- REMOVE DOOR INSIDE HANDLE BEZEL COVER Using a screwdriver, remove the inside handle bezel cover. HINT: Tape the screwdriver tip before use.
- REMOVE DOOR TRIM Using a screwdriver, remove the screws. Insert a screwdriver between the door panel and door trim to pry out. HINT: Tape the screwdriver tip before use. Pull the trim upward to remove it, then disconnect the courtesy light connector. Remove the courtesy light from the door trim. Remove the 2 cables from the door inside handle.
- REMOVE DOOR FRAME GARNISH Remove the nut. Remove the door frame garnish.
- REMOVE TWEETER SPEAKER
- REMOVE OUTSIDE REAR VIEW MIRROR Remove the 3 bolts. Remove the outside rear view mirror.
- REMOVE SPEAKER
- REMOVE DRIVER DOOR ECU
- REMOVE SERVICE HOLE COVER
- REMOVE DOOR GLASS Remove the 2 bolts. Pull the glass out off the panel carefully. HINT: At the time of reassembly, please refer to the following item. Insert a shop rag inside the panel to prevent scratching the glass.
- REMOVE WINDOW REGULATOR Torque: 11 N.m (112 kgf.cm, 8 ft.lbf) HINT: At the time of reassembly, please refer to the following item. Apply MP grease to the window regulator rollers.
- REMOVE FRONT DOOR LOWER FRAME
- REMOVE DOOR GLASS RUN
- REMOVE DOOR BELT MOULDING
- REMOVE DOOR BELT MOULDING
- REMOVE DOOR LOCK Disconnect the 2 links from the outside handle and key cylinder. Disconnect the connector. Remove the bolt. Torque: 5.5 N.m (56 kgf.cm, 49 in..lbf) Remove the 3 screws and door lock. Torque: 5.5 N.m (56 kgf.cm, 49 in..lbf) HINT: At the time of reassembly, please refer to the following item. Apply adhesive to the 3 screws. Part No.08833-00070, THREE BOND 1324 or equivalent. HINT: AT the time of reassembly, please refer to the following item. Apply MP grease to the sliding and rotating parts of the door lock.
- REMOVE OUTSIDE HANDLE Disconnect the connector. Remove the 2 bolts and handle. Torque: 5.5 N.m (56 kgf.cm, 49 in..lbf) Remove the key cylinder from the handle.
