Cellular Communication (Service Information): Overview Lexus GS III facelift

Scheme 231

Scheme 232

Scheme 233

Scheme 234

Scheme 235

Scheme 236

Scheme 237

Scheme 238

Scheme 239

Scheme 240

Scheme 241

Scheme 242

Scheme 243

Scheme 244

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL WARNING: Wait at least 90 seconds after disconnecting the cable from the negative (-) battery terminal to prevent airbag and seat belt pretensioner activation.
2. REMOVE LUGGAGE COMPARTMENT FLOOR MAT Remove the floor mat.
3. REMOVE LUGGAGE COMPARTMENT NO. 1 LIGHT ASSEMBLY Using a screwdriver, detach the claw and remove the light. HINT: Tape the screwdriver tip before use. Disconnect the connector.
4. REMOVE TOOL BOX Remove the tool box.
5. REMOVE REAR FLOOR FINISH PLATE Remove the 2 bolts and 2 hooks. Remove the 3 clips labeled A. Detach the 4 clips to remove the finish plate.
6. REMOVE LUGGAGE COMPARTMENT TRIM COVER FRONT Detach the hook. Remove the rope hook. Detach the 4 claws and remove the trim cover.
7. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER LH Remove the bolt and hook. Remove the 3 clips and trim cover.
8. REMOVE LUGGAGE COMPARTMENT TRIM COVER INNER RH Remove the bolt and hook. Remove the 3 clips and trim cover.
9. REMOVE MAYDAY ASSEMBLY Remove the 2 bolts and mayday assembly with wire harness. Disconnect the 5 connectors and 2 clamps and remove the mayday assembly.

Scheme 245

Scheme 246

Scheme 247

1. REMOVE NO. 2 MOBILEPHONE BRACKET Remove the 2 bolts and bracket.
2. REMOVE MAYDAY ECU Remove the 4 bolts and ECU.
3. REMOVE MAYDAY BATTERY Remove the bolt, No. 4 mobilephone bracket and battery.
