Air Conditioning: Removal & Installation Lexus ES XV40

REMOVAL

1. RECOVER REFRIGERANT FROM REFRIGERATION SYSTEM (See «REPLACEMENT»(ref-283108-S11484630632008041700000) )
2. ALIGN FRONT WHEELS FACING STRAIGHT AHEAD
3. DISCONNECT BATTERY NEGATIVE TERMINAL NOTE: Wait for 90 seconds after disconnecting the terminal to prevent the airbag from deploying (See «AIRBAG SYSTEM»(ref-283084-S06808104192008041700000) )
4. REMOVE COOL AIR INTAKE DUCT SEAL (See «REMOVAL»(ref-283116-S42135128222008041700000) )
5. REMOVE HOOD HINGE COVER (for LH Side) (See «REMOVAL»(ref-283123-S18755761682008041700000) )
6. REMOVE HOOD HINGE COVER (for RH Side) (See «REMOVAL»(ref-283123-S18755761682008041700000) )
7. REMOVE ENGINE ROOM SIDE COVER LH (See «REMOVAL»(ref-283123-S18755761682008041700000) )
8. REMOVE ENGINE ROOM SIDE COVER RH (See «REMOVAL»(ref-283123-S18755761682008041700000) )
9. REMOVE AIR CLEANER CAP SUB-ASSEMBLY (See «REMOVAL»(ref-283100-S09855447692008041700000) )
10. REMOVE AIR CLEANER FILTER ELEMENT SUB-ASSEMBLY
11. REMOVE FRONT SUSPENSION UPPER CENTER BRACE (See «REMOVAL»(ref-283090-S09785113182008041700000) )
12. REMOVE FRONT WIPER ARM AND BLADE ASSEMBLY LH (See «REMOVAL»(ref-283123-S18755761682008041700000) )
13. REMOVE FRONT WIPER ARM AND BLADE ASSEMBLY RH (See «REMOVAL»(ref-283123-S18755761682008041700000) )
14. REMOVE COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY (See «REMOVAL»(ref-283123-S18755761682008041700000) )
15. REMOVE WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY (See «REMOVAL»(ref-283123-S18755761682008041700000) )
16. DISCONNECT SUCTION PIPE SUB-ASSEMBLY (See «REMOVAL»(ref-283108-S41068793822008041700000) )
17. DISCONNECT AIR CONDITIONER TUBE AND ACCESSORY (See «REMOVAL»(ref-283108-S41068793822008041700000) )
18. DISCONNECT HEATER OUTLET WATER HOSE (See «REMOVAL»(ref-283108-S41068793822008041700000) )
19. DISCONNECT HEATER INLET WATER HOSE (See «REMOVAL»(ref-283108-S41068793822008041700000) )
20. REMOVE LOWER NO. 3 STEERING WHEEL COVER (See «REMOVAL»(ref-283084-S07206761792008041700000) )
21. REMOVE LOWER NO. 2 STEERING WHEEL COVER (See «REMOVAL»(ref-283084-S07206761792008041700000) )
22. REMOVE STEERING PAD (See «REMOVAL»(ref-283084-S07206761792008041700000) )
23. REMOVE STEERING WHEEL ASSEMBLY (See «REMOVAL»(ref-283089-S28153843412008041700000) )
24. REMOVE FRONT DOOR SCUFF PLATE LH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
25. REMOVE FRONT DOOR OPENING TRIM COVER LH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
26. REMOVE SIDE INSTRUMENT PANEL LH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
27. REMOVE INSTRUMENT PANEL FINISH PANEL END LH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
28. REMOVE LOWER INSTRUMENT PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
29. REMOVE STEERING COLUMN COVER (See «REMOVAL»(ref-283109-S39106719462008041700000) )
30. REMOVE TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY (See «REMOVAL»(ref-283089-S28153843412008041700000) )
31. REMOVE TILT & TELESCOPIC SWITCH (See «REMOVAL»(ref-283089-S28153843412008041700000) )
32. REMOVE INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
33. REMOVE COMBINATION METER ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
34. REMOVE NO. 1 SWITCH HOLE BASE (See «REMOVAL»(ref-283109-S39106719462008041700000) )
35. REMOVE INSTRUMENT PANEL FINISH PANEL END RH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
36. REMOVE FRONT DOOR SCUFF PLATE RH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
37. REMOVE FRONT DOOR OPENING TRIM COVER RH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
38. REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
39. REMOVE SIDE INSTRUMENT PANEL RH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
40. REMOVE FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY (See «REMOVAL»(ref-283084-S03530163112008041700000) )
41. REMOVE LOWER INSTRUMENT PANEL RH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
42. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
43. REMOVE UPPER CONSOLE PANEL ASSEMBLY WITH FRONT ASH RECEPTACLE (See «REMOVAL»(ref-283109-S39106719462008041700000) )
44. REMOVE NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
45. REMOVE INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY (w/o Navigation System) (See «REMOVAL»(ref-283118-S05330376912008041700000) )
46. REMOVE MULTI-DISPLAY WITH RADIO RECEIVER ASSEMBLY (w/ Navigation System) (See «REMOVAL»(ref-283118-S05330376912008041700000) )
47. REMOVE HEATER SEAT SWITCH CONSOLE BASE (w/o Seat Heater System) (See «REMOVAL»(ref-283109-S39106719462008041700000) )
48. REMOVE HEATER SEAT SWITCH CONSOLE BASE (w/ Seat Heater System) (See «REMOVAL»(ref-283109-S39106719462008041700000) )
49. REMOVE CONSOLE BOX POCKET (See «REMOVAL»(ref-283109-S39106719462008041700000) )
50. REMOVE CONSOLE BOX CARPET (See «REMOVAL»(ref-283109-S39106719462008041700000) )
51. REMOVE CONSOLE REAR END PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
52. REMOVE REAR CONSOLE BOX ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
53. REMOVE FRONT PILLAR GARNISH LH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
54. REMOVE NO. 1 INSTRUMENT PANEL SPEAKER PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
55. REMOVE FRONT NO. 2 SPEAKER ASSEMBLY (for LH Side) (See «REMOVAL»(ref-283118-S31252883322008041700000) )
56. REMOVE NO. 1 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
57. REMOVE FRONT PILLAR GARNISH RH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
58. REMOVE NO. 2 INSTRUMENT PANEL SPEAKER PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
59. REMOVE FRONT NO. 2 SPEAKER ASSEMBLY (for RH Side) (See «REMOVAL»(ref-283109-S39106719462008041700000) )
60. REMOVE NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
61. REMOVE NO. 1 SPEAKER HOLE COVER (See «REMOVAL»(ref-283109-S39106719462008041700000) )
62. REMOVE FRONT STEREO COMPONENT SPEAKER ASSEMBLY (See «REMOVAL»(ref-283118-S24299402762008041700000) )
63. REMOVE NO. 1 INSTRUMENT PANEL MOUNTING BRACKET (See «REMOVAL»(ref-283109-S39106719462008041700000) )
64. REMOVE PUSH START SWITCH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
65. DISCONNECT INSTRUMENT PANEL WIRE ASSEMBLY (See «REMOVAL»(ref-283084-S39923556922008041700000) )
66. REMOVE ROOM TEMPERATURE SENSOR (See «REMOVAL»(ref-283108-S29434752532008041700000) )
67. REMOVE INSTRUMENT PANEL SAFETY PAD ASSEMBLY (w/o DVD Player) (See «REMOVAL»(ref-283109-S39106719462008041700000) )
68. REMOVE INSTRUMENT PANEL SAFETY PAD ASSEMBLY (w/ DVD Player) (See «REMOVAL»(ref-283109-S39106719462008041700000) )
69. REMOVE FLOOR CARPET BRACKET LH (See «REMOVAL»(ref-283108-S41068793822008041700000) )
70. REMOVE FLOOR CARPET BRACKET RH (See «REMOVAL»(ref-283108-S41068793822008041700000) )
71. REMOVE NO. 2 CONSOLE BOX DUCT (See «REMOVAL»(ref-283108-S41068793822008041700000) )
72. REMOVE NO. 3 CONSOLE BOX DUCT (See «REMOVAL»(ref-283108-S41068793822008041700000) )
73. REMOVE NO. 1 CONSOLE BOX DUCT (See «REMOVAL»(ref-283108-S41068793822008041700000) )
74. REMOVE REAR NO. 2 AIR DUCT (See «REMOVAL»(ref-283108-S41068793822008041700000) )
75. REMOVE REAR NO. 1 AIR DUCT (See «REMOVAL»(ref-283108-S41068793822008041700000) )
76. REMOVE NO. 1 AIR DUCT SUB-ASSEMBLY (See «REMOVAL»(ref-283089-S28153843412008041700000) )
77. SEPARATE STEERING INTERMEDIATE SHAFT ASSEMBLY (See «REMOVAL»(ref-283089-S28153843412008041700000) )
78. REMOVE STEERING COLUMN ASSEMBLY (See «DISASSEMBLY»(ref-283089-S25061384542008041700000) )
79. REMOVE AIR CONDITIONING AMPLIFIER ASSEMBLY (See «REMOVAL»(ref-283108-S08681489852008041700000) )
80. REMOVE INSTRUMENT PANEL REINFORCEMENT ASSEMBLY (See «REMOVAL»(ref-283108-S41068793822008041700000) )
81. REMOVE BLOWER ASSEMBLY Disconnect the connector. Remove the 2 screws and blower assembly.

