CUSTOMIZE PARAMETERS

HINT

The following can be customized.

Note. When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting.

Scheme 68

Scheme 69

Scheme 70

1. POWER TILT AND POWER TELESCOPIC STEERING COLUMN SYSTEM Tilt & Telescopic DISPLAY DEFAULT CONTENTS SETTING Autoaway/Return function ON ON/OFF of the auto away/return function ON/OFF
2. AIR CONDITIONING SYSTEM Air Conditioner Tester Display Default Contents Setting Shift Set Temperature (Set Temp Shift) NORMAL To control with the shifted temperature against the display temperature +2 C / +1 C / NORMAL / -1 C / -2 C Air Inlet Mode (Air Inlet Mode) AUTO In case of turning the A/C ON when you desire to make the compartment cool down quickly, this is the function to change the mode automatically to RECIRCULATION mode MANUAL / AUTO Compressor Mode (Compressor Mode) AUTO Function to turn the A/C ON automatically by pressing the AUTO button when the blower is ON and the A/C is OFF MANUAL / AUTO Compressor/DEF Mode (Comprs/DEF Oper) LINK Function to turn the A/C ON automatically linked with the FRONT DEF button when A/C OFF MANUAL / LINK Evaporator Control (Evap Ctrl) AUTO Function to set the evaporator control to the AUTOMATIC position (AUTO) to save power, or to the coldest position (MANUAL) to dehumidify the air and to prevent the windows from fogging up MANUAL / AUTO Emission Gas Sensor Shift (Gas Sens Shift) NORMAL Function to change the sensitivity of the exhaust gas sensor MU MORE / MORE / LI MORE / NORMAL / LI LESS / LESS / MU LESS Button Press Buzzer (Button Prs Buz) ON Function to sound a buzzer when button is pressed OFF / ON Foot/DEF Auto Mode (Foot/DEF Mode) ON Function to turn the airflow from FOOT / DEF ON automatically when AUTO MODE is ON OFF / ON Foot/DEF Auto Blow Up (Auto Blow Up) ON Function to change the blower level automatically when the defroster is ON OFF / ON Ambient Temperature Shift (Ambient Tmp Sft) NORMAL Function to control the shifted ambient temperature in relation to the displayed ambient temperature +3 C / +2 C / +1 C / NORMAL / -1 C / -2 C / -3 C Foot Air Leak (Foot Air Leak) ON Function to cut off the airstream felt underfoot while the vehicle is moving OFF / ON
3. THEFT DETERRENT SYSTEM Security Display (Item) Default Contents Setting Warning by Horn ON Function that allows vehicle horns and theft deterrent horn to be used as warning device. ON/OFF Passive Mode OFF Passive mode is a function that switches theft deterrent system from arming preparation state to armed state 30 seconds after key is not inside vehicle and driver side door is closed. In passive mode, theft deterrent system will judge that a theft is taking place and switch to alarm sounding state if one of the following operations are not performed within 14 seconds (see entry delay below) after door is opened: Unlock any door by key or wireless operation Turn the engine switch on (ACC or IG) 2 seconds have passed after turn the engine switch on (IG) ON/OFF Entry Delay Time* 14s Function that changes entry delay time (time before warning starts) for PASSIVE MODE 0 s/14 s/ 30 s HINT: *: w/o Intrusion Sensor
4. LIGHTING SYSTEM Illuminated Entry Display Default Contents Setting I/L when ACC OFF ON Function to light the interior light when the engine switch is operated from on (IG) to off ON / OFF Lighting Time 15s To change the lighting time after closing the door. (It will quickly fade out in case of turning the engine switch on (IG)) 7.5s / 15s / 30s Light Control ON Function to light up the step light and door inside handle light when the engine switch is on (IG) and the shift position is not P. ON / OFF I/L ON W / Unlock ON Function to light, the interior light etc. when the door is unlocked with a transmitter, door key or door lock control switch. ON / OFF Foot Light Set Up ON Function to light up foot light. ON / OFF Seat Light Control AVAIL Function to light up the seat light when unlocking with the door key cylinder. NOT AVL / AVAIL Steering Light Control AVAIL Function to light up the steering light when unlocking with the door key cylinder. NOT AVL / AVAIL Shift Light Control AVAIL Function to light up the shift light when unlocking with the door key cylinder. NOT AVL / AVAIL HINT: Sensitivity adjustment can hardly be