Pre-Collision System (Diagnostic Codes & Circuit Tests): Overview Lexus GS IV

Airbag 5 illustrations ~1984 words

DESCRIPTION

The seat belt control ECU receives collision information from the driving support ECU and skid control ECU via CAN communication, and tightens the seat belt by operating the motor inside the front seat outer belt assembly.

When DTC B2000 is detected, DTCs B2016, B2026, B2027, and B2035 will not be detected.

When DTC B2005 is detected, DTCs B2021, B2031, B2032, and B2035 will not be detected.

DTC CodeDTC Detection ConditionTrouble Area
B2000Short to the power supply in the seat belt motor RH circuit continues for 1 second or more.Front seat outer belt assembly RH Seat belt control ECU Harness or connector
B2005Short to the power supply in the seat belt motor LH circuit continues for 1 second or more.Front seat outer belt assembly LH Seat belt control ECU Harness or connector

Scheme 169

Scheme 169: WIRING DIAGRAM

Scheme 170

Scheme 170

The seat belt control ECU receives collision information from the driving support ECU and skid control ECU via CAN communication, and tightens the seat belt by operating the motor inside the front seat outer belt assembly.

When DTC B2001 is detected, DTCs B2015, B2026, and B2027 will not be detected.

When DTC B2006 is detected, DTCs B2020, B2031, and B2032 will not be detected.

DTC CodeDTC Detection ConditionTrouble Area
B2001Short to ground in the seat belt motor RH circuit continues for 1 second or more.Front seat outer belt assembly RH Seat belt control ECU Harness or connector
B2006Short to ground in the seat belt motor LH circuit continues for 1 second or more.Front seat outer belt assembly LH Seat belt control ECU Harness or connector

The seat belt control ECU receives collision information from the driving support ECU and skid control ECU via CAN communication, and tightens the seat belt by operating the motor inside the front seat outer belt assembly.

When DTC B2002 is detected, DTCs B2026 and B2027 will not be detected.

When DTC B2007 is detected, DTCs B2031 and B2032 will not be detected.

DTC CodeDTC Detection ConditionTrouble Area
B2002Open in the seat belt motor RH circuit continues for 1 second or more.Front seat outer belt assembly RH Seat belt control ECU Harness or connector
B2007Open in the seat belt motor LH circuit continues for 1 second or more.Front seat outer belt assembly LH Seat belt control ECU Harness or connector

The DTCs above are output during the seat belt control ECU's self diagnosis.

When DTC B2015 or B2016 is detected, DTCs B2026 and B2027 will not be detected.

When DTC B2020 or B2021 is detected, DTCs B2031 and B2032 will not be detected.

DTC CodeDTC Detection ConditionTrouble Area
B2015While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2016While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2020While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2021While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2025While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2026While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2027While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2030While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2031While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2032While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2035While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2040While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2041While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2043While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU
B2047While initial check is running and power switch is on (IG), seat belt control ECU detects an internal malfunction for 1 second.Seat belt control ECU

If the seat belt control ECU judges that there is a malfunction in its internal circuit as a result of self-diagnosis, or if the power source voltage (+B) is not input to the seat belt control ECU, this DTC will be stored.

DTC CodeDTC Detection ConditionTrouble Area
B2036Malfunction in seat belt control ECU Power source voltage (+B) is not input to the seat belt control ECU.Seat belt control ECU Harness or connector

Scheme 171

Scheme 171: WIRING DIAGRAM

This DTC is output when a malfunction in the brake system is detected. This circuit consists of the skid control ECU and seat belt control ECU. Signals are sent from the skid control ECU assembly to the seal belt control ECU through the CAN communication line.

When DTC B2060 is detected, ABS system DTCs will also be detected.

DTC CodeDTC Detection ConditionTrouble Area
B2060While initial check is running, power switch is on (IG) and pre-collision system is operating, Vehicle stability control system malfunction signal is received from skid control ECU assembly for 1 second.Electronically controlled brake system CAN communication system Seat belt control ECU assembly

The seat belt control ECU is connected to the main body ECU (multiplex network body ECU) through CAN communication.

The seat belt control ECU receives vehicle model information from the main body ECU (multiplex network body ECU) and determines whether the seat belt buckle switch information from the airbag sensor center is for the driver seat or the front passenger seat.

DTC B2064 is output when CAN communication with the main body ECU is normal and when communication is available, but the steering wheel position information is not set or varies.