Scheme 175

Scheme 176

Scheme 177

Scheme 178

Scheme 179

1. REMOVE AIR DUCT SUB-ASSEMBLY Release the 4 claws and remove the air duct sub-assembly.
2. REMOVE AIR FILTER COVER PLATE Release the 2 claws and remove the air filter cover plate.
3. REMOVE CLEAN AIR FILTER Remove the clean air filter as shown in the illustration.
4. REMOVE AIR INLET SERVO MOTOR Remove the 3 screws and air inlet servo motor.
5. REMOVE BLOWER WITH FAN MOTOR SUB-ASSEMBLY Remove the 3 screws and blower with fan motor sub-assembly.

Scheme 180

1. INSTALL BLOWER WITH FAN MOTOR SUB-ASSEMBLY Install the blower with fan motor sub-assembly with the 3 screws.
2. INSTALL AIR INLET SERVO MOTOR Install the air inlet servo motor with the 3 screws.
3. INSTALL CLEAN AIR FILTER Install the clean air filter as shown in the illustration.
4. INSTALL AIR FILTER COVER PLATE Engage the 2 claws to install the air filter cover plate.
5. INSTALL AIR DUCT SUB-ASSEMBLY Engage the 4 claws to install the air duct sub-assembly.

INSTALLATION

1. INSTALL BLOWER ASSEMBLY Install the blower assembly with the 2 screws. Connect the connector.
2. INSTALL INSTRUMENT PANEL REINFORCEMENT ASSEMBLY (See «INSTALLATION»(ref-283108-S27507012742008041700000) )
3. INSTALL AIR CONDITIONING AMPLIFIER ASSEMBLY (See «REMOVAL»(ref-283108-S08681489852008041700000) )
4. INSTALL STEERING COLUMN ASSEMBLY (See «INSTALLATION»(ref-283089-S19903248562008041700000) )
5. CONNECT STEERING INTERMEDIATE SHAFT ASSEMBLY (See «INSTALLATION»(ref-283089-S19903248562008041700000) )
6. INSTALL NO. 1 AIR DUCT SUB-ASSEMBLY (See «INSTALLATION»(ref-283089-S19903248562008041700000) )
7. INSTALL REAR NO. 1 AIR DUCT (See «INSTALLATION»(ref-283108-S27507012742008041700000) )
8. INSTALL REAR NO. 2 AIR DUCT (See «INSTALLATION»(ref-283108-S27507012742008041700000) )
9. INSTALL NO. 1 CONSOLE BOX DUCT (See «INSTALLATION»(ref-283108-S27507012742008041700000) )
10. INSTALL NO. 3 CONSOLE BOX DUCT (See «INSTALLATION»(ref-283108-S27507012742008041700000) )
11. INSTALL NO. 2 CONSOLE BOX DUCT (See «INSTALLATION»(ref-283108-S27507012742008041700000) )
12. INSTALL FLOOR CARPET BRACKET RH
13. INSTALL FLOOR CARPET BRACKET LH
14. INSTALL INSTRUMENT PANEL SAFETY PAD ASSEMBLY (w/o DVD Player) (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
15. INSTALL INSTRUMENT PANEL SAFETY PAD ASSEMBLY (w/ DVD Player) (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
16. INSTALL ROOM TEMPERATURE SENSOR (See «INSTALLATION»(ref-283108-S41444453192008041700000) )
17. CONNECT INSTRUMENT PANEL WIRE ASSEMBLY (See «INSTALLATION»(ref-283084-S03379903972008041700000) )
18. INSTALL PUSH START SWITCH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
19. INSTALL NO. 1 INSTRUMENT PANEL MOUNTING BRACKET (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
20. INSTALL FRONT STEREO COMPONENT SPEAKER ASSEMBLY (See «INSTALLATION»(ref-283118-S07980423762008041700000) )
21. INSTALL NO. 1 SPEAKER HOLE COVER (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
22. INSTALL NO. 1 INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
23. INSTALL FRONT NO. 2 SPEAKER ASSEMBLY (for LH Side) (See «INSTALLATION»(ref-283118-S04410051032008041700000) )
24. INSTALL NO. 1 INSTRUMENT PANEL SPEAKER PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
25. INSTALL FRONT PILLAR GARNISH LH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
26. INSTALL NO. 3 INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
27. INSTALL FRONT NO. 2 SPEAKER ASSEMBLY (for RH Side) (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
28. INSTALL NO. 2 INSTRUMENT PANEL SPEAKER PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
29. INSTALL FRONT PILLAR GARNISH RH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
30. INSTALL REAR CONSOLE BOX ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
31. INSTALL CONSOLE REAR END PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
32. INSTALL CONSOLE BOX CARPET (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
33. INSTALL CONSOLE BOX POCKET (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
34. INSTALL HEATER SEAT SWITCH CONSOLE BASE (w/o Seat Heater System) (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
35. INSTALL HEATER SEAT SWITCH CONSOLE BASE (w/ Seat Heater System) (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
36. INSTALL INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY (w/o Navigation System) (See «INSTALLATION»(ref-283118-S03159211972008041700000) )
37. INSTALL MULTI-DISPLAY WITH RADIO RECEIVER ASSEMBLY (w/ Navigation System) (See «INSTALLATION»(ref-283118-S03159211972008041700000) )
38. INSTALL NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
