Automatic Transmission (Diagnostic Codes & Circuit Tests): Other Lexus GX J150

Automatic Trans 15 illustrations ~1651 words

MONITOR STRATEGY

Related DTCsP0705: Park/neutral position switch/Verify switch input
Required sensors/ComponentsPark/neutral position switch
Frequency of operationContinuous
DurationCondition (A) and (B) 2 seconds Condition (C) 60 seconds
MIL operation2 driving cycles
Sequence of operationNone

TYPICAL ENABLING CONDITIONS

The monitor will run whenever the following DTCs are not presentNone
Battery voltage8 V or higher
Engine switchOn (IG)
StarterOFF

ALL

TYPICAL MALFUNCTION THRESHOLDS

  1. One of the following conditions is met: Condition (A), (B) or (C) Condition (A) When 2 or more of the following signals are input at the same time P switch ON N switch ON NSW switch ON R switch ON D switch ON Condition (B) When the shift lever is in S, one of the following conditions is met P switch ON N switch ON NSW switch ON R switch ON Condition (C) All of the following conditions are met P switch OFF N switch OFF NSW switch OFF R switch OFF D switch OFF

COMPONENT OPERATING RANGE

Park/neutral position switchThe park/neutral position switch sends only one signal to the ECM

Scheme 453

Scheme 453: WIRING DIAGRAM
Related DTCsP0711: ATF temperature sensor/Rationality check
Required sensors/ComponentsATF temperature sensor
Frequency of operationContinuous
Duration3 seconds
MIL operation2 driving cycles
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentP0712, P0713, P2742, P2743 (ATF temperature sensor "A" circuit) P0327, P0328, P0332, P0333, P032C, P032D, P033C, P033D (IAT (Intake air temperature) sensor circuit)
ECT (Engine Coolant Temperature) sensor circuitNot circuit malfunction

ALL

Soak time5 hours or more
Duration time from engine start12 seconds or more
Time after engine start10 minutes
Driving distance after engine start4.7 km (3.0 miles) or more
IAT (12 seconds after engine start)15°C (59°F) or higher
ECT (12 seconds after engine start)15°C (59°F) or higher

CONDITION (A)

Duration time for ECT to reach 60°C (140°F)10 seconds or more
ATF temperature (12 seconds after engine start)110°C (230°F) or higher
ECT (12 seconds after engine start)Below 35°C (95°F)

CONDITION (B)

When either condition below is met: Condition (A) or (B)

ATF temperatureBelow 20°C (68°F)

CONDITION (A)

ATF temperature110°C (230°F) or higher

CONDITION (B)

ATF temperature20°C (68°F) or higher

CONDITION (A)

ATF temperatureBelow 110°C (230°F)

CONDITION (B)

PROCEDURE

  1. CHECK DTC OUTPUT (IN ADDITION TO DTC P0711) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0711 is output A P0711 and other DTCs are output B HINT: If any other codes besides P0711 are output, perform troubleshooting for those DTCs first. B --> See step 4 A: Go to next step
  2. CHECK TRANSMISSION FLUID LEVEL Check the transmission fluid level. Refer to «ADJUSTMENT»(ref-524256-S25715515122013012800000) . OK Automatic transmission fluid level is correct. NG --> See step 5 OK --> See step 3
  3. REPAIR OR REPLACE TRANSMISSION WIRE. Refer to «REMOVAL»(ref-524256-S15629588202013012800000)
  4. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524128-S24287833502013012800000)
  5. ADD FLUID. Refer to «ADJUSTMENT»(ref-524256-S25715515122013012800000)
Related DTCsP0712: ATF temperature sensor/Range check (Low resistance) P0713: ATF temperature sensor/Range check (High resistance)
Required sensors/ComponentsATF temperature sensor
Frequency of operationContinuous
Duration0.5 seconds
MIL operationImmediate
Sequence of operationNone

All

  1. Battery voltage 8 V or higher Engine switch On (IG) Starter OFF

P0712: Range check (Low resistance)

  1. The monitor will run whenever the following DTCs are not present None

P0713: Range check (High resistance)

  1. One of the following conditions is met: Condition (A) or (B) Condition (A) The monitor will run whenever the following DTCs are not present P0115, P0117, P0118 (ECT sensor circuit) P0097, P0098, P0110, P0112, P0113 (IAT sensor circuit) Engine coolant temperature or intake air temperature at engine start -29.375°C (-20.875°F) or less Time after engine start 332 seconds or more Condition (B) The monitor will run whenever the following DTCs are not present P0115, P0117, P0118 (ECT sensor circuit) P0097, P0098, P0110, P0112, P0113 (IAT sensor circuit) Engine coolant temperature and intake air temperature at engine start Higher than -29.375°C (-20.875°F) Time after engine start 10 seconds or more
ATF temperature sensor resistanceBelow 79 ohms

P0712: RANGE CHECK (LOW RESISTANCE)

ATF temperature sensor resistanceHigher than 156 kohms

P0713: RANGE CHECK (HIGH RESISTANCE)

