Differential (Service Information): Overview Lexus GS III рестайлинг

Differentials & Drive Axles 22 illustrations ~1837 words

Scheme 1

Scheme 1: ON-VEHICLE INSPECTION
Scheme 1: ON-VEHICLE INSPECTION

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3
  1. CHECK DIFFERENTIAL OIL Stop the vehicle on a level place. Using a 10 mm hexagon wrench, remove the differential filler plug and gasket. Check that the oil surface is within 5 mm (0.20 in.) of the lowest position of the inner surface of the differential filler plug opening. NOTE: Excessively large or small amounts of oil may cause trouble. After replacing oil, drive the vehicle and check the oil level. HINT: If necessary, fill the rear differential carrier with Toyota Genuine Differential gear oil LT 75W-85 GL-5, Toyota Genuine Differential synthetic gear oil GL-5 75W-90 or their equivalent. Check for oil leakage when the oil level is low. Using a 10 mm hexagon wrench, install the differential filler plug and a new gasket. Torque: 49 N*m ( 500 kgf*cm, 36 ft.*lbf)
  2. ADD DIFFERENTIAL OIL Using a 10 mm hexagon wrench, remove the differential filler plug and gasket. Add oil. Standard capacity 1.30 to 1.40 liters (1.38 to 1.48 US qts, 1.15 to 1.23 Imp. qts) Oil grade Toyota Genuine Differential gear oil LT 75W-85 GL-5, Toyota Genuine Differential synthetic gear oil GL-5 75W-90 or their equivalent Check the oil level. Using a 10 mm hexagon wrench, install the differential filler plug with a new gasket. Torque: 49 N*m ( 500 kgf*cm, 36 ft.*lbf) NOTE: After replacing the oil, recheck the oil level after driving.

