Steering Column (Service Information): Removal & Installation Lexus ES XV60

REMOVAL [06/2012 - ]

Note. Do not replace the spiral cable with sensor sub-assembly with the battery connected and the engine switch on (IG). Do not rotate the spiral cable with sensor sub-assembly without the steering wheel with the battery connected and the engine switch on (IG). Ensure that the steering wheel is installed and aligned straight when inspecting the steering sensor.

Scheme 33

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. ALIGN FRONT WHEELS FACING STRAIGHT AHEAD
2. REMOVE HORN BUTTON ASSEMBLY Refer to «REMOVAL [06/2012 - ]»(ref-598451-S10127139952014021400000)
3. REMOVE STEERING WHEEL ASSEMBLY Disconnect the connectors from the spiral cable sub-assembly. w/ Steering Heater: Disconnect the connector. Remove the steering wheel assembly set nut. TEXT IN ILLUSTRATION *a Matchmark Put matchmarks on the steering wheel assembly and steering main shaft. Using SST, remove the steering wheel assembly. SST: 09950-50013 09951-05010 09952-05010 09953-05020 09954-05070 TEXT IN ILLUSTRATION *a Turn *b Hold NOTE: Apply a small amount of grease to the threads and tip of SST (09953-05020) before use.
4. REMOVE STEERING PAD SWITCH ASSEMBLY See step 2
5. REMOVE CRUISE CONTROL MAIN SWITCH . Refer to «REMOVAL [06/2012 - ] - Step 2»(ref-598474-S35582052972014021400000)
6. REMOVE CRUISE CONTROL SWITCH WIRE Remove the cruise control switch wire.
7. REMOVE STEERING SHAKE DAMPER Remove the 2 screws and steering shake damper from the steering wheel sub-assembly.
8. REMOVE LOWER STEERING WHEEL BOSS COVER w/ Steering Heater: Disconnect the connector. Remove the double-sided tape and separate the steering heater harness from the lower steering wheel boss cover. TEXT IN ILLUSTRATION *a Double-sided Tape Disengage the 4 claws to remove the lower steering wheel boss cover from the steering wheel sub-assembly.
9. REMOVE STEERING WHEEL HEATER CONTROL ASSEMBLY (w/ Steering Heater) See step 2

INSTALLATION [06/2012 - ]

Note. Do not replace the spiral cable with sensor sub-assembly with the battery connected and the engine switch on (IG). Do not rotate the spiral cable with sensor sub-assembly without the steering wheel with the battery connected and the engine switch on (IG). Ensure that the steering wheel is installed and aligned straight when inspecting the steering sensor.

1. INSTALL STEERING WHEEL HEATER CONTROL ASSEMBLY (w/ Steering Heater) See step 1
2. INSTALL LOWER STEERING WHEEL BOSS COVER Engage the 4 claws to install the lower steering wheel boss cover to the steering wheel sub-assembly. NOTE: Do not allow the steering heater wire harness to be caught between the lower steering wheel boss cover and the steering wheel sub-assembly. w/ Steering Heater: Remove the release paper from new double-sided tape and install the steering heater harness to the lower steering wheel boss cover. NOTE: Do not touch the adhesive surface of the double-sided tape. Connect the connector to the steering wheel heater control assembly.
3. INSTALL STEERING SHAKE DAMPER Install the steering shake damper to the steering wheel sub-assembly with the 2 screws. Torque: 2.4 N*m (24 kgf*cm, 21 in.*lbf)
4. INSTALL CRUISE CONTROL SWITCH WIRE Install the cruise control switch wire.
5. INSTALL CRUISE CONTROL MAIN SWITCH . Refer to «INSTALLATION [06/2012 - ] - Step 1»(ref-598474-S05318643852014021400000)
6. INSTALL STEERING PAD SWITCH ASSEMBLY See step 1
7. ALIGN FRONT WHEELS FACING STRAIGHT AHEAD
8. INSPECT AND ADJUST SPIRAL CABLE WITH SENSOR SUB-ASSEMBLY . Refer to «INSTALLATION [06/2012 - ] - Step 6»(ref-598451-S31798076212014021400000)
9. INSTALL STEERING WHEEL ASSEMBLY Install the steering wheel assembly aligning the matchmarks on the steering wheel assembly and steering main shaft. TEXT IN ILLUSTRATION *a Matchmark Install the steering wheel assembly set nut. Torque: 50 N*m (510 kgf*cm, 37 ft.*lbf) w/ Steering Heater: Connect the connector. Connect the connectors to the spiral cable sub-assembly.
10. CHECK STEERING WHEEL CENTER POINT
11. INSTALL HORN BUTTON ASSEMBLY Refer to «INSTALLATION [06/2012 - ]»(ref-598451-S05269589622014021400000)

