AVC-LAN WIRING DIAGRAM
HINT
If any DTCs are simultaneously output for 2 or more slave units that are connected in series, there may be a problem between the master unit and the slave unit which is closest to the master unit. Therefore, first proceed with troubleshooting of that slave unit.
For example, if DTCs are output for the radio receiver assy and stereo component amplifier assy, there may be a problem between the master unit and radio receiver assy. ( (Scheme 246)and (Scheme 247) below.)
Scheme 246
Scheme 247
HINT
Titles for each unit are stated in the following order: part name (physical address) [Name indicated by DTC]
Scheme 248
Scheme 249
Scheme 250
Scheme 251
Scheme 252
Scheme 253
Scheme 254
Scheme 255
Scheme 256
Scheme 257
Scheme 258
Scheme 259
Scheme 260
- MULTI-DISPLAY (physical address: 110) [EMV] Logical address: 01 (Communication control) LOGICAL ADDRESS DESCRIPTION DTC Name Diagnosis Verification Reference D5 (1) (5) Absence of registration unit The device indicated by the sub code is (was) disconnected from the system when turning the ignition switch to the ACC or ON position. The communication condition with the device indicated by the code cannot be obtained when the engine starts. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 D8 (2) (5) No response to connection check The device indicated by the sub code is (was) disconnected from the system after engine start. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 D9 (1) (5) Last mode error The device (for audio visual system) that had functioned before the engine stopped is (was) disconnected from the system when the ignition switch is (was) in the ACC or ON position. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 DA (5) No response to ON/OFF command No response is identified when changing mode (audio and visual mode change). Sound and image do not change by switch operation. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 DB (1) (5) Mode status error A dual alarm is detected. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 DC (3) (5) Failure in transmission A transmission failure to the device indicated by the sub code is detected. NOTE: This DTC may have no direct relationship with the malfunction. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 DE (4) (5) Slave reset A slave device has been disconnected after engine start. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 21 ROM error A malfunction exists in ROM. Replace multi-display «MULTI-DISPLAY (CRT DISPLAY) DISPLAY»(ref-228804-S08378569802006041100000) 22 RAM error A malfunction exists in RAM. Replace multi-display «MULTI-DISPLAY (CRT DISPLAY) DISPLAY»(ref-228804-S08378569802006041100000) (1) This code may be stored depending on the battery condition or engine start voltage even if no failure is detected. (2) If the power connector is disconnected after the engine starts, this code is stored after 180 seconds. (3) This code may be stored if the ignition key is turned to the START position again with the engine running. (4) this code may be stored if the ignition key is held in the start position for 1 minute or more before returning to the on position. (5) If the device is reported as not existing during verification, check the power source circuit and AVC-LAN circuit for the device. Logical address: 21 (SW): 23 (SW with name): 24 (SW converting): 25 (command SW) LOGICAL ADDRESS DESCRIPTION DTC Name Diagnosis Verification Reference 10 Panel switch error The panel SW detection circuit has a failure. Replace multi-display «MULTI-DISPLAY (CRT DISPLAY) DISPLAY»(ref-228804-S08378569802006041100000) 11 Touch switch error Error in touch switch sensor is detected. Replace multi-display «MULTI-DISPLAY (CRT DISPLAY) DISPLAY»(ref-228804-S08378569802006041100000)
- NAVIGATION ECU (Physical address: 178) [NAVI] NOTE: Any vehicle except those not equipped with either the RSE or back monitor system: The following inspection procedures of the navigation ECU are described on the assumption that the television camera ECU (w/o RSE) or multi-display controller sub-assy (w/ RSE) is normal. If any television camera ECU (w/o RSE) DTC or multi-display controller sub-assy (w/ RSE) DTC is output, first proceed with troubleshooting of the television camera ECU (w/o RSE) or multi-display controller sub-assy (w/ RSE). (Refer to step 5 or 7 .) Logical address: 01 (Communication control) HINT: Methods used to verify the cause of the problem are listed in order of probability in the verification column. HINT: *1: Even if no failure is detected, this code may be stored depending on the battery condition or engine start voltage. *2: If the power connector is disconnected after the engine starts, this code is stored after 180 seconds. *3: This code may be stored if the ignition key is turned to the START position again after the engine starts. *4: This code may be stored if the ignition key is held in the START position for one minute or more before returning to the ON position. *5: If the device is reported as not existing during verification, check the power source circuit and AVC-LAN circuit for the device. Logical address: 58 (Navigation): 80 (GPS) HINT: Methods used to verify the cause of the problem are listed in order of probability in the verification column.