ATF temperature sensor resistance79 ohms to 156 kohms

Scheme 454

Scheme 454: WIRING DIAGRAM
Related DTCsP0717: Speed sensor (NT)/Verify pulse input
Required sensors/Components (Main)Speed sensor (NT)
Required sensors/Components (Related)Speed sensor (SP2)
Frequency of operationContinuous
Duration5 seconds
MIL operationImmediate
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentP0705 (Park/neutral position switch circuit) P0751, P0973, P0974 (Shift solenoid valve S1) P0756, P0976, P0977 (Shift solenoid valve S2) P0761, P0979, P0980 (Shift solenoid valve S3) P0766, P0982, P0983 (Shift solenoid valve S4) P0748 (Shift solenoid valve SL1 circuit) P0776, P0778 (Shift solenoid valve SL2)
Shift changeAfter shift change is completed and before starting next shift change operation
ECM selected gear4th, 5th or 6th
Output shaft rpm1000 rpm or more
NSW switchOFF
R switchOFF
EngineRunning
Battery voltage8 V or higher
Engine switchOn (IG)
StarterOFF
Speed sensor signal rpmLess than 300 rpm
Speed sensor signal rpm300 rpm or more

Scheme 455

Scheme 455: WIRING DIAGRAM
Related DTCsP0722: Speed sensor SP2/Verify pulse input
Required Sensors/ComponentsSpeed sensor (SP2)
Frequency of operationContinuous
Duration5 seconds
MIL operation2 driving cycles
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentNone
Vehicle speed from vehicle speed sensor9 km/h (5.59 mph) or more
Battery voltage8 V or higher
Engine switchOn (IG)
StarterOFF
Speed sensor signalNo signal
Vehicle speed from output speed sensor9 km/h (5.59 mph) or more

Scheme 456

Scheme 456: WIRING DIAGRAM
Related DTCsP0729: Gear 6 incorrect ratio (Sequence valve) / Functional check
Required sensors/ComponentsSequence valve
Frequency of operationContinuous
Duration0.4 seconds
MIL operation2 driving cycles
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentP0717 (Turbine speed sensor circuit) P0500 (Output speed sensor circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit)
Shift solenoid valve S1 circuitNot circuit malfunction
Shift solenoid valve S2 circuitNot circuit malfunction
Shift solenoid valve S3 circuitNot circuit malfunction
Shift solenoid valve S4 circuitNot circuit malfunction
Shift solenoid valve SR circuitNot circuit malfunction
Shift solenoid valve SL1 circuitNot circuit malfunction
Shift solenoid valve SL2 circuitNot circuit malfunction
ECT (Engine Coolant Temperature) sensor circuitNot circuit malfunction
ETCS (Electric Throttle Control System)Not system down
Transmission position"D"
Duration time from shifting "N" to "D"4 seconds or more
ECT40°C (104°F) or higher
Spark advance from max. retard timing by KCS control0° crankshaft angle or more
EngineStarting
Transfer positionHIGH*

ALL

HINT

*: Following conditions are met

Vehicle speed sensor "A" circuitNot circuit malfunction
Transfer output speed143 rpm or more
Transfer input speed / Transfer output speed (NO / NOtf)0.9 or more, and less than 1.1
ECM selected gear5th
Vehicle speed2 km/h (1.2 mph) or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

CONDITION (A)

ECM selected gear6th
Vehicle speed2 km/h (1.2 mph) or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

CONDITION (B)

Both of the following conditions are met: Condition (A) and (B)

Turbine speed / Output speed (NT / NO)0.65 or more, and 0.79 or less (This means actual gear is 5th)

CONDITION (A)

Turbine speed / Output speed (NT / NO)0.93 or more, and 1.07 or less (This means actual gear is 4th)

CONDITION (B)

Related DTCsP0748: Shift solenoid valve SL1/Range check
Required sensors/ComponentsShift solenoid valve SL1
Frequency of operationContinuous
Duration1 second
MIL operationImmediate
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentNone
Solenoid current cut statusNot cut
Battery voltage11 V or higher
Engine switchOn (IG)
StarterOFF
Solenoid status from MICFailure
Output signal dutyLess than 100%

Scheme 457

Scheme 457: WIRING DIAGRAM
Related DTCsP0751: Shift solenoid valve S1/Functional check
Required sensors/ComponentsShift solenoid valve S1, Speed sensor (NT), Speed sensor (SP2), Crankshaft position sensor (NE), Throttle position sensor, MAF
Frequency of operationContinuous
DurationOFF malfunction (A) and ON malfunction (A), (B) 0.4 seconds OFF malfunction (B) 3 seconds OFF malfunction (C) 1 second
MIL operation2 driving cycles
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentP0717 (Turbine speed sensor circuit) P0500 (Output speed sensor circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit)
Shift solenoid valve S1 circuitNot circuit malfunction
Shift solenoid valve S2 circuitNot circuit malfunction
Shift solenoid valve S3 circuitNot circuit malfunction
Shift solenoid valve S4 circuitNot circuit malfunction
Shift solenoid valve SR circuitNot circuit malfunction
Shift solenoid valve SL1 circuitNot circuit malfunction
Shift solenoid valve SL2 circuitNot circuit malfunction
ECT (Engine Coolant Temperature) sensor circuitNot circuit malfunction
ETCS (Electric Throttle Control System)Not system down
Transmission position"D"
Duration time from shifting "N" to "D"4 seconds or more
ECT40°C (104°F) or higher
Spark advance from max. retard timing by KCS control0° crankshaft angle or more
EngineStarting
Transfer positionHIGH*

