WIRING DIAGRAM
See DTC P0710 TRANSMISSION FLUID TEMPERATURE SENSOR "A" CIRCUIT : DTC P0712 TRANSMISSION FLUID TEMPERATURE SENSOR "A" CIRCUIT LOW INPUT : DTC P0713 TRANSMISSION FLUID TEMPERATURE SENSOR "A" CIRCUIT HIGH INPUT .
See DTC P0504: BRAKE SWITCH "A"/"B" CORRELATION .
See PATTERN SELECT SWITCH CIRCUIT .
Scheme 149
- Check pattern select switch. PREPARATION: Disconnect the pattern select switch connector. CHECK: Check continuity between each terminal of pattern select switch connector when the select switch is set to PWR, NORM and SNOW positions. OK: TESTER CONNECTION & SPECIFIC CONDITION Switch condition Tester connection Specified condition PWR 3 - 7 Continuity NORM 1 - 3, 3 - 7 No continuity SNOW 1 - 3 Continuity If the continuity is not as specified, replace the switch. NG: Replace pattern select switch. OK: Go To Next Step.
- Check harness and connector between pattern select switch and body ECU No. 1, pattern select switch and body ground (See «HOW TO USE THE DIAGNOSTIC CHART AND INSPECTION PROCEDURE»(ref-229346-S26338991582006041400000) ). NG: Repair or replace the harness or connector. OK: Proceed to next circuit inspection shown on problem symptoms table (See «PROBLEM SYMPTOMS TABLE»(ref-229177-S10193164582006042000000) )
