Maintenance Lexus GS IV

Procedures 3 illustrations ~2468 words
  1. These are maintenance and inspection items that are considered to be the owner's responsibility. The owner can do them or they can have them done at a service center. These items include those that should be checked on a daily basis, those that in most cases do not require special tools, and those that are considered to be reasonable for the owner to do. General maintenance items and procedures are as follows
  1. GENERAL NOTES Maintenance requirements vary depending on the country. Check the maintenance schedule in the owner's manual supplement. Following the maintenance schedule is mandatory. Determine the appropriate time to service the vehicle using either miles driven or time (months) elapsed, whichever reaches the specification first. Failing to check each vehicle part could lead to poor engine performance and increase exhaust emissions.
  2. TIRES Check the tire inflation pressure with a gauge. Make adjustments if necessary. Check the surfaces of the tires for cuts, damage or excessive wear.
  3. WHEEL NUTS Check for nuts that are loose or missing. Tighten them if necessary.
  4. TIRE ROTATION Check the maintenance schedule in the owner's manual supplement.
  5. WINDSHIELD WIPER BLADES Check the blades for wear or cracks whenever they are unable to wipe the windshield clean. Replace them if necessary.
  6. FLUID LEAKS Check under the vehicle for leaking fuel, oil, water and other fluids. NOTE: If you smell fuel or notice any leaks, locate the cause and correct it.
  7. DOORS AND ENGINE HOOD Check that all of the doors and the hood operate smoothly, and that all the latches lock securely. When the primary latch is released, check that the engine hood secondary latch prevents the hood from opening.
  1. These are maintenance and inspection items that are considered to be the owner's responsibility. The owner can do them or they can have them done at a service center. These items include those that should be checked on a daily basis, those that in most cases do not require special tools, and those that are considered to be reasonable for the owner to do. General maintenance items and procedures are as follows