DTC CodeDTC Detection ConditionTrouble Area
B2064While the initial check is running, the steering wheel position information is not received for 3 seconds or more.Main body ECU (multiplex network body ECU) CAN communication system Seat belt control ECU

The seat belt control ECU receives buckle switch condition information from the center airbag sensor through the CAN communication line and controls the pre-collision system.

This code is output when a buckle switch malfunction signal is received from the airbag system.

When DTC B2074 is detected, DTC B1655 is also output.

When DTC B2075 is detected, DTC B1650 is also output.

DTC CodeDTC Detection ConditionTrouble Area
B2074Open or short to ground in the front seat inner belt assembly LH (buckle switch) circuit continues for 1 second or more.Airbag system Front seat inner belt assembly LH Seat belt control ECU
B2075Open or short to ground in the front seat inner belt assembly RH (buckle switch) circuit continues for 1 second or more.Airbag system Front seat inner belt assembly RH Seat belt control ECU

This DTC is stored when CAN communication between the driving support ECU and skid control ECU assembly is interrupted.

This circuit consists of the driving support ECU, skid control ECU assembly and seat belt control ECU. DTC B2085 is stored when the seat belt control ECU detects an interruption in CAN communication between the driving support ECU and skid control ECU assembly.

DTC CodeDTC Detection ConditionTrouble Area
B2085When the power switch is on (IG), the skid control ECU assembly detects an interruption in communication with the driving support ECU for 1 second or more.CAN communication system Skid control ECU assembly Seat belt control ECU Driving support ECU

The seat belt control ECU receives collision information from the driving support ECU and skid control ECU assembly via CAN communication, and tightens the seat belt by operating the motor inside the front seat outer belt assembly.

When the driving support ECU detects a malfunction in the cruise control system, dynamic radar cruise control system, lane-keeping assist system, and pre-collision system ("Pre-Collision 2" part), or detects that the lane recognition camera sensor has not been adjusted, the malfunction information is sent to the seat belt control ECU, which outputs this DTC.

When DTC B2090 is detected, other DTCs output by the driving support ECU (cruise control system, dynamic radar cruise control system, lane-keeping assist system, Pre-Collision 2) are also output.

HINT

If the object recognition camera sensor is replaced with a new one and the adjustment of the lane recognition camera sensor has not been performed, DTC B2090 is output.

DTC CodeDTC Detection ConditionTrouble Area
B2090While the initial check is running, the power switch is on (IG) and the pre-collision system is operating, the driving support ECU detects a malfunction for 1 second or more, or the state in which the lane recognition camera sensor assembly beam axis adjustment has not been performed is detected for 1 second or more.Cruise control system Dynamic radar cruise control system Lane-keeping assist system Seat belt control ECU

The driving support ECU uses the millimeter wave radar sensor to detect obstacles in front of the vehicle.

Based on this information, the driving support ECU calculates the risk of a collision and operates the pre-collision system when it determines that the risk is high.

DTC CodeDTC Detection ConditionTrouble Area
C1A01While the initial check is running, the power switch is on (IG) and the pre-collision system is operating, an internal malfunction is detected in the driving support ECU for 2 seconds or more.Driving support ECU

When a new driving support ECU is installed, the new ECU receives and stores country specification information from the main body ECU (multiplex network body ECU). DTC C1A02 is stored when the driving support ECU receives the vehicle specification information from the main body ECU but cannot record it.

DTC CodeDTC Detection ConditionTrouble Area
C1A02While the power switch is on (IG) and the pre-collision system is operating, the vehicle information in the driving support ECU has not been set for 1 second or more while the vehicle is being driven at a speed of 50 km/h (31 mph) or more.Main body ECU (multiplex network body ECU) Driving support ECU

The driving support ECU uses the millimeter wave radar sensor to detect obstacles in front of the vehicle. Based on this information, the driving support ECU sends pre-collision control operation signals.

When the millimeter wave radar sensor is replaced with a new one, it acquires the country specification information from the driving support ECU. Also, when the driving support ECU is replaced with a new one, it receives country specification information from the main body ECU. When country specification information in the sensor, ECU and/or main body ECU do not match, DTC C1A0A is stored.

