Lighting: Removal & Installation Lexus GX J120

REPLACEMENT

HINT

See COMPONENTS

Scheme 81

Scheme 82

Scheme 83

1. REMOVE RADIATOR SUPPORT SEAL UPPER (SEE «RADIATOR ASSY (2UZ-FE)»(/lexus/gx/j120-2002-2009/remont/cooling-system-mechanical/#cooling) )
2. REMOVE FRONT BUMPER GUARD (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
3. REMOVE FRONT FENDER LINER RH (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
4. REMOVE FRONT FENDER LINER LH (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
5. REMOVE FRONT BUMPER COVER (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
6. REMOVE LH HEADLAMP ASSY Remove the 3 screws. Disconnect the each connector. Pull out the headlamp unit forward, then disengage the bracket on the body side.
7. REMOVE HEADLAMP, NO. 1 BULB Rotate the headlamp No. 1 bulb in the direction of the arrow and pull it off toward the rear of the vehicle.
8. REMOVE HEADLAMP, NO. 2 BULB Rotate the headlamp No. 2 bulb in the direction of the arrow and pull it off toward the rear of the vehicle.
9. REMOVE HOOD TO FRONT END PANEL SEAL NO. 1
10. REMOVE HEADLAMP UNIT ASSY LH Remove the headlamp cord with 3 bulbs Remove the headlamp unit assy LH.
11. INSTALL FRONT FENDER LINER RH (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
12. INSTALL FRONT FENDER LINER LH (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
13. ADJUST HEADLIGHT AIM ONLY (See «ADJUSTMENT»(ref-228802-S30748407702006041100000) )
14. PUT VEHICLE THESE CONDITIONS (See «ADJUSTMENT»(ref-228802-S29782066172006041100000) )
15. ADJUST FOG LIGHT AIM (See «ADJUSTMENT»(ref-228802-S29782066172006041100000) )

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

1. ADJUST HEADLIGHT AIM ONLY HINT: Perform the headlight aiming adjustment with Low beam. Since the Low-beam light or High-beam light is a unit, if either aiming of them is proper, the other should also be proper. However, check the both beams just to make sure. Prepare vehicle in the following conditions. Any damages or deformations does not exist around the headlight. Fuel is full. Tire inflation pressure is in the specified level. The vehicle is parked on a level surface. A person with standard weight sit on the driver seat. The vehicle is bounced up and down to stabilize the suspension to the normal position. Prepare a thick white paper (Draw a based line). HINT: Stand the paper perpendicular to the ground. The based line differs in "Low-beam inspection" and "High-beam inspection". H line (Headlight height) For the vehicle, when checking the height from the ground to the center mark of Low-beam (or High-beam), draw a horizontal line A-B at the height of Low-beam (or High-beam). V LH line, V RH line (Center mark position of right and left head lamp) Draw a V LH line and V RH line in the width of the center mark of the right and left Low-beam (when checking High-beam, draw a V LH line and V RH line in the width of the center mark of the right and left Hi-beam). V line (Vehicle Center position) At the middle of the V LH line and V RH line, draw a line to align the center of the paper with that of the vehicle. Check the headlight aiming. Align the paper with the vehicle position. Make a distance of 3 m (9.84 ft) between the head lamp and the paper, and put the paper on the wall with the H line being at the height of the center mark. Align the center line of the vehicle with the V line on the paper, and make the center line of the vehicle and the paper 90 degrees. Start the engine of the vehicle with air suspension. Turn the headlight on and check that the aiming is between the specified values. HINT: When checking the aiming of the High-beam, shut off the Low-beam or disconnect the Low-beam head lamp connector so that the Low-beam does not interrupt. Unlock the headlight aiming cap (Scheme 88) When adjusting the aiming in the vertical direction. Using adjusting bolt A, adjust the headlight aim to the specified range. HINT: Turning a screwdriver clockwise makes the optical axis aim downward and turning it counter clockwise makes it upward. When adjusting the aiming in the horizontal direction. Using adjusting bolt B, adjust the headlight aim to the specified range.