Scheme 1

Scheme 1
Scheme 1

Scheme 2

Scheme 2
Scheme 2
  1. GENERAL NOTES Maintenance requirements vary depending on the country. Check the maintenance schedule in the owner's manual supplement. Determine the appropriate time to service the vehicle using either miles driven or time (months) elapsed, whichever reaches the specification first. Maintain similar intervals between periodic maintenance unless noted. Failing to check each vehicle part could lead to poor engine performance and increase exhaust emissions.
  2. LIGHTS Check that the headlights, stop lights, taillights, turn signal lights, and other lights illuminate or blink properly. Also, check if they have enough brightness. Check that the headlights are aimed properly.
  3. WARNING LIGHTS AND BUZZERS Check that all the warning lights and buzzers are working.
  4. HORNS Check if the horns are working correctly.
  5. WINDSHIELD GLASS Check for scratches, pits or abrasions.
  6. WINDSHIELD WIPER AND WASHER Check that the washers are aimed properly. Also, check that the washer fluid hits the center of the operating range of each wiper on the windshield. Check if the wipers streak. Replace them if necessary.
  7. WINDSHIELD DEFROSTER When the air conditioning is on the defroster setting, check that air comes out of the defroster outlets.
  8. REAR VIEW MIRROR Check that the rear view mirror is securely mounted.
  9. SUN VISORS Check that the sun visors move freely and are securely mounted.
  10. STEERING WHEEL Check that the steering wheel has the proper amount of free play. Also check for steering difficulty and unusual noise.
  11. SEATS Check that the seat adjusters, seatback recliner and other seat controls operate smoothly. Check that all the latches lock securely in all positions. Check that the locks hold securely in all positions. Check that the headrests move up and down smoothly and that the locks hold securely in all latched positions. Check power seat function. for Driver Side: TEXT IN ILLUSTRATION *a Sliding Function *b Front Vertical Function *c Lifter Function *d Reclining Function *e Lumbar Support Adjustment Function *f Cushion Length Function *g Pelvis Support Function *h Side Support Function *i Front Seat back Adjustment Function Operate the power seat switches and check that each seat function operates properly: Sliding function Front vertical function Lifter function Reclining function Lumbar support adjustment function Cushion length function* Pelvis support function* Side support function* Front seat back adjustment function* *: for Luxury Seat Type for Front Passenger Side TEXT IN ILLUSTRATION *a Sliding Function *b Front Vertical Function *c Lifter Function *d Reclining Function *e Lumbar Support Adjustment Function *f Cushion Length Function *g Pelvis Support Function *h Side Support Function *i Front Seat back Adjustment Function Operate the power seat switches and check that each seat function operates properly: Sliding function Front vertical function Lifter function Reclining function Lumbar support adjustment function Cushion length function* Pelvis support function* Side support function* Front seat back adjustment function* *: for Luxury Seat Type
  12. SEAT BELTS Check that the seat belt components, such as the buckles, retractors and anchors, operate properly and smoothly. Check that the belt webbing is not cut, frayed, worn or damaged.
  13. ACCELERATOR PEDAL Check that the pedal operates smoothly. Check that the pedal does not have uneven resistance or stick in certain positions.
  14. BRAKE PEDAL Check that the brake pedal operates smoothly. Check that the pedal has the proper reserve distance and free play. Turn the power switch on (READY) and check the brake system indicator.
  15. BRAKES In a safe place, check that the vehicle does not pull or lead to the side when applying the brakes.
  16. PARKING BRAKE Turn the power switch on (READY) and move the shift lever to D. Then depress the brake pedal and push the electric parking brake switch assembly to the lock side for 1 second. Check the parking brake indicator light (red) condition. Release the brake pedal and check that the vehicle does not move. Depress the brake pedal and pull the electric parking brake switch assembly to the release side for 1 second. Check the parking brake indicator light (red) condition. Release the brake pedal and check that the vehicle moves.
  17. HYBRID VEHICLE TRANSMISSION "PARK" MECHANISM Check the lock release button of the shift lever for proper and smooth operation. Check the shift lever for proper and smooth operation. When the shift lever is in P and all brakes are released in an area that has a slight grade, check that the vehicle is stable.
  18. FLOOR MATS Check that the correct floor mats are used, and that they are properly installed.
  1. GENERAL NOTES Maintenance requirements vary depending on the country. Check the maintenance schedule in the owner's manual supplement. Following the maintenance schedule is mandatory. Determine the appropriate time to service the vehicle using either miles driven or time (months) elapsed, whichever reaches the specification first. Maintain similar intervals between periodic maintenance unless noted. Failing to check each maintenance item could lead to poor engine performance and increase exhaust emissions.
  2. WINDSHIELD WASHER FLUID Check that there is sufficient fluid in the tank.
  3. ENGINE COOLANT LEVEL Check that the coolant level is between the "FULL" and "LOW" lines on the see-through reservoir tank.
  4. INVERTER COOLANT LEVEL Check that the coolant level is between the "FULL" and "LOW" lines on the see-through reservoir tank.
  5. RADIATOR AND HOSES Check that the front of the radiator is clean and not blocked by leaves, dirt and bugs. Check the radiator and hoses for: Damage Cracks Kinks Corrosion Rot Clogging Leaks
  6. BRAKE FLUID LEVEL Check that the brake fluid level is near the upper level line on the see-through reservoirs.
  7. ENGINE DRIVE BELT Check the drive belt for fraying, cracks, wear or oil.
  8. ENGINE OIL LEVEL Check that the engine oil level is between the full level and low level marks on the dipstick with the engine turned off.
  9. EXHAUST SYSTEM Visually inspect for severe corrosion, cracks, holes or loose supports. HINT: If any change in the sound of the exhaust or smell of the exhaust fumes is noticed, inspect and repair the exhaust system.

HINT

Inspect these items on a cooled down engine.