DTC CodeDTC Detection ConditionTrouble Area
C1A0AWhile the initial check is running, the power switch is on (IG) and the pre-collision system is operating, the country specification information in the driving support ECU and the front millimeter wave radar sensor do not match for 2 seconds or more.Millimeter wave radar sensor assembly Driving support ECU

When the Lane recognition camera sensor is replaced with a new one, it acquires the country specification information from the driving support ECU. Also, when the driving support ECU is replaced with a new one, it receives country specification information from the combination meter. When country specification information in the Lane recognition camera sensor and driver monitor ECU do not match, DTC C1A0C is output.

If the sensor and vehicle country specification information are the same, and the combination meter and the driving support ECU country specification information are different, C1A0A is output.

DTC CodeDTC Detection ConditionTrouble Area
C1A0CWhile the initial check is running, the power switch is on (IG) and the pre-collision system is operating, the country specification information in the driving support ECU and lane recognition camera sensor assembly do not match for 2 seconds or more.Lane recognition camera sensor assembly Driving support ECU

The driving support ECU uses the millimeter wave radar sensor to detect obstacles in front of the vehicle. Based on this information, the driving support ECU sends pre-collision control operation signals.

When the driving support ECU receives information that there is a malfunction in the millimeter wave radar sensor, DTC C1A10 is output.

DTC CodeDTC Detection ConditionTrouble Area
C1A10While the power switch is on (IG), there is a malfunction in the front millimeter wave radar sensor for 2 seconds or more.Millimeter wave radar sensor assembly Driving support ECU

When the vehicle is determined to be moving in a straight line according to the signal from the yaw rate sensor, the millimeter wave radar sensor assembly performs a self-diagnosis to check whether its beam axis is misaligned. When it is determined that the vehicle in front is off to the side for a long period of time (10 hours at approximately 50 km/h (31 mph)), the millimeter wave radar sensor assembly determines that its beam axis is misaligned and DTC C1A11 is stored. Also, if the millimeter wave radar sensor assembly is installed at an angle with respect to the vehicle, the millimeter wave radar sensor assembly makes the same determination. After a new millimeter wave radar sensor assembly is installed, if the millimeter wave radar sensor beam axis adjustment is not performed, DTC C1A14 is stored.

DTC CodeDTC Detection ConditionTrouble Area
C1A11When the power switch is on (IG), a misalignment of the millimeter wave radar sensor beam axis is detected for 2 seconds or more.Millimeter wave radar sensor assembly Driving support ECU
C1A14When the vehicle is being driven at 10 km/h (6 mph) or more, the state in which the millimeter wave radar sensor adjustment has not been performed is detected for 2 seconds or more.Millimeter wave radar sensor assembly Driving support ECU

This DTC is stored when the driving support ECU receives information that the lane recognition camera sensor assembly has an internal malfunction.

DTC CodeDTC Detection ConditionTrouble Area
C1A20Pre-collision system: The power switch is on (IG). Radar cruise control system: The vehicle is being driven at a speed of approximately 50 km/h (31 mph) or more and the ACC main switch is on. Lane keeping assist system: The vehicle is being driven at a speed of approximately 50 km/h (31 mph) or more and the lane keeping assist main switch is on. When the conditions above are met, the driving support ECU detects a problem in the signal sent from the lane recognition camera sensor assembly.Lane recognition camera sensor assembly Driving support ECU

When it has been determined that the beam axis of the lane recognition camera sensor assembly has deviated, DTC C1A22 is stored.

After installing a new lane recognition camera sensor assembly, if camera beam axis adjustment is not performed, DTC C1A23 is stored.

When the distance from an object detected by the left and right camera greatly differs from the distance detected by the millimeter wave radar sensor assembly, DTC C1A25 is stored.

DTC CodeDTC Detection ConditionTrouble Area
C1A22Pre-collision system: The power switch is on (IG). Radar cruise control system: The vehicle is being driven at a speed of approximately 50 km/h (31 mph) or more and the ACC main switch is on. Lane keeping assist system: The vehicle is being driven at a speed of approximately 50 km/h (31 mph) or more and the lane keeping assist main switch is on. When the conditions above are met, a misalignment of the lane recognition camera sensor assembly is detected for 2 seconds or more.Lane recognition camera sensor assembly Driving support ECU
C1A23Pre-collision system: The vehicle is being driven at a speed of approximately 10 km/h (6 mph) or more. Radar cruise control system: The vehicle is being driven at a speed of approximately 50 km/h (31 mph) or more and the ACC main switch is on. Lane keeping assist system: The vehicle is being driven at a speed of approximately 50 km/h (31 mph) or more and the lane keeping assist main switch is on. When the conditions above are met, the state in which the lane recognition camera sensor assembly adjustment has not been performed continues for 2 seconds or more.Lane recognition camera sensor assembly Driving support ECU

The driving support ECU uses the millimeter wave radar sensor, driver monitor camera and lane recognition camera sensor to detect obstacles in front of and behind the vehicle, and detect the direction that the driver's head is facing. Based on this information, the driving support ECU sends pre-collision control operation signals.

