ON-VEHICLE INSPECTION

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. Check battery electrolyte level. Check the electrolyte quantity of each cell. Maintenance-Free Battery: Charging (2JZ-GE) If under the lower level, replace the battery (or add distilled water if possible). Check the charging system. Except Maintenance-Free Battery: If under the lower level, add distilled water.
2. Except Maintenance-Free Battery: Check battery specific gravity. Check the specific gravity of each cell. Standard Specific Gravity : 1.25-1.29 at 20°C (68°F) If the specific gravity is less than specification, charge the battery.
3. Maintenance-Free Battery: Check battery positive voltage. After having driven the vehicle and in the case that 20 minutes have not passed after having stopped the engine, turn the ignition switch ON and turn on the electrical system (headlight, blower motor, rear defogger etc.) for 60 seconds to remove the surface charge. Turn the ignition switch OFF and turn off the electrical systems. Measure the battery positive voltage between the negative (-) and positive (+) terminals of the battery. Standard Voltage : 12.5-12.9 V at 20°C (68°F) If the voltage is less than specification, charge the battery.
4. Check battery terminals and fuses. Check that the battery terminals are not loose or corroded. If the terminals are corroded, clean the terminals. Check the fusible link and fuses for continuity.
5. Inspect drive belt. NOTE: A belt tensioner is used, so checking the belt tension is not necessary. Visually check the drive belt for excessive wear, frayed cords, etc. If necessary, replace the drive belt. NOTE: Cracks on the rib side of a drive belt are considered acceptable. If the drive belt has chunks missing from the ribs, it should be replaced. The drive belt tension can be released by turning the belt tensioner clockwise. Check the belt tensioner operation. Check that the belt tensioner moves downward when the drive belt is pressed down at the points indicated in the illustration with approx. 98 N (10 kgf, 22.0 lbf) of force. Check the alignment of the belt tensioner pulley to make sure the drive belt will not slip off the pulley. If necessary, replace the belt tensioner. Check that the arrow mark on the belt tensioner falls within area A of the scale. If it is outside area A, replace the drive belt. NOTE: When a new belt is installed, it should lie within area B. If not, the drive belt is not correct. After installing a drive belt, check that it fits properly in the ribbed grooves. Check by hand to confirm that the belt has not slipped out of the groove on the bottom of the pulley.
6. Visually check generator wiring and listen for abnormal noises. Check that the wiring is in good condition. Check that there is no abnormal noise from the generator while the engine is running.
7. Check charge warning light circuit. Warm up the engine and then turn it off. Turn off all accessories. Turn the ignition switch "ON". Check that the charge warning light is lit. Start the engine. Check that the light goes off. If the light does not go off as specified, troubleshoot the charge light circuit.
8. Inspect charging circuit without load. NOTE: If a battery/generator tester is available, connect the tester to the charging circuit as per manufacturer's instructions. If a tester is not available, connect a voltmeter and ammeter to the charging circuit as follows: Disconnect the wire from terminal B of the generator, and connect it to the negative (-) probe of the ammeter. Connect the positive (+) probe of the ammeter to terminal B of the generator. Connect the positive (+) probe of the voltmeter to terminal B of the generator. Ground the negative (-) probe of the voltmeter. Check the charging circuit as follows: With the engine running from idling to 2000 RPM, check the reading on the ammeter and voltmeter. Standard Amperage : 10 A or less Standard Voltage : 13.2-14.8 V If the value is not specified, check the generator.
9. Inspect charging circuit with load. With the engine running at 2000 RPM, turn on the high beam headlights and place the heater blower switch at "HI". Check the reading on the ammeter. Standard Amperage : 30 A or more If the ammeter reading is less than the standard amperage, repair the generator. NOTE: If the battery is fully charged, the indication will sometimes be less than standard amperage.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Remove engine under cover.
2. Remove drive belt. Loosen the belt tension by turning the drive belt tensioner clockwise, and remove the drive belt. NOTE: At the time of installation, please refer to the following items. Do an on-vehicle inspection. See «CHARGING SYSTEM»(ref-175564-S25193318752005042200000) .
3. Remove generator. Disconnect the generator connector. Remove the rubber cap and nut, and disconnect the generator wire. Disconnect the engine wire clamp from the wire clip on the generator. Remove the bolt and pipe clamp, and disconnect the 2 A/T oil cooler pipes from the generator. Remove the bolt, nut, pipe bracket and generator. Torque : 40 N.m (400 kgf.cm, 30 ft.lbf)

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

1. Remove rear end cover. Remove the nut and terminal insulator. Remove the bolt, 3 nuts, plate terminal and end cover.
2. Remove brush holder and voltage regulator. Remove the brush holder cover from the brush holder. Remove the 5 screws, brush holder and voltage regulator. Remove the seal plate from the rectifier end frame.
3. Remove rectifier holder. Remove the 4 screws and rectifier holder. Remove the 4 rubber insulators.
4. Remove pulley. Hold SST (A) with a torque wrench, and tighten SST (B) clockwise to the specified torque. SST 09820-63011 Torque: 39 N.m (400 kgf.cm, 29 ft.lbf) Check that SST (A) is secured to the rotor shaft. Mount SST (C) in a vise. Insert SST (B) into SST (C), and attach the pulley nut to SST (C). To loosen the pulley nut, turn SST (A) in the direction shown in the illustration. NOTE: To prevent damage to the rotor shaft, do not loosen the pulley nut more than one-half of a turn. Remove the generator from SST (C). Turn SST (B), and remove SST (A and B). Remove the pulley nut and pulley.
5. Remove rectifier end frame. Remove the 4 nuts and wire clip. Using SST, remove the rectifier end frame. SST 09950-40011 (09951-04020, 09952-04010, 09953-04030, 09954-04010, 09955-04041) Remove the generator washer.
6. Remove rotor from drive end frame

