Starting (3UZ-FE): Diagnosis Lexus GS III

Starter 45 illustrations ~1673 words

ON-VEHICLE INSPECTION

Note. Before changing the starter, check the following items again: Connector connection Accessory installation, e.g.: theft deterrent system

Scheme 1

Scheme 1: COMPONENTS
Scheme 1: COMPONENTS

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4: REMOVAL
Scheme 4: REMOVAL

Scheme 5

Scheme 5
Scheme 5
  1. DRAIN ENGINE COOLANT
  2. REMOVE V-BANK COVER
  3. REMOVE INTAKE AIR CONNECTOR PIPE
  4. REMOVE THROTTLE BODY (See THROTTLE BODY )
  5. REMOVE UPPER AND LOWER INTAKE MANIFOLDS ASSEMBLY (See appropriate step(s) under REMOVAL )
  6. REMOVE WATER BYPASS PIPE (See REMOVAL )
  7. REAR WATER BYPASS JOINT (See REMOVAL )
  8. REMOVE STARTER Disconnect the starter connector. Remove the nut, and disconnect the starter cable. Remove the bolt, and disconnect the engine wire protector. Remove the 2 bolts and starter.

Scheme 6

Scheme 6: DISASSEMBLY
Scheme 6: DISASSEMBLY

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. REMOVE FIELD FRAME AND ARMATURE Remove the nut, and disconnect the lead wire from the magnetic switch terminal. Remove the 2 through bolts. Pull out the field frame together with the armature from the magnetic switch. Remove the O-ring from the field frame.
  2. REMOVE STARTER HOUSING, CLUTCH ASSEMBLY AND GEARS Remove the 2 screws. Remove these parts from the magnetic switch: Remove the starter housing. Remove the return spring. Remove the idler gear. Remove the bearing. Remove the starter clutch assembly. Remove the O-ring from the starter housing.
  3. REMOVE STEEL BALL Using a magnetic finger, remove the steel ball from the clutch shaft hole.
  4. REMOVE BRUSH HOLDER Remove the 2 screws and end cover from the field frame. Using a screwdriver, hold the spring back and disconnect the brush from the brush holder. Disconnect the 4 brushes, and remove the brush holder.
  5. REMOVE ARMATURE FROM FIELD FRAME

Scheme 11

Scheme 11: INSPECTION
Scheme 11: INSPECTION

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23
  1. INSPECT ARMATURE COIL Check the commutator for open circuit. Using an ohmmeter, check that there is continuity between the segments of the commutator. If there is no continuity between any segment, replace the armature. Check the commutator for ground. Using an ohmmeter, check that there is no continuity between the commutator and armature coil core. If there is continuity, replace the armature.
  2. INSPECT COMMUTATOR Check the commutator for the dirty and burnt surfaces. If the surface is dirty or burnt, correct it with sandpaper (No. 400) or on a lathe. Check the commutator circle runout. Place the commutator on V-blocks. Using a dial gauge, measure the circle runout. Maximum circle runout: 0.05 mm (0.0020 in.) If the circle runout is greater than maximum, correct it on a lathe. Using vernier calipers, measure the commutator diameter. Standard diameter: 35.0 mm (1.378 in.) Minimum diameter: 34.0 mm (1.339 in.) If the diameter is less than minimum, replace the armature. Check that the undercut depth is clean and free of foreign materials. Smooth out the edge. Standard undercut depth: 0.7 mm (0.0281.339 in.) Minimum undercut depth: 0.2 mm (0.008 in.) If the undercut depth is less than minimum, correct it with a hacksaw blade.
  3. INSPECT FIELD FRAME Check the field coil for open circuit. Using an ohmmeter, check that there is continuity between the lead wire and field coil brush lead. If there is no continuity, replace the filed frame. Check the shunt coil for open circuit. Using an ohmmeter, measure the resistance between shunt coil terminals A and B. Resistance: 1.5 - 1.9 ohm at 20°C (68°F) If the resistance is not as specified, replace the field frame.
  4. INSPECT BRUSHES Using vernier calipers, measure the brush length. Standard length: 15.0 mm (0.591 in.) Minimum length: 9.0 mm (0.354 in.) If the length is less than minimum, replace the brush holder and field frame
  5. INSPECT BRUSH SPRINGS Check the brush spring load. Take the pull scale reading the instant the brush spring separates from the brush. Standard spring installed load: 21.5 - 27.5 N (2.2 - 2.8 kgf, 4.9 - 6.2 lbf) Minimum spring installed load: 12.7 N (1.3 kgf, 2.9 lbf) If the installed load is less than minimum, replace the brush springs.
  6. INSPECT BRUSH HOLDER Check the brush holder insulation. Using an ohmmeter, check that there is no continuity between the positive (+) and negative (-) brush holders. If there is continuity, repair or replace the brush holder.
  7. INSPECT CLUTCH AND GEARS Check the gear teeth on the pinion gear, idle gear and clutch assembly for wear or damage. If damaged, replace the gear or clutch assembly. If damaged, also check the ring gear of the flywheel for wear or damage. Check the clutch pinion gear. Hold the starter clutch and rotate the pinion gear clockwise, and check that it turns freely. Try to rotate the pinion gear counterclockwise and check that it locks. If necessary, replace the clutch assembly.
  8. INSPECT BEARINGS Turn the bearing by hand while applying inward force. If resistance is felt or the bearing sticks, replace the bearing (See REPLACEMENT ).
  9. INSPECT MAGNETIC SWITCH Check the pull-in coil for open circuit. Using an ohmmeter, check that there is continuity between terminals 50 and C. If there is no continuity, replace the magnetic switch. Check the hold-in coil for open circuit. Using an ohmmeter, check that there is continuity between terminal 50 and the switch body. If there is no continuity, replace the magnetic switch.