ALL

HINT

*: Following conditions are met

Vehicle speed sensor "A" circuitNot circuit malfunction
Transfer output speed143 rpm or more
Transfer input speed / Transfer output speed (NO / NOtf)0.9 or more, and less than 1.1
ECM selected gear5th
Vehicle speed2 km/h (1.2 mph) or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

OFF MALFUNCTION (A)

Current ECM selected gear6th
Last ECM selected gear5th
Vehicle speed (During transition from 5th to 6th gear)Less than 100 km/h (62.2 mph)

OFF MALFUNCTION (B)

ECM selected gear6th
Engine speed - Turbine speed (NE - NT) (After transition from 5th to 6th gear)150 rpm or less
Vehicle speed (After transition from 5th to 6th gear)Less than 100 km/h (62.2 mph)

OFF MALFUNCTION (C)

ECM selected gear1st
Vehicle speed2 km/h (1.2 mph) or more and less than 40 km/h (24.9 mph)
Engine speed - Turbine speed (NE - NT)50 rpm or more

ON MALFUNCTION (A)

ECM selected gear5th
Vehicle speed2 km/h (1.2 mph) or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

ON MALFUNCTION (B)

[OFF malfunction]

  1. Both of the following conditions are met: OFF malfunction (A) and OFF malfunction (B) or (C)
Turbine speed / Output speed (NT / NO)0.65 or more, and 0.79 or less (This means actual gear is 5th)

OFF MALFUNCTION (A)

Turbine speed - Output speed x 5th gear ratio (NT - NO x 5th gear ratio)1000 rpm or more

OFF MALFUNCTION (B)

Turbine speed - Output speed x 6th gear ratio (NT - NO x 6th gear ratio)1000 rpm or more

OFF MALFUNCTION (C)

[ON malfunction]

  1. Both of the following conditions are met: ON malfunction (A) and (B)
  2. 2 detections are necessary per driving cycle
  3. 1st detection: temporary flag ON
  4. 2nd detection: pending fault code ON
Turbine speed / Output speed (NT / NO)1.91 or more, and 2.35 or less (This means actual gear is 2nd)

ON MALFUNCTION (A)

Turbine speed / Output speed (NT / NO)0.65 or more, and 0.79 or less (This means actual gear is 5th)

ON MALFUNCTION (B)

Related DTCsP0756: Shift solenoid valve S2/Functional check
Required sensors/ComponentsShift solenoid valve S2
Frequency of operationContinuous
Duration0.4 seconds
MIL operation2 driving cycles
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentP0717 (Turbine speed sensor circuit) P0500 (Output speed sensor circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit)
Shift solenoid valve S1 circuitNot circuit malfunction
Shift solenoid valve S2 circuitNot circuit malfunction
Shift solenoid valve S3 circuitNot circuit malfunction
Shift solenoid valve S4 circuitNot circuit malfunction
Shift solenoid valve SR circuitNot circuit malfunction
Shift solenoid valve SL1 circuitNot circuit malfunction
Shift solenoid valve SL2 circuitNot circuit malfunction
ECT (Engine Coolant Temperature) sensor circuitNot circuit malfunction
ETCS (Electric Throttle Control System)Not system down
Transmission position"D"
Duration time from shifting "N" to "D"4 seconds or more
ECT40°C (104°F) or higher
Spark advance from max. retard timing by KCS control0° crankshaft angle or more
EngineStarting
Transfer positionHIGH*

ALL

HINT

*: Following conditions are met

Vehicle speed sensor "A" circuitNot circuit malfunction
Transfer output speed143 rpm or more
Transfer input speed / Transfer output speed (NO / NOtf)0.9 or more, and less than 1.1
ECM selected gear1st
Vehicle speed2 km/h (1.2 mph) or more and less than 40 km/h (24.9 mph)
Engine speed - Turbine speed (NE - NT)50 rpm or more

OFF MALFUNCTION (A)

ECM selected gear6th
Vehicle speed2 km/h (1.2 mph) or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

OFF MALFUNCTION (B)

ECM selected gear5th
Vehicle speed2 km/h (1.2 mph) or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

ON MALFUNCTION (A)

ECM selected gear6th
Vehicle speed2 km/h (1.2 mph) or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

ON MALFUNCTION (B)

OFF malfunction is detected when OFF malfunction (A) and (B) are detected.

Turbine speed / Output speed (NT / NO)1.28 or more, and 1.53 or less (This means actual gear is 3rd)

OFF MALFUNCTION (A)

Turbine speed / Output speed (NT / NO)0.65 or more, and 0.79 or less (This means actual gear is 5th)

OFF MALFUNCTION (B)

ON Malfunction is detected when ON malfunction (A) and (B) are detected.