Scheme 4

Scheme 4: ILLUSTRATION
Scheme 4: ILLUSTRATION

Scheme 5

Scheme 5: ILLUSTRATION
Scheme 5: ILLUSTRATION

Scheme 6

Scheme 6: ILLUSTRATION
Scheme 6: ILLUSTRATION

Scheme 7

Scheme 7: REMOVAL
Scheme 7: REMOVAL

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
  1. REMOVE REAR WHEEL
  2. DRAIN REAR DIFFERENTIAL OIL Using a 10 mm hexagon wrench, remove the differential filler plug and gasket. Using a 10 mm hexagon wrench, remove the differential drain plug and gasket, and drain the oil.
  3. REMOVE EXHAUST PIPE ASSEMBLY Remove the exhaust pipe. Refer to «REMOVAL»(/lexus/gs/iii-2007-2011/remont/exhaust/#exhaust-service-information__removal) .
  4. REMOVE PROPELLER SHAFT ASSEMBLY Remove the propeller shaft. Refer to «REMOVAL»(/lexus/gs/iii-2007-2011/remont/driveshaft-universal-joints/#propeller-shaft-service-information) .
  5. REMOVE REAR SHOCK ABSORBER WITH COIL SPRING LH . Refer to «REMOVAL - Step 14»(ref-386957-S35820228732011022400000)
  6. REMOVE REAR SHOCK ABSORBER WITH COIL SPRING RH HINT: Use the same procedures for the RH side and LH side.
  7. REMOVE REAR AXLE ASSEMBLY LH Remove the rear axle. Refer to «REMOVAL»(ref-386958-S13621183122011022400000) .
  8. REMOVE REAR AXLE ASSEMBLY RH HINT: Use the same procedures for the RH side and LH side.
  9. REMOVE NO. 2 DIFFERENTIAL SUPPORT PROTECTOR . Refer to «REMOVAL - Step 9»(ref-386957-S35820228732011022400000)
  10. REMOVE NO. 1 DIFFERENTIAL SUPPORT PROTECTOR HINT: Use the same procedures described for the No. 2 protector.
  11. REMOVE REAR SUSPENSION MEMBER BRACE LH . Refer to «REMOVAL - Step 10»(ref-386957-S35820228732011022400000)
  12. REMOVE REAR SUSPENSION MEMBER BRACE RH HINT: Use the same procedures for the RH side and LH side.
  13. REMOVE NO. 3 PARKING BRAKE CABLE ASSEMBLY . Refer to «REMOVAL - Step 23»(ref-386961-S14376632922011022400000)
  14. REMOVE NO. 2 PARKING BRAKE CABLE ASSEMBLY HINT: Use the same procedures described for the No. 3 cable.
  15. REMOVE REAR DRIVE SHAFT ASSEMBLY LH . Refer to «REMOVAL - Step 16»(ref-387126-S23181533302011022400000)
  16. REMOVE REAR DRIVE SHAFT ASSEMBLY RH HINT: Use the same procedures for the RH side and LH side.
  17. REMOVE REAR FLOOR SIDE MEMBER COVER LH Remove the 3 screws and side member cover LH.
  18. REMOVE REAR FLOOR SIDE MEMBER COVER RH HINT: Use the same procedures for the RH side and LH side.
  19. REMOVE REAR HEIGHT CONTROL SENSOR LH Disconnect the height control sensor connector. Remove the clamp from the rear suspension member.
  20. REMOVE REAR SUSPENSION MEMBER BRACE REAR LOWER LH Remove the 4 bolts and suspension member brace rear lower LH.
  21. REMOVE REAR SUSPENSION MEMBER BRACE REAR LOWER RH HINT: Use the same procedures for the RH side and LH side.
  22. REMOVE REAR SUSPENSION MEMBER ASSEMBLY Support the rear suspension member with a jack. HINT: Remove the rear suspension member along with the differential carrier assembly rear. Remove the 8 bolts, 2 rear suspension member stoppers, 2 differential support member stoppers and rear suspension member stopper lowers from the rear suspension member. Lower the jack slowly and remove the rear suspension member with the differential carrier assembly rear.
  23. REMOVE REAR DIFFERENTIAL CARRIER ASSEMBLY See step 7
  24. REMOVE REAR NO. 1 DIFFERENTIAL MOUNT CUSHION Pass the SST bolts through the areas shown in the illustration, and remove the No. 1 mount cushion. SST: 09570-24011 SST: 09316-12010 NOTE: When removing the No. 1 mount cushion, do not connect SST (09316-12010) to the rear suspension member. Be sure to combine SST properly. Do not install the SST bolts at an angle. Make sure the SST bolts are tightened equally.
  25. REMOVE REAR NO. 2 DIFFERENTIAL MOUNT CUSHION Pass the SST bolt through the area shown in the illustration, and remove the mount cushion No. 2. SST: 09570-24011 SST: 09316-12010 NOTE: When removing the mount cushion No. 2, do not connect SST (09316-12010) to the rear suspension member. Be sure to combine the SST properly. Do not install the SST bolt at an angle.