39. INSTALL UPPER CONSOLE PANEL ASSEMBLY WITH FRONT ASH RECEPTACLE (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
40. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
41. INSTALL LOWER INSTRUMENT PANEL RH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
42. INSTALL FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY (See «INSTALLATION»(ref-283084-S17962540712008041700000) )
43. INSTALL SIDE INSTRUMENT PANEL RH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
44. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
45. INSTALL FRONT DOOR OPENING TRIM COVER RH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
46. INSTALL FRONT DOOR SCUFF PLATE RH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
47. INSTALL INSTRUMENT PANEL FINISH PANEL END RH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
48. INSTALL NO. 1 SWITCH HOLE BASE (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
49. INSTALL COMBINATION METER ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
50. INSTALL INSTRUMENT CLUSTER FINISH PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
51. INSTALL TURN SIGNAL SWITCH ASSEMBLY WITH SPIRAL CABLE (See «INSTALLATION»(ref-283089-S19903248562008041700000) )
52. INSTALL TILT & TELESCOPIC SWITCH (See «INSTALLATION»(ref-283089-S19903248562008041700000) )
53. INSTALL STEERING COLUMN COVER (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
54. ADJUST SPIRAL CABLE SUB-ASSEMBLY (See «INSTALLATION»(ref-283084-S20058970502008041700000) )
55. INSTALL LOWER INSTRUMENT PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
56. INSTALL INSTRUMENT PANEL FINISH PANEL END LH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
57. INSTALL SIDE INSTRUMENT PANEL LH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
58. INSTALL FRONT DOOR OPENING TRIM COVER LH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
59. INSTALL FRONT DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
60. INSTALL STEERING WHEEL ASSEMBLY (See «INSTALLATION»(ref-283089-S19903248562008041700000) )
61. INSTALL STEERING PAD (See «INSTALLATION»(ref-283084-S18494394012008041700000) )
62. INSTALL LOWER NO. 3 STEERING WHEEL COVER (See «INSTALLATION»(ref-283084-S18494394012008041700000) )
63. INSTALL LOWER NO. 2 STEERING WHEEL COVER (See «INSTALLATION»(ref-283084-S18494394012008041700000) )
64. INSTALL HEATER INLET WATER HOSE (See «INSTALLATION»(ref-283108-S27507012742008041700000) )
65. INSTALL HEATER OUTLET WATER HOSE (See «INSTALLATION»(ref-283108-S27507012742008041700000) )
66. INSTALL AIR CONDITIONER TUBE AND ACCESSORY (See «INSTALLATION»(ref-283108-S27507012742008041700000) )
67. INSTALL SUCTION HOSE SUB-ASSEMBLY (See «INSTALLATION»(ref-283108-S27507012742008041700000) )
68. INSTALL WINDSHIELD WIPER MOTOR AND LINK ASSEMBLY (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
69. INSTALL FRONT FENDER TO COWL SIDE SEAL RH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
70. INSTALL FRONT FENDER TO COWL SIDE SEAL LH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
71. INSTALL COWL TOP VENTILATOR LOUVER SUB-ASSEMBLY (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
72. INSTALL FRONT WIPER ARM AND BLADE ASSEMBLY LH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
73. INSTALL FRONT WIPER ARM AND BLADE ASSEMBLY RH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
74. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
75. INSPECT STEERING PAD (See «INSTALLATION»(ref-283084-S18494394012008041700000) )
76. INSPECT FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY (See «ON-VEHICLE INSPECTION»(ref-283084-S12307634032008041700000) )
77. INSPECT SRS WARNING LIGHT Inspect the SRS warning light (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) ).
78. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery terminal (See «INITIALIZATION»(ref-283083-S29543038892008041700000) ).
79. ADD ENGINE COOLANT (See «ON-VEHICLE INSPECTION»(ref-283095-S36778739482008041700000) )
80. CHECK FOR ENGINE COOLANT LEAKS
81. CHARGE WITH REFRIGERANT (See «REPLACEMENT»(ref-283108-S11484630632008041700000) )
82. WARM UP COMPRESSOR (See «REPLACEMENT»(ref-283108-S11484630632008041700000) )
83. CHECK FOR REFRIGERANT LEAKS (See «REPLACEMENT»(ref-283108-S11484630632008041700000) )
84. INSTALL ENGINE ROOM SIDE COVER RH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
85. INSTALL ENGINE ROOM SIDE COVER LH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
86. INSTALL HOOD HINGE COVER (for RH Side) (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
87. INSTALL HOOD HINGE COVER (for LH Side) (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
88. INSTALL COOL AIR INTAKE DUCT SEAL (See «INSTALLATION»(ref-283116-S26519527622008041700000) )