Scheme 24

Scheme 24: REPLACEMENT
Scheme 24: REPLACEMENT

Scheme 25

Scheme 25
Scheme 25

Scheme 26

Scheme 26
Scheme 26

Scheme 27

Scheme 27
Scheme 27

Scheme 28

Scheme 28
Scheme 28

Scheme 29

Scheme 29
Scheme 29

Scheme 30

Scheme 30
Scheme 30

Scheme 31

Scheme 31
Scheme 31

Scheme 32

Scheme 32
Scheme 32

Scheme 33

Scheme 33
Scheme 33

Scheme 34

Scheme 34
Scheme 34

Scheme 35

Scheme 35
Scheme 35

Scheme 36

Scheme 36
Scheme 36
  1. REPLACE FRONT BEARING Using SST, remove the bearing. SST 09286-4601 1 Using SST and a press, press in a new bearing. SST 09820-00031 NOTE: Be careful of the installation direction.
  2. REPLACE REAR BEARING Using SST, remove the bearing. SST 09286-4601 1 Using a press, press in a new bearing.
  3. REPLACE MAGNETIC SWITCH TERMINAL KIT PARTS Remove the 3 nuts, end cover, gasket and plunger. NOTE: Do not loosen the 3 stud bolts. Using vernier calipers, measure the contact plate for depth of wear. Maximum wear: 0.9 mm (0.035 in.) If the depth of wear is greater than the maximum, replace the contact plate. Remove the terminal kit parts. Put a wooden block on the contact plate and press it down with a hand press. Dimensions of wooden block: 20 x 33 x 40 mm (0.79 x 1.30 x 1.57 in.) press force: 981 N (100 kgf, 221 lbf) NOTE: Check the diameter of the hand press ram. Then calculate the gauge pressure of the press when 981 N (100 kgf, 221 lbf) of force is applied. Gauge pressure: (kgf/cm 2 ) = 100 kgf/(Ram diameter (cm)/2) 2 x 3.14 (phi) (psi) = 221 lbf/Ram diameter (in.)/2) 2 x 3.14 (phi) (kPa) = (kgf/cm 2 ) x 98.1 (kPa) = (psi) x 6.9 If the contact plate is not pressed down with the specified pressure, the contact plate may tilt due to coil deformation or the tightening of the nut. Using SST, loosen the terminal nuts. SST 09810-38140 Terminal C: Remove the terminal nut, washer, O-ring, terminal bolt and contact plate. Terminal 30: Remove the terminal nut, washer, O-ring, terminal bolt and contact plate. Temporarily install these new terminal 30 kit parts: Install the contact plate. Install the terminal bolt. Install the o-ring. Install the washer. Install the terminal nut. Temporarily install these new terminal C kit parts: Install the contact plate. Install the terminal bolt. Install the o-ring. Install the washer. Install the terminal nut. Temporarily tighten the terminal nuts. Tighten terminal nuts. Put a wooden block on the contact plate and press it down with a hand press. Using SST, tighten the nuts to the specified torque. SST 09810-38140 Torque: 17 N.m (173 kgf.cm, 13 ft.lbf) NOTE: If the nut is over tightened, it may cause cracks on the plastic frame. Clean the contact surfaces of the remaining contact plate and plunger with a dry shop rag. Reinstall the plunger, a new gasket and end cover with the 3 nuts. Torque: 3.6 N.m (37 kgf.cm, 32 in..lbf)