confirmed. Check by driving the customer's vehicle. Light Control Display Default Contents Setting Light Auto OFF Delay 30s Function to keep on lighting the headlight for a certain period of time after closing all the doors with the engine switch turned off from on (IG) to off under the condition that the light control switch is at HEAD or AUTO with the headlight ON. OFF / 30s / 60s / 90s Sensitivity NORMAL To adjust the sensitivity of the lighting illumination. *1 LIGHT2 / LIGHT1 / NORMAL / DARK1 / DARK2 Disp Ex ON Sen NORMAL Changes the brightness when lowering lights such as the combination meter indicator light, A/C indicator light, and clocklamp. Refer to the «Illustration *2»(ref-382578-S17981611812011012800000) LIGHT2 / LIGHT1 / NORMAL / DARK1 / DARK2 Disp Ex OFF Sen NORMAL Changes the brightness when lowering lights such as the combination meter indicator light, A/C indicator light, and clocklamp. Refer to the «Illustration *3»(ref-382578-S26315618732011012800000) LIGHT2 / LIGHT1 / NORMAL / DARK1 / DARK2 Foot Light Time (Driver's Side) 15s Function to set how long the foot light stays on (driver's side). OFF / 7.5s / 15s / 30s Foot Light Time (Passenger's Side) 15s Function to set how long the foot light stays on (passenger's side). OFF / 7.5s / 15s / 30s DRL Function* ON DRL control ON / OFF HINT: *:Except Canada Illustration *1 Lighting Brightness Setting DARK2 DARK1 NORMAL LIGHT1 LIGHT2 Illustration *2 Brightness of lowering the lights Setting DARK2 DARK1 NORMAL LIGHT1 LIGHT2 Illustration *3 Brightness when canceling the lowering of the lights Setting DARK2 DARK1 NORMAL LIGHT1 LIGHT2
5. LIGHTING SYSTEM (Door linked personal light illumination control) Mode 1: When door is opened, personal light of opened door illuminates Mode 2: When door is opened, both front personal lights and rear personal lights illuminate Mode 3: Front personal lights and rear personal lights are not linked to doors To change modes, press the map light assembly DOOR and ON switch simultaneously, and then turn the engine switch from off to on (IG). Each this operation will change the mode (Mode 1 --> Mode 2 --> Mode 3 --> Mode 1). HINT: After changing modes, the front personal lights respond by blinking as follows: Mode 1: once Mode 2: twice Mode 3: three times
6. LIGHTING SYSTEM (Map light assembly ON switch linked illumination control) Mode 4: When map light assembly ON switch is pressed, front personal lights, rear personal lights, front seat lights and rear seat lights illuminate Mode 5: When map light assembly ON switch is pressed, front seat lights and rear seat lights illuminate To change modes, press the map light assembly ON, DOOR and OFF switches simultaneously, and then turn the engine switch from off to on (IG). Each this operation will change the mode (Mode 4 --> Mode 5 --> Mode 4). HINT: After changing modes, the front personal lights responds by blinking as follows: Mode 4: four times Mode 5: five times
7. WIPER AND WASHER SYSTEM Wiper Display (Item) Default Contents Setting Auto Wiper Available Function to operate the wiper automatically when it is raining Not Available / Available Re-wiper Control Speed Mode Function to change the time between end of wiper motor operation and start of wiper operation to prevent streaking from washer fluid OFF / 3s / Speed Mode Speed Mode Available Function to change to the intermittent operation when the vehicle comes to a stop from driving condition with the wiper switch in the LO position Not Available / Available
8. POWER DOOR LOCK CONTROL SYSTEM Power door lock control system Tester Display Default Contents Setting Unlock/Park ON OFF*1 Function that unlocks all doors when lever is shifted to P from any position other than P while the engine switch is on (IG) ON/OFF All Unlock/Open-Close OFF Function that unlock all other doors when opening driver door within 10 seconds after turning the engine switch is on (IG) ON/OFF Unlock/Key Twice ON Function that unlocks only driver side door when driver side door key cylinder is turned to unlock once, and unlock all doors when it is turned to unlock twice. For OFF setting, turning it once unlocks all doors ON/OFF Auto Lock OFF ON*2 Function that locks all doors when vehicle speed reaches a certain level ON/OFF Auto Lock/Shift ON OFF*2 Function that locks all doors when lever is shifted to P from any position other than P ON/OFF *1: for Taiwan *2: for Korea and Taiwan