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

1. RECOVER REFRIGERANT FROM REFRIGERATION SYSTEM (See «REPLACEMENT»(ref-283108-S11484630632008041700000) )
2. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL
3. REMOVE FRONT WHEEL RH
4. REMOVE FRONT FENDER APRON SEAL RH
5. REMOVE COOL AIR INTAKE DUCT SEAL (See «REMOVAL»(ref-283093-S19183759882008041700000) )
6. REMOVE ENGINE ROOM SIDE COVER LH (See «REMOVAL»(ref-283093-S19183759882008041700000) )
7. REMOVE ENGINE ROOM SIDE COVER RH (See «REMOVAL»(ref-283093-S19183759882008041700000) )
8. REMOVE V-BANK COVER SUB-ASSEMBLY (See «REMOVAL»(ref-283093-S19183759882008041700000) )
9. REMOVE FRONT WHEEL OPENING EXTENSION PAD LH
10. REMOVE FRONT WHEEL OPENING EXTENSION PAD RH
11. REMOVE ENGINE UNDER COVER LH
12. REMOVE ENGINE UNDER COVER RH
13. DRAIN ENGINE COOLANT (See «COOLANT»(ref-283095-S36931409572008041700000) )
14. REMOVE AIR CLEANER CAP SUB-ASSEMBLY (See «REMOVAL»(ref-283100-S09855447692008041700000) )
15. REMOVE NO. 2 AIR CLEANER INLET
16. REMOVE NO. 1 AIR CLEANER INLET
17. REMOVE FRONT BUMPER ASSEMBLY (See «DISASSEMBLY»(ref-283116-S04634594762008041700000) )
18. REMOVE FRONT BUMPER ENERGY ABSORBER
19. REMOVE MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) (See «REMOVAL»(ref-283119-S28432684002008041700000) )
20. SEPARATE RADIATOR RESERVE TANK HOSE (See «REMOVAL»(ref-283095-S15408234482008041700000) )
21. DISCONNECT RADIATOR HOSE INLET (See «REMOVAL»(ref-283095-S15408234482008041700000) )
22. DISCONNECT RADIATOR HOSE OUTLET (See «REMOVAL»(ref-283095-S15408234482008041700000) )
23. DISCONNECT NO. 1 OIL COOLER INLET HOSE (See «REMOVAL»(ref-283095-S15408234482008041700000) )
24. DISCONNECT NO. 1 OIL COOLER OUTLET HOSE (See «REMOVAL»(ref-283095-S15408234482008041700000) )
25. REMOVE RADIATOR SUPPORT UPPER (See «REMOVAL»(ref-283095-S15408234482008041700000) )
26. REMOVE FAN SHROUD (See «REMOVAL»(ref-283095-S15408234482008041700000) )
27. REMOVE RADIATOR ASSEMBLY (See «REMOVAL»(ref-283095-S15408234482008041700000) )
28. REMOVE V-RIBBED BELT (See «REMOVAL»(ref-283093-S00211596642008041700000) )
29. REMOVE GENERATOR ASSEMBLY (See «REMOVAL»(ref-283097-S02944761222008041700000) )
30. DISCONNECT NO. 1 COOLER REFRIGERANT DISCHARGE HOSE Remove the bolt and disconnect the No. 1 cooler refrigerant discharge hose from the compressor and pulley. Remove the O-ring from the No. 1 cooler refrigerant discharge hose. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent entry of moisture and foreign matter.
31. DISCONNECT NO. 1 COOLER REFRIGERANT SUCTION HOSE Remove the bolt and disconnect the No. 1 cooler refrigerant suction hose from the compressor and pulley. Remove the O-ring from the No. 1 cooler refrigerant suction hose. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent entry of moisture and foreign matter.
32. REMOVE COMPRESSOR AND MAGNETIC CLUTCH Disconnect the magnetic clutch connector. Remove the 4 bolts. Remove the compressor and magnetic clutch.

Scheme 188

Scheme 189

Scheme 190

1. REMOVE MAGNETIC CLUTCH ASSEMBLY Place the compressor and magnetic clutch in a vise. Using locking pliers, hold the magnetic clutch hub. Remove the bolt, magnetic clutch hub, and magnetic clutch washers. HINT: There is no set number of magnetic clutch washers because they are used for adjustment. Using a snap ring expander, remove the snap ring and then remove the magnetic clutch rotor. NOTE: Take care not to damage the seal cover of the bearing when removing the snap ring. Disconnect the connector. Remove the screw. Using a snap ring expander, remove the snap ring and magnetic clutch stator.

Scheme 191

Scheme 192

Scheme 193

Scheme 194

Scheme 195

1. INSPECT COMPRESSOR AND MAGNETIC CLUTCH (A/C LOCK SENSOR) Measure the resistance according to the value(s) in the table below. Standard resistance COMPRESSOR AND MAGNETIC CLUTCH (A/C LOCK SENSOR Tester Connection Condition Specified Condition 1 - 2 Always (at 20°C (68°F)) 165 to 205 ohms If the resistance is not as specified, replace the compressor and magnetic clutch.
2. INSPECT COMPRESSOR AND MAGNETIC CLUTCH (A/C COMPRESSOR SOLENOID) Measure the resistance according to the value(s) in the table below. Standard resistance COMPRESSOR AND MAGNETIC CLUTCH (A/C COMPRESSOR SOLENOID) Tester Connection Condition Specified Condition 2 - 1 20°C (68°F) 10 to 11 ohms If the resistance is not as specified, replace the compressor and magnetic clutch.
3. INSPECT COMPRESSOR AND MAGNETIC CLUTCH Disconnect the connector from the compressor and magnetic clutch. Disconnect the connector from the magnetic clutch. Measure the resistance according to the value(s) in the table below. Standard resistance COMPRESSOR AND MAGNETIC CLUTCH Tester Connection Condition Specified Condition A-3 - B-1 Always Below 1 ohms A-3 - Body ground Always 10 kohms or higher If the resistance is not as specified, replace the compressor and magnetic clutch.
4. INSPECT MAGNETIC CLUTCH Measure the resistance according to the value(s) in the table below. Standard resistance MAGNETIC CLUTCH Tester Connection Condition Specified Condition 1 - Body ground Always 3.4 to 3.8 ohms If the resistance is not as specified, replace the magnetic clutch. When connector terminal 1 is connected to the positive (+) battery terminal, check that the following occurs: 1) the magnetic clutch's operating sound can be heard, and 2) the magnetic clutch's hub and rotor lock. OK: 1): The magnetic clutch's operating sound can be heard. 2): The magnetic clutch's hub and rotor lock. If the result is not as specified, replace the magnetic clutch.

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

1. INSTALL MAGNETIC CLUTCH ASSEMBLY Install the magnetic clutch stator while aligning the protrusion on the stator with the notch on the air compressor assembly as shown in the illustration. Using a snap ring expander, install a new snap ring with the chamfered side facing up. NOTE: Take care not to damage the seal cover of the bearing when installing the snap ring. Connect the connector. Using a snap ring expander, install the magnetic clutch rotor and a new snap ring with the chamfered side facing up. NOTE: Do not expand the snap ring by more than 35.5 mm (1.39 in.) when installing it. Do not damage the seal cover of the bearing when installing the snap ring. Install the magnetic clutch washer and magnetic clutch hub. NOTE: Do not change the combination of the magnetic clutch washers used before disassembly. Using locking pliers, hold the magnetic clutch hub and install the bolt. Torque: 18 N*m (184 kgf*cm, 13 ft.*lbf) NOTE: Make sure that there is no foreign matter or oil on the compressor shaft, bolt, and clutch hub.
2. INSPECT MAGNETIC CLUTCH CLEARANCE Set the dial indicator to the magnetic clutch hub. Connect the battery positive lead to terminal 1 of the magnetic clutch connector, and the negative lead to the ground wire. Turn the magnetic clutch on and off and measure the clearance. Standard clearance: 0.26 to 0.60 mm (0.010 to 0.024 in.) If the measured value is not within the standard range, remove the magnetic clutch hub and adjust it with magnetic clutch washers. NOTE: Adjustment should be performed with 3 or less magnetic clutch washers. Remove the compressor and magnetic clutch from the vise.
3. ADJUST COMPRESSOR OIL LEVEL When replacing the compressor and magnetic clutch with a new one, gradually discharge the refrigerant gas from the service valve, and drain the following amount of oil from the new compressor and magnetic clutch before installation. Standard: (Oil capacity inside the new compressor and magnetic clutch: 130 + 15 cc (4.6 + 0.51 fl.oz.)) - (Remaining oil amount in the removed compressor and magnetic clutch) = (Oil amount to be removed from the new compressor when replacing) NOTE: When checking the compressor oil level, observe the precautions on the cooler removal/installation. If a new compressor and magnetic clutch are installed without removing some oil, due to the oil remaining in the pipes of the vehicle, the oil amount will be too large. This prevents heat exchange in the refrigerant cycle and causes refrigerant failure. If the volume of oil remaining in the removed compressor and magnetic clutch is too small, check for oil leakage. Be sure to use ND-OIL 8 or equivalent for compressor oil.