TEST

Note. These tests must be performed within 3 to 5 seconds to avoid during out the coil.

Scheme 37

Scheme 37: TEST
Scheme 37: TEST

Scheme 38

Scheme 38
Scheme 38

Scheme 39

Scheme 39
Scheme 39

Scheme 40

Scheme 40
Scheme 40
  1. PERFORM PULL-IN TEST Disconnect the field coil lead wire from terminal C. Connect the battery to the magnetic switch as shown. Check that the clutch pinion gear moves outward.
  2. PERFORM HOLD-IN TEST With battery connected as above with the clutch pinion gear out, disconnect the negative (-) lead from terminal C. Check that the pinion gear remains out.
  3. INSPECT CLUTCH PINION GEAR RETURN Disconnect the negative (-) lead from the switch body. Check that the clutch pinion gear returns inward.
  4. PERFORM NO-LOAD PERFORMANCE TEST Connect the battery and ammeter to the starter as shown. Check that the starter rotates smoothly and steadily with the pinion gear moving out. Check that the ammeter shows the specified current. Specified current: 100 A or less at 11.5 V

Scheme 41

Scheme 41: INSTALLATION
Scheme 41: INSTALLATION

Scheme 42

Scheme 42
Scheme 42
  1. INSTALL STARTER Install the starter with the 2 bolts. Torque: 37 N.m (380 kgf.cm, 27 ft.lbf) Connect the starter cable with the nut. Torque: 9.8 N.m (100 kgf.cm, 87 in..lbf) Install the engine wire protector to the starter with the bolt. Connect the starter connector.
  2. INSTALL REAR WATER BYPASS JOINT (See appropriate step(s) under INSTALLATION )
  3. INSTALL WATER BYPASS PIPE (See INSTALLATION )
  4. INSTALL UPPER AND LOWER INTAKE MANIFOLDS ASSEMBLY (See INSTALLATION )
  5. INSTALL THROTTLE BODY (See INSTALLATION )
  6. INSTALL INTAKE AIR CONNECTOR PIPE
  7. FILL WITH ENGINE COOLANT (See REPLACEMENT )
  8. CHECK THAT ENGINE STARTS
  9. START ENGINE AND CHECK FOR ENGINE COOLANT AND FUEL
  10. INSTALL V-BANK COVER

Scheme 43

Scheme 43: INSPECTION
Scheme 43: INSPECTION

Scheme 44

Scheme 44
Scheme 44

Scheme 45

Scheme 45
Scheme 45
  1. REMOVE RELAY BOX COVER
  2. REMOVE STARTER RELAY
  3. INSPECT STARTER RELAY Inspect the relay continuity. Using an ohmmeter, check that there is continuity between terminals 1 and 2. If there is no continuity, replace the relay. Check that there is no continuity between terminals 3 and 5. If there is continuity, replace the relay. Inspect the relay operation. Apply battery positive voltage across terminals 1 and 2. Using an ohmmeter, check that there is continuity between terminals 3 and 5. If there is no continuity, replace the relay.
  4. REINSTALL STARTER RELAY
  5. REINSTALL RELAY BOX COVER
