Audio & Visual System: Removal & Installation Lexus GX J120

Entertainment Systems 70 illustrations ~4032 words

REPLACEMENT

HINT

See LOCATION

Scheme 171

Scheme 171: REPLACEMENT
Scheme 171: REPLACEMENT

Scheme 172

Scheme 172
Scheme 172

Scheme 173

Scheme 173
Scheme 173

Scheme 174

Scheme 174
Scheme 174

Scheme 175

Scheme 175
Scheme 175
  1. REMOVE CONSOLE UPPER PANEL GARNISH NO.2 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  2. REMOVE CONSOLE UPPER PANEL GARNISH NO.1 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  3. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY LH (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  4. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY RH (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  5. REMOVE INTEGRATION CONTROL & PANEL ASSY (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  6. REMOVE RADIO BRACKET NO. 1 Remove the 5 screws. Remove the screw. Release the 2 claws and remove the radio bracket No.1.
  7. REMOVE RADIO BRACKET NO.2 Remove the 5 screws. Remove the screw. Release the 2 claws and remove the radio bracket No.2.
  8. REMOVE RADIO RECEIVER ASSY w/o EMV: Release the 3 claws and remove the radio receiver assy. w/ EMV: Release the 4 claws and remove the radio receiver assy.

HINT

See LOCATION

Scheme 176

Scheme 176: REPLACEMENT
Scheme 176: REPLACEMENT
  1. REMOVE CONSOLE UPPER PANEL GARNISH NO.2 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  2. REMOVE CONSOLE UPPER PANEL GARNISH NO.1 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  3. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY LH (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  4. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY RH (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  5. REMOVE INTEGRATION CONTROL & PANEL ASSY (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  6. REMOVE RADIO BRACKET NO.1 (SEE «REPLACEMENT»(ref-228804-S26983311292006041100000) )
  7. REMOVE RADIO BRACKET NO.2 (SEE «REPLACEMENT»(ref-228804-S26983311292006041100000) )
  8. REMOVE MULTI-DISPLAY (CRT DISPLAY) DISPLAY Release the 2 claws and remove the multi-display.

HINT

See LOCATION.

Scheme 177

Scheme 177: REPLACEMENT
Scheme 177: REPLACEMENT

Scheme 178

Scheme 178
Scheme 178

Scheme 179

Scheme 179
Scheme 179

Scheme 180

Scheme 180
Scheme 180
  1. REMOVE FRONT LH SEAT ASSY (SEE «OVERHAUL»(ref-228808-S19466326792006041100000) )
  2. REMOVE STEREO COMPONENT AMPLIFIER ASSY W/ BRACKET (MARK LEVINSON AMPLIFIER TYPE) Remove the 2 screws and bolt. Disconnect the connectors and remove the stereo component amplifier assy w/ bracket.
  3. REMOVE AMPLIFIER COVER (MARK LEVINSON AMPLIFIER TYPE) Remove the 4 screws and amplifier cover.
  4. REMOVE AMPLIFIER BRACKET NO.1 (MARK LEVINSON AMPLIFIER TYPE) Remove the 2 screws and amplifier bracket No.1.
  5. REMOVE AMPLIFIER BRACKET NO.1 (MARK LEVINSON AMPLIFIER TYPE) Remove the 2 screws and amplifier bracket No.1.
  6. REMOVE STEREO COMPONENT AMPLIFIER ASSY (EXCEPT MARK LEVINSON AMPLIFIER TYPE) Remove the 2 screws and bolt. Disconnect the connectors and remove the stereo component amplifier assy.
  7. INSTALL FRONT LH SEAT ASSY (SEE «OVERHAUL»(ref-228808-S19466326792006041100000) )

HINT

See LOCATION

Scheme 181

Scheme 181: REPLACEMENT
Scheme 181: REPLACEMENT

Scheme 182

Scheme 182
Scheme 182
  1. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  2. REMOVE FRONT DOOR INSIDE HANDLE BEZEL LH (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  3. REMOVE FRONT ARMREST ASSY LH (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  4. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSY (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  5. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  6. REMOVE FRONT NO.1 SPEAKER ASSY Disconnect the connector. Remove the 4 screws and front No.1 speaker assy.
  7. INSTALL FRONT NO.1 SPEAKER ASSY Install the front No.1 speaker assy with the 4 screws. NOTE: Install the screws in the order (Scheme 182) Connect the connector.

HINT

See LOCATION.

Scheme 183

Scheme 183: REPLACEMENT
Scheme 183: REPLACEMENT
  1. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  2. REMOVE FRONT DOOR INSIDE HANDLE BEZEL LH (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  3. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSY (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  4. REMOVE FRONT ARMREST ASSY LH (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  5. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  6. REMOVE FRONT NO.2 SPEAKER ASSY Disconnect the connector. Remove the 2 clamps. Remove the 2 screws and front No.2 speaker assy.

HINT

See LOCATION.