  1. INSPECT DRIVE BELT Check the drive belt. Type See procedures 2GR-FXE Refer to «ON-VEHICLE INSPECTION [03/2012 - ]»(ref-600560-S01241840222014022400000)
  2. INSPECT ENGINE OIL Inspect the engine oil. Type See procedures 2GR-FXE Refer to «ON-VEHICLE INSPECTION [03/2012 - ]»(/lexus/gs/iv-2011-2015/remont/lubrication-system/#engine-lubrication-system-inspection)
  3. REPLACE ENGINE OIL AND OIL FILTER Replace the engine oil and oil filter. Type See procedures 2GR-FXE Refer to «REPLACEMENT [03/2012 - ]»(ref-600562-S31809832662014022400000)
  4. INSPECT ENGINE COOLANT Inspect the engine coolant. Type See procedures 2GR-FXE Refer to «ON-VEHICLE INSPECTION [03/2012 - ]»(/lexus/gs/iv-2011-2015/remont/cooling-system-mechanical/#engine-cooling-system-inspection__on-vehicle-inspection-032012)
  5. REPLACE ENGINE COOLANT Replace the engine coolant. Type See procedures 2GR-FXE Refer to «REPLACEMENT [03/2012 - ]»(ref-600564-S28430641862014022400000)
  6. INSPECT INVERTER COOLANT Inspect the inverter coolant. Type See procedures 2GR-FXE Refer to «ON-VEHICLE INSPECTION [03/2012 - ]»(ref-600413-S06968522352014022400000)
  7. REPLACE INVERTER COOLANT Replace the inverter coolant. Type See procedures 2GR-FXE Refer to «REPLACEMENT [03/2012 - ]»(ref-600413-S09274160512014022400000)
  8. REPLACE SPARK PLUGS Replace the spark plugs. Type See procedures 2GR-FXE Refer to «REMOVAL [03/2012 - ]»(ref-600565-S18103547432014022400000)
  9. INSPECT AIR CLEANER FILTER Remove the air cleaner filter. Check that the air cleaner is not excessively dirty. If the air cleaner is excessively dirty, replace the air cleaner filter element. Clean the air cleaner filter with compressed air. Reinstall the air filter.
  10. INSPECT EXHAUST PIPES AND MOUNTINGS Visually check the pipes, hangers and connections for severe corrosion, leaks or damage.
  11. INSPECT FUEL TANK CAP GASKET Check the fuel tank cap gasket. Type See procedures 2GR-FXE Refer to «INSPECTION [03/2012 - ]»(ref-600566-S30718773162014022400000)
  12. INSPECT FUEL LINES, FUEL LINE CONNECTIONS, FUEL TANK VAPOR VENT SYSTEM HOSES AND FUEL TANK BAND Visually check the fuel lines and hoses for cracks, leakage, loose connections and deformation. Also, visually check the tank band for looseness.

