Oem System Circuits: Wiring Lexus ES XV40 facelift

Body Electrical 8 illustrations

Junction Block and Wire Harness Connector

Code	See	Junction Block and Wire Harness (Connector Location)
1C	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Wire and Engine Room J/B (Engine Compartment Left)
1E	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1F	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
1G
3E	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3I
3Q
3R
3U
DA	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DB	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DI	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Connector Joining Wire Harness and Wire Harness

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1B
1D
1F	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
1G
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3B
3C
3D
3E
3G
3I
3K
3M
3N
3O
3P
3Q
3R
3S
3U
4B	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT

Code	See	Junction Block and Wire Harness (Connector Location)
4E	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4H
4I
DA	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DC
DD
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DI	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DJ	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DK
DM
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)
DP	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)
DR	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
AE5	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
BA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
BA2
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
EM2
EM3
EQ2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Roof Wire (Front Pillar LH)
HE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
HE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
HZ1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Front Door RH Wire and Electrical Key Wire Harness Front RH (Front Door Inner Panel RH)
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
Ia1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Front Door LH Wire and Electrical Key Wire Harness Front LH (Front Door Inner Panel LH)
JM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 1 Wire and Floor No. 2 Wire (Center Pillar RH)
Jb1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 1 Wire and Electrical Key Wire Harness Rear RH (Rear Door Inner Panel RH)
KL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 2 Wire and Floor Wire (Center Pillar LH)
Kc1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 2 Wire and Electrical Key Wire Harness Rear LH (Rear Door Inner Panel LH)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)

Code	See	Junction Block and Wire Harness (Connector Location)
1C	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Wire and Engine Room J/B (Engine Compartment Left)
1G	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3E	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3S	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)

Scheme 99

Scheme 99: Ignition

Scheme 99: Ignition

Scheme 100

Scheme 100

Scheme 100

Code	See	Junction Block and Wire Harness (Connector Location)
3I	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3U	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
BA3	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1D
1E
1G	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3D
3E
3F
3I
3J
3L
3P
3Q
3S
3U
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4E
4H
4I
4M
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DI	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Engine Room Main Wire (Cowl Side Right)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE5	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
BA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
BA2
BA3
BA4
BV1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Sensor Wire (Right Side of the Cylinder Block)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
LA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor Wire and Engine Room Main Wire (Cowl Side Left)

Code	See	Junction Block and Wire Harness (Connector Location)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3F
3G
3H
3J
3K
3L
3P
3U
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4E
4G
4I
4M
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
AE5	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
BA3	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
MT2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Front Seat RH Wire (Under the Front RH Seat)

Code	See	Junction Block and Wire Harness (Connector Location)
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4E
4K
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
LU1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor Wire and Front Seat LH Wire (Under the Front LH Seat)
MT1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Front Seat RH Wire (Under the Front RH Seat)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1B
1D
1E
1G	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3C
3D
3E
3I
3P
3Q
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4I	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
GE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel No. 3 Wire and Instrument Panel Wire (Instrument Panel Center)

Code	See	Junction Block and Wire Harness (Connector Location)
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3B
3D
3E
3G
3H
3I
3K
3N
3O
3P
3Q
3R
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4H
4I
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DK	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)
DP	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)
DR	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
EM2
EM3
EQ2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Roof Wire (Front Pillar LH)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
HE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
HE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
JM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 1 Wire and Floor No. 2 Wire (Center Pillar RH)
KL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 2 Wire and Floor Wire (Center Pillar LH)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)

Code	See	Junction Block and Wire Harness (Connector Location)
3C	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3P
3S
3T
3U
4G	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DI	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DL	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DP	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
HE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1F	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
1G
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3C
3D
3E
3F
3I
3P
3Q
3S
3T
3U
4A	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4B
4C
4D
4E
4F
4G
4H
4I
4K
4L
4M
DA	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
FE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel No. 2 Wire and Instrument Panel Wire (Under the Console Box)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1F	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
1G
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3C
3D
3E
3P
3Q
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4I	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DA	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DC
DD
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)
DP	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3F
3P
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4I
4M
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
LA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor Wire and Engine Room Main Wire (Cowl Side Left)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)