- RADIO RECEIVER ASSY (Physical address: 190) [AUDIO H/U] Logical address: 01 (Communication control) HINT: Methods used to verify the cause of the problem are listed in order of probability in the verification column. Logical address: 01 (Communication control) LOGICAL ADDRESS DESCRIPTION DTC Name Diagnosis Verification Reference D5 (1) (5) Absence of registration unit The device indicated by the sub code is (was) disconnected from the system when turning the ignition switch to the ACC or ON position. The communication condition with the device indicated by the code cannot be obtained when the engine starts. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 D8 (2) (5) No response to connection check The device indicated by the sub code is (was) disconnected from the system after engine start Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 D9 (1) (5) Last mode error The device (for audio visual system) that had functioned before the engine stopped is (was) disconnected from the system when the ignition switch is (was) in the ACC or ON position. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 DA (5) No response to ON/OFF command No response is identified when changing mode (audio and visual mode change). Sound and image do not change by switch operation. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 DB (1) (5) Mode status error A dual alarm is detected. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 DC (3) (5) Failure in transmission A transmission failure to the device indicated by the sub code. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 DC (3) (5) Failure in transmission NOTE: This DTC may have no direct relationship with the malfunction. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 DE (4) (5) Slave reset A slave device has been disconnected after engine start. Inspection for the device indicated by the sub code. (Refer to the inspection list for the device indicated by the sub code.) Refer to step 9 21 ROM error A malfunction exists in ROM. Replace radio receiver assy «RADIO RECEIVER ASSY»(ref-228804-S20905580902006041100000) 22 RAM error A malfunction exists in RAM. Replace radio receiver assy «RADIO RECEIVER ASSY»(ref-228804-S20905580902006041100000) (1) Even if no failure is detected, this code may be stored depending on the battery condition or engine start voltage. (2) If the power connector is disconnected after the engine starts, this code is stored after 180 seconds. (3) This code may be stored if the ignition key is turned to the START position again after the engine starts. (4) This code may be stored if the ignition key is held in the START position for one minute or more before returning to the ON position. (5) If the device is reported as not existing during verification, check the power source circuit and AVC-LAN circuit for the device. Logical address: 62 (CD): 63 (In-dash CD changer) HINT: Methods used to verify the cause of the problem are listed in order of probability in the verification column. Logical address: 61 (Cassette) HINT: Methods used to verify the cause of the problem are listed in order of probability in the verification column.
- GATEWAY ECU (Physical address: 1C6) [G/W] Logical address: 01 (Communication control) HINT: Methods used to verify the cause of the problem are listed in order of probability in the verification column. HINT: This code is stored 210 seconds after the power supply connector of the master component is disconnected with the ignition switch in the ACC or ON position.
- TELEVISION CAMERA ECU (Physical address: 280) [CAMERA] Logical address: 01 (Communication control) HINT: Methods used to verify the cause of the problem are listed in order of probability in the verification column. Logical address: 5C (Camera) HINT: Methods used to verify the cause of the problem are listed in order of probability in the verification column.
- STEREO COMPONENT AMPLIFIER ASSY (Physical address: 440) [DSP AMP] NOTE: The following inspection procedures of the stereo component amplifier assy are described on the assumption that the radio receiver assy is normal. If any radio receiver assy DTC is output, first proceed with troubleshooting of the radio receiver assy. (Refer to step 3 .) Logical address: 01 (Communication control) HINT: Methods used to verify the cause of the problem are listed in order of probability in the verification column.
- MULTI-DISPLAY CONTROLLER SUB-ASSY (Physical address: 1F6) [RSE ECU] NOTE: The following inspection procedures of the multi-display controller sub-assy are described on the assumption that the radio receiver assy is normal. If any radio receiver assy DTC is output, first proceed with troubleshooting of the radio receiver assy. (Refer to step 3 .) Logical address: 01 (Communication control) HINT: Methods used to verify the cause of the problem are listed in order of probability in the verification column.
- STEREO COMPONENT CONTROLLER ASSY (Physical address: 1F4) [RSA] NOTE: The following inspection procedures of the stereo component controller assy are described on the assumption that the radio receiver assy is normal. If any radio receiver assy DTC is output, first proceed with troubleshooting of the radio receiver assy. (Refer to step 3 .) Logical address: 01 (Communication control) HINT: Methods used to verify the cause of the problem are listed in order of probability in the verification column.
- THE INSPECTION LIST FOR THE DEVICE INDICATED BY THE SUB CODE HINT: If any DTCs are output for 2 or more slave units that are connected in series, there may be a problem between the master unit and the slave unit which is closest to the master unit. Therefore, first proceed with troubleshooting of that slave unit. Methods used to verify the cause of the problem are listed in order of probability in the verification column.