Scheme 3

Scheme 3: GENERAL MAINTENANCE [03/2012 - ]
Scheme 3: GENERAL MAINTENANCE [03/2012 - ]
  1. INSPECT BRAKE LINES AND HOSES HINT: Work in a well-lighted area. Turn the front wheels fully to the right or left before beginning the inspection. Using a mirror, check the entire circumference and length of the brake lines and hoses for: Damage Wear Deformation Cracks Corrosion Leaks Bends Twists Check all the clamps for tightness and the connections for leakage. Check that the hoses and lines are not near sharp edges, moving parts or the exhaust system. Check that the lines are installed properly and pass through the center of the grommets.
  2. INSPECT BRAKE PEDAL Check the brake pedal. Refer to «ADJUSTMENT [03/2012 - ]»(ref-600567-S21459084432014022400000) .
  3. INSPECT PARKING BRAKE Check the parking brake cables to ensure that they are not deformed or binding. Check the electric parking brake actuator assembly. Refer to «ON-VEHICLE INSPECTION [03/2012 - ]»(ref-600568-S31409499482014022400000) .
  4. INSPECT BRAKE LININGS AND DRUMS, PADS AND DISCS Inspect the brake pads and discs. Type See procedures Front brake (17 inch) Refer to «INSPECTION [03/2012 - ]»(ref-600569-S08531616642014022400000) Front brake (18 inch) Refer to «INSPECTION [03/2012 - ]»(ref-600569-S35848272362014022400000) Rear brake Refer to «INSPECTION [03/2012 - ]»(ref-600570-S20176446952014022400000) Inspect the parking brake linings and drums. Inspect the parking brake linings and drums. Refer to «INSPECTION [03/2012 - ]»(ref-600568-S33273221872014022400000) . Check the parking brake shoe clearance. Refer to «ADJUSTMENT [03/2012 - ]»(ref-600571-S27447039652014022400000) .
  5. INSPECT BRAKE FLUID Inspect the brake fluid. Refer to «ON-VEHICLE INSPECTION [03/2012 - ] - Step 1»(ref-600567-S31430554282014022400000) .
  6. REPLACE BRAKE FLUID Replace the brake fluid. Refer to «REPLACEMENT [03/2012 - ]»(ref-600567-S27061006172014022400000) .
  1. INSPECT STEERING LINKAGE AND GEAR BOX Check the steering wheel free play. Refer to «ON-VEHICLE INSPECTION [03/2012 - ]»(ref-600572-S35430616272014022400000) . Check the steering linkage for looseness or damage. Check that the tie rod ends do not have excessive play. Check that the dust seals and boots are not damaged. Check that the boot clamps are not loose. Check that the steering gear box is not damaged. Check that the connectors are properly connected to the steering gear box.
  2. INSPECT SUSPENSION BALL JOINT AND DUST COVER Inspect the ball joints for excessive looseness. Jack up the front of the vehicle and place wooden blocks with a height of 180 to 200 mm (7.09 to 7.87 in.) under the front tires. Jack up the lower suspension arm until there is about half a load on the front suspension. Check that the front wheels are pointing straight ahead. Use wheel chocks on all 4 wheels. Using a lever, pry up the end of the lower arm. Check the amount of play. Maximum ball joint vertical play 0 mm (0 in.) If there is any play, replace the ball joint. Check the dust cover for damage.
  3. INSPECT DRIVE SHAFT BOOTS Check the drive shaft boots for loose clamps, grease leakage, kinks or damage.
  4. INSPECT HYBRID VEHICLE TRANSMISSION FLUID Visually check the hybrid vehicle transmission for fluid leakage. If fluid is leaking, find the cause and repair it. Inspect the hybrid vehicle transmission fluid. Type See procedure L110 Refer to «ADJUSTMENT [03/2012 - ]»(ref-600573-S21213649032014022400000)
  5. REPLACE HYBRID VEHICLE TRANSMISSION FLUID (for Canada, Driving Conditions) HINT: Driving Conditions: Heavily loaded vehicle. Replace the hybrid vehicle transmission fluid. Type See procedure L110 Refer to «REPLACEMENT [03/2012 - ]»(ref-600573-S03763345122014022400000)
  6. INSPECT REAR DIFFERENTIAL OIL Inspect the rear differential oil. Refer to «REPLACEMENT [03/2012 - ] - Step 2»(ref-600574-S02186313722014022400000) .
  7. REPLACE REAR DIFFERENTIAL OIL (for Canada, Driving Conditions) HINT: Driving Conditions: Heavily loaded vehicle. Replace the rear differential oil. Refer to «REPLACEMENT [03/2012 - ]»(ref-600574-S33572424342014022400000) .
  8. TIGHTEN PROPELLER SHAFT BOLTS (for Canada, Road Conditions, Driving Conditions) HINT: Road Conditions: Operating on rough or muddy roads, or roads with melted snow, operating on dusty roads and operating on road which has road salt applied. Driving Conditions: Heavily loaded vehicle. Tighten the bolts for the propeller shaft. Type See procedure Propeller shaft Refer to «INSTALLATION [03/2012 - ]»(ref-600415-S18190355762014022400000)
  9. PERFORM TIRE ROTATION . Refer to «INSPECTION [03/2012 - ] - Step 2»(/lexus/gs/iv-2011-2015/remont/wheel-tire-system/#tires-wheel-system-inspection)
  10. INSPECT FRONT AND REAR SUSPENSION Check the front and rear suspension. Suspension Type See Procedure Front suspension Refer to «ADJUSTMENT [03/2012 - ]»(/lexus/gs/iv-2011-2015/remont/wheel-alignment/#wheel-alignment-inspection-adjustment__adjustment-032012) Rear suspension Refer to «ADJUSTMENT [03/2012 - ]»(/lexus/gs/iv-2011-2015/remont/wheel-alignment/#wheel-alignment-inspection-adjustment)
  1. BODY INSPECTION Check the body exterior for dents, scratches and rust. Check the underbody for rust and damage.
  2. REPLACE AIR CONDITIONING FILTER Remove the air conditioning filter. Refer to «DISASSEMBLY [03/2012 - ] - Step 1»(ref-600577-S13080845002014022400000) . Visually inspect the surface of the air conditioning filter. If the air conditioning filter is contaminated with foreign matter, replace it.
  3. ROAD TEST Check the engine and chassis for abnormal noises. Check that the brakes work properly and do not drag. Set the parking brake shoes and drums.
  4. TIGHTEN BOLTS AND NUTS ON CHASSIS Tighten the bolts and nuts on the chassis parts listed below, if necessary. Front axle and suspension Drivetrain Rear axle and suspension Brake system Engine mounting Other chassis parts Tighten the bolts and nuts on the body parts listed below, if necessary. Seat belt system Seats Doors and hood Body mountings Fuel tank Exhaust pipe system Other body parts