Turbine speed / Output speed (NT / NO)0.51 or more, and 0.65 or less (This means actual gear is 6th)

ON MALFUNCTION (A)

Turbine speed / Output speed (NT / NO)0.51 or more, and 0.65 or less (This means actual gear is 6th)

ON MALFUNCTION (B)

Related DTCsP0761: Shift solenoid valve S3/Functional check
Required sensors/ComponentsShift solenoid valve S3
Frequency of operationContinuous
DurationOFF malfunction (A), (B) and ON malfunction (A) 0.4 seconds ON malfunction (B) 3 seconds ON malfunction (C) 1 second
MIL operation2 driving cycles
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentP0717 (Turbine speed sensor circuit) P0500 (Output speed sensor circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit)
Shift solenoid valve S1 circuitNot circuit malfunction
Shift solenoid valve S2 circuitNot circuit malfunction
Shift solenoid valve S3 circuitNot circuit malfunction
Shift solenoid valve S4 circuitNot circuit malfunction
Shift solenoid valve SR circuitNot circuit malfunction
Shift solenoid valve SL1 circuitNot circuit malfunction
Shift solenoid valve SL2 circuitNot circuit malfunction
ECT (Engine Coolant Temperature) sensor circuitNot circuit malfunction
ETCS (Electric Throttle Control System)Not system down
Transmission position"D"
Duration time from shifting "N" to "D"4 seconds or more
ECT40°C (104°F) or higher
Spark advance from max. retard timing by KCS control0° crankshaft angle or more
EngineStarting
Transfer positionHIGH*

ALL

HINT

*: Following conditions are met

Vehicle speed sensor "A" circuitNot circuit malfunction
Transfer output speed143 rpm or more
Transfer input speed / Transfer output speed (NO / NOtf)0.9 or more, and less than 1.1
ECM selected gear2nd
Vehicle speed2 km/h (1.2 mph) or more
Output speed2nd --> 1st down-shift point or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

OFF MALFUNCTION (A)

ECM selected gear6th
Vehicle speed2 km/h (1.2 mph) or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

OFF MALFUNCTION (B)

ECM selected gear4th
Vehicle speed2 km/h (1.2 mph) or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

ON MALFUNCTION (A)

Current ECM selected gear5th
Last ECM selected gear4th
Vehicle speed (During transition from 4th to 5th gear)Less than 100 km/h (62.2 mph)

ON MALFUNCTION (B)

ECM selected gear5th
Engine speed - Turbine speed (NE - NT) (After transition to 5th gear)150 rpm or less
Vehicle speed (After transition to 5th gear)Less than 100 km/h (62.2 mph)

ON MALFUNCTION (C)

[OFF malfunction]

  1. Both of the following conditions are met: OFF malfunctions (A) and (B)
Turbine speed / Output speed (NT / NO)0.93 or more, and 1.07 or less (This means actual gear is 4th)

OFF MALFUNCTION (A)

Turbine speed / Output speed (NT / NO)0.51 or more, and 0.65 or less (This means actual gear is 6th)

OFF MALFUNCTION (B)

[ON malfunction]

  1. One of the following conditions is met: ON malfunctions (A), (B) or (C)
Turbine speed / Output speed (NT / NO)1.28 or more, and 1.53 or less (This means actual gear is 3rd)

ON MALFUNCTION (A)

Turbine speed - Output speed x 4th gear ratio (NT - NO x 4th gear ratio)1000 rpm or more

ON MALFUNCTION (B)

Turbine speed - Output speed x 5th gear ratio (NT - NO x 5th gear ratio)1000 rpm or more

ON MALFUNCTION (C)

Related DTCsP0766: Shift solenoid valve S4/Functional check P0776: Shift solenoid valve SL2/Functional check
Required sensors/ComponentsShift solenoid valve S4, Speed sensor (NT), Speed sensor (SP2), Crankshaft position sensor (NE)
Frequency of operationContinuous
Duration0.4 seconds
MIL operation2 driving cycles
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentP0717 (Turbine speed sensor circuit) P0500 (Output speed sensor circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit)
Shift solenoid valve S1 circuitNot circuit malfunction
Shift solenoid valve S2 circuitNot circuit malfunction
Shift solenoid valve S3 circuitNot circuit malfunction
Shift solenoid valve S4 circuitNot circuit malfunction
Shift solenoid valve SR circuitNot circuit malfunction
Shift solenoid valve SL1 circuitNot circuit malfunction
Shift solenoid valve SL2 circuitNot circuit malfunction
ECT (Engine Coolant Temperature) sensor circuitNot circuit malfunction
ETCS (Electric Throttle Control System)Not system down
Transmission position"D"
Duration time from shifting "N" to "D"4 seconds or more
ECT40°C (104°F) or higher
Spark advance from max. retard timing by KCS control0° crankshaft angle or more
EngineStarting
Transfer positionHIGH*

ALL

HINT

*: Following conditions are met

Vehicle speed sensor "A" circuitNot circuit malfunction
Transfer output speed143 rpm or more
Transfer input speed / Transfer output speed (NO / NOtf)0.9 or more, and less than 1.1
ECM selected gear5th
Vehicle speed2 km/h (1.2 mph) or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

