  2. The procedure listed below is for the LH side.
  1. INSTALL REAR AXLE HUB AND BEARING ASSEMBLY Clean the installation surfaces of the rear axle hub and bearing assembly and parking brake assembly. Install the rear axle hub and bearing assembly to the rear axle carrier sub-assembly with the 4 bolts. Torque: 90 N*m (918 kgf*cm, 66 ft.*lbf)
  2. INSPECT REAR AXLE HUB BEARING LOOSENESS See step 8
  3. INSPECT REAR AXLE HUB RUNOUT See step 9
  4. INSTALL REAR DISC . Refer to «INSTALLATION - Step 1»(ref-398222-S29799490762011051600000)
  5. INSTALL REAR DISC BRAKE CALIPER ASSEMBLY Install the rear disc brake caliper assembly with the 2 bolts. Torque: 78 N*m (799 kgf*cm, 58 ft.*lbf) Install the rear flexible hose to the No. 2 flexible hose bracket with the bolt. Torque: 19 N*m (192 kgf*cm, 14 ft.*lbf)
  6. INSTALL REAR SPEED SENSOR WIRE . Refer to «INSTALLATION - Step 6»(ref-398283-S32629862552011051600000)
  7. INSTALL REAR SUSPENSION ARM COVER . Refer to «INSTALLATION - Step 14»(ref-398258-S20342142182011051600000)
  8. ADJUST PARKING BRAKE
  9. INSTALL PARKING BRAKE SHOE ADJUSTING HOLE PLUG . Refer to «INSTALLATION - Step 2»(ref-398222-S29799490762011051600000)
  10. INSTALL REAR WHEEL Torque: 103 N*m (1050 kgf*cm, 76 ft.*lbf)
  11. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Connect the cable to the negative (-) battery terminal and close the front luggage compartment trim cover. Connect the reservoir level switch connector. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398097-S18517405762011051600000) .
  12. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 3»(ref-398219-S33566720602011051600000)
  13. CHECK FOR SPEED SENSOR SIGNAL

Scheme 29

Scheme 29: ILLUSTRATION
Scheme 29: ILLUSTRATION

Scheme 30

Scheme 30: ILLUSTRATION
Scheme 30: ILLUSTRATION

Note. When the brake pedal is first depressed after replacing the brake pads or pushing back the disc brake piston, DTC C1214 may be output. As there is no malfunction, clear the DTC.