Scheme 201

Scheme 202

1. TEMPORARILY TIGHTEN COMPRESSOR AND MAGNETIC CLUTCH Temporarily install the compressor and magnetic clutch onto the bolt.
2. FULLY TIGHTEN COMPRESSOR AND MAGNETIC CLUTCH Install the compressor and magnetic clutch with the 4 bolts. Torque: 25 N*m (255 kgf*cm, 18 ft.*lbf) NOTE: Tighten the bolts in the order shown in the illustration to install the compressor and magnetic clutch.
3. INSTALL NO. 1 COOLER REFRIGERANT SUCTION HOSE Remove the attached vinyl tape from the hose. Apply sufficient compressor oil to a new O-ring and the fitting surface of the compressor and magnetic clutch. Compressor oil: ND-OIL 8 or equivalent Install the O-ring onto the No. 1 cooler refrigerant suction hose. Install the No. 1 cooler refrigerant suction hose onto the compressor and magnetic clutch with the bolt. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf)
4. INSTALL NO. 1 COOLER REFRIGERANT DISCHARGE HOSE Remove the attached vinyl tape from the hose. Apply sufficient compressor oil to a new O-ring and the fitting surface of the compressor and magnetic clutch. Compressor oil: ND-OIL 8 or equivalent Install the O-ring onto the No. 1 cooler refrigerant discharge hose sub-assembly. Install the No. 1 cooler refrigerant discharge hose onto the compressor and magnetic clutch with the bolt. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf)
5. INSTALL GENERATOR ASSEMBLY (See «INSTALLATION»(ref-283097-S22447610432008041700000) )
6. INSTALL V-RIBBED BELT (See «INSTALLATION»(ref-283093-S36814178942008041700000) )
7. INSTALL RADIATOR ASSEMBLY (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
8. INSTALL FAN SHROUD (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
9. INSTALL RADIATOR SUPPORT UPPER (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
10. CONNECT NO. 1 OIL COOLER OUTLET TUBE (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
11. CONNECT NO. 1 OIL COOLER INLET TUBE (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
12. CONNECT RADIATOR HOSE OUTLET (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
13. CONNECT RADIATOR HOSE INLET (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
14. CONNECT RADIATOR RESERVOIR TANK HOSE (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
15. INSTALL MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) (See «INSTALLATION»(ref-283119-S01020670112008041700000) )
16. INSTALL FRONT BUMPER ENERGY ABSORBER
17. INSTALL FRONT BUMPER ASSEMBLY (See «INSTALLATION»(ref-283116-S26519527622008041700000) )
18. INSTALL NO. 1 AIR CLEANER INLET (See «INSTALLATION»(ref-283093-S25114169122008041700000) )
19. INSTALL NO. 2 AIR CLEANER INLET (See «INSTALLATION»(ref-283093-S25114169122008041700000) )
20. INSTALL AIR CLEANER CAP SUB-ASSEMBLY (See «INSTALLATION»(ref-283100-S06986286212008041700000) )
21. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
22. ADD ENGINE COOLANT (See «ON-VEHICLE INSPECTION»(ref-283095-S36778739482008041700000) )
23. CHECK FOR ENGINE COOLANT LEAKS (See «COOLING SYSTEM»(ref-283095-S35963749672008041700000) )
24. CHARGE WITH REFRIGERANT (See «REPLACEMENT»(ref-283108-S11484630632008041700000) )
25. WARM UP COMPRESSOR (See «REPLACEMENT»(ref-283108-S11484630632008041700000) )
26. CHECK FOR REFRIGERANT LEAKS (See «REPLACEMENT»(ref-283108-S11484630632008041700000) )
27. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery terminal (See «INITIALIZATION»(ref-283083-S29543038892008041700000) ).
28. INSTALL COOL AIR INTAKE DUCT SEAL (See «INSTALLATION»(ref-283116-S26519527622008041700000) )
29. INSTALL ENGINE ROOM SIDE COVER LH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
30. INSTALL ENGINE ROOM SIDE COVER RH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
31. INSTALL V-BANK COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-283093-S25114169122008041700000) )
32. INSTALL ENGINE UNDER COVER LH
33. INSTALL ENGINE UNDER COVER RH
34. INSTALL FRONT WHEEL OPENING EXTENSION PAD LH
35. INSTALL FRONT WHEEL OPENING EXTENSION PAD RH
36. ADJUST MILLIMETER WAVE RADAR SENSOR (See «ADJUSTMENT»(ref-283119-S05554633662008041700000) )
37. VEHICLE PREPARATION FOR FOG LIGHT AIM ADJUSTMENT (See «ADJUSTMENT»(ref-283105-S02188119532008041700000) )
38. PREPARATION FOR FOG LIGHT AIMING (See «ADJUSTMENT»(ref-283105-S02188119532008041700000) )
39. FOG LIGHT AIMING INSPECTION (See «ADJUSTMENT»(ref-283105-S02188119532008041700000) )
40. FOG LIGHT AIMING ADJUSTMENT (See «REASSEMBLY»(ref-283105-S38489348292008041700000) )