Scheme 184

Scheme 184: REPLACEMENT
Scheme 184: REPLACEMENT

Scheme 185

Scheme 185
Scheme 185
  1. REMOVE REAR DOOR INSIDE HANDLE BEZEL LH (SEE «OVERHAUL»(ref-228811-S42066552342006041100000) )
  2. REMOVE REAR LH ARMREST ASSY (SEE «OVERHAUL»(ref-228811-S42066552342006041100000) )
  3. REMOVE POWER WINDOW REGULATOR SWITCH ASSY REAR (SEE «OVERHAUL»(ref-228811-S42066552342006041100000) )
  4. REMOVE REAR DOOR TRIM BOARD SUB-ASSY LH (SEE «OVERHAUL»(ref-228811-S42066552342006041100000) )
  5. REMOVE REAR SPEAKER ASSY Disconnect the connector. Remove the 3 screws and rear speaker assy.
  6. INSTALL REAR SPEAKER ASSY Install the rear speaker assy with the 3 screws. NOTE: Install the screws in the order (Scheme 185) Connect the connector.

HINT

See LOCATION.

Scheme 186

Scheme 186: REPLACEMENT
Scheme 186: REPLACEMENT
  1. TABLE OF BOLT, SCREW AND NUT
  2. DISCONNECT BATTERY NEGATIVE TERMINAL
  3. REMOVE SHIFT LEVER KNOB SUB-ASSY
  4. REMOVE SHIFT LEVER KNOB SUB-ASSY
  5. REMOVE CONSOLE UPPER PANEL GARNISH NO.2
  6. REMOVE CONSOLE UPPER PANEL GARNISH NO.1
  7. REMOVE CONSOLE PANEL UPPER ASSY
  8. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY LH
  9. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY RH
  10. REMOVE INSTRUMENT CLUSTER FINISH PANEL CENTER LOWER
  11. REMOVE INTEGRATION CONTROL & PANEL ASSY
  12. REMOVE CONSOLE REAR END PANEL SUB-ASSY
  13. REMOVE RR CONSOLE BOX ASSY
  14. REMOVE CONSOLE BOX INSERT FRONT NO.2
  15. REMOVE CONSOLE BOX INSERT
  16. REMOVE CONSOLE UPPER PANEL GARNISH FRONT
  17. REMOVE CONSOLE BOX LOWER
  18. REMOVE STEERING WHEEL COVER LOWER NO.2
  19. REMOVE STEERING WHEEL COVER LOWER NO.3
  20. REMOVE HORN BUTTON ASSY
  21. REMOVE STEERING WHEEL ASSY SST 09950-50013 (09951-05010, 09952-05010, 09953-05020, 09954-05021)
  22. REMOVE STEERING COLUMN COVER
  23. REMOVE TURN SIGNAL SWITCH ASSY W/ SPIRAL CABLE SUB-ASSY
  24. REMOVE FRONT DOOR SCUFF PLATE LH
  25. REMOVE FRONT DOOR SCUFF PLATE RH
  26. REMOVE FRONT FLOOR FOOTREST
  27. REMOVE COWL SIDE TRIM BOARD LH
  28. REMOVE COWL SIDE TRIM BOARD RH
  29. REMOVE INSTRUMENT PANEL UNDER COVER SUB-ASSY NO.1
  30. REMOVE INSTRUMENT CLUSTER FINISH PANEL ORNAMENT
  31. REMOVE SWITCH HOLE BASE NO.1
  32. REMOVE INSTRUMENT PANEL FINISH PLATE
  33. REMOVE INSTRUMENT PANEL FINISH LOWER PANEL RH
  34. REMOVE INSTRUMENT PANEL LOWER LH
  35. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY
  36. REMOVE COMBINATION METER ASSY
  37. REMOVE INSTRUMENT PANEL REGISTER ASSY NO.1
  38. REMOVE INSTRUMENT PANEL UNDER COVER NO.2
  39. REMOVE GLOVE COMPARTMENT DOOR SUB-ASSY
  40. REMOVE INSTRUMENT PANEL ORNAMENT
  41. DISCONNECT PASSENGER AIRBAG CONNECTOR
  42. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER NO.2
  43. REMOVE INSTRUMENT PANEL REGISTER ASSY NO.2
  44. REMOVE DISC PLAYER CHANGER W/BRACKET (W/ DISC PLAYER CHANGER)
  45. REMOVE ASSIST GRIP ASSY
  46. REMOVE FRONT PILLAR GARNISH LH
  47. REMOVE FRONT PILLAR GARNISH RH
  48. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/ DEFROSTER NOZZLE DUCT (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  49. REMOVE STEREO COMPONENT SPEAKER ASSY FRONT Disconnect the connector. Remove the 2 screws and stereo component speaker assy front.
  50. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/ DEFROSTER NOZZLE DUCT (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  51. INSTALL COMBINATION METER ASSY
  52. ADJUST SPIRAL CABLE SUB-ASSY
  53. INSTALL STEERING WHEEL ASSY
  54. INSTALL HORN BUTTON ASSY
  55. INSPECT HORN BUTTON ASSY
  56. INCLINATION SENSOR CORRECTION
  57. INSPECT SRS WARNING LIGHT

HINT

See LOCATION.

