Power Mirror Control (Diagnostics & Symptom Tests): Diagnosis Lexus GS IV

HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ]

HINT

1. Use the following procedures to troubleshoot the power mirror control system.
2. *: Use the Techstream.

1. VEHICLE BROUGHT TO WORKSHOP NEXT: Go to next step
2. INSPECT AUXILIARY BATTERY VOLTAGE Standard voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the auxiliary battery before proceeding to the next step. NEXT: Go to next step
3. CHECK COMMUNICATION FUNCTION OF LIN COMMUNICATION SYSTEM* Use the Techstream to check if the LIN communication system is functioning normally. RESULT Result Proceed to LIN DTC is not output A LIN DTC is output B B --> Go to LIN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ]»(ref-600622-S38803552542014022400000) A: Go to next step
4. CHECK COMMUNICATION FUNCTION OF CAN COMMUNICATION SYSTEM* Use the Techstream to check if the CAN communication system is functioning normally. Refer to «DIAGNOSIS SYSTEM [03/2012 - ]»(ref-600620-S06280412312014022400000) . RESULT Result Proceed to CAN DTC is not output A CAN DTC is output B B --> Go to CAN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [03/2012 - ]»(ref-600588-S38298476802014022400000) A: Go to next step
5. PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [03/2012 - ]»(ref-600433-S00078887162014022400000) . RESULT Result Proceed to Fault is not listed in Problem Symptoms Table A Fault is listed in Problem Symptoms Table B B --> ADJUST, REPAIR OR REPLACE IN ACCORDANCE WITH PROBLEM SYMPTOMS TABLE A: Go to next step
6. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check. Refer to «OPERATION CHECK [03/2012 - ]»(ref-600433-S32810621082014022400000) Data List / Active Test. Refer to «DATA LIST / ACTIVE TEST [03/2012 - ]»(ref-600433-S02279602982014022400000) Terminals of ECU. Refer to «TERMINALS OF ECU [03/2012 - ]»(ref-600433-S07994266512014022400000) NEXT: Go to next step
7. REPAIR OR REPLACE NEXT: Go to next step
8. CONFIRMATION TEST NEXT --> END