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

1. Inspect voltage regulator. Using an ohmmeter, check the continuity between terminals F and B. Standard : When the positive and negative poles between terminals F and B are exchanged, there is continuity in one way but no continuity in another way. If the continuity is not as specified, replace the voltage regulator. Using an ohmmeter, check the continuity between terminals F and E. Standard : When the positive and negative poles between terminals F and E are exchanged, there is continuity in one way but no continuity in another way. If the continuity is not as specified, replace the voltage regulator.
2. Inspect rotor. Check rotor for open circuit. Using an ohmmeter, check that there is continuity between the slip rings. Standard Resistance : 2.2-2.4 ohms at 20°C (68°F) If there is no continuity, replace the rotor. Check the rotor for ground. Using an ohmmeter, check that there is no continuity between the slip ring and rotor. If there is continuity, replace the rotor. Check that the slip rings are not rough or scored. If rough or scored, replace the rotor. Using vernier calipers, measure the slip ring diameter. Standard Diameter : 14.2-14.4 mm (0.559-0.567 in.) Minimum Diameter : 12.8 mm (0.504 in.) If the diameter is less than minimum, replace the rotor.
3. Inspect stator (drive end frame) Check the stator for open circuit. Using an ohmmeter, check that there is continuity between the coil leads. If there is no continuity, replace the drive end frame assembly. Check the stator for ground. Using an ohmmeter, check that there is no continuity between the coil lead and drive end frame. If there is continuity, replace the drive end frame assembly.
4. Inspect brushes. Using vernier calipers, measure the exposed brush length. Standard Exposed Length : 9.5-11.5 mm (0.374-0.453 in.) Minimum Exposed Length : 1.5 mm (0.059 in.) If the exposed length is less than minimum, replace the brush holder assembly.
5. Inspect rectifiers (rectifier holder). Check the positive (+) rectifier. Using an ohmmeter, connect one tester probe to the positive (+) terminal and the other to each rectifier terminal. Reverse the polarity of the tester probes and repeat step (a). Check that one shows continuity and the other shows no continuity. If continuity is not as specified, replace the rectifier holder. Check the negative (-) rectifier. Using an ohmmeter, connect one tester probe to each negative (-) terminal and the other to each rectifier terminal. Reverse the polarity of the tester probes and repeat step (a). Check that one shows continuity and the other shows no continuity. If continuity is not as specified, replace the rectifier holder.
6. Inspect bearing. Check the bearing is not rough or worn. If necessary, replace the bearing. See «REPLACEMENT»(ref-175564-S41389140362005042200000) .

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

1. Replace front bearing. Remove the 4 screws, bearing retainer and bearing. Using a socket wrench and press, press out the bearing. Using SST and a press, press in a new bearing. SST 09950-60010 (09951-00500) Install the bearing retainer with the 4 screws. Torque : 3.0 N.m (31 kgf.cm 27 in.lbf)
2. Replace rear bearing. Using SST, remove the bearing cover (outside) and bearing. SST 09820-00021 NOTE: Be careful not to damage the fan. Remove the bearing cover (inside). Place the bearing cover (inside) on the rotor. Using SST and a press, press in a new bearing. SST 09820-00031 Using SST, push in the bearing cover (outside). SST 09285-76010

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

1. Place drive end frame on pulley.
2. Install rotor to drive end frame.
3. Install rectifier end frame Place the generator washer on the rotor. Using a 29 mm socket wrench and press, slowly press in the rectifier end frame. Install the 3 nuts. Torque: 4.5 N.m (46 kgf.cm, 40 in.lbf) Install the wire clip with the nut. Torque: 5.4 N.m (55 kgf.cm, 48 in.lbf)
4. Install pulley. Install the pulley to the rotor shaft by tightening the pulley nut by hand. Hold SST (A) with a torque wrench, and tighten SST (B) clockwise to the specified torque. SST 09820-63011 Torque: 39 N.m (400 kgf.cm, 29 ft.lbf) Check that SST (A) is secured to the pulley shaft. Mount SST (C) in a vise. Insert SST (B) into SST (C), and attach the pulley nut to SST (C). To torque the pulley nut, turn SST (A) in the direction shown in the illustration. (Scheme 46) Torque: 110.5 N.m (1,125 kgf.cm, 81 ft.lbf) Remove the generator from SST (C). Turn SST (B), and remove SST (A and B).
5. Install rectifier holder. Install the 4 rubber insulators on the lead wires. Install the rectifier holder while pushing it with the 4 screws. Torque: 2.9 N.m (30 kgf.cm, 26 in.lbf)
6. Install voltage regulator and brush holder. Place the seal plate on the rectifier end frame. Place the voltage regulator and brush holder on the rectifier end frame. NOTE: Be careful of the holder installation direction. Install the 5 screws. Torque: 2.0 N.m (20 kgf.cm, 18 in.lbf) Place the brush holder cover on the brush holder.
7. Install rear end cover. Install the end cover and plate terminal with the bolt and 3 nuts. Torque: Nut: 4.4 N.m (45 kgf.cm, 39 in.lbf) Bolt: 3.9 N.m (39 kgf.cm, 35 in.lbf) Install the terminal insulator with the nut. Torque: 6.5 N.m (67 kgf.cm, 58 in.lbf)
8. Check that rotor rotates smoothly.
