Intuitive Parking Assist System (Diagnostic Codes & Circuit Tests): Overview Lexus ES XV60

Warning System 11 illustrations ~604 words

DESCRIPTION

The No. 1 ultrasonic sensor (front left sensor) is installed on the front bumper. The ECU detects obstacles based on signals received from the No. 1 ultrasonic sensor (front left sensor). If the No. 1 ultrasonic sensor (front left sensor) has an open circuit or other malfunction, it will not function normally.

DTC No.DTC Detection ConditionTrouble Area
C1AE1A malfunction of the No. 1 ultrasonic sensor (front left sensor).No. 1 ultrasonic sensor (front left sensor) Harness or connector Clearance warning ECU assembly

Scheme 77

Scheme 77: WIRING DIAGRAM

The No. 1 ultrasonic sensor (front left center sensor) is installed on the front bumper. The ECU detects obstacles based on signals received from the No. 1 ultrasonic sensor (front left center sensor). If the No. 1 ultrasonic sensor (front left center sensor) has an open circuit or other malfunction, it will not function normally.

DTC No.DTC Detection ConditionTrouble Area
C1AE2A malfunction of the No. 1 ultrasonic sensor (front left center sensor).No. 1 ultrasonic sensor (front left center sensor) Harness or connector Clearance warning ECU assembly

Scheme 78

Scheme 78: WIRING DIAGRAM

The No. 1 ultrasonic sensor (front right center sensor) is installed on the front bumper. The ECU detects obstacles based on signals received from the No. 1 ultrasonic sensor (front right center sensor). If the No. 1 ultrasonic sensor (front right center sensor) has an open circuit or other malfunction, it will not function normally.

DTC No.DTC Detection ConditionTrouble Area
C1AE3A malfunction of the No. 1 ultrasonic sensor (front right center sensor).No. 1 ultrasonic sensor (front right center sensor) Harness or connector Clearance warning ECU assembly

Scheme 79

Scheme 79: WIRING DIAGRAM

The No. 1 ultrasonic sensor (front right sensor) is installed on the front bumper. The ECU detects obstacles based on signals received from the No. 1 ultrasonic sensor (front right sensor). If the No. 1 ultrasonic sensor (front right sensor) has an open circuit or other malfunction, it will not function normally.

DTC No.DTC Detection ConditionTrouble Area
C1AE4A malfunction of the No. 1 ultrasonic sensor (front right sensor).No. 1 ultrasonic sensor (front right sensor) Harness or connector Clearance warning ECU assembly

Scheme 80

Scheme 80: WIRING DIAGRAM

The No. 1 ultrasonic sensor (rear left sensor) is installed on the front bumper. The ECU detects obstacles based on signals received from the No. 1 ultrasonic sensor (rear left sensor). If the No. 1 ultrasonic sensor (rear left sensor) has an open circuit or other malfunction, it will not function normally.

DTC No.DTC Detection ConditionTrouble Area
C1AE6A malfunction of the No. 1 ultrasonic sensor (rear left sensor).No. 1 ultrasonic sensor (rear left sensor) Harness or connector Clearance warning ECU assembly

Scheme 81

Scheme 81: WIRING DIAGRAM

The No. 1 ultrasonic sensor (rear left center sensor) is installed on the front bumper. The ECU detects obstacles based on signals received from the No. 1 ultrasonic sensor (rear left center sensor). If the No. 1 ultrasonic sensor (rear left center sensor) has an open circuit or other malfunction, it will not function normally.

DTC No.DTC Detection ConditionTrouble Area
C1AE7A malfunction of the No. 1 ultrasonic sensor (rear left center sensor).No. 1 ultrasonic sensor (rear left center sensor) Harness or connector Clearance warning ECU assembly

Scheme 82

Scheme 82: WIRING DIAGRAM

The No. 1 ultrasonic sensor (rear right center sensor) is installed on the front bumper. The ECU detects obstacles based on signals received from the No. 1 ultrasonic sensor (rear right center sensor). If the No. 1 ultrasonic sensor (rear right center sensor) has an open circuit or other malfunction, it will not function normally.

DTC No.DTC Detection ConditionTrouble Area
C1AE8A malfunction of the No. 1 ultrasonic sensor (rear right center sensor).No. 1 ultrasonic sensor (rear right center sensor) Harness or connector Clearance warning ECU assembly

Scheme 83

Scheme 83: WIRING DIAGRAM

The No. 1 ultrasonic sensor (rear right sensor) is installed on the front bumper. The ECU detects obstacles based on signals received from the No. 1 ultrasonic sensor (rear right sensor). If the No. 1 ultrasonic sensor (rear right sensor) has an open circuit or other malfunction, it will not function normally.

DTC No.DTC Detection ConditionTrouble Area
C1AE9A malfunction of the No. 1 ultrasonic sensor (rear right sensor).No. 1 ultrasonic sensor (rear right sensor) Harness or connector Clearance warning ECU assembly

Scheme 84

Scheme 84: WIRING DIAGRAM

These DTCs are stored when the clearance warning ECU assembly cannot receive and recognize several signals via the CAN communication line.

DTC No.DTC Detection ConditionTrouble Area
U0101Lost communication with ECMCAN communication system
U0155Lost communication with combination meter assembly

HINT

When 2 or more DTCs starting with "U" are output simultaneously, inspect the connectors and wire harnesses of each ECU.

The back sonar or clearance sonar switch assembly is installed at the base of the driver side of the instrument panel.

When the clearance sonar main switch is turned on, an on signal is sent to the clearance warning ECU assembly. The intuitive parking assist system operates according to this signal.

Scheme 85

Scheme 85: WIRING DIAGRAM

This circuit consists of the No. 1 clearance warning buzzer and clearance warning ECU assembly. An ECU-excited type buzzer is used. The ECU operates the buzzer using a sound pattern that changes depending on the distance to the obstacle.

Scheme 86

Scheme 86: WIRING DIAGRAM

This circuit provides power to operate the clearance warning ECU assembly.

Scheme 87

Scheme 87: WIRING DIAGRAM