P0766 OFF MALFUNCTION (A) AND P0776 ON MALFUNCTION (A)

ECM selected gear6th
Vehicle speed2 km/h (1.2 mph) or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

P0766 OFF MALFUNCTION (B) AND P0776 ON MALFUNCTION (B)

[OFF malfunction]

  1. Both of the following conditions are met: OFF malfunction (A) and (B)
Turbine speed / Output speed (NT / NO)0.93 or more, and 1.07 or less (This means actual gear is 4th)

P0766 OFF MALFUNCTION (A)

Turbine speed / Output speed (NT / NO)0.93 or more, and 1.07 or less (This means actual gear is 4th)

P0766 OFF MALFUNCTION (B)

[ON malfunction]

  1. Both of the following conditions are met: ON malfunction (A) and (B)
Turbine speed / Output speed (NT / NO)0.93 or more, and 1.07 or less (This means actual gear is 4th)

P0776 ON MALFUNCTION (A)

Turbine speed / Output speed (NT / NO)0.93 or more, and 1.07 or less (This means actual gear is 4th)

P0776 ON MALFUNCTION (B)

Related DTCsP0778: Shift solenoid valve SL2/Range check
Required sensors/ComponentsShift solenoid valve SL2
Frequency of operationContinuous
Duration1 second
MIL operationImmediate
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentNone
Solenoid current cut statusNot cut
Battery voltage11 V or higher
Engine switchOn (IG)
StarterOFF
Solenoid status from MICFailure
Output signal dutyLess than 100%

Scheme 458

Scheme 458: WIRING DIAGRAM
Related DTCsP0781: Valve body / Functional check
Required sensors/ComponentsValve body, Automatic transmission assembly
Frequency of operationContinuous
DurationCondition (A) and (B) 0.4 seconds Condition (C) 3 seconds Condition (D) 1 second
MIL operation2 driving cycles
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentP0717 (Turbine speed sensor circuit) P0500 (Output speed sensor circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit)
Shift solenoid valve S1 circuitNot circuit malfunction
Shift solenoid valve S2 circuitNot circuit malfunction
Shift solenoid valve S3 circuitNot circuit malfunction
Shift solenoid valve S4 circuitNot circuit malfunction
Shift solenoid valve SR circuitNot circuit malfunction
Shift solenoid valve SL1 circuitNot circuit malfunction
Shift solenoid valve SL2 circuitNot circuit malfunction
ECT (Engine Coolant Temperature) sensor circuitNot circuit malfunction
ETCS (Electric Throttle Control System)Not system down
Transmission position"D"
Duration time from shifting "N" to "D"4 seconds or more
ECT40°C (104°F) or higher
Spark advance from max. retard timing by KCS control0° crankshaft angle or more
EngineStarting
Transfer positionHIGH*

ALL

HINT

*: Following conditions are met

Vehicle speed sensor "A" circuitNot circuit malfunction
Transfer output speed143 rpm or more
Transfer input speed / Transfer output speed (NO / NOtf)0.9 or more, and less than 1.1
ECM selected gear2nd
Vehicle speed2 km/h (1.2 mph) or more
Output speed2nd --> 1st down-shift point or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

CONDITION (A)

ECM selected gear4th
Vehicle speed2 km/h (1.2 mph) or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

CONDITION (B)

Current ECM selected gear5th
Last ECM selected gear4th
Vehicle speed (During transition from 4th to 5th gear)Less than 100 km/h (62.2 mph)

CONDITION (C)

ECM selected gear5th
Engine speed - Turbine speed (NE - NT) (After transition to 5th gear)150 rpm or less
Vehicle speed (After transition to 5th gear)Less than 100 km/h (62.2 mph)

CONDITION (D)

  1. Both of the following conditions are met: Condition (A), and Condition (B), (C) or (D)
Turbine speed / Output speed (NT / NO)3.30 or more, and 7.50 or less (This means actual gear is 1st)

CONDITION (A)

Turbine speed / Output speed (NT / NO)1.28 or more, and 1.53 or less (This means actual gear is 3rd)

CONDITION (B)

Turbine speed - Output speed x 4th gear ratio (NT - NO x 4th gear ratio)1000 rpm or more

CONDITION (C)

Turbine speed - Output speed x 5th gear ratio (NT - NO x 5th gear ratio)1000 rpm or more

CONDITION (D)

