Charging System (Service Information): Removal & Installation Lexus HS I

INSTALLATION

1. INSTALL AUXILIARY BATTERY Install the battery. Connect the battery ventilation hose to the battery without kinking it. HINT: Push in the battery ventilation hose to the battery until a click sound is heard. Install the battery clamp with the nut. Torque: 5.4 N*m (55 kgf*cm, 48 in.*lbf) Install the positive (+) battery terminal with the nut. Install the battery terminal cap.
2. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL Connect the cable to the negative (-) battery terminal and close the front luggage compartment trim cover.
3. INSTALL LUGGAGE COMPARTMENT FLOOR MAT Install the luggage compartment floor mat.

Scheme 8

1. INSPECT BATTERY THERMOMETER SENSOR Disconnect the connector from the battery thermometer sensor. TEXT IN ILLUSTRATION *1 Ohmmeter *2 Resistance kohms *3 Battery Temperature °C (°F) - - Standard Resistance Tester Connection Condition Specified Condition 1 - 2 24 to 26°C (75 to 79°F) 1.91 to 2.05 kohms If the resistance is not within the specified range, replace the battery thermometer sensor.