Scheme 203

Scheme 204

Scheme 205

Scheme 206

Scheme 207

Scheme 208

1. RECOVER REFRIGERANT FROM REFRIGERATION SYSTEM (See «REPLACEMENT»(ref-283108-S11484630632008041700000) )
2. REMOVE FRONT WHEEL OPENING EXTENSION PAD LH
3. REMOVE FRONT WHEEL OPENING EXTENSION PAD RH
4. REMOVE ENGINE UNDER COVER LH
5. REMOVE ENGINE UNDER COVER RH
6. DRAIN ENGINE COOLANT (See «ON-VEHICLE INSPECTION»(ref-283095-S36778739482008041700000) )
7. REMOVE V-BANK COVER SUB-ASSEMBLY (See «REMOVAL»(ref-283093-S19183759882008041700000) )
8. REMOVE COOL AIR INTAKE DUCT SEAL (See «REMOVAL»(ref-283093-S19183759882008041700000) )
9. REMOVE ENGINE ROOM SIDE COVER LH (See «REMOVAL»(ref-283093-S19183759882008041700000) )
10. REMOVE ENGINE ROOM SIDE COVER RH (See «REMOVAL»(ref-283093-S19183759882008041700000) )
11. REMOVE AIR CLEANER CAP SUB-ASSEMBLY (See «REMOVAL»(ref-283100-S09855447692008041700000) )
12. REMOVE AIR CLEANER INLET SUB-ASSEMBLY (See «REMOVAL»(ref-283093-S19183759882008041700000) )
13. REMOVE NO. 1 AIR CLEANER INLET (See «REMOVAL»(ref-283093-S19183759882008041700000) )
14. REMOVE FRONT BUMPER ASSEMBLY (See «DISASSEMBLY»(ref-283116-S04634594762008041700000) )
15. REMOVE FRONT BUMPER ENERGY ABSORBER (See «DISASSEMBLY»(ref-283116-S04634594762008041700000) )
16. REMOVE MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) (See «REMOVAL»(ref-283119-S28432684002008041700000) )
17. SEPARATE RADIATOR RESERVE TANK HOSE (See «REMOVAL»(ref-283095-S15408234482008041700000) )
18. DISCONNECT RADIATOR HOSE INLET (See «REMOVAL»(ref-283095-S15408234482008041700000) )
19. DISCONNECT RADIATOR HOSE OUTLET (See «REMOVAL»(ref-283095-S15408234482008041700000) )
20. DISCONNECT NO. 1 OIL COOLER INLET HOSE (See «REMOVAL»(ref-283095-S15408234482008041700000) )
21. DISCONNECT NO. 1 OIL COOLER OUTLET HOSE (See «REMOVAL»(ref-283095-S15408234482008041700000) )
22. REMOVE RADIATOR SUPPORT UPPER (See «REMOVAL»(ref-283095-S15408234482008041700000) )
23. DISCONNECT LIQUID TUBE SUB-ASSEMBLY Remove the bolt and disconnect the liquid tube sub-assembly from the condenser. Remove the O-ring from the liquid tube sub-assembly. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent entry of moisture and foreign matter.
24. DISCONNECT COOLER REFRIGERANT DISCHARGE PIPE Remove the bolt and disconnect the cooler refrigerant discharge pipe from the condenser. Remove the O-ring from the cooler refrigerant discharge pipe. NOTE: Seal the openings of the disconnected parts using vinyl tape to prevent entry of moisture and foreign matter.
25. REMOVE COOLER CONDENSER ASSEMBLY Remove the 4 bolts and condenser.
26. REMOVE COOLER DRYER Using a 14 mm straight hexagon wrench, remove the cap from the modulator. Using pliers, remove the cooler dryer.

Scheme 209

1. INSTALL COOLER DRYER Using pliers, install the cooler dryer to the modulator. Apply sufficient compressor oil to an O-ring and cap fitting surface. Compressor oil: ND-OIL 8 or equivalent Using a straight hexagon wrench 14 mm, install the cap to the cooler condenser core. Torque: 2.9 N*m (30 kgf*cm, 26 in.*lbf)
2. INSTALL COOLER CONDENSER ASSEMBLY Install the cooler condenser assembly with the 4 bolts. Torque: 5.0 N*m (51 kgf*cm, 44 in.*lbf) HINT: If the condenser is replaced with a new one, add compressor oil to the new condenser. Capacity: 40cc(1.4fl. oz.) Compressor oil: ND-8 or equivalent
3. INSTALL COOLER REFRIGERANT DISCHARGE PIPE Remove the attached vinyl tape from the pipe and the connecting part of the cooler condenser assembly. Sufficiently apply compressor oil to a new O-ring and the fitting surface of the pipe joint. Compressor oil: ND-OIL 8 or equivalent Install the O-ring on the cooler refrigerant discharge pipe. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf)
4. INSTALL LIQUID TUBE SUB-ASSEMBLY Remove the attached vinyl tape from the tube and the connecting part of the cooler condenser assembly. Sufficiently apply compressor oil to a new O-ring and the fitting surface of the tube joint. Compressor oil: ND-OIL 8 or equivalent Install the O-ring on the liquid tube sub-assembly. Install the liquid tube sub-assembly on the cooler condenser assembly with the bolt. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf)
5. INSTALL RADIATOR SUPPORT UPPER (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
6. CONNECT NO. 1 OIL COOLER OUTLET TUBE (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
7. CONNECT NO. 1 OIL COOLER INLET TUBE (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
8. CONNECT RADIATOR HOSE OUTLET (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
9. CONNECT RADIATOR HOSE INLET (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
10. CONNECT RADIATOR RESERVOIR TANK HOSE (See «INSTALLATION»(ref-283095-S34241682862008041700000) )
11. INSTALL MILLIMETER WAVE RADAR SENSOR ASSEMBLY (w/ Dynamic Radar Cruise Control System) (See «INSTALLATION»(ref-283119-S01020670112008041700000) )
12. INSTALL FRONT BUMPER ENERGY ABSORBER (See «REASSEMBLY»(ref-283116-S12947305112008041700000) )
13. INSTALL FRONT BUMPER ASSEMBLY (See «INSTALLATION»(ref-283116-S26519527622008041700000) )
14. INSTALL NO. 1 AIR CLEANER INLET (See «INSTALLATION»(ref-283093-S25114169122008041700000) )
15. INSTALL AIR CLEANER INLET SUB-ASSEMBLY (See «INSTALLATION»(ref-283093-S25114169122008041700000) )
16. INSTALL AIR CLEANER CAP SUB-ASSEMBLY (See «INSTALLATION»(ref-283100-S06986286212008041700000) )
17. ADD ENGINE COOLANT (See «ON-VEHICLE INSPECTION»(ref-283095-S36778739482008041700000) )
18. CHECK FOR ENGINE COOLANT LEAKS (See «ON-VEHICLE INSPECTION»(ref-283095-S01427015922008041700000) )
19. CHARGE WITH REFRIGERANT (See «REPLACEMENT»(ref-283108-S11484630632008041700000) )
20. WARM UP COMPRESSOR (See «REPLACEMENT»(ref-283108-S11484630632008041700000) )
21. CHECK FOR REFRIGERANT LEAKS (See «REPLACEMENT»(ref-283108-S11484630632008041700000) )
22. INSTALL COOL AIR INTAKE DUCT SEAL (See «INSTALLATION»(ref-283093-S25114169122008041700000) )
23. INSTALL ENGINE ROOM SIDE COVER LH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
24. INSTALL ENGINE ROOM SIDE COVER RH (See «INSTALLATION»(ref-283123-S10239775612008041700000) )
25. INSTALL V-BANK COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-283093-S25114169122008041700000) )
26. INSTALL ENGINE UNDER COVER LH
27. INSTALL ENGINE UNDER COVER RH
28. INSTALL FRONT WHEEL OPENING EXTENSION PAD LH
29. INSTALL FRONT WHEEL OPENING EXTENSION PAD RH
30. ADJUST MILLIMETER WAVE RADAR SENSOR (w/ Dynamic Radar Cruise Control System) (See «ADJUSTMENT»(ref-283119-S05554633662008041700000) )
31. VEHICLE PREPARATION FOR FOG LIGHT AIM ADJUSTMENT (See «ADJUSTMENT»(ref-283105-S02188119532008041700000) )
32. PREPARATION FOR FOG LIGHT AIMING (See «ADJUSTMENT»(ref-283105-S02188119532008041700000) )
33. FOG LIGHT AIMING INSPECTION (See «ADJUSTMENT»(ref-283105-S02188119532008041700000) )
34. FOG LIGHT AIMING ADJUSTMENT (See «ADJUSTMENT»(ref-283105-S02188119532008041700000) )

Scheme 210

Scheme 211

1. REMOVE FRONT DOOR SCUFF PLATE LH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
2. REMOVE FRONT DOOR OPENING TRIM COVER LH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
3. REMOVE SIDE INSTRUMENT PANEL LH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
4. REMOVE INSTRUMENT PANEL FINISH PANEL END LH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
5. REMOVE LOWER INSTRUMENT PANEL SUB-ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
6. REMOVE ROOM TEMPERATURE SENSOR Disconnect the connector and air hose. Release the claw and remove the sensor.