Scheme 90

Scheme 91

1. REMOVE RADIATOR SUPPORT SEAL UPPER (SEE «RADIATOR ASSY (2UZ-FE)»(/lexus/gx/j120-2002-2009/remont/cooling-system-mechanical/#cooling) )
2. REMOVE FRONT BUMPER GUARD (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
3. REMOVE FRONT FENDER LINER RH (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
4. REMOVE FRONT FENDER LINER LH (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
5. REMOVE FRONT BUMPER COVER (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
6. REMOVE FOG LAMP UNIT LH Remove the screw. Disengage the claw and remove the fog lamp assy. Remove the fog lamp cover and the fog lamp bulb.
7. INSTALL FRONT FENDER LINER RH (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
8. INSTALL FRONT FENDER LINER LH (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
9. PUT VEHICLE THESE CONDITIONS (See «ADJUSTMENT»(ref-228802-S29782066172006041100000) )
10. ADJUST FOG LIGHT AIM (See «ADJUSTMENT»(ref-228802-S29782066172006041100000) )

Scheme 92

1. REMOVE FRONT FENDER LINER LH (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )
2. PUT VEHICLE THESE CONDITIONS Tire inflation pressure is in the specified value. (See «WHEEL AND TIRE SYSTEM»(ref-228790-S11193813852006041100000) ) Engine is running.
3. ADJUST FOG LIGHT AIM Adjust the fog light aiming by moving the aiming screw in the vertical direction.
4. INSTALL FRONT FENDER LINER LH (SEE «REPLACEMENT»(ref-228812-S26815643742006041100000) )

Scheme 93

1. REMOVE REAR COMBINATION LAMP ASSY LH Remove the 2 bolts and release the 2 claws. Disconnect the connector and remove the rear combination lamp assy LH.
2. REMOVE REAR COMBINATION LAMP LENS LH Remove the 3 sockets with 3 bulbs.

Scheme 94

Scheme 95

1. REMOVE BACK DOOR GARNISH CENTER (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
2. REMOVE BACK DOOR SIDE GARNISH RH (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
3. REMOVE BACK DOOR SIDE GARNISH LH (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
4. REMOVE TOOL BOX PANEL SUB-ASSY UPPER (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
5. REMOVE DOOR PULL HANDLE SUB-ASSY (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
6. REMOVE BACK DOOR TRIM BOARD (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
7. REMOVE BACK DOOR SERVICE HOLE COVER (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
8. REMOVE LICENSE REAR LAMP COVER (SEE «BACK DOOR GARNISH SUB-ASSY OUTSIDE»(ref-228812-S39805326622006041100000) )
9. REMOVE BACK DOOR OUTSIDE GARNISH Disconnect the connectors. Remove the 4 nuts. Release the 5 clips, and remove the back door outside garnish.
10. REMOVE BACK-UP LAMP LENS & BODY LH Remove the back up lamp body gasket LH. Remove the socket with the bulb. Release the 2 claws and remove the back-up lamp lens & body LH.

Scheme 96

1. REMOVE LICENSE PLATE LAMP LENS Disconnect the connector. Remove the license plate lamp assy (Scheme 96) Remove the license plate lamp socket and the wire with the license plate lamp bulb from license plate lamp lens.

Scheme 97

1. REMOVE CENTER STOP LAMP ASSY Using a clip remover wrapped around with the protective tape, disengage the 4 claws on the bottom side. Disengage the 4 claws on the upper side and pull the center stop lamp assy. Disconnect the connector and remove the center stop lamp assy.

Scheme 98

1. REMOVE REAR NO. 2 SEAT ASSY LH (SEE «OVERHAUL»(ref-228808-S27930267532006041100000) )
2. REMOVE QUARTER SCUFF PLATE INSIDE LH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
3. REMOVE REAR DOOR SCUFF PLATE LH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
4. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
5. REMOVE BACK DOOR WEATHERSTRIP
6. REMOVE REAR FLOOR MAT SUPPORT PLATE REAR (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
7. REMOVE PACKAGE TRAY TRIM PANEL ASSY (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
8. REMOVE QUARTER INSIDE TRIM BOARD LH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
9. REMOVE ROOF SIDE GARNISH INNER LH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
10. REMOVE TOWING CONVERTER RELAY Disconnect the connector. Remove the bolt and the towing converter relay.
11. INSTALL ROOF SIDE GARNISH INNER LH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
12. INSTALL REAR NO. 2 SEAT ASSY LH (SEE «OVERHAUL»(ref-228808-S27930267532006041100000) )

Scheme 99

1. REMOVE NO. 3 WIRE FRAME Disconnect the connector. Release the clamp and remove the 2 bolts and the No. 3 wire frame.

Scheme 100

1. REMOVE STEERING COLUMN COVER (SEE «OVERHAUL»(ref-228797-S36379552682006041100000) )
2. REMOVE HEADLAMP DIMMER SWITCH ASSY Disconnect the connector. Remove the 2 screws and the headlamp dimmer switch assy.
3. INSTALL STEERING COLUMN COVER (SEE «OVERHAUL»(ref-228797-S36379552682006041100000) )
