SYSTEM DESCRIPTION [06/2012 - ]
- POWER MIRROR CONTROL SYSTEM DESCRIPTION This system has the following functions: power retract mirror function, reverse shift-linked function, electrical remote control function, memory function and mirror heater function.
- FUNCTION OF MAIN COMPONENT Component Function Outer rear view mirror assembly Vertical mirror motor Receives a signal from the outer mirror control ECU assembly and adjusts the mirror surface position vertically. Horizontal mirror motor Receives a signal from the outer mirror control ECU assembly and adjusts the mirror surface position horizontally. Outer mirror retractor Receives a signal from the outer mirror control ECU assembly, and retracts and returns the outer rear view mirror assemblies. Mirror position sensor Detects the mirror surface position. This data is detected by the outer mirror control ECU assembly. Mirror heater Receives a signal from the outer mirror control ECU assembly and operates the mirror heater. EC mirror cell Varies reflection rate of the mirror through function of EC elements. Outer mirror switch assembly Mirror select switch Consists of R and L switches. One must be chosen to operate the outer mirror switch assembly. Mirror adjust switch Mirror R and L signals are sent to each outer mirror control ECU assembly from the mirror select switch. After selecting the R or L switch, the right, left, up and down control switches can be operated to change the angle of the mirror. Retractable outer mirror switch Retracts and returns the outer rear view mirror assemblies. Mirror retract and return signals are sent to each outer mirror control ECU assembly from the main body ECU (multiplex network body ECU). Seat memory switch When the seat memory M1, M2 or M3 switch is pressed while the SET switch is being pressed, or the M1, M2 or M3 switch is pressed within 3 seconds of the SET switch being pressed, a signal is sent to the outer mirror control ECU assembly (driver door), which records the mirror surface position. When the seat memory switch is pressed, a signal is sent to the outer mirror control ECU assembly (driver door) and sent to the main body ECU (multiplex network body ECU), which changes the mirror surface position to the memorized position. Outer mirror control ECU assembly Operates each mirror motor based on signals from the mirror select switch and mirror adjust switch. Based on information from the mirror position sensors, 3 different mirror surface positions can be stored. By operating a seat memory switch, the mirror surface moves to the stored position.
- SYSTEM OPERATION The remote control mirrors have the following features. Function Outline Remote control mirror function When the outer mirror switch assembly is operated, this function moves the mirror surface vertically or horizontally to enable the driver to attain an optimal mirror angle. Setting the mirror select switch to the R position operates the right mirror, and setting it to the L position operates the left mirror. Memory and reactivation function Stores the adjusted mirror position in the outer mirror control ECU assembly. AUTO power retract mirror function Retracts and returns each outer rear view mirror assembly together with the following operations while the retractable outer mirror switch is in the AUTO position. Manual lock/unlock Key-linked lock/unlock Wireless door lock/unlock Wireless 30 seconds auto lock Entry lock/unlock Smart 30 seconds auto lock Reverse shift-linked function of mirrors Directs the mirror surface downward to improve visibility when driving in reverse after all the conditions below are met: The engine switch is on (IG). Shift lever is moved to R. The mirror select switch is in the R or L position. Mirror heater function Turns on the mirror heaters when the rear window defogger is turned on. The rear window defogger and mirror heaters automatically turn off after 15 minutes after the mirror heater was activated. The mirror heater continues to operate up to an additional 45 minutes if the following conditions are met. The outside temperature is -3°C (27°F) or below. The vehicle speed is 45 km/h (28 mph) or more. Automatic glare-resistant EC mirror function Reduces glare/reflection in the mirror during nighttime driving for safer driving conditions. Glare/reflection from vehicle headlights behind could blind the driver and cause dangerous driving conditions.
SYSTEM DESCRIPTION
When the mirror adjust switch is operated, the main body ECU (multiplex network body ECU) detects the switch operation and sends the mirror adjust switch signal to the outer mirror control ECU assembly (driver door) via CAN communication. On receiving the signal, the outer mirror control ECU assembly (driver door) operates the vertical and horizontal mirror motors, which are built into the outer rear view mirror assembly (driver door), to adjust the mirror surface position.
Scheme 1
When the mirror adjust switch is operated, the main body ECU (multiplex network body ECU) detects the switch operation and sends the mirror adjust switch signal to the outer mirror control ECU assembly (front passenger door) via CAN communication. On receiving the signal, the outer mirror control ECU assembly (front passenger door) operates the vertical and horizontal mirror motors, which are built into the outer rear view mirror assembly (front passenger door), to adjust the mirror surface position.