When the driving support ECU receives information that there is a malfunction in the driver monitor ECU, DTC C1A30 is output.

DTC CodeDTC Detection ConditionTrouble Area
C1A30While the power switch is on (IG), a malfunction in the driver monitor ECU is detected for 2 seconds or more.Driver monitor ECU Driving support ECU

The driving support ECU uses the millimeter wave radar sensor, driver monitor camera and lane recognition camera sensor to detect obstacles in front of and behind the vehicle, and detect the direction that the driver's head is facing. Based on this information, the driving support ECU sends pre-collision control operation signals.

When the driving support ECU receives information that there is a malfunction in the driver monitor camera, DTC C1A31 is output.

DTC CodeDTC Detection ConditionTrouble Area
C1A31While the power switch is on (IG), a malfunction in the driver monitor camera is detected for 2 seconds or more.Driver monitor camera Driving support ECU

When the driving support ECU receives a hybrid control system or SFI system malfunction signal, DTC C1A40 is stored.

DTC CodeDTC Detection ConditionTrouble Area
C1A40Diagnosis condition for each system: Pre-collision system: Power switch on (IG) Radar cruise control system: Vehicle is being driven at speed of approximately 50 km/h (31 mph) or more and distance control switch is on Driving support ECU detects problem with hybrid control system transmission signalHybrid control system Hybrid vehicle control ECU SFI system ECM Driving support ECU

The skid control ECU assembly receives brake control request signals from the power management control ECU and driving support ECU.

When the request signals received from the power management control ECU and driving support ECU are not consistent, the skid control ECU assembly determines that a malfunction has occurred and sends a malfunction signal to the driving support ECU.

If the driving support ECU receives a malfunction signal, DTC C1A41 is stored.

DTC CodeDTC Detection ConditionTrouble Area
C1A41While power switch is on (IG), brake request signal from power management control ECU and driving support ECU are inconsistent for approximately 1 second.Electronically controlled brake system Hybrid control system Skid control ECU assembly Power management control ECU Driving support ECU

The skid control ECU assembly receives vehicle stability signals from the yaw rate sensor and sends the signals to the driving support ECU and ECM. If the skid control ECU assembly detects that the yaw rate sensor is malfunctioning, the skid control ECU assembly sends a malfunction signal to the driving support ECU and outputs DTC C1A46. Also, when DTC C1A46 is output, the skid control ECU outputs DTC C1234 at the same time.

When DTC C1A46 is detected, DTC C1234 is also output from the "ABS/VSC/TRAC".

DTC CodeDTC Detection ConditionTrouble Area
C1A46While the vehicle speed is 5 km/h (3 mph) or more, a yaw rate sensor malfunction signal is received from the skid control ECU assembly for 13 seconds or more.Yaw rate sensor Skid control ECU assembly Driving support ECU

The skid control ECU assembly receives steering rotation angle information from the spiral cable sub-assembly, and sends the information to the driving support ECU through the CAN communication line.

When DTC C1A47 is detected, DTC C1231 is also output from the "ABS/VSC/TRAC".

DTC CodeDTC Detection ConditionTrouble Area
C1A47While the vehicle speed is 50 km/h (31 mph) or more, a steering angle sensor malfunction signal is received from the skid control ECU assembly for 2 seconds or more.Electronically controlled brake system Driving support ECU

Based on pre-collision control, the driving support ECU informs to the driver to be careful. The driving support ECU performs this by sending a sounding signal to the skid control ECU assembly to sound the skid control buzzer.

When the skid control ECU assembly detects a malfunction in the skid control buzzer circuit, a malfunction signal is sent to the driving support ECU, and a DTC is output. Although the skid control ECU assembly sends a malfunction signal to the driving support ECU, the ABS does not output a relevant malfunction detection DTC.

