ENGINE ROOM NO. 1 RELAY & JUNCTION BLOCK

Note. Engine room No. 1 relay and junction block is located in right rear of engine compartment. (Scheme 1)

Scheme 1

Scheme 1: ENGINE ROOM NO. 1 RELAY & JUNCTION BLOCK
Scheme 1: ENGINE ROOM NO. 1 RELAY & JUNCTION BLOCK

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9
FuseSystem
7.5ADOMEActive Stabilizer Suspension System Adaptive Front-Lighting System Automatic Glare-Resistant EC Mirror Combination Meter Compass Cruise Control Dynamic Radar Cruise Control Engine Control Front Fog Light Garage Door Opener Headlight Headlight Beam Level Control Hybrid System Illumination Interior Light Luggage Compartment Door Opener and Closer Parking Assist (Intuitive Parking Assist) Pre-Collision System Shift Control System Sliding Roof Smart Access System with Push-Button Start (*Hybrid Vehicle Immobiliser) Smart Access System with Push-Button Start (*Push-Button Start) Smart Access System with Push-Button Start (*Steering Lock) Smart Access System with Push-Button Start (*Wireless Door Lock Control) Taillight Tire Pressure Warning System Vehicle Dynamics Integrated Management (for Hybrid Vehicle) VGRS System
7.5AIGCT NO.2Hybrid System Shift Control System
7.5AIGCT NO.3Hybrid System Shift Control System
7.5AMPX-BActive Stabilizer Suspension System Adaptive Front-Lighting System Audio System Automatic Light Control Back-Up Light Combination Meter Cruise Control Door Lock Control Dynamic Radar Cruise Control Electronic Modulated Suspension Engine Control EPS Front Fog Light Front Wiper and Washer Headlight Headlight Beam Level Control Horn Hybrid System Illumination Interior Light LEXUS Navigation System Light Auto Turn Off System Luggage Compartment Door Opener and Closer Mirror Heater Multi Display Multiplex Communication System (AVC-LAN) Multiplex Communication System (BEAN) Multiplex Communication System (CAN) Parking Assist (Intuitive Parking Assist) Parking Assist (Rear View Monitor) Power Seat (Driver's Seat) Power Seat (Front Passenger's) Power Tilt and Power Telescopic Power Window Pre-Collision System Rear Sunshade Remote Control Mirror Seat Belt Warning Shift Control System Sliding Roof Smart Access System with Push-Button Start (*Hybrid Vehicle Immobiliser) Smart Access System with Push-Button Start (*Push-Button Start) Smart Access System with Push-Button Start (*Push-Button Start) Smart Access System with Push-Button Start (*Wireless Door Lock Control) SRS Taillight Theft Deterrent Tire Pressure Warning System Vehicle Dynamics Integrated Management (for Hybrid Vehicle) VGRS System
10AABS MAIN1Vehicle Dynamics Integrated Management (for Hybrid Vehicle)
10AABS MAIN2Dynamic Radar Cruise Control Vehicle Dynamics Integrated Management (for Hybrid Vehicle)
10AABS MAIN3Dynamic Radar Cruise Control Vehicle Dynamics Integrated Management (for Hybrid Vehicle)
10AECU-BElectronic Modulated Suspension EPS Fuel Lid Opener Headlight Cleaner LEXUS Link System (Mayday System) Parking Assist (Intuitive Parking Assist) Rear Sunshade Remote Control Mirror Vehicle Dynamics Integrated Management (for Hybrid Vehicle) VGRS System
10AEFI NO.2Engine Control
10AETCSCruise Control Dynamic Radar Cruise Control Engine Control
10AFR TAILAutomatic Light Control Light Auto Turn Off System Smart Access System with Push-Button Start (*Wireless Door Lock Control) Taillight Theft Deterrent
10AHORNHorn LEXUS Link System (Mayday System) Smart Access System with Push-Button Start (*Wireless Door Lock Control) Theft Deterrent
10AIG2Combination Meter Engine Control Ignition
10AINV W/PHybrid System Shift Control System
10ARELIEF VLVEngine Control
15AA/FEngine Control
15AFR FOGFront Fog Light
15AH-LP L LWRHeadlight
15AH-LP R LWRHeadlight
15ATURN-HAZTurn Signal and Hazard Warning Light
20ABATT FANHybrid System Shift Control System
15AH-LP UPRHeadlight Theft Deterrent
20AIGCT NO.1Cruise Control Dynamic Radar Cruise Control Hybrid System Shift Control System
20AINJEngine Control
20AWASHERFront Wiper and Washer
25ADEICERFront Window Deicer
25AEFICruise Control Dynamic Radar Cruise Control Engine Control
25AF/PMPEngine Control
30AABS MOTORDynamic Radar Cruise Control Vehicle Dynamics Integrated Management (for Hybrid Vehicle)
30AABS2Dynamic Radar Cruise Control Vehicle Dynamics Integrated Management (for Hybrid Vehicle)
30AH-LP CLNHeadlight Cleaner
30AMAINAutomatic Light Control Headlight LEXUS Link System (Mayday System) Light Auto Turn Off System Smart Access System with Push-Button Start (*Wireless Door Lock Control) Theft Deterrent
30ARAD NO.1Audio System LEXUS Navigation System Multi Display Parking Assist (Rear View Monitor)
30ARAD NO.2Audio System LEXUS Navigation System Multi Display Parking Assist (Rear View Monitor)
30ASTB-AMActive Stabilizer Suspension System
40AVGRSVGRS System
50ADEFOGRear Window Defogger
50AHEATERAir Conditioning
60AOIL PMPHybrid System Shift Control System
60ARAD FANCooling Fan
80AEPSEPS
80ALH J/B-AMClimate Control Seat Illumination Seat Heater
80ARR J/BRear Sunshade
150ADC/DCHybrid System Shift Control System