Scheme 212

1. INSPECT ROOM TEMPERATURE SENSOR Measure the resistance according to the value(s) in the table below. Standard resistance ROOM TEMPERATURE SENSOR Tester Connection Condition Specified Condition 1 - 2 10°C (50°F) 3.00 to 3.73 kohms 1 - 2 15°C (59°F) 2.45 to 2.88 kohms 1 - 2 20°C (68°F) 1.95 to 2.30 kohms 1 - 2 15°C (77°F) 1.60 to 1.80 kohms 1 - 2 30°C (86°F) 1.28 to 1.47 kohms 1 - 2 35°C (95°F) 1.00 to 1.22 kohms 1 - 2 40°C (104°F) 0.80 to 1.00 kohms 1 - 2 45°C (113°F) 0.65 to 0.85 kohms 1 - 2 50°C (122°F) 0.50 to 0.70 kohms 1 - 2 55°C (131°F) 0.44 to 0.60 kohms 1 - 2 60°C (140°F) 0.36 to 0.50 kohms NOTE: Hold the sensor only by its connector. Touching the sensor may change the resistance value. When measuring, the sensor temperature must be the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (Scheme 212) If the resistance is not as specified, replace the room temperature sensor.

1. INSTALL ROOM TEMPERATURE SENSOR Engage the claw to install the sensor. Connect the connector and attach the air hose.
2. INSTALL LOWER INSTRUMENT PANEL SUB-ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
3. INSTALL INSTRUMENT PANEL FINISH PANEL END LH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
4. INSTALL SIDE INSTRUMENT PANEL LH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
5. INSTALL FRONT DOOR OPENING TRIM COVER LH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
6. INSTALL FRONT DOOR SCUFF PLATE LH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )

Scheme 213

Scheme 214

1. REMOVE COOL AIR INTAKE DUCT SEAL (See «REMOVAL»(ref-283116-S42135128222008041700000) )
2. REMOVE FRONT BUMPER ASSEMBLY (See «DISASSEMBLY»(ref-283116-S04634594762008041700000) )
3. REMOVE AMBIENT TEMPERATURE SENSOR Disconnect the connector and detach the clamp. Remove the ambient temperature sensor.

Scheme 215

1. INSPECT AMBIENT TEMPERATURE SENSOR Measure the resistance according to the value(s) in the table below. Standard resistance AMBIENT TEMPERATURE SENSOR Tester Connection Condition Specified Condition 1 - 2 10°C (50°F) 3.00 to 3.73 kohms 1 - 2 15°C (59°F) 2.45 to 2.88 kohms 1 - 2 20°C (68°F) 1.95 to 2.30 kohms 1 - 2 25°C (77°F) 1.60 to 1.80 kohms 1 - 2 30°C (86°F) 1.28 to 1.47 kohms 1 - 2 35°C (95°F) 1.00 to 1.22 kohms 1 - 2 40°C (104°F) 0.80 to 1.00 kohms 1 - 2 45°C (113°F) 0.65 to 0.85 kohms 1 - 2 50°C (122°F) 0.50 to 0.70 kohms 1 - 2 55°C (131°F) 0.44 to 0.60 kohms 1 - 2 60°C (140°F) 0.36 to 0.50 kohms NOTE: Even slightly touching the sensor may change the resistance value. Be sure to hold the connector of the sensor. When measuring, the sensor temperature must be the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (Scheme 215) If the resistance is not as specified, replace the ambient temperature sensor.

1. INSTALL AMBIENT TEMPERATURE SENSOR Install the ambient temperature sensor with the clamp. Connect the connector.
2. INSTALL FRONT BUMPER ASSEMBLY (See «INSTALLATION»(ref-283116-S26519527622008041700000) )
3. INSTALL COOL AIR INTAKE DUCT SEAL (See «INSTALLATION»(ref-283116-S26519527622008041700000) )

Scheme 216

1. INSPECT EVAPORATOR TEMPERATURE SENSOR Measure the resistance according to the value(s) in the table below. Standard resistance EVAPORATOR TEMPERATURE SENSOR Tester Connection Condition Specified Condition 5 - 6 -10°C (14°F) 7.30 to 9.10 kohms 5 - 6 -5°C (23°F) 5.65 to 6.95 kohms 5 - 6 0°C (32°F) 4.40 to 5.35 kohms 5 - 6 5°C (41°F) 3.40 to 4.15 kohms 5 - 6 10°C (50°F) 2.70 to 3.25 kohms 5 - 6 15°C (59°F) 2.14 to 2.58 kohms 5 - 6 20°C (68°F) 1.71 to 2.05 kohms 5 - 6 25°C (77°F) 1.38 to 1.64 kohms 5 - 6 30°C (86°F) 1.11 to 1.32 kohms NOTE: Even slightly touching the sensor may change the resistance value. Be sure to hold the connector of the sensor. When measuring, the sensor temperature must be the same as the ambient temperature. HINT: As the temperature increases, the resistance decreases (Scheme 216) If the resistance is not as specified, replace the air conditioning harness (evaporator temperature sensor).

Scheme 217

Scheme 218

1. REMOVE COOL AIR INTAKE DUCT SEAL (See «REMOVAL»(ref-283116-S42135128222008041700000) )
2. REMOVE SMOG VENTILATION SENSOR Disconnect the connector. Remove the bolt and smog ventilation sensor.

Scheme 219

Scheme 220

1. INSPECT SMOG VENTILATION SENSOR HC, CO Apply battery voltage between terminals 3 (IG) and 6 (E). Allow exhaust gas (HC, CO) to travel to the sensing portion of the smog ventilation sensor, and measure the resistance between terminals 1 (SG) and 2 (DGS). OK: When the sensor is exposed to the exhaust gas, the resistance increases. HINT: The resistance before blowing exhaust gas is 10kohms to 40kohms. If the resistance is not as specified, replace the smog ventilation sensor. NOx Apply battery voltage between terminals 3 (IG) and 6 (E). Allow exhaust gas (NOx) to travel to the sensing portion of the smog ventilation sensor, and measure the resistance between terminals 1 (SG) and 4 (DGS1). OK: When the sensor is exposed to the exhaust gas, the resistance increases. HINT: The resistance before blowing exhaust gas is 10kohms to 40kohms. If the resistance is not as specified, replace the smog ventilation sensor.