Code	See	Junction Block and Wire Harness (Connector Location)
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE3	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1F	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
1G
3	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3C
3D
3E
3I
3P
3Q
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4I	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DA	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DC
DD
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DI	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DL	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
1D	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1F	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
1G
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3C
3E
3P
3Q
DA	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
GE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel No. 3 Wire and Instrument Panel Wire (Instrument Panel Center)

Code	See	Junction Block and Wire Harness (Connector Location)
1D	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1F	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
1G
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3B
3C
3E
3G
3I
3P
3Q
DA	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1D
1G	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3C
3D
3E
3F
3I
3P
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4I
4M
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DP	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
LA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor Wire and Engine Room Main Wire (Cowl Side Left)
MA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Engine Room Main Wire (Cowl Side Right)
OM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor No. 4 Wire and Floor No. 2 Wire (Under the Rear Seat)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3C	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3D
3E
3F
3I
3J
3P
3Q
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4E
4H
4I
4J
4M
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DI	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EQ2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Roof Wire (Front Pillar LH)
GE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel No. 3 Wire and Instrument Panel Wire (Instrument Panel Center)

Code	See	Junction Block and Wire Harness (Connector Location)
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3B
3E
3M
3O
3Q
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DK	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DL
DM
DP	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
EL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
HE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
HE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
JM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 1 Wire and Floor No. 2 Wire (Center Pillar RH)
KL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 2 Wire and Floor Wire (Center Pillar LH)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3B
3D
3E
3G
3I
3M
3N
3O
3P
3Q
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4I	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DE	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DJ	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DK
DM
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)
DP	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)
DR	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
HE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
HE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
IE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
JM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 1 Wire and Floor No. 2 Wire (Center Pillar RH)
KL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 2 Wire and Floor Wire (Center Pillar LH)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1B
1D
1F	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
1G
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3B
3C
3D
3E
3G
3I
3K
3M
3N
3O
3Q
4B	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4C
4E
4H
4I
DA	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DK	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)
DP	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)
DR	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
EL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
EM2
EM3
EQ2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Roof Wire (Front Pillar LH)
GE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel No. 3 Wire and Instrument Panel Wire (Instrument Panel Center)
HE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
HE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
JM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 1 Wire and Floor No. 2 Wire (Center Pillar RH)
KL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 2 Wire and Floor Wire (Center Pillar LH)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1E
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3D
3E
3F
3I
3J
3L
3P
3Q
3S
3U
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4D
4E
4H
4I
4M
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DH
DI
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE5	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
BA3
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1E
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3D
3E
3F
3J
3K
3L
3P
3S
3U
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4D
4E
4I
4L
4M
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Engine Room Main Wire (Cowl Side Right)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
AE5	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
BA3
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
LA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor Wire and Engine Room Main Wire (Cowl Side Left)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1E
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3F
3J
3L
3P
3S
3U
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4D
4E
4I
4L
4M
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE5	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
BA3
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3C	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3D
3E
3F
3J
3K
3L
3O
3P
3S
3U
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4D
4I
4M
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE5	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
BA3
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Instrument Panel Wire (Near the Shift Lever)
LA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor Wire and Engine Room Main Wire (Cowl Side Left)
MA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Engine Room Main Wire (Cowl Side Right)
WM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Skid Control Sensor Wire Rear RH and Floor No. 2 Wire (Quarter Wheel House RH)
XL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Skid Control Sensor Wire Rear LH and Floor Wire (Quarter Wheel House LH)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3F
3G
3M
3P
3S
3T
3U
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4I
4M
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DE	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE4	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
ED1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Instrument Panel Wire Assembly (Instrument Panel Right)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
MT2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Front Seat RH Wire (Under the Front RH Seat)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3F
3G
3P
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4I
4M
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Floor No. 2 Wire (Right Kick Panel)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
LM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Floor No. 2 Wire (Under the Rear Seat)
MT2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Front Seat RH Wire (Under the Front RH Seat)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3F
3H
3J
3L
3P
3R
3S
4A	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4C
4E
4I
4M
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
3B	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3Q	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4K	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DL	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3B
3D
3E
3K
3O
3P
3Q
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4I	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DK	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM
DR

