PROBLEM SYMPTOMS TABLE
Use (Scheme 1) to help find the cause of the problem. The numbers indicate the priority of the likely cause of the problem. Check each part in order. If necessary, replace these parts.
Scheme 1
Scheme 2
- INSPECT AND ADJUST DIFFERENTIAL OIL Stop the vehicle on the level place. Remove the differential filler plug and gasket. Check that the oil surface is within 5 mm (0.20 in.) from the lowest position of the inner surface of the differential filler plug opening. NOTE: Excessively large or small amount of oil may cause troubles. After replacing oil, drive the vehicle and check the oil level. HINT: If necessary, fill the differential carrier assy with hypoid gear oil. Oil grade: Hypoid gear oil API GL - 5 Recommended viscosity: Above - 18°C (0°F) SAE 90 Below - 18°C (0°F) SAE 80W or 80W-90 Capacity: Fr Differential: 1.4 +/- 0.05 litters Rr Differential: 3.05 +/- 0.05 litters Check for oil leakage when the oil level is low. Install the differential filler plug and a new gasket. Fr Differential: Torque: 39 N.m (400 kgf.cm, 29 ft.lbf) Re Differential: Torque: 49 N.m (500 kgf.cm, 36 ft.lbf)