Scheme 13

Scheme 13: INSTALLATION
Scheme 13: INSTALLATION

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17
  1. INSTALL REAR NO. 1 DIFFERENTIAL MOUNT CUSHION Pass the SST bolts through the areas shown in the illustration, and install the mount cushion No. 1. SST: 09570-24011 NOTE: Make sure the mount cushion is not at an angle by first temporarily installing the mount cushion to the member before installing SST. Be sure to combine SST properly. Confirm that SST contacts the entire bush surface of the mount cushion.
  2. INSTALL REAR NO. 2 DIFFERENTIAL MOUNT CUSHION Pass the SST bolt through the area shown in the illustration, and install the mount cushion No. 2. SST: 09570-24011 NOTE: Make sure the mount cushion is not at an angle by first temporarily installing the mount cushion to the member before installing SST. Be sure to combine SST properly. Confirm that SST contacts the entire bush surface of the mount cushion.
  3. INSTALL REAR DIFFERENTIAL CARRIER ASSEMBLY Support the rear differential carrier with a jack. NOTE: Do not drop the differential carrier. Using a 12 mm hexagon wrench, temporarily install the differential carrier to the suspension member with 3 new bolts. Install the mount stopper upper and mount stopper lower. Temporarily install the differential carrier rear to the suspension member with 2 new bolts. Using a 12 mm hexagon wrench and torque wrench, tighten the 3 bolts to the specified torque. Torque: 142 N*m ( 1,450 kgf*cm, 105 ft.*lbf) Using a torque wrench, tighten 2 bolts to the specified torque. Torque: 95 N*m ( 970 kgf*cm, 70 ft.*lbf) NOTE: Do not tilt the inner tube and rubber parts when fully tightening the differential mount stopper.
  4. INSTALL REAR SUSPENSION MEMBER ASSEMBLY Support the rear suspension member along with the differential using a jack. HINT: Install the rear suspension member along with the rear differential carrier. Install the 2 rear suspension member stoppers and 2 differential support member stoppers to the rear suspension member. Install the rear suspension member along with the rear suspension member stopper lower with the 8 bolts. Torque: 127 N*m ( 1,300 kgf*cm, 94 ft.*lbf) for bolt A Torque: 19 N*m ( 195 kgf*cm, 14 ft.*lbf) for bolt B
  5. INSTALL REAR SUSPENSION MEMBER BRACE REAR LOWER LH Install the suspension member brace rear lower LH with the 4 bolts. Torque: 19 N*m ( 195 kgf*cm, 14 ft.*lbf)
  6. INSTALL REAR SUSPENSION MEMBER BRACE REAR LOWER RH HINT: Use the same procedures for the RH side and LH side.
  7. CONNECT REAR HEIGHT CONTROL SENSOR LH Install the clamp to the rear suspension member. Connect the height control sensor connector.
  8. INSTALL REAR FLOOR SIDE MEMBER COVER LH Install the side member cover LH with the 3 screws.
  9. INSTALL REAR FLOOR SIDE MEMBER COVER RH HINT: Use the same procedures for the RH side and LH side.
  10. INSTALL REAR DRIVE SHAFT ASSEMBLY LH . Refer to «INSTALLATION - Step 2»(ref-387126-S00893833692011022400000)
  11. INSTALL REAR DRIVE SHAFT ASSEMBLY RH HINT: Use the same procedures for the RH side and LH side.
  12. INSTALL NO. 3 PARKING BRAKE CABLE ASSEMBLY . Refer to «INSTALLATION - Step 1»(ref-386961-S11410492532011022400000)
  13. INSTALL NO. 2 PARKING BRAKE CABLE ASSEMBLY HINT: Use the same procedures described for the No. 3 cable.
  14. INSTALL REAR SUSPENSION MEMBER BRACE LH . Refer to «INSTALLATION - Step 7»(ref-386957-S29848116532011022400000)
  15. INSTALL REAR SUSPENSION MEMBER BRACE RH HINT: Use the same procedures for the RH side and LH side.
  16. INSTALL NO. 2 DIFFERENTIAL SUPPORT PROTECTOR . Refer to «INSTALLATION - Step 8»(ref-386957-S29848116532011022400000)
  17. INSTALL NO. 1 DIFFERENTIAL SUPPORT PROTECTOR HINT: Use the same procedures described for the No. 2 protector.
  18. TEMPORARILY TIGHTEN REAR SHOCK ABSORBER WITH COIL SPRING LH . Refer to «INSTALLATION - Step 1»(ref-386957-S29848116532011022400000)
  19. TEMPORARILY TIGHTEN REAR SHOCK ABSORBER WITH COIL SPRING RH HINT: Use the same procedures for the RH side and LH side.
  20. INSTALL REAR AXLE ASSEMBLY LH Install the rear axle. Refer to «INSTALLATION - Step 2»(ref-386958-S42916047382011022400000) .
  21. INSTALL REAR AXLE ASSEMBLY RH HINT: Use the same procedures for the RH side and LH side.
  22. TIGHTEN REAR SHOCK ABSORBER WITH COIL SPRING LH Tighten the rear shock absorber with coil spring. Refer to «INSTALLATION - Step 5»(ref-386957-S08262590542011022400000) .
  23. TIGHTEN REAR SHOCK ABSORBER WITH COIL SPRING RH HINT: Use the same procedures for the RH side and LH side.
  24. INSTALL PROPELLER SHAFT ASSEMBLY Install the propeller shaft. Refer to «INSTALLATION - Step 1»(/lexus/gs/iii-2007-2011/remont/driveshaft-universal-joints/#propeller-shaft-service-information) .
  25. ADD REAR DIFFERENTIAL OIL See step 2
  26. INSPECT AND ADJUST REAR DIFFERENTIAL OIL See step 1
  27. INSTALL REAR WHEEL Torque: 103 N*m ( 1,050 kgf*cm, 76 ft.*lbf)
  28. INSTALL EXHAUST PIPE ASSEMBLY Install the exhaust pipe. Refer to «INSTALLATION - Step 4»(/lexus/gs/iii-2007-2011/remont/exhaust/#exhaust-service-information) .
  29. INSPECT PARKING BRAKE PEDAL TRAVEL . Refer to «ADJUSTMENT - Step 4»(/lexus/gs/iii-2007-2011/remont/parking-brake-system/#parking-brake-inspection)
  30. ADJUST PARKING BRAKE PEDAL TRAVEL . Refer to «ADJUSTMENT - Step 5»(/lexus/gs/iii-2007-2011/remont/parking-brake-system/#parking-brake-inspection)
  31. INSPECT AND ADJUST REAR WHEEL ALIGNMENT Inspect and adjust the rear wheel alignment. Refer to «ADJUSTMENT»(ref-386957-S40713542812011022400000) .
  32. CHECK EXHAUST GAS LEAK . Refer to «INSTALLATION - Step 8»(/lexus/gs/iii-2007-2011/remont/exhaust/#exhaust-service-information)
  33. CHECK ABS SPEED SENSOR SIGNAL . Refer to «INSTALLATION - Step 3»(ref-386953-S01368261382011022400000)