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
EQ2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Roof Wire (Front Pillar LH)
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS

Code	See	Junction Block and Wire Harness (Connector Location)
3B	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3F
3P
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4M	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DL	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3P
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4E
4H
4I
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
3B	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
4F	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4I	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DJ	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)

Code	See	Junction Block and Wire Harness (Connector Location)
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3B
3E
3I
3K
3P
4E	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4F	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)

Code	See	Junction Block and Wire Harness (Connector Location)
3F	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3G	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4M	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
LU1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor Wire and Front Seat LH Wire (Under the Front LH Seat)
MT1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Front Seat RH Wire (Under the Front RH Seat)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3G
3M
3P
3S
3T
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4G
4I
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DE	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
MT2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Front Seat RH Wire (Under the Front RH Seat)

Code	See	Junction Block and Wire Harness (Connector Location)
3B	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3F
3Q
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4M	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
LU1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor Wire and Front Seat LH Wire (Under the Front LH Seat)

Code	See	Junction Block and Wire Harness (Connector Location)
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
LU1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor Wire and Front Seat LH Wire (Under the Front LH Seat)

Code	See	Junction Block and Wire Harness (Connector Location)
3F	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3G	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4M	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
HE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
HE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
MA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Engine Room Main Wire (Cowl Side Right)
MT1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Front Seat RH Wire (Under the Front RH Seat)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
MA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Engine Room Main Wire (Cowl Side Right)
MT1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Front Seat RH Wire (Under the Front RH Seat)

Code	See	Junction Block and Wire Harness (Connector Location)
4A	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
FE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel No. 2 Wire and Instrument Panel Wire (Under the Console Box)
LU1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor Wire and Front Seat LH Wire (Under the Front LH Seat)
MT1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Front Seat RH Wire (Under the Front RH Seat)

Code	See	Junction Block and Wire Harness (Connector Location)
4A	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
FE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel No. 2 Wire and Instrument Panel Wire (Under the Console Box)
LU1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor Wire and Front Seat LH Wire (Under the Front LH Seat)
MT1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Front Seat RH Wire (Under the Front RH Seat)

Code	See	Junction Block and Wire Harness (Connector Location)
3K	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3N
3O
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DR	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EQ2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Roof Wire (Front Pillar LH)
HE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
IE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DR	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EQ2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Roof Wire (Front Pillar LH)

Code	See	Junction Block and Wire Harness (Connector Location)
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
FE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel No. 2 Wire and Instrument Panel Wire (Under the Console Box)

Code	See	Junction Block and Wire Harness (Connector Location)
1B	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1D
1G	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
4F	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4L	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DI	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)

Scheme 101

Scheme 101: Remote Control Mirror

Scheme 101: Remote Control Mirror

Scheme 102

Scheme 102

Scheme 102

Scheme 103

Scheme 103

Scheme 103

Scheme 104

Scheme 104

Scheme 104

Scheme 105

Scheme 105

Scheme 105

Scheme 106

Scheme 106

Scheme 106

Code	See	Junction Block and Wire Harness (Connector Location)
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3B
3E
3F
3N
3O
3P
3Q
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4E
4H
4M
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DK	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
HE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3D
3E
3J
3M
3P
3S
3U
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4I	J/B NO. 4 - INSTRUMENT PANEL RIGHT
DB	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DJ	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DK
DM
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
HE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
HE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
IE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS

Code	See	Junction Block and Wire Harness (Connector Location)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3F
3P
3T
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4I
4M
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3F
3G
3P
3S
4A	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4C
4I
4M
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Engine Room Main Wire (Cowl Side Right)
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
MA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Engine Room Main Wire (Cowl Side Right)
SM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Luggage Room No. 2 Wire and Floor No. 2 Wire (Right Side of the Lower Back Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
1G	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3F
3J
3P
3S
4B	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4C
4F
4I
4K
4M
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DE	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EM3	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
EQ2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Roof Wire (Front Pillar LH)
HE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3F
3J
3L
3P
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4D
4E
4G
4I
4J
4L
4M
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DH	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE3	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
BA2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
EM3	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
EQ2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Roof Wire (Front Pillar LH)
Ez1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and No. 1 Stereo Component Wire (Under the Console Box)
GE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel No. 3 Wire and Instrument Panel Wire (Instrument Panel Center)
HE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
JM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 1 Wire and Floor No. 2 Wire (Center Pillar RH)
KL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 2 Wire and Floor Wire (Center Pillar LH)
LM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Floor No. 2 Wire (Under the Rear Seat)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)
MA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Engine Room Main Wire (Cowl Side Right)
ME1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Instrument Panel Wire (Instrument Panel Right)
ZE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	No. 1 Stereo Component Wire and Instrument Panel Wire (Under the Console Box)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3F
3J
3P
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4D
4E
4I
4K
4L
4M
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EF1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Instrument Panel No. 2 Wire (Under the Console Box)
EM3	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
EQ2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Roof Wire (Front Pillar LH)
Ez1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and No. 1 Stereo Component Wire (Under the Console Box)
GE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel No. 3 Wire and Instrument Panel Wire (Instrument Panel Center)
HE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door RH Wire and Instrument Panel Wire (Right Kick Panel)
IE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Front Door LH Wire and Instrument Panel Wire (Left Kick Panel)
JM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 1 Wire and Floor No. 2 Wire (Center Pillar RH)
KL1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Rear Door No. 2 Wire and Floor Wire (Center Pillar LH)
LM1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Floor No. 2 Wire (Under the Rear Seat)
MA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Engine Room Main Wire (Cowl Side Right)
ME1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Instrument Panel Wire (Instrument Panel Right)
ZE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	No. 1 Stereo Component Wire and Instrument Panel Wire (Under the Console Box)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3B
3D
3E
3F
3G
3H
3I
3J
3P
3Q
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4D
4E
4G
4I
4J
4K
4L
4M
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DO	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Floor Wire and Instrument Panel J/B (Lower Finish Panel)

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
AE5	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
BA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
BA2
BA3
BA4
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
EL2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor Wire (Left Kick Panel)
EM2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Floor No. 2 Wire (Right Kick Panel)
LR1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Floor Wire and Luggage Room Wire (Roof Side Rear Inner Panel LH)
ME1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Floor No. 2 Wire and Instrument Panel Wire (Instrument Panel Right)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3D	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3E
3F
3J
3P
3S
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4E
4I
4M
DC	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Engine Room Main Wire (Cowl Side Right)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE5	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)

Code	See	Junction Block and Wire Harness (Connector Location)
1A	ENGINE ROOM R/B; : ENGINE ROOM J/B - ENGINE COMPARTMENT LEFT	Engine Room Main Wire and Engine Room J/B (Engine Compartment Left)
3A	J/B NO. 3 - INSTRUMENT PANEL LEFT	Instrument Panel Wire and J/B No. 3 (Instrument Panel Left)
3D
3E
3F
3H
3J
3M
3P
3S
3T
3U
4C	J/B NO. 4 - INSTRUMENT PANEL RIGHT	Instrument Panel Wire and J/B No. 4 (Instrument Panel Right)
4E
4I
4M
DD	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Engine Room Main Wire and Instrument Panel J/B (Lower Finish Panel)
DF	INSTRUMENT PANEL J/B - LOWER FINISH PANEL	Instrument Panel Wire and Instrument Panel J/B (Lower Finish Panel)
DG	INSTRUMENT PANEL J/B - LOWER FINISH PANEL
DM	INSTRUMENT PANEL J/B - LOWER FINISH PANEL

Code	See	Joining Wire Harness and Wire Harness (Connector Location)
AE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE2	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Left)
AE3	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Engine Room Main Wire and Instrument Panel Wire (Instrument Panel Right)
AE5	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
BA3	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS; : LOCATION OF GROUND POINTS	Engine Wire and Engine Room Main Wire (Inside of the Engine Room R/B and Engine Room J/B)
EA1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel Wire and Engine Room Main Wire (Left Kick Panel)
FE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel No. 2 Wire and Instrument Panel Wire (Under the Console Box)
GE1	LOCATION OF CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS	Instrument Panel No. 3 Wire and Instrument Panel Wire (Instrument Panel Center)