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

1. CHECK REMOTE CONTROL MIRROR FUNCTION Turn the power switch on (IG). With the mirror select switch set to L, check that the mirror surface moves up, down, left and right normally. With the mirror select switch set to R, check that the mirror surface moves up, down, left and right normally.
2. CHECK POWER RETRACTABLE MIRROR FUNCTION (w/ Retract Mirror) Turn the power switch on (IG). At each outer mirror actuator position, check the retractable mirror operation when operating the retractable outer mirror switch. Move the mirrors to the driving position. Turn the retractable outer mirror switch to the retract position. Check that the right and left outer mirror actuators move from the driving position to the retracted position. Move the mirrors to the driving position. Move one of the outer mirror actuators to the forward position by hand. Turn the retractable outer mirror switch to the retract position. Check that the outer mirror actuator in the forward position moves to the retracted position, and check that the other mirror also moves to the retracted position. Move the outer mirror actuators to driving position. Move one of the outer mirror actuators to the retracted position by hand. Turn the retractable outer mirror switch to the retract position. Check that the outer mirror actuator in the driving position moves to the retracted position. Move the mirrors to the retracted position. Turn the retractable outer mirror switch to the driving position. Check that the right and left mirrors move from the retracted position to the driving position. Move the mirrors to the retracted position. Move one of the outer mirror actuators to the driving position by hand. Turn the retractable outer mirror switch to the driving position. Check that the retracted outer mirror actuator moves to the driving position. Check the operation of the outer mirror actuator according to retract switch operations and power switch condition. When the outer mirror actuator is operating, turn the power switch off and check that the mirror operation does not stop and continues until the operation has finished. This time, turn the power switch on (ACC) and press the retract switch. Check that the outer mirror actuator operates in the opposite direction. Check the operation of the outer mirror actuator when it is blocked by an obstacle. When the outer mirror actuator is moving to the retracted or driving position, block the outer mirror actuator by hand. Check that the mirror stops moving. With the outer mirror actuator stopped partway, push the retract switch. Check that the outer mirror actuator moves in the opposite direction.
3. CHECK AUTO ELECTRIC RETRACT FUNCTION (w/ Retract Mirror) HINT: The default setting is Door Lock. If necessary, the function must be set to ACC through the customize function. With the power switch off and the retractable outer mirror switch AUTO, when the doors are unlocked through the entry, wireless or key-linked function, check that the outer mirror actuators move from the retracted position to the driving position, and then stop in the driving position. With the power switch off and the retractable outer mirror switch AUTO, when the doors are locked through the entry, wireless or key-linked function, check that the outer mirror actuators move from the driving position to the retracted position, and then stop in the retracted position. When the power switch is on (ACC) and then turned off while the retractable outer mirror switch is AUTO, check that both outer mirror actuators automatically move from the driving position to the retracted position. When the power switch is off and then turned on (ACC) while the retractable outer mirror switch is AUTO, check that both outer mirror actuators automatically move from the retracted position to the driving position.
4. CHECK MEMORY AND MIRROR RESTORING OPERATION TEXT IN ILLUSTRATION *1 SET Switch *2 M1 Switch *3 M2 Switch *4 M3 Switch HINT: If the M1 switch, M2 switch and M3 switch are simultaneously pressed while the SET switch is pressed and held, the seat position will not be stored. Turn the power switch on (IG) and move the shift lever to P. Check the M1 switch. Using the outer mirror switch, turn the mirror surface to the full left position. TEXT IN ILLUSTRATION *a Turn to Left Fully Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized when the M1 switch is pressed within 3 seconds after the SET switch is pressed. NOTE: The mirror surface position will also be stored when the M1 switch is pressed after first pressing and holding the SET switch. The mirror surface position will not be stored when the SET switch and M1 switch are pressed simultaneously. The mirror surface position will not be stored when 2 or more of the memory switches are pressed simultaneously (for example, M1 and M2) after first pressing the SET switch. Using the outer mirror switch, turn the mirror surface to the full right position. Press the M1 