Scheme 18

Scheme 18: ILLUSTRATION
Scheme 18: ILLUSTRATION

Scheme 19

Scheme 19: REPLACEMENT
Scheme 19: REPLACEMENT

Scheme 20

Scheme 20
Scheme 20
  1. REMOVE REAR WHEEL
  2. DRAIN DIFFERENTIAL OIL Using a 10 mm hexagon wrench, remove the filler plug and gasket. Using a 10 mm hexagon wrench, remove the drain plug and gasket and drain the oil. Install the differential drain plug and a new gasket. Torque: 49 N*m ( 500 kgf*cm, 36 ft.*lbf)
  3. REMOVE REAR DRIVE SHAFT ASSEMBLY . Refer to «REMOVAL - Step 16»(ref-387126-S23181533302011022400000)
  4. REMOVE REAR DIFFERENTIAL SIDE GEAR SHAFT OIL SEAL Using SST, tap out the oil seal. SST: 09308-10010
  5. INSTALL REAR DIFFERENTIAL SIDE GEAR SHAFT OIL SEAL Using SST and a hammer, tap in a new oil seal. SST: 09950-70010 09951-07150 SST: 09223-15030 Standard depth -0.5 to 0.5 mm (-0.020 to 0.020 in.) Apply MP grease to the lip of the oil seal.
  6. INSTALL REAR DRIVE SHAFT ASSEMBLY . Refer to «INSTALLATION - Step 2»(ref-387126-S00893833692011022400000)
  7. ADD DIFFERENTIAL OIL See step 2
  8. INSPECT DIFFERENTIAL OIL See step 1
  9. INSTALL REAR WHEEL Torque: 103 N*m ( 1,050 kgf*cm, 76 ft.*lbf)
  10. INSPECT AND ADJUST REAR WHEEL ALIGNMENT Inspect and adjust the rear wheel alignment. Refer to «ADJUSTMENT»(ref-386957-S40713542812011022400000) .
  11. CHECK ABS SPEED SENSOR SIGNAL . Refer to «INSTALLATION - Step 3»(ref-386953-S01368261382011022400000)

Scheme 21

Scheme 21: ILLUSTRATION
Scheme 21: ILLUSTRATION

Scheme 22

Scheme 22: ILLUSTRATION
Scheme 22: ILLUSTRATION