Scheme 187

Scheme 187: REPLACEMENT
Scheme 187: REPLACEMENT

Scheme 188

Scheme 188
Scheme 188
  1. REMOVE FRONT DOOR LOWER FRAME BRACKET GARNISH LH (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  2. REMOVE FRONT DOOR INSIDE HANDLE BEZEL LH (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  3. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSY (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  4. REMOVE FRONT ARMREST ASSY LH (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  5. REMOVE FRONT DOOR TRIM BOARD SUB-ASSY LH (SEE «OVERHAUL»(ref-228811-S12836174562006041100000) )
  6. REMOVE STEREO COMPONENT SPEAKER ASSY Remove the 8 screws and stereo component speaker assy. NOTE: Since the panel on the interior side is taken off with the stereo component speaker assy, be careful not to drop it. Remove the clamp. Remove the 2 screws and stereo component speaker assy.

HINT

See LOCATION.

Scheme 189

Scheme 189: REPLACEMENT
Scheme 189: REPLACEMENT

Scheme 190

Scheme 190
Scheme 190
  1. REMOVE BACK DOOR GARNISH CENTER (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  2. REMOVE BACK DOOR SIDE GARNISH RH (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  3. REMOVE BACK DOOR SIDE GARNISH LH (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  4. REMOVE TOOL BOX PANEL SUB-ASSY UPPER (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  5. REMOVE DOOR PULL HANDLE SUB-ASSY (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  6. REMOVE BACK DOOR TRIM BOARD (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  7. REMOVE REAR SPEAKER ASSY NO.2 Disconnect the connector. Remove the 3 bolts and rear speaker assy No.2.
  8. INSTALL REAR SPEAKER ASSY NO.2 Install the rear speaker assy No.2 with the 3 bolts. NOTE: Install the bolts in the order (Scheme 190) Connect the connector.

HINT

See LOCATION.

Scheme 191

Scheme 191: REPLACEMENT
Scheme 191: REPLACEMENT

Scheme 192

Scheme 192
Scheme 192

Scheme 193

Scheme 193
Scheme 193
  1. REMOVE REAR DOOR SCUFF PLATE RH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  2. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
  3. REMOVE BACK DOOR WEATHERSTRIP
  4. REMOVE REAR FLOOR MAT SUPPORT PLATE REAR (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  5. REMOVE PACKAGE TRAY TRIM PANEL ASSY (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  6. REMOVE QUARTER INSIDE TRIM BOARD RH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  7. REMOVE ROOF SIDE GARNISH INNER RH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  8. REMOVE W/BOX SPEAKER ASSY NO.1 Disconnect the connector. Remove the 4 bolts and w/ box speaker assy No.1.
  9. INSTALL W/BOX SPEAKER ASSY NO.1 Place the w/ box speaker assy No.1 temporarily on the body Install the w/ box speaker assy No.1 with the 4 bolts. NOTE: Install the bolts in the order (Scheme 193) Connect the connector.

HINT

See LOCATION.

Scheme 194

Scheme 194: REPLACEMENT
Scheme 194: REPLACEMENT

Scheme 195

Scheme 195
Scheme 195

Scheme 196

Scheme 196
Scheme 196
  1. REMOVE FRONT DOOR SCUFF PLATE RH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  2. REMOVE COWL SIDE TRIM BOARD RH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  3. REMOVE MULTI-DISPLAY CONTROLLER W/BRACKET Disconnect the connectors. Remove the 2 nuts and multi-display controller w/ bracket.
  4. REMOVE TELEVISION DISPLAY BRACKET A Remove the 3 screws and television display bracket A.
  5. REMOVE TELEVISION DISPLAY BRACKET B Remove the 2 screws and television display bracket B.

HINT

See LOCATION.

  1. REMOVE BACK DOOR GARNISH CENTER (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  2. REMOVE BACK DOOR SIDE GARNISH RH (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  3. REMOVE BACK DOOR SIDE GARNISH LH (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  4. REMOVE TOOL BOX PANEL SUB-ASSY UPPER (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  5. REMOVE DOOR PULL HANDLE SUB-ASSY (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  6. REMOVE BACK DOOR TRIM BOARD (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  7. REMOVE BACK DOOR SERVICE HOLE COVER (SEE «OVERHAUL»(ref-228811-S04824556122006041100000) )
  8. REMOVE LICENSE REAR LAMP COVER (SEE «BACK DOOR GARNISH SUB-ASSY OUTSIDE»(ref-228812-S39805326622006041100000) )
  9. REMOVE BACK DOOR OUTSIDE GARNISH (SEE «BACK-UP LAMP LENS & BODY LH»(ref-228802-S25911455202006041100000) )
  10. REMOVE TELEVISION CAMERA ASSY

HINT

See LOCATION.

  1. REMOVE FRONT DOOR SCUFF PLATE RH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  2. REMOVE COWL SIDE TRIM BOARD RH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  3. REMOVE INSTRUMENT PANEL UNDER COVER NO.2 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  4. REMOVE INSTRUMENT PANEL ORNAMENT (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  5. REMOVE GLOVE COMPARTMENT DOOR SUB-ASSY (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  6. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER NO.2 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  7. REMOVE ECM (SEE «ECM (2UZ-FE)»(/lexus/gx/j120-2002-2009/remont/removal-installation/#engine-control-system) )
  8. REMOVE TELEVISION CAMERA CONTROLLER

HINT

See LOCATION.