Scheme 2
The main body ECU (multiplex network body ECU) detects the mirror adjust switch status and sends the signal to each outer mirror control ECU assembly via CAN communication. Based on this signal, each outer mirror control ECU assembly operates the vertical and horizontal mirror motors to adjust the mirror surface position.
Scheme 3
DESCRIPTION
When the rear defogger switch is operated, the mirror heater signal is sent to the air conditioning amplifier assembly and then to each outer mirror control ECU assembly via CAN communication. Based on this signal, the outer mirror control ECU assemblies operate the mirror heaters.
Scheme 4
The main body ECU (multiplex network body ECU) receives the retractable outer mirror switch signal from the outer mirror switch assembly (retractable outer mirror switch). The main body ECU then sends the mirror retract/return signal to each outer mirror control ECU assembly via CAN communication. Based on this signal, each outer mirror control ECU assembly retracts or returns the outer rear view mirror assembly.
Scheme 5
The retractable outer mirror switch sends a voltage signal to the main body ECU (multiplex network body ECU) in accordance with switch operation (switch input signal). The main body ECU (multiplex network body ECU) uses CAN communication to send this information to the outer mirror control ECU assembly, which then controls the mirrors.
When the outer mirror control ECU assembly receives a door lock signal from the main body ECU (multiplex network body ECU) while the retractable outer mirror switch is in the AUTO position, the outer mirror control ECU assemblies operate the retract motors built into the outer rear view mirror assemblies to retract or return the outer rear view mirror assemblies.
Scheme 6
If either the M1, M2 or M3 seat memory switch is pressed, the outer mirror control ECU assembly (driver door) detects the switch operation and sends the seat memory switch signal to the main body ECU (multiplex network body ECU) via CAN communication. On receiving the seat memory switch signal, the main body ECU (multiplex network body ECU) sends the memory request signal to each outer mirror control ECU assembly via CAN communication. When receiving this signal, each outer mirror control ECU assembly stores the mirror surface position based on information from the mirror position sensor, which is built into the outer rear view mirror assembly.
HINT
Each outer rear view mirror assembly has a built-in mirror vertical position sensor and mirror horizontal position sensor.
Note. The mirror surface position will not be memorized if the engine switch is not on (IG). The mirror surface position will not be stored if the seat memory SET switch and 2 or more seat memory switches are pressed simultaneously. If the operation fails, the mirror surface position will not be memorized until the seat memory SET switch is released and the operation is attempted again. The mirror surface position will not be memorized when the mirror is operated manually.
Scheme 7
If either the M1, M2 or M3 seat memory switch is pressed, the outer mirror control ECU assembly (driver door) detects the seat memory switch status and sends the switch signal to the main body ECU (multiplex network body ECU) via CAN communication. The main body ECU (multiplex network body ECU) sends back reproduction signals to each outer mirror control ECU assembly via CAN communication. When receiving the reproduction signals, each outer mirror control ECU assembly operates the vertical and horizontal mirror motors, which are built into the outer rear view mirror assembly, to adjust the mirror surface to the stored position.
On receiving a reverse signal from the park/neutral position switch assembly, the ECM sends the reverse signal to the main body ECU (multiplex network body ECU) via CAN communication. When receiving the reverse signal, the main body ECU (multiplex network body ECU) sends the reverse request signal to each outer mirror control ECU. Each outer mirror control ECU then performs control in response to the reverse signal.
Scheme 8
Key IDs can be registered (linked) with either the M1, M2 or M3 seat memory switches. The key ID registration procedure should be performed while the electrical key transmitter sub-assembly is in the vehicle, the engine switch is on (IG), and the driver door is closed. When registration is completed, the buzzer will sound as an answerback.
When the vehicle doors are unlocked through wireless unlock or entry unlock operation, the certification ECU (smart key ECU assembly) sends the key ID signal and smart memory call request signal to the main body ECU (multiplex network body ECU). When the main body ECU (multiplex network body ECU) receives the signal and the driver door is opened, the ECU sends the memory call command signal for the received key ID to each outer mirror control ECU assembly. On receiving the memory call command signal, each outer mirror control ECU assembly moves the mirror surface to the stored position.