9. WIRELESS DOOR LOCK CONTROL SYSTEM Wireless door lock control system Display (Item) Default Contents Setting Hazard Answer Back ON When wireless lock switch on transmitter is pressed, this function illuminates all hazard warning lights once. When unlock switch is pressed, all hazard warning lights illuminate twice ON / OFF Wireless Control ON ON /OFF of the wireless door lock function ON / OFF Open Door Warning ON If door is not completely closed and transmitter LOCK switch is pressed, this function makes buzzer sound for 10 seconds ON / OFF Trunk Lid Operation 0.8 PR This function changes transmitter operation method for opening luggage compartment door 1 time / 2 times/ 0.8 PR / OFF Panic Function ON Function to operate theft deterrent system by continuously pressing panic switch on transmitter for 2.5 seconds. ON / OFF Unlock 2 Operation ON This function unlocks the driver side door when UNLOCK is pressed once, and unlocks all doors when pressed twice. If set to OFF, pressing UNLOCK once unlocks all doors. ON / OFF Auto Lock Time 60 s To change time until relocking after unlocking with wireless door lock function 30 s / 60 s / 120 s Wireless Buzzer Resp ON ON / OFF on wireless buzzer response function ON / OFF Wireless Auto Lock ON This function controls unlocking doors to automatic relocking function ON / OFF
10. SMART ACCESS SYSTEM WITH PUSH-BUTTON START (FOR DOOR LOCK) Smart access system with push-button start Tester Display Default Contents Setting Park Wait Time 2.5s Function that sets waiting time to permit opening door after door is locked with entry lock function 0.5s / 1.5s / 2.5s / 5.0s Trunk Open Mode ON Function that permits opening luggage compartment door ON / OFF Key Low Battery Warning ON Function that warns driver that key battery power is low ON / OFF Ignition Available Area All Function that chooses the available area for electrical key to start engine and release the steering lock. All / FRONT
11. SMART ACCESS SYSTEM WITH PUSH-BUTTON START (FOR DOOR LOCK) (ENTRY UNLOCK MODE SWITCHING FUNCTION) NOTE: Because the key (for card type) does not have a wireless transmitter function, it cannot be used to change the entry unlock mode. Check that the power source mode is off and the LED on the key is not blinking. Press the LOCK switch and one of the other switches on the key at the same time for approximately 5 seconds while the key is in the actuation area. Driver door unlock default setting: When the switches are pressed and held for 5 seconds, the entry door unlock mode changes in the following order: driver door mode, one door mode, doors on one side mode, all doors mode. NOTE: After pressing and holding the switches for 5 seconds, wait 5 seconds before performing the same procedure again. Driver door unlock mode: When the driver door touch sensor is touched, only the driver door unlocks. When another touch sensor is touched, all doors unlock. All door unlock mode: When a touch sensor is touched, all doors unlock. One door mode: When a touch sensor is touched, the touch sensor door unlocks. For example, if the driver door touch sensor is touched, the driver door unlocks. Doors on one side mode: When a touch sensor is touched, the doors on the side of the touch sensor unlock. For example, when the driver door touch sensor is touched, the driver door and driver side rear door unlock. The certification ECU receives this signal from the entry door control receiver and changes the smart access system with push-button start to the entry unlock mode. The certification ECU sounds the buzzers of the wireless door lock buzzer and combination meter to inform the user that the mode has been switched. HINT: The function only changes the entry unlock mode of the smart access system with push-button start. It does not switch the unlocking of the wireless door lock control.