Scheme 197

Scheme 197: REPLACEMENT
Scheme 197: REPLACEMENT

Scheme 198

Scheme 198
Scheme 198

Scheme 199

Scheme 199
Scheme 199
  1. REMOVE TELEVISION BASE Push the television base to the front of the vehicle in order to disengage the 2 claws on the backside. Disengage the 2 claws on the front side and remove the television base.
  2. REMOVE TELEVISION DISPLAY ASSY Disconnect the connector. Remove the 4 bolts. Remove the television display assy.

HINT

See LOCATION.

Scheme 200

Scheme 200: REPLACEMENT
Scheme 200: REPLACEMENT

Scheme 201

Scheme 201
Scheme 201

Scheme 202

Scheme 202
Scheme 202
  1. REMOVE CONSOLE UPPER PANEL GARNISH NO.2 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  2. REMOVE CONSOLE UPPER PANEL GARNISH NO.1 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  3. REMOVE CONSOLE REAR END PANEL SUB-ASSY (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  4. REMOVE RR CONSOLE BOX ASSY (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  5. REMOVE DISC PLAYER CONTROLLER W/BRACKET Remove the 4 screws and disc player controller w/ bracket.
  6. REMOVE DISC PLAYER BRACKET Remove the 2 screws and disc player bracket.
  7. REMOVE BRACKET Remove the 2 screws and bracket.

HINT

See LOCATION.

Scheme 203

Scheme 203: REPLACEMENT
Scheme 203: REPLACEMENT
  1. REMOVE ROOM LAMP ASSY NO.1 (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  2. REMOVE STEREO COMPONENT CONTROLLER ASSY Remove the 2 screws and stereo component controller assy.

HINT

See LOCATION.

Scheme 204

Scheme 204: REPLACEMENT
Scheme 204: REPLACEMENT
  1. REMOVE CONSOLE REAR END PANEL SUB-ASSY (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  2. REMOVE HEADPHONE TERMINAL Remove the 2 screws and headphone terminal.

HINT

See LOCATION.

Scheme 205

Scheme 205: REPLACEMENT
Scheme 205: REPLACEMENT

Scheme 206

Scheme 206
Scheme 206

Scheme 207

Scheme 207
Scheme 207

Scheme 208

Scheme 208
Scheme 208
  1. REMOVE GLOVE COMPARTMENT DOOR SUB-ASSY (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  2. REMOVE INSTRUMENT PANEL ORNAMENT (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  3. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER NO.2 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  4. REMOVE DISC PLAYER CHANGER W/BRACKET Remove the 4 bolts. Release the 2 claws and pull the disc player changer w/ bracket. Disconnect the connectors and remove the disc player changer w/ bracket.
  5. REMOVE DISC PLAYER BRACKET Remove the 2 screws and disc player bracket.
  6. REMOVE DISC PLAYER BRACKET Remove the 2 screws and disc player bracket.
  7. INSTALL DISC PLAYER CHANGER W/BRACKET Connect the connectors. Engage the 2 claws and place the disc player changer w/ bracket temporarily on the body. Install the 4 bolts and disc player changer w/ bracket. NOTE: Install the bolts in the order (Scheme 208)

HINT

See LOCATION.

Scheme 209

Scheme 209: REPLACEMENT
Scheme 209: REPLACEMENT
  1. DISCONNECT BATTERY NEGATIVE TERMINAL
  2. REMOVE SHIFT LEVER KNOB SUB-ASSY
  3. REMOVE SHIFT LEVER KNOB SUB-ASSY
  4. REMOVE CONSOLE UPPER PANEL GARNISH NO.2
  5. REMOVE CONSOLE UPPER PANEL GARNISH NO.1
  6. REMOVE CONSOLE PANEL UPPER ASSY
  7. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY LH
  8. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY RH
  9. REMOVE INSTRUMENT CLUSTER FINISH PANEL CENTER LOWER
  10. REMOVE INTEGRATION CONTROL & PANEL ASSY
  11. REMOVE CONSOLE REAR END PANEL SUB-ASSY
  12. REMOVE RR CONSOLE BOX ASSY
  13. REMOVE CONSOLE BOX INSERT FRONT NO.2
  14. REMOVE CONSOLE BOX INSERT
  15. REMOVE CONSOLE UPPER PANEL GARNISH FRONT
  16. REMOVE CONSOLE BOX LOWER
  17. REMOVE STEERING WHEEL COVER LOWER NO.2
  18. REMOVE STEERING WHEEL COVER LOWER NO.3
  19. REMOVE HORN BUTTON ASSY
  20. REMOVE STEERING WHEEL ASSY SST 09950-50013 (09951-05010, 09952-05010, 09953-05020, 09954-05021)
  21. REMOVE STEERING COLUMN COVER
  22. REMOVE TURN SIGNAL SWITCH ASSY W/SPIRAL CABLE SUB-ASSY
  23. REMOVE FRONT DOOR SCUFF PLATE LH
  24. REMOVE FRONT DOOR SCUFF PLATE RH
  25. REMOVE FRONT FLOOR FOOTREST
  26. REMOVE COWL SIDE TRIM BOARD LH
  27. REMOVE COWL SIDE TRIM BOARD RH
  28. REMOVE INSTRUMENT PANEL UNDER COVER SUB-ASSY NO.1
  29. REMOVE INSTRUMENT CLUSTER FINISH PANEL ORNAMENT
  30. REMOVE SWITCH HOLE BASE NO.1
  31. REMOVE INSTRUMENT PANEL FINISH PLATE
  32. REMOVE INSTRUMENT PANEL FINISH LOWER PANEL RH
  33. REMOVE INSTRUMENT PANEL LOWER LH
  34. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY
  35. REMOVE COMBINATION METER ASSY
  36. REMOVE INSTRUMENT PANEL REGISTER ASSY NO.1
  37. REMOVE INSTRUMENT PANEL UNDER COVER NO.2
  38. REMOVE GLOVE COMPARTMENT DOOR SUB-ASSY
  39. REMOVE INSTRUMENT PANEL ORNAMENT
  40. DISCONNECT PASSENGER AIRBAG CONNECTOR
  41. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER NO.2
  42. REMOVE INSTRUMENT PANEL REGISTER ASSY NO.2
  43. REMOVE DISC PLAYER CHANGER W/ BRACKET (W/ DISC PLAYER CHANGER)
  44. REMOVE ASSIST GRIP ASSY
  45. REMOVE FRONT PILLAR GARNISH LH
  46. REMOVE FRONT PILLAR GARNISH RH
  47. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/ DEFROSTER NOZZLE DUCT (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  48. REMOVE ANTENNA CORD SUB-ASSY Remove the 6 clamps and antenna cord sub-assy.
  49. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/ DEFROSTER NOZZLE DUCT (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  50. INSTALL COMBINATION METER ASSY
  51. CENTER SPIRAL CABLE
  52. INSTALL STEERING WHEEL ASSY
  53. INSTALL HORN BUTTON ASSY
  54. INSPECT HORN BUTTON ASSY
  55. INCLINATION SENSOR 0 CORRECTION
  56. INSPECT SRS WARNING LIGHT