  1. CHECK DTC OUTPUT (IN ADDITION TO DTC P0781) Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs using the Techstream. RESULT Result Proceed to Only P0781 is output A P0781 and other DTCs are output B HINT: If any other codes besides P0781 are output, perform troubleshooting for those DTCs first. B --> See step 5 A: Go to next step
  2. PERFORM ACTIVE TEST USING TECHSTREAM (RUNNING TEST) WARNING: This test should always be performed with at least 2 people. NOTE: Perform the test while the ATF temperature is between 50 and 80°C (122 and 176°F). Perform the test with the A/C turned off. HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. HINT: While driving, the shift position can be forcibly changed with the Techstream. ENGINE AND ECT Tester Display Test Part Control Range Diagnostic Note Control the Shift Position Operate shift solenoid valves and set each shift position Press "-->" button: Shift up Press "<--" button: Shift down Possible to check operation of the shift solenoid valves. [Vehicle Condition] 50 km/h (30 mph) or less HINT: This test can be conducted when the vehicle speed is 50 km/h (30 mph) or less. The 4th to 5th and 5th to 6th up-shifts must be performed with the accelerator pedal released. The 6th to 5th and 5th to 4th down-shifts must be performed with the accelerator pedal released. Do not operate the accelerator pedal for at least 2 seconds after shifting and do not shift successively. The shift position commanded by the ECM is shown in the Data List display on the Techstream. Gear positions in the event of a solenoid valve mechanical problem: Tester gear shift command 1st 2nd 3rd 4th 5th 6th Actual gear position under malfunction 1st 1st 3rd 3rd N* N* N*: Neutral OK Gear position changes in accordance with the Techstream command. NG --> See step 6 OK: Go to next step
  3. PERFORM ACTIVE TEST USING TECHSTREAM (SHIFT SOLENOID VALVE SLT) See step 3 NG --> See step 7 OK: Go to next step
  4. CLEAR DTC AND PERFORM RUNNING TEST See step 4 NG --> See step 8 OK --> END
  5. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-524128-S24287833502013012800000)
  6. REPAIR OR REPLACE TRANSMISSION VALVE BODY ASSEMBLY. Refer to «REMOVAL»(ref-524256-S19236801412013012800000)
  7. REPLACE SHIFT SOLENOID VALVE SLT. Refer to «DISASSEMBLY - Step 3»(ref-524256-S02781877062013012800000)
  8. REPAIR OR REPLACE AUTOMATIC TRANSMISSION ASSEMBLY. Refer to «REMOVAL»(ref-524256-S08579335952013012800000)

Scheme 459

Scheme 459: DESCRIPTION

Shift solenoid valve SLT controls the transmission line pressure for smooth transmission operation based on signals from the throttle position sensor and vehicle speed sensor. The ECM adjusts the current to shift solenoid valve SLT to control the hydraulic line pressure coming from the primary regulator valve. Appropriate line pressure assures smooth shifting with varying engine outputs.

DTC CodeDTC Detection ConditionTrouble Area
P0894The ECM detects a malfunction in shift solenoid valve SLT, S1, S2, S3, S4 or SL2, or the 1-2 shift valve, or an incorrect gear 6 ratio according to the difference in speed of the turbine and output shaft, and also by the oil pressure (2-trip detection logic).Shift solenoid valve SLT remains open or closed Shift solenoid valve S1, S2, S3, S4 or SL2 remains open or closed Gear 6 incorrect ratio (sequence valve) or 1-2 shift valve is stuck Valve body is blocked Automatic transmission (clutch, brake, gear, etc.)
P2714The ECM detects a malfunction in shift solenoid valve SLT (ON side) according to the difference in speed of the turbine and output shaft, and also by the oil pressure (2-trip detection logic).Shift solenoid valve SLT remains open or closed Shift solenoid valve S1, S2, S3, S4 or SL2 remains open or closed Gear 6 incorrect ratio (sequence valve) or 1-2 shift valve is stuck Valve body is blocked Automatic transmission (clutch, brake, gear, etc.)
Related DTCsP0894: Automatic transmission slip malfunction P2714: Shift solenoid valve SLT/Functional check
Required sensors/ComponentsShift solenoid valve SLT
Frequency of operationContinuous
DurationP0894 ON malfunction (A): Immediate P0894 ON malfunction (B): 0.4 seconds P2714: Immediate
MIL operation2 driving cycles
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentP0717 (Turbine speed sensor circuit) P0500 (Output speed sensor circuit) P0712, P0713 (ATF temperature sensor circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit)
Shift solenoid valve S1 circuitNot circuit malfunction
Shift solenoid valve S2 circuitNot circuit malfunction
Shift solenoid valve S3 circuitNot circuit malfunction
Shift solenoid valve S4 circuitNot circuit malfunction
Shift solenoid valve SR circuitNot circuit malfunction
Shift solenoid valve SL1 circuitNot circuit malfunction
Shift solenoid valve SL2 circuitNot circuit malfunction
Shift solenoid valve SLT circuitNot circuit malfunction
ECT (Engine Coolant Temperature) sensor circuitNot circuit malfunction
ETCS (Electric Throttle Control System)Not system down
Transmission position"D"
Duration time from shifting "N" to "D"4 seconds or more
ECT40°C (104°F) or higher
Spark advance from max. retard timing by KCS control0° crankshaft angle or more
EngineStarting
Transfer positionHIGH*

ALL

HINT

*: Following conditions are met

Vehicle speed sensor "A" circuitNot circuit malfunction
Transfer output speed143 rpm or more
Transfer input speed / Transfer output speed (NO / NOtf)0.9 or more, and less than 1.1

[P0894: ON malfunction]

  1. When either condition below is met: ON malfunction (A) or (B)
Summation of C1 clutch heat generationsSpecified value

ON MALFUNCTION (A)

