Power Steering Pump: Overview Lexus GS II рестайлинг

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. REMOVE ENGINE UNDER COVER Remove the 16 bolts and engine under cover.
2. REMOVE DRIVE BELT Loosen the drive belt tension by turning the drive belt tensioner clockwise, and remove the drive belt.
3. REMOVE RETURN HOSE Remove the clip and disconnect the return hose.
4. REMOVE PRESSURE FEED TUBE Remove the union bolt, gasket and pressure feed tube.
5. REMOVE PS VANE PUMP ASSEMBLY Disconnect the connector. Remove the 2 bolts and PS vane pump assembly.