HINT

See LOCATION.

Scheme 210

Scheme 210: REPLACEMENT
Scheme 210: REPLACEMENT
  1. REMOVE REAR NO.2 SEAT ASSY LH
  2. REMOVE REAR NO.2 SEAT ASSY RH
  3. REMOVE FRONT DOOR SCUFF PLATE LH
  4. REMOVE FRONT DOOR SCUFF PLATE RH
  5. REMOVE COWL SIDE TRIM BOARD LH
  6. REMOVE COWL SIDE TRIM BOARD RH
  7. REMOVE QUARTER SCUFF PLATE INSIDE LH
  8. REMOVE QUARTER SCUFF PLATE INNER RH
  9. REMOVE REAR DOOR SCUFF PLATE LH
  10. REMOVE REAR DOOR SCUFF PLATE RH
  11. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP LH
  12. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP RH
  13. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
  14. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
  15. REMOVE CENTER PILLAR GARNISH LOWER LH
  16. REMOVE CENTER PILLAR GARNISH LOWER RH
  17. REMOVE CENTER PILLAR GARNISH LH
  18. REMOVE CENTER PILLAR GARNISH RH
  19. REMOVE BACK DOOR WEATHERSTRIP
  20. REMOVE REAR FLOOR MAT SUPPORT PLATE REAR
  21. REMOVE PACKAGE TRAY TRIM PANEL ASSY
  22. REMOVE QUARTER INSIDE TRIM BOARD LH
  23. REMOVE QUARTER INSIDE TRIM BOARD RH
  24. REMOVE ROOF SIDE GARNISH INNER LH
  25. REMOVE ROOF SIDE GARNISH INNER RH
  26. REMOVE FRONT PILLAR GARNISH LH
  27. REMOVE FRONT PILLAR GARNISH RH
  28. REMOVE ASSIST GRIP ASSY
  29. REMOVE TELEVISION BASE (W/ RR TELEVISION)
  30. REMOVE ROOF CONSOLE BOX SUB-ASSY
  31. REMOVE ROOM LAMP ASSY NO.1
  32. REMOVE ROOM LAMP ASSY NO.2
  33. REMOVE ROOF HEADLINING REAR TRIM COVER LH
  34. REMOVE VISOR BRACKET COVER
  35. REMOVE VISOR BRACKET COVER
  36. REMOVE LH VISOR ASSY
  37. REMOVE RH VISOR ASSY
  38. REMOVE VISOR HOLDER
  39. REMOVE ROOF HEADLINING ASSY (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  40. REMOVE AMPLIFIER ANTENNA ASSY Disconnect the connectors. Remove the 4 bolts. Remove the 17 clamps and amplifier antenna assy.
  41. INSTALL AMPLIFIER ANTENNA ASSY Install the 4 bolts. Torque: 8 N.m (82 kgf.cm, 71 in.lbf) Connect the connectors.
  42. INSTALL ROOF HEADLINING ASSY (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  43. INSTALL ROOF SIDE GARNISH INNER LH
  44. INSTALL ROOF SIDE GARNISH INNER RH
  45. INSTALL FRONT SEAT OUTER BELT ASSY LH
  46. INSTALL FRONT SEAT OUTER BELT ASSY RH
  47. INSTALL REAR SEAT BELT ASSY OUTER
  48. INSTALL REAR SEAT BELT ASSY OUTER
  49. INSTALL REAR NO. 2 SEAT ASSY LH
  50. INSTALL REAR NO. 2 SEAT ASSY RH

HINT

See LOCATION.