Summation of C2 clutch heat generationsSpecified value
Actual gear for SLT failure judgmentNot determined

ON MALFUNCTION (B)

[P2714: ON malfunction]

  1. One of the following conditions is met: ON malfunction (A), (B), (C), (D), (E), (F), (G) or (H)
Summation of C1 clutch heat generationsSpecified value

ON MALFUNCTION (A)

Shift solenoid valve S1 OFF malfunctionDetected

ON MALFUNCTION (B)

Shift solenoid valve S2 OFF malfunctionDetected

ON MALFUNCTION (C)

Shift solenoid valve S3 ON malfunctionDetected

ON MALFUNCTION (D)

Shift solenoid valve S4 OFF malfunctionDetected

ON MALFUNCTION (E)

1-2 shift valve malfunctionDetected

ON MALFUNCTION (F)

Sequence valve malfunctionDetected

ON MALFUNCTION (G)

Shift solenoid valve SL2 ON malfunctionDetected

ON MALFUNCTION (H)

Related DTCsP0973: Shift solenoid valve S1/Range check (Low resistance) P0974: Shift solenoid valve S1/Range check (High resistance)
Required sensors/ComponentsShift solenoid valve S1
Frequency of operationContinuous
Duration0.128 seconds or more
MIL operationImmediate
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentNone
Battery voltage8 V or higher
Engine switchOn (IG)
StarterOFF

ALL

Shift solenoid valve S1ON

P0973: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve S1OFF

P0974: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve S1 resistance8 ohms or less

P0973: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve S1 resistance100 kohms or higher

P0974: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve S1 resistance11 to 15 ohms at 20°C (68°F)

Scheme 460

Scheme 460: WIRING DIAGRAM
Related DTCsP0976: Shift solenoid valve S2/Range check (Low resistance) P0977: Shift solenoid valve S2/Range check (High resistance)
Required sensors/ComponentsShift solenoid valve S2
Frequency of operationContinuous
Duration0.128 seconds or more
MIL operationImmediate
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentNone
Battery voltage8 V or higher
Engine switchOn (IG)
StarterOFF

ALL

Shift solenoid valve S2ON

P0976: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve S2OFF

P0977: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve S2 resistance8 ohms or less

P0976: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve S2 resistance100 kohms or higher

P0977: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve S2 resistance11 to 15 ohms at 20°C (68°F)

Scheme 461

Scheme 461: WIRING DIAGRAM
Related DTCsP0979: Shift solenoid valve S3/Range check (Low resistance) P0980: Shift solenoid valve S3/Range check (High resistance)
Required sensors/ComponentsShift solenoid valve S3
Frequency of operationContinuous
Duration0.128 seconds or more
MIL operationImmediate
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentNone
Battery voltage8 V or higher
Engine switchOn (IG)
StarterOFF

ALL

Shift solenoid valve S3ON

P0979: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve S3OFF

P0980: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve S3 resistance8 ohms or less

P0979: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve S3 resistance100 kohms or higher

P0980: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve S3 resistance11 to 15 ohms at 20°C (68°F)

Scheme 462

Scheme 462: WIRING DIAGRAM
Related DTCsP0982: Shift solenoid valve S4/Range check (Low resistance) P0983: Shift solenoid valve S4/Range check (High resistance)
Required sensors/ComponentsShift solenoid valve S4
Frequency of operationContinuous
Duration0.128 seconds or more
MIL operationImmediate
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentNone
Battery voltage8 V or higher
Engine switchOn (IG)
StarterOFF

ALL

Shift solenoid valve S4ON

P0982: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve S4OFF

P0983: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve S4 resistance8 ohms or less

P0982: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve S4 resistance100 kohms or higher

P0983: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve S4 resistance11 to 15 ohms at 20°C (68°F)

Scheme 463

Scheme 463: WIRING DIAGRAM
Related DTCsP0985: Shift solenoid valve SR/Range check (Low resistance) P0986: Shift solenoid valve SR/Range check (High resistance)
Required sensors/ComponentsShift solenoid valve SR
Frequency of operationContinuous
Duration0.128 seconds or more
MIL operationImmediate
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentNone
Battery voltage8 V or higher
Engine switchOn (IG)
StarterOFF

ALL

Shift solenoid valve SRON

P0985: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve SROFF

P0986: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve SR resistance8 ohms or less

P0985: RANGE CHECK (LOW RESISTANCE)

Shift solenoid valve SR resistance100 kohms or higher

P0986: RANGE CHECK (HIGH RESISTANCE)

Shift solenoid valve SR resistance11 to 15 ohms at 20°C (68°F)

Scheme 464

Scheme 464: WIRING DIAGRAM
Related DTCsP2716: Shift solenoid valve SLT/Range check
Required sensors/ComponentsShift solenoid valve SLT
Frequency of operationContinuous
Duration1 second
MIL operationImmediate
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentNone
Solenoid current cut statusNot cut
Battery voltage11 V or higher
Engine switchOn (IG)
StarterOFF
Output signalNo signal
Output signal dutyLess than 100%