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded full left position. Check the M2 switch. Using the outer mirror switch, turn the mirror surface to the full right position. TEXT IN ILLUSTRATION *a Turn to Right Fully Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized when the M2 switch is pressed within 3 seconds after the SET switch is pressed. NOTE: The mirror surface position will also be stored when the M2 switch is pressed after first pressing and holding the SET switch. The mirror surface position will not be stored when the SET switch and M2 switch are pressed simultaneously. The mirror surface position will not be stored when 2 or more of the memory switches are pressed simultaneously (for example, M1 and M2) after first pressing the SET switch. Using the outer mirror switch, turn the mirror surface to the full left position. Press the M2 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded full right position. Check the M3 switch. Using the outer mirror switch, turn the mirror surface to the full left position. TEXT IN ILLUSTRATION *a Turn to Left Fully Check that the buzzer sounds for 0.5 seconds and the mirror surface position is memorized when the M3 switch is pressed within 3 seconds after the SET switch is pressed. NOTE: The mirror surface position will also be stored when the M3 switch is pressed after first pressing and holding the SET switch. The mirror surface position will not be stored when the SET switch and M3 switch are pressed simultaneously. The mirror surface position will not be stored when 2 or more of the memory switches are pressed simultaneously (for example, M2 and M3) after first pressing the SET switch. Using the outer mirror switch, turn the mirror surface to the full right position. Press the M3 switch. Check that the buzzer sounds for 0.1 seconds and the outer mirror automatically moves to the recorded full left position.
5. CHECK REVERSE SHIFT-LINKED OPERATION OF MIRRORS Turn the power switch on (IG). Set the mirror select switch to L or R. Check that the mirror surface turns downward when the shift lever is moved to R. Check that the mirror surface position returns to the original position when one of the following conditions is met: Shift lever is moved to any position other than R. Mirror select switch is in the neutral position (off). Power switch is turned off.
6. CHECK REVERSE SHIFT-LINKED MIRROR POSITION MEMORIZATION FUNCTION Turn the power switch on (IG). Set the mirror select switch to L or R. Check that the mirror surface turns downward when the shift lever is moved to R. While the mirror is in the reverse shift-linked operation position, move the mirror to the desired position. Check that the mirror moves to its normal position when the shift lever is moved to a different position from R, and then moves back to the memorized position when the shift lever is moved to R again.
7. CHECK MEMORY CALL FUNCTION Memory call function check. With a transmitter key recognition code registered: With the recognition code of the transmitter registered in memory, perform an entry unlock or wireless unlock operation. Open the driver door and check that the front seat, steering wheel (tilt & telescopic) and outer mirror surface position automatically move to the positions recorded in memory. Memory registration. Prepare by recording the driving position through the memory switch (M1, M2 or M3). With the power switch on (IG), press and hold both of the following: a memory switch (M1, M2 or M3) and manual door control switch (LOCK or UNLOCK). Continue holding the switches until the answer-back buzzer sounds once (0.5 seconds). NOTE: Do not bring 2 or more keys into the vehicle. Memory erasure. With the power switch on (IG), press and hold both of the following: the memory SET switch and manual door control switch (LOCK or UNLOCK). Continue holding the switches until the answer-back buzzer sounds twice (0.1 seconds each time). NOTE: Do not bring 2 or more keys into the vehicle.
8. CHECK MEMORY CALL EMERGENCY STOP FUNCTION While a memory call function is operating, check that any one of the following actions will stop the memory call operation: 1) pressing the SET, M1, M2 or M3 switch, 2) moving the shift lever to R, 3) moving the mirror surface manually, or 4) moving the mirror surface to the uppermost, lowermost, leftmost or rightmost position.
9. CHECK MIRROR HEATER Turn the power switch on (IG). Check that pressing the rear window defogger switch illuminates the indicator and warms the mirror surface. Check that after approximately 15 minutes, the indicator light turns off and the mirror heater deactivates. HINT: There is a timer extension function which can operate the mirror heater system for up to an additional 45 minutes.
10. CHECK AUTOMATIC GLARE-RESISTANT EC MIRROR FUNCTION Check that the automatic glare-resistant EC mirror function of the outer rear view mirror assembly operates when the automatic glare-resistant function of the inner rear view mirror assembly is operating.