12. SMART ACCESS SYSTEM WITH PUSH-BUTTON START (FOR DOOR LOCK) (KEY CANCEL) NOTE: Because the key (for card type) does not have a wireless transmitter function, it cannot be used to perform the key cancel operation. The key cancel operation disables the following functions: Entry Ignition Entry Unlock / Lock Entry Luggage Compartment Open Key Lock-in Prevention Warning Memory Call The operation procedure is as follows: Precondition: Engine switch off, driver side door closed and unlocked Unlock the driver side door once with the UNLOCK switch of the key. Open the driver door within 5 seconds. Unlock the driver side door twice with the UNLOCK switch of the key within 5 seconds. Close and open the driver door twice within 30 seconds. (Driver door: Close --> Open --> Close --> Open) Unlock the driver side door twice with the UNLOCK switch of the key within 5 seconds. Close and open the driver door within 30 seconds. (Driver door: Close --> Open) Close the driver door within 5 seconds. When key cancel is activated, the wireless door lock buzzer sounds twice. To return to the original condition, perform this procedure again. When the original condition is returned, the wireless door lock buzzer sounds once.
13. METER / GAUGE SYSTEM Combination Meter: Tester Display Default Contents Setting Key Remind Volume Large To change the volume of the key reminder buzzer Large / Medium / Small Key Remind Sound Normal To change the frequency of the key reminder buzzer Normal / Fast / Slow Language * French To change the language of the multi-information display French / English *: for Canada
14. INTUITIVE PARKING ASSIST SYSTEM Warning Tester Display DEFAULT CONTENTS SETTING Front Buzzer Onset Range Wide Function to set front buzzer activation range Narrow / Wide Rear Buzzer Onset Range Wide Function to set rear buzzer activation range Narrow / Wide Keep Sense Status Buzzer ON Function to make buzzer sound when distance between vehicle and obstacle does not change for more than 3 seconds ON / OFF Fr & Rr Buzzer Volume M2 Function to change volume of buzzer L / M1 / M2 / M3 / H Sensor Tester Display DEFAULT CONTENTS SETTING Sensor Condition N Range OFF Function to make sensors available when shift position is N OFF / ON Sonar Mode Steering Function to change sonar mode Normal / Steering Display Tester Display DEFAULT CONTENTS SETTING Display Mode Guide Function to change display mode All / Guide / Undisp
15. POWER WINDOW CONTROL SYSTEM Power Window Tester Display Default Contents Setting Door Key Linked P/W Up ON Function that raises all engine windows when, with engine switch off, key is used to hold driver door key cylinder to lock position for more than 2.3 seconds ON/OFF Door Key Linked P/W Down ON Function that lowers all engine windows when, with engine switch off, key is used to hold driver door key cylinder to unlock position for more than 2.3 seconds ON/OFF P/W Down w/ Transmitter ON Function that lowers all engine windows when, with engine switch off, unlock switch on transmitter is pressed and held for more than 3.0 seconds ON/OFF
16. REAR SUNSHADE SYSTEM Rear Sunshade System Tester Display Contents Default Selection Automatic Transmission Reverse Signal Response Time Function to adjust reverse-linked sunshade lowering function's response time 0.7 sec. 0 / 0.7 / 0.9 / 1.2
17. SLIDING ROOF SYSTEM Sliding Roof ECU Tester Display Default Contents Setting Door Key Related Open ON Function to manually open sliding roof linked with power window if holding driver side door key for 1.5 seconds or more to unlock position when engine switch is off ON / OFF Door Key Related Close ON Function to manually close sliding roof linked with power window if holding driver side door key for 1.5 seconds or more to lock position when engine switch is off ON / OFF Wireless Key Related Open ON Function to manually open sliding roof linked with power window if pressing transmitter UNLOCK switch for 1.5 seconds or more when engine switch is off ON / OFF Door Key Related Operation SLIDE Function to select tilt up or slide open of manual sliding roof operation linked with power window Activate by holding driver side door key for 1.5 seconds or more to unlock position when engine switch is off TILT / SLIDE Wireless Key Related Operation SLIDE Function to select tilt up or slide open of manual sliding roof operation linked with power window Activate by pressing on transmitter UNLOCK switch for 1.5 seconds or more when engine switch is off TILT / SLIDE