Scheme 465

Scheme 465: WIRING DIAGRAM
Related DTCsP2757: Shift solenoid valve SLU/Functional check
Required sensors/ComponentsShift solenoid valve SLU
Frequency of operationContinuous
DurationOFF malfunction (A) 2 seconds OFF malfunction (B) 0.4 seconds ON malfunction 1.8 seconds
MIL operation2 driving cycles
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentP0717 (Turbine speed sensor circuit) P0500 (Output speed sensor circuit) P0327, P0328, P0332, P0333 (KCS sensor circuit)
Shift solenoid valve S1 circuitNot circuit malfunction
Shift solenoid valve S2 circuitNot circuit malfunction
Shift solenoid valve S3 circuitNot circuit malfunction
Shift solenoid valve S4 circuitNot circuit malfunction
Shift solenoid valve SR circuitNot circuit malfunction
Shift solenoid valve SLU circuitNot circuit malfunction
Shift solenoid valve S1 circuitNot off malfunction
Shift solenoid valve S3 circuitNot on malfunction
Shift solenoid valve S4 circuitNot off malfunction
Shift solenoid valve SL2 circuitNot on malfunction
1 - 2 shift valveNo malfunction
Sequence valveNo malfunction
ETCS (Electric Throttle Control System)Not system down
Transmission position"D"
Duration time from shifting "N" to "D"4 seconds or more
ECT40°C (104°F) or higher
Spark advance from max. retard timing by KCS control0° crankshaft angle or more
EngineStarting
ECM selected gear2nd, 3rd, 4th, 5th or 6th
Vehicle speed25 km/h (15.5 mph) or more
Transfer positionHIGH*

ALL

HINT

*: Following conditions are met

Vehicle speed sensor "A" circuitNot circuit malfunction
Output shaft speed sensor circuitNot circuit malfunction
Transfer output speed143 rpm or more
Transfer input speed / Transfer output speed (NO / NOtf)0.9 or more, and less than 1.1
ECM lock-up commandON (SLU pressure: 513 kPa (5.2 kgf/cm 2 , 74 psi) or more)
Duration time from lock-up on command3 seconds or more
Vehicle speedLess than 120 km/h (74.6 mph)

OFF MALFUNCTION (A)

ECM selected gear2nd
Vehicle speed2 km/h (1.2 mph) or more
Output speed2nd --> 1st down-shift point or more
Throttle valve opening angle6.6% or more at 2000 rpm (Conditions vary with engine speed)

OFF MALFUNCTION (B)

ECM lock-up commandOFF (SLU pressure: Less than 4 kPa (0.04 kgf/cm 2 , 0.6 psi))
Duration time from lock-up off command3 seconds or more
Throttle valve opening angle6% or more
Vehicle speedLess than 120 km/h (74.6 mph) in 2nd gear (Varies with ECM selected gear)

ON MALFUNCTION

[OFF malfunction]

  1. Both of the following conditions are met: OFF malfunction (A) and (B)
Engine speed - Turbine speed (NE - NT)70 rpm or more

OFF MALFUNCTION (A)

Turbine speed / Output speed (NT / NO)Less than 3.30 or more than 7.50

OFF MALFUNCTION (B)

[ON malfunction]

  1. 2 detections are necessary per driving cycle
  2. 1st detection: temporary flag ON
  3. 2nd detection: pending fault code ON
  4. Vehicle speed must be under 10 km/h (6.2 mph) once before 2nd detection.
Engine speed - Turbine speed (NE - NT)Less than 35 rpm

ON MALFUNCTION

Speed sensor (NT)Input speed is equal to engine speed when lock-up ON.
Related DTCsP2759: Shift solenoid valve SLU/Range check
Required sensors/ComponentsShift solenoid valve SLU
Frequency of operationContinuous
Duration1 second
MIL operationImmediate
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentNone
Solenoid current cut statusNot cut
Battery voltage11 V or higher
Engine switchOn (IG)
StarterOFF
Solenoid status from MICFailure
Output signal dutyLess than 100%

Scheme 466

Scheme 466: WIRING DIAGRAM
Related DTCsP2772: Transfer L4 position switch/Functional check
Required sensors/ComponentsTransfer L4 position switch
Frequency of operationContinuous
DurationON malfunction (A): 1.8 seconds ON malfunction (B): 0.5 seconds
MIL operation1 driving cycle
Sequence of operationNone
The monitor will run whenever the following DTCs are not presentP0500 (Vehicle speed sensor "A" circuit)
Output speed sensor circuitNot circuit malfunction
Transfer neutral position switchOFF

ALL

Output speed (Transfer output speed)1000 to 3000 rpm

ON MALFUNCTION (A)

Output speed (Transfer output speed)143 rpm or more

ON MALFUNCTION (B)

Both of the following conditions are met: ON malfunction (A) and (B)

L4 switchON

ON MALFUNCTION (A)

Actual transfer gear ratio Transfer input speed / Transfer output speed0.9 or more, and less than 1.1

ON MALFUNCTION (B)

Scheme 467

Scheme 467: WIRING DIAGRAM