1. INSTALL SMOG VENTILATION SENSOR Install the smog ventilation sensor with the bolt. Torque: 9.8 N*m (100 kgf*cm, 87 in.*lbf) Connect the connector.
2. INSTALL COOL AIR INTAKE DUCT SEAL (See «INSTALLATION»(ref-283116-S26519527622008041700000) )

Scheme 221

1. INSPECT PRESSURE SENSOR Install the manifold gauge set (See «ON-VEHICLE INSPECTION»(ref-283108-S07691190632008041700000) ). Connect the three 1.5 V dry cell batterie's positive (+) lead to terminal 3 and the negative (-) lead to terminal 1. Then connect the voltmeter's positive (+) lead to terminal 2 and the negative (-) lead to terminal 1. Measure the voltage. OK: The voltage changes according to refrigerant pressure, as shown in the graph. If the voltage is not as specified, replace the pressure sensor.

Scheme 222

Scheme 223

Scheme 224

1. REMOVE SHIFT LEVER KNOB SUB-ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
2. REMOVE UPPER CONSOLE PANEL SUB-ASSEMBLY WITH FRONT ASH RECEPTACLE (See «REMOVAL»(ref-283109-S39106719462008041700000) )
3. REMOVE INSTRUMENT PANEL FINISH PANEL END LH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
4. REMOVE INSTRUMENT PANEL FINISH PANEL END RH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
5. REMOVE NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
6. REMOVE INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY (See «REMOVAL»(ref-283118-S05330376912008041700000) )
7. REMOVE NO. 1 RADIO BRACKET (See «REMOVAL»(ref-283118-S05330376912008041700000) )
8. REMOVE NO. 2 RADIO BRACKET (See «REMOVAL»(ref-283118-S05330376912008041700000) )
9. REMOVE RADIO RECEIVER ASSEMBLY (See «REMOVAL»(ref-283118-S05330376912008041700000) )

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

1. REMOVE HEATER CONTROL ORNAMENT LH Remove the 5 screws and heater control ornament LH.
2. REMOVE HEATER CONTROL ORNAMENT RH Remove the 5 screws and heater control ornament RH.
3. REMOVE HEATER CONTROL HOUSING SUB-ASSEMBLY Remove the 4 screws and disengage the 4 claws. Remove the heater control housing sub-assembly.
4. REMOVE CENTER CLUSTER MODULE CONTROL ASSEMBLY NOTE: When disassembling the center cluster module control assembly, eliminate static electricity by touching the vehicle body to prevent the components from being damaged. Remove the 9 screws and center cluster module control assembly. NOTE: Do not drop the switches or buttons.
5. REMOVE AIR CONDITIONING PANEL SUB-ASSEMBLY LH Remove the screw and air conditioning panel sub-assembly LH.
6. REMOVE AIR CONDITIONING PANEL SUB-ASSEMBLY RH Remove the screw and air conditioning panel sub-assembly RH.

Scheme 231

Scheme 232

Scheme 233

1. INSTALL CENTER CLUSTER MODULE CONTROL ASSEMBLY NOTE: When reassembling the center cluster module control assembly, eliminate static electricity by touching the vehicle body to prevent the components from being damaged. Install the center cluster module control assembly with the 5 screws.
2. INSTALL AIR CONDITIONING PANEL SUB-ASSEMBLY RH Install the air conditioning panel sub-assembly RH with the 3 screws.
3. INSTALL AIR CONDITIONING PANEL SUB-ASSEMBLY LH Install the air conditioning panel sub-assembly LH with the 3 screws.
4. INSTALL HEATER CONTROL HOUSING SUB-ASSEMBLY Engage the 4 claws and install the heater control housing sub-assembly with the 4 screws.
5. INSTALL HEATER CONTROL ORNAMENT LH Install the heater control ornament LH with the 5 screws.
6. INSTALL HEATER CONTROL ORNAMENT RH Install the heater control ornament RH with the 5 screws.

1. INSTALL RADIO RECEIVER ASSEMBLY (See «INSTALLATION»(ref-283118-S03159211972008041700000) )
2. INSTALL NO. 2 RADIO BRACKET (See «INSTALLATION»(ref-283118-S03159211972008041700000) )
3. INSTALL NO. 1 RADIO BRACKET (See «INSTALLATION»(ref-283118-S03159211972008041700000) )
4. INSTALL INTEGRATION CONTROL PANEL WITH RADIO RECEIVER ASSEMBLY (See «INSTALLATION»(ref-283118-S03159211972008041700000) )
5. INSTALL INSTRUMENT PANEL FINISH PANEL END LH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
6. INSTALL INSTRUMENT PANEL FINISH PANEL END RH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
7. INSTALL UPPER CONSOLE PANEL SUB-ASSEMBLY WITH FRONT ASH RECEPTACLE (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
8. INSTALL NO. 2 INSTRUMENT PANEL REGISTER ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
9. INSTALL SHIFT LEVER KNOB SUB-ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
10. ADJUST CLOCK

Scheme 234

Scheme 235

1. DISCONNECT CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: Wait for 90 seconds after disconnecting the cable to prevent airbag deployment (See «AIRBAG SYSTEM»(ref-283084-S06808104192008041700000) ).
2. REMOVE FRONT DOOR SCUFF PLATE RH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
3. REMOVE FRONT DOOR OPENING TRIM COVER RH (See «REMOVAL»(ref-283110-S29464350012008041700000) )
4. REMOVE NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «REMOVAL»(ref-283109-S39106719462008041700000) )
5. REMOVE SIDE INSTRUMENT PANEL RH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
6. REMOVE FRONT PASSENGER SIDE KNEE AIR BAG ASSEMBLY (See «REMOVAL»(ref-283084-S03530163112008041700000) )
7. REMOVE LOWER INSTRUMENT PANEL RH (See «REMOVAL»(ref-283109-S39106719462008041700000) )
8. REMOVE AIR CONDITIONING AMPLIFIER ASSEMBLY Disconnect the 3 connectors. Remove the 2 bolts and air conditioning amplifier assembly.

1. INSTALL AIR CONDITIONING AMPLIFIER ASSEMBLY Install the air conditioning amplifier assembly with the 2 bolts. Connect the 3 connectors.
2. INSTALL LOWER INSTRUMENT PANEL RH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
3. INSTALL FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY (See «INSTALLATION»(ref-283084-S17962540712008041700000) )
4. INSTALL SIDE INSTRUMENT PANEL RH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
5. INSTALL NO. 2 INSTRUMENT PANEL UNDER COVER SUB-ASSEMBLY (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
6. INSTALL FRONT DOOR OPENING TRIM COVER RH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
7. INSTALL FRONT DOOR SCUFF PLATE RH (See «INSTALLATION»(ref-283110-S31613301962008041700000) )
8. INSTALL INSTRUMENT PANEL FINISH PANEL END RH (See «INSTALLATION»(ref-283109-S06931105292008041700000) )
9. CONNECT CABLE TO NEGATIVE BATTERY TERMINAL
10. INSPECT FRONT PASSENGER SIDE KNEE AIRBAG ASSEMBLY (See «ON-VEHICLE INSPECTION»(ref-283084-S12307634032008041700000) )
11. INSPECT SRS WARNING LIGHT Inspect the SRS warning light (See «DIAGNOSIS SYSTEM»(ref-283084-S16988396502008041700000) ).
12. PERFORM INITIALIZATION NOTE: Some systems need initialization after reconnecting the negative battery terminal (See «INITIALIZATION»(ref-283083-S29543038892008041700000) ).