Scheme 211

Scheme 211: REPLACEMENT
Scheme 211: REPLACEMENT

Scheme 212

Scheme 212
Scheme 212

Scheme 213

Scheme 213
Scheme 213

Scheme 214

Scheme 214
Scheme 214

Scheme 215

Scheme 215
Scheme 215

Scheme 216

Scheme 216
Scheme 216
  1. REMOVE FRONT RH SEAT ASSY (SEE «OVERHAUL»(ref-228808-S19466326792006041100000) )
  2. REMOVE DISC PLAYER BRACKET Remove the bolt and screw. Remove the disc player bracket.
  3. REMOVE NAVIGATION COMPUTER W/ BRACKET Disconnect the connectors and remove the bolt and screw. Remove the navigation computer w/ bracket.
  4. REMOVE NAVIGATION ECU COVER Release the 2 claws and remove the navigation ECU cover. Remove the 4 screws and navigation ECU cover.
  5. REMOVE DISC PLAYER BRACKET NO.2 Remove the 2 screws and disc player bracket No.2.
  6. REMOVE DISC PLAYER BRACKET NO.3 Remove the 2 screws and disc player bracket No.3.
  7. INSTALL FRONT RH SEAT ASSY (SEE «OVERHAUL»(ref-228808-S19466326792006041100000) )

HINT

See LOCATION.

Scheme 217

Scheme 217: REPLACEMENT
Scheme 217: REPLACEMENT

Scheme 218

Scheme 218
Scheme 218
  1. DISCONNECT BATTERY NEGATIVE TERMINAL
  2. REMOVE SHIFT LEVER KNOB SUB-ASSY
  3. REMOVE SHIFT LEVER KNOB SUB-ASSY
  4. REMOVE CONSOLE UPPER PANEL GARNISH NO.2
  5. REMOVE CONSOLE UPPER PANEL GARNISH NO.1
  6. REMOVE CONSOLE PANEL UPPER ASSY
  7. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY LH
  8. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY RH
  9. REMOVE INSTRUMENT CLUSTER FINISH PANEL CENTER LOWER
  10. REMOVE INTEGRATION CONTROL & PANEL ASSY
  11. REMOVE CONSOLE REAR END PANEL SUB-ASSY
  12. REMOVE RR CONSOLE BOX ASSY
  13. REMOVE CONSOLE BOX INSERT FRONT NO.2
  14. REMOVE CONSOLE BOX INSERT
  15. REMOVE CONSOLE UPPER PANEL GARNISH FRONT
  16. REMOVE CONSOLE BOX LOWER
  17. REMOVE STEERING WHEEL COVER LOWER NO.2
  18. REMOVE STEERING WHEEL COVER LOWER NO.3
  19. REMOVE HORN BUTTON ASSY
  20. REMOVE STEERING WHEEL ASSY SST 09950-50013 (09951-05010, 09952-05010, 09953-05020, 09954-05021)
  21. REMOVE STEERING COLUMN COVER
  22. REMOVE TURN SIGNAL SWITCH ASSY W/SPIRAL CABLE SUB-ASSY
  23. REMOVE FRONT DOOR SCUFF PLATE LH
  24. REMOVE FRONT DOOR SCUFF PLATE RH
  25. REMOVE FRONT FLOOR FOOTREST
  26. REMOVE COWL SIDE TRIM BOARD LH
  27. REMOVE COWL SIDE TRIM BOARD RH
  28. REMOVE INSTRUMENT CLUSTER FINISH PANEL ORNAMENT
  29. REMOVE SWITCH HOLE BASE NO.1
  30. REMOVE INSTRUMENT PANEL FINISH PLATE
  31. REMOVE INSTRUMENT PANEL FINISH LOWER PANEL RH
  32. REMOVE INSTRUMENT PANEL LOWER LH
  33. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSY
  34. REMOVE COMBINATION METER ASSY
  35. REMOVE INSTRUMENT PANEL REGISTER ASSY NO.1
  36. REMOVE INSTRUMENT PANEL UNDER COVER NO.2
  37. REMOVE GLOVE COMPARTMENT DOOR SUB-ASSY
  38. REMOVE INSTRUMENT PANEL ORNAMENT
  39. DISCONNECT PASSENGER AIRBAG CONNECTOR
  40. REMOVE INSTRUMENT PANEL FINISH PANEL LOWER NO.2
  41. REMOVE INSTRUMENT PANEL REGISTER ASSY NO.2
  42. REMOVE DISC PLAYER CHANGER W/BRACKET (W/ DISC PLAYER CHANGER)
  43. REMOVE ASSIST GRIP ASSY
  44. REMOVE FRONT PILLAR GARNISH LH
  45. REMOVE FRONT PILLAR GARNISH RH
  46. REMOVE INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/DEFROSTER NOZZLE DUCT (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  47. REMOVE NAVIGATION ANTENNA ASSY Remove the 3 clamps. Remove the 2 screws and navigation antenna assy.
  48. INSTALL NAVIGATION ANTENNA ASSY Install the navigation antenna assy with the 2 screws. Install the 3 clamps. NOTE: Pass the navigation antenna code under the radio antenna cord.
  49. INSTALL INSTRUMENT PANEL SAFETY PAD SUB-ASSY W/DEFROSTER NOZZLE DUCT (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  50. INSTALL COMBINATION METER ASSY
  51. CENTER SPIRAL CABLE
  52. INSTALL STEERING WHEEL ASSY
  53. INSTALL HORN BUTTON ASSY
  54. INSPECT HORN BUTTON ASSY
  55. INCLINATION SENSOR ZERO DEGREE CORRECTION
  56. INSPECT SRS WARNING LIGHT

HINT

See LOCATION.

