Fuse & Circuit Breaker Identification
- 1 - 15 Amp Seat Heater
- 2 - 20 Amp Shift Lock System, High Mount Stoplight, Cruise Control, ABS System, Stoplights, Traction Control, Fuel Injection System
- 3 - 15 Amp Rear Window/Mirror Defogger, Heater, Air Conditioning, Gauges & Meters, Service Reminder Indicators, Warning Buzzers, Charging System, Auto. Trans. Indicator, Back-Up Lights, Daytime Lights
- 4 - 10 Amp Shift Lock System, Telephone, Passenger Power Door Locks, ABS System, Seat Belts, Power Steering Control, Traction Control, Cruise Control, Driving Pattern Selector System, Tilt/Telescopic Control, Power Antenna, Electronic Cooling Fan, Instrument Panel Lights, Automatic Light Control, Power Door Locks
- 5 - 15 Amp Clock, Air Conditioning, Radio, Cassette/CD Player, Shift Lock System, SRS System, Cigarette Lighters, Power Door Locks, Power Rear View Mirror
- 6 - 10 Amp Turn Signal Lights & Indicator
- 7 - 15 Amp Windshield Wiper/Washer, Headlight Cleaner
- 8 - 7.5 Amp Auto. Trans Indicator, Heater Control, Flashers, Glove Box Light, Rear Ashtrays, Radio/Cassette/CD/Tape Player Lights, Driving Pattern Light, Instrument Panel Lights, Daytime Running Lights
- 9 - 7.5 Amp Supplemental Restraint System
- 10 - 10 Amp License/Tail/Parking Lights
- 11 - 10 Amp Outside Rear View Mirror Defogger
Scheme 1
Scheme 1: ENGINE COMPARTMENT FUSE PANEL IDENTIFICATION - 1993-94
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- 1 - 15 Amp - Foglights
- 2 - 7.5 Amp - Daytime Running Lights (Canada)
- 3 - 10 Amp - Traction Control System
- 4 - 10 Amp - Interior/Vanity Lights, Sun Roof, Cruise Control, Open Door Warning, Personal/Trunk/Door/Footwell Lights, Ignition Lights, Clock, ABS System, Power Antenna
- 5 - 7.5 Amp - Wireless Remote Locking System, ABS System, Traction Control, Cruise Control, Daytime Lights
- 6 - 7.5 Amp - Charging System
- 7 - 15 Amp - Fuel Injection System, SRS System, Charge Light, Starting System, Electronic Ignition, Distributor Ignition, Gauges & Meters, Service Reminder Indicators, Warning Buzzers
- 8 - 15 Amp - Telephone
- 9 - 20 Amp - Emergency Flashers, Horn
- 10 - 20 Amp - Electronic Transmission, Fuel Injection system
- 11 - 25 Amp - Radio, Power Antenna, Cassette Tape/Compact Disc Player
- 12 - 30 Amp - Electronic Ignition, Distributor Ignition
- 13 - 15 Amp - Right Headlight (Low Beam)
- 14 - 15 Amp - Left Headlight (Low Beam)
- 15 - 10 Amp - Right Headlight (Low Beam Canada)
- 16 - 10 Amp - Left Headlight (Low Beam Canada)
- 17 - 30 Amp - Electronic Cooling Fan
Scheme 2
Scheme 2: ENGINE COMPARTMENT FUSE PANEL IDENTIFICATION - 1995-96
| WARNING | Always disconnect battery ground cable before servicing "high-current fuses. It is recommended that "high-current" fuses be replaced by a qualified technician. |
- 12 - 15 Amp - Foglights
- 13 - 7.5 Amp - Daytime Running Lights (Canada)
- 14 - 10 Amp - Traction Control System
- 15 - 10 Amp - Interior/Vanity Lights, Sun Roof, Cruise Control, Open Door Warning, Personal/Trunk/Door/Footwell Lights, Ignition Lights, Clock, ABS System, Power Antenna
- 16 - 7.5 Amp - Locking With Wireless Remote Control System, ABS System, Traction Control System, Cruise Control, Daytime Lights System, Air Conditioning System
- 17 - 7.5 Amp - Charging System
- 18 - 15 Amp - Multiport Fuel Injection System/Sequential Fuel Injection System, SRS, Charging Lamp, Starting System, Electronic Ignition System/Distributor Ignition System, Gauges & Meters, Service Reminder Indicators, Warning Buzzers
- 19 - 15 Amp - Telephone
- 20 - 20 Amp - Emergency Flashers, Horn
- 21 - 20 Amp - Electronic Transmission, Fuel Injection system
- 22 - 25 Amp - Radio, Power Antenna, Cassette Tape/Compact Disc Player
- 23 - 30 Amp - Electronic Ignition, Distributor Ignition
- 24 - 15 Amp - Right Headlight
- 25 - 15 Amp - Left Headlight
- 26 - 10 Amp - Right Headlight (Low Beam Canada)
- 27 - 10 Amp - Left Headlight (Low Beam Canada)
- 28 - 30 Amp - Electronic Cooling Fan