Scheme 40

Scheme 41

Scheme 42

1. REMOVE HORN BUTTON ASSEMBLY Refer to «REMOVAL [06/2012 - ]»(ref-598451-S10127139952014021400000)
2. REMOVE STEERING PAD SWITCH ASSEMBLY Disengage the clamp to separate the connector from the lower steering wheel boss cover. Remove the 2 screws. Disengage the 2 claws and 2 pins to remove the steering pad switch assembly from the steering wheel sub-assembly.

Scheme 43

Scheme 44

1. INSPECT STEERING PAD SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition z5-1 (HO) - Terminal A Always Below 2.5 ohms z5-4 (DIST) - z5-7 (ECC) Distance control switch pushed Below 2.5 ohms Lane departure alert main switch being pushed and held 228 to 252 ohms No switch pushed 10 kohms or higher z5-10 (AU2) - z5-8 (EAU) No switch pushed 95 to 105 kohms MODE switch pushed Below 2.5 ohms Voice switch pushed 2955 to 3265 ohms Voice return switch pushed 313 to 345 ohms On hook switch pushed 313 to 345 ohms Off hook switch pushed 950 to 1050 ohms z5-11 (AU1) - z5-8 (EAU) No switch pushed 95 to 105 kohms Seek+ switch pushed Below 2.5 ohms Seek- switch pushed 313 to 345 ohms Volume+ switch pushed 950 to 1050 ohms Volume- switch pushed 2955 to 3265 ohms A-3 (ECC) - z5-7 (ECC) Always Below 2.5 ohms HINT: If the result is not as specified, replace the steering pad switch assembly. TEXT IN ILLUSTRATION *a Component without harness connected (Steering Pad Switch Assembly) *b Seek+ *c Volume+ *d Volume- *e MODE *f Lane departure alert main switch *g Seek- *h Voice switch *i Voice return switch *j Off hook *k On hook *l DISP *m Distance control switch *n Terminal A Check the illumination. Connect a positive (+) lead to terminal IL+2 and a negative (-) lead to terminal -DP of the steering pad switch assembly connector. Check that the switch illumination comes on. OK Steering pad switch illumination comes on. HINT: If the result is not as specified, replace the steering pad switch assembly. TEXT IN ILLUSTRATION *a Component without harness connected (Steering Pad Switch Assembly)

1. INSTALL STEERING PAD SWITCH ASSEMBLY Engage the 2 claws and 2 pins to install the steering pad switch assembly to the steering wheel sub-assembly. Install the 2 screws. Torque: 2.4 N*m (24 kgf*cm, 21 in.*lbf) Engage the clamp to install the connector to the lower steering wheel boss cover.
2. INSTALL HORN BUTTON ASSEMBLY Refer to «INSTALLATION [06/2012 - ]»(ref-598451-S05269589622014021400000)

Scheme 45

Scheme 46

Scheme 47

1. REMOVE LOWER NO. 1 INSTRUMENT PANEL AIRBAG ASSEMBLY Refer to «REMOVAL [06/2012 - ]»(ref-598451-S04532970082014021400000)
2. REMOVE MULTIPLEX TILT AND TELESCOPIC ECU Disconnect the connector from the multiplex tilt and telescopic ECU. Disengage the wire harness clamp. Disengage the claw to remove the multiplex tilt and telescopic ECU from the steering column assembly.