Scheme 219

Scheme 219: REPLACEMENT
Scheme 219: REPLACEMENT
  1. REMOVE REAR DOOR SCUFF PLATE RH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  2. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
  3. REMOVE BACK DOOR WEATHERSTRIP
  4. REMOVE REAR FLOOR MAT SUPPORT PLATE REAR (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  5. REMOVE PACKAGE TRAY TRIM PANEL ASSY (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  6. REMOVE QUARTER INSIDE TRIM BOARD RH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  7. REMOVE VOLTAGE INVERTER ASSY Disconnect the connector and remove the 3 bolts. Release the claw and remove the voltage inverter assy.

HINT

See LOCATION.

Scheme 220

Scheme 220: REPLACEMENT
Scheme 220: REPLACEMENT

Scheme 221

Scheme 221
Scheme 221

Scheme 222

Scheme 222
Scheme 222

Scheme 223

Scheme 223
Scheme 223

Scheme 224

Scheme 224
Scheme 224

Scheme 225

Scheme 225
Scheme 225

Scheme 226

Scheme 226
Scheme 226
  1. DISCONNECT BATTERY NEGATIVE TERMINAL (SEE «PRECAUTION»(ref-228800-S14421764032006041100000) )
  2. REMOVE STEERING WHEEL COVER LOWER NO.2 (SEE «REPLACEMENT»(ref-228800-S24187539102006041100000) )
  3. REMOVE STEERING WHEEL COVER LOWER NO.3 (SEE «REPLACEMENT»(ref-228800-S24187539102006041100000) )
  4. REMOVE HORN BUTTON ASSY (SEE «REPLACEMENT»(ref-228800-S24187539102006041100000) )
  5. REMOVE STEERING PAD SWITCH LH (W/O STEERING PAD SWITCH RH) Disconnect the connector. Disconnect the connector of cruise control main switch. Remove the screw. Disengage the 2 pins and remove the steering pad switch LH.
  6. REMOVE STEERING PAD SWITCH LH (W/ STEERING PAD SWITCH RH) Disconnect the connector. Disconnect the connector of cruise control main switch. Remove the screw. Remove the clamp. Disengage the 2 pins and release the steering pad switch LH from the steering wheel. Release the tab of steering pad switch cable from the steering pad switch LH. Disengage the 2 claws and open the latch on the top of the connector. Pull out the connector while pinching the latch with fingers and disconnect the steering pad switch cable from the steering pad switch LH.
  7. INSTALL HORN BUTTON ASSY (SEE «REPLACEMENT»(ref-228800-S24187539102006041100000) )
  8. INSPECT HORN BUTTON ASSY (SEE «PRECAUTION»(ref-228800-S14421764032006041100000) )
  9. INSPECT SRS WARNING LIGHT (SEE «DIAGNOSIS SYSTEM»(ref-228757-S15620024632006041100000) )

HINT

See LOCATION.

Scheme 227

Scheme 227: REPLACEMENT
Scheme 227: REPLACEMENT

Scheme 228

Scheme 228
Scheme 228

Scheme 229

Scheme 229
Scheme 229

Scheme 230

Scheme 230
Scheme 230
  1. DISCONNECT BATTERY NEGATIVE TERMINAL (SEE «PRECAUTION»(ref-228800-S14421764032006041100000) )
  2. REMOVE STEERING WHEEL COVER LOWER NO.2 (SEE «REPLACEMENT»(ref-228800-S24187539102006041100000) )
  3. REMOVE STEERING WHEEL COVER LOWER NO.3 (SEE «REPLACEMENT»(ref-228800-S24187539102006041100000) )
  4. REMOVE HORN BUTTON ASSY (SEE «REPLACEMENT»(ref-228800-S24187539102006041100000) )
  5. REMOVE STEERING PAD SWITCH RH Remove the screw. Remove the clamp. Disengage the 2 pins and release the steering pad switch RH from the steering wheel. Release the tab of steering pad switch cable from the steering pad switch RH. Disengage the 2 claws and open the latch on the top of the connector. Pull out the connector while pinching the latch with fingers and disconnect the steering pad switch cable from the steering pad switch RH.
  6. INSTALL HORN BUTTON ASSY (SEE «REPLACEMENT»(ref-228800-S24187539102006041100000) )
  7. INSPECT HORN BUTTON ASSY (SEE «PRECAUTION»(ref-228800-S14421764032006041100000) )
  8. INSPECT SRS WARNING LIGHT (SEE «DIAGNOSIS SYSTEM»(ref-228757-S15620024632006041100000) )

HINT

See LOCATION.