PROBLEM SYMPTOMS TABLE [03/2012 - ]

HINT

1. Use the table below to help determine the cause of problem symptoms. If multiple suspected areas are listed, the potential causes of the symptoms are listed in order of probability in the "Suspected Area" column of the table. Check each symptom by checking the suspected areas in the order they are listed. Replace parts as necessary.
2. Inspect the fuses and relays related to this system before inspecting the suspected areas below.

POWER MIRROR CONTROL SYSTEM

1. *: w/ Windshield Deicer System

Scheme 20

Scheme 21

Scheme 22

1. CHECK FRONT MULTIPLEX NETWORK DOOR ECU LH Disconnect the Q19 ECU connector. Measure the voltage and resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition Q19-6 (BDR) - Body ground V - Body ground Power source Always 11 to 14 V Q19-4 (CPUB) - Body ground P - Body ground Power source Always 11 to 14 V Q19-16 (BCUT) - Body ground W - Body ground Power source Always 11 to 14 V Q19-3 (SIG) - Body ground B - Body ground Power source Power switch on (IG) 11 to 14 V Power switch off Below 1 V Q19-18 (ECI+) - Q19-19 (ECI-) P - GR Automatic glare-resistant EC mirror drive voltage Power switch on (IG) Automatic glare-resistant EC mirror off Below 1 V Power switch on (IG) Automatic glare-resistant EC mirror on 1.05 to 1.35 V Q19-1 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms Reconnect the Q19 ECU connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition z10-3 (MR) - Body ground* G - Body ground Power retract mirror motor drive voltage Power switch on (ACC) Outer mirror actuator LH being retracted 11 to 14 V Power switch on (ACC) Outer mirror actuator LH stopped Below 1 V z10-11 (MF) - Body ground* L - Body ground Power retract mirror motor drive voltage Power switch on (ACC) Outer mirror actuator LH returning 11 to 14 V Power switch on (ACC) Outer mirror actuator LH stopped Below 1 V z10-1 (MV) - Body ground W - Body ground Mirror motor drive voltage Power switch on (ACC) LH mirror surface stopped Below 1 V Power switch on (ACC) LH mirror surface moving downward or left Below 1 V Power switch on (ACC) LH mirror surface moving upward 11 to 14 V z10-9 (MH) - Body ground R - Body ground Mirror motor drive voltage Power switch on (ACC) LH mirror surface stopped Below 1 V Power switch on (ACC) LH mirror surface moving upward or right Below 1 V Power switch on (ACC) LH mirror surface moving left 11 to 14 V z10-10 (M+) - Body ground B - Body ground Mirror motor drive voltage Power switch on (ACC) LH mirror surface stopped Below 1 V Power switch on (ACC) LH mirror surface moving upward or left Below 1 V Power switch on (ACC) LH mirror surface moving downward or right 11 to 14 V z10-4 (+) - z10-12 (-) BR-W - B-R Mirror heater drive voltage Power switch on (IG) Rear window defogger switch on 11 to 14 V Power switch on (IG) Rear window defogger switch off Below 1 V z10-5 (VC) - z10-14 (E1) SB - GR Mirror position sensor power supply Power switch on (IG) 4.75 to 5.25 V Power switch off Below 1 V z10-6 (VSRL) - z10-14 (E1) V - GR Vertical direction position sensor signal Power switch on (ACC) LH mirror surface moving upward or downward 5 V Power switch on (ACC) LH mirror surface stopped Below 1 V z10-13 (HSRL) - z10-14 (E1) LG - GR Horizontal direction position sensor signal Power switch on (ACC) LH mirror surface moving left or right 5 V Power switch on (ACC) LH mirror surface stopped Below 1 V z10-7 (EC+) - z10-15 (EC-) BR - B-L Automatic glare-resistant EC mirror drive signal Power switch on (IG) Automatic glare-resistant EC mirror on 1.05 to 1.35 V Power switch on (IG) Automatic glare-resistant EC mirror off Below 1 V Q19-15 (CPBJ) - Q19-9 (SGND) P - W-B Power source Always 11 to 14 V Q19-22 (M1) - Q19-26 (MSWE) B - P Seat memory switch M1 signal Power switch on (IG) Seat memory switch M1 off Pulse generation Power switch on (IG) Seat memory switch M1 on Below 1 V Q19-23 (M2) - Q19-26 (MSWE) SB - P Seat memory switch M2 signal Power switch on (IG) Seat memory switch M2 off Pulse generation Power switch on (IG) Seat memory switch M2 on Below 1 V Q19-24 (M3) - Q19-26 (MSWE) V - P Seat memory switch M3 signal Power switch on (IG) Seat memory switch M3 off Pulse generation Power switch on (IG) Seat memory switch M3 on Below 1 V Q19-25 (MM) - Q19-26 (MSWE) LG - P Seat memory switch SET signal Power switch on (IG) Seat memory switch SET off Pulse generation Power switch on (IG) Seat memory switch SET on Below 1 V *: w/ Retract Mirror