Engine Room No. 1 Relay & Junction Block Fuses

COWL SIDE JUNCTION BLOCK LEFT HAND

Note. Driver side junction block is located under left side of instrument panel. (Scheme 10)

Scheme 10

Scheme 10: COWL SIDE JUNCTION BLOCK LEFT HAND
Scheme 10: COWL SIDE JUNCTION BLOCK LEFT HAND

Scheme 11

Scheme 11
Scheme 11
FuseSystem
7.5AA/CAir Conditioning
7.5AA/C W/PAir Conditioning
7.5AH-LP LVLAdaptive Front-Lighting System Headlight Beam Level Control
7.5APANELClimate Control Seat Illumination
7.5ATVAudio System LEXUS Navigation System Multi Display Parking Assist (Rear View Monitor)
10AECU-IG LHAutomatic Glare-Resistant EC Mirror Automatic Light Control Compass Dynamic Radar Cruise Control Electronic Modulated Suspension EPS Front Fog Light Front Wiper and Washer Garage Door Opener Headlight Horn Interior Light Light Auto Turn Off System Sliding Roof Taillight Vehicle Dynamics Integrated Management (for Hybrid Vehicle) VGRS System
10AFUEL OPENFuel Lid Opener
10ALH-IGAir Conditioning Cooling Fan Door Lock Control Electric Tension Reducer Front Window Deicer Front Wiper and Washer Headlight Cleaner Illumination Interior Light Luggage Compartment Door Opener and Closer Mirror Heater Parking Assist (Intuitive Parking Assist) Power Window Rear Window Defogger Remote Control Mirror Smart Access System with Push-Button Start (* Wireless Door Lock Control) Theft Deterrent Turn Signal and Hazard Warning Light
10ARAD NO.3Audio System LEXUS Navigation System Multi Display Parking Assist (Rear View Monitor)
10ATRK OPNLuggage Compartment Door Opener and Closer
15AFR S/HTR LHClimate Control Seat Seat Heater
20AFR DOOR LHDoor Lock Control Interior Light Mirror Heater Power Window Remote Control Mirror Smart Access System with Push-Button Start (* Wireless Door Lock Control) Theft Deterrent
20ARR DOOR LHDoor Lock Control Interior Light Power Window Smart Access System with Push-Button Start (* Wireless Door Lock Control) Theft Deterrent
25AS/ROOFSliding Roof
30AFR P/SEAT LHPower Seat (Driver's Seat)
30AFR WIPFront Wiper and Washer

Driver Side Junction Block Fuses

COWL SIDE JUNCTION BLOCK RIGHT HAND

Note. Passenger side junction block is located under right side of instrument panel. (Scheme 10)