HINT

  1. Use the same procedure for the RH side and LH side.
  2. The procedure listed below is for the LH side.

Scheme 31

Scheme 31: REMOVAL
Scheme 31: REMOVAL

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36

Scheme 37

Scheme 37
Scheme 37

Scheme 38

Scheme 38
Scheme 38
  1. PRECAUTION (w/ Navigation System) NOTE: After the power switch is turned off, the display and navigation module display (HDD navigation system) records various types of memory and settings. As a result, after turning the power switch off, make sure to wait at least 60 seconds before disconnecting the cable from the negative (-) battery terminal.
  2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT . Refer to «REMOVAL - Step 2»(ref-398219-S28362000682011051600000)
  3. DISABLE BRAKE CONTROL . Refer to «REMOVAL - Step 3»(ref-398212-S03672311542011051600000)
  4. REMOVE REAR WHEEL
  5. REMOVE REAR SUSPENSION ARM COVER . Refer to «REMOVAL - Step 2»(ref-398258-S10231511732011051600000)
  6. REMOVE REAR FLOOR SIDE MEMBER COVER LH (for LH Side) . Refer to «REMOVAL - Step 3»(ref-398258-S10231511732011051600000)
  7. REMOVE REAR FLOOR SIDE MEMBER COVER RH (for RH Side) . Refer to «REMOVAL - Step 4»(ref-398258-S10231511732011051600000)
  8. SEPARATE REAR SPEED SENSOR WIRE . Refer to «REMOVAL - Step 6»(ref-398283-S24702569462011051600000)
  9. REMOVE REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY (w/ Height Control Sensor) . Refer to «REMOVAL - Step 5»(ref-398250-S07410154312011051600000)
  10. SEPARATE REAR DISC BRAKE CALIPER ASSEMBLY See step 7
  11. REMOVE PARKING BRAKE SHOE ADJUSTING HOLE PLUG . Refer to «REMOVAL - Step 16»(ref-398222-S35463831962011051600000)
  12. REMOVE REAR DISC . Refer to «REMOVAL - Step 17»(ref-398222-S35463831962011051600000)
  13. REMOVE REAR AXLE HUB AND BEARING ASSEMBLY See step 10
  14. SEPARATE PARKING BRAKE ASSEMBLY Remove the 3 bolts, and separate the No. 3 parking brake cable assembly. Remove the nut, and separate the parking brake assembly from the rear axle carrier sub-assembly. NOTE: Use wire or an equivalent tool to keep the parking brake assembly from hanging down by the parking brake cable.
  15. REMOVE REAR NO. 1 SUSPENSION ARM ASSEMBLY . Refer to «REMOVAL - Step 5»(ref-398258-S10231511732011051600000)
  16. REMOVE REAR AXLE CARRIER SUB-ASSEMBLY Loosen the 2 bolts (A), bolt (B) and bolt (C). TEXT IN ILLUSTRATION Bolt (A) Bolt (B) Bolt (C) NOTE: Since the stopper nuts are used, turn the bolts. Do not remove the bolts. Using a jack and wooden block, jack up the rear No. 2 suspension arm assembly to replicate standard vehicle height conditions. TEXT IN ILLUSTRATION *a Jack *b Wooden Block WARNING: Do not jack up the rear No. 2 suspension arm assembly too high as the vehicle may fall. Remove the 2 bolts (A), and separate the rear trailing arm assembly from the rear axle carrier sub-assembly. TEXT IN ILLUSTRATION *1 No. 2 Flexible Hose Bracket Bolt (A) Bolt (B) Bolt (C) Remove the bolt (B), nut and No. 2 flexible hose bracket, and then separate the rear upper control arm assembly from the rear axle carrier sub-assembly. NOTE: Since the stopper nut is used, turn the bolt. Remove the bolt (C), nut and rear axle carrier sub-assembly from the rear No. 2 suspension arm assembly. NOTE: Since the stopper nut is used, turn the bolt.