2. CHECK FRONT MULTIPLEX NETWORK DOOR ECU RH Disconnect the Q4 ECU connector. Measure the voltage and resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition Q4-6 (BDR) - Body ground V - Body ground Power source Always 11 to 14 V Q4-4 (CPUB) - Body ground P - Body ground Power source Always 11 to 14 V Q4-3 (SIG) - Body ground B - Body ground Power source Power switch on (IG) 11 to 14 V Power switch off Below 1 V Q4-18 (ECI+) - Q4-19 (ECI-) P - GR Automatic glare-resistant EC mirror drive voltage Power switch on (IG) Automatic glare-resistant EC mirror off Below 1 V Power switch on (IG) Automatic glare-resistant EC mirror on 1.05 to 1.35 V Q4-1 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms Reconnect the Q4 ECU connector. Measure the voltage according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition z11-3 (MR) - Body ground* G - Body ground Power retract mirror motor drive voltage Power switch on (ACC) Outer mirror actuator RH being retracted 11 to 14 V Power switch on (ACC) Outer mirror actuator RH stopped Below 1 V z11-11 (MF) - Body ground* L - Body ground Power retract mirror motor drive voltage Power switch on (ACC) Outer mirror actuator RH returning 11 to 14 V Power switch on (ACC) Outer mirror actuator RH stopped Below 1 V z11-1 (MV) - Body ground W - Body ground Mirror motor drive voltage Power switch on (ACC) RH mirror surface stopped Below 1 V Power switch on (ACC) RH mirror surface moving downward or left Below 1 V Power switch on (ACC) RH mirror surface moving upward 11 to 14 V z11-9 (MH) - Body ground R - Body ground Mirror motor drive voltage Power switch on (ACC) RH mirror surface stopped Below 1 V Power switch on (ACC) RH mirror surface moving upward or right Below 1 V Power switch on (ACC) RH mirror surface moving left 11 to 14 V z11-10 (M+) - Body ground B - Body ground Mirror motor drive voltage Power switch on (ACC) RH mirror surface stopped Below 1 V Power switch on (ACC) RH mirror surface moving upward or left Below 1 V Power switch on (ACC) RH mirror surface moving downward or right 11 to 14 V z11-4 (+) - z11-12 (-) BR-W - B-R Mirror heater drive voltage Power switch on (IG) Rear window defogger switch on 11 to 14 V Power switch on (IG) Rear window defogger switch off Below 1 V z11-5 (VC) - z11-14 (E1) SB - GR Mirror position sensor power supply Power switch on (IG) 4.75 to 5.25 V Power switch off Below 1 V z11-6 (VSRR) - z11-14 (E1) V - GR Vertical direction position sensor signal Power switch on (ACC) RH mirror surface moving upward or downward 5 V Power switch on (ACC) RH mirror surface stopped Below 1 V z11-13 (HSRR) - z11-14 (E1) LG - GR Horizontal direction position sensor signal Power switch on (ACC) RH mirror surface moving left or right 5 V Power switch on (ACC) RH mirror surface stopped Below 1 V z11-7 (EC+) - z11-15 (EC-) BR - B-L Automatic glare-resistant EC mirror drive signal Power switch on (IG) Automatic glare-resistant EC mirror on 1.05 to 1.35 V Power switch on (IG) Automatic glare-resistant EC mirror off Below 1 V *: w/ Retract Mirror
3. CHECK MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Disconnect the Q25 switch connector. Measure the voltage and resistance according to the value(s) in the table below. Terminal No. (Symbol) Wiring Color Terminal Description Condition Specified Condition Q25-11 (B) - Body ground P - Body ground Power source Always 11 to 14 V Q25-12 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms

DATA LIST / ACTIVE TEST [03/2012 - ]

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under "Normal Condition" are reference values. Do not depend solely on these reference values when deciding whether a part is faulty or not. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body / (desired system) / Data List. According to the display on the Techstream, read the Data List. MASTER SWITCH Tester Display Measurement Item/Range Normal Condition Diagnostic Note Mirror Selection SW (L) Mirror select switch signal for LH mirror / ON or OFF ON: Mirror select switch in L position OFF: Mirror select switch off or in R position - Mirror Selection SW (R) Mirror select switch signal for RH mirror / ON or OFF ON: Mirror select switch in R position OFF: Mirror select switch off or in L position - Mirror Position SW (L) Mirror adjust switch signal (Left) / ON or OFF ON: Mirror adjust switch pressed left OFF: Mirror adjust switch not pressed left Check with the mirror select switch in the L or R position. Mirror Position SW (R) Mirror adjust switch signal (Right) / ON or OFF ON: Mirror adjust switch pressed right OFF: Mirror adjust switch not pressed right Check with the mirror select switch in the L or R position. Mirror Position SW (Up) Mirror adjust switch signal (Up) / ON or OFF ON: Mirror adjust switch pressed up OFF: Mirror adjust switch not pressed up Check with the mirror select switch in the L or R position. Mirror Position SW (Dwn) Mirror adjust switch signal (Down) / ON or OFF ON: Mirror adjust switch pressed down OFF: Mirror adjust switch not pressed down Check with the mirror select switch in the L or R position. Outer Mirror Fold SW* Retractable outer mirror switch signal / ON or OFF ON: Retractable outer mirror switch in retract position OFF: Retractable outer mirror switch not in retract position - Auto Mirror SW* Retractable outer mirror switch signal / ON or OFF ON: Retractable outer mirror switch in AUTO position OFF: Retractable outer mirror switch not in AUTO position - *: w/ Retract Mirror FRONT RIGHT DOOR / FRONT LEFT DOOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note Seat Memory Switch1*1 Seat memory switch M1 signal / ON or OFF ON: Seat memory switch M1 on OFF: Seat memory switch M1 off - Seat Memory Switch2*1 Seat memory switch M2 signal / ON or OFF ON: Seat memory switch M2 on OFF: Seat memory switch M2 off - Seat Memory Switch3*1 Seat memory switch M3 signal / ON or OFF ON: Seat memory switch M3 on OFF: Seat memory switch M3 off - Seat Memory Set SW*1 Seat memory switch SET signal / ON or OFF ON: Seat memory switch SET on OFF: Seat memory switch SET off - Mirror Memory No. 1 No. 1 mirror position memorized / OFF or ON ON: Memorized OFF: Not memorized - Mirror Memory No. 2 No. 2 mirror position memorized / OFF or ON ON: Memorized OFF: Not memorized - Mirror Memory No. 3 No. 3 mirror position memorized / OFF or ON ON: Memorized OFF: Not memorized - Mirror Memory No. 4 No. 4 mirror position memorized / OFF or ON ON: Memorized OFF: Not memorized - Mirror Memory No. 5 No. 5 mirror position memorized / OFF or ON ON: Memorized OFF: Not memorized - Mirror Memory No. 6 No. 6 mirror position memorized / OFF or ON ON: Memorized OFF: Not memorized - Mirror Memory(Rev) No. 1 Reverse shift-linked mirror position memorized / OFF or ON ON: Memorized OFF: Not memorized - Mirror Vertical Sensor Vol Vertical mirror position / MIN: 0, MAX: 4.98 V Within range of 0 to 4.98 V - Mirror Fold Detect*2 Condition of retractable outer mirror / Normal or Error Normal: Retractable outer mirror is normal Error: Retractable outer mirror is malfunction - *1: Front Left Door Only *2: w/ Retract Mirror
2. ACTIVE TEST HINT: Using the Techstream to perform Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body / (desired system) / Active Test. According to the display on the Techstream, perform the Active Test. FRONT RIGHT DOOR / FRONT LEFT DOOR Tester Display Test Part Control Range Diagnostic Note Mirror Up/Down Mirror vertical operation Up/Down - Mirror Right/Left Mirror horizontal operation Right/Left - Mirror Fold/Return* Mirror retract operation Fold/Return - Mirror Heater Mirror heater operation ON/OFF - *: w/ Retract Mirror

INSPECTION PROCEDURE

Note. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no CAN communication malfunctions before troubleshooting this problem. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no LIN communication malfunctions before troubleshooting this problem. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .

Note. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no CAN communication malfunctions before troubleshooting this problem. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no LIN communication malfunctions before troubleshooting this problem. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .

Note. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no CAN communication malfunctions before troubleshooting this problem. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no LIN communication malfunctions before troubleshooting this problem. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .

Note. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no CAN communication malfunctions before troubleshooting this problem. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no LIN communication malfunctions before troubleshooting this problem.

Note. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no CAN communication malfunctions before troubleshooting this problem. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no LIN communication malfunctions before troubleshooting this problem. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .

Note. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no CAN communication malfunctions before troubleshooting this problem. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no LIN communication malfunctions before troubleshooting this problem. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .

Note. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no CAN communication malfunctions before troubleshooting this problem. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .

Note. First perform the communication function inspections in How to Proceed with Troubleshooting to confirm that there are no CAN communication malfunctions before troubleshooting this problem. Recognition code registration is necessary when replacing the main body ECU (multiplex network body ECU). If the main body ECU (multiplex network body ECU) is replaced, refer to Registration. Refer to REGISTRATION [03/2012 - ] .

HINT

The reverse shift-linked function will not activate when the mirror select switch is in the neutral position (off).