Scheme 12

Scheme 12: COWL SIDE JUNCTION BLOCK RIGHT HAND
Scheme 12: COWL SIDE JUNCTION BLOCK RIGHT HAND
FuseSystem
7.5AACCAudio System Automatic Light Control Front Fog Light Headlight Illumination Interior Light LEXUS Link System (Mayday System) LEXUS Navigation System Light Auto Turn Off System Multi Display Multiplex Communication System (AVC-LAN) Multiplex Communication System (BEAN) Multiplex Communication System (CAN) Parking Assist (Rear View Monitor) Power Tilt and Power Telescopic Smart Access System with Push-Button Start (* Wireless Door Lock Control) Theft Deterrent
7.5AAM2Smart Access System with Push-Button Start (* Hybrid Vehicle Immobiliser) Smart Access System with Push-Button Start (* Push-Button Start) Smart Access System with Push-Button Start (* Steering Lock)
7.5AGAUGEActive Stabilizer Suspension System Adaptive Front-Lighting System Audio System Combination Meter Cruise Control Dynamic Radar Cruise Control Electronic Modulated Suspension Engine Control EPS Front Fog Light Front Wiper and Washer Headlight Headlight Beam Level Control Hybrid System Illumination Interior Light LEXUS Navigation System Luggage Compartment Door Opener and Closer Multi Display Parking Assist (Intuitive Parking Assist) Parking Assist (Rear View Monitor) Pre-Collision Safety System Seat Belt Warning Shift Control System Sliding Roof Smart Access System with Push-Button Start (* Engine Immobiliser) Smart Access System with Push-Button Start (* Push-Button Start) Smart Access System with Push-Button Start (* Steering Lock) SRS Taillight Tire Pressure Warning System Vehicle Dynamics Integrated Management (for Hybrid Vehicle) VGRS System
7.5AOBDData Link Connector 3
7.5ARH-IGClimate Control Seat Door Lock Control Electric Tension Reducer Hybrid System Interior Light Mirror Heater Parking Assist (Intuitive Parking Assist) Power Window Seat Heater Shift Control System Smart Access System with Push-Button Start (* Wireless Door Lock Control) Theft Deterrent Vehicle Dynamics Integrated Management (for Hybrid Vehicle)
7.5ASECURITYSmart Access System with Push-Button Start (* Engine Immobiliser) Smart Access System with Push-Button Start (* Push-Button Start) Smart Access System with Push-Button Start (* Steering Lock) Smart Access System with Push-Button Start (* Wireless Door Lock Control)
7.5ASTOP SWCruise Control Dynamic Radar Cruise Control Electronic Modulated Suspension Front Wiper and Washer Hybrid System Shift Control System Shift Lock Smart Access System with Push-Button Start (* Engine Immobiliser) Smart Access System with Push-Button Start (* Push-Button Start) Smart Access System with Push-Button Start (* Steering Lock) Stop Light Vehicle Dynamics Integrated Management (for Hybrid Vehicle)
10AECU-IG RHActive Stabilizer Suspension System Air Conditioning Audio System Automatic Light Control Dynamic Radar Cruise Control Front Fog Light Front Wiper and Washer Headlight Illumination Interior Light LEXUS Navigation System Light Auto Turn Off System Multi Display Multiplex Communication System (AVC-LAN) Multiplex Communication System (BEAN) Multiplex Communication System (CAN) Parking Assist (Rear View Monitor) Power Seat (Driver's Seat) Power Seat (Front Passenger's) Power Tilt and Power Telescopic Shift Lock Smart Access System with Push-Button Start (* Wireless Door Lock Control) Taillight Theft Deterrent Tire Pressure Warning System
10AIGNCruise Control Dynamic Radar Cruise Control Engine Control Hybrid System LEXUS Link System (Mayday System) Seat Belt Warning Shift Control System Smart Access System with Push-Button Start (* Engine Immobiliser) Smart Access System with Push-Button Start (* Push-Button Start) Smart Access System with Push-Button Start (* Steering Lock) SRS Vehicle Dynamics Integrated Management (for Hybrid Vehicle)
15ACIGCigarette Lighter
15AFR S/HTR RHClimate Control Seat Seat Heater
15APWR OUTLETPower Outlet
20AAIR SUSElectronic Modulated Suspension
20AFR DOOR RHDoor Lock Control Front Fog Light Front Wiper and Washer Headlight Illumination Interior Light Light Auto Turn Off System Mirror Heater Power Tilt and Power Telescopic Power Window Smart Access System with Push-Button Start (* Wireless Door Lock Control) Theft Deterrent
20ARR DOOR RHDoor Lock Control Interior Light Power Window Smart Access System with Push-Button Start (* Wireless Door Lock Control) Theft Deterrent
20ATI & TEPower Tilt and Power Telescopic
25ASTR LOCKSmart Access System with Push-Button Start (* Engine Immobiliser) Smart Access System with Push-Button Start (* Push-Button Start) Smart Access System with Push-Button Start (* Steering Lock)
30AFR P/SEAT RHPower Seat (Front Passenger's Seat)

Passenger Side Junction Block Fuses

LUGGAGE ROOM JUNCTION BLOCK

Note. Luggage room junction block is located in left front of luggage room. (Scheme 13)

Scheme 13

Scheme 13: LUGGAGE ROOM JUNCTION BLOCK
Scheme 13: LUGGAGE ROOM JUNCTION BLOCK

Scheme 14

Scheme 14
Scheme 14
FuseSystem
7.5AECU-BRear Sunshade
10ARR TAILStop Light Taillight
10ARR-BBack-Up Light Interior Light Rear Sunshade Stop Light Taillight
10ARR-IG1Back-Up Light Electric Tension Reducer Pre-Collision System Rear Sunshade Taillight
10ASTOP LP LDynamic Radar Cruise Control Stop Light
10ASTOP LP RDynamic Radar Cruise Control Stop Light
30APSBPre-Collision Safety System

Luggage Room Junction Block Fuses

LUGGAGE ROOM RELAY BLOCK NO. 6

Note. Luggage room relay block No. 6 is located under rear center of luggage room. (Scheme 13)

Scheme 15

Scheme 15: LUGGAGE ROOM RELAY BLOCK NO. 6
Scheme 15: LUGGAGE ROOM RELAY BLOCK NO. 6
FuseSystem
30ASTB DC/DCActive Stabilizer Suspension System
30ASTB RRActive Stabilizer Suspension System
50ASTB FRActive Stabilizer Suspension System

Luggage Room Relay Block No. 6 Fuses

FUSIBLE LINK BLOCK

Note. Fusible link block is located under rear center of luggage room. (Scheme 13)

Scheme 16

Scheme 16: FUSIBLE LINK BLOCK
Scheme 16: FUSIBLE LINK BLOCK
FuseSystem
80ASTBActive Stabilizer Suspension System

Fusible Link Block Fuse