DTC CodeDTC Detection ConditionTrouble Area
C1A4AWhile the power switch is on (IG), a skid control buzzer circuit malfunction signal is received from the skid control ECU assembly for 3 seconds or more.Skid control buzzer Skid control buzzer circuit Skid control ECU assembly Driving support ECU

The skid control ECU assembly outputs a stop light operation signal to the stop light control relay. When the skid control ECU assembly detects a malfunction in the circuit related to the stop light, it informs the driving support ECU via CAN communication and stores DTC C1A4B.

DTC CodeDTC Detection ConditionTrouble Area
C1A4BWhen the IG1 terminal voltage is between 11 and 14 V, there is no input signal to terminal STP2 of the skid control ECU assembly for 5 seconds or more when the stop light illumination output (STP0) of the skid control ECU assembly is ON, or the input signals to terminals STP and STP2 of the skid control ECU assembly are different for 5 seconds or more when the stop light illumination output (STP0) of the skid control ECU assembly is OFF.Light system No. 2 integration relay Skid control ECU assembly Driving support ECU Harness or connector

During vehicle-to-vehicle distance control mode, when the actual vehicle speed exceeds the set vehicle speed, such as on a steep downhill slope, etc., the driving support ECU sends a brake control signal to the skid control ECU assembly, and deceleration control is performed together with throttle valve control. When a malfunction occurs in the electronically controlled brake system which is controlled by the skid control ECU assembly, this DTC is stored.

DTC CodeDTC Detection ConditionTrouble Area
C1A50When the radar cruise control system is operating, the input malfunction signal from the skid control ECU assembly continues for 0.2 seconds or more.Electronically controlled brake system Driving support ECU

The driving support ECU uses the front millimeter wave radar sensor, driver monitor camera and lane recognition camera sensor to detect obstacles in front of and behind the vehicle, and detect the direction that the driver's head is facing. Based on this information, the driving support ECU sends pre-collision control operation signals.

This DTC is output when a communication malfunction occurs between the sensors and ECUs that detect collisions, or between ECUs that perform the pre-collision control.

DTC CodeDTC Detection ConditionTrouble Area
U0125The driving support ECU is unable to receive certain data from the yaw rate sensor for 0.77 seconds or more.CAN communication system Yaw rate sensor Driving support ECU
U0126The driving support ECU is unable to receive certain data from the spiral with sensor cable sub-assembly (steering angle sensor) for 3.76 seconds or more.CAN communication system Spiral with sensor cable sub-assembly Driving support ECU
U0129The driving support ECU is unable to receive certain data from the skid control ECU assembly for 5.24 seconds or more.CAN communication system Skid control ECU assembly Seat belt control ECU Driving support ECU
U0142The driving support ECU is unable to receive certain data from the main body ECU (multiplex network body ECU) for 14.2 seconds or more.CAN communication system Main body ECU (multiplex network body ECU) Driving support ECU
U0235The data sent to the driving support ECU from the millimeter wave radar sensor assembly is abnormal for 0.65 second or more.CAN communication system Millimeter wave radar sensor assembly Driving support ECU
U0293The driving support ECU is unable to receive certain data from the power management control ECU for 3.8 seconds or more.CAN communication system Power management control ECU Driving support ECU
U1002The driving support ECU detects a problem when communicating with the millimeter wave radar sensor assembly, lane recognition camera sensor assembly, driver monitor ECU assembly.CAN communication system Millimeter wave radar sensor assembly Lane recognition camera sensor assembly Driving support ECU
U1100The driving support ECU is unable to receive certain data from the seat belt control ECU for 8.6 seconds or more.CAN communication system Seat belt control ECU Driving support ECU
U1104The driving support ECU data sent to the millimeter wave radar sensor assembly or driver monitor ECU assembly is lost for 0.35 seconds or more.CAN communication system Lane recognition camera sensor assembly Driving support ECU
U1119The driving support ECU is unable to receive certain data from the lane recognition camera sensor assembly for 0.65 second or more.CAN communication system Lane recognition camera sensor assembly Driving support ECU
U1121The driving support ECU is unable to receive certain data from the driver monitor ECU assembly for 1.93 second or more.CAN communication system Driver monitor ECU Driving support ECU

The driving support ECU receives pre-collision cancel on/off signals from the pre-collision system cancel switch assembly.

Scheme 172

Scheme 172: WIRING DIAGRAM

This circuit supplies power to the seat belt control ECU when the power switch is on (IG).

Scheme 173

Scheme 173: WIRING DIAGRAM