INITIALIZATION

Note. When disconnecting the cable from negative (-) battery terminal, initialize the following system(s) after the terminal is reconnected.

1. The initialization procedures are below the table.

Scheme 71

Scheme 72

1. RESET INTUITIVE PARKING ASSIST SYSTEM HINT: The mid-point learning operation (steering angle mid-point, maximum steering angle) can be performed using 4 methods: Method 1 Use the Techstream to perform initial setting of mid-point When clearance warning ECU is replaced When steering wheel mid-point or wheel alignment is adjusted When battery terminal is disconnected and reconnected When malfunction causes momentary drop in the power supply voltage (due to cranking, depleted battery, etc.) When steering angle sensor is removed and installed When steering angle sensor is replaced Method 2 Use customize mode to perform initial setting of mid-point When clearance warning ECU is replaced When steering wheel mid-point or wheel alignment is adjusted Method 3 Perform steering angle mid-point learning operation by rotating steering wheel to left and right full lock position When battery terminal is disconnected and reconnected When malfunction causes momentary drop in the power supply voltage (due to cranking, depleted battery, etc.) When steering angle sensor is removed and installed When steering angle sensor is replaced Method 4 Perform steering angle mid-point learning operation by traveling in approximate straight line for extended distance When battery terminal is disconnected and reconnected When malfunction causes momentary drop in the power supply voltage (due to cranking, depleted battery, etc.) When steering angle sensor is removed and installed When steering angle sensor is replaced Method 1 (Techstream) Turn the engine switch off. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / INTUITIVE P/A / Utility. Perform the STEERING INITIALIZATION procedure. Method 2 (Manual operation method) Using customize mode, set the mid-point and maximum steering angle. HINT: *1: Steering wheel is centered (tires aligned straightforward). *2: If 180 seconds pass, steering angle mid-point setting and maximum steering angle range setting will not occur and initialize mode will end. Multi-information Display Indication Settings in Each Mode [1] [2] [3] [4] [5] [6] [7] [8] [9] [10] Note {A} • x x x x - x <-- <-- <-- [8], [9], [10] will illuminate if steering wheel mid-point is not set {B} • ↓ o x ↓ o x x ↓ o x - x • ↓ o • ↓ o • ↓ o [1], [8] to [10] will illuminate for 2 seconds: then [1], [2], [4], [8] to [10] will flash {C} o o x o x x x x x x [1], [2], [4] will flash • : Illumination o : Flashing <-- : Flashes depending on condition x : No illumination or flashing Method 3 (Manual operation method) Turn the engine switch on (IG). Turn the clearance sonar main switch ON. Turn the steering wheel to the full left and right lock position. NOTE: Make sure to completely turn the steering wheel to the left and right full lock position. Confirm that the learning operation has been completed by checking the multi-information display. Method 4 (Manual operation method) At an area with few turns and curves, and minimal traffic, drive at 20 km/h (12 mph) or more for 5 minutes or more.
2. STEERING ANGLE SENSOR INITIALIZATION (to obtain a tire angle (during straight-ahead driving) signal) Turn the engine switch on (IG), and check that the master warning light and VSC/ABS warning lights illuminate for a few seconds. NOTE: If the warning lights remain on or blink, repair he applicable system. Drive the vehicle on a straight road at 35 km/h (22 mph) or more for 5 seconds or longer. HINT: At this point, the steering wheel will still remain off-center by 5 to 10 degrees. In this step, the neutral position of the steering wheel is restored from the steering control ECU memory. Confirm that steering angle sensor initialization is completed (when using the Techstream). Enter the VGRS menu using the Techstream. Select "Straight Angle Valid Flag" from "Data List". Check if the steering angle sensor has obtained a tire angle (during straight-ahead driving) signal. Standard "Valid" is displayed on the Techstream screen. Confirm that steering angle sensor initialization is completed (when not using the Techstream). Drive the vehicle on a straight road at 60 km/h (37 mph) or more for 30 seconds or longer. Stop the vehicle (engine running). Slowly turn the steering wheel from lock to lock. If it turns approximately 2.7 turns, steering angle sensor initialization is completed. If it turns approximately 3.2 turns, steering angle sensor initialization is not completed. NOTE: If the steering wheel turns approximately 3.2 turns, perform step (b) again.
3. THEFT DETERRENT SYSTEM HINT: If the battery is reconnected during the armed state, the system may enter the alarm sounding state and the alarm may sound. If so, perform a wireless unlock operation or entry unlock operation to stop the alarm.