Scheme 231

Scheme 231: REPLACEMENT
Scheme 231: REPLACEMENT

Scheme 232

Scheme 232
Scheme 232
  1. REMOVE CONSOLE UPPER PANEL GARNISH NO.2 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  2. REMOVE CONSOLE UPPER PANEL GARNISH NO.1 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  3. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY LH (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  4. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY RH (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  5. REMOVE INSTRUMENT CLUSTER FINISH PANEL CENTER LOWER (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  6. REMOVE CIGARETTE LIGHTER COVER Release the 2 claws, and remove the cigarette lighter cover.
  7. REMOVE CIGARETTE LIGHTER ASSY Remove the cigarette lighter knob and element assy. Turn the socket counterclockwise (Scheme 232), disengage the claw between the socket and the cigarette lighter bezel stay, and push out the socket to the room side. Align the socket with the notch on the cigarette lighter bezel stay, and remove the cigarette lighter assy to the room side.
  8. INSTALL CIGARETTE LIGHTER ASSY Align the socket with the notch on the cigarette lighter bezel stay, and push in the cigarette lighter assy as hard as possible to install it. Install the cigarette lighter knob and element assy.

HINT

See LOCATION.

Scheme 233

Scheme 233: REPLACEMENT
Scheme 233: REPLACEMENT
  1. REMOVE CONSOLE UPPER PANEL GARNISH NO.2 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  2. REMOVE CONSOLE UPPER PANEL GARNISH NO.1 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  3. REMOVE CONSOLE PANEL UPPER ASSY (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  4. REMOVE CONSOLE UPPER PANEL GARNISH FRONT (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  5. REMOVE POWER POINT SOCKET ASSY Pressing the claw of the power point socket assy in the direction of the arrow, push the power point socket assy toward the room side to remove it.
  6. INSTALL POWER POINT SOCKET ASSY Align the claw of the power point socket assy with the cutout of the power point socket cover and fully push it to install.

HINT

See LOCATION.

Scheme 234

Scheme 234: REPLACEMENT
Scheme 234: REPLACEMENT
  1. REMOVE REAR DOOR SCUFF PLATE LH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  2. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
  3. REMOVE BACK DOOR WEATHERSTRIP
  4. REMOVE REAR FLOOR MAT SUPPORT PLATE REAR (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  5. REMOVE PACKAGE TRAY TRIM PANEL ASSY (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  6. REMOVE QUARTER INSIDE TRIM BOARD LH (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  7. REMOVE POWER POINT SOCKET ASSY RR Disengage the 2 claws and remove the power point socket assy RR.

HINT

See LOCATION.

Scheme 235

Scheme 235: REPLACEMENT
Scheme 235: REPLACEMENT
  1. REMOVE SHIFT LEVER KNOB SUB-ASSY
  2. REMOVE SHIFT LEVER KNOB SUB-ASSY
  3. REMOVE CONSOLE UPPER PANEL GARNISH NO.2 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  4. REMOVE CONSOLE UPPER PANEL GARNISH NO.1 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  5. REMOVE CONSOLE PANEL UPPER ASSY (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  6. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY LH (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  7. REMOVE INSTRUMENT PANEL GARNISH SUB-ASSY RH (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  8. REMOVE CONSOLE REAR END PANEL SUB-ASSY (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  9. REMOVE RR CONSOLE BOX ASSY (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  10. REMOVE CONSOLE BOX INSERT FRONT NO.2 (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  11. REMOVE CONSOLE BOX INSERT (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  12. REMOVE CONSOLE UPPER PANEL GARNISH FRONT (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  13. REMOVE CONSOLE BOX LOWER (SEE «REPLACEMENT»(ref-228807-S32953263012006041100000) )
  14. REMOVE NETWORK GATEWAY ECU Disconnect the connector. Remove the 2 screws and network gateway ECU.

HINT

  1. See «LOCATION»(ref-228804-S20056246162006041100000).
  2. Installation is in the reverse order of removal.

Scheme 236

Scheme 236
Scheme 236
  1. REMOVE ROOF CONSOLE BOX ASSY (SEE «REPLACEMENT»(ref-228812-S42057540512006041100000) )
  2. REMOVE AMPLIFIER MICROPHONE ASSY Remove the 3 screws. Disconnect the connector. Remove the amplifier microphone assy.

Scheme 237

Scheme 237: REPAIR
Scheme 237: REPAIR

Scheme 238

Scheme 238
Scheme 238

Scheme 239

Scheme 239
Scheme 239

Scheme 240

Scheme 240
Scheme 240
  1. INSPECT WINDOW GLASS (ANTENNA WIRE) NOTE: When cleaning the glass, use a soft and dry cloth, and wipe the glass in the direction of the wire. Take care not to damage the wires. Do not use detergents or glass cleaners with abrasive ingredients. When measuring voltage, wind a piece of tin foil around the top of the negative probe and press the foil against the wire with your finger (Scheme 237) Inspect the continuity, at the center of each antenna wire (Scheme 238)
  2. REPAIR WINDOW GLASS (ANTENNA WIRE) Clean the broken wire tips with a grease, wax and silicone remover. Place the masking tape along both sides of the wire to be repaired. Thoroughly mix the repair agent (DuPont paste No. 4817). Using a fine tip brush, apply a small amount of the mixture to the wire. After a few minutes, remove the masking tape. Do not repair the defogger wire for at least 24 hours.

See also:
• ECM (2UZ-FE)

More articles — Audio & Visual System