1. INSTALL MULTIPLEX TILT AND TELESCOPIC ECU Engage the claw to install the multiplex tilt and telescopic ECU to the steering column assembly. Engage the wire harness clamp. Connect the connector to the multiplex tilt and telescopic ECU.
2. INSTALL LOWER NO. 1 INSTRUMENT PANEL AIRBAG ASSEMBLY Refer to «INSTALLATION [06/2012 - ]»(ref-598451-S29860631972014021400000)

Scheme 48

Scheme 49

1. ALIGN FRONT WHEELS FACING STRAIGHT AHEAD
2. REMOVE HORN BUTTON ASSEMBLY Refer to «REMOVAL [06/2012 - ]»(ref-598451-S10127139952014021400000)
3. REMOVE STEERING WHEEL ASSEMBLY See step 3
4. REMOVE LOWER STEERING COLUMN COVER See step 9
5. REMOVE TILT AND TELESCOPIC SWITCH Disconnect the connectors. Disengage the claw and pull out the tilt and telescopic switch. NOTE: Pushing on the claw too hard will break the claw.

Scheme 50

1. INSPECT TILT AND TELESCOPIC SWITCH Remove the tilt and telescopic switch. Refer to «REMOVAL [06/2012 - ]»(ref-598450-S14352628182014021400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 1 (VC) - 3 (MSW) Tilt up 342 to 378 ohms Tilt down 1890.5 to 2089.5 ohms Telescopic contract 750.5 to 829.5 ohms Telescopic extend 152 to 168 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Tilt and Telescopic Switch)

1. INSTALL TILT AND TELESCOPIC SWITCH Engage the claw to install the tilt and telescopic switch. Connect the connectors.
2. INSTALL LOWER STEERING COLUMN COVER See step 9
3. ALIGN FRONT WHEELS FACING STRAIGHT AHEAD
4. INSPECT AND ADJUST SPIRAL CABLE WITH SENSOR SUB-ASSEMBLY . Refer to «INSTALLATION [06/2012 - ] - Step 6»(ref-598451-S31798076212014021400000)
5. INSTALL STEERING WHEEL ASSEMBLY See step 9
6. INSTALL HORN BUTTON ASSEMBLY Refer to «INSTALLATION [06/2012 - ]»(ref-598451-S05269589622014021400000)

Scheme 51

Scheme 52

1. REMOVE LOWER STEERING WHEEL BOSS COVER Refer to «REMOVAL [06/2012 - ]»(ref-598450-S16085896072014021400000)
2. REMOVE STEERING WHEEL HEATER CONTROL ASSEMBLY Disengage the clamp. Remove the 2 screws and steering wheel heater control assembly from the lower steering wheel boss cover.

1. INSTALL STEERING WHEEL HEATER CONTROL ASSEMBLY Install the steering wheel heater control assembly to the lower steering wheel boss cover with the 2 screws. Torque: 0.8 N*m (9 kgf*cm, 7 in.*lbf) Engage the clamp.
2. INSTALL LOWER STEERING WHEEL BOSS COVER See step 2

Scheme 53

Scheme 54

1. REMOVE CONSOLE PANEL SUB-ASSEMBLY Refer to «REMOVAL [06/2012 - ]»(ref-598633-S11793974212014021400000)
2. REMOVE COMBINATION SWITCH ASSEMBLY Disengage the 4 claws to remove the combination switch assembly from the console panel sub-assembly.

Scheme 55

1. INSPECT STEERING HEATER SWITCH (COMBINATION SWITCH ASSEMBLY) Remove the steering heater switch (combination switch assembly). Refer to «REMOVAL [06/2012 - ]»(ref-598450-S16085896072014021400000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition 9 (IG) - 3 (IN) Steering heater switch (combination switch assembly) is pushed Below 1 ohms 9 (IG) - 3 (IN) Steering heater switch (combination switch assembly) is not pushed 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Steering Heater Switch (Combination Switch Assembly))

1. INSTALL COMBINATION SWITCH ASSEMBLY Engage the 4 claws to install the combination switch assembly to the console panel sub-assembly.
2. INSTALL CONSOLE PANEL SUB-ASSEMBLY Refer to «INSTALLATION [06/2012 - ] - Step 8»(ref-598633-S41851355832014021400000)