HINT

  1. Use the same procedure for the RH side and LH side.
  2. The procedure listed below is for the LH side.

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40

Scheme 41

Scheme 41
Scheme 41
  1. INSTALL REAR AXLE CARRIER SUB-ASSEMBLY Hold the rear axle carrier sub-assembly between aluminium plates in a vise. NOTE: Do not overtighten the vise. Using a brass bar and a hammer, push out the bushing until it is positioned as shown in the illustration. HINT: Pushing out the bushing makes it easier to install the rear axle carrier sub-assembly. Using a jack and wooden block, jack up the rear No. 2 suspension arm assembly to replicate standard vehicle height conditions. WARNING: Do not jack up the rear No. 2 suspension arm assembly too high as the vehicle may fall. Temporarily install the rear axle carrier sub-assembly to the rear No. 2 suspension arm assembly with the bolt (C) and nut. TEXT IN ILLUSTRATION *1 No. 2 Flexible Hose Bracket Bolt (A) Bolt (B) Bolt (C) NOTE: Insert the bolt with the threaded end facing the front of the vehicle. Since the stopper nut is used, turn the bolt. Temporarily install the rear axle carrier sub-assembly and No. 2 flexible hose bracket to the rear upper control arm assembly with the bolt (B) and nut. NOTE: Insert the bolt with the threaded end facing the rear of the vehicle. Since the stopper nut is used, turn the bolt. Install the rear axle carrier sub-assembly to the rear trailing arm assembly with the 2 bolts (A). Torque: 200 N*m (2039 kgf*cm, 148 ft.*lbf) Fully tighten the bolt (B) and bolt (C). Torque: 90 N*m (918 kgf*cm, 66 ft.*lbf) NOTE: Since the stopper nuts are used, turn the bolts. Slowly lower the rear No. 2 suspension arm assembly.
  2. TEMPORARILY TIGHTEN REAR NO. 1 SUSPENSION ARM ASSEMBLY . Refer to «INSTALLATION - Step 8»(ref-398258-S20342142182011051600000)
  3. TEMPORARILY TIGHTEN PARKING BRAKE ASSEMBLY Clean the installation surfaces of the parking brake assembly and rear axle carrier sub-assembly. Temporarily tighten the parking brake assembly to the rear axle carrier sub-assembly with the nut. NOTE: Do not twist the No. 3 parking brake cable assembly when installing the parking brake assembly. HINT: Fully tighten the nut after installing the rear axle hub and bearing assembly. Install the No. 3 parking brake cable assembly with the 3 bolts. Torque: 6.0 N*m (61 kgf*cm, 53 in.*lbf) NOTE: Make sure that the 3 guides of the No. 3 parking brake cable assembly are inserted.
  4. INSTALL REAR AXLE HUB AND BEARING ASSEMBLY See step 1
  5. FULLY TIGHTEN PARKING BRAKE ASSEMBLY Fully tighten the nut. Torque: 140 N*m (1428 kgf*cm, 103 ft.*lbf)
  6. INSTALL REAR DISC . Refer to «INSTALLATION - Step 1»(ref-398222-S29799490762011051600000)
  7. INSTALL REAR DISC BRAKE CALIPER ASSEMBLY See step 5
  8. INSTALL REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY (w/ Height Control Sensor) . Refer to «INSTALLATION - Step 1»(ref-398250-S41236947682011051600000)
  9. INSTALL REAR SPEED SENSOR WIRE . Refer to «INSTALLATION - Step 6»(ref-398283-S32629862552011051600000)
  10. ADJUST PARKING BRAKE
  11. INSTALL PARKING BRAKE SHOE ADJUSTING HOLE PLUG . Refer to «INSTALLATION - Step 2»(ref-398222-S29799490762011051600000)
  12. STABILIZE SUSPENSION . Refer to «INSTALLATION - Step 5»(ref-398258-S22236517902011051600000)
  13. FULLY TIGHTEN REAR NO. 1 SUSPENSION ARM ASSEMBLY . Refer to «INSTALLATION - Step 11»(ref-398258-S20342142182011051600000)
  14. INSTALL REAR FLOOR SIDE MEMBER COVER LH (for LH Side) . Refer to «INSTALLATION - Step 12»(ref-398258-S20342142182011051600000)
  15. INSTALL REAR FLOOR SIDE MEMBER COVER RH (for RH Side) . Refer to «INSTALLATION - Step 13»(ref-398258-S20342142182011051600000)
  16. INSTALL REAR SUSPENSION ARM COVER . Refer to «INSTALLATION - Step 14»(ref-398258-S20342142182011051600000)
  17. INSTALL REAR WHEEL Torque: 103 N*m (1050 kgf*cm, 76 ft.*lbf)
  18. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Connect the cable to the negative (-) battery terminal and close the front luggage compartment trim cover. Connect the reservoir level switch connector. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-398097-S18517405762011051600000) .
  19. INSTALL LUGGAGE COMPARTMENT FLOOR MAT . Refer to «INSTALLATION - Step 3»(ref-398219-S33566720602011051600000)
  20. INSPECT AND ADJUST REAR WHEEL ALIGNMENT
  21. HEIGHT CONTROL SENSOR SIGNAL INITIALIZATION (w/ Height Control Sensor)
  22. INSPECT AND ADJUST HEADLIGHT AIMING (w/ Height Control Sensor)
  23. CHECK FOR SPEED SENSOR SIGNAL

More articles — Differential (Service Information)